User Manual

Introduction to your Dash Cam

This range of Nextbase™ Dash Cams has been designed specifically with ease of use in mind; it is recommended NOT to change the default settings, which have been carefully selected to give the best performance for day to day use.

Please check the firmware version of the Dash Cam, the version can be found in the Setup menu under System Info. The latest versions are available to download from our website, where you can download and update when necessary.

www.nextbase.com

Basic Operation

It is essential that a quality branded Class 10 or U1 type Micro SD card is used with this Dash Cam use to the very large data rate generated by high resolution recording. For best results, we recommend using our Nextbase™ branded SD cards with your Dash Cam. Your Nextbase™ Dash Cam is set to record video, in ﬁles of just 1 minute in length. This means that each video ﬁle is a manageable size should you need to download and send to your insurance company. Eventually your MicroSD card will ﬁll up with video ﬁles but don't worry, the camera automatically deletes the oldest ﬁle to make space for new recordings. This way you never run out of space and have plenty of driving data saved.

Typically a 16Gb card will store the last 1.5 hours of driving footage.

For summer months where the clocks are brought forward or for driving in other countries, adjust the time in the Setup Menu (Time & Date) to account for the time difference from GMT by adding or subtracting 1 hour as required.

1. Tips for capturing best video footage:

1.1 Position the Dash Cam in the centre of the windscreen and ideally behind the rear view mirror so it is not a distraction to the driver.

1.2 Ensure that the area on the windscreen that the Dash Cam is looking through is clear of dirt and is within the wiper zone. This will ensure that your videos are as clear as possible.

1.3 Reduce the amount of sky in the picture, by angling the view of the camera towards the road. Too much sky will make the road appear darker due to the automatic exposure compensation.

1.4 Remove unnecessary items from your dashboard. If objects are placed on your dashboard these can cause reﬂections to be seen on the windscreen and these reﬂections may be captured during recording.

1.5 To improve dash board glare, a Nextbase Polarising Filter/Reflection Free Lens can be purchased.

2. Tips for stable memory card performance:

2.1 Periodically format the memory card. Every 2-3 weeks we recommend that you format the memory card. This will wipe any ﬁles from the card and set it up afresh for continued use with your Dash Cam. Of course, you should only do this AFTER you've downloaded any ﬁles from the card that you may want to keep, as formatting the card will remove all content.

There are 3 modes of camera operation - Video, Photo and Playback. Press the MODE button on the Dash Cam to select required mode. Video Mode: The default mode when the camera is turned on, for video recording. Photo Mode: Allows you to take still photographs. Playback Mode: Allows you to view recorded video or photographs upon the Dash Cam LCD screen.

Automatic Start / Stop Technology

This Nextbase™ Dash Cam senses power supplied to the cigarette lighter socket as soon as the vehicle ignition is turned on and will start to record automatically. When the ignition is turned off, the Dash Cam will perform an automatic shutdown process.

2.2 Format your memory card using the Dash Cam. This will make sure that the card is structured specifically for your camera. Within the Setup menu, select ‘Format SD Card’ and follow the on-screen instructions.

2.3 Switch off the Dash Cam before removing the SDcard, to prevent the chance of damage being caused to the memory card or the ﬁles stored upon it.

Table of Contents

INTRODUCTION TO USING AN IN-CAR CAM

TABLE OF CONTENTS

PRECAUTIONS / CAUTIONS ON USING THIS PRODUCT

PRODUCT WARNINGS

USAGE PRECAUTIONS / NOTICES / CANADA COMPLIANCE

FCC STATEMENT

FCC- SUPPLIER’S DECLARATION OF CONFORMITY

PRODUCT SPECIFICATION

PACKAGE CONTENTS / PRODUCT FEATURES

CAMERA PARTS & CONTROLS

IN VEHICLE INSTALLATION

POSITIONING YOUR DASH CAM / ACCESSORIES

CHANGING MOUNT ATTACHMENTS

FIRST TIME USE

11 - 12

13 - 16

19 - 21

EMERGENCY SOS FREQUENTLY ASKED QUESTIONS

MYNEXTBASE

VIDEO MODE / PLAYBACK MODE

VIDEO MODE / PHOTO MODE / PLAYBACK MODE

PLAYBACK MODE - VIDEO EDITING

PLAYBACK MODE - PROTECT & DELETE

MYNEXTBASE CONNECT™

MYNEXTBASE PLAYER™ - OVERVIEW

MYNEXTBASE PLAYER™ - EDITING

MYNEXTBASE CLOUD™

PC CONNECTION

FIRMWARE UPDATE INFORMATION

TV CONNECTION

NEXTBASE™ SD CARDS / CE MARK INFORMATION

MENUS / VIDEO SETTINGS

VIDEO SETTINGS (CONT.) / SETUP SETTINGS

SETUP SETTINGS (CONT.)

DRIVER ASSISTANCE

DRIVER ASSISTANCE - EMERGENCY SOS

EMERGENCY SOS - FLOW DIAGRAM

FREQUENTLY ASKED QUESTIONS

SOFTWARE LICENSE AGREEMENT

WARRANTY / ONLINE & INTERNATIONAL PURCHASES

MORE NEXTBASE™ PRODUCTS / SERVICES / SOFTWARE

DASH CAM RANGE FUNCTIONS

42 - 43

Precautions

Cautions on Using this Product

Please read this manual carefully before operation and keep it for future reference. It will be helpful should you encounter any operational problem.

WARNING:

CAUTION:

LCD:

WEEE:

CHOKING

HAZARD:

Do not expose this product to rain, moisture or water under any circumstances, doing so may result in the risk of electric shock or fire.

To reduce the risk of electric shock, do not perform any servicing other than that contained in the instruction manual unless you are qualified to do so. Have the unit serviced by a qualified service technician if; The unit has been exposed to rain or water. The unit does not seem to operate normally. The unit exhibits a marked change in performance.

A Liquid Crystal Display (LCD) screen is a multilayer complex component, containing 311,040 pixels. Pixels can however fail during normal product life. 1 pixel = 0.00003% failure rate, and one pixel failure per year of operation is considered normal and not a cause for concern.

Disposal of Waste Electrical and Electronic Equipment and/or Battery by users in private households in the European Union. This symbol on the product or on the packaging indicates that this cannot be disposed of as household waste. You must dispose of your waste equipment and/or battery by handing it over to the applicable take-back scheme for the recycling of electronic equipment and/or batteries. Formore information please contact your local household waste disposal office.

Some Products may contain components that are small enough to be swallowed. Please keep out of reach of children.

1. Ensure that the windscreen is free of dirt or grease before placing mount upon it.

2. Do not obscure the view of the road ahead or impede the deployment of any airbags in the event

of an accident.

3. When not in use, please disconnect the car adaptor from both the 12/24Vdc outlet in your vehicle and the device itself.

4. Only clean the device with a soft dry cloth, for tough dirt, apply some neutral detergent diluted in 5 to 6 parts water to a soft cloth. Please note that alcohol, thinner, benzene etc could cause damage to the paint or coatings.

5. Avoid making contact with the lenses as damage may be caused.

6. If required clean the glass lens carefully using spectacle lens cleaning fluid on a soft cloth only.

7. The video recordings made by this Dash Cam are intended for personal use only.

8. Publication of the recordings on Youtube, the internet or other methods are subject to the

Data Protection Act and the requirements thereof must be adhered to. If the Dash Cam is to be used within a commercial environment, i.e. truck use, then the CCTV regulation apply also, in addition to the Protection Act regulations. This includes labelling to identify the use of CCTV is taking place, the omission of Audio recording and informing the relevant authorities of who controls the data.

9. Video playback upon the device which is visible to the driver is prohibited or restricted in some countries or States. Please adhere to these laws.

10. Whilst driving, do not adjust the controls of your device as this is a distraction to driving.

11. Before using the device on your windscreen, check the state and local laws and ordinances where

you drive. Some laws prohibit or restrict the placement of objects on the windscreen of a motor vehicle. IT IS THE USER'S RESPONSIBILITY TO MOUNT THE DEVICE IN COMPLIANCE WITH ALL APPLICABLE LAWS AND ORDINANCES. Always mount your Nextbase device in a location that does not obstruct the driver's view of™ the road. Nextbase does not assume any responsibility for any fines, penalties, or damages of your Nextbase device. Nextbase accepts no responsibility for any damage or injury caused when the dash cam is in use.

Distractions can lead to accidents, and the risk of injury or death. Always keep your eyes on the road, and keep aware of your surroundings.

Product Warnings

Failure to heed the following warnings could result in an accident or collision resulting in death or serious injury.

Distraction Warning

This device is intended to enhance the situational awareness when used properly. If used improperly, you could become distracted by the display, which could lead to an accident causing serious personal injury or death. DO NOT seek to access the information stored on the device or change the device settings whilst driving. Information stored on the device should be reviewed only when your vehicle is stationary, and you are parked in a safe place in compliance with local laws. The device settings should only be changed when your vehicle is stationary, and you are parked in a safe place in compliance with local laws. Always maintain awareness of your surroundings and do not stare at the display or become distracted by the display. Focusing on the display could cause you to miss obstacles or hazards. Use the device at your own risk.

Do not change settings, or access any functions requiring prolonged use of the device controls while driving. Pull over in a safe and legal manner before attempting such operations.

Video playback upon devices with display which are visible to the driver, is prohibited or restricted in some countries or States. Please adhere to these laws.

Vehicle Installation Warnings

When installing the device in a vehicle, do not place the device where it obstructs the driver's view of the road or interferes with vehicle operating controls, such as the steering wheel, foot pedals, or transmission levers. Do not place unsecured on the vehicle dashboard. Do not place the device in front of or above any airbag.

Battery Warnings

Lithium-ion batteries are used in most Nextbase™ devices. If these guidelines are not followed, batteries may experience a shortened life span or may present a risk of damage to the device, fire, chemical burn, electrolyte leak, and/or injury.

- Do not disassemble, modify, remanufacture, puncture, or damage the device or batteries.

- Do not remove or attempt to remove the non-user replaceable battery.

- Do not expose the device to fire, explosion, or other hazard.

- Do not expose the device to rain or water.

Magnet Warnings

Both the Dash Cam and its mount may contain magnets. Under certain circumstances, magnets may cause interference with some internal medical devices, including pacemakers and insulin pumps. Devices and mounts that contain magnets should be kept away from such medical devices. Magnets may cause damage to some electronic devices, including hard drives in laptop computers and bank / credit or membership cards. Use caution when devices and mounts that contain magnets are near electronic devices or bank / credit or membership cards.

Usage Precautions

Notices

Failure to heed the following precautions could result in personal injury or property damage, or negatively impact the device functionality.

Battery Precaution

- Do not immerse or expose the Dash Cam or batteries to rain, water or other liquids.

- Do not leave the device exposed to a heat source or in a high-temperature location, such as in the sun or in an unattended vehicle. To prevent the possibility of damage, remove the Dash Cam from the vehicle or store it out of direct sunlight, such as in the glove box.

- Do not operate the Dash Cam outside of the following temperature range: from -20° to 45°C (from -4° to 113°F).

- When storing the Dash Cam for an extended time period, store within the following temperature range: from 0° to 25°C (from 32° to 77°F).

- Do not use a power and/or data cable that is not approved or supplied by Nextbase™.

- Contact your local waste disposal department to dispose of the Dash Cam/batteries in accordance with applicable local laws and regulations.

Windshield Mounting Legal Restriction Precaution

Before using the Dash Cam on your windshield, check the state and local laws and ordinances where you drive. Some laws prohibit or restrict the placement of objects on the windshield of a motor vehicle. IT IS THE USER'S RESPONSIBILITY TO MOUNT THE DEVICE IN COMPLIANCE WITH ALL APPLICABLE LAWS AND ORDINANCES. Always mount your Nextbase™ Dash Cam in a location that does not obstruct the driver's view of the road. Nextbase does not assume any responsibility for any fines, penalties, or damages that may be incurred as a result of any state or local law or ordinance relating to the use of your Nextbase Dash Cam.

Camera Legal Requirements Precaution

In some jurisdictions it could be considered an invasion of privacy rights to take or publicly display photographs or videos of people or their vehicles using this product. It is your responsibility to know and comply with applicable laws and rights to privacy in your jurisdiction and in any jurisdiction in which you may use this device. Video recordings made by this Dash Cam should be for personal use only.

Publication of the recordings on YouTube, the internet or other methods is subject to the data protection legislation and the requirements thereof must be adhered to. Such data protection legislation may prohibit the use and dissemination by you of Dash Cam footage or may impose restrictions on it – we recommend that you check the legal requirements with your legal advisor before disseminating any Dash Cam footage.

G Sensor Notice

The G Sensor within the Dash Cam measures forces exerted upon it, with reference to one g which is the nominal force exerted upon us when stationary on the earth's surface. The G Sensor will also trigger to protect any recording currently in progress, if a pre-determined threshold of force is exceeded.

The G Sensor protection will be adversely affected if the Dash Cam is NOT mounted in the vertical direction i.e. with the lens pointing to or from the direction of travel.

G Force information derived from a G Sensor is not warranted to be totally accurate at all times, as it is derived from the G Sensor through a sampling method over time. The precision of the G Sensor value recorded depends upon when the acceleration took place at the instance of the sample taken.

The thresholds to trigger the video protection rely upon a trigger value being exceeded between two successive samples, in any one of the three G Sensor axis.

If the Automatic G Sensor protection does NOT trigger during an event, then the Protect button should be pressed, in order to protect the file. Protecting the file can also be performed using the Playback function upon the Dash Cam (models with LCD screens), or indeed through the MyNextbase Connect™ App for applicable Wi-Fi models.

Product Compliance Information

Innovation, Science, and Economic Development Canada Compliance

This device complies with Innovation, Science and Economic Development Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. interference, including interference that may cause undesired operation of the device.

Radio Frequency Band and Power Information

Hereby, Portable Multimedia Limited declares that the radio equipment type Series 2 Dash Cam is in compliance with Directive 2014/53/EU.

If the Dash Cam is to be used within a UK commercial environment, i.e. truck use, then the CCTV regulations apply in addition to the Data Protection Act regulations. This includes labelling to identify the use of CCTV is taking place, the omission of Audio recording and informing the relevant authorities of who controls the data. For use in a commercial environment in non-UK countries, please refer and adhere to local regulations and requirements. For non-UK operation, specific legal requirements may apply where Dash Cams are to be used in a commercial or employment context - again, we recommend that you check the legal requirements with your legal advisors prior to commencing use of Dash Cams in commercial or employment contexts.

Product Wireless Information

2400–2483.5 MHz: Wi-Fi (Max 16.3 dBm), BT (Max 6.0 dBm), BLE (Max 6.0 dBm).

RF Exposure Information (MPE)

This device meets the EU requirements and the International Commission on Non-Ionising Radiation Protection (ICNIRP) on the limitation of exposure of the general public to electromagnetic fields by way of health protection. To comply with the RF exposure requirements, this equipment must be operated in a minimum of 20 cm separation distance to the user.

FCC Statement

FCC Identiﬁer

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment oﬀ and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment to an outlet on a circuit diﬀerent from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

- This appliance and its antenna must not be co-located or operated conjunction with any other antenna or transmitter.

- A minimum separation distance of 20cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements.

The FCC Identifier (FCC ID) is available as an E-label within your Dash Cam’s System Info pages.

To view the FCC ID please follow the steps below:

Step 1: Step 2:

Connect Apps

Press the ‘Menu’ button to enter

Press the ‘Setup’ button.

the Dash Cam’s menu system.

Step 3:

Swipe through the menu pages

and select System Info.

Model: Firmware: Serial No: FCC ID: Battery Status:

System Info

2AOT9-NBDVR322GW

The FCC Identiﬁer (FCC ID) is

seen as above.

322GW

Rxx.x

123456789

Charging

Note:

- The Regulatory Information (inc. the FCC ID) is embedded with the Dash Cam’s firmware, applied to

the gift box and included within this User Manual.

- The FCC ID cannot be changed by the user.

FCC CAUTION:

This product does not contain any user-serviceable parts. Repairs should only be made by an authorised Nextbase™ service centre. Unauthorized repairs or modiﬁcations could result in permanent damage to the equipment, and void your warranty and your authority to operate this device under Part 15 regulations.

FCC - Supplier’s Declaration of Conformity Statement

SUPPLIER'S DECLARATION OF CONFORMITY (47 CFR Section 2.906).

We; Tank Design (The responsible party, who must be located in the United States)

Hereby, Declare that the essential requirements set out in the 47 CFR Sections 2.906 of FCC, have been fully fulfilled on our product with indication below:

1. Applicant's Info

Company Name: Portable Multimedia Ltd Mailing Address : Unit 2, Caerphilly Business Park, Van Road, Caerphilly. CF83 3ED. UK Contact : Graham Lambert Tel : +44 02920 866429 Email Address : support@nextbase.com

2. Product Info

Product Name : Dash Cam Model No. : NBDVR322GW Brand Name : Nextbase

3. Applied Standard

Standards E-CFR Title 47 Part 15 Subpart B—Unintentional Radiators: 2018

5. FCC Marking

6. Responsibilities and obligations

Strictly follow the FCC rules of 2.906, 2.908, 2.909.

7. Applicant's Authorisation

Company Name: Portable Multimedia Ltd Mailing Address : Unit 2, Caerphilly Business Park, Van Road, Caerphilly. CF83 3ED. UK Contact person : Graham Lambert Signature: Email Address : support@nextbase.com Tel : +44 02920 866429 Date : 30th April 2019

8. Responsible party in US.

Company name: Tank Design Mailing Address: 158 Sidney Street, Cambridge, MA 02139, United States Contact person : Mr Scott Watts Signature: Email address : SWatts@tankdesign.com Tel : (617) 388-8380 Date : 30th April 2019

Report No. WTS19S04021635E

4. Test Firm Used to Take Measurements:

Name : Waltek Services (Shenzhen) Co., Ltd. Address : 1/F, Fukangtai Building, West Baima Rd Songgang Street, Baoan District, Shenzhen, Guangdong, People's Republic of China, 518105 Contact Name : Philo Zhong Tel : +86 755 8355 1033 802 Email : CB@waltek.com.cn Designation No. : CN1201 FRN : 523476

Product Speciﬁcation

Model Number / Name

Power Requirements

Power Supply

Sensor Resolution

Lens Type / Angle / Aperture

Recording Resolution

Screen Size

Screen Resolution

Screen Ratio

Card Reader

SD Card (Recommended Type)

SD Card Recorded File Capacity (based on default settings)

Recording Format

Internal Battery

GPS Module

Unit Dimensions

Unit Weight

NBDVR322GW

5V / 1.5A

12-24Vdc Car Power Cable (supplied) Fuse Type: 32mm / 2A Output: 5Vdc

Hardwire Kit also available to purchase for a hidden, permanent power supply.

2.12M Pixel (1936 x 1097)

5G / 140° / F1.6

1920 x 1080 @60fps day & night

2.5"

732 (W) X 240 (H) pixels x RGB (720)

16:9

MicroSD, Class 10, up to 128GB

8-128GB SDHC, U3, Class 10 (48mb/s) For best results, use a recognized brand.

8GB MicroSD = 60 minutes of recording 16GB MicroSD = 120 minutes of recording 32GB MicroSD = 240 minutes of recording 64GB MicroSD = 480 minutes of recording 128GB MicroSD = 960 minutes of recording

MP4

Lithium-Polymer 3.7V / 320mAh (approx. 15 mins recording time) Battery design allows the 'Auto Power Off' feature to function in event of power loss within the vehicle. It is not intended as an alternative power source to replace the supplied car adaptor.

Simple / ST702G-15C40

82 x 46 x 47

104g

The Bluetooth™ word mark and logos are registered trademarks owned by Bluetooth SIG. Windows is a registered trademark of Microsoft Corporation in the United States and other countries. Android is a trademark of Google Inc in the United States and in other countries. 2015 Google Inc. All rights reserved. Google Maps™ mapping service is a trademark of Google Inc. Mac is a registered trademark of Apple Inc in the United States and in other countries. iOS is a trademark or registered trademark of Cisco in the United States and in other countries. Wi-Fi is a registered mark of Wi-Fi Alliance Corporation. microSD and the microSD logo are trademarks of SD-3C, LLC. MyNextbase Player™, MyNextbase Cloud™, and Click&Go PRO™ are registered trademarks of Portable Muultimedia Ltd.

Package Contents

Product Features

Please check the contents of you Nextbase Dash Cam product.

Nextbase ™322GW Dash Cam

Click & Go Powered Mounts: Suction and Adhesive

Car Power Cable (4m)

USB Connection Cable

Your Dash Cam to record the road ahead

Two mount attachments

for you to choose

between.

Charge your Dash Cam in car

using the Car Power Cable

Connect your Dash Cam to a PC

Thank you for purchasing this Nextbase™ Dash Cam product, in this section we will outline some of the features available with this dash cam.

HD Recording Capability

1080p HD recording at 60 fps, to record the road ahead.

HD Touch Panel Display

Bright, clear, high definition 2.5" screen with IPS technology for a wide viewing angle.

Click & Go Pro Powered Mount

Our exclusive Click and Go Pro powered magnetic car mount to easily install and remove your Dash Cam with just one hand. Supplied with both adhesive and suction fittings.

G Sensor / File Protection

In the event of an impact the device will automatically 'protect' the recording, stopping the file from being over-written. This can also be performed manually, by pressing the ‘protect’ button. Individual files can also be 'protected' when viewed within playback mode.

Inbuilt GPS

Inbuilt GPS to keep track of your journeys.

Automatic Start / Stop Technology

As soon as the vehicle ignition is turned on, your Dash Cam will start to record automatically. When the ignition is turned off, the Dash Cam will perform an automatic shutdown process.

Intelligent Parking Mode

Intelligent Parking Mode triggers recording automatically when motion is detected, keeping your car safe when parked.

222 Quick Start Guide

Cable Tidy Tool

Product appearance may differ slightly to that shown above.

Quickly get your Dash Cam up and

running using Quick Start Guide.

Use the Cable Tidy Tool to stow the

power cable within the lining of your car.

Built-in Microphone & Speaker

Record audio to compliment the video recordings.

Nextbase Cloud™ Service

View and share your footage online using the MyNextbase Cloud™ service. Upload your video to the Nextbase™ server to get a shareable link to send to friends, insurers, and social media. Upload your videos via the file upload area on . The uploaded file will be deleted after 30 days,Mynextbase.com when the link will also expire.

MyNextbase Connect™

MyNextbase Connect™ is the new Nextbase™ app that allows you to view and manage your videos, upload files to social media, and contact emergency services in the event of an incident.

Dash Cam Accessories

You Dash Cam can be fitted with a range of Nextbase accessories to enhance your recordings, including Rear Facing Cameras to record the road behind you, or the interior of your vehicle. See the Nextbase™ Accessories Manual on to view the full range.nextbase.com

Camera Parts and Controls

See below to identify the parts and controls of your Dash Cam

Dust Cover

Mounting point located under the dust cover

Speaker

Integrated speaker for audio playback

Camera Lens

Wide angle 120º

Power Button

Press and hold for 2 seconds to turn the Dash Cam On/Off

LEDs

Top: Blue

- The Blue LED will be on while the Dash Cam is charging. It will turn off when charging is complete, even if the Dash Cam is still plugged in. Bottom: Red The Red LED is permanently on while the Dash Cam is active. It will flash while recording.-

Protect Button

Press whilst recording to protect the current file in event of an emergency situation.

Note:

- When the 'Protect' function is activated a file containing 10 seconds prior to the incident

and 20 seconds after is written to the Protected folder.

Screen

2.5" Inch High Resolution Screen. Tap the screen to take a photo; this applies both when recording and when not. If a Rear Cam is attached, touch the centre of the Front Facing view to take a photo. This will save 2 photos, one from the Front Facing camera, and one from the Rear Facing camera.

Camera Parts and Controls (cont.)

See below to identify the parts and controls of your Dash Cam

Dust Cover

Mount point located under the dust cover

USB Cover

USB port located under the dust cover

Light Sensor

Automatically adjusts the screen brightness relative to the ambient light levels.

Reset Button

Press to force the Dash Cam to restart.

Microphone

Integrated microphone for audio recording

Reset

Power Button

Press and hold for 2 seconds to turn the Dash Cam On/Off. Short press acts as a back button when in the menus.

MicroSD Card Slot

Insert the MicroSD card here, taking care that the gold contacts are facing towards the rear of the Dash Cam.

HD-Out/Rear Cam Input

Connection point for the Rear Cameras and TV connection, see page xx.

In Vehicle Installation

Please follow the instruction below for the first-time installation of the Dash Cam. For day to day use, simply remove the camera from the mount as required.

1 Insert MicroSD Card

Insert a suitable MicroSD card (Class 10, minimum 48/Mbps) in to the Dash Cam, taking care that the gold contacts are facing towards the LCD screen side of the Dash Cam. Push the memory card until it clicks into place.

Note:

- Use the edge of a small coin (or similar object) to push the memory card in place if required. Take care that card has 'clicked' into place, a second push inwards will release the memory card.

- For best results, we recommend using Nextbase™ branded SD cards.

- Do not remove or insert the memory card when the Dash Cam is turned on. This may damage the memory card, or the recordings within.

2 Remove dust cover from the Dash Cam

Remove the dust cover that is located on the front of the Dash Cam to gain access to the mounting point.

To remove the dust cover, lift the cover away from the body of the Dash Cam.

Note:

- If the Dash Cam is not to be used for a period of time replace the dust cover to help keep the components free of dust or other contaminants.

3 Attach the mount to the Dash Cam

Place the mount in space under the dust cover on the Dash Cam. Once in place, magnets within the mount and camera will hold the two parts together.

See page 16 for more information on changing mounts attachments.

In Vehicle Installation (cont.)

4 Connect car power cable

Connect the supplied car power cable to the Dash Cam Mount’s USB port. Do NOT connect the power cable to the USB port on the Dash Cam.

5 Plug the power cable into the 12-24Vdc outlet of your vehicle

The Dash Cam will automatically power on and start recording once power is available. In some vehicles this will be when connections are made, for others the Dash Cam will power on once the ignition has been turned on.

Also available to purchase is a Nextbase Hardwire Kit. This connects your Dash Cam directly to the vehicle’s fusebox to power it leaving your cigarette socket available for Phone / Sat Nav charging. The Nextbase™ Hardwire Kit includes the necessary 12-24VDC to 5Vdc convertor and battery protection circuitry. See page 9-10 of the Nextbase™ Accessories Manual for further information.

Route the power cable around the windshield to the 12-24Vdc socket, ensuring that your view is not obstructed, and that the cable is not a distraction. Use the cable fitting tool included with your Dash Cam (below, left) to more easily open the lining of your vehicle, within which you can stow the cable. See page 17, ‘Positioning your Dashcam’ for more details.

Note:

- Do NOT wire the Dash Cam directly to a 12V supply by cutting the cigarette plug off the end of the cable, or permanent damage will result.

12-24Vdc

The above diagram is for illustration purposes only.

Cable Tidy Tool (included with your Dash Cam)

In Vehicle Installation (cont.)

6 Remove the adhesive cover layer

Peel back the red cover layer to expose the adhesive surface, ready to mount on your windscreen.

7 Straighten the Dash Cam

Ensure that the Dash Cam is horizontal and faces straight out of the windscreen. Ensure that objects on the Dash Cam display appear level, and adjust as required.

8 Attach the Dash Cam to the windscreen

When you are satisfied with the placement and orientation of the Dash Cam, firmly place the mount on the windscreen.

In Vehicle Installation (cont.)

9 Adjusting the Dash Cam

With the mount attached to the windscreen, ensure that objects on the Dash Cam display are level and adjust as required. Ensure that the road ahead is at the centre of the image, in the central third of the display. If too much of the sky is visible it may risk underexposing details on the road; ensure that the road ahead is clearly visible on the Dash Cam display. Do NOT attempt to adjust the Dash Cam while driving.

Positioning Your Dash Cam

Notes On Positioning Your Dash Cam

Please read and follow the notes below for the safe operation of your Dash Cam within your vehicle.

Before using the device on your windscreen, check the state and local laws and ordinances where you drive. Some laws prohibit or restrict the placement of objects on the windscreen of a motor vehicle. IT IS THE USER'S RESPONSIBILITY TO MOUNT THE DEVICE IN COMPLIANCE WITH ALL APPLICABLE LAWS AND ORDINANCES. Always mount your Nextbase™ device in a location that does not obstruct the driver's view of the road. Nextbase does not assume any responsibility for any fines, penalties, or damages that may be incurred as a result of any state or local law or ordinance relating to the use of your Nextbase device.

As per the installation instructions, you must install the Dash Cam so it does NOT obstruct the driver’s view of the road (red, above), preferably on the passenger side of the vehicle and behind the rear view mirror. The Dash Cam needs to view through a clear section of windscreen in an area swept by the windscreen wipers (green, above). However, the Dash Cam should be installed so as not to intrude significantly within the wiped area. A 40mm intrusion into the green wiped area is the maximum permitted by UK law.

Hiding the Cable

Make sure the hanging cable does not obstruct your view out of your rear window. Ensure that there are no kinks in the cable as you are stowing it. If necessary, use the cable tidy tool supplied with your Dash Cam; this can be used to help pry open the lining of your car (see illustration below).

- Do NOT mount the Dash Cam in front of the driver, as depicted by the red area in the illustration to the left of this page.

- When installing the Dash Cam in a vehicle, always place the device securely against the windscreen and where possible conceal the power cable under trim.

- Make sure that the Dash Cam power cable does not interfere with the drivers operating controls, such as the steering wheel, pedals or gear levers.

- Do NOT mount the Dash Cam in front of an airbag field of deployment or in a position to obscure any mirrors.

- Clean the windscreen at the point of location, prior to fitting the Dash Cam, also, applying some moisture to the suction cup may be beneficial, to ensure absolute adhesion.

- It is recommended NOT to operate the Dash Cam whilst driving. The automatic Start-Stop technology incorporated within the device negates any need to operate the controls whilst driving.

- Adjust any settings or review recordings whilst stationery, not whilst driving.

- After the preliminary SETUP has been carried out upon the Dash Cam, adjust the Screen Saver settings to either ON or Speed display (showing only your speed). Turning the Screen Saver ON will blank the screen 30 seconds after starting the vehicle and therefore the screen will NOT be a distraction to the driver.

Accessories

Multiple accessories can be purchased for your Nextbase Dash Cam, including a Rear Window Camera, a Polarising Filter, and a Rear Facing Camera. Some of these products can effect where you should position your camera. For more information on how to position and use these products, download the ‘Nextbase Accessories Manual’ PDF a www.nextbase.com.

Changing Mount Attachments

Follow the instructions below to switch between mounts attachments; 3M adhesive or suction. To attach each mount, align the pins on the mount with the holes on the adhesive/suction attachment and slide firmly to the right until you hear the pieces click into place. To remove the top, simply do the reverse, slide it to the left until you can lift it off of the mounting pins.

Ensure the windshield is free of grease and dirt before mounting; if necessary, clean with a warm, clean cloth. Ensure that the Mount and Dash Cam do not obstruct the driver’s view.

Removing Adhesive Residue

If you wish to remove the adhesive mount from your windscreen, use hot soapy water or an alcohol based solution to get rid of any sticky residue and ensure that your windscreen remains clean and clear. Leaving residue on the windscreen for an extended period of time will make it harder to remove. If hot water or an alcohol based solution proves ineﬀective, it may be necessary to use a small sharp blade. If this is the case, protect your ﬁngers and use the blade ﬂat against the surface of the glass to avoid causing scratches.

Rollover the camera above to preview both mounts

First Time Use

To ensure the set up of this Dash Cam is as quick and simple as possible, there is an easy to follow ‘First Time Use’ menu.

This menu is used to set your preferred Language, Country (inc. Time Zone) and Speed Units.

This menu will appear when:

1. The Dash Cam is first turned on.

2. There has been a Firmware Update applied to the Dash Cam and ‘Keep User Settings’ has been set to OFF. If It is set to ON, your Dash Cam will start normally, with your settings intact.

3. After the Dash Cam’s settings have been reset, by using the ‘Default Settings’ option in the Setup Menu.

Follow the on-screen instruction to select the Language, Country, and Speed Units. The settings that influence the displayed time & date will be applied upon receiving a GPS connection.

The First Time Use menu is in place to get you up and running quickly and smoothly.Note:

The settings you choose during First Time Use can be changed at any later time in the setup menus.

See pages 20 and 21 for the First Time Use screens.

First Time Use - Screens

Options:

English (UK), English (US), Dansk, Deutsch, Espanol Francais, Italiano, Nederlands, Norsk, Suomi, Svenska

Select Time Zone

Select a Location to designate your Time Zone. Selecting Other allows you to choose a Time Zone manually.

EUR: UK & Ireland, Belgium, Denmark, Finland, France, Germany

Italy, Netherlands, Norway, Poland, Spain, Sweden.

USA: Eastern, Central, Mountain, Pacific, Alaska, Hawaii CAN: Newfoundland, Atlantic, Eastern, Central, Mountain, Pacific MEX: Eastern, Central, Mountain, Pacific

GMT / UTC

First Time Use - Screens

App Features

To enable Emergency SOS and more, you Dash Cam needs to be linked to your phone.

SKIP

Dash Cam will open Live View upon successful connection to App.

App Features

Install MyNextbase Connect

on your phone to begin.

GET IT ON

Google Play

nxtb.se/app

Connecting

Download on the

App Store

Google Play StoreiOS App Store

Dash Cam searching for phone...

Scan the QR Code (on iOS use your camera; for Android users, download a QR Scanner from the Play Store) or search: ‘MyNextbase Connect’ on the appropriate app store. Once the app is succesfully installed, press ‘OK’ to make the Dash Cam discoverable by your smart-phone. Use the ‘Connect Dash Cam’ feature in the app to pair your Dash Cam.

Menus

Press the ‘Menu’ button to enter the Dash Cam’s ‘Video Menu’ system.

Video Settings

MyNextbase

The default settings have been carefully selected to allow you to use your Dash Cam without the need to change any settings. However, should you wish to change a setting then please see below:

- Use the touch screen to select a settings submenu (Video Settings, Setup, Driver Assistance, Communications)

- Once in the submenu, use the touchscreen to select which function to change.

- When swiping through the menu pages, swipe from the middle of the screen, to avoid accidentally selecting a submenu/function.

Notes:

- Menus are not accessible whilst the Dash Cam is recording.

- Within the Setup Menu there is a ‘Default Settings’ option to allow you to reset the Dash Cam to the factory defaults, if required.

Menu Tree:

See below for the settings to be found under each submenu:

Video Settings:

- Resolution

- Exposure

- Video Length

- Audio

-Time Stamp

- Speed Stamp

- GPS Stamp

- Model Stamp

Dual Files Time lapse Number Plate G Sensor

Setup:

- Screen Saver

- Alerts

-Recording History

- Parking Mode

- Language

- Country

- Time Zone / DST

- Time & Date

- Speed Units

- Device Sounds

- Screen Dimming

- Auto Power Off

- Keep User Settings

- System Info

- Format SD Card

- Default Settings

Driver Assistance:

- Emergency SOS

- Reversing Camera

MyNextbase:

- Setup Phone

- Paired Devices

Resolution

Change your Dash Cam’s recording resolution

Options: 1080pP, 720P, 720P @ 60FPS Default: 1080p

Exposure

Adjust the exposure level for different lighting conditions.

Options: Values range from -6 to +6 Default: 0

Video Length

Set the length of the individual recorded video files. The Dash Cam will continue recording, filling the memory card. When the memory card becomes full, the oldest file will be automatically deleted to make space for the new recording. Note: Protected Files will never be deleted

Options: 1minute, 2 minutes, 3 minutes Default: 1 minute

Audio

Turn On/Off the microphone for video recording.

Options: On and Off Default: On

Time Stamp

Turn On/Off the time and date stamp shown on recorded files.

Options: On and Off Default: On

Speed Stamp

Turn On/Off the speed stamp shown on recorded files.

Options: On and Off Default: On

GPS Stamp

Turn On/Off the GPS stamp shown on recorded files.

Options: On and Off Default: On

Model Stamp

Turn On/Off the Dash Cam model stamp shown on recorded files.

Options: On and Off Default: On

Video Settings (cont.)

Dual Files

When recording, both a high and low quality video are saved. The smaller file size of the low quality video means it is quicker to transfer and edit within the app. If a Rear-Cam is attached, and Dual Files is switched ON, High and Low quality files will be saved for the Rear view as well, giving you a total of 4 files (Front High, Front Low, Rear High, Rear Low) Note: Recording both high and low quality versions will take up more space on the memory card.

Options: On and Off Default: On

Time Lapse

Turn on to record a time-lapse video of your journey. When Time Lapse is turned On, Recording History will be turned Off.

Options: 3 mins, 30 mins, Off Default: Off

Number Plate

Input your vehicle’s number plate to add a number plate stamp to your recordings.

Default: Off

G Sensor

Turn off or adjust the sensitivity of the internal G Sensor. The G Sensor detects forces which will protect the current recording in the event of a collision. The higher the G Sensor sensitivity, the less force will be needed to trigger automatic file protection.

Options: Off, Low, Medium, High Default: Medium

Setup Settings

Screen Saver

Turn on the screen saver function to shut down the screen after a chosen period of inactivity. You can also choose for the screensaver to show your current speed.

Options: On and Off and Speed Display Default: Off

Alerts

Turn On/Off the beeps that sound when a recording starts, when a recording ends, and when a file is protected.

Options: On and Off Default: Off

Recording History

In some territories, there are laws prohibiting the amount of footage your Dash Cam should hold. The default setting is ‘Maximum’, where your Dash Cam records and stores videos without restriction. If ‘Minimum’ is selected you will first be asked to Format (wipe) your SD Card; be sure to back up, or protect any files you wish to keep before doing this. If you choose not to Format the SD Card, no action is taken and the function will not be activated. Format SD Card will not affect protected files. Once the SD Card has been formatted, the file recording length will be automatically set to 1 minute. The Dash Cam will now be limited to storing only 4 unprotected files at any one time. When a new file is recorded it will overwrite the oldest file, keeping the number of stored files at the maximum of 4. As protected files (i.e. recordings of incidents) cannot be overwritten, these do not count towards the 4 file maximum, and are stored to the capacity of the SD Card. When Recording History is turned On, Time Lapse will be turned Off.

Options: Maximum and Minimum Default: Maximum

Parking Mode

When Parking Mode has been turned on, the Dash Cam enters standby mode when the 12Vdc supply has been turned OFF (typically removing your ignition key).

The Dash Cam will also enter standby mode if no physical movement is detected for 5 minutes, this is designed to allow use of a permanent 12Vdc supply, i.e hard-wire kit.

Should physical movement of the vehicle be detected, the Dash Cam will power on and start recording a 1-2 minute protected video. If no further physical movement is detected then the Dash Cam will return to standby mode, if physical movement is detected subsequently, then the camera will continue to record normally, i.e. driving once more.

Options: On and Off Default: Off

Setup Settings (cont.)

Language

Select your preferred language Options: English (UK), English (US) Danish, German, Spanish, French, Italian, Dutch, Norwegian, Finnish, Swedish

Default: Follows your First Time Use selection.

Country

Select your country to adjust your Dash Cam’s time display.

Options: EUR, USA, CAN, MEX, Other Default: Follows your First Time Use selection.

Time Zone/DST

Manually adjust your time zone to adjust your Dash Cam’s time display. Manually changing your time zone will change your Country setting to Other.

Options: -12 to +12 Default: GMT / UTC

Time & Date

Adjust the time & date as required. Press MENU to exit and return to the Setup Menu.

Time and date settings will be over-written upon satellite connection.Note:

Speed Units

Choose between MPH and KMH

Options: MPH and KMH Default: MPH

Device Sounds

Turn On/Off the beep that sounds when the touch panel is pressed. Start up sound is NOT muted.

Options: On and Off Default: On

Keep User Settings

Turn this ON in order to keep your preferred individual user settings during the Dash Cam firmware update process. Select OFF in order to clear all user settings and return them to defaults during the Dash Cam update process.

Options: On and Off Default Setting: On

System Info

Information such as Dash Cam model, Battery status, Firmware version, and SD card information can be found here. This information covers multiple screens (pages), swipe left or right on the display to scroll through as required.

Format SD Card

Format the inserted SD card. This will delete all content. If the format is unsuccessful, a message will appear on the display; “Format failed, please try another SD Card (Class 10 128GB Max).”

For stable performance, it is recommended that you format the SD card every 2-3 weeks.Note: You should only do this AFTER you've downloaded any ﬁles from the card that you may want to keep.

Default Settings

Resets the Dash Cam to default settings. Your recordings will not be affected.

Screen Dimming

The Dash Cam automatically adjusts the brightness of the display to match ambient light levels. This is to ensure that a bright screen is not a distraction while driving at night.

Options: On and Off Default: Off

Auto Power Off

While recording, if Auto Power Off is turned OFF and the Dash Cam loses power: the Dash cam will turn off after 10 seconds. While recording, if Auto Power Off is turned ON and the Dash Cam loses power: the Dash Cam will turn off after 30 seconds.

Options: On and Off Default: Off

Driver Assistance

Emergency SOS

See next page (page 26)

Reversing Camera

With a rear-facing camera connected (Rear View, Cabin View, Rear Window), tapping the Rear View Display on the screen will make it full screen (tap again to minimise). With the Reversing Camera function activated, when the Rear View Display is in full screen mode, the image will be flipped horizontally to mimic looking in a mirror, making it easier to reverse. Recordings made with Reversing Camera ON are not affected,

Objects may appear further away than they are in reality; always stay aware of yourNote:

surroundings while driving and do not rely exclusively on the Dash Cam while reversing.

Options: On and Off Default: Off

Driver Assistance - Emergency SOS

Driver Assistance

In order for this function to work, you must have the ‘MyNextbase Connect™’ app installed on your smart-phone (or similar device), have an internet connection, and have Bluetooth turned on. ‘MyNexbase Connect™’ can be downloaded from the Apple App Store® or Google Play®. Use the QR codes below, or search for ‘MyNextbase Connect™’ in the relevant store.

In the event of an incident

The camera immediately notifies the MyNextbase Connect app to begin monitoring key sensors in your smartphone such as GPS, accelerometers and the pedometer. The camera and app will notify you that it has begun monitoring your smartphone's sensors with on-screen messages and an alarm tone.

Should the accident render you unconscious and/or you are unable to cancel the on-screen emergency SOS countdown, the MyNextbase Connect app will automatically send a crash alert containing your GPS location, mobile number, medical details and vehicle information to the Emergency Services. If you are ok, you can deactivate the alert manually or respond to the follow-up call from an emergency services operator.

Emergency SOS

Your Nextbase™ Dash Camera and MyNextbase Connect App features life-saving crash detection and emergency alerting technology. It is designed to automatically and directly connect you to the nearest Ambulance Service in the event of an accident when you are unable to call for assistance.

If your dash camera detects a crash, the MyNextbase Connect app monitors key sensors in your phone. If you are unable to call for help, it will automatically send your last known GPS location, medical and vehicle details to the nearest Emergency Service within minutes of the crash.

Providing you have a valid subscription, you can drive with total peace of mind; safe in the knowledge that your phone is being monitored by this award-winning technology.

App

Once MyNextbase Connect is installed, you must set up

Apple App StoreGoogle Play Store

Emergency SOS with your personal and medical information. Follow the Emergency SOS setup menu in the app, filling out the information fields. This will include information such as your name, medical history, and any pre-existing conditions, Providing accurate medical and vehicle details helps emergency responders locate and treat you as quickly and appropriately as possible. You will also be asked to enter your mobile phone number, as this will be the number the emergency services will call in the event of an incident. When entering your phone number, be sure to enter it with your country dialling code (see below for examples):

GB FR ES NL NO FI SE DK DE IT US

+44 +33 +34 +31 +47 +358 +46 +45 +49 +39 +1

Once you enter your phone number you will be sent a verification code to enter. This will confirm that the phone you are using can be contacted by emergency services. If you do not receive a verification request, re-enter your phone number. Once you have entered all of your Emergency SOS information and are paired with the Dash Cam, the Dash Cam will automatically turn Emergency SOS ON.

Dash Cam Screen Icon

If Emergency SOS If it is turned ON and you have not set up your Emergency SOS information on the app, or it has disconnected, you will see a pop-up on your Dash Cam: “Emergency SOS Error. Please open MyNextbase Connect on your phone to reconnect”. Once turned ON, the Emergency SOS icon will appear on the Dash Cam’s Live view screen.

No Icon = Feature turned OFF = Flashing icon; establishing connection = Solid Icon; connected

If the alert does not get cancelled, Emergency Response operatorss will automatically begin the process of dispatching paramedics to your last known location.

If the crash detection technology within the camera is triggered inadvertently, the MyNextbase Connect app is designed to detect a range of vehicle and customer movements such as continued driving, walking around or moving the phone. It will automatically cancel the Emergency SOS process if movement is detected as we expect you can call the emergency services if medical assistance is required.

09:36

94%

116

115

During countdowns the screen on the Dash Cam will alternate

between red and black backgrounds

to be as noticeable as possible.

Press to cancel the countdown. On phone; “I’m Okay”, “I’m not Okay, ”.

Countdown; time remaining until emergency services are contacted.

1 21

Crash Detected

116

sec onds

I’m OK

Contact Emergency Services

A crash has been detected. The Emergency SOS system is monitoring your smartphone sensors for movement. If this is a ﬂase alarm, please tap the “I’m Okay” button.

When the countdown is cancelled, the Dash Cam and App will revert to normal usage mode. See page 27 for an additional overview of the Emergency SOS system.

Options: On and Off Default: Off

Please note that the emergency services response may differ from territory to territory, and not all territories are covered within this feature. If you are unsure, or would like further information, refer to the Emergency SOS FAQs on page 28 or contact our support team at support@nextbase.com

You can turn the Emergency SOS function ON or OFF in the Dash Cam’s Emergency SOS menu. Your information is stored on the app, and can be edited or deleted at any time.

Emergency SOS (cont.)

The below diagram illustrates how the user’s smart-phone and Dash Cam operate in the event of an incident.

Dash Cam

Crash Detected

High G-Sensor Activity (Crash)

registers on Dash Cam

10 second countdown

(waiting for crash to end)

30 second countdown

(Checking for

normal movement)

120 second countdown;

can be cancelled via

smart-phone or Dash Cam

“Contacting Emergency Services in

seconds remaining”

“Contacting Emergency Services”

message

Smart-Phone (app enabled

and set up)

Emergency SOS

Function Triggered

10 second countdown

(waiting for crash to end)

MyNextbase Connect™ app to

begin monitoring key sensors in

your smartphone such as GPS,

accelerometers and the pedometer

No movement

120 second countdown:

MyNextbase Connect app

continues monitoring key

sensors for movement.

Countdown NOT stopped by user; no movement

Countdown End

Countdown stopped by user

Movement Detected

- Normal Driving

- Phone Movement

- Walking movement

Emergency SOS

feedback

09:36

94%

Emergency Response Cancelled

We’re glad that you are OK, please help us to improve the service by letting us know what happened. If you still require medical attention, go to your app’s call function and dial 999/911/112.

I didn’t have an accident

Crash but OK

Something Else?

Back to App

Emergency SOS

Function Cancelled;

Will not contact

Emergency Services

Emergency SOS

Function Cancelled;

Will not contact

Emergency Services

“Expect Inbound Phone Call”

message

Emergency

Responders

sent to user’s

location.

SOS containing your Personal & Medical Information sent to

User Does Not Answer;

user is assumed to be

unconscious/unable to answer

Emergency Services

Phone Call

Received

Talk with Emergency Services to decide

whether further help is necessary

User Answers;

Emergency

Services

Emergency Services call user’s registered phone number

Emergency SOS

Function Ends

Emergency SOS Frequently Asked Questions

The below points are there to answer any further questions you might have about the Emergency SOS system.

Question Response

If I crash, will you notify the Police?

Can I set it off inadvertently?

What happens if I receive a call and don't need an ambulance?

What happens if I am out of mobile phone signal range?

What happens if the phone battery dies?

What testing and evaluation has the MyNextbase Connect™ App undergone?

No. The MyNextbase Connect™ app automatically sends your location, medical and vehicle details to the nearest Ambulance or Emergency Response Service only.

The Emergency SOS feature has a range of safeguards to ensure it won't alert the emergency services unless it has validated that assistance is required. This is tried and tested technology has been UK Government approved for connecting directly to the emergency services.

The Emergency SOS countdown gives you 150 seconds to deactivate the phone sensor monitoring process. Failure to deactivate will then result in a call from the Emergency Services operator. If you are ok you can simply cancel the process via the camera or app within 150 seconds or answer the emergency services call. If you do not manage to do either, simply press the ‘Contact Emergency Services' button and tell the operator that the crash detection feature sent an alert and that you missed the call back.

In the event of an accident, the MyNextbase Connect app requires a network connection and mobile signal. The network connection is needed to send a very small data packet (about 1.5kb) to the emergency services, and the mobile signal is required for the Emergency operator to call your phone. If there is no network coverage, then the MyNextbase Connect app cannot send the data.

If your phone's battery dies while the MyNextbase Connect app is monitoring your phone's key sensors, then this data can NOT be sent.

Due to the nature of the Emergency SOS feature and it's ability to connect directly to the Emergency Services, rigorous testing and evaluations are carried out on a regular basis. These include but are not limited to:

- Regular camera/app crash, processing and connectivity testing

- Confidence and accuracy testing

- Emergency Service integration and process testing

MyNextbase Connect™

MyNextbase

Setup Phone

MyNextbase

Paired Devices

In order for this function to work, you must have MyNextbase Connect™ installed on your smart-phone (or similar device), have an internet connection, and have Bluetooth turned on.

Within this menu, you will be able to manage your connected devices. You will be able to

MyNextbase

connect and set up new devices (as seen in

Setup Phone

your Dash Cam’s First Time Use), and manage

Paired Devices

devices which are already connected.

Setup Phone

Install the MyNextbase Connect App from the Google Play Store or the Apple App Store. Once installed, select ‘Connect to Dash Cam’ on the app. Once a connection is established, a confirmation message will appear on both devices. You may then proceed to use both your Dash Cam and smartphone as usual. Your paired device can be viewed on the ‘Paired Devices’ screen.

MyNextbase Connect

Install MyNextbase Connect

on your phone to begin.

GET IT ON

Google Play

nxtb.se/app

Download on the

App Store

Paired Devices

This screen shows you which smart-phones are currently linked to your Dash Cam. Here you can also unpair devices by pressing the cross (X) to the right of the device’s name.

Paired Devices

Bob’s Phone

Apple App StoreGoogle Play Store

This page describes the steps required to connect your Dash Cam to the MyNextbase Connect™ App. For more information about using the App, see page 34 (MyNextbase Connect™).

Video Mode

Folder Selection Screen

The key below explains the various information displayed on the screen when your Dash Cam is in Video mode, some icons will only be displayed once the relevant function has been selected within the Video menu, as described below.

Not Recording

3 7

Settings

Select to open the Dash Cam’s Menu system.

Playback

Select to view recorded videos (protected and unprotected) and photos.

Record

Select to Start recording.

Time & Date

Shows the current time and date. This can be edited in the Setup Menu.

Active Functions Bar

Audio Recording, Bluetooth, Wi-Fi, Emergency SOS, GPS connection, Parking Mode, Time Lapse. Icons displayed will be dependent on the functions activated in the Settings Menu.

Battery Status

Stop Recording (flashing)

During recording the record button will flash. Press to stop recording.

Recording Duration

While recording, this shows how long the Dash Cam has been recording for.

Screen Capture

While recording, tap the centre of the screen to take a photo. If a Rear Cam is attached, touch the centre of the Front Facing view to take a photo. This will save 2 photos, one from the Front Facing camera, and one from the Rear Facing camera.

Recording

When you select Playback Mode, you will have a choice of viewing your protected videos, you unprotected videos, or your photos.

Videos

Protected

Files

Photos

Playback Mode - Photo

Preview Mode

Preview Mode - On-screen icons timeout

Protect Icon

If present, the file is protected; if not present, the file is unprotected.

File Name

Back Button

Return to the Folder Selection Screen. (Protected Files, Unprotected Files, Photos)

Protect Button

Press this button to protect/unprotect the file you’re viewing.

Navigation

Use the forward and backward arrows to scroll through your photos.

Delete

Delete the current photo. If you try to delete a protected file you will see a pop-up telling you to unprotect the file first.

Note: The on-screen icons (navigation, delete,

protect, etc.) timeout after 5 seconds. Press the screen to bring up the icons.

Playback Mode - Video

The key below explains the various information displayed on the screen when your Dash Cam is in Playback Mode (Protected/Unprotected Video).

Preview Mode

Playback Mode - Video (cont.)

Video Playback

Video Playback - display timeout

Protect Icon

If present, the file is protected; if not present, the file is unprotected.

Recording Length

Shows the length of the current recording

File Name

Back button

Return to the top Playback Menu (Protected Files, Unprotected Files, Photos)

Protect Button

Press this button to protect/unprotect the file you’re viewing. You cannot protect/unprotect files during playback. Stop the video to protect/unprotect.

Play

Play the current video file.

Navigation

Use the forward and backward arrows to scroll through your videos.

Delete

Delete the current video file. If you try to delete a protected file you will see a pop-up telling you to unprotect the file first.

9 10

Video Paused

13 14

Video Slow Motion

During playback, the on-screen icons will disappear after 5 seconds. Tap the screen to bring up the controls.

Pause

Press to pause the video playback.

Fast Forward

Press during playback to scroll through x2, x4, x8, and x16 speed.

Rewind

Press during playback to scroll through x2, x4, x8, and x16 speed.

Stop

During playback/paused, press stop to return to Preview Screen.

Edit

While paused, press to edit the video. See next page for more details.

Slow Motion - Forward

While paused, press to play the video at 1/2 speed. Press pause or fast forward to return to normal speed.

Slow Motion - Rewind

While paused, press to rewind the video at 1/2 speed. Press pause or rewind to eturn to normal speed.

Playback Mode - Video Editing

The key below explains the various information displayed on the screen when your Dash Cam is in Playback Mode (Protected/Unprotected Video).

Edit Mode

1b 2b 2a3

Press Play to begin playback.

Trim Start (green)

Press to place Start Indicator on the timeline.

Trim Start Indicator

Start point of your new file.

Trim End (Red)

Press to place End Indicator on the timeline.

Trim End Indicator

End point of your new file.

Timeline and Position Indicator (White)

Shows your current position in the recording. When you reach the point where you want to start your new file, press Trim Start (1a). When you reach the point where you want to end your new file, press Trim End (2a). This will move the indicators (green/red)

Audio Recording

Toggle the audio ON/OFF.

Back

Pressing Back while editing will take you back to the video preview screen. If you were in the process of editing a video, it will not be saved.

Save

Press to save the video as a separate file that will appear in your file library. The original file is unaffected.

Playback. The white ball indicates your position.

Press Trim Start to move the Trim Start Indicator.

Continue Playback. The white ball indicates your position.

Directions

Once in Edit Mode, you will see a white timeline bar with a green indicator and red indicator at either end. A white ball indicates how far through playback of the current file you are. While paused, press the ‘Trim Start’ button (top left) to move the green indicator bar to the current point on the timeline. Once saved, anything before this point will be trimmed off. While paused, Press the ‘Trim End’ button (top right) to move the red indicator bar to the current point on the timeline. Once saved, anything after this point will be trimmed off. During playback, the editing controls are greyed out, and cannot be activated, pause to use the trim tools, remove audio, and save functions.

When moving the Start/End trim tools, make sure that the Green (start) indicator comes before theNote:

Red (end) indicator on the timeline. if the Red is placed before the Green, the save function will not work.

Press Trim End to move the Trim End Indicator. Press Save to export the new file. The new file will be saved the original file name + EDI (i.e. 180125_175618_009_FH_EDI). If you are editing a protected file, the new file will also be protected. The original file is unaffected.

Playback Mode - Protect & Delete

The key below explains the various information displayed on the screen when you are protecting and deleting files.

Preview Mode - Protect and Delete

1 2

Protect Button

Press this button to protect/unprotect the file you’re viewing.

Delete Button

Delete the current video file. If you try to delete a protected file you will see a pop-up telling you to unprotect the file.

Preview Mode - Protect

While in Preview Mode, press the Protect Button to protect/unprotect a file. When a file is protected, a red padlock icon will appear in the top left of the screen. You cannot protect or unprotect a video during playback.

When a file is protected/unprotected, it will remain in its original folder.Note:

Preview Mode - Delete

While in Preview mode, press the Delete Button to delete a file. If the file is protected, you will see a pop-up “File is protected. Unprotect to delete”.

MyNextbase Connect

MyNextbase Connect™ is an easy-to-use app that will enable you to effortlessly manage and share your videos. In addition to this, there are features on the ash Cam that can only be used in conjunction with the app; for example, the Emergency SOS function. Use the QR Codes below to download MyNextbase Connect App from the Apple App Store® or the Google Play Store®. Please note that the app is only compatible with Nextbase™ Dash Cam models 322GW and above (322GW, 422GW, and 522GW).

Apple App StoreGoogle Play Store

Features:

- Camera Live View: (see what your Dash Cam is seeing)

- Download files from your Dash Cam to your smartphone/mobile device

- Edit clips

- Share videos to popular social media platforms

- National Dash Cam Safety Portal

- Emergency SOS services (322GW, 422GW, & 522GW only)

- Check for and install Firmware Updates

- Contact Us details, including Live Chat

- FAQs

- Nextbase™ latest offers and deals

Connect to Dash Cam

In order to make use of the full range of features, you will need to pair your smart-phone with your Dash Cam. To do this, select ‘Connect Dash Cam’ on the Home Screen. You will need to allow the app to use Bluetooth in order to connect to the Dash Cam. Once you have turned on Bluetooth, the app will automatically begin searching for devices. Make sure your Dash Cam is powered ON and ready to pair the Dash Cam will appear as a device on the app screen. Simply select it to connect.

MyNextbase Connect

Home Screen

Dash Cam

Select to pair a new Dash Cam with your smart-phone, or view currently paired devices.

Amazon Alexa

This function is NOT available on 322GW.

Nextbase™ News

Click here to sign up for new Nextbase products, offers, and updates.

National Dash Cam Safety Portal

Upload a video of an incident directly to police services across the UK.

Home Button

Select to return to your home screen.

Connect Dash Cam

See videos that are stored on your connected Dash Cam.

Emergency SOS

Setup Emergency SOS on your Dash Cam. (see pages 26-28).

Video Library

Select to view files you have downloaded to the app (see image, above). If paired with your Dash Cam

Video Library

Monday 1st January 2019

10:01 01/01/2019

Woking, Surrey

180101010_101_001.MOV

11:50 01/01/2019

Woking, Surrey

180101010_101_001.MOV

12:35 01/01/2019

Woking, Surrey

180101010_101_001.MOV

12:39 01/01/2019

Woking, Surrey

180101010_101_001.MOV

15:00 01/01/2019

Woking, Surrey

180101010_101_001.MOV

15:12 01/01/2019

Woking, Surrey

Home Library Dash Cam

Video Library

94%

Emergency

09:36

SOS

you will be able to view and manage files on your Dash Cam. If NOT paired with your Dash Cam you will only be able to see files that you have transferred to your smart-phone. Various filters are available to make it easier for you to sort and find your files. From here, you can protect/unprotect videos, edit clips, and share files with you insurer or to social media.

Emergency SOS

In order for this function to work, you must have an internet connection, have Bluetooth turned on, be paired with your Dash Cam, and have your Emergency SOS information set up in MyNextbase Connect.

The Nextbase Emergency SOS feature is deigned to automatically contact the emergency services in your time of need, and send them to your last known location To set up this feature, select the menu button, and select ‘Emergency SOS’; you will then be prompted to enter personal and medical information that would help emergency responders locate and treat you as quickly and appropriately as possible.

Please note that this information is stored ONLY on your smart-phone; we will ONLY send it to emergency responders if the Emergency SOS system is triggered.

The first year of Emergency SOS cover is free, and chargeable thereafter. See for details.nextbase.com

See pages 26-28 for more information about Emergency SOS setup and usage.

Home Screen

Select to browse features, menus, and settings, including ‘Connect to Dash Cam’.

Dash Cam Live View

See a live feed direct from your Dash Cam.

MyNextbase Player - Playback Software

View, edit, and share your footage on your computer with the new easy to use free PC/Mac software. The software also allows you to view in-depth analysis of your journeys, including information on dates and times, speed, GPS location, and more. Connect your Dash Cam via USB (see ‘PC Connection’, page 38) or use an SD card reader (integrated or external). When you connect your Dash Cam, if MyNextbase Player™ is already open it will ask if you would like to import all files directly to your video library.

MyNextbase Player can be downloaded for free from the ‘Support and Downloads’ page at:

.www.nextbase.com

MyNextbase Player

00:00

Add Video

0 max

0 mph

0 miles

105

0 avg

Update Dash Cam Snapshot

For best performance please insert the memory card into the computer directly, or connect the camera using the supplid

USB cable and select Mass Storage. To watch recordings add them to the Playlist using the “Add Video” option or drag and

120

135

180

0º

150

north

0º 0º 0º N 0º 0º 0º E

165

Edit Video Share Video HelpSettings

drop them into the application.

X: 0 Y: 0 Z: 0

Add Video Remove

Save

00:00

ACCEL

RIGHT

LEFT

BRAKE

File List

Edit Video

Within the video editing process you can join multiple videos together, trim the clips, add annotations and titles screen, and alter output settings. See the next page (page 36) for more details.

Share Video

Allows you to easily share your Dash Cam videos with insurance companies and social media. See page 37 for details on MyNextbase Cloud™.

Settings

Opens the settings tab for MyNextbase Player. Options available include: language, speed units, software update options, map provider (Google Maps™ or Open Street Maps), connection tips, error reports, and Nextbase™ special offers.

Help

Opens the Help menu for MyNextbase Connect. Options available include: how to use, check for updates, Nextbase™ website, help & support, send diagnostics, register your Dash Cam, contact us, and about.

Playback Window

Displays Dash Cam videos playing in MyNextbase Connect.

Map

Displays your journey if the video playing has GPS data.

Zoom

Use to zoom in/out of the playback window. You can also use the scroll wheel on your mouse.

Speed Display

Shows the speed data for the currently playing video. Includes distance travelled, average and max speeds.

GPS Display

Shows the GPS data for the currently playing video. Includes co-ordinates and compass direction.

Video Timeline

Shows your playback position. Position the slider to move to a specific point in the video.

Add Video

Add a video to the file list, ready for you to view, edit, and share. Clicking this will open your default file explorer; your Dash Cam/SD Card will appear as an external device. Once located, select the file(s) you wish to import. You can also drag and drop your videos anywhere on the player to add videos.

Update Dash Cam

You can update your Dash Cam’s firmware through MyNextbase Player; please note that an internet connection is required to access the latest firmware version. For more information, see page 39 (Firmware Updates).

Snapshot

During video playback, pressing ‘Snapshot’ will Pause the video. You can move one frame at a time using the video controls beneath the playback timeline or the left/right arrow keys. Clicking ’Save Image’ in the dialogue box will save the image as a PNG in a destination of your choice .

Video Playback Controls

Use to control playback of your videos. Includes colour adjustment, next/previous video, next/previous frame, stop, play, pause, fullscreen.

G Sensor Timeline and Display

Shows the live G Sensor data for the currently playing video.

Volume Controls

Control the volume of the audio on the currently playing video.

File Management Bar

Add, remove, save, and filter videos in your file list.

File List

Displays your video library, ready for playback and editing. This list can be filtered in a number of ways, including by name, date, resolution, or whether the file is protected.

MyNextbase Player - Editing Videos

To use MyNextbase Player to edit your recorded files, you need to ensure that the file you wish to edit is™ currently playing in the Playback Window. You can do this by double clicking the file as it appears in the File List window. When the file is playing, click on the ‘Edit’ button to begin the 6 step editing process.

1. Join Videos (Optional)

The first step allows you to join multiple videos together. Please note that the videos you join together must all be the same resolution. Your video will appear in the centre of the screen, with buttons on either side to add additional videos before or after the chosen video file. Clicking either of these buttons will open up the list of files in your library that can be added. Once added, these will appear next to your original video file. The order of the video files can be altered by clicking and dragging a video. To remove a video, hover over the chosen file and a ‘Remove Video’ option will appear. Click to remove this video. Once you are happy with the video(s) selected, click on the continue button to move to step 2.

2. Trim Video

Trimming the video allows you to shorten your selected clip to only include the incident or event that you are interested in. To the left of the Playback Timeline is a green marker, indicating the beginning of your video. To the right of the Playback Timelime is a red marker, indicating the end of your video. These can be dragged to a point on the Timeline of your choosing; when exporting, MyNextbase Player will create a single video file from the footage located between the markers. The white marker indicates your current playback position.

3. Annotate Video (Optional)

During the video there may be an object or incident that you wish to highlight, annotating you video will allow you to do this. When you annotate a frame, your video will pause at the specified frame and display any annotations that you have added.

MyNextbase Player

Fill Colour

Stroke Colour

RectangleSquareCircleDrawDelete AnnotationSave and Close

Bring to Front

Bring Forwards

Bring Backwards

Send to Back

Text

Abc

The video will resume after 4 seconds.

To begin adding annotations, find the frame you wish to annotate (using the white marker, and left/right arrows to scroll through frames), and click

Annotation window

on the ‘Add Annotation’ button to open the annotation screen. Along the top of the annotation screen you will see the annotation tools; Draw, Circle, Square, Rectangle, and Text. Clicking any of these options will add an editable annotation to that frame. This shape/text can be moved, resized, and rotated using the handles on the sides and corners of the selected annotation.

5. Output Settings (Optional)

The ﬁnal step in the editing process allows you to specify the quality of your video ﬁle and the data included.

The Video Resolution determines the quality of the video footage; by default the Video Resolution will be set to output at the same quality as the original ﬁles. Lowering the Video Resolution will produce lower resolution ﬁles but will also reduce the size of the ﬁle and lower the time it takes to produce the ﬁle. Stamps for GPS, number plate, and time can also be removed, as well as the audio and GPS data from the video by ticking the corresponding box. Once the data has been removed it cannot be added back into the edited video. This will not aﬀect the original ﬁle.

Lastly, you can specify the name of the ﬁle being created and the location that you would like it saved. When you have chosen your output settings click on the ‘Conﬁrm’ button and MyNextbase Player will begin processing your video.

6. Process Video

During step 6, MyNextbase Player will process your video clip(s) and edits, and produce a single ﬁle in the location speciﬁed. This can take some time and will depend on the number and length of video ﬁles being joined and video resolution. Once the video has been processed, it will be added to your MyNextbase Player ﬁle list.

Video Sharing

Videos can be shared to social media and insurers through the ‘Share Video’ button. When a destination is selected (i.e Facebook), the target web page will open in your default browser. You will then be asked to sign into your account, and once you are logged in, the browser will close and a pop up will show your upload’s progress. When the ﬁle is ﬁnished uploading you will see an option to view your uploaded ﬁle. Videos can also be upload to the Nextbase server; you will be e-mailed a secure link to view or™ download your video. This link can be sent to your insurer, without the need to transfer a large video file. Videos will be automatically deleted 30 days after upload.

More Features

When a video is being played back in the Playback Window, press ‘Crtl + i’ to open a window displaying all of the metadata for that video including information such as: file name and size, resolution and frame rate, max and average speeds, GPS information, and more.

When you have finished your annotation, click ‘Save and Close’ to return to the Add Annotation screen, where more annotations can be added. When you have finished adding annotations, press ‘Continue’ to proceed.

4. Add Title Screen (Optional)

Add a title screen to your video. The title will be displayed for 4 seconds at the start of your video. To add a title, click inside the white rectangle and type the desired title. Press ‘Continue’ to proceed.

Some functions, such as GPS data, are available only on select models.

MyNextbase Cloud™

MyNextbase Cloud™ is our free online video sharing service where you can safely and securely store your Dash Cam files. Upload your file to the Nextbase™ Server using the ‘Share Video’ function on either MyNextbase Player™, or the MyNextbase Connect™ app. Please note that upload times are dependent on video file size. Once your video has finished uploading you will be given a secure link to watch your video online and/or download it to your computer/device. This link can be shared with others (including your insurer) to view/download the video. Videos will be automatically deleted 30 days after they are uploaded.

Nextbase Secure Server is a free online video sharing service for

owners of Nextbase Dash Cams. Once your video has ﬁnished

uploading you will be e-mailed a secure link to watch your video

online or download it to your computer. Videos will be automatically deleted 30 days after they are uploaded.

user1@youremail.co.uk

Remember my e-mail address

Continue

The upload window will guide you through the upload process; next, you will be prompted to enter your e-mail.

MyNextbase Player

Add Video

00:00

Update Dash Cam Snapshot

105

120

135

0 mph

0 avg

0 max

0 miles

180

Edit Video Share Video HelpSettings

For best performance please insert the memory card into the computer directly, or connect the camera using the supplid USB cable and select Mass Storage. To watch recordings add them to the Playlist using the “Add Video” option or drag and

0º

150

north

0º 0º 0º N 0º 0º 0º E

165

drop them into the application.

X: 0 Y: 0 Z: 0

Selecting ‘Share Video’ will allow you to choose where to upload your video to. Select ‘Share with Nextbase to upload your video to MyNextbase Cloud, and bring up the upload window.

Videos uploaded to the Nextbase Secure Server can be viewed

by anyone you share the link with.

For an additional layer of security you can protect your video

with a password which must then be shared with alongside

Add Video Remove

00:00

ACCEL

RIGHT

LEFT

BRAKE

Save

File List

the link.

Protect my video with a password

Continue

Uploading to Nextbase Secure Server...

84%

28.95 /

34.49 MB

Cancel

You will have the option to protect your video with a password.

Once the setup of the video has been decided, the upload will begin. Upload times are dependent on file size and internet speed.

When the upload has completed, you will be given a unique web address that will link to your video hosted on the

Upload Complete! You can now view your online or share it

with your insurer using the link below. Uploads will be

automatically deleted after 30 days, your video will expire on

http://myvideo.netbase.co.uk/6PUJG

01/01/2019

Nextbase server. This link can be shared with others (including your insurer) so that they too can view/download the video. When you first view the video online you may see this message: “This video was uploaded very recently, it may take up to half an

View on NextbaseCopy Link

Review us on

hour to generate the online preview however your video can be downloaded immediately.” This is normal and the

preview will become available within half an hour.

PC Connection

Use the supplied USB cable to connect the Dash Cam directly to your PC via the socket; do NOT connect the USB cable to the Powered Mount.

Once connected the Dash Cam will turn on with three options available; ‘Access Files’, ‘Power On’, and ‘Update Firmware’, as described below. Firmware Update information can be found on the next page.

Access Files (Windows)

When this option is selected, the Dash Cam will function as a card reader for your PC. An extra drive will appear, and you will be able to view / manage the stored files upon the MicroSD card within the Dash Cam. You will be able to view your files using MyNextbase Player™, a free editing and sharing software available to download from . The Dash Cam is a ‘read-only’ device, therefore uploading files towww.nextbase.com the SD card when in Access Files mode is not possible.

Access Files (Mac)

When this option is selected, the Dash Cam will function as a card reader for your MAC. The 'Nextbase’ external USB disk icon will appear on your MAC and you will be able to view and/or manage stored files. You will be able to view your files using MyNextbase Player, a free editing and sharing software available to download from .www.nextbase.com The Dash Cam is a ‘read-only’ device, therefore uploading files to the SD card when in Access Files mode is not possible. When the Dash Cam is connected to either a Windows or Mac system you will see a pop up on the Dash Cam that will read ‘Use MyNextbase Player to review, edit, save, and share recordings’.

Power On (Windows & Mac)

When this option is selected, the Dash Cam will power on with all functions available. This includes charging of the internal battery, a full charge will take approximately 2 hours.

ALWAYS turn OFF the Dash Cam before disconnecting from your PC/Mac.

Firmware Update Information

Firmware controls the basic functioning of the Dash Cam. If your Dash Cam is not functioning correctly, you may need to update your firmware.

Firmware updates may also be released to fix bugs, and improve the general functionality of the Dash Cam. In short, it’s important to keep the firmware on your Dash Cam up to date so it can operate to it’s full capacity.

How to Check your Dash Cam’s current Firmware Version

Within the Setup Menu, on page 4, select ‘System Info’. Here you will find information relating to your Dash Cam, including what firmware version is currently active (i.e R05.3)

Ways to Update Firmware on your Dash Cam

There are a number of ways for you to update your firmware version.

- Connect your Dash Cam’s SD Card to PC or Mac using a card reader. This will open a file explorer drive, and show the contents of your SD Card. Go to the ‘Support & Downloads’ page on nextbase.com and download the newest firmware version (i.e R05.4); this will download as a .bin file. Drag and drop the .bin file to the SD Card. Eject the SD Card and insert it back into your Dash Cam. When power is supplied to your Dash Cam it will turn on, and will automatically begin updating. While updating, the red LED to the left of the screen will start flashing. Once the update has been completed your Dash Cam will automatically restart.

- If you have a PC, You can also update your Dash Cam using the ‘Update Dash Cam’ function on MyNextbase Player™. This function will NOT work on a Mac. Connect your Dash Cam to PC via USB, select ‘Firmware Update’ and open up MyNextbase Player™ (available to download for free from nextbase.com). Select ‘Update Dash Cam’. A pop-up will appear on your PC describing your current firmware, and the latest version available. When you select ‘Update’, your Dash Cam will automatically begin updating. While the Dash Cam is updating, the red LED will flash. Once the update has been completed your Dash Cam will automatically restart. Please note that an internet connection is required for the Dash Cam to be updated.

If ‘Keep User Settings’ is turned ON in the Setup Menu, your Dash Cam will boot up normally,Notes: straight into video live view mode, ready to use. If ‘Keep User Settings’ is turned OFF, after the update is complete, the Dash Cam will boot up into the First Time Use menu, which must be completed before the Dash Cam can be used. Files saved on the SD card will not be affected by the firmware update.

TV Connection

The Dash Cam can be connected to external video equipment such as a television or monitor to allow you to view your videos on a larger screen. You can connect your Dash Cam to any television or monitor using an HD-Out cable. Please note that not all televisions/monitors will be compatible with your Dash Cam.

Connect the HD-Out cable (available from your nearest retailer) between the Dash Cam and your external device (see diagram below), then turn on the Dash Cam. The screen on the Dash Cam will be blank as the video image is now being sent to the external device, the red power LED on the Dash Cam will be lit indicating the unit is turned on. You can then proceed to use the Dash Cam as you would normally.

Make sure that the Dash Cam battery is charged prior to use, as power is not supplied to the Dash Cam via the HD-Out cable.

For prolonged use, an external power supply may be required; use the supplied USB cable with a 5Vdc/USB adaptor, of the type typically supplied with mobile phones.

ENSURE that any external power sources are of the correct 5Vdc output, otherwise damageNote:

will be caused that is not covered under the manufacturer’s warranty.

HDMI

Nextbase SD Cards™

CE Mark Information (Conformité Europénne)

For best results, we recommend using our Nextbase branded SD cards with your Dash Cam, available™ to purchase online from , or your nearest retailer.nextbase.com

32GB

Approx 4 hours footage.

We recommend formatting your SD Card every 2 weeks to ensure that there is enough space to record and store new footage. When formatting, protected files WILL be deleted. If you wish to keep these protected files, you must back then up externally, most commonly by saving files to a desktop computer, or another secure storage point. To clear your SD card, go to the ‘Format SD Card’ function in your Dash Cam’s Setup settings Menu and follow the instructions on screen.

64GB

Approx 8 hours footage.

128GB

Approx 16 hours footage.

The CE (Conformité Européenne) mark is a symbol (below) printed on products to indicates it’s conformity with health, safety, and environmental protection standards for products sold within Europe. It is used on many products across many industries (for example, SD cards) as a mark of compliance with European standards.

In recent years, many variations of this mark have appeared in the market. While similar, the mark above is the only variant that is associated with, and declares compliance with European standards. Other marks, like the ones below, do not guarantee that the product it is attached to or is compliant with European standards for sale in the European Economic Area (EEA).

The main difference between a legitimate CE mark and an misused CE mark is the spacing of the letters. The letters, C and E, tend to be formed identically, however the spacing between them is what separates the real from the false. The images below show how the letters should be spaced. There will never be additional markings such as a border or circle used on a legitimate CE Mark.

CE Mark False CE Mark

As products without the correct CE marking are not guaranteed to comply with European Health and Safety standards, those products are potentially less reliable and could pose a safety risk. Be aware of the CE marking when purchasing electrical products. The descriptions above of false CE markings are not comprehensive; be aware that new variations may appear on the market.

False CE Mark

(too close)

(too far)

Frequently Asked Questions

Problem Solution

Video Image is blurred.

I cannot insert the MicroSD card.

I cannot remove the MicroSD card.

Video Files cannot be played on my computer.

Video File playback is jumpy.

The sound is not synchronised with video during playback.

Video has no sound.

Photograph is blurred.

I can only record a few minutes of video on my MicroSD card.

Access Files does not work.

I cannot save files to the memory card when the Dash Cam is connected to my computer under ‘Access Files’.

The sucker will not stay in place upon my windshield.

Remove the protective lens cover, clean the lens, make sure the windshield is clean and clear of grease, dirt, and debris. Ensure that the Polarising Filter has been set properly if you have one attached.

MicroSD cards are very small and require delicate use. Align the card with the diagram shown upon the Dash Cam and insert the card until you feel a slight spring resistance. You now need to push the card, using your finger nail until you hear and feel a small click. Release pressure and the card will stay retained within the Dash Cam. If you are having difficulty, use the edge of a small coin.

With the card installed, using your fingernail, you now need to push the card further inwards slightly, until you hear and feel a small click. If you are having difficulty, use the edge of a small coin. Release pressure and the MicroSD card will spring out far enough for you to take a hold of it.

The video files from the Dash Cam are in .MP4 format and may not be compatible with your PC if suitable playback software is not installed.

Remove the SD card and format to remove non-contiguous files. For best recording use a branded class 10 type (48MB/s), U3, or UHS type 1 micro SD card of 8 to 128GB recommended size. PC may not be sufficient for the playback task, try a different PC. Copy the recorded video files onto the PC / Mac for playback directly rather than use the Dash Cam as a card reader, as the USB system on your PC may be too slow for HD video playback.

The Codecs upon your PC may not be compatible or the latest standard. Download the latest Codecs from: .www.nextbase.com

Ensure that ‘Audio’ setting is turned ON within the Video Menu.

Make sure the Dash Cam is still while taking the photo. The Dash Cam has a minimum focal range of around 2 meters. objects closer than this are likely to become blurred,

Change the recording size (Video Length function) to a smaller size. Increase the size of the MicroSD card. Max 128GB. In the Setup Menu, ensure that Recording History is set to Maximum. Minimum limits the total number of recordings on your Dash Cam to 4.

The Access Files function will work on both Windows and Mac. Restart the PC, as this may be required for the necessary driver to be loaded correctly. Disconnect and reconnect the Dash Cam. Be aware that you cannot transfer files to the Dash Cam in ‘Access Files’. Files can be transferred to the SD Card using an SD Card reader.

Correct, the Dash Cam is a ‘read-only’ device. It is not recommenced to save files from other sources to the same memory that you will use for recording within the Dash Cam, as these may have a negative effect on the performance of the Dash Cam.

Ensure that the protective cover (plastic film) has been removed from the suction pad. Moisten the sucker slightly before affixing upon the windshield. Ensure that the locking lever is fully closed. Make sure that the glass is smooth and clean. Do not stick to glass that has any non-smooth effect or paint whatsoever. Affix to the glass firmly and then close the locking lever fully.

My Dash Cam shuts down by itself after a while.

No power to my Dash Cam but it works upon my computer.

I can’t delete files on my SD card within the Dash Cam. Check to see if these files are ‘protected’. If so please follow instructions to ‘un-protect’.

www.nextbase.com support@nextbase.com

Either the battery has gone flat, there is no power to the Dash Cam and the Auto Power Off period has been triggered or Parking Mode has been turned on and no vehicle movement has been detected for 5 minutes.

The cigarette power cable is not working. Inspect the fuse in the Car Power Cable plug. Replacement fuse = 2A 32mm type. If the fuse is found to be blown, inspect the power cable for damage which may have caused the fuse to blow.

Frequently Asked Questions (page 2)

Problem

The screen blanks after a few minutes upon my Dash Cam. The screen saver is set to ON. Change settings to OFF if required. Default setting is OFF.

I get the message: “Cluster size wrong. Please format SD card” on screen.

The battery will not charge.

The battery only lasts 30 seconds.

The battery only lasts 6 minutes.

I get the message “Card Error” on screen.

I get the message “Card Full” on screen.

When connected to a TV/monitor via HDMI cable, there is no image on the TV/monitor.

I have turned on ‘Parking Mode’ and now can’t stop the recording.

When I press the Menu button nothing happens.

Downloading files from www.nextbase.com using Google Chrome results in a Malicious Software message.

There’s no Mass Storage option when connected to my computer.

Unresolved Issues

Solution

The SD card has been formatted in another device and the Cluster size is not compatible. Use the Setup option to re-format the SD card from within the SD card.

Ensure the Dash Cam is connected to a reliable power source and that the supplied Car Power Cable is being used, with the blue LED lit.

The battery will only receive charge when the Dash Cam is connected to a power source.

Charging takes approximately 2 hours and a full charge is indicated when the blue LED on the Dash Cam goes out. To charge, take the camera indoors and charge it for 2 hours; once fully charged, check to see if the problem persists. If it persists, the car power supply may be causing the issue.

This is normal, the battery design allows the 'Auto Power Off' feature to function in event of power loss within the vehicle. It is not intended as an alternative power source to replace the supplied car adaptor.

The SD card has become unusable by the Dash Cam. Back up useful files to your PC and then Format your SD card from within the Dash Cam setup menu.

The SD card has become full as there are too many protected files which cannot be deleted to allow for further recording to take place. Transfer useful files to your PC and delete unnecessary files, or Format the SD card from within the Dash Cam setup menu.

The Dash Cam is not compatible with all TVs and monitors. Ensure that all connections are correctly attached.

The Dash Cam will start a recording whenever motion is detected. To turn off Parking Mode firstly shutdown the Dash Cam and remove the SD card, this will avoid recording being activated accidentally. Switch the Dash Cam On and within the Setup Menu, turn off the 'Parking Mode'.

This is normal during recording. Stop the recording before pressing the MENU button. If recording re-starts before you can press MENU, then see the Parking Mode section above.

This is not a cause for concern, as this message will appear whenever new software is downloaded from the internet. Simply go to the settings within Google Chrome and turn off the malicious software protection temporarily to download and install the playback software. Reinstate previous Google Chrome settings afterwards.

Try multiple USB ports and an alternative mini USB cable (if possible). Please ensure it is inserted into the USB port on the Dash Cam and not into the mount.

It is normal for the camera to feel warm during typical use, especially when it’s recording high definition video or communicating via Wi-Fi.My Camera feels warm when it is operating.

Reset the Dash Cam to the default settings within the Setup Menu and try again. Should the problem persist call the UK helpline (02920) 866429 or call your local support centre, found at www.nextbase.com Alternatively email: support@nextbase.com

www.nextbase.com support@nextbase.com

Software License Agreement

By using the device, you agree to be bound by the terms and conditions of the following software licence agreement.

Nextbase™ grants to you for the period for which you possess the relevant device a non-exclusive, non-transferrable (save in circumstances where you sell or transfer the relevant device to another person – please see below for more details) a limited license to use the software embedded in this device (the “Software”) in binary executable form in the normal operation of the product together with any documentation and material (whether printed or on-line) made available by Nextbase in respect of the Software (the “Documentation”). Title, ownership rights, and intellectual property rights in and to the Software and the Documentation remain in Nextbase and/or its third-party providers.

You acknowledge that the Software and the documentation is the property of Nextbase and/or its third-party providers and is protected throughout the world by intellectual property rights laws and treaties, including the United States of America and international copyright treaties.

You further acknowledge that the structure, organization, and code of the Software, for which source code is not provided, are valuable trade secrets of Nextbase and/or its third-party providers and that the Software in source code form remains a valuable trade secret of Nextbase and/or its third-party providers. You agree not to decompile, disassemble, modify, reverse assemble, reverse engineer, or reduce to human readable form the Software or any part thereof or create any derivative works based on the Software or the Documentation.

You agree not to copy, rent, lease, sub-license, loan, translate, merge, adapt, vary, alter or modify, the whole or any part of the Software or Documentation nor permit the Software or any part of it to be combined with, or become incorporated in, any other programs

You agree not to export or re-export the Software or Documentation to any country in violation of the export control laws of the United States of America or the export control laws of any other applicable country.

If you use MyNextbase Connect™ or MyNextbase Player™, you must comply with the applicable terms of use and acceptable use policies, which can be found at www.Nextbase.com.

Warranty

Warranty (cont.)

Limited Warranty

This limited warranty gives you specific legal rights, and you may have other legal rights, which vary from state to state (or by country or province). Nextbase™ does not exclude, limit or suspend other legal rights you may have under the laws of your state (or country or province). For a full understanding of your rights you should consult the laws of your state, country or province.

Nextbase Liability extends to the cost of the Dash Cam alone. Any recordings which have not taken place or recoverable from the SD card for whatever reason are not covered by the product warranty. No liability for costs incurred due to corrupt, missing, erased video recordings will be accepted. No claims for additional costs outside the cost of the Dash Cam itself will be accepted.

Nextbase products are warranted to be free from defects in materials or workmanship for one year from the date of purchase, with batteries warranted to be free from defects in materials or workmanship for six months from the date of purchase. Within this period, Nextbase will, at its sole option, repair or replace any components that fail in normal use. Such repairs or replacement will be made at no charge to the customer for parts or labour, provided that the customer shall be responsible for any transportation cost. This Limited Warranty does not apply to: (i) cosmetic damage, such as scratches, nicks and dents; (ii) consumable parts, such as batteries, unless product damage has occurred due to a defect in materials or workmanship; (iii) damage caused by accident, abuse, misuse, water, flood, fire, or other acts of nature or external causes; (iv) damage caused by service performed by anyone who is not an authorised service provider of Nextbase; (v) damage to a product that has been modified or altered without the written permission of Nextbase, or (vi) damage to a product that has been connected to power and/or data cables that are not supplied by Nextbase, or (vii) damage to a product that has been connected to 12Vdc directly, having cut off the Cigarette Lighter plug which contains the 12/24Vdc to 5Vdc adaptor. In addition, Nextbase reserves the light to refuse warranty claims against products or services that are obtained and/or used in contravention of the laws of any country.

exclusive remedy for any breach of warranty. Repaired or replaced devices have a 30 day warranty. If the unit sent in is still under its original warranty, then the new warranty is 30 days or to the end of the original 1 year warranty, whichever is longer.

Before seeking warranty service, please access and review the online help resources available on

. If your device is still not functioning properly after making use of these www.nextbase.com resources, contact a Nextbase Authorised service facility in the original country of purchase or follow the instructions on support at to obtain warranty service. www.nextbase.com

If you seek warranty service outside of the original country of purchase, Nextbase cannot guarantee that the parts and products needed to repair or replace your product will be available due to differences in product offerings and applicable standards, laws and regulations. In that case, Nextbase may, in its sole discretion and subject to applicable laws, repair or replace your product with comparable Nextbase products and parts, or require you to ship your product to a Nextbase Authorised service facility in the country of original purchase or to a Nextbase Authorised service facility in another country that can service your product, in which case you will be responsible for complying with all applicable import and export laws and regulations and for paying all custom duties, V.A.T., shipping fees and other associated taxes and charges. In some cases, Nextbase and its dealers may be unable to service your product in a country outside of the original country of purchase or return a repaired or replaced product to you in that country due to applicable standards, laws or regulations in that country.

Online Auction Purchases of Non-New Goods

To the maximum extent permitted by applicable law, the warranties and remedies contained in this limited warranty are exclusive and in lieu of, and Nextbase expressly disclaims, all other warranties and remedies, whether express, implied, statutory, or otherwise, including without limitation any implied warranty of merchantability or fitness for a particular purpose, statutory remedy or otherwise. This limited warranty gives you specific legal rights, and you may have other legal rights, which vary from state to state and from country to country. If implied warranties cannot be disclaimed under the laws of your state or country, then such warranties are limited in duration to the duration of this limited warranty. Some states (and countries and provinces) do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

In no event shall Nextbase be liable in a claim for breach of warranty for any incidental, special, indirect or consequential damages, whether resulting from the use, misuse or inability to use this product or from defects in the product. Some states (and countries and provinces) do not allow the exclusion of incidental or consequential damages, so the above limitations may not apply to you.

If during the warranty period you submit a claim for warranty service in accordance with this Limited Warranty, then Nextbase will, at its option: (i) repair the device using new parts or previously used parts that satisfy Nextbase's quality standards, (ii) replace the device with a new device or a refurbished device that meets Nextbase's quality standards. Such remedy shall be your sole and

Products purchased through online auctions are not eligible for Nextbase warranty coverage. Online auction confirmations are not accepted for warranty verification. To obtain warranty service, an original or copy of the sales receipt from the original retailer is required. Nextbase will not replace missing components from any package purchased through an online auction.

International Purchases

A separate warranty may be provided by international distributors for devices purchased outside the United Kingdom depending on the country. If applicable, this warranty is provided by the local in-country distributor and this distributor provides local service for your device. Distributor warranties are only valid in the area of intended distribution.

More Nextbase Products™

Dash Cams

Eyes on the Road

Nextbase™ offers a wide range of Dash Cams to best suit your driving needs.

Rear View Cameras

Ready for the Drive

The new Rear Facing Camera, Cabin View Camera, and Rear Window Camera offer views of the road behind as well as ahead, protecting you from all angles.

Accessories

Ready for the Drive

Everything you might need for video storage, Dash Cam protection, and more.

Nextbase™ Services and Software

MyNextbase.com Cloud™

Access your footage anywhere in the world using the free online web portal (internet connection required)

MyNextbase Connect™

The new Nextbase App to transfer, view, and edit footage on your smart-phone or tablet.

Dash Cam Services Compatibility

MyNextbase Cloud™ MyNextbase Connect™ MyNextbase Player™

MyNextbase Player™

View, edit, and share your footage on your computer with the new easy to use free PC/Mac software.

For more details on our full range of Dash Cams and Accessories, download the Nextbase™ Accessories Manual, available from www.nextbase.com

Dash Cam Functions

Nextbase™ Emergency

Response

Nextbase™ Module Cam Compatible

(Rear Cam, Rear Facing Cam)

Nextbase Cloud™ Storage

MyNextbase Player™

MyNextbase Connect™

NBDVR322GW-ENG-R3

NEXTBASE NBDVR322GW User Manual [nl]

Specifications and Main Features

Frequently Asked Questions

User Manual
