T3
R
OPERATOR’S MANUAL
FLASHLIGHT
1
Quick start guide
..................
2
Flashlight's structure
..............
3,4
T3 flashlight feature
...............
5
Instruction
......................
6
Notice and maintenance
...............
7
Lifetime warranty / About NT123A battery
.......
8
Battery safety guide
... . . ........... .
9
Accessories
....................
10
English
Index
Congratulations on purchasing our NexTORCH
flashlight. You have chosen high quality product
designed from the latest technology. For the best
use of this product, please read the instruction
manual carefully.
尊敬的客户，恭喜您拥有了纳丽德手电筒。它选用
最好的材料，经过科学的设计，精密的制造工艺，呈现
在您的面前。为了您能对我们的产品有全面的了解，请
仔细阅读我们为您准备的《使用手册》。
CONTENTS
内容
English
...........................................
1
中文版
...........................................
11
Step 1: Remove the lamp assembly by unscrewing
it anti-clockwise.
Step 2: Insert the batteries correctly by placing
the negative side in first.
Step 3: Screw the lamp assembly on.
3W LUXEON LED
LITHIUM BATTERIES
NT123A
RUBBER
TAILCAP
CAUDAL PAN
O-RING
O-RING
BRAINPAN
REFLECTOR
POLYCARBONATE LENS
BARREL
5
T3 FLASHLIGHT FEATURES
Product Model
Bulb
Battery
Material
Lens’ Material
Runtime
Dimensions
Weight
Special Features
T3
3 Watt LUXEON LED,
Max output 60 lumens
2 NT123A 3V Lithium Batteries
Aerospace grade aluminum 6061-T6
with Mil-Spec typeⅢhard-anodized
finish
Anti-scratch Polycarbonate
Up to 150 Minutes
Length 126mm
Barrel diameter 22mm
Head diameter 27mm
65g（batteries excluded）
Compact size, click tailcap, patent
anti-rolling structure, watertight
structure. Mil-spec hard-anodized
typeⅢfinish
BATTERIES INSTALLING
ON/OFF
Unscrew the lamp assembly, put the NT123A batteries into the barrel
with proper polarity, install the lamp assembly back on to the barrel.
Press the rubber tailcap until you hear audible click
to turn your flashlight on. You can turn it off in the same way.
Thank you for choosing NexTORCH
flashlight. It produces
not only brilliant, extraordinary white light, but also a lot of heat.
In case of damaging your flashlight and the things around the
flashlight, please pay attention to the following:
1.
Do not put the the head of fl as hl ig ht straight on the flat,
which would damage the bulb or even cause a fire as the
heat can't release from the flashlight.
2. Do not shine the eyes straight as the powerful light could
cause a permanent injury.
3. Do not dismantle the bulb assembly.
4. Tactical flashlight is intended for short term usage and
should not be used for more than 15 minutes continuously.
NOTICE
MAINTENANCE
To keep your flashlight always in a perfect condition, follow
the instructions as below.
1. Clean your flashlight with a soft clean cloth (N e xTORCH
offers you a professional lens cleaning tool(I t em #LC6).
Please check the accessories right after this instruction).
2. Wash the flashlight (make sure the flashlight is well screwed
on and no water can sink in) by clean water after using in
the seawater or causticity liquid, and dry it by hot air.
3.
When the tailcap doesn't rotate smoothly, lay on some silicone
grease on the "O" ring (you can buy the silicon grease
(Item# SL6)in the outdoor shops, most of the hardware
shops or our retail shops that sell the NexTORCH
flashlights)
.
4.
Please release the battery and keep them dry and cool
when you wouldn't use the flashlight for a time.
NexTORCH guarantees that all products under NexTORCH brand
are free from manufacture defects. NexTORCH will repair or
replace any defective products,Please contact your local dealer
or e-mail to
info@nextorch.com.
This warranty excludes the following:
1). Failure of product due to misuse and/or lack of maintenance.
2). Internal water damage.
NexTORCH LIFETIME WARRANTY
9
READ THE FOLLOWING BEFORE USING
It is strongly recommend that the user takes the following
precautions to avoid fire, violent rupture, personal injury
or death when using the Lithium-Manganese Dioxide
Cylindrical Batteries.
NT123A, NT2 Lithium Battery Safety Guide
HANDLE WITH CARE
If liquid discharged from a lithium battery comes in contact with
clothing, rinse well with water. If the
discharged liquid comes into
contact with eyes or skin, rinse immediately with water and seek
medical
attention if necessary.
DO NOT HEAT OR DISPOSE OF THEM IN A FIRE
When heated, lithium batteries may leak. When short circuited,
they may burst or combust. If
disposed of them in a fire, they
may
violently rupture, causing personal injury.
DO NOT CHARGE
Charging a lithium battery may cause swelling, over heating,
leakage, violent rupture or fire.
DO NOT FORCED DISCHARGE
Forced discharge may result in swelling, overheating, leakage,
violent rupture or fire.
DO NOT SHORT CIRCUIT
Short circuiting a lithium battery may lead to swelling, overheating,
leakage, violent rupture or fire.
DO NOT DISASSEMBLE, PERFORATE, DEFORM OR APPLY MECHANICAL PRESSURE
Disassembly or perforation of a lithium battery may lead to generation
of gas or overheating. Pressure or
deformation may lead to an
internal short circuit.
DO NOT USE WITH OTHER TYPES OF BATTERIES OR OLDER LITHIUM BATTERIES
Different types of batteries or older lithium batteries may exhibit
different voltage or capacity characteristics.
Using with a new lithium battery may cause over discharge, resulting in swelling,
overheating, leakage,
violent rupture or fire.
OBSERVE THE PROPER POLARITY
If a lithium battery is inserted backwards, the resulting polarity reversal may lead to a short circuit or
over charging. This can
cause swelling, overheating, leakage, violent rupture or fire.
DO NOT SWALLOW OR TAKE INTERNALLY
Always store batteries out of the reach of children and assure that
batteries cannot be easily removed
from equipment. If lithium
batteries are swallowed, seek immediate medical attention.
STORE BATTERIES PROPERLY
Store lithium batteries in a cool, dry place out of direct sunlight.
Excessive moisture or humidity may lead
to deterioration, corrosion
and generation of combustible gas.
DO NOT SOLDER OR WELD ON THE BATTERY SURFACE DISPOSAL
Recycle used lithium batteries. Do not dispose of them in the
trash.
10
LC6
NT123A
LITHIUM BATTERY NT123A
ACCESSORIES
LENS CLEANER
NexTORCH
offers a full range of product accessories
suited for your flashlight.
SL6
SILICONE GREASE
V1335 V1438
HOLSTER
11
T3快速安装指引
..................
12
T3电筒结构
...................
13,14
T3电筒具体参数
.................
15
T3使用方法
.....................
16
T3使用注意事项及T3保养注意事项
..........
17
关于NT123A锂电池及安全使用指引
..........
18
附件
.........................
19
索引
12
第一步：拧开灯头。
第二步：插入电池，注意正确放置正负极。
第三步：拧上灯头。
13 14
NT123A锂锰电池
LUXEON 3瓦 LED
T3电筒结构
按钮开关
尾盖
防水圈
防水圈
头盖
反光杯
T3电筒装配图
防刮PC镜片
筒身
15
产品编号
灯泡
3W LUXEON LED
60流明
NT123A 3V锂锰电池×2
航天等级强化铝材6061-T6
军规级三型硬质阳极氧化
T3
光束亮度
电源
材质
表面处理
镜片材料
使用时间
尺寸
重量
产品特点
防刮PC镜片
65g（不含电池）
持续照明150分钟
长126mm×握柄22mm(灯头直径：27mm)
T3电筒具体参数
紧凑型设计，专利防滚动结构，按钮尾
盖，防水结构设计，表面采用硬质阳极
氧化三型处理，更加结实耐磨。
16
电池安装
打开
拧开灯头，注意电池的正负极，把NT123A电池放入，拧上灯头。
电筒处于关闭状态时，按动尾盖橡胶帽听见“咔吧”生表示电筒打开。
重复以上步骤即关闭。
18
重要提示
由于电池使用不当，有可能引起火灾、爆炸等危险，以致造成灾难。
强烈建议使用前仔细阅读以下安全使用指引。
NT123A、NT2锂锰电池安全使用指引
漏液处理
若电池发生漏液并沾染身体或衣物，请立即用清水冲洗。必要时请寻求医院帮助。
请勿将电池加热或投入火中
电池加热后会发生漏液，引起短路，轻则燃烧，重则爆炸。若将电池投入火中，则会引起爆炸，造成
人员伤亡。
请勿充电
NT123A,N T2锂锰电池为一次性电池，不可进行充电。强行充电会使电池过热、泄露，甚至爆炸、引起火灾。
请勿过放
当电池耗尽前（氙气灯光色偏红，LED在1米内无法看清楚被照物体），请立即更换电池。过放会使电池过
热、泄露，甚至爆炸、引起火灾。
请勿短路
电池的正负极短路会使电池过热、泄漏，甚至爆炸、引起火灾。
请勿拆解、毁坏电池
电池被拆解后会释放对人体有害的气体，或者造成电池过热。毁坏电池则可能引起电池短路。
新电池请勿与旧电池或不同类型的电池混用
旧电池或不同类型的电池具有不同的电性能，与新电池混用会发生过放
电，使电池过热、泄露，甚至爆
炸、引起火灾。
正确放置电池正负极
正负极反向会引起短路或超负荷，使电池过热、泄露，甚至爆炸、引起
火灾。
请勿吞食电池或放入口中
电池不可食用，慎防小童吞食电池或放入口中。万一吞食电池，请立即寻
求医院救助。
正确存放电池
若长时间不使用，请将电池从电筒取出，放置于阴凉干爽处，避免太阳
直射或潮湿环境。
NT123A锂锰电池是为NexTORCH 系列电筒专门设计制作的。它具有优良的安全性能。外壳
采用铝合金，达到电池轻量化；1400毫安时高容量锂电，比普通CR123A容量增加了10%；电压为
3.0伏（标称电压），比一般的CR123A锂电池放电时间；延长了20%.
LC6
NT123A
SL6
V1335 V1438
19
附件
为了满足您对电筒的不同需求，并使电筒得到全面
的维护，我们设计了一系列的配件。请根据您的个人需
要进行选择，如需详细了解附件参数请登陆我们的网站
www.nextorch.com。
NT123A锂锰电池 硅油擦镜布
电筒套
