Nextbase SDV485-BY Instruction Manual

Download

MODEL NO.

SDV485-B/BY

OPERATING INSTRUCTIONS

SETUPADJUSTMODE

SCAN

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (Including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15. To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

16. The shock hazard marking and the associated graphical symbol is provided on the bottom panel of the unit.

17. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, shall be placed on the apparatus.

MOBILE ENTERTAINMENT

ENG

DVD DVB-T

ENG

PRECAUTIONS

Thank you for purchasing this tablet DVD player. Please read this manual carefully

before operating and reserve it for future reference. It will be helpful to you if you

encounter any operational problem.

DVD DVB-T

WARNING:

ATTENTION:

LASER:

To reduce the risk of fire or electric shock. Do not expose this appliance to rain or moisture, dripping or splashing and that no objects filled with liquids, Such as vases, Shall be placed on the apparatus. Dangerous high voltages are present inside the enclosure. Do not open the cabinet. Refer servicing to qualified personnel only.

To prevent electric shock, match wide blade of plug to wide slot, fully insert.

This Digital Video Disc player employs a Laser System. To ensure proper use of this product, please read this owner s manual carefully and retain for future reference. Should the unit require maintenance, contact an authorized service location - see service procedure.

Use of controls, adjustments or the performance of procedures other than those specified may result in hazardous radiation exposure. To prevent direct exposure to laser beam, do not try to open the enclosure. Visible and invisible laser radiation will be exposed when open and interlocks defeated. DO NOT STARE INTO BEAM

LASER

Type Wave length Output Power Beam divergence

Semiconductor laser GaAIAs 650 nm/780nm 5mW 60degree

LASER RADIATION

DO NOT VIEW DIRECTLY WITH

OPTICAL INSTRUMENTS

CLASS 1M LASER PRODUCT

MOBILE ENTERTAINMENT

PRECAUTIONS

CAUTION:

These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.

WARNING:

To reduce the risk of fire or electric shock, do not expose this

appliance to rain or moisture.

CAUTION:

Use of controls or adjustments or performance of procedures

those specified may result in hazardous radiation exposure.

CAUTION

RISK OF ELECTRIC SHOCK. DO NOT OPENRISK OF ELECTRIC SHOCK. DO NOT OPEN

To reduce the risk of electric shock, do not remove cover (Or back). No user serviceable parts inside. Refer servicing to qualified service personnel.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the product enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

SA 1965

DANGEROUS VOLTAGE

ENG

DVD DVB-T

SA 1966

INSTRUCTION

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (Servicing) instruction in the literature accompanying the appliance.

MOBILE ENTERTAINMENT

ENG

PRECAUTIONS

MACROVISION:

DVD DVB-T

DOLBY:

DivX:

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision. If not, the use of this technology is only permitted for domestic use and other limited playback uses. Reverse engineering or disassembly is prohibited.

Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.

This device incorporates copyright protection technology

that is protected by DivX, Inc.

DivX, DivX Certified and associated logos are trademarks

of DivX, Inc. and used under license.

DVD

MOBILE ENTERTAINMENT

IMPORTANT SAFETY INSTRUCTIONS

PRECAUTIONS TABLE OF CONTENTS

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS..........................

PRECAUTIONS...............................................................

TABLE OF CONTENTS...................................................

ENG

2 5

DVD DVB-T

CAUTIONS ON USING THIS PLAYER DISCS PLAYABLE

PACKAGE CONTENTS

PARTS AND CONTROLS

AUDIO/ VIDEO CONNECTIONS

CONNECTING THE PLAYER TO OTHER DEVICES

CAUTIONS ON USING THIS PLAYER............................

TYPES OF DISCS PLAYABLE ON THIS PLAYER...

PLAYABLE FORMATS ........................................

PACKAGE CONTENTS..................................................

FRONT SIDE..................................................................

BUTTON DEFINITION...................................................

RIGHT SIDE...................................................................

LEFT SIDE......................................................................

MAIN UNIT REAR SIDE.................................................

HOW TO STAND............................................................

REMOTE CONTROL......................................................

KEY DESCRIPTION OF REMOTE CONTROL..............

NOTES ON USING THE REMOTE CONTROL UNIT.....

REPLACING THE BATTERY..........................................

CONNECTING THE PLAYER TO A TV SET....................

CONNECTING THE

ADAPTER TO THE DC IN 12V SOCKET.......................

USING THE EARPHONE...............................................

CONNECTING TO A DOLBY DIGITAL /MPEG DECODER

OR AN AMPLIFIER WITH A BUILT-IN DECODER.........

CONNECTING TO A DIGITAL AMPLIFIER THAT IS NOT DOLBY

DIGITAL/ MPEG COMPATIBLE.....................................

CONNECTING TO ACTIVE SPEAKER SYSTEMS.......

10 10

12 12 14 14 15 15

16 17

19 19

21 21

23 24

BASIC OPERATIONS

TURNING ON THE POWER..........................................

TURNING OFF THE POWER........................................

LOADING.......................................................................

PLAYBACK....................................................................

STOP PLAYBACK.........................................................

PAUSE PLAYBACK.......................................................

PLAY AT FAST SPEED.................................................

MOBILE ENTERTAINMENT

25 25 26 27 27 27 28

ENG

TABLE OF CONTENTS

DVD DVB-T

SYSTEM SETUP

LANGUAGE SETUP

DIGITAL SETUP

PLAYBACK IN SLOW MOTION.....................................

A-B/ REPEAT PLAYBACK.............................................

ZOOM FUNCTION.........................................................

SEARCHING FOR A SPECIFIC SCENE.......................

SELECTING SUBTITLE................................................

CHANGING THE ANGLE..............................................

CHANGING THE AUDIO LANGUAGE..........................

PROGRAM PLAYBACK.................................................

USING THE ON-SCREEN DISPLAY.............................

PLAYING A MP3 FORMAT DISC AND JPEG CD..........

PLAYING DivX FILES....................................................

USB AND CARD READING...........................................

TV SYSTEM...................................................................

SCREEN SAVER...........................................................

PASSWORD..................................................................

RATING..........................................................................

DEFAULT........................................................................

OSD LANGUAGE...........................................................

AUDIO LANG. ...............................................................

SUBTITLE LANG. .........................................................

MENU LANG. ................................................................

AUDIO OUT...................................................................

SOUND EFFECT............................................................

DYNAMIC RANGE .........................................................

DivX VOD.......................................................................

28 28 29 29 29 29 29 30

32 32

34 35

35 36 36

37 37 38 38

39 39 40 40

31 31

FIRST TIME INSTALLATION

SPECIAL KEYS

MOBILE ENTERTAINMENT

DVB

FIRST TIME INSTALLATION........................................

EPG ...............................................................................

SCAN.............................................................................

AUDIO............................................................................

43 43 44

CHANNEL GUIDE

SYSTEM CONFIG

INSTALLATION

GAME

FM TRANSMITTER INSTRUCTIONS

IR TRANSMITTER

FIT THE DVD PORTABLE PLAYER TO THE HEADREST MOUNT OR VESA WALL MOUNTING BRACKET

MINI-MAGNETIC ANTENNA INSTALLGTION GUIDE

OTHERS

TABLE OF CONTENTS

TV CHANNELS..........................................................

RADIO CHANNELS...................................................

CHANNELS FAVORITE.............................................

CHANNEL EDIT..........................................................

TV SETTING..............................................................

AUDIO SETTING.......................................................

LANGUAGE............................................................... 49

PARENT CONTROL.................................................. 49

ANTENNA POWER....................................................

AUTO SCAN.............................................................. 51

MANUAL SCAN ....................................................... .51

DEFAULT SETUP...................................................... 52

BOXMAN................................................................... 53

BURNING TETRIS.....................................................53

HIT RAT..................................................................... 54

FM TRANSMITTER................................................... 55

IR TRANSMITTER.....................................................56

FIT THE DVD PORTABLE PLAYER TO THE HEADREST MOUNT OR

VESA WALL MOUNTING BRACKET ........................57

MINI-MAGNETIC ANTENNA INSTALLGTION

GUIDE..................................................................... 58

SIZE AND PARAMETER........................................... 59

TROUBLE SHOOTING..............................................60

ENG

45 45

46 46

48 48

...

DVD DVB-T

MOBILE ENTERTAINMENT

ENG

CAUTIONS ON USING THIS PLAYER

1. DO NOT MOVE THE PLAYER DURING PLAYBACK

DVD DVB-T

2 .TRANSPORTING THE PLAYER

3. PLACE OF INSTALLATION

4. DO NOT PLACE OBJECTS ON TOP OF THE PLAYER

5. TURN OFF THE POWER WHEN NOT USING THE PLAYER

6. SPECIAL NOTE REGARDING USE OF PLAYER IN VEHICLES

CAUTIONS ON USING THIS PLAYER

During playback, the disc spins at high speed. So do not lift or move the player. Doing so may damage the disc.

Before transporting the player, be sure to remove the disc and turn off the

power, then unplug the power cord.

Select a stable place near the TV or stereo system to which you are going to

connect the player.

Do not place the player on top of a TV or color monitor.

Install the player away from cassette decks or other devices which are easily

affected by magnetic forces.

Do not expose this apparatus to rain, moisture, dipping or splashing and no

objects filled with liquids, such as vases, shall be placed on the apparatus.

If the player is connected to your TV but not inuse, switch the power off. It can

avoid interference to your normal TV picture.

Noise problems may also be experienced if used near a radio.

We strongly advise against using the player while driving. Most countries and states have laws which prohibit or severely restrict the use of the player in vehicles while driving.

Do not leave the player or the battery pack in places where the temperature is extremely low (About-10 C or lower) or extremely high (About 60 C or higher), such as inside the passenger cabin or trunk in midsummer. Doing so may warp the outer case or reduce the performance or quality of the battery pack.

MOBILE ENTERTAINMENT

CAUTIONS ON USING THIS PLAYER

7. WHEN USING WITH CAR POWER CABLE IN CARS

Please turn on the engine and then connect the car power cable for using.

8. CLEANING THE PLAYER

Normally clean the player with a soft, dry cloth. For tough dirt, apply some neutral detergent diluted in 5 to 6 parts water to a soft cloth, wring out thoroughly. Wipe off the dirt, then wipe off the player with a dry cloth. Note that alcohol, thinner, benzene, insecticides, etc., may cause the print or coating to peel off. Also avoid leaving rubber or plastic products in contact with the player for long periods of time, as this may damage the cabinet. When using chemically treated cloths, read the cloth's instructions carefully. Always unplug the power cord from the power outlet before cleaning the player.

9. COPYRIGHTS

Unauthorized duplication, broadcast, public performance or rental of discs is prohibited by law.

ENG

DVD DVB-T

MOBILE ENTERTAINMENT

ENG

DISCS PLAYABLE

TYPES OF DISCS PLAYABLE ON THIS PLAYER

The discs listed on the table below can be played on this player without an adapter.

DVD

The marks shown on the table below are indicated on the disc's label, package or jacket.

Types of playable discs and their marks

DVD-Video disc

Diameter/Playable sides

DVD video 12cm/singlesided 12cm/doublesided

DVD video 8 cm/singlesided 8 cm/doublesided

CD 12 cm/single-sided

CD 8 cm/single-sided

1 layer 2 layer 1 layer 2 layer

Playback time

Playback time (MPEG 2 format) 133 minutes (4.7GB) 242 minutes (8.5GB) 266 minutes (9.4GB) 484 minutes (17GB)

(MPEG 2 format) 41 minutes 75 minutes 82 minutes 150 minutes

74 minutes

20 minutes

Marks indicated on DVDs

DVD discs or packages include the marks shown below. These marks indicate the type of video or audio signals recorded on the disc and the functions that can be used.

Mark Meaning

Indicates the number of audio tracks.

Indicates the number of angles.

16 : 9

Indicates the selectable picture aspect ratio.

ALL

Indicates the playable region number.

PLAYABLE FORMATS

The unit is able to play most audio/video files such as: PICTURE: JPEG AUDIO: MP3, WMA VIDEO: DAT, VOB, MPEG2, MPEG4 (AVI,DIV )

MOBILE ENTERTAINMENT

PACKAGE CONTENTS

After unpacking, first check the contents of your DVD player package as listed below:

Operating manual

485

I N

R U

I O

Digital TV Antenna (SDV485-BY)

Active antenna (SDV485-B)

ENG

DVD DVB-T

Earphone

Backplate

Headrest mount

Remote control

Screw & gasket

AC / DC adapter

Car power cable

AV cable

NOTES: Actual products' appearance might vary slightly from the pictures shown.

MOBILE ENTERTAINMENT

ENG

DVD DVB-T

PARTS AND CONTROLS

FRONT SIDE

1£®

3. MODE

4. ADJUST

10. SETUP

SETUPADJUSTMODE

SCAN

11. CH-

12. CH+

13. SCAN

BUTTON DEFINITION

SETUPADJUSTMODE

SCAN

1. Play / Pause button

Press it to start / pause the playback. (Invalid in DVB-T state)

2. Stop button

Stop the playback. (Invalid in DVB-T state)

3. Mode button

Press it to pop out the play modes selecting menu: DVD, DVB -T, and AV IN. Press it again to exit.

VIDEO

:SEL :ENT

Digital

INPUT

The default mode is DVD. Turn off the player. If you turn it on again, it will return back to the playing mode before power off.

MOBILE ENTERTAINMENT

PARTS AND CONTROLS

4. Adjust button

:ENT

Press it to enter the adjustments of brightness, color, TFT mode and view mode, FM tranmitter and IR . tranmitter Press it again to exit. Keep pressing the button for about 1.5 seconds to turn of fthe TFT display and press any key to resume display.

5. Left / Previous button

Press it to move left at the MENU or SETUP status. Press it to locate at the previous track or chapter when playing DVD.

6. Right / Next button

Press it to move right at the MENU or SETUP status. Press it to locate at the next track or chapter when playing DVD.

7. Up / Forward button

Press it to move up at the MENU SETUP status. Press it to forward the playing speed through x2, x4, x8, x20 when playing DVD.

8. Down / Rev button

Press it to move down at the MENU SETUP status. Press it to backward the playing speed through x2, x4, x8, x20 when playing DVD.

9. Enter button

Press it to confirm your selection.

10. Setup button

Press it to bring forth the main setup menu. Press it again to exit.

11. CH- button

Press it to channel down. ( Invalid in DVD state)

12. CH+ button

Press it to channel up. ( Invalid in DVD state)

13. Scan Function

Perform program scanning by pressing the CH- and CH+ buttons together simultaneously. ( Invalid in DVD state)

ENG

DVD DVB-T

MOBILE ENTERTAINMENT

DVD DVB-T

ENG

PARTS AND CONTROLS

RIGHT SIDE

Volume control

Use it to adjust the volume of the speaker or the earphone.

Earphone jack

For connecting a stereo earphone or an amplifier.

DC OUT(DC 12V 500mA )

DC output. Note:

This DC out port can connect to products from our company only. Otherwise it might cause bad performance. The maximum output current is 500mA.

Video in/out jack

Input or output video signals to connected device by setting AV IN/OUT mode value. The included AV cable is connected from here.

6 7

Audio in/out and optical output jack

Input or output audio signals to connected device by setting AV IN /OUT mode value. Output optical audio signals to connected device. The included AV cable or optical digital cable is connected here.

Power on/off

DC IN (DC 12V )

Connect the included AC/DC adapter here.

LEFT SIDE

MOBILE ENTERTAINMENT

USBUSB

SD/MMCSD/MMC MS/MS-PROMS/MS-PRO

2 4

PARTS AND CONTROLS

OPEN button

Push it to open the cover.

USB port

Support USB 1.1 use.

MAIN UNIT REAR SIDE

Support

The unit can stand with this device.

HOW TO STAND

1. Pull out the support.

2. Draw out the support to a proper position.

3. Pull down the button to lock it.

Slot Protector Open the rubber cover to find the card slot and USB port.

SD/MMC/MS/MS-PRO card slot

DVB-T jack

DVB-T type aerial input.

ENG

DVD DVB-T

UNLOCK

LOCK

UNLOCK

LOCK

22 33

MOBILE ENTERTAINMENT

PARTS AND CONTROLS

REMOTE CONTROL

PARTS AND CONTROLS

KEY DESCRIPTION OF REMOTE CONTROL

ENG

DVD DVB-T

SETUP

Press it to bring forth the main setup menu. Press it again to exit.

MODE

Press it to pop out the play modes selecting menu: DVD, DVB -T, and AV IN. Press it again to exit.

ADJUST

Press it to enter the adjustments of brightness, color, TFT mode and view mode, FM tranmitter and IR

. tranmitter Press it again to exit.

SCAN

Perform program scanning. Press it again to exit. ( Invalid in DVD state)

OSD

Press it to display the disc's or the program's information.

AUDIO

Press it to switch the audio language.

MUTE

Audio mute on/ off.

/CH+

Press it to channel up in DVB-T state while move the cursor up in menu state.

CH-/

Press it to channel down in DVB-T state while the cursor down in menu state.

move

/FAV-

Move the cursor left in the menu state or switch to previous favorite program in DVB-T state.

FAV+/

Move the cursor right in the menu state or switch to next favorite program in DVB-T state.

ZOOM

Zoom the picture on screen.

Jump to previous track. ( Invalid in

DVB-T state )

Jump to next track. (Invalid in DVB-T

state)

STOP( )

Press this button to stop playback. (Invalid in DVB-T state)

Fast backward. (Invalid in DVB-T

state)

Press this button to play or pause playback. (Invalid in DVB-T state)

Fast forward key. (Invalid in DVB-T

state)

STEP/SLOW

During playing status, press it to switch to SLOW mode, while switch to STEP mode at pause status. (Invalid in DVB-T state)

SUBTITLE

Press it to switch the DVD'S subtitle language. (Invalid in DVB-T

state)

RETURN

Return to the menu in DVD state while return to the previous channel

.in DVB-T state

Enter the selected item.

MOBILE ENTERTAINMENT

ENG

PARTS AND CONTROLS

ANGLE

Press it to switch angle. (Invalid in

DVB-T state)

EPG

DVD DVB-T

Press it to enter the electric program guide. (Press it again to exit. Invalid in

DVD state)

TITLE

Press it to display the DVD's title. (Invalid in DVB-T state)

REPEAT

Press this button to repeat playback. (Invalid in DVB-T state)

A-B

Press this button during playback to set two points and play the section between them repeatedly. (Invalid in

DVB-T state)

TTX

Press it to show the teletext information.(Invalid in DVD state)

Press it to display menu information. (Invalid in DVB-T state)

PROGRAM

Program playing order of tracks. (Invalid in DVB-T state)

Locate title/ chapter/ playtime to play. (Invalid in DVB-T state)

DTV/RADIO

Press it to choose TV program or radio program. (Invalid in DVD state)

-/- -

Press this button to select channel numbers of one figure or double digits

in DVB-T state and it equals to 10+ to select tracks and chapters in DVD state.

SHIFT

Press this button to switch between number and function.

P/N

Press it to output the TV type: PAL and NTSC. ( Invalid in DVD state)

MOBILE ENTERTAINMENT

PARTS AND CONTROLS

NOTES ON USING THE REMOTE CONTROL UNIT

Do not drop or step on the remote control unit or subject it to shocks. Note that the remote control unit may not work if there are obstacles between the remote sensor and itself. Do not expose the remote sensor to strong light. Doing so may make operation impossible. Use the remote control unit within the specified operating range.

REPLACING THE BATTERY

Insert your finger nails into A and B on the diagram below, press A according to the direction, then pull out the battery holder.

Remove the old battery, then insert the new battery into the battery holder with the + side facing upwards.

ENG

DVD DVB-T

Fit the battery holder back to its place.

Lithium

Battery

(CR2025)

NOTE:

To prevent leakage of fluid from the lithium battery, remove the battery when not using the remote control unit for long periods of time (One month or more). If the battery leaks fluid, carefully wipe it out of the battery case, then change to a new lithium battery.

Caution: The battery may present a risk of fire if mistreated. Do not recharge, disassemble, or heat it above 100 C. Replace battery with the same type. Dispose of used battery properly, keep away from children and do not dispose of in fire.

MOBILE ENTERTAINMENT

ENG

AUDIO/VIDEO CONNECTIONS

CONNECTING THE PLAYER TO A TV SET

DVD DVB-T

MOBILE ENTERTAINMENT

Yellow

White

Red

Yellow

Black

AUDIO/VIDEO CONNECTIONS

CONNECTING THE ADAPTER TO THE DC IN 12V SOCKET

USING THE EARPHONE

ENG

DVD DVB-T

1. Set the volume control to minimum sound level.

2. Connect the earphone plug to the player's " " jack.

3. Adjust the volume control to the preferred sound level.

MOBILE ENTERTAINMENT

ENG

CONNECTING TO A DOLBY DIGITAL / MPEG DECODER OR AN AMPLIFIER WITH A BUILT-IN DECODER

With this player, you can enjoy powerful Dolby Digital or MPEG sound. Output the

DVD DVB-T

digital signals from the player's digital output to a decoder or amplifier with built-in decoder.

CONNECTING THE PLAYER TO OTHER DEVICES

Main unit right panel

Optical digital cable (Not included)

Front speaker (Left)

(Left)

Surround speaker

Hint:

For a compatible decoder or amplifier, 5 speakers (Front left / right, center and surround left / right) and a subwoofer are required to enjoy Dolby Digital channel sound.

Center speaker

See details of connections to the TV.

Front speaker (Right)

Surround speaker (Right)

Subwoofer

Signal flow

MOBILE ENTERTAINMENT

CONNECTING THE PLAYER TO OTHER DEVICES

CONNECTING TO A DIGITAL AMPLIFIER THAT IS NOT DOLBY DIGITAL / MPEG COMPATIBLE

Output the digital signals from the player's digital output to a digital amplifier that is not Dolby/MPEG compatible. For instructions of audio settings, refer to AUDIO OUT of AUDIO SETUP.

Main unit right panel

ENG

DVD DVB-T

Notes

Carefully check the player s digital output settings before connecting the player to an amplifier equipped with a digital audio input jack which is not Dolby Digital / MPEG compatible.

Optical digital cable (Not included)

See details of connections to TV.

To digital audio input jack

Do not play DVDs when the audio settings are not correct. Or it may cause strong noise and damage your speakers.

Signal flow

MOBILE ENTERTAINMENT

ENG

CONNECTING THE PLAYER TO OTHER DEVICES

CONNECTING TO ACTIVE SPEAKER SYSTEMS

DVD DVB-T

Main unit right side

Black

Yellow

AV cable

To audio input

To Video Input jack

Yellow

jacks

Red

White

Active speaker systems

MOBILE ENTERTAINMENT

TURNING ON THE POWER

BASIC OPERATIONS

ENG

Connect the AC/DC adapter to a socket.

Connect the DC output plug of the adapter to the DC input jack on the main unit.

Switch the POWER button to ON position.

The included AC/DC adapter is compatible with voltage from 100V to 240 V, you can use it on trips overseas.

Power

TURNING OFF THE POWER

When the power is on, switch the power button to OFF position.

Note that you need a converter plug (Available in stores) suited for the region in which you are travelling.

DVD

Unplug the power cord from the power outlet.

Disconnect the AC/DC adapter from the player's DC input jack.

MOBILE ENTERTAINMENT

ENG

DVD

BASIC OPERATIONS

1 Press the OPEN button to open

the cover.

2 Place in a disc and press it

down the disc with your fingers near the center hole.

A click is heard.

Notes:

Set the disc securely. Failure to set it securely could result in damage. Do not use cracked or warped discs. Doing so could result in damage. Place single-sided DVDs or CDs in with the label (Printed) side facing upwards. For double-sided DVDs, check each side carefully, then place the disc in securely (Until a click is heard). For CDs or one-sided DVDs, you do not have to worry about touching the label (Printed) side of the disc with your fingers. Since two-sided DVDs have signals recorded on both sides, be careful not to scratch them when removing them from the player.

MOBILE ENTERTAINMENT

3 Close the disc cover.

PLAYBACK

Turn on the power of the player. Open the disc cover.

Insert a disc correctly.

Close the cover.

The player will load the disc and play

automatically. If not, please press the button.

STOP PLAYBACK

BASIC OPERATIONS

PLAY/PAUSE

ENG

DVD

1. Press on the remote control while playing.

2. The player remembers the stopping place.

3. To resume playback from the point where it stopped, just press key.

4. To clear stopping mark, press again at stop status. The player will not play from the stopping place when pressing next time.

PAUSE PLAYBACK

1. Press on the main unit board or on the remote control during playback.

2. Press again to resume normal playback.

STOP

PLAY/PAUSE

MOBILE ENTERTAINMENT

ENG

PLAYING AT FAST SPEED

1. Press or button on the main unit board or on the remote control during playback.

DVD

2. The playback speed will be changed each time you press the or . The speed will be changed to 2X, 4X, 8X, 20X, 1X each time you press the button.

PLAYBACK IN SLOW MOTION

1. Press the button on the remote control during playback. The playback speed becomes1/2, 1/3, 1/4, 1/5, 1/6 or 1/7 of the normal speed each time you press the button.

2. When pressing during pause status, the player will show still a picture on the screen. The picture will be changed one frame each time the button is pressed.

BASIC OPERATIONS

NOTE:

During fast or slow motion playback, the sound is muted except playing a CD & MP3 disc. To resume normal playback, press .

A-B/REPEAT PLAYBACK

1. A-B playback When pressing A-B button on the remote control during playback, the current point would be located on the remote control, and¡°REPEAT A-¡±appears on the screen. Press A-B button again, B point would be located and the player would play from A point to B point repeatedly. Press A-B button again.¡°A-B¡±playback would be cancelled and the player resume normal playback.

2. Repeat a Title, Chapter or Track Press REPEAT button on the remote control during playback. The chapter or the title(for DVD) and the track or entire disc (for CD) will be played repeatedly. The REPEAT mode will be changed each time when the repeat button is pressed.

MOBILE ENTERTAINMENT

BASIC OPERATIONS

ZOOM FUNCTION

1. Press ZOOM on the remote control during playback. The picture on the screen will be zoomed.

2. The zooming rate changed each time when the ZOOM button is pressed. The sequence is 2X, 3X, 4X, 1/2X, 1/3X, 1/4X, 1X.

SEARCHING FOR A SPECIFIC SCENE

1. Press the SEARCH button on the remote control.

2. Press the UP, DOWN and ENTER buttons to move to desired section.

3. Input valid number to choose specific time or title, chapter or track.

4. Press ENTER button to play the specific scene.

5. Press SEARCH button to resume normal screen.

SELECTING SUBTITLE

You can select a preferred subtitle from those included on the DVD video disc by pressing SUBTITLE button on the remote control during playback.

ZOOM

ENG

DVD

CHANGING THE ANGLE

Press the ANGLE button on the remote control while playing a scene recorded with multiple angles. If your DVD disc is not recorded with multiple angles,pressing ANGLE button will not effect at all.

CHANGING THE AUDIO LANGUAGE

1. Press the AUDIO button on the remote control during playback. You can select different audio languages included on the DVD video disc.

2. For VCD or CD, you can choose channels to play.

MOBILE ENTERTAINMENT

ENG

DVD

BASIC OPERATIONS

PROGRAM PLAYBACK

The program playback function can automatically play titles, chapters, or tracks in accordance with the programmed order.

1. Insert a disc and then press the PROGRAM button on the remote control. At this time, menu appears as below.

2. Using and the number buttons to select the title and chapter in your preferred order.

3. Using to move the cursor to PLAY and press ENTER button. The player starts PROGRAM playback.

4. To exit, press the PROGRAM again.

NOTES:

When the DVD video player is turned off or the discs are removed, the programmed items will be removed.

Referring to the disc, some may not have this function.

Selecting an inexistent title or chapter, program playback will be canceled automatically.

MOBILE ENTERTAINMENT

USING THE ON-SCREEN DISPLAY

BASIC OPERATIONS

ENG

1. This DVD video player allows you to view the operational status and disc s information on screen.

2. Press OSD button on the remote control

during playback. The disc s information

will be displayed on screen.

3. Press OSD button again, the information

will disappear.

PLAYING A MP3 FORMAT DISC AND JPEG CD

Mp3

1. Folder

2. Files

3. MP3 ICON

4. JPEG ICON

Use to move the cursor to a folder, a file, MP3 ICON or JPEG ICON. In order to play MP3 files, move the cursor to MP3 ICON and press ENTER button. In order to play JPEG files, move the cursor to JPEG ICON and press ENTER button. Choose the desired file and press ENTER to play. Press A-B button to get A-B REPEAT function. Press REPEAT button to switch repeat mode(REP1, REP DIR, REP ALL, REP OFF). REP1 means repeating the track; REP DIR means repeating the folder; REP ALL means repeating the whole disc.

DVD

MOBILE ENTERTAINMENT

ENG

BASIC OPERATIONS

PLAYING DivX FILES

Your player is an official DivX Certified product that plays DivX.5, DivX.4, DivX.3, and DivX. VOD video content in compliance with DivX Certified technical requirements.

DVD

NOTE:

To guarantee playback of DivX files the audio must be MP3 format. DivX Certified devices can play any interleaved MP3 audio at any bitrate, both CBR and VBR. The audio must be sampled at standard frequencies, such as 32 kHz, 44.1 kHz, and 48 kHz, and must conform to the AVI file specification. Apart from MP3, the audio formats recognised by your player are MPEG layer 1 / 2, AC3, PCM. Formats such as AAC and Ogg Vorbis are not supported by this player.

1. Open the compartment by sliding down the OPEN button.

2. Place the disc with the printed side facing up and close the compartment.

3. A menu appears on the screen. Select a folder using the and buttons on the remote control, then press to open the folder s contents.

4. Select a file using the and buttons on the remote control.

NOTE:

AVI

To go back to the folder list, press .

5. Press to start playback.

6. Press STOP to stop playback.

USB AND CARD READING

1. If there is only one media inside the player after power on or closing the compartment cover, this media will be read directly.

2. If there are two or more media, the following prompt message will appear to help select your choice.

3. If a media is playing prior to another media connecting, the playback will stop to pop out the prompt message.

4. If there are two or more media in STOP state, you have to press STOP button

twice to bring up the prompt message.

Memory

MOBILE ENTERTAINMENT

Disc

USB

BASIC OPERATIONS

Note:

Supply USB 1.1 use.

The player may not work properly if using USB connecting cable. Suggested not

to use it.

3. Support SD/MS/MS-Pro / MMC cards.

Insert the cards as the following picture shows:

This product has been tested with most brand name flash media cards. Using poor quality flash cards may affect the readability of the unit.

This unit can read flash memory card up to capacity.1GB

ENG

DVD

MOBILE ENTERTAINMENT

ENG

SYSTEM SETUP

The system setup options are illustrated below:

TV SYSTEM

If you want to connect the player to a TV, please choose a correct TV system first.

DVD

AUTO: Choose this setting if your DVD player is connected to a multi-system TV.

NTSC: Choose this setting if your DVD player is connected to a NTSC TV.

PAL: Choose this setting if your DVD player is connected to a PAL TV.

The default setting is AUTO.

SYSTEM SETUP TV SYSTEM

SCREEN SAVER PASSWORD RATING DEFAULT

EXIT SETUP

NTSC PAL

AUTO

NOTE:

Setting with incorrect TV system will result in black and white picture on your

TV screen.

MOBILE ENTERTAINMENT

SYSTEM SETUP

SCREEN SAVER

Set the screen saver option to ON status. When your DVD player is at STOP or NO DISC status, or there is a frame frozen for a little long time, the screen saver will be displayed. This feature can protect the screen from damage.

ON: Choose this setting to activate the screen saver. OFF: Choose this setting to cancel the screen saver. The default setting is ON.

SYSTEM SETUP

TV SYSTEM

SCREEN SAVER

PASSWORD RATING DEFAULT

EXIT SETUP

PASSWORD

Step1: For first time use: Enter 0000 as password or assigned password to unlock.

Step2: Once parental control is unlocked, go to rating meun and assign rating.

Step3: Enter new password of your choose in 4 digit number to lock player rating.

If you forget your assigned password, you can use 0000 to unlock the rating again.

OFF

ENG

DVD

SYSTEM SETUP

TV SYSTEM SCREEN SAVER

PASSWORD

RATING DEFAULT

EXIT SETUP

MOBILE ENTERTAINMENT

ENG

SYSTEM SETUP

RATING

The rating feature works with DVD discs that have been assigned a rating. This helps you to control the types of DVDs that the player can be watched.

There are eight limited rating options: KID SAFE, G, PG, PG13, PG-R, R, NC-17, ADULT.

DVD

The default setting is ADULT.

SYSTEM SETUP

TV SYSTEM SCREEN SAVER PASSWORD

RATING

DEFAULT

EXIT SETUP

1 KID SAFE 2 G 3 PG 4 PG13 5 PG-R 6 R 7 NC-17

8 ADULT

NOTE:

If the password option is locked, you cannot change the rating.

DEFAULT

Choose this option to resume factory settings.

SYSTEM SETUP

TV SYSTEM SCREEN SAVER PASSWORD RATING

DEFAULT

EXIT SETUP

RESTORE

MOBILE ENTERTAINMENT

LANGUAGE SETUP

The language setup options are illustrated below:

ENG

OSD LANGUAGE

Highlight the OSD LANGUAGE option, and press the arrow buttons to choose the OSD language you prefer. Press ENTER to confirm, and it will display OSD in that language. There are 5 optional OSD languages: English, German, Spanish, French and Italian.

LANGUAGE SETUP OSD LANGUAGE

AUDIO LANG. SUBTITLE LANG. MENU LANG.

EXIT SETUP

ENGLISH

GERMAN SPANISH FRENCH ITALIAN

AUDIO LANG.

Highlight the AUDIO LANG. option, and press the arrow buttons to choose the audio

language you prefer. Press ENTER to confirm. If the disc you are playing has that language available, it will output audio in that language. There are 8 optional audio languages: Chinese, English, Japanese, French, Spanish, Portuguese, Italian and German.

LANGUAGE SETUP

OSD LANGUAGE

AUDIO LANG.

SUBTITLE LANG. MENU LANG.

EXIT SETUP

CHINESE

ENGLISH

JAPANESE FRENCH SPANISH PORTUGUESE ITALIAN GERMAN

DVD

MOBILE ENTERTAINMENT

ENG

LANGUAGE SETUP

SUBTITLE LANG.

Highlight the option, and press the arrow buttons to choose the

SUBTITLE LANG. subtitle language you prefer. Press ENTER to confirm. If the disc you are playing has that language available, it will display subtitles in that language. There are 7 optional

DVD

subtitle languages: Chinese, English, Japanese, French, Spanish, Italian and German.

LANGUAGE SETUP

OSD LANGUAGE AUDIO LANG.

SUBTITLE LANG.

MENU LANG.

EXIT SETUP

CHINESEE

ENGLISH

JAPANESE FRENCH SPANISH ITALIAN GERMAN OFF

MENU LANG.

Highlight the MENU LANG. option, and press the arrow buttons to choose the menu language you prefer. Press ENTER to confirm. If the disc you are playing has that language available, it will display menu in that language. There are 8 optional menu languages: Chinese, English, Japanese, French, Spanish, Portuguese, German and Italian.

LANGUAGE SETUP

OSD LANGUAGE AUDIO LANG. SUBTITLE LANG.

MENU LANG.

EXIT SETUP

CHINESE

ENGLISH

JAPANESE FRENCH SPANISH PORTUGUESE GERMAN ITALIAN

NOTE:

If your preferred language isn't available, the disc's default language will be played. The default language of your DVD player is English.

MOBILE ENTERTAINMENT

The digital setup options are illustrated below:

DIGITAL SETUP

ENG

AUDIO OUT

Highlight the AUDIO OUT option, and press the arrow buttons to choose the audio output mode you prefer. Press ENTER to confirm. There are 3 optional audio output modes: SPDIF/OFF, SPDIF/RAW and SPDIF/PCM.

SPDIF/OFF: Choose this setting to output analog signal, and there will be no signal is outputted from optical jack. SPDIF/RAW: Choose this setting if your DVD player is connected to a power amplifier with an optical cable. When playing a disc recorded with Dolby Digital and MPEG audio formats, the corresponding digital signals will be outputted from the optical output jack. SPDIF/PCM: Choose this setting if your DVD player is connected to a 2-channel digital stereo amplifier. When playing a disc recorded with Dolby Digital and MPEG audio formats, audio signals will be modulated into a 2-channel PCM signal, and it will be outputted from the optical jack.

DIGITAL SETUP AUDIO OUT

SOUND EFFECT DYNAMIC RANGE DivX(R) VOD

EXIT SETUP

SPDIF/OFF

SPDIF/RAW SPDIF/PCM

SOUND EFFECT

There are two sound output effect modes: NORMAL and SURROUND. You can choose SURROUND to enhance the output sound effect.

DIGITAL SETUP

AUDIO OUT

SOUND EFFECT

DYNAMIC RANGE DivX (R) VOD

EXIT SETUP

NORMAL

SURROUND

DVD

MOBILE ENTERTAINMENT

ENG

DIGITAL SETUP

DYNAMIC RANGE

Choose this setting to adjust the line out compressing ratio and get different effects. If adjusting to FULL, the audio signal peak value will be compressed to be the minimum; while adjusting to OFF, to be the maximum.

DVD

DIGITAL SETUP

AUDIO OUT SOUND EFFECT

DYNAMIC RANGE

DivX (R) VOD

EXIT SETUP

FULL 6/8 4/8 2/8 OFF

DivX(R) VOD

DivX VOD files are downloaded after paying a rental from certain commercial websites. Prior to downloading a VOD you need to input the registration number of your DVD player on the purchase form on the site. Write down the VOD 8-character registration number so that you can fill in the form on the website you purchase your DivX VOD files from.

Note: If you cannot play a DivX VOD file recorded on a CD-R disc after downloading it, the rental period allocated during purchasing from the website may have expired. It is also possible that the recorded file is not compatible with your player because of different versions or incorrect download parameters. The parameters used when copying to CD-R may be another reason for this. Since it is not possible here to supply all the information, parameters and advice relating to the use of DivX VOD files, we recommend that you visit speciallist websites such as www.divx.com/vod.

MOBILE ENTERTAINMENT

DIGITAL SETUP

AUDIO OUT SOUND EFFECT DYNAMIC RANGE

DivX (R) VOD

EXIT SETUP

DIGITAL SETUP

-DIVX[R] VIDEO ON DEMAND-

YOUR REGISTRATION CODE IS: XXXXXXXX TO LEARN MORE VISIT WWW.DIVX.COM/VOD

[DONE]

NOTE:

The registration code will be changed each time you use it to download the DivX files. You have to use new code to carry out downloading operation next time.

ENG

DVD

MOBILE ENTERTAINMENT

ENG

FIRST TIME INSTALLATION

First, press MODE button to enter DVB-T enjoyment .

For the first time use, the system will pop out a message: First Time Installation.

First Time Installation

DVB-T

Do you want to start first

time installation wizard?

YES

Choose "Yes " to enter the next OSD display.

Select Country:

England Italy France Spain Holland Australia Norway Sweden Finland Portugal Others China

First Time Installation(1)

Select Country EngLand

OSD Language English

Back

OSD Language:

English Deutsch

Espanol Francais Italiano

Taiwan Germany

Select the proper region according to the place you are located and the preferred OSD language.

Then come to the "NEXT" to bring forth the Auto Scan.

First Time Installation(2)

Do you want to start Auto

Scan?

Channel : 21 Frequency : 474000KHZ Progress 2/49

TV : Radio :

DVBDVB

BACK

YES

MOBILE ENTERTAINMENT

SPECIAL KEYS

ENG

EPG (ELECTRIC PROGRAM GUIDE)

A quick program guide that the user can easily move up/down to view the brief description of the selected program.

Electric Program Guide

Video

Program List

03/04/2008 GD 1 GD 2 GD 3

17:00 18:00

Program Description

If the current channel is scrambled, the prompt message "scrambled channel." will appear on the screen.

Channel is scrambled.

SCAN

Perform quick program scanning.(Found programs will be appended to the program list.)

Auto Scan Select Country

Select Country EngLand

Start Scan

Press Enter

DVB-T

MOBILE ENTERTAINMENT

ENG

SPECIAL KEYS

Channel : 21 Frequency : 474000KHZ Progress 2/49

DVD ATV DVB-T

TV : Radio :

DVB-T

Country list for selecting:

England, Italy, France, Spain, Holland, Australia, Norway, Sweden, Finland, Portugal, Others, China, Taiwan, and Germany. Just select your preferred scan area and press ENTER to start scan.

AUDIO

Audio channel information displays. And you can also use this button to select the inherent audio languages.

Language 1/1

MOBILE ENTERTAINMENT

CHANNEL GUIDE

ENG

SYSTEM SETTING

Press the SETUP key on the remote control to bring up the main menu. There are four classifications: Channel Guide, System Config, Installation and Game.

TV CHANNELS

Highlight TV Channels and press ENTER to snapshoot all channels.""

Channel Guide

TV Channels

Radio Channels Channels Favorite Channels Edit Exit Setup

Channel Guide TV Channels

N0. ALL TV 0001 GD 1 0002 GD 2 0003 GD 3 0004 GD 4

< > to switch classify OSD key to sort channel

Press SETUP to exit from the current OSD.

RADIO CHANNELS

Select this item to show radio program information.

DVB-T

Channel Guide

TV Channels

Radio Channels

Channels Favorite Channels Edit Exit Setup

MOBILE ENTERTAINMENT

ENG

CHANNEL GUIDE

CHANNELS FAVORITE

This function will help you to classify all the channels to four groups: Favor, Movie, News and Show. After the classification, please exit from the menu. Then you can use Left (Fav-) / Right (Fav+) buttons to choose your favorite groups and UP(CH+)/ Down ( CH-) buttons to get each specific channel within the groups.

DVB-T

Channel Guide Channels Favorite

NO . TV Favor Movie News Show 0001 GD 1 0002 GD 2 0003 GD 3 0004 GD 4

ENTER key to check/ uncheck DTV/ RADIO key to switch TV/ RADIO

CHANNELS EDIT

There are three edit functions with this option.

Rename program

Channel Guide Channel Edit

NO . TV Move Delete 0001 GD 1 0002 GD 2 0003 GD 3 0004 GD 4

UP/DOWN to Choice character,<> to move position ENTER key to finish rename

1. Press ENTER key to rename the program.

2. Then use UP/ Down to choose characters and Left / Right to move to the need-to-be edited position.

3. Press ENTER key again to finish these actions.

MOBILE ENTERTAINMENT

CHANNEL GUIDE

Move program

Channel Guide Channel Edit

NO . TV MOVE Delete 0001 GD 1 0002 GD 2 0003 GD 3 0004 GD 4

DVBD

UP/DOWN key to move program ENTER key to finish move

1. Press ENTER to bring up the Move symbol.

2. Move the channel to a new position with Up/Down buttons.

3. Press ENTER key again to finish these actions.

Delete program

Channel Guide Channel Edit

NO . TV Move Delete 0001 GD 1 0002 GD 2 0003 GD 3 0004 GD 4

ENTER Key to check/uncheck DTV/RADIO key to switch TV /RADIO

Highlight the corresponding position of the need-to-be-deleted channel and press ENTER to mark the channel. Then exit. You'll find the channel had been deleted and cannot revamp it if you delete programs in wrong.In this case you need to rescan.

ENG

DVB-T

MOBILE ENTERTAINMENT

ENG

SYSTEM CONFIG

Use and buttons to get your actual need.

TV SETTING

Select the corresponding TV system.( Auto means the output signal format will be changed automatically according to the received signal.)

DVB-T

System Config

NTSC PAL

TV Setting

Audio Setting Language Parent Control Antenna Power Exit Setup

NTSC PAL

Auto

The default is Auto.

AUDIO SETTING

There are three optional audio output modes: SPDIF/OFF, SPDIF/RAW and SPDIF/ PCM.

System Config

TV Setting

Audio Setting

Language Parent Control Antenna Power Exit Setup

SPDIF/OFF

SPDIF/RAW SPDIF/PCM

SPDIF/OFF:

Choose this setting to output analog signal, and there will be no signal output from the optical jack.

SPDIF/RAW:

Choose this setting to output digital signals if connected to a power amplifier with an optical cable.

SPDIF/PCM:

If connected to a 2-channel digital stereo amplifier, choose this option to output audio

signals which will be modulated to a 2-channel PCM signal.

The default is SPDIF/OFF.

MOBILE ENTERTAINMENT

SYSTEM CONFIG

ENG

LANGUAGE

English German Spanish French Italian

System Config

TV Setting Audio Setting

Language

Parent Control Antenna Power Exit Setup

English

German Spanish French Italian

The default is English.

PARENT CONTROL

System Config

TV Setting Audio Setting Language

Parent Control

Antenna Power Exit Setup

Press ENTER to display the pin-change information. The default pin is 0000.

Parent Control Change pin

Change pin Press Enter Channel Lock Press Enter

Old Pin: New Pin: Confirm:

**** **** ****

DVB-T

Parent Control Change pin

Change pin Press Enter Channel Lock Press Enter

Success!

MOBILE ENTERTAINMENT

ENG

SYSTEM CONFIG

If you want to change the Channel Lock, you will be required to input the password first.

Parent Control Change Lock

Change pin Press Enter Channel Lock Press Enter

DVB-T

Password:

****

After unlocked, a whole channel list will be displayed for your selecting.

Channel Guide Channel Lock

No TV Lock 0001 GZTV-M1 0002 GZTV-M2 0003 GZTV-M3 0004 GD 1 0005 GD 2 0006 GD 3 0007 GD 4

ENTER key to lock/unlock DTV/RADIO key to switch TV/RADIO

ANTENNA POWER

Choose On to activate the active antenna power. This can help you to get better signal. The default is On.

MOBILE ENTERTAINMENT

System Config

TV Setting Audio Setting Language Parent Control

Antenna Power

Exit Setup

Off

INSTALLATION

ENG

AUTO SCAN

Auto scanning.

Auto Scan Select Country

Installation

Auto Scan

Manual Scan Default Setup Exit Setup

Select Country England Start Scan Press Enter

Note:

Press SCAN on the remote control to bring up the quick auto scan.

MANUAL SCAN

Perform program scanning. ( Found programs will be appended to the program list.)

Scan Country

England Italy France Spain Holland Australia Norway Sweden

Manual Scan Country

Country EngLand Scan Type Single Channel Start Channel 21 start Freq 474000KHz End Channel 21 End Freq 474000KHz Band Width 8MHZ Start Scan Press Enter

Finland Portugal Others China Taiwan Germany

There are 4 optional items:

Country: Choose the right territory.

Scan Type: Channel Range and Single Channel.

Start Channel: Choose the desired start channel which is in accordance with certain frequency.

END Channel: Choose the desired end channel which is in accordance with certain frequency.

DVB-T

MOBILE ENTERTAINMENT

ENG

INSTALLATION

DEFAULT SETUP

Resume the factory settings.

DVB-T

Installation

Auto Scan Manual Scan

Default Setup

Exit Setup

Message BOX

Reset to default!

Note:

The default settings action will resume all the factory settings, including the deletion of all the saved programs.

Cancel

MOBILE ENTERTAINMENT

GAME

ENG

Get to the game function from the main menu. You will find three kinds of games in DTV state.

Game

BoxMan Burning Tetris Hit Rat Exit Setup

BOXMAN

Use , , and buttons to control the little man to move the boxes to the appointed place. Only one box can be moved at a time.

STEP 000 LEVEL 1

DVB-T

Press the OK key to play the higher level one.

BURNING TETRIS

1. Use and to move Tetris left and right.

2. Press to shift the direction of the Tetris.

3. Press to accelerate the Tetris downwards.

Press the OK key to pause/play the game.

LEVEL 1 SCORE 0000

MOBILE ENTERTAINMENT

ENG

GAME

HIT RAT

Press 1,2,3,4,5,6,7,8,9 to hit the rat according to its corresponding directions of where it appears on the screen.

DVB-T

SCORE OO LEVEL 1

MOBILE ENTERTAINMENT

FM TRANSMITTER

FM TRANSMITTER INSTRUCTIONS

ENG

FM transmitter

1. Press ADJUST button to enter the adjustments of brightness, color, TFT mode,

view mode, FM transmitter and IR transmitter.

2. Use the / buttons on the main unit board or / buttons on the remote control to choose FM transmitter, then press enter button.

OFFON: 87.6 MHZ

:ENT

FM:87.6--107.9 MHZ

0 87.6 MHZ

:SEL :-/+

3. Use the / buttons to choose ON , then press enter button to enter frequency input mode.

4. There are two frequency input modes: one is to input numbers directly; the other is to increase or decrease frequencies by the direction buttons. By pressing the / buttons to change the place number inputted, while the / buttons to decrease and increase frequency number.

5. The input frequency range is from 87.6-107.9MHZ. The default is OFF.

6. If the input number is out of the range of 87.6-107.9MHZ the frequency will be displayed in cycles from the beginning.

:ENT

7. Press ENTER button to save the choice after selecting the preferable frequency within the permissible range. Then the player will transmit audio signal according to this frequency. Choose OFF to turn off the FM function.

8. Adjust your receiving set (eg. car stereo) to the corresponding frequency to receive the transmitted audio signal from the player.

9. The transmission range will be within approximately 3 meters.

MOBILE ENTERTAINMENT

ENG

IR TRANSMITTER

1. Press ADJUST button to enter the adjustments of brightness, color, TFT mode,

view mode, FM transmitter and IR transmitter.

IR transmitter

2. Use the / buttons on the main unit board or remote control to choose IR transmitter, then press enter button.

OFFON

:ENT

OFFON

:SEL

3. Use the / buttons to choose ON , then press enter button to confirm. Then the IR transmitter works and the IR lens on the front board lights up.

4. Only the IR headphone produced by the same company (who makes this player) can get the IR signal from the player.

5. The transmission range will be within approximately 5 meters.

6. The default is OFF.

:EXIT

MOBILE ENTERTAINMENT

Fit the Portable DVD Player to

the Headrest Mount or VESA Wall Mounting Bracket

1. The followings show you how to fit the portable DVD player to the headrest mount in the car.

1). Take out the headrest mount and fix it on the car chair.

ENG

DVD DVB-T

Release the straps Place the two mounting straps over

2). Take out the backplate and fit it on the rear side of portable DVD player

Fit the screws in the four screw holes where the arrow pointed

3). Gently slide the portable DVD player down by aligning the backplate groove with the headrest mount until you hear the click sound. Then the installment is finished.

your headrest with the mount's sponge facing the headrest .

Secure the mount by tightening the straps

Screw Size: M4*8

2. How to fit portable DVD player to the VESA wall mounting bracket

Gasket Size: 4.3*9*0.8mm

Connect the portable DVD player with the VESA wall mounting bracket with the middle four screw holes (there are 4 gaskets for using).

MOBILE ENTERTAINMENT

ENG

Please place the antenna as follows to improve the receiving strength of TV signals.

MINI-MAGNETIC ANTENNA INSTALLATION GUIDE

1.Please position the antenna close

DVD DVB-T

to the window when using in-door.

2.Please position the antenna on the

roof when using in-car. (Do not use

it when the car is moving)

(SDV485-BY)

MOBILE ENTERTAINMENT

(SDV485-B)

SIZE AND PARAMETER

Product name: TABLET DVD player

OTHERS

ENG

DVD DVB-T

Power:

Consumption:

Audio out:

Video out:

Size:

Weight:

DC12V

<10W

R/L 2ch,OPTICAL

Composite

260X175.6X26.5mm

950g

MOBILE ENTERTAINMENT

ENG

OTHERS

TROUBLE SHOOTING

Symptoms

DVD DVB-T

The disc does

not play

No display

No sound

Maintenance and clean the unit only as recommended in the operational instructions.

DAMAGE REQUIRING SERVICE

Possible causes Remedies

Disc is loaded incorrectly.

Disc is dirty or scratched.

Wrong region disc.

AV cable is disconnected. Wrong setting or

connection for the player or TV. The antenna is not connected well. Wrong mode setting.

AV cable is disconnected.

Wrong setting or connection for the player or TV.

Load the disc with the label side up, and firmly pressed into the center.

Make sure the disc is free from scratches or fingerprints.

Use the right region disc.

Connect the cable firmly. Setting or connecting correctly with your player or TV. Connect the antenna well.

Set the right mode.

Connect the cable firmly.

Setting or connecting correctly with your player or TV.

Have the unit serviced by a qualified service technician if: The unit has been exposed to rain or water. The unit does not seem to operate normally. The unit exhibits a marked change in performance.

DO NOT ATTEMPT TO SERVICE THE UNIT BY YOURSELF!

MOBILE ENTERTAINMENT

SDV485-B/BY-ENG-NB-A0

Nextbase SDV485-BY Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
