iR1200 Rugged Modem

iR1200 GPS-Enabled Modem

Administrator’s Guide

General

Page 2

Page 3

Table of Contents

Table of Figures................................................................................................ 1

FCC Compliance ..............................................................................................3

Required Components .....................................................................................5

How to Order..................................................................................................5

Online Documentation ...................................................................................6

Introduction......................................................................................................7

Welcome to Nextel

Using This Guide........................................................................................7



Nextel



Nextel

Overview ...........................................................................................................9

General Overview ..........................................................................................9

Modem Operating Modes.............................................................................10

Modem Configurations.................................................................................10

iR1200 Rugged Modem ............................................................................10

iR1200 GPS-Enabled Modem...................................................................11

Modem Specifications..................................................................................12



......................................................................................7

Coverage.......................................................................................7

Customer Care..............................................................................8

Getting Started ...............................................................................................15

Connecting the Modem ................................................................................15

Communication Indicators ...........................................................................17

Packet Data ..............................................................................................19

Page 4



iR1200 Modem

Circuit Switched Data ..............................................................................19

Installing iDEN

Hardware and Installation Requirements......................................................21

Before You Begin.........................................................................................22

Download Software Instructions ..................................................................22

Windows 95/98/ME ..................................................................................23

Windows NT .............................................................................................26

Windows 2000 ..........................................................................................31

Setting Up Windows Components.................................................................35

Verify Dial-Up Networking .........................................................................35

Windows 95/98/ME ..................................................................................35

Windows NT .............................................................................................36

Windows 2000 ..........................................................................................36

Verify TCP/IP Protocol Installation .............................................................36

Windows 95/98/ME ..................................................................................37

Windows NT/2000 ....................................................................................38

Installing the Dial-Up Adapter .....................................................................39

Windows 95/98/ME ..................................................................................39

Windows NT/2000 ....................................................................................39



Packet Data Applet.......................................................... 21

Manual Modem Configuration .....................................................................41

Modem Configuration – Windows 95/98/ME ..............................................41

Install the Modem.....................................................................................41

Configure the Modem Driver ...................................................................42

Create a Dial-up Networking Connection ................................................43

Page 5

Table of Contents

Modem Configuration – Windows NT.........................................................44

Install the Modem.....................................................................................44

Configure the Modem Driver ...................................................................46

Create a Dial-up Networking Connection ................................................47

Modem Configuration – Windows 2000 ......................................................48

Install the Modem.....................................................................................48

Create and Configure a Dial-up Networking Connection ........................49

Modify Dial-up Connection Parameters...................................................51

Modem Profiles and Settings.........................................................................53

HyperTerminal Setup ...................................................................................54

Opening a HyperTerminal Session...............................................................56

Configuring With AT Commands ................................................................57

Modem Initialization ................................................................................57

Restore Factory Defaults..........................................................................57

Activate DTR Monitoring .........................................................................58

Activate DCD Management......................................................................58

Set Computer’s IP Address.......................................................................58

Select iDEN Packet Wireless Data.........................................................59

Select SLIP or PPP...................................................................................59

Mobile IP Activation ................................................................................60

Mobile IP Home Agent Address ...............................................................60

Mobile IP Authentication Key ..................................................................60

Mobile IP Security Parameter Index (SPI)...............................................61

Mobile Node IP Prefix Length..................................................................61

Header Compression ................................................................................62

Page 6

iR1200 Modem

Saving AT Settings....................................................................................62

GPS Default Parameters...............................................................................63

AT Commands................................................................................................65

General AT Commands................................................................................65

User Image Profile Commands.....................................................................66

Registration, Reset, and Authentication Commands ....................................66

Network Status Commands ..........................................................................66

Other Useful AT Commands........................................................................67

Answer...................................................................................................... 67

Command Mode Echo ..............................................................................67

Dial...........................................................................................................68

Hang-up....................................................................................................69

Request Modem Information ....................................................................69

Go Online .................................................................................................69

Pulse Dialing............................................................................................70

Quiet Mode............................................................................................... 70

Tone Dialing.............................................................................................70

Verbose Result Codes ...............................................................................71

Extended Result Codes .............................................................................71

Restore User Defaults ..............................................................................72

DCD Behavior..........................................................................................72

DTR Behavior...........................................................................................73

Restore Factory Default ...........................................................................73

Local Flow Control (Traditional).............................................................74

Display Current Parameter Value............................................................74

Local Character Framing.........................................................................75

Page 7

Table of Contents

Local Flow Control (PCCA).....................................................................75

Local Data Rate .......................................................................................76

Lock/Unlock the DCE...............................................................................77

Change the DCE’s PIN. ...........................................................................77

Packet Data Sleep Timer ..........................................................................78

SLIP MTU ................................................................................................78

Select Mobile IP Client.............................................................................79

Mobile IP Authentication Key ..................................................................79

Mobile IP Session Timer ..........................................................................80

DTE IP Address........................................................................................80

DTE IP Address Prefix Length ................................................................. 81

Data Encryption .......................................................................................81

DTE Stack.................................................................................................82

WDS Stack................................................................................................83

Service Class ............................................................................................83

Packet Data Registration Timeout............................................................83

Circuit Data Auto-Answer ........................................................................84

Circuit Data Establishment Timeout ........................................................ 84

Comma Dial Modifier Timer ....................................................................85

Circuit Data Idle Timer ............................................................................85

S-Registers ......................................................................................................87

S-Registers ...................................................................................................87

Programming the S-Register ........................................................................87

Reading an S-Register Value........................................................................88

Supported S-Registers ..................................................................................88

Page 8

iR1200 Modem

Troubleshooting..............................................................................................91

Common Problems.......................................................................................91

Error Messages.............................................................................................93

Diagnostic Commands .................................................................................94

Extended Error AT Command ..................................................................95

Extended Error Result Codes ...................................................................95

Safety Notice ...................................................................................................99

Safe and Efficient Operation Guidelines ......................................................99

Exposure to Radio Frequency Energy ..........................................................99

Medical and Personal Electronic Devices ....................................................99

Pacemakers ..............................................................................................99

Hearing Aids ..........................................................................................100

Other Medical Devices ...........................................................................100

Interference with Other Electronic Devices................................................100

Appendix A: Glossary ..................................................................................103

Index..............................................................................................................111

Page 9

Table of Contents

IMPORTANT!

Please Read Safety Notice on Page 99

before using the iR1200 Modem.

Last Updated

RFM-4002-5015 Rev 3

November 2003

Page 10

Page 11

Table of Figures

Table of Figures Page

Figure 1 – iR1200 GPS-Enabled Modem 9 Figure 2 – Rear Panel of iR1200 Rugged Modem 11 Figure 3 – Rear Panel of iR1200 GPS-Enabled Modem 11 Figure 4 – Front Panel View of iR1200 Modem 15 Figure 5 – Cabling Diagram (Fixed Environment) 16

RFM-4002-5015 Rev 3

Page 12

iR1200 Modem

2 nextel.com

Page 13

DECLARATION OF CONFORMITY

Responsible party name: eLutions, Inc. Address: 5905 Breckenridge Parkway

Phone number: 1-800-836-9909

Hereby declares that the product:

Product name: iR1200 GPS-Enabled Modem Model Number: 4000-C5-RFM

Product name: iR1200 Rugged Modem Model Number: 4100-C5-RFM

Conforms to the following regulation:

FCC Part 15, subpart B FCC Part 90, subpart S Class B Digital device

Date: May 16, 2003

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 and 90 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. The equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference or by one or more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-- Consult the dealer or an experienced radio/TV technician for help.

FCC Compliance

Per FCC CFR 47 2.989

Suite F Tampa, FL 33610

FCC Compliance

RFM-4002-5015 Rev 3

Page 14

iR1200 Modem

4 nextel.com

Page 15

Required Components

The following table lists components that have been approved for use with the iR1200 Rugged Modem and iR1200 GPS-Enabled modems.

Part No. Description

5000-C5-RFM Magnetic Mount Cellular Antenna 5010-C5-RFM Magnetic Mount Cellular Antenna (spring

wire) 5020-C5-RFM Direct Mount Cellular Antenna 5030-C5-RFM Magnetic Mount GPS Antenna 5040-C5-RFM Fixed Mount Cellular Antenna (spring wire) 5050-C5-RFM Dual Fixed Mount Cellular/GPS Antenna 5060-C5-RFM Dual Covert Mount Cellular/GPS Antenna 5100-C5-RFM Vehicle Power Harness 5200-C5-RFM AC Power Adapter (standard temperature)

How to Order

To obtain any of the items listed above, please contact your Nextel sales representative or visit www.elutions.com/wireless.

RFM-4002-5015 Rev 3

Page 16

iR1200 Modem

Online Documentation

The iR1200 modem is shipped with the following product documentation. Additional copies of these documents can be downloaded (at no charge) online at www.elutions.com/wireless or calling 1-888-349-4338.

Part No. Description

RFM-4000-5015 Installation Guide RFM-4001-5015 Quick Reference Guide RFM-4003-5015 Warranty Card/Installation and Usage

Requirements

6 nextel.com

Page 17

Introduction

Welcome to Nextel

Thank you for purchasing the Nextel iR1200 modem. This modem works on the iDEN network. Once installed and configured, the iR1200 modem

provides users with wireless data communications.

This chapter includes:



Using This Guide Page 7

Nextel Coverage

Nextel Customer Care Information

Page 7

Page 8

Using This Guide

This guide provides instructions for installing the iR1200 Rugged Modem and the iR1200 GPS-Enabled Modem.



Nextel

For details on Nextel digital cellular and data coverage, visit nextel.com.

Coverage

NOTE: Transmission and reception speed may vary, based on your

relative position within the coverage area. If you are in a marginal location (close to the border of the coverage area), the throughput of your modem during data transmission may be affected.

RFM-4002-5015 Rev 3

Page 18

iR1200 Modem



Nextel

Customer Care

For customer care issues including technical support contact Nextel Customer Care at 1-800-639-6111.

When you call, please have a detailed description of your problem. To provide you with fast and quality support, our Customer Care representative may ask for information on the following:

• Computer operating system (Windows 95/98/NT/2000/CE)

• Version of the operating system (e.g. NT 4, Windows 95 Version B, CE

2.1, etc.)

• Information regarding the modem (most can found on the diagnostic menu)

• Geographic location of use

• Extended Error Result Codes

8 nextel.com

Page 19

Overview

This chapter provides general details about the iR1200 modem.

This chapter includes:

General Overview Page 9 Modem Operating Modes Page 10 Modem Configurations Page 10 Modem Specifications Page 12

General Overview

The iR1200 Modem is an iDEN data modem consisting of a modem card and an optional GPS (iR12000 GPS-Enabled Modem) receiver, contained in a rugged enclosure, to provide wireless data communications. The iR1200 modem is easy to mount, whether in a mobile or a fixed environment.

Figure 1. iR1200 GPS-Enabled Modem

RFM-4002-5015 Rev 3

Page 20

iR1200 Modem

Modem Operating Modes

The iR1200 provides the following data connection modes:

• Packet Data: A wireless modem connection used for accessing the Internet, sending and receiving e-mail, and transferring small files over the packet data network using standard IP protocols.

Data is sent in packets (blocks) at high speed.

• Circuit Switched Data: A wireless modem connection for sending and receiving data (faxes, files, etc.) over the circuit-switched cellular channel, providing a direct point-to-point connection with the destination device.

Modem Configurations

Nextel offers two models of the iR1200 Modem. While both are designed to provide wireless communication for rugged environments, one model offers GPS capability as well.

The iR1200 modem can be purchased with the following configurations:

•

iR1200 Rugged Modem (Base Model) - Available in bulk or individual packaging

•

iR1200 GPS-Enabled Modem - Available in bulk or individual packaging

iR1200 Rugged Modem

The following diagram displays the components on the rear panel of the iR1200 Rugged Modem.

10 nextel.com

Page 21

Overview

Ignition Sense /

Bypass

Connector

Modem

Serial Data

Connector

Modem Antenna

Connector

12VDC Power

Connector

Figure 2. Rear Panel of iR1200 Rugged Modem

iR1200 GPS-Enabled Modem

The following diagram displays components on the rear panel of the iR1200 GPS-Enabled Modem.

GPS Antenna

GPS Serial

Data

Connector

GPS Antenna

Connector

Ignition Sense /

Bypass

Connector

Modem

Serial Data

Connector

Modem Antenna

Connector

Figure 3. Rear Panel of iR1200 GPS-Enabled Modem

RFM-4002-5015 Rev 3

12VDC Power

Connector

Page 22

iR1200 Modem

Modem Specifications

Transmission Modes

Rugged metal

enclosure

Status monitoring

LED

External Modem

Software

Internal Modem

Software

Radio Frequency

TX Output Power

Static Sensitivity

Input Voltage

Current

Consumption

Dimensions

Weight

Data Connector

Power Connector

Ignition Connector

Operating

Temperature

Storage Temperature

Humidity

Circuit-Switched, Packet Data & Hayes AT Commands

Extruded Aluminum

One bi-color LED for operating status

User to utilize Windows drivers

Micro controller firmware

Tx 806-821 MHz Rx 851-866 MHz

0.6 W at 25 degrees C

-111dbm @ -10% BER

12VDC nominal, 10 to 16 VDC operating range

0.1 Amps average, 1.5 Amps peak

Approximately 5.04"W x 2.21"H x 7"D

Approximately 625 grams

DB-9 for modem, DB-9 for GPS (optional)

Molex 39-01-2020 with 39-00-0186 pins

Molex 39-01-2040 with 39-00-0186 pins

-25 degrees C to +60 degrees C

-40 degrees C to +85 degrees C

0-95% non-condensing

12 nextel.com

Page 23

Button (RF & Master

Overview

Vibration

Shock

Dust/Water

Resistance

External Reset

reset)

External LED

Lights/Indicators

GPS Receiver

External Antenna

Connectors

Power Requirements

Internal monitoring

with self-reset

capability

per TIA/EIA 603 par 3.3.4

per MIL-STD-810E, method 516.4, procedure I

Dust per MIL-STD-810E, method 510.3, procedure I Water per MIL-STD-810E, method 506.3, procedure II

Yes

6 Single color LEDs for modem RS-232 signal status (TX, RX DR, DSR, CTS, RTS per RS-232-C/E Specifications)

8 channel, NMEA 0183 protocol

Mini UHF female for modem and MCX female for GPS

Yes, Ignition sense, 6'-20' range Yes, 5 sec power-off delay from loss of ignition (12V

still available)

Yes, field support diagnostic screen provided and self-reset

RFM-4002-5015 Rev 3

Page 24

iR1200 Modem

14 nextel.com

Page 25

Getting Started

This chapter describes how to connect your modem to a computer or mobile device in preparation for the configuration process.

This chapter includes:

Connecting the Modem Page 15 Communication Indicators Page 17

Connecting the Modem

The following table describes how to connect the modem to the computer using the RS-232 cable.

Diagnostic Connector

LED (signal indicators)

displays the modem’s

displays the modem’s serial interface status.

serial interface status.

Diagnostic Connector

used to receive modem

diagnostic information.

Status LED

Status LED displays the

displays the

modem’s

iDEN network

status.

Figure 4 – Front Panel View of the iR1200 Modem

RFM-4002-5015 Rev 3

Reset Button used to

power cycle the

power cycle the modem and re-

modem and re-

establishes connection

to the network.

Page 26

iR1200 Modem

COMPUTER

120VAC POWER SUPPLY

GPS ANTENNA (OPTIONAL)

MODEM ANTENNA

IGNITION BYPASS PLUG

POWER

IGNITION

iR1200

Figure 5 – Cabling Diagram (Fixed Environment)

NOTE: DCE (data communication equipment) refers to your iR1200

Modem DTE (data terminal equipment) refers to your computer or mobile device.

1 Make sure that there is no power being supplied to the modem

(unplug the ignition bypass plug or power connector – refer to Figure 5 – Cabling Diagram above).

2 Connect the DB-9-P (male) connector on the cable to the DB-

9-S (female) to the connector DCE (labeled Diagnostic on the modem’s front panel –refer to Figure 4 on page 15).

3 Connect the DB-9-P connector on the cable to the DB-9-S

connector on the DTE.

4 Connect the modem antenna cable to the connector labeled

MODEM antenna on the rear panel of the modem (refer to Figures 2 and 3 on page 11).

RS-232

GPS DATA

RS-232

MODEM DATA

16 nextel.com

Page 27

Getting Started

5 Plug the AC power cord into the 2-prong polarized power

jack located on the rear panel of the modem. Plug the other end into a 120VAC-wall outlet.

6 Insert the ignition bypass plug into the 4-prong polarized

IGNITION jack located on the rear panel of the modem (refer to Figures 2 and 3 on page 11).

7 The STATUS Led light will be solid RED. This indicates that

the modem is attempting to register with the iDEN network.

8 A blinking green light indicates that the modem has

successfully registered with the iDEN network.

Communication Indicators

Your iR1200 modem is equipped with the LED indicators (located on the front panel of the modem – see Figure 4) that identify various communication functions.

The following table contains descriptions of the LED indicators and their functions.

Signal Color Indication

Tx Blinking

Green

Rx Blinking

Green

Modem is transmitting data to the computer data terminal (DTE).

Modem is receiving data from the computer. Modem is receiving data from the DTE.

RTS Green

(Off)

RFM-4002-5015 Rev 3

Request To Send from computer (DTE) is asserted (not asserted).

Page 28

iR1200 Modem

Signal Color Indication

CTS Green

(Off)

DTR Green

(Off)

DSR Green

Clear To Send from modem is asserted (not asserted).

Data terminal equipment is ready (not ready).

Modem is ready (not ready).

(Off)

STATUS Solid Red The modem is searching for a signal

within the Nextel network. If the modem status changes from blinking green back to solid red, the signal has been lost and the modem is attempting to re-acquire.

NOTE: If after several minutes the status

does not return to green, you may be out of range. The modem will attempt to re-acquire automatically when you are back in range.

NOTE: The STATUS indicators are different depending on the mode

in which the modem is operating.

18 nextel.com

Page 29

Getting Started

The following tables describe the STATUS indicators for the Packet Data and Circuit Switched Data operating modes.

Packet Data

STATUS

Blinking

Green

Blinking

Green

Circuit Switched Data

STATUS

Blinking

Green

Solid

Green

In-range (modem is connected to the Nextel network) but idle (but not passing data).

The modem is in use – Nextel network communication is active and is passing data.

In-range (modem is connected to the Nextel network) but idle (but not passing data).

The modem is in use – Nextel network communication is active and is passing data.

RFM-4002-5015 Rev 3

Page 30

iR1200 Modem

20 nextel.com

Page 31

Installing iDEN Packet Data Applet

Installing iDEN Packet Data Applet

In this chapter, you will learn how to install the iDEN Packet Data Applet. The applet enables connectivity for the iR1200 modem connected to a laptop or mobile device and allows you to monitor the service and modem status such as signal strength.

This chapter includes:

Hardware and Installation Requirements Page 21 Before You Begin Page 22 Download and Installation Instructions

Instructions for Windows 95/98/ME Instructions for Windows NT Instructions for Windows 2000

Page 22 Page 23 Page 26 Page 31

Hardware and Installation Requirements

To run the installation program, you will need the following:

• An IBM compatible PC with:

- 586 (or higher) processor

- Microsoft Windows 95, 98, NT or 2000, XP

- Minimum 8 MB of addressable RAM

- 3 MB free hard-disk space

- Recommended: Mouse or compatible pointing device

• Communication software

• Standard Internet browser (such as Internet Explorer or Netscape)

• An active account with Nextel (for connection to the iDEN

network)

RFM-4002-5015 Rev 3

Page 32

iR1200 Modem

NOTE: Please check the Nextel.com website for the latest hardware and

installation requirements.

Before You Begin

Windows must have a Dial-up Networking Version 1.3 or later and the TCP/IP protocol Installed.

NOTE: If the version of your Dial-up Networking is earlier than v1.3,

please go to www.microsoft.com to obtain an upgrade.

Before proceeding, please check that your computer has a network card or security program that prevents IP address changes.

• Windows Dial-Up Networking version 1.3 or higher installed (refer to the “Manual Modem Configuration” chapter in this guide for installation instructions)

• TCP/IP installed (refer to the “Setup Windows Components” chapter in this guide for installation instructions)

• Dial-Up Adapter installed (refer to the “Setup Windows Components” chapter in this guide for installation instructions)

Download Software Instructions

This software configures your computer to receive Packet Data services. It also monitors the service and provides service status information such as battery status and signal strength.

NOTE: Windows NT and 2000 users will need administrator rights to

complete the installation.

22 nextel.com

Page 33

Installing iDEN Packet Data Applet

The following table describes steps to download and install the iDEN data packet applet.

Windows 95/98/ME

1 Access the Nextel website by entering www.nextel.com.

From the Nextel Home Page, select ServicesNextel

Online. The Nextel Online Services page appears.

2 From the Nextel Online page, find and select Wireless

Web AccessPacketstreamGold.

3 The Packetstream Gold Service page appears. 4 Click the Download Packetstream Gold Software (PC

Only) link. The Download Packetstream Gold Software

page appears.

5 Scroll down the page to find and select either Nextel

Online Packetstream Gold Service Install link or the Download Now link located that the bottom of the page.

The download program will copy the files that are needed to install the software to the appropriate location on your

RFM-4002-5015 Rev 3

Page 34

iR1200 Modem

computer.

IMPORTANT: When you have finished downloading the program, you MUST connect the data cable to your modem and computer before proceeding further.

7 Find the program in the appropriate folder and double-click

the Setup.exe to launch the program to initiate the installation process.

NOTE: The setup.exe will be contained in a zip or compressed file.

8 Click Next to accept the default Program Folder, iDEN

Data Modem Applet. The installation program starts, a

status window opens while the files are copying.

9 The Installshield Wizard screen appears during the setup

process.

10 Click Next on the iDEN Packet Data Applet Setup

screen.

11 The iDEN License Agreement screen appears. Select Yes

to accept the terms of the agreement and proceed with the installation.

12 The Customer Information window opens. Enter your

name and company then click Next.

13 The Choose Destination Location window opens. Click

Next to accept the default destination folder, C:\Program Files.

14 The Select Program Folder window opens. Click Next to

accept the default program folder, iDEN Packet Data Applet.

15 After the files are copied, the Question window opens.

Click Yes to add a shortcut to your taskbar then click OK to continue.

24 nextel.com

Page 35

NOTE: Check to make sure that your modem is turned on and

Installing iDEN Packet Data Applet

16 Click OK to the message stating that you “must maximize

the ‘Communication Settings’ window…”.

17 Click Communication Settings on your taskbar to

maximize the window. The Communication Settings window opens.

connected to your computer before continuing with the installation.

18 Select the following value on the Communication Settings

window:

• Click the Auto Detect to have the software automatically check for the COM Port or select the appropriate COM Port (typically COM1)

• Multiple Baudrate should be unchecked

• Baud Rate: 19200 (bps)

The program will check the communication settings and attempt

RFM-4002-5015 Rev 3

Page 36

iR1200 Modem

to connect to the modem.

19 The Packet Data Configuration window opens. Select No,

I would like to configure my modem later or my modem has already been configured then click Next.

20 The Installation Complete window opens. Select Finish

on the following screens to complete the installation process.

21 The Setup Complete window opens. Click Finish.

Windows NT

NOTE: Administrative rights are required to install the software on

Windows NT. Contact your IT Representative or Systems Administrator for assistance.

1 Access the Nextel website by entering www.nextel.com.

From the Nextel Home Page, select ServicesNextel Online. The Nextel Online Services page appears.

26 nextel.com

Page 37

Installing iDEN Packet Data Applet

2 From the Nextel Online page, find and select Wireless

Web AccessPacketstreamGold.

3 The Packetstream Gold Service page appears. 4 Click the Download Packetstream Gold Software (PC

Only) link. The Download Packetstream Gold Software

page appears.

5 Scroll down the page to find and select either Nextel

Online Packetstream Gold Service Install link or the Download Now link located that the bottom of the page.

6 The download program will copy the files that are needed

to install the software to the appropriate location on your computer.

IMPORTANT: When you have finished downloading the program, you MUST connect the data cable to your modem and computer before proceeding further.

7 Find the program in the appropriate folder and double-click

the Setup.exe to launch the program to initiate the installation process.

NOTE: The setup.exe will be contained in a zip or compressed file.

8 Click Next to accept the default Program Folder, iDEN

Data Modem Applet. The installation program starts, a

status window opens while the files are copying.

9 The Installshield Wizard screen appears during the setup

process.

10 Click Next on the iDEN Packet Data Applet Setup

screen.

11 The iDEN License Agreement screen appears. Select Yes

to accept the terms of the agreement and proceed with the installation.

12 The Customer Information window opens. Enter your

name and company then click Next.

RFM-4002-5015 Rev 3

Page 38

iR1200 Modem

13 The Choose Destination Location window opens. Click

Next to accept the default destination folder, C:\Program Files.

14 The Select Program Folder window opens. Click Next to

accept the default program folder, iDEN Packet Data Applet.

15 After the files are copied, the Question window opens.

Click Yes to add a shortcut to your taskbar then click OK to continue.

16 An additional Information window opens. Click OK to

continue with the installation.

17 The Add/Remove Hardware window opens. Click the

Don’t Detect my modem; I will select it from a list of checkbox then click Next.

18 The Modem Selection window opens. From

Manufacturers list box, locate and select Motorola and Motorola iDEN plus Series then click Next.

19 The Port Selection window opens. Highlight the COM port

that your modem is connected and click Next.

20 The Modem Installation Finish window opens. Click

Finish.

21 The Information window opens indicating that you need to

add the modem to the RAS manager and reboot the computer. Click OK to continue.

22 The Network Configuration window opens. Select the

Services tab.

23 The Network Services Selection window opens. Highlight

the Remove Access Service and click Properties.

28 nextel.com

Page 39

Installing iDEN Packet Data Applet

24 The Remove Access Service window opens. Click Add. 25 The RAS Device window opens. Verify that the correct

COM port is displayed in the RAS Capable Device box then click OK.

NOTE: If the Motorola iDEN plus Series modem is not displayed

in the RAS Capable Device box, click the Install Modem button to install the modem again.

26 The Remote Access Setup window now displays the added

COM port.

27 From the Remote Access Setup window, highlight the

COM port/Device that was just added and click Configure. The Configure Port Usage window opens. Click on the

Dial out only radio button then click OK.

28 The Remote Access Setup window opens. Click

Continue. 29 Click Close to the Network Services Selection window. 30 Click Finish on the iDEN Packet Data Applet Setup

window. 31 The Network Settings change/Computer Restart window

opens. Click Yes. 32 The Installshield Wizard window will appear once

Windows has completed the restart process. Click Reinstall

Packet Data Applet icon to proceed with the installation.

NOTE: Check to make sure that your modem is turned on and

connected to your computer before continuing with the installation.

RFM-4002-5015 Rev 3

Page 40

Installation Complete

Finish

iR1200 Modem

33 Select the following value on the Communication Settings

window:

• Click the Auto Detect to have the software automatically check for the COM Port or select the appropriate COM Port (typically COM1)

• Multiple Baudrate should be unchecked

• Baud Rate: 19200 (bps)

The program will check the communication settings and attempt to connect to the modem.

34 The Packet Data Configuration window opens. Select No,

I would like to configure my modem later or my modem has already been configured then click Next.

The

window opens. Select

on the following screens to complete the installation

30 nextel.com

Page 41

iDEN

Installing iDEN Packet Data Applet

process.

36 The Setup Complete window opens. Click Finish.

Windows 2000

NOTE: Administrative rights are required to install the software on

Windows 2000. Contact your IT Representative or Systems Administrator for assistance.

1 Access the Nextel website by entering www.nextel.com.

From the Nextel Home Page, select ServicesNextel

Online. The Nextel Online Service Page appears.

2 From the Nextel Online page, find and select Wireless

Web AccessPacketstreamGold.

3 The Packetstream Gold Service page appears. 4 Click the Download Packetstream Gold Software (PC

Only) link. The Download Packetstream Gold Software

page appears.

5 Scroll down the page to find and select either Nextel

Online Packetstream Gold Service Install link or the Download Now link located that the bottom of the page.

6 The download program will copy the files that are needed

to install the software to the appropriate location on your computer.

IMPORTANT: When you have finished downloading the program, you MUST connect the data cable to your modem and computer before proceeding further.

7 Find the program in the appropriate folder and double-click

the Setup.exe to launch the program to initiate the installation process.

NOTE: The setup.exe will be contained in a zip or compressed file.

Click

to accept the default Program Folder,

Data Modem Applet. The installation program starts and, a

RFM-4002-5015 Rev 3

Page 42

Port Selection

iR1200 Modem

status window opens while the files are copying.

9 The Installshield Wizard screen appears during the setup

process.

10 Click Next on the iDEN Packet Data Applet Setup screen. 11 The iDEN License Agreement screen appears. Select Yes

to accept the terms of the agreement and proceed with the installation.

12 The iDEN Packet Data Applet Setup window will prompt

you to enter a Username and Company. Enter the appropriate information and click Next.

13 The Select Program Folder window opens and you are

asked to name the destination folder, click Next to accept the default.

14 After the files are copied, the Question window opens. You

will be asked if you would like to add the shortcut to your Windows desktop. Select Yes to add the shortcut

15 The Information window opens. Click Yes to begin

installing.

16 An additional Information window opens. Click OK. 17 The Phone and Modem Options window opens with the

Modems tab selected. Click Add.

18 The Add/Remove Hardware window opens. Click the

Don’t Detect my modem; I will select it from a list of checkbox then click Next.

19 The Modem Selection window opens. From

Manufacturers list box, locate and select Motorola and Motorola iDEN plus Series then click Next.

The

32 nextel.com

window opens. Highlight the COM port

Page 43

NOTE: Check to make sure that your modem is turned on and

Installing iDEN Packet Data Applet

that your modem is connected and click Next.

21 The Digital Signature Not Found window opens. Click

Yes to continue the installation.

22 The Modem Installation Finish window opens. Click

Finish.

23 The Phone and Modem Options window reopens with the

Modems tab selected. Verify that the Motorola iDEN plus Series modem appears on the list. Click OK.

connected to your computer before continuing with the installation.

24 Select the following value on the Communication Settings

window:

• Click the Auto Detect to have the software automatically check for the COM Port or select the

RFM-4002-5015 Rev 3

Page 44

iR1200 Modem

appropriate COM Port (typically COM1)

• Multiple Baudrate should be unchecked

• Baud Rate: 19200 (bps)

The program will check the communication settings and attempt to connect to the modem.

25 The Packet Data Configuration window opens. Select No,

I would like to configure my modem later or my modem has already been configured then click Next.

26 The Installation Complete window opens. Select Finish

on the following screens to complete the installation process.

27 The Setup Complete window opens. Click Finish.

34 nextel.com

Page 45

Setting Up Windows Components

In this chapter, you will learn how to set up Windows components and verify their installation.

This chapter includes:

Verifying Dial-Up Networking Page 35 Verify TCP/IP Installation Page 36 Install Dial-Up Adapter Page 39

Verify Dial-Up Networking

This section describes the procedures for verifying dial-up networking on your Windows computer.

If it is determined that your computer does not have dial-up networking, please proceed to the “Manual Modem Configuration” for instructions on how to install dial-up networking.

Windows 95/98/ME

1 From your desktop, double-click the My Computer icon to

open the My Computer window.

2 Double-click the Dial-Up Networking icon to open the

Dial-Up Networking window.

3 Double-click the Make New Connection icon. The Make

New Connection window should appear, indicating that

dial-up networking is installed.

4 Click Cancel to close the Make New Connection window.

RFM-4002-5015 Rev 3

Page 46

iR1200 Modem

Windows NT

1 From your desktop, double-click the My Computer icon to

open the My Computer window.

2 Double-click the Dial-Up Networking icon to open the

Dial-Up Networking window.

3 The Dial-Up Networking window opens and displays the

Phone book entry to dial heading.

If the Dial-Up Networking window displays the Install prompt then dial-up networking has not been installed.

4 Click Close to close the Dial-Up Networking window.

Windows 2000

1 From your desktop, double-click the My Computer icon to

open the My Computer window.

2 Double-click the Control Panel icon. The Control Panel

window opens.

3 Double-click the Networking and Dial-Up Connections

icon. The Make New Connection window should appear, indicating that dial-up networking is installed.

4 Click Close to close the Network and Dial-up

Connections window.

Verify TCP/IP Protocol Installation

The following table describes the steps for verifying TCP/IP Protocol and Dialup Adapter.

36 nextel.com

Page 47

Setting Up Windows Components

Windows 95/98/ME

1 From your desktop, double-click the My Computer icon to

open the My Computer window.

2 Double-click the Control Panel icon to open the Control

Panel window.

3 Double-click the Network icon to open the Network

window.

4 Scroll down the list to find TCP/IP Dial-Up Adapter.

• If you see TCP/IPDial-Up Adapter in the list, click OK; you have TCP/IP installed and can proceed with

installation.

• If you do not see TCP/IPDial-Up Adapter in the list, you will need to add the TCP/IP protocol. Click

Add and proceed with the remaining instructions.

5 The Select Network Component Type window opens.

Highlight Protocol and then click Add.

6 The Select Network Protocol window opens. Under

Manufacturer, select Microsoft. Under Network Protocol, select TCP/IP. Click OK.

7 The TCP/IP Dial-Up Adapter appears in the list.

• If the Dial-Up Adapter appears in the Network Adapters list, it is installed. You may proceed with

installation.

• If the Dial-Up Adapter does not appear in the Network Adapters list, you do not have a Dial-Up

Adapter installed. Refer to page 38 for instructions for installing Dial-Up adapter.

8 Click OK to close the Select Network Protocol window.

RFM-4002-5015 Rev 3

Page 48

iR1200 Modem

Windows NT/2000

In most cases the TCP/IP protocol was installed automatically. However, for Windows NT and 2000, TCP/IP may not have been included in the standard installation. The following steps describe how to check that TCP/IP is in fact installed, and if necessary add the TCP/IP protocol.

NOTE: This may require that you contact your IT Representative or

System Administrator.

1 From your desktop, select StartSettingsNetwork and

Dialup ConnectionsLocal Area Connection. The Local

Area Connection window opens.

2 Click the Properties button on the Local Area Connection

window.

3 Is the Internet Protocol listed under the Components

listing?

4 If the Internet Protocol is not listed, click the Install

button. The Select Network Component Type window opens.

5 Under Network Component Type listing, highlight

Protocol and click Add.

6 The Select Network Protocol window opens. Under

Network Protocol listing, highlight Internet Protocol and click OK.

7 The installation will now begin — if prompted do NOT

restart.

38 nextel.com

Page 49

Network and Dial Up Connections

Setting Up Windows Components

Installing the Dial-Up Adapter

The following table describes the steps for installing the Dial-Up Adapter.

Windows 95/98/ME

1 From the Select Network Adapter window, highlight

Dial-Up Adapter in the Network Adapters list. 2 Under Manufacturers, highlight Microsoft. Click OK. 3 The Select Network Component Type window opens.

Highlight Adapter. Click Add. 4 The Select Network Adapters window opens. 5 To verify that the adapter was added, from Start, select

Settings.

• Select Control Panel.

• Click Network.

• Look for Dial-Up Adapter on the Network

Configuration screen.

Windows NT/2000

The Dial-Up Adapter may not have been included in the standard installation. The following steps describe how to check that TCP/IP is in fact installed, and if necessary add the TCP/IP protocol.

NOTE: This may require that you contact your IT Representative or

System Administrator.

1 Select Start SettingsControl Panel. The Control

Panel window opens. Double click on Network and Dial

Up Connections.

The

window opens.

Double click on Make New Connection which brings up

RFM-4002-5015 Rev 3

Page 50

iR1200 Modem

the connection wizard. Click Next. 3 Select I want to set up my Internet connection manually

as above, then click on Next. 4 Select I connect through a phone line and a modem then

click on Next. 5 Enter the new phone number:

• Packet Data enter: s=2

• Circuit Switched enter: ISP Phone Number

Click on the Advanced button.

6 The Advance Connection Properties window opens. On

the Connection tab, select PPP and for Logon procedure

select None.

7 Click on the Addresses tab. Select My ISP automatically

provides... Click on OK to return to the phone number

screen. Click on Next to continue. 8 Enter your username and password then click Next. 9 Enter a connection name such as “iR1200 Modem” or

“iDEN Connection” and then click Next. 10 Select No and click Next. Click on Finish to complete the

setup.

40 nextel.com

Page 51

Install New Modem/Modem Detection

Manual Modem Configuration

In this chapter, you will learn how to manually add a modem, configure the modem drivers and create a dial-up networking connection for Nextel.

NOTE: Use these instructions only if you did not previously install the

This chapter includes:



iDEN

Packet Data Applet.

Modem Configuration – Windows 95/98/ME Page 41

Modem Configuration – Windows NT 4.0 Page 44 Modem Configuration – Windows 2000 Page 48

Modem Configuration – Windows 95/98/ME

Install the Modem

1 Go to Start Settings Control Panel and click on the

Modems icon. 2 The Modem Properties window opens. Select the General

tab and click Add. 3 The Install New Modem window opens. Select Other.

Click Next. 4 The Install New Modem/Hardware Installation window

opens. Check the Don’t run the Hardware Installation

Wizard box. Click Next.

NOTE: If this option is not available, proceed to the next step.

The

opens. Check the Don’t detect my modem; I will select

window

RFM-4002-5015 Rev 3

Page 52

iR1200 Modem

from a list box. Click Next. 6 The Install New Modem/Modem Selection window

opens. Under Manufacturer, select Standard Modem

Types. Under Models, click Standard 19200 bps Modem.

Click Next. 7 Select the COM port that you will be using to connect to the

modem (i.e., COM1, COM2, or COM3), then click Next.

NOTE: If you are not sure which COM port to use, begin with

COM1. If you are unable to connect to a network using COM1,

you will need to reinstall the modem after attaching the modem

to a different COM port.

8 The Install New Modem/Modem Installation Finish

window opens. Click Finish.

9 Continue with the steps to Configure the Modem Driver.

Configure the Modem Driver

1 From the Modems Properties window, select Standard

19200 bps Modem. Click Properties. 2 The Standard 19200 bps Modems Properties window

opens. On the General tab, confirm the Maximum Speed

is 19200 bps. 3 Click the Connection tab and verify the following settings:

• Data Bits: 8

• Parity: None

• Stop Bits: 1

Click Advanced. 4 The Advanced Connection Settings window opens. If they

are not selected already, select the following:

42 nextel.com

Page 53

Setup Finish

Finish

Manual Modem Configuration

• Use Flow Control and

• Hardware (RTS/CTS)

• If the Duplex option is present, select Full.

5 Click OK to close the Advanced Connection Settings

window.

6 Click OK (or Close) to close the Standard 19200 bps

Modem’s Properties window. 7 Click Close to close the Modem’s Properties window. 8 Click Close to close the Control Panel. 9 Continue with the steps to Create a Dial-Up Networking

Connection.

Create a Dial-up Networking Connection

1 With the My Computer window open, double-click the

Dial-Up Networking icon. 2 The Dial-Up Networking window opens. Double-click

Make New Connection. 3 The Make New Connection window opens. Enter a name

for the connection, such as iR1200 Modem. Under Select a

device, use the drop-down box to locate and select

Standard 19200 bps Modems. Click Next. 4 The Make New Connection window changes and now

displays fields for entering the phone number. Delete any

information contained in the Area Code box.

• For Packet Data: At Telephone number, enter s=2.

• For Circuit Switched Data: Enter the ISP phone

number. Click Next. The

RFM-4002-5015 Rev 3

window opens, click

. This

Page 54

iR1200 Modem

procedure creates the iR1200 Modem icon in the Dial-Up Networking window.

6 In the Dial-Up Networking window, right click iR1200

Modem. Click Properties.

7 The iR1200 Modem Network window opens. Click the

Server Types tab.

NOTE: For packet data, country code and area code (under the General Tab) should always be blank to allow s=2 to be the telephone number.

8 Under Type of Dial-Up Server, select PPP.

Under Allowed Network Protocols, ensure that the box next to TCP/IP is checked. Remove the check marks from all other selection boxes.

Click the TCP/IP button.

9 The TCP/IP Settings window opens. Ensure that the

following are checked:

• Server assigned IP address

• Server assigned name server addresses

• Use IP header compression

• Use default gateway on remote network

All other boxes should remain unchecked. Click OK.

10 Click OK to complete the set up

Modem Configuration – Windows NT

Install the Modem

1 Go to Start Settings Control Panel and click on the

Modems icon.

44 nextel.com

Page 55

Remote Access Setup

Add

the other modem before proceeding. Otherwise a conflict will

Manual Modem Configuration

2 The Modems Properties window opens. Under the

General tab click Add.

3 The Install New Modem window opens. Select Other then

Next.

4 The Install New Modem/Hardware Installation window

opens. Check the Don't run the Hardware Installation Wizard box. Click the Next button.

NOTE: If this option is not present, proceed to the next instruction.

5 The Install New Modem/Modem Detection window

opens. Check the Don't detect my modem; I will select it

from a list box. Click Next.

6 The Install New Modem/Modem Selection window

opens. Under Manufacturer, select (Standard Modem Types). Under Models, click Standard 19200 bps Modem. Click Next.

7 The Port Selection window opens. Highlight the COM port

that you will be using to connect to the phone. Click Next.

8 The Modem Installation Finish window opens. Click

Finish.

9 The Modems Properties window reappears with the newly

added Standard 19200 bps modem displayed in the dialog box. Click Close.

10 The following message appears: Dial-Up Networking

needs to be configured because the list has changed. Do you wish to reconfigure? Click Yes.

The

NOTE: In Windows NT, only one modem can be installed per COM port. If you are attempting to install the Standard 19200 bps modem on a COM port to which another modem is directed, you must choose an alternate COM port or remove

RFM-4002-5015 Rev 3

window opens. Click

Page 56

iR1200 Modem

occur and Windows NT will not recognize the Standard 19200 bps modem.

12 The Add RAS Device window opens. Make sure the proper

COM port for your modem connection is selected. Click

OK.

13 The Remote Access Setup window now shows the added

COM port. Click Continue.

14 The system automatically configures the appropriate

settings.

15 Continue with the steps to Configure the Modem Driver.

Configure the Modem Driver

1 From the Modems Properties window, select the

Standard 19200 bps Modem. Click Properties.

2 The Standard 19200 bps Modems Properties window

opens. On the General tab, confirm the Maximum Speed is 19200 bps.

3 Click the Connection tab and verify the following settings:

• Data Bits: 8

• Parity: None

• Stop Bits: 1

Click Advanced.

4 The Advanced Connection Settings window opens. If they

are not selected already, select the following:

• Use Flow Control and

• Hardware (RTS/CTS)

• If the Duplex option is present, select Full.

46 nextel.com

Page 57

Dial-Up Networking Phonebook

Manual Modem Configuration

5 Click OK to close the Advanced Connection Settings

window.

6 Click OK (or Close) to close the Standard 19200 bps

Modems Properties window.

7 Click Close to close the Modem's Properties window. 8 Click Close to close the Control Panel. 9 Continue with the steps to Create a Dial-Up Networking

Connection.

Create a Dial-up Networking Connection

1 With the My Computer window open, double-click the

Dial-Up Networking icon.

2 The Dial-Up Networking window opens. Click New. 3 The New Phonebook Entry Wizard window opens. Enter

a name for the phonebook entry such as iR1200 Modem. Click Next.

4 The Server window opens. Check the box next to I am

calling the Internet. Click Next.

5 The Modem or Adapter window opens. Select the

Standard 19200 bps Modem. Click Next.

6 The Phone Number window opens. In the Phone number

box, enter the following:

• For Packet Data: s=2

• For Circuit Switched Cellular: ISP Phone Number.

Click Next.

7 The Wizard Finish window opens. Click Finish.

The

window opens with

the iR1200 Modem entry displayed. Click More and select

RFM-4002-5015 Rev 3

Page 58

iR1200 Modem

Edit entry and modem properties from the drop-down list.

9 The Edit Phonebook Entry window displays. Click the

Server tab.

10 In the Dial-up server type, select PPP. Under Network

protocols, check the box next to TCP/IP. Remove the

check marks from all other selection boxes. Click the

TCP/IP button.

11 The PPP TCP/IP Settings window opens. Ensure that the

following are checked:

• Server assigned IP address

• Server assigned name server addresses

• Use IP header compression

• Use default gateway on remote network

All other boxes should remain unchecked. Click OK.

12 Click OK to complete the set up.

Modem Configuration – Windows 2000

Install the Modem

1 Go to Start Settings Control Panel and click on the

Phone and Modem icon.

2 The Phone and Modem Options window opens. Click the

Modems tab.

3 The Modems window opens. Click Add. 4 The Install New Modem window opens. Check the Don't

detect my modem; I will select if from a list box then click Next.

48 nextel.com

Page 59

Manual Modem Configuration

5 The Modem Detection window opens. Under

Manufacturer, select (Standard Modem Types). Under Models, click Standard 19200 bps Modem. Click Next.

6 The Port Selection window opens. Highlight the COM port

that you will be using to connect to your modem (i.e., COM1, COM2, COM3, etc.). Click Next.

7 The Digital Signature Not Found window opens. Click

Yes to proceed.

8 The Modem Installation Finish window opens. Click

Finish.

9 The Modems window reappears with the newly added

Standard 19200 bps modem displayed in the dialog box. Click OK.

Create and Configure a Dial-up Networking Connection

1 From the computer’s desktop, double-click the My

Computer icon. Then, double-click the Control Panel

icon.

2 The Control Panel window opens. Double-click on the

Network and Dial-up Connections icon.

3 The Network and Dial-up Connections window opens.

Double-click on Make New Connection.

4 The Network Connection Wizard window opens. Click

Next.

5 The Network Connection Type window opens. Select

Dial-up to the Internet and click Next.

6 The Welcome to the Internet Connection Wizard opens.

Select I want to set up my Internet connection manually, or I want to connect through a Local Area Network (LAN) and click Next.

RFM-4002-5015 Rev 3

Page 60

iR1200 Modem

7 The Setting up your Internet connection window opens.

Select I connect through a phone line and a modem and click Next.

8 The Choose Modem window opens. From the drop-down

box, select Standard 19200 bps Modem and click Next.

9 The Internet Connection, Step 1 window opens. Enter a

temporary telephone number (this phone number will be modified in Modem Properties later in the configuration). Make sure that the Use area code and dialing rules is

NOT checked. Click Advanced.

10 The Advanced Connection Properties window opens with

the Connection tab selected. Verify the following settings:

Under Connection type:

• PPP (Point-to-Point Protocol) – should remain

checked

• Disable LCP Extensions – should remain checked

• SLIP – should remain unchecked

• C-SLIP – should remain unchecked

Under Logon procedure:

• None – should remain checked

• Log on manually – should remain unchecked

• Use logon script – should remain unchecked.

11 Click the Addresses tab and verify the following settings:

Under IP address:

• Internet service provider automatically provides

one –should remain checked

50 nextel.com

Page 61

Manual Modem Configuration

• Always use the following – should remain unchecked

Under DNS server address:

• My ISP automatically provides a DNS address –

should remain checked

• Always use the following – should remain unchecked. Click OK.

12 The Internet Connection, Step 2 window opens. User

name and password are not required fields. Click Next. You will receive two warning boxes asking if you want to continue with a blank user name and a blank password. Click Yes on both boxes.

13 The Internet Connection, Step 3 window opens. Enter a

name for the connection, such as iR1200 Modem. Click

Next.

14 The Set Up Your Internet Mail Account window opens.

Select No (optional) and click Next.

15 The Completing the Internet Connection Wizard

window opens. Click Finish.

Modify Dial-up Connection Parameters

1 From the computer’s desktop, double-click the My

Computer icon. Then, double-click the Control Panel

icon.

2 The Control Panel window opens. Double-click on the

Network and Dial-up Connections icon.

3 The Network and Dial-up Connections window opens

with the new iR1200 Modem icon inside.

4 Right-click on the iR1200 Modem connection icon and

select Properties.

RFM-4002-5015 Rev 3

Page 62

iR1200 Modem

5 The iR1200 Modem window opens. Select the General

tab. In the Phone number box, erase the temporary phone number previously entered:

• For Packet Data enter: s=2

• For Circuit Switched Cellular enter: the ISP phone

number

Click OK.

52 nextel.com

Page 63

Modem Profiles and Settings

In this chapter, you will learn how to use AT commands to setup parameters and configure the iR1200 modem for usage.

This chapter includes:

HyperTerminal Setup Page 54 Opening HyperTerminal Session Page 56 Configuring with AT Commands

Modem Initialization Restore Defaults Activate DTR Monitoring Activate DCD Management Set Computer’s IP Address Select iDEN Packet Wireless Data Select SLIP or PPP Mobile IP Activation Mobile IP Home Agent Address Mobile IP Authentication Key Mobile IP Security Parameter Index (SPI) Mobile Node IP Prefix Length Header Compression Saving AT Settings

GPS Default Parameters

RFM-4002-5015 Rev 3

Page 57 Page 57 Page 57 Page 58 Page 58 Page 58 Page 59 Page 59 Page 60 Page 60 Page 60 Page 61 Page 61 Page 62 Page 62

Page 63

Page 64

iR1200 Modem

HyperTerminal Setup

A HyperTerminal session must be setup for you to enter AT commands. The following table outlines steps to setup a HyperTerminal session for the

iR1200 modem:

1 From your computer, locate and select the HyperTerminal

program.

2 The Connection Description screen appears.

3 Type a description of the connection in the Name: box. 4 Select the dial function (red and yellow phone icon) and

click OK.

5 The Connect To screen appears.

54 nextel.com

Page 65

Modem Profiles and Settings

6 Select the appropriate communication port (typically

COM1) from the “Connect Using:” drop-down list then Click OK.

7 The COM1 Properties screen appears.

8 Select the following parameters from each of the drop-

down list on the Port Settings tab:

• Bits Per second: 19200

• Data Bits: 8

RFM-4002-5015 Rev 3

Page 66

iR1200 Modem

• Parity: None

• Stop Bits: 1

• Flow Control: Hardware

9 Click OK when all the parameters have been selected. 10 Test to make sure that you have established communication

with the modem by typing the AT command “ATi4” and pressing Enter.

11 You should see a message “Nextel, iDEN OK” or “Nextel,

iDEN 0”.

Opening a HyperTerminal Session

The following table describes steps to start a HyperTerminal Session:

1 Windows 2000/XP/Windows 98:

StartProgramsAccessoriesCommunicationsHyper Terminal.

2 Windows NT:

StartProgramsAccessoriesHyperTerminalHyperT erminal

3 The HyperTerminal window will open. You are now ready

to issue AT commands to the Modem.

56 nextel.com

Page 67

Modem Profiles and Settings

Configuring With AT Commands

Modem Initialization

The iR1200 modem’s factory default image 2 is configured to start up with packet data. If you are using circuit switched data, we recommend that you

Step 1 – Backup image 2 (default) to image 1

AT Command Save User Default profile 2 to

profile 1 Command Syntax AT&W1 Expected Return Code(s) OK

Step 2 – Change default call setting (packet data) to circuit switched

AT Command Change Call Setting Parameter Command Syntax ATZ0 Expected Return Code(s) OK

Step 3 – Save new setting as default profile.

AT Command Save User Default

Configuration Command Syntax AT&W2 Expected Return Code(s) OK

Restore Factory Defaults

To ensure a clean configuration process, you should restore the current values to their factory default values by applying the following.

AT Command Restore Factory-Default

RFM-4002-5015 Rev 3

Page 68

iR1200 Modem

Configuration Command Syntax AT&F Expected Return Code(s) OK

Activate DTR Monitoring

The DCE does not monitor the DTR line of the DTE/DCE physical connection. This is the default factory setting. To activate DTR monitoring in the DCE, you must apply the following command.

AT Command DTR Behavior Command Syntax AT&D2 Expected Return Code(s) OK

Activate DCD Management

The factory default for the modem keeps the Data Carrier Detect (DCD) line of the computer-to-modem physical connection active at all times. Some communication programs monitor this line to determine the status of the connection. To promote compatibility with these programs, enable DCD management in the modem.

AT Command DCD Behavior Command Syntax AT&C1 Expected Return Code(s) OK

Set Computer’s IP Address

Inform the modem of the computer’s IP address to establish SLIP or PPP connection between the modem and the computer.

AT Command Computer IP Address Command Syntax AT+WPNEI=XXX.XXX.XX,

58 nextel.com

Page 69

Expected Return Code(s) OK

IMPORTANT INFORMATION: Customers cannot ping a Non Routable IP address when provisioned due to the NAT (Network Address Translator) Server. This server

attaches a Class C Public IP Address to a Private Class A Non Routable IP address for a specific period of time to browse the public internet. This Class C address is needed in order to route on the public internet, as Non-Routable IPs are for internal routing only (Intranet).

Modem Profiles and Settings

0,0,0

(Insert appropriate IP address

where X appears.)

Select iDEN



Packet Wireless Data

The iR1200 modem supports multiple wireless data formats. Select the desired data service by applying the following command.

AT Command Select WDS-side stack Command Syntax AT+WS46=24 Expected Return Code(s) OK

Select SLIP or PPP

By default, the modem attempts to establish a PPP connection. To specify the type of connection the modem will establish, apply the following command

AT Command Select computer-side stack Command Syntax AT+WS45=4 (PPP)

AT+WS45=3 (SLIP) Expected Return Code(s) OK

RFM-4002-5015 Rev 3

Page 70

iR1200 Modem

Mobile IP Activation

The modem makes use of mobile IP to manage a truly mobile computer. You may use a Mobile IP stack on the computer or use the Mobile IP stack built into the modem.

By default, the modem is configured to work with a third-party stack. If you desire this mode of operation, skip ahead to the “Configure Encryption Settings”. Otherwise, you must activate the Mobile Node functionality within the modem as well the security-related parameters.

NOTE: The Data Terminal Equipment (DTE) uses a TCP/IP stack to format the data message with standard TCP/IP protocols used on the Internet. The iR1200 modem does not have a TCP/IP stack. The “mobile-IP stack”

capability of the iR1200 is required to transmit data on the iDEN network.

AT Command Modem Mobile IP Control Command Syntax AT+WV300=1 (activate)

AT+WV300=0 (deactivate) Expected Return Code(s) OK

Mobile IP Home Agent Address

You must supply the IP address for the Home Agent. This is accomplished by applying the following command

AT Command MIP Home Agent Address Command Syntax AT+WV305=XXX.XXX.XX

(Insert appropriate IP address

where X appears.) Expected Return Code(s) OK

Mobile IP Authentication Key

The Mobile IP Authentication Key is used as a PIN number to validate your Mobile IP connection with the Home Agent.

60 nextel.com

Page 71

Modem Profiles and Settings

AT Command MIP Authentication Key Command Syntax AT+WV301=”AAAXXX”

(Make sure that the

Authentication Key Name is

entered with the quotation

mark. Substitute the values

within the quotation with the

one supplied by your system

administrator or service

provider.) Expected Return Code(s) OK

Mobile IP Security Parameter Index (SPI)

The SPI is similar to the Authentication Key in that the modem and the home Agent must have identical values registered for the computer.

AT Command MIP Security Parameter Index Command Syntax AT+WV309=XXX

(Insert appropriate SPI where X

appears, the SPI can be

obtained from your system

administration or service

provider.) Expected Return Code(s) OK

Mobile Node IP Prefix Length

The IP address prefix length is the number of contiguous bits that make up the network prefix of that address. This command allows you to specify the prefix length of the computer’s IP address.

AT Command Mobile Node IP Prefix Length Command Syntax AT+WV311=X

RFM-4002-5015 Rev 3

Page 72

iR1200 Modem

(Insert appropriate prefix length

where X appears.) Expected Return Code(s) OK

Header Compression

This command enables or disables TCP header compression options. Some DTE-side stacks (such as PPP) will negotiate local header compression independently from this setting. To disable header compression, apply this command.

AT Command Header Compression Command Syntax AT+ws182=<header

compression>

AT+ws182? (?=Query

parameter)

AT+ws182=? (?=Range

Parameter) Parameter Value 0 = over the air and local header

compression enabled.

1 = over the air header

compression enabled.

2 = Local header compression

enabled

3 = header compression

disabled.

Expected Return Code(s) OK

Saving AT Settings

Your modem is now properly configured for Nextel’s iDEN network.

62 nextel.com

Page 73

Modem Profiles and Settings

IMPORTANT: These settings are stored on the modem’s Random Access Memory (RAM) and are lost when the modem is turned off unless stored in the modem’s non-volatile memory.

The iR1200 modem can store up to three profile or image. By default, image 2 is loaded when the modem is powered on. We recommend that you save this setting to the first profile/image.

AT Command Save User Default

Configuration Command Syntax AT&W1 Expected Return Code(s) OK

GPS Default Parameters

The iR1200 GPS-Enabled modem will use the following NMEA default parameters.

The factory default port characteristics are:

• Baud rate = 4800 bps

• Data bits = 8

• Stop bits = 1

• Parity = None

Note: These settings should not be changed unless absolutely

necessary.

RFM-4002-5015 Rev 3

Page 74

iR1200 Modem

64 nextel.com

Page 75

AT Commands

This chapter describes common AT commands that can be applied to the iR1200 modem.

This chapter includes:

General AT Commands Page 65 User Image Profile Commands Page 66 Registration, Reset, and Authentication

Page 66

Commands Network Status Commands Page 66 Other Useful Commands Page 67

General AT Commands

Command Usage Action

AT AT Checks communication. ATEx ATE0 or ATE1 Sets echo on or off. AT&V AT&V Displays modem

parameters.

AT+IPR AT+IPR = baud rate Sets the modem’s baud

rate.

RFM-4002-5015 Rev 3

Page 76

iR1200 Modem

User Image Profile Commands

Command Usage Action

ATz ATz0, ATz1, or

ATz2

Sets the specified image as the active image.

AT&Wx AT&W0, 1, or 2. Writes active image to the

specified profile

Registration, Reset, and Authentication Commands

Command Usage Action

AT+wvreset AT+wvreset Resets the modem and

performs power cycle.

AT+wvmr AT+wvmr=’xxxx’

(0000)

AT+wvcsk AT+wvcsk=’xxxx’

(0000)

AT+wvrsk AT+wvrsk=’xxxx’

(0000)

AT+WPDEREG AT+WPDEREG Forces modem to

AT+WPREG AT+WPREG Forces mode to register

Mater Resets the modem.

Changes authentication service key.

Resets the service key to all 0’s.

deregister.

Network Status Commands

Command Usage Action

66 nextel.com

Page 77

AT Commands

AT+WS53? AT+WS53? Checks Signal Quality AT+WS50? AT+WS50? Check Signal Strength AT+WPSTATE AT+WPSTATE Checks mobile IP

registration

AT+WPREG AT+WPREG DTE IP Address

Other Useful AT Commands

The following table outlines other common AT commands for your reference.

Answer

This command instructs the DCE to immediately connect to the call and start the answer sequence, as appropriate for the selected service.

Command A

Action ATa Query Range

Command Mode Echo

The setting for this parameter determines whether or not the DCE echoes characters received from the DTE during command state and online command state.

Command E

Action ATe <echo> Query AT&v Range Parameter 0 = Disabled command mode character echo.

RFM-4002-5015 Rev 3

Page 78

iR1200 Modem

Values:

1 = Enabled command mode character echo.

Dial

This command instructs the DCE to originate a call. When the DCE receives the dial string from the computer, all non-numeric characters in the Dial String that are not recognized dial-modifiers are ignored. This allows the DTE to request modem numbers containing unsupported dial modifiers, hyphens, parenthesis, and other punctuation.

Command D

Action ATd <Dial String> Query Range Parameter

Values (dial modifiers) :

Dial string contains a modem number to be dialed, translated into an array of ASCII characters between 0 and 9 inclusive

T = Allowed, but ignored by the modem. P = Allowed, but ignored by the modem. ! = Hook Flash (1/2 second). W = Wait for time specified in S7 for dial tone. (blank) = Wait for time specified in S7 for one or more

rings followed by five seconds of silence before continuing execution of dial string.

, = Pause for time specified in S8 ; = After dialing return to command mode.

68 nextel.com

Page 79

AT Commands

Hang-up

This command instructs the modem to terminate the active call.

Command H

Action ATh Query Range

Request Modem Information

This command causes the modem to issue a string to provide product information.

Command I

Action ATi <request> Query Range Parameter

Values:

0 = OK Response code 1 = iDEN DTE/DCE Specification Version 2 = Software Model 3 = Product Model 4 = Product Manufacturer

Go Online

This command causes the modem to enter the online state from the online command state.

Command O

Action Ato

RFM-4002-5015 Rev 3

Page 80

iR1200 Modem

Query Range

Pulse Dialing

This command selects pulse dialing. It is provided for compatibility purposes.

Command P

Action Atp Query Range

Quiet Mode

This command controls whether or not the result codes are sent to the computer. If turned on, the Result Code Format and Extended Result code commands may further modify the result codes.

Command Q

Action ATq <setting> Query Range Parameter

Values:

0 = Result codes sent 1 = Result codes not sent

Tone Dialing

This command selects DTMF dialing. It is provided for compatibility purposes and has no processing effect.

Command T

70 nextel.com

Page 81

AT Commands

Action ATt Query Range

Verbose Result Codes

This command sets your preference for the result code format. It allows the computer to select either Terse or Verbose result code formats.

Command V

Action ATv <setting> Query AT&v Range Parameter

Values:

0 = Numeric result code format 1 = Verbose result code format

Extended Result Codes

This command provides an extended result code selection.

Command X

Action ATx <setting> Query AT&v Range Parameter

Values:

0, 1 = The modem does not return the BUSY or NO DIALTONE result codes.

2 = The modem might return the NO DIALTONE result code if appropriate, but does not return the BUSY result code.

3 = The modem may not return the BUSY result code, if

RFM-4002-5015 Rev 3

Page 82

iR1200 Modem

appropriate, but does not return the NO DIALTONE result code.

4 = The modem may return either the BUSY or NO DIALTONE result code, if appropriate.

Restore User Defaults

This command causes the modem to reset all parameters and S-registers to their user-defined default values. There are three sets of user defaults (or images). The parameter selects between which image is being requested.

Command Z

Action Atz <image> Query Range Parameter

Values:

0 = Local user image 0 1 = Local user image 1 2 – Local user image 2

DCD Behavior

This parameter determines how the DCD line relates to the detection of received line signals from the distant end.

Changing the parameter takes effect immediately in both the command and online command states.

Command &C

Action AT&c <setting> Query AT&v

72 nextel.com

Page 83

Range

AT Commands

Parameter Values:

0 = DCD always on 1 = The modem turns on the DCD to indicate the

presence of a connection, and turns off the DCD to indicate the loss of connection.

DTR Behavior

This parameter determines how the computer responds when the DTR line is changed from the ON condition to the OFF condition during the online data state.

Command &D

Action AT&d <setting> Query AT&v Range Parameter

Values:

0 = Modem ignores DTR 1 = If the DTR is turned ON while in online data mode,

the mode returns the command mode and issues the OK result code. The call remains connected.

2 = If the DTR is turned OFF while in online data mode, the modem disconnects the call and returns the OK result code. If DTR is OFF while in command mode, the modem will not answer an incoming call, regardless of the setting, S0 (automatic answer).

Restore Factory Default

This command causes the modem to reset all parameters and S-registers to their factory defined default value. The optional parameter value, if present must be

Command &F

RFM-4002-5015 Rev 3

Page 84

iR1200 Modem

Action AT&f <setting> Query AT&v Range

Local Flow Control (Traditional)

This parameter selects the type of flow control used between the computer and the modem while in data transfer mode. This command is supported for backward compatibility purposes. This command sets the method of flow control for both directions of the computer-to-modem interface, while the +IFC command allows for a separate setting for each direction.

The setting for this command may implicitly alter the settings of the +IFC command.

Command &K

Action AT&k <setting> Query Range Parameter

Values:

0 = No Flow Control (not recommended) 3 = RTS/CTS Flow Control. 4 = XON/XOFF Flow Control.

Display Current Parameter Value

This command allows the computer to view the parameter and S-register settings for the active configuration profile.

Command &V

Action AT&fv <setting>

74 nextel.com

Page 85

AT Commands

Query Range

Local Character Framing

This parameter determines the local serial port asynchronous data framing. The second parameter is needed only if you select fewer than eight data bits.

Command &ICF

Action AT+icf <framing>, <parity> Query AT+icf? Range AT+icf? Framing

Parameter Values:

Parity Parameter Values:

0 = AutoDetect 3 = 8 data bits, 1 stop bit 5 = 7 data bits, 1 parity bit, 1 stop bit

0 = Odd 1 = Even 2 = Mark 3 = Space

Local Flow Control (PCCA)

This extended compound parameter controls, the local flow control between the computer and the modem. The two numeric sub-parameters are DCE_by_ DTE (which controls the data format he modem) and DTE_by_DCE (which controls the data from the computer).

NOTE: To change the setting of these parameters, use the &K

command.

Command +IFC

Action AT+ifc <DCE_by_DTE>, <DTE_by_DCE> Query AT+ifc? Range AT+ifc=?

RFM-4002-5015 Rev 3

Page 86

iR1200 Modem

DCE_by_ DTE Parameter Values:

0 = No flow control was set by DTE. 1 = XON/XOFF; do not pass XON/XOFF characters to

the remote DCE. 2 = RFR active/inactive flow control 3 = XON/XOFF; Pass DC1/DC3 characters to the

remote DCE in addition to acting upon local flow control.

DTE_by_ DCE Parameter Values:

0 = No flow control was set by DTE. 1 = XON/XOFF flow control 2 = CTS/RFS active/inactive flow control

Local Data Rate

This numeric extended-format parameter specifies the data rate between the DTE and the DCE.

Command +IPR

Action AT+ipr=<rate> Query AT+ipr? Range AT+ipr=?? Parameter

Values:

0 = Automatic detection on baud rate, data framing 300 = Transmission speed in bits per second. 2400 = Transmission speed in bits per second. 4800 = Transmission speed in bits per second. 9600 = Transmission speed in bits per second. 19200 = Transmission speed in bits per second.

76 nextel.com

Page 87

AT Commands

38400 = Transmission speed in bits per second. 57600 = Transmission speed in bits per second. 115200 = Transmission speed in bits per second.

Lock/Unlock the DCE

When the DCE is locked, communication over the serial port to the modem is suspended.

NOTE: If the PIN was removed (by setting its value to the empty string

(“ ”), the DTE must still specify the PIN, represented by the empty string.

Command +WCLK

Action AT+wclk=<LockStatus>, <PIN> Query Range AT+WCLK=? Parameter

Values – Lock

0 = Unlock the DCE 1 = Lock the DCE

Status: PIN

A PIN is stored as a series of alphanumeric characters, with a maximum length of 8 characters. If more than 8 characters are set as a PIN, only the first 8 are recognized.

Change the DCE’s PIN.

This command sets the PIN that locks or unlocks the DCE.

NOTE: You must specify the desired PIN, as well as the current PIN.

The factory-default PIN is the “empty string” or a value of “ ”.

RFM-4002-5015 Rev 3

Page 88

iR1200 Modem

Command +WCPN

Action AT+wcpn=<newPIN>, <oldPIN> Query Range AT+wcpn=? Parameter

Values:

A PIN is stored as a series of alphanumeric characters, with a maximum length of 8 characters. If more than 8 characters are set as a PIN, only the first 8 are recognized.

Packet Data Sleep Timer

This timer controls the length of time the DCE stays on a packet channel though no traffic is actively being transferred.

Command +WS175

Action AT+ws175<timer> Query AT+ws175? Range AT+ws175=? Parameter

Values:

0 = Disable sleep timer 5-255 = Seconds before sleeping 10 = Default value

SLIP MTU

This setting specifies the Maximum Transmitted Unit used by SLIP connections. (PPP Connections negotiates this value).

Command +WV312

Action AT+wv312=<MTU>

78 nextel.com

Page 89

Query AT+wv312? Range AT+wv312=?

AT Commands

Parameter Values:

68-1500 = MTU Value Range 1006 = Default Value

Select Mobile IP Client

This parameter activates/deactivates the Mobile Node client in the DCE. The mobile host can operate in two modes to access the iDEN packet data

network.

Command +WV300

Action AT+wv300<MIP Mode> Query AT+wv300? Range AT+wv300=? Parameter

Values:

0 = Activate Mobile Node in DCE. 1 = Deactivate Mobile Node in DCE.

Mobile IP Authentication Key

The iDEN network uses the MIP Authentication Key to verify the authenticity of the DCE with the Home Agent. The DCE and the Home Agent must have identical values for this shared secret key for the DCE to satisfy the authentication process.

NOTE: This command is applicable only when the Mobile IP Client in

the DCE is activated.

Command +WV301

Action AT+wv301<”key”> Query Range AT+wv301=?

RFM-4002-5015 Rev 3

Page 90

iR1200 Modem

Parameter Values:

The authentication Key parameter is a text string of up to 32 characters. Unlike most text-string parameters, the Authentication key is a text representation of a hexadecimal number. Therefore, only the characters 0-9 and A-F are acceptable. (The lower case character, a-f is also acceptable).

NOTE: Although the parameter represents a numeric value,

the parameter is actually a text string, so the parameter must be enclosed in quotation marks.

Mobile IP Session Timer

The command determines the maximum amount of time that a remote node can be registered with its Home Agent before having to renew its registration. This parameter sets a user preference for a value that is negotiated within the network. During the negotiation process, the user preference may be overruled by the network without notification.

Command +WV302

Action AT+wv302<timer> Query AT+wv302? Range AT+wv302=? Parameter

Values:

1800-65534 = Second before expiration 65536 = Timer never expires 7200 = Default value

DTE IP Address

This command sets the mobile node’s permanent IP Address (also known as the network Entry Identified, or NEI).

80 nextel.com

Page 91

AT Commands

NOTE: This parameter is applicable only when the Mobile Node Client in

the DCE is activated.

Command +WPNEI

Action AT+wpnei<”address”> Query AT+wpnei? Range AT+wpnei=? Parameter

Values:

An IP Address consists of up to 15 characters, and is in the format “ddd.ddd.ddd.ddd”.

0.0.0.0. = Default value

DTE IP Address Prefix Length

The prefix-length is the number of contiguous bits in an IP address that makes up the network prefix (or network number plus subnet number) of the IP address.

NOTE: This command sets the prefix length of the Mobile Node’s IP

address, as specified by +WPNEI.

Command +WV311

Action AT+wv311<length> Query AT+wv311? Range AT+wv311=? Parameter

Values:

2-24 = Prefix length 2 = Default value

Data Encryption

The DTE uses this command to select whether or not to encrypt the air-link interface and determines how the air-link is encrypted. Encryption is negotiated during the packet data registration.

RFM-4002-5015 Rev 3

Page 92

iR1200 Modem

Command +WV308

Action AT+wv308<encryption>, <firm offer>, <key size> Query AT+wv308? Range AT+wv308=? Parameter

Values Encryption:

Parameter Values – Firm Offer:

Parameter Value – Key Size:

0 = Disabled 1 = Vancouver Encryption

0 = Encryption setting is a negotiable preference. 1 = Encryption setting is not negotiable.

40-64 = Encryption key size 40 = Default value

DTE Stack

This command sets the protocol for communication between the DEC and the DTE. Circuit-switched data connections allow only the transparent character stream for packet data connections; use SLIP or CSLIP or PPP.

Command +WS45

Action AT+ws45<stack> Query AT+ws45? Range AT+wv45=? Parameter

Values:

0 = Transparent Character Stream 1 = Reliable Transparent Character Stream (TMOL) 3= SLIP/CSLIP 4 = PPP

82 nextel.com

Page 93

AT Commands

WDS Stack

This command changes the data mode of the modem between circuit-switched data and packet data.

Command +WS46

Action AT+ws46<service> Query AT+ws46? Range AT+wv46=? Parameter

Values:

23 = iDEN Circuit-switched data/fax 24 = iDEN packet data 252 = Local Data Services

Service Class

This command switches between normal circuit-switched data mode and Class 2 fax mode. This setting has no effect during the packet data service.

Command +FCLASS

Action AT+fclass<class> Query AT+fclass? Range AT+fclass=? Parameter

Values:

0 = Class 0 operation (modem operation) 2 = Class 2 operation (fax operation) 8 = Class 8 (voice operation – while tethered)

Packet Data Registration Timeout

This command allows the DTE to specify a maximum amount of time to wait for packet data operation.

Command +WS198

RFM-4002-5015 Rev 3

Page 94

iR1200 Modem

Action AT+ws198<time> Query AT+ws198? Range AT+ws198=? Parameter

Values:

1-255 = Seconds 30 = Default value

Circuit Data Auto-Answer

This command determines if and when the DCE should automatically answer an incoming call.

Command S0

Action AT+s0<rings> Query AT+s0? Range AT+s0=? Parameter

Values:

0 = Do not automatically answer incoming calls 1-255 = Answer after specified number of rings

Circuit Data Establishment Timeout

This command allows the DTE to specify the maximum amount of time between a request for a circuit data connection and the establishment of this connection.

Command S7

Action AT+s7<timer> Query AT+s7? Range AT+s7=?

84 nextel.com

Page 95

AT Commands

Parameter Values:

1-255 = Seconds 30 = Default value

Comma Dial Modifier Timer

This command allows the DTE to set the duration of the pause associated with a comma (,) dial modifier.

Command S8

Action AT+s8<timer> Query AT+s8? Range AT+s8=? Parameter

Values:

0-255 = Seconds 2 = Default value

Circuit Data Idle Timer

This command specifies an idle line timeout for online data mode. If no data is sent by the DTE on the transmit data line for the specified period of time, the DCE disconnects the call, returns the OK result code, and returns to command mode.

Command S30

Action AT+s30<timer> Query AT+s30? Range AT+s30=? Parameter

Values:

0-255 = Seconds 0 = Default value

RFM-4002-5015 Rev 3

Page 96

iR1200 Modem

86 nextel.com

Page 97

S-Registers

In this chapter, you are will learn about S-registers and how to configure registers for your iR1200 modem.

This chapter includes:

S-Register Page 87 Programming S-Register Page 87 Reading S-Register Page 88 Supported S-Register Page 88

S-Registers

S-registers are memory locations in the modem that you can program to meet your communication needs. S-register parameters are numbered from 0 (zero) to 255. Since many of the registers are reserved for internal operation purposes, you are allowed to customize only a subset of the modem’s register.

Programming the S-Register

The following table describes the steps to program an S-Register.

1 From the command mode of your communication software,

type ATSn=x where n is the number of the S-register you wish to customize and x is the value that you wish to assign to that register.

2 Press ENTER to execute the command.

RFM-4002-5015 Rev 3

You may experience undesirable consequences if you modify the S7 or S10 registers from their set default values. For optimal performance, it is recommended that you use the default values set for these two registers.

Page 98

iR1200 Modem

If you write to an S-register that is not programmable or if the value you assigned is invalid, the modem will still return an OK message to the computer screen. The attempted changes will not affect the S-register values. .

Reading an S-Register Value

The following table describes how to read a value for an S-Register.

1 From the command mode, type ATSn (n= the number of

the S-register that you want to read) and press ENTER.

2 The value of the requested S-register displays.

NOTE: If you attempt to read the value of an S-register that is not

supported, the modem will display an ERROR message.

Supported S-Registers

The following table outlines the list of S-Registers that can be used to customize your modem.

0 Automatic Answer. Determines if the modem

automatically answers incoming calls.

• If the value assigned to this register is 0 (zero), the modem does not answer the call but sends an appropriate message to the computer that commands the modem to answer the call.

• If the value assigned to this register is a non- zero, the modem answers the call without waiting for the computer to issue its answer-call command.

88 nextel.com

Page 99

Valid value ranges from 0 (zero) to 255. 0 (zero) is the default value.

2 Escape (ESC) Code Character. Specifies the ASCII

character to be used to escape from either data or online mode to command mode.

Valid value ranges from 0 (zero) to 127. 43 or the ASCII plus (+) key is the default value.

3 Command Line Terminating Character. Specifies

the ASCII character to be used to terminate a command line without carrying out any command that might be issued.

Valid value ranges from 0 (zero) to 127. 13 (which represents the ENTER (PC Compatible) or RETURN (Macintosh) key) is the default value.

4 Response Format Character.

Valid value ranges from 0 (zero) to 127. 10 is the default value.

5 Command Line Editing Character.

Valid value ranges from 0 (zero) to 127. 8 (representing the Backspace key) is the default value.

S-Registers

6 Pause Before Blind Dialing.

Valid value ranges from 2 to 10. 2 (seconds) is the default value.

7 Connection Completion Timeout.

Valid value ranges from 0 (zero) to 255 seconds. 120 (seconds) is the default value.

RFM-4002-5015 Rev 3

Page 100

iR1200 Modem

8 Command Dial Modifier Time.

Valid value ranges from 0 (zero) to 255 seconds. 2 (seconds) is the default value.

10 Automatic Disconnect Delay. Determines the

amount of time between loss of carrier and disconnection of the data call.

Valid value ranges from 1 to 254 tenths of a second. 14 (1.4 seconds) is the default value.

12 Escape Code Timer. Determines the time duration

within which the escape code must be sent by the computer to escape from online command mode. The time (in seconds) the modem waits is determined by dividing the specific register value by 50.

Valid value ranges from 20 to 255. 50 or 1 second (50/50) is the default value.

30 Idle Timeout. Determines the amount of time that

the modem waits in online mode for a command from the computer before disconnecting the call and returning to command mode.

Valid value ranges from 0 (zero) to 255 seconds. 0 (infinite time period) is the default value.

90 nextel.com
