Nextel comm IR1200 User Manual

iR1200 Rugged Modem

iR1200 GPS-Enabled Modem

Installation Guide

Table of Contents

Table of Contents

Table of Contents .............................................................................................1

FCC Compliance ..............................................................................................1

Before You Begin Installation .........................................................................3

Box Contents:.................................................................................................3

Required Installation Components .................................................................3

Vehicle Installation.....................................................................................3

Stationary Installation ................................................................................4

Required Accessories .......................................................................................5

Introduction ......................................................................................................7

Welcome to Nextel

Using This Guide........................................................................................7



Nextel

Nextel

Coverage.......................................................................................7



Customer Care..............................................................................8



......................................................................................7

Overview ...........................................................................................................9

General Overview...........................................................................................9

Modem Operating Modes.............................................................................10

Modem Configurations.................................................................................10

iR1200 Modem .........................................................................................10

iR1200 GPS-Enabled Modem...................................................................11

Installation Preparation.................................................................................13

iR1200 Modem

Before You Start Installing...........................................................................13

Installation Planning.....................................................................................13

Planning Modem Location .......................................................................14

Modem Dimensions .............................................................................14

Planning Antenna Location ......................................................................16

Planning Cable Layout.............................................................................16

Serial Cable Routing ............................................................................17

Installation Tools......................................................................................17

Vehicle Installation.........................................................................................19

Installation Steps ..........................................................................................20

Mounting the Modem...................................................................................20

Select Modem Location ............................................................................20

Mount the Modem.....................................................................................21

Mounting the Antenna(s)..............................................................................21

Approved Antennas...................................................................................22

Select Antenna Location ...........................................................................22

Mount the Antenna(s) ...............................................................................22

Mount GPS Antenna (optional)............................................................23

Route and Connect Cables............................................................................23

Approved Cable........................................................................................23

Route and Connect Power Cable..............................................................24

Route and Connect Ignition Cable ...........................................................26

Approved Cable....................................................................................26

Route Cable..........................................................................................26

Connect Antenna Cable............................................................................27

Connect Data Cable .................................................................................27

Table of Contents

Stationary Installation ...................................................................................29

Installation Steps ..........................................................................................29

Mounting the Modem...................................................................................30

Select Modem Location ............................................................................30

Mount the Modem.....................................................................................30

Mounting the Antenna(s)..............................................................................31

Approved Antennas...................................................................................31

Select Antenna Location ...........................................................................32

Mount the Antenna(s) ...............................................................................32

Mount GPS Antenna (optional)............................................................32

Route and Connect Cables............................................................................34

Approved Cables ......................................................................................34

Connect Power Cable...............................................................................34

Connect Antenna Cables ..........................................................................35

Connect Data Cables................................................................................35

Verifying Installation .....................................................................................37

Powering Up the Modem..............................................................................37

Powering Up – Vehicle Installation .........................................................37

Powering Up – Building Installation........................................................38

Communication Indicators ...........................................................................38

Packet Data ..............................................................................................40

Circuit Switched Data ..............................................................................40

Troubleshooting..............................................................................................41

Common Problems.......................................................................................41

Diagnostic Port.............................................................................................44

iR1200 Modem

HyperTerminal Setup ...................................................................................45

Diagnostic Menu ......................................................................................47

Unsolicited Firmware Updates ................................................................51

Safety Notice ...................................................................................................55

Safe and Efficient Operation Guidelines ......................................................55

Exposure to Radio Frequency Energy ..........................................................55

Medical and Personal Electronic Devices ....................................................55

Pacemakers ..............................................................................................55

Hearing Aids ............................................................................................56

Other Medical Devices .............................................................................56

Interference with Other Electronic Devices..................................................56

Copyright and Trademark ............................................................................57

Index................................................................................................................61

IMPORTANT!

Please Read Safety Notice on Page 55

before using the iR1200 Modem.

Last Updated

RFM-4000-5015 Rev 1

May 2003

Table of Contents

Table of Figures Page

Figure 1 – iR1200 GPS-Enabled Modem 9

Figure 2 – Rear Panel of iR1200 Rugged Modem 11

Figure 3 – Rear Panel of iR1200 GPS-Enabled Modem 11

Figure 4 – Dimension of iR1200 GPS-Enabled Modem 15

Figure 5 – iR1200 Installation Wiring Diagram (Vehicle) 24

Figure 6 – Modem Power Wiring Diagram (Level 1) 25

Figure 7 – Modem Power Wiring Diagram (Level 2) 26

Figure 8 – iR1200 Installation Wiring Diagram (Stationary)

34

Figure 9 – iR1200 Front Panel Layout 39

iR1200 Modem

FCC Compliance

will not occ ur in a parti cular in stallation.

FCC Compliance

Hereby declares that the product:

Conforms to the following regulation:

FCC Part 15, subp art B
FCC Part 90, subp art S
Class B Digita l device

Date: May 16, 2003

DECLARATION OF CONFORMITY

Responsible party name:
Address:

Phone number:

Product name:
Model Number:

Product name:
Model Number:

Note: This equipment has b een tested and found to comply with the limits
for a Class B d igital d evice, pursua nt to part 15 and 90 of the F CC Rules.
These limit s are designe d to provide reasonabl e protection against
harmful inter ference in a residentia l install ation. The equipment gener ates,
uses and can radiate radi o frequency energy and, i f not instal led and use d
in accordan ce with the instructions, may c ause harmful i nterference to
radio communica tions. However, the re is no gu arantee that interference

If this equi pment does cause harmful interf erence to rad io or televi sion
reception, wh ich can be det ermined by turn ing the equ ipment off and on ,
the user is encouraged to try to correct the interfer ence or by o ne or more
of the foll owing measures:

-- Reorient or reloc ate the recei ving antenna .

-- Increase the separati on between the e quipment and receiver.

-- Connect the equipment i nto an outlet on a circu it different from that to
which the receiver i s connected.

-- Consul t the dealer or an experi enced radio/T V technician for help.

Per FCC CFR 47 2.989

eLutions, Inc.
5905 Breckenridg e Parkway
Suite F
Tampa, FL 33610
1-800-836-99 09

iR1200 GPS-Enable d Modem
4000-C5-RF M

iR1200 Rugged Modem
4100-C5-RF M

RFM-4200-5015 Rev1

1

iR1200 Modem

2 nextel.com

Before You Begin Installation

Before You Begin Installation

Before you begin installing the iR1200 Rugged

!

For a list of approved accessories, consult the Accessories Table on page 5.
To order the required installation accessories, and the Administrator’s Guide,

contact your sales representative, technology administrator or designated field
care representative.

Box Contents:

The iR1200 modem ships with the following:

• iR1200 Modem

• Installation Guide

• Quick Reference Guide (for operators/end users)

• Warranty Card

Modem or the iR1200 GPS-Enabled Modem, you
must obtain the required installation accessories and
download the Administrators Guide.

Required Installation Components

The following table lists the items that are required to successfully install your
modem:

Vehicle Installation

• Approved Cellular Antenna

• Vehicle Power Harness

RFM-4200-5015 Rev1

3

iR1200 Modem

• Data Cable for computer (laptop/MDT)

• Approved GPS Antenna (iR1200 GPS Enabled Modem

only)

• Data cable for GPS (iR1200 GPS-Enabled Modem)

• 4 screws

Stationary Installation

• Approved Cellular Antenna

• AC Power Adapter

• Data Cable for computer (laptop/MDT)

• 4 screws

Use only an approved antenna. Unauthorized
antennas, modifications or attachments could
impair call quality, damage the modem, or result in
the violation of FCC mandates.

4 nextel.com

Required Accessories

Required Accessories

The following table lists the required accessories that have been approved for
use with the iR1200 Rugged Modem and the iR1200 GPS-Enabled modems.
Please contact your Nextel sales representative or visit

www.elutions.com/wireless to order these items.

Part No. Description

5000-C5-RFM Mag Mount Cellular Antenna
5030-C5-RFM Mag Mount GPS Antenna
5100-C5-RFM Vehicle Power Harness
5200-C5-RFM AC Power Adapter (standard temperature)

RFM-4200-5015 Administrator’s Guide

RFM-4200-5015 Rev1

5

iR1200 Modem

6 nextel.com

Introduction

Introduction

Welcome to Nextel

Thank you for purchasing the Nextel iR1200 modem. This modem is designed
to work specifically within the iDEN network. Once installed and configured,

the iR1200 modem provides you with wireless data communications.

This chapter includes:



Using This Guide Page 7

Nextel Coverage

Nextel Customer Care Information

Page 7

Page 8

Using This Guide

This guide provides instructions for the installation of the iR1200 Rugged
Modem and the iR1200 GPS-Enabled Modem.

Nextel

For details on Nextel digital cellular and data coverage, visit nextel.com.



Coverage

NOTE: Transmission and reception speed may vary, based on your

relative position within the coverage area. If you are in a marginal
location (close to the border of the coverage area), the throughput
of your modem during data transmission may be affected.

RFM-4200-5015 Rev1

7

iR1200 Modem



Nextel

Customer Care

For domestic customer care issues, including installation, technical support, or
to order accessories contact your technology administrator or designated field
care representative.

When you call, please have a detailed description of your problem. To provide
you with fast and quality support, our Customer Care representative may ask
for the following:

• Computer operating system (Windows 95/98/NT/2000/CE).

• Version of the operating system (e.g. NT 4, Windows 95 Version B, CE

2.1, etc.).

• Information regarding the modem (most can found on the diagnostic
menu).

• Geographic location of use.

• IMEI Number

• SIM ID Number

• Account Number

8 nextel.com

Overview

Overview

This chapter contains general details about the iR1200 modem.

This chapter includes:

General Overview Page 9
Modem Operating Modes Page 10
Modem Configurations Page 10

General Overview

The iR1200 Modem is an iDEN data modem that consists of a modem card
and an optional GPS (iR12000 GPS-Enabled Modem) receiver, contained in a
rugged enclosure, to provide wireless data communications. The iR1200
modem is easy to mount, whether in a mobile or stationary environment.

RFM-4200-5015 Rev1

Figure 1. iR1200 GPS-Enabled Modem

9

iR1200 Modem

Modem Operating Modes

The iR1200 provides the following data connection modes:

• Packet Data: A wireless modem connection used for accessing the
Internet, sending and receiving e-mail, and transferring small files over the
packet data network using standard IP protocols.

Data is sent in packets (blocks) of data at high speed.

• Circuit Switched Data: A wireless modem connection for sending and
receiving data (faxes, files, etc.) over the circuit-switched cellular channel,
providing a direct point-to-point connection with the destination device.

Modem Configurations

Nextel offers two models of the iR1200 Modem. Both are designed to provide
wireless communication for rugged environments. The distinction between the
two models is the optional GPS feature.

The iR1200 modem can be purchased with the following configurations:

•

iR1200 Modem (Base Model) - Available in bulk or individual packaging

•

iR1200 GPS-Enabled Modem - Available in bulk or individual
packaging

iR1200 Modem

The following diagram displays the components that exist on the rear panel of
the iR1200 Modem.

10 nextel.com

Overview

Ignition Sense /

Ignition Sense /

Bypass

Bypass

Connector

Connector

Modem

Modem

Serial Data

Serial Data

Connector

Connector

Modem Antenna

Modem Antenna

Connector

Connector

12VDC Power

12VDC Power

Connector

Connector

Figure 2. Rear Panel of iR1200 Rugged Modem

iR1200 GPS-Enabled Modem

The following diagram shows the components that exist on the rear panel of the
iR1200 GPS-Enabled Modem.

GPS Antenna

GPS Serial

GPS Serial

Data

Data

Connector

Connector

GPS Antenna

Connector

Connector

Ignition Sense /

Ignition Sense /

Bypass

Bypass

Connector

Connector

Modem

Modem

Serial Data

Serial Data

Connector

Connector

Figure 3. Rear Panel of iR1200 GPS-Enabled Modem

RFM-4200-5015 Rev1

Modem Antenna

Modem Antenna

Connector

Connector

12VDC Power

12VDC Power

Connector

Connector

11

iR1200 Modem

12 nextel.com

Installation Preparation

Installation Preparation

In this chapter, you will learn how to begin installing your iR1200 modem.

This chapter includes:

Before You Start Installing Page 13
Installation Planning

Planning Modem Location

Modem Dimensions
Planning Antenna Location
Planning Cable Layout

Page 13
Page 14
Page 14
Page 16

Page 16
Serial Cable Routing Page 17
Installation Tools Page 17

Before You Start Installing

Only experienced technicians familiar with installing similar types of hardware
equipment should install the modem. For safety and to avoid damage to the
modem or vehicle wiring, the installer should have knowledge of the following
subjects.

• Automotive wiring (if applicable)

• Vehicle cable routing (if applicable)

• Antenna location

Installation Planning

Planning is the key to a quick and simple installation. Before drilling holes or
running wires, you should inspect the vehicle or area of the building to

RFM-4200-5015 Rev1

13

iR1200 Modem

determine how and where you intend to mount the modem, antenna and
accessories. (See Required Installation Components listed on page 3).

Planning Modem Location

Factors to consider when planning for the location or placement of your iR1200
modem:

• Easily Accessible – You should allow easy access to the modem (for
troubleshooting purposes).

• Easily Visible – You should allow a clear view of the modem’s LED
indicators.

• Proximity of the Cables – The distance between connections affects
performance, especially the distance between the modem and antenna. The
shorter the distance between these components, the better the signal.

(Please refer to the antenna’s Safety Warranty for proper installation
of modem and antenna.)

• Environment Considerations:

!

- Heat - Placing the modem, antenna or cables near

a heat source can cause several problems,
including radio interference. Select a location away
from a source of heat and make sure the modem
has at least a 1-inch clearance on all sides for cool
air to circulate.

- Wetness – The modem should not be mounted in

an area where it would be directly exposed to
water.

- Direct Sunlight – The modem should not be

mounted in direct sunlight.

Modem Dimensions

Consider the size of the modem. Will the modem fit in the area where you want
to perform the installation?

14 nextel.com

Installation Preparation

The following diagram outlines the modem’s dimensions:

NOTE: This diagram depicts the dimensions of both the iR1200 Rugged

and iR1200 GPS-Enabled Modems and should not be used as a
template for mounting the modem.

Figure 4 – Dimensions of iR1200 GPS-Enabled Modem

RFM-4200-5015 Rev1

15

iR1200 Modem

The following table describes the overall dimensions of the iR1200 modem.

Component Dimension

Overall dimensions from connector to

7.86in. [199.69mm]

connector
End panel to end panel 7.09in. [180.14mm]
Width (including mounting tabs) 5.04in. [128.02mm]
Width of enclosure 4.04in. [102.62mm]
Height of enclosure 2.20in. [55.88mm]

Planning Antenna Location

Factors to consider when planning for the location or placement of the antenna:

• Choose a location with easy access to cable routing to ease the process of
connecting the antenna to the modem.

• In vehicle installation, mount the modem antenna on the center of the
outside trunk for optimum signal reception.

• In a stationary (building or desk) environment, position the GPS antenna
where it has a direct line-of-sight to the sky. In some cases, this can be
accomplished by placing the antenna adjacent to a window. In most cases
it will require mounting outside of the building.

Planning Cable Layout

Once you have chosen the location of the modem and antenna and before the
installation, layout the cables to determine:

• If the cables can reach the modem and antenna.

• If the distance between components is adequate and allows you to make

adjustments to receive a better signal. (Please refer to the manufacturer’s
installation manual for safe installation of your antenna).

16 nextel.com

Installation Preparation

• If there are kinks or bends in the cable or obstructions in the vehicle that
could affect routing.

Serial Cable Routing

Serial cable routing is the most important factor to ensure a trouble-free
operation. The serial cable should be as stable as possible (e.g., it should
experience little or no movement and have very few or no bends or kinks).

NOTE: The majority of the problems occur because of serial cable failure.

Installation Tools

You will need these tools to install the iR1200 modem.

• Portable Drill • Hammer

• Center Punch • Connector Crimp tool

• Four #10 self-tapping sheet metal screws • Phillips Screwdriver

RFM-4200-5015 Rev1

17

iR1200 Modem

18 nextel.com

Vehicle Installation

Vehicle Installation

In this chapter, you will learn how to install your iR1200 modem and antennas
in a vehicle.

This chapter includes:

Installation Steps Page 20
Mounting the Modem

Select Modem Location
Mount the Modem

Mounting the Antenna(s)

Approved Antennas
Select Antenna Location
Mount the Antenna

Mount the GPS Antenna

Route and Connect Cables

Approved Cable
Route and Connect Power Cable
Route and Connect Ignition Cable
Connect Antenna Cable
Connect Data Cable

RFM-4200-5015 Rev1

Page 20
Page 20
Page 21
Page 21
Page 22
Page 22
Page 22
Page 23
Page 23
Page 23
Page 24
Page 26
Page 27
Page 27

19

iR1200 Modem

Installation Steps

To install, you must complete the following steps:

• Mount Modem – Mount the modem in the desired location.

• Mount Antenna – Mount the antenna using the instructions included with

your selected antenna’s installation guide.

• Route and Connect Power Cable – route the power cable from modem
to the vehicle’s power supply (ignition switch).

• Route and Connect the Ignition Cable – Route the ignition cable from
the modem to the ignition.

• Connect Antenna Cable – Connect cable to the mounted modem and
antenna.

• Connect Data Cable – Connect the data cable from the modem to the
mobile device.

Mounting the Modem

Select Modem Location

The following describes typical locations that you should consider for
mounting the modem:

• Under seat • In trunk

• Under dashboard • In accessory compartment

• Center console

Mounted on side of console

20 nextel.com

Mounted on side wall of trunk

Vehicle Installation

Mount the Modem

The following table lists the steps for mounting the iR1200 data modem in a
vehicle.

1 Determine a convenient location in the vehicle.
2 Use the iR1200 modem and mark the positions of the holes

on the mounting surface.

3 Drill the holes in the marked location.
4 Mount the unit using the #10 sheet metal screws.

Mounting the Antenna(s)

The location of the antenna should be chosen carefully.

!

RFM-4200-5015 Rev1

Important things to consider when installing the
antenna equipment.

• Installation of recommended equipment must be
installed in accordance with Nextel’s installation
instructions.

• To assure compliance with United States FCC
regulations on RF exposure, equipment must be
installed in such a way as to maintain a separation
of at least 8 inches (20 cms) between the antenna
and the human body.

• Ensure that the antenna is properly installed
external to the vehicle and in accordance with the
requirements of the antenna manufacturer/supplier.

• Use only an approved antenna. Unauthorized
antennas, modifications or attachments could impair
call quality, damage the modem, or result in the
violation of FCC mandates.

21

iR1200 Modem

Approved Antennas

The following table states the approved antennas that can be used with the
iR1200 modem.

Part No. Description

5000-C5-RFM Mag Mount Cellular Antenna
5030-C5-RFM Mag Mount GPS Antenna

NOTE: Antennas with gain exceeding 3db do not comply with FCC RF

exposure and are not allowed for use with this product.

Select Antenna Location

The following are some common layouts for co-locating an external antenna
and the iR1200 modem.

• Roof to trunk – This layout accommodates a trunk-mounted modem and
antenna that is attached to the roof.

• Trunk to trunk – This layout accommodates a trunk-mounted modem
and antenna that is attached to the trunk.

• Roof to console or dashboard – This layout accommodates a console or
dashboard mounted modem and the antenna attached to the roof. This
setup gives you access to the modem.

Mount the Antenna(s)

The following table describes the steps for mounting an antenna.

1 Use an antenna suitable for the cellular band of frequencies

(806-870 MHz) with Mini UHF jack and matched for 50­ohm impedance.

2 Mount the antenna according to the manufacturer’s

specifications or instructions. (Use only an approved
antenna – see list of Approved Antennas above.)

22 nextel.com

Vehicle Installation

NOTE: Each antenna has specific installation instructions. Please refer

to the antenna installation instructions for specific requirements
and details.

Mount GPS Antenna (optional)

The iR1200 GPS-Enabled modem comes equipped with a connector for a GPS
antenna. Nextel has tested and recommends using the GPS Magnetic Mount
Antenna (part number 5030-C5-RFM) with the iR1200 Modem.

The following table contains the steps for mounting a GPS antenna.

1 Use an antenna suitable for the GPS of frequency 1575

MHz with an MCX connector and matched for 50-ohm
impedance. (Use only an approved antenna – see list of
Approved Antennas on page 22.)

2 Position the antenna where it has a direct line-of-sight to the

satellite.

3 Mount the antenna according to the manufacturer’s

specifications or instructions.

NOTE: Because of the operating frequencies involved with the GPS

signal, splicing or using adapters to extend the length of the
antenna coaxial cable is not recommended and will likely prevent
the system from operating properly. We recommend that a single
length of coax without splices or adapters be used.

Route and Connect Cables

Approved Cable

The following DC power cable must be used (sold separately, see Accessories
Table for ordering information).

5100-C5-RFM – Vehicle Power Harness

RFM-4200-5015 Rev1

23

iR1200 Modem

The following diagram illustrates typical installation wiring of the iR1200 into
a vehicle.

MOBILE DATA

COMPUTER

FUSE

+12VDC
VEHICLE BATTERY

GPS ANTENNA
(OPTIONAL)

ENGINE IGNITION
SWITCH

+12VDC

MODEM
ANTENNA

POWER

IGNITION

iR1200

Figure 5 – iR1200 Installation Wiring Diagram (Vehicle)

Route and Connect Power Cable

Route the DC power cable using the following diagram as a guideline:

RS-232

GPS DATA

RS-232

MODEM DATA

24 nextel.com

Vehicle Installation

Figure 6 – Modem Power Wiring Diagram (Level 1)

The following table contains the steps for routing and connecting the power
cable:

1 Determine a cable routing plan that will allow you to connect

the DC power cable between the modem and the vehicle
battery. Connect the male end of the power cable to the 2­prong connector labeled POWER on the modem.

2 Route the free end of the cable to the vehicle battery. If

necessary, drill a hole in the vehicle firewall and route the
cable through it using the supplied grommet (Refer to
Figure 6 – Modem Power Wiring Diagram above).

3 Locate an available chassis ground mounting point near the

battery and shorten the black lead to remove any excess
cable length.

4 Crimp on the ring tongue terminal and connect the black lead

directly to the chassis ground.

5 Position the fuse holder as close to the battery as possible,

and away from any potentially hot components.

RFM-4200-5015 Rev1

25

iR1200 Modem

6 Mount the fuse holder by tie wrapping it to the other cabling

wires and dress wires as necessary.

7 Shorten the red lead of the DC power cable to remove any

excess length and crimp the fuse holder’s red lead to it using
the in-line splice.

8 Connect the ring tongue terminal from the fuse holder to the

positive (+) battery terminal.

Route and Connect Ignition Cable

Approved Cable

The following DC power cable must be used (sold separately, see Accessories
Table for ordering information).

5100-C5-RFM – Vehicle Power Harness

Route Cable

Route the Ignition cable using the following diagram as a guideline:

Figure 7 – Modem Power Wiring Diagram (Level 2)

26 nextel.com

Vehicle Installation

1 Connect the male end of the ignition cable to the 4-prong

connector labeled IGNITION on the modem.

2 Connect the free end of the ignition cable to a vehicle circuit

that provides 12VDC when the vehicle is running or in ACC,
and no 12VDC when the vehicle is OFF or not in ACC.

Connect Antenna Cable

The following table describes the steps for connecting the antenna cable to the
modem:

1 Insert the male end of the modem antenna cable to the

connector labeled MODEM ANT on the modem. (Use only
an approved antenna – see list of Approved Antennas on
page 22.)

2 Insert the male end of the GPS antenna (optional) cable to

the connector labeled GPS ANT on the modem. (Use only an
approved antenna – see list of Approved Antennas on page

22.)

Connect Data Cable

The iR1200 modem can be connected to the host DTE equipment using a
standard “straight through” 9-pin male to a 9-pin female serial cable.

The following step describes how to connect the data cable:

Connect the 9-pin male end of the cable to the iR1200
communication connector and the 9 pin female end of the cable
to the data terminal equipment (DTE).

RFM-4200-5015 Rev1

27

iR1200 Modem

28 nextel.com

Stationary Installation

Stationary Installation

In this chapter, you will learn how to install your iR1200 modem in a stationary
(i.e. building/desktop) environment.

This chapter includes:

Installation Steps Page 29
Mounting the Modem

Select Modem Location
Mount the Modem

Mounting the Antenna(s)

Approved Antennas
Select Antenna Location
Mount the Antenna

Mount the GPS Antenna

Route and Connect Cables

Approved Cable
Connect Power Cable
Connect Antenna Cable
Connect Data Cable

Installation Steps

To install, you must complete the following steps:

• Mount Modem – Mount the modem in the desired location.

RFM-4200-5015 Rev1

Page 30
Page 30
Page 30
Page 31
Page 31
Page 32
Page 32
Page 32
Page 34
Page 34
Page 34
Page 35
Page 35

29

iR1200 Modem

• Mount Antenna – Mount the antenna using the instructions included with
your selected antenna’s installation guide.

• Route and Connect Power Cables – route the power cables from modem
to the power supply.

• Connect Antenna Cable – Connect cables to the mounted modem and
antenna.

• Connect Data Cable – Connect the data cables from the modem to the
mobile device.

Mounting the Modem

The iR1200 modem can be mounted on different types of surfaces. You should
determine if the surface is able to support the weight of the iR1200 modem.
The area should allow sufficient space around the modem for cool air to
circulate.

Select Modem Location

The iR1200 modem within a building or stationary environment is typically
installed in an area where the antenna has a direct line-of-sight to sky for
maximum reception.

Mount the Modem

The following table lists the steps for mounting the iR1200 data modem in a
stationary environment.

1 Determine a convenient location within the stationary

environment.

2 Use the iR1200 modem and mark the positions of the holes

on the mounting surface.

3 Drill the holes in the marked location.
4 Mount the unit using the #10 sheet metal screws.

30 nextel.com

Mounting the Antenna(s)

The location of the antenna should be chosen carefully.

Stationary Installation

!

Important things to consider when installing the
antenna equipment.

• Installation of recommended equipment must be
installed in accordance with Nextel’s installation
instructions.

• To assure compliance with United States FCC
regulations on RF exposure, equipment must be
installed in such a way as to maintain a separation
of at least 8 inches (20 cms) between the antenna
and the human body.

• Ensure that the antenna is properly installed
external to the vehicle and in accordance with the
requirements of the antenna manufacturer/supplier.

• Use only an approved antenna. Unauthorized
antennas, modifications or attachments could
impair call quality, damage the modem, or result in
the violation of FCC mandates.

Approved Antennas

The following table states the approved antennas that can be used with the
iR1200 modem.

Part No. Description

5000-C5-RFM Mag Mount Cellular Antenna
5030-C5-RFM Mag Mount GPS Antenna

NOTE: Antennas with gain exceeding 3db do not comply with FCC RF

exposure and are not allowed for use with this product.

RFM-4200-5015 Rev1

31

iR1200 Modem

Select Antenna Location

The following are some common layouts for co-locating an external antenna
and the iR1200 modem.

• Roof to trunk – This layout accommodates a trunk-mounted modem and
antenna that is attached to the roof.

• Trunk to trunk – This layout accommodates a trunk-mounted modem
and antenna that is attached to the trunk.

• Roof to console or dashboard – This layout accommodates a console or
dashboard mounted modem and the antenna attached to the roof. This
setup gives you access to the modem.

Mount the Antenna(s)

The following table describes the steps for mounting an antenna.

1 Use an antenna suitable for the cellular band of frequencies

(806-870 MHz) with Mini UHF jack and matched for 50­ohm impedance.

2 Mount the antenna according to the manufacturer’s

specifications or instructions. (Use only an approved
antenna – see list of Approved Antennas on page 31.)

NOTE: Each antenna has specific installation instructions. Please refer

to the antenna installation instructions for specific requirements
and details.

Mount GPS Antenna (optional)

The iR1200 GPS-Enabled modem comes equipped with a connector for a GPS
antenna. Nextel recommends using the GPS Magnetic Mount Antenna (part
number 5030-C5-RFM) with the iR1200 Modem.

The following table contains the steps for mounting a GPS antenna.

1 Use an antenna suitable for the GPS of frequency 1575

MHz with an MCX connector and matched for 50-ohm

32 nextel.com

Stationary Installation

impedance.

2 Position the antenna where it has a direct line-of-sight to the

satellite.

3 Mount the antenna according to the manufacturer’s

specifications or instructions. (Use only an approved
antenna – see list of Approved Antennas on page 31.)

NOTE: Because of the operating frequencies involved with the GPS

signal, splicing or using adapters to extend the length of the
antenna coaxial cable is not recommended and will likely prevent
the system from operating properly. We recommend that a single
length of coax without splices or adapters be used.

RFM-4200-5015 Rev1

33

iR1200 Modem

Route and Connect Cables

The following diagram illustrates typical installation wiring of the iR1200 into
a stationary environment.

COMPUTER

120VAC TO 12VDC
POWER CONVERTER

GPS ANTENNA
(OPTIONAL)

Figure 8 – iR1200 Installation Wiring Diagram (Stationary)

Approved Cables

The following DC power cable must be used (see Accessories Table for
ordering information).

MODEM
ANTENNA

IGNITION
BYPASS
PLUG

POWER

IGNITION

iR1200

RS-232

GPS DATA

RS-232

MODEM DATA

5100-C5-RFM – Vehicle Power Harness

Connect Power Cable

The following table contains the steps for routing and connecting the power
cable:

1 Connect male end of the AC Power Adapter cable to the 2-

prong connector labeled POWER on the modem.

2 Connect the free end of the power cable to a 120VAC-power

outlet.

34 nextel.com

Stationary Installation

Connect Antenna Cables

The following table describes the steps for connecting antenna cables to the
modem (use only an approved antenna – see list of Approved Antennas on page

31):

1 Insert the male end of the modem antenna cable to the

connector labeled MODEM ANT on the modem.

2 Insert the male end of the GPS antenna (optional) cable to

the connector labeled GPS ANT on the modem.

Connect Data Cables

The iR1200 modem can be connected to the host DTE equipment using a
standard “straight through” 9-pin male to a 9-pin female serial cable.

The following step describes how to connect the data cable:

Connect the 9-pin male end of the cable to the iR1200
communication connector and the 9 pin female end of the cable
to the data terminal equipment (DTE).

RFM-4200-5015 Rev1

35

iR1200 Modem

36 nextel.com

Verifying Installation

Verifying Installation

In this chapter, you will learn how to verify that the installation of the iR1200
modem was successful.

This chapter includes:

Powering up the Modem

Vehicle Installation
Stationary Installation

Page 37
Page 37
Page 38

Communication Indicators Page 38

Powering Up the Modem

Once you have completed the installation of the modem’s hardware
components and connected all the power cables, power up the modem to ensure
that the installation was successful.

Powering Up – Vehicle Installation

The following table contains the steps for powering up the modem for a vehicle
installation:

1 Turn on the vehicle’s ignition.
2 The STATUS LED light will initially blink Red. This

indicates that the modem is searching for a signal within the
Nextel network.

3 A blinking Green light indicates that a signal has been found

and the modem was successful in making a connection.

4 The STATUS LED should blink Green within 3 minutes

from the time the vehicle’s ignition was turned ON.

RFM-4200-5015 Rev1

37

iR1200 Modem

Powering Up – Building Installation

To turn on the iR1200 modem, an ignition signal is required at the ignition
connector. Use the ignition sense short plug to simulate an ignition signal to
power up the modem.

The following table contains the steps for powering up the modem for a
building installation:

1 Insert the ignition bypass plug into the 4-prong IGNITION

connector located in the rear panel of the modem (refer to
Figures 2 and 3 on Page 11).

2 Plug the AC power cord into a standard 2-prong polarized

wall socket.

3 The STATUS LED light will first blink Red. This indicates

that the modem is searching for a signal within the Nextel
network.

4 A blinking green light indicates that a signal has been found

and the modem was successful in making a connection.

5 The STATUS LED should blink Green within 3 minutes

from the time the power was activated on the modem.

Communication Indicators

Your

iR1200 modem is equipped with LED indicators (see Figure 9 on page

39) that identify various communication functions.

38 nextel.com

LED (signal indicators)

LED (signal indicators)

displays the modem’s

displays the modem’s

serial interface status.

serial interface status.

Status LED

Status LED
displays the

displays the

modem’s

modem’s

iDEN network

iDEN network

status.

status.

Figure 9 – iR1200 Front Panel Layout

Signal Color Indication

Verifying Installation

Diagnostic Connector

Diagnostic Connector

used to receive modem

used to receive modem

diagnostic information.

diagnostic information.

Reset Button used to

Reset Button used to

power cycle the

power cycle the
modem and re-

modem and re-

establishes connection

establishes connection

to the network.

to the network.

Tx Blinking

Green

Rx Blinking

Green

Modem is transmitting data to the
computer data terminal (DTE).

Modem is receiving data from the
computer. Modem is receiving data from
the DTE.

RTS Green

(Off)

CTS Green

(Off)

DTR Green

(Off)

DSR Green

Request To Send from computer (DTE) is
asserted (not asserted).

Clear To Send from modem is asserted
(not asserted).

Data terminal equipment is ready (not
ready).

Modem is ready (not ready).

(Off)

STATUS Solid Red The modem is searching for signal within

the Nextel network. If the modem status
changes from blinking green back to solid
red, the signal has been lost and the

RFM-4200-5015 Rev1

39

iR1200 Modem

modem is attempting to re-acquire.

NOTE: If after a period of several minutes

it the status does not return to
green, you may be out of range.
The modem will attempt to re­acquire automatically when you
are back in range.

NOTE: The STATUS indicators are different depending on the type

of mode the modem is operating in.

The following tables describe the STATUS indicators for the Packet Data and
Circuit Switched Data operating modes.

Packet Data

In-range (modem is connected to the
Nextel network) but idle (but not passing
data).

The modem is in use – Nextel network
communication is active and is passing
data.

STATUS

STATUS

Blinking

Green

Blinking

Green

Circuit Switched Data

STATUS

STATUS

40 nextel.com

Blinking

Green

Solid

Green

In-range (modem is connected to the
Nextel Network) but idle (but not passing
data).

The modem is in use – Nextel network
communication is active and is passing
data.

Troubleshooting

Troubleshooting

In this chapter, you will learn how to troubleshoot the most common
installation problems and how to resolve them.

This chapter includes:

Common Problems Page 41
Diagnostic Port Page 44
HyperTerminal Setup Page 45
Diagnostic Menu Page 47
Unsolicited Firmware Updates Page 51

Common Problems

The following table outlines the most common installation issues and
instructions for resolution.

What’s the

Problem?

Nothing happens
when I power up
the modem.

RFM-4200-5015 Rev1

What it means: How to Resolve:

This indicates that
there is no power
being supplied to the
modem.

There are several things
that could be wrong. Go
through this list and
eliminate all the possible
problems:

• Is the ignition on?

• Is the ignition bypass

plug inserted into the
IGNITION

41

iR1200 Modem

What’s the

Problem?

The modem has
power but the
LED light is not
blinking green.

The modem
doesn’t appear to
be
communicating.

What it means: How to Resolve:

connector on the
modem (for building
installations)?

• Check power supply
and make sure that
everything is
connected properly.

• Is the battery voltage
at least 12 volt?

• Check the cables and
wiring.

- You may not be
within coverage
area.

- Signal strength
may be weak.

This could indicate a
number of things (see
How to Resolve
column to eliminate
the possibilities).

• Antenna may be
loose. Check to make
sure the antenna is
properly connected.

• Reposition antenna.

• Is data cable plugged

into the diagnostic
port?

• Is data cable
connected properly
to the mobile device
or computer?

42 nextel.com

• Check the RSSI

• Check coverage:

• Move to another

location to see if

Troubleshooting

What’s the

What it means: How to Resolve:

Problem?

GPS does not
operate.

Either:

- Coverage in the
area is bad.

- Antenna may be

improperly
installed or
defected.

GPS is slow. It is normal for the

GPS to take up to 5
minutes to acquire the
first reading.

coverage is not
affected.

• Verify that your
account has been
activated. Contact
your technology
administrator or
designated field care
representative.

• Verify that the
antenna has direct
line of sight to
satellite.

• Move to another
area.

• Are you in a parking
garage where GPS
signal will not be
received?

• Wait for an
appropriate amount
of time for
communication to
take place. If
attempts are taking
longer than 5 or more
minutes, contact your
system administrator.

RFM-4200-5015 Rev1

43

iR1200 Modem

What’s the

What it means: How to Resolve:

Problem?

Modem will not
power up or
down

The wiring to the
modem may not be
connected properly.

• Check the ignition
sense wiring to be
sure that it is
connected.

• Verify that the
diagnostic port is
plugged in correctly.

• Check LED status to
see if the modem is
communicating.

NOTE: The Status LED remains red for up to 3 minutes after power is

applied to the iR1200 or immediately after the Reset button is
pressed.

Diagnostic Port

The diagnostic port located on the front panel of the iR1200 modem (see Figure
9 on page 39) is used to retrieve data from the modem that will help to analyze
and diagnose possible communication issues.

The following table describes steps to connect to the diagnostic port:

1 Insert the 9-pin male end of a serial signal cable into the RS-

232 connector labeled DIAGNOSTIC PORT of the modem’s
rear panel and tighten the screws.

2 Connect the other end of the serial signal cable to a serial

COM port on the back of your computer or mobile device
and tighten the screws.

44 nextel.com

Troubleshooting

HyperTerminal Setup

The following table outlines steps to setup a HyperTerminal session for the
iR1200 modem:

1 From your computer, locate and select the HyperTerminal

program.

2 The Connection Description screen appears.

3 Type a description of the connection in the “Name:” box.
4 Select the dial function (red and yellow phone icon) and

click OK.

5 The Connect To screen appears.

RFM-4200-5015 Rev1

45

iR1200 Modem

6 Select the appropriate communication port (typically

COM1) from the “Connect Using:” drop down list then
Click OK.

7 The COM1 Properties screen appears.

8 Select the following parameters from each of the drop-

down lists on the Port Settings tab:

• 19200 for Bits per second

46 nextel.com

Troubleshooting

• 8 for Data bits

• NONE for Parity

• 1 for Stop bits

• None or Hardware for Flow control

9 Click OK when all the parameters have been selected.
10 Once connection to the modem is successful, the iR1200

Rugged Modem Diagnostic Menu appears.

Diagnostic Menu

The iR1200 modem Diagnostic Menu provides you with commands to help
analyze potential problems with the modem. The menu contains actions that
call the modem and receive diagnostic information.

The following table outlines the types of information that can be retrieved with
the commands on the diagnostic menu.

RFM-4200-5015 Rev1

47

iR1200 Modem

Command Action Reply

1 – Reset This command

resets the radio
section of the
modem.

2 – Master Reset This command is

used when
certain changes
are made to the
firmware and the
modem needs to
acquire the
changes.

3 – Signal

Quality

This determines
the quality of the
signal.

4 – Signal

Strength

This determines
the signal
strength of the
modem.

5 – Packet Data

Registration
Information

This will check
for packet data
registration
status.

WARNING: We do not
recommend that you perform
this command unless otherwise
instructed by a Nextel
Customer Care representative.

Signal quality can be 0 –
100

Signal strength can be 0 –

100.

• Service type: PACKET

• VALID NEI: (IP

Address of the Modem)

• Registration Status:
REGISTERED or
UNREGISTERED

• MIP Registration
Status: REGISTERED
or UNREGISTERED

48 nextel.com

Command Action Reply

6 – Channel

Information

This determines
if channel data
has been
obtained.

• Area

• RSSI

• Channel

• State

• TX Level

7 – Stored

Parameters

This provides the
modem’s preset
parameters.

• Flow Control

• Character Framing

• Service Class

• DTE-side Stack

• WDS-side Stack

• Mobile IP Activation

• Mobile UP Registration

Lifetime

• Security Parameter
Index

• Home Agent IP
Address

• +WPNEI Prefix Length

• Request Broadcast

Datagrams

• DCE IP Addresses

• DTE IP Addresses

• Data Encryption

• Data Compression

• Header Compression

Troubleshooting

8 – DNS IP

Address

RFM-4200-5015 Rev1

Displays the
address of the
Domain Name
Server.

49

iR1200 Modem

Command Action Reply

9 – Modem Pass-

Thru Mode

0 – iR1200

Firmware
Update

i – Radio

Information

d –Deregister

From
Network

r – Register with

Network

h – iR1200

Config Data

Allows you to
issue Hayes
compatible AT
commands to the
modem during
diagnostic port.

Sends updates to
the firmware.

Obtains
information
specific to the
modem.

Forces the
modem to
deregister from
the Nextel
Network.

Forces the
modem to
register with the
Nextel network.

Checks the
modem’s data
configuration.

WARNING: We do not
recommend that you perform
this command unless otherwise
instructed by a Nextel
Customer Care representative.

• Serial Number

• IMEI

• SIM ID

• Software Version

DEREGISTERED

REGISTERED

• Hardware Part ID

• Serial number

• Boot Loader

• Application ID

50 nextel.com

Troubleshooting

Unsolicited Firmware Updates

We want to emphasize that this diagnostic option should be executed only
when instructed by a Nextel Customer Care Representative. However, there are
certain sequences of events that will prompt you for a firmware update.

!

The following lists the sequence of events that will
cause HyperTerminal to prompt you for firmware
update.

1 Modem is OFF (all cables are connected except for the

power connector).

2 The computer is ON and the HyperTerminal is active.

3 Modem is switched ON (power connector is inserted into

the power slot).

4 HyperTerminal automatically presents the option 0 –

Firmware Update prompt.

RFM-4200-5015 Rev1

51

iR1200 Modem

!

To safely exit out of the update firmware mode,
please select “N”. There will be about a 1-minute
delay before the system returns you to the diagnostic
menu. This is because the modem is attempting to
register with the iDEN network.

5 Once the modem has successfully registered with the

network, the HyperTerminal will present you with the
Diagnostic Menu.

52 nextel.com

6 You are safe to use the modem.

Troubleshooting

RFM-4200-5015 Rev1

53

iR1200 Modem

54 nextel.com

Safety Notice

Safety Notice

The following is important information for safe and efficient
operation of the iR1200 modem. We recommend that all users read
this information before using the modem.

Safe and Efficient Operation Guidelines

Your modem contains a transmitter and receiver. When it is ON, it receives and
transmits radio frequency (RF) energy. The modem operates in the frequency
range of 806 MHz to 870 MHz and utilizes the digital modulation techniques.
This product is authorized by FCC Rule Part 47CFR2.989 (b) which states that
it should be used in such a way that it maintains a distance of at least 8 inches
(20 cms) between the human body and the radio's antenna or modem. When
you use your modem, the system handling your call controls the power level at
which your modem transmits. The output power level typically may vary over a
range from 600 mW to 2.5 watts.

Exposure to Radio Frequency Energy

Your modem is designed to comply with the United States Federal
Communications Commission, Code of Federal Regulations; FCC part 90-sub
part S, and FCC-part 15, Class B. The modem is in compliance with FCC’s
national standards and guidelines regarding exposure of human beings to radio
frequency electromagnetic energy.

Medical and Personal Electronic Devices

Most electronic equipment are protected from RF energy. However, certain
equipment may not be shielded against the RF signals being emitted from your
modem.

Pacemakers

Operators should not use the modem if individuals with pacemakers are
within 6 inches (0.15 meters) of the antenna.

RFM-4000-5015 Rev1

55

iR1200 Modem

Hearing Aids

The modem may cause interference with hearing aid devices. Individuals
who experience such interference should consult the hearing aid
manufacturer to discuss alternative solutions.

Other Medical Devices

Individuals who have other medical devices not specifically mentioned in
this safety notice may want to consult their physician or the manufacturer
of the device to determine if it is adequately protected from external RF
energy.

Interference with Other Electronic Devices

RF energy may affect improperly installed or inadequately protected electronic
operating and entertainment systems in motor vehicles. Check with the
manufacturer or representative to determine if these systems are adequately
shielded from external RF energy. It is recommended that you also check with
the manufacturer of any equipment that has been added to the vehicle.
