NextBase 622GW User Manual

User Manual

Introduction to your Dash Cam

This range of Nextbase™ Dash Cams has been designed specifically with ease of use in mind; it is recommended NOT to change the default settings, which have been carefully selected to give the best performance for day to day use.

Please check the firmware version of the Dash Cam, the version can be found in the Setup menu under System Info. The latest versions are available to download from our website, where you can download and update when necessary.

www.nextbase.com

First Time Use

Before you can use your Dash Cam, it is essential to make sure it is fully charged. Connect your Dash Cam via the USB port to a home power source such as a PC or home USB socket for approximately 2 hours.

Basic Operation

A U3 type Micro SD card is required to use this Dash Cam. This is due to the very large data rate generated by high resolution recording. For best results, we recommend using our Nextbase branded SD cards with your Dash Cam. For use with Rear Cam attached, a U3 Card is required. Your Nextbase Dash Cam is set to record video, in ﬁles of just 1 minute in length. This means that each video ﬁle is a manageable size should you need to download and send to your insurance company. Eventually your MicroSD card will ﬁll up with video ﬁles but don't worry, the camera automatically deletes the oldest ﬁle to make space for new recordings. This way you never run out of space and have plenty of driving data saved.

1. Tips for capturing best video footage:

1.1 Position the Dash Cam in the centre of the windscreen and ideally behind the rear view mirror so it is not a distraction to the driver.

1.2 Ensure that the area on the windscreen that the Dash Cam is looking through is clear of dirt and is within the wiper zone. This will ensure that your videos are as clear as possible.

1.3 Reduce the amount of sky in the picture, by angling the view of the camera towards the road. Too much sky will make the road appear darker due to the automatic exposure compensation.

1.4 Remove unnecessary items from your dashboard. If objects are placed on your dashboard these can cause reﬂections to be seen on the windscreen and these reﬂections may be captured during recording.

2. Tips for stable memory card performance:

2.1 Periodically format the memory card. Every 2-3 weeks we recommend that you format the memory card. This will wipe any ﬁles from the card and set it up afresh for continued use with your Dash Cam. Of course, you should only do this AFTER you've downloaded any ﬁles from the card that you may want to keep, as formatting the card will remove all content.

2.2 Format your memory card using the Dash Cam. This will make sure that the card is structured specifically for your camera. Within the Setup menu, select ‘Format SD Card’ and follow the on-screen instructions.

Typically a 16Gb card will store the last 45 minutes of driving footage.

The GPS will automatically adjust for Daylight Savings Time.

Automatic Start / Stop Technology

The Dash Cam will automatically power on and be ready to use once power is available. In some vehicles this will be when connections are made, for others the Dash Cam will power on once the ignition has been turned on. When power is cut off, the Dash Cam will perform an automatic shutdown process.

2.3 Switch off the Dash Cam before removing the SD card, to prevent the chance of damage being caused to the memory card or the ﬁles stored upon it.

Nextbase SD Cards

For best results, we strongly recommend using our Nextbase branded SD cards with your Dash Cam, available to purchase online from nextbase.com, or your nearest retailer. A card that is not made specifically for a Dash Cam may appear to work perfectly in the beginning, although failure tends to happen after prolonged use, this could be days, weeks, or months. In a worst-case scenario, you may only discover recording failure after your SD card fails to record a serious incident, therefore using a suitable SD card is imperative. See page 45 for more information on Nextbase SD cards.

Table of Contents

INTRODUCTION TO USING YOUR DASH CAM

TABLE OF CONTENTS

PRECAUTIONS / CAUTIONS ON USING THIS PRODUCT

PRODUCT WARNINGS

USAGE PRECAUTIONS / NOTICES / CANADA COMPLIANCE

FCC STATEMENT / FCC IDENTIFIER

FCC- SUPPLIER’S DECLARATION OF CONFORMITY

DECLARATION OF CONFORMITY / PRODUCT SPECIFICATION

PACKAGE CONTENTS

PRODUCT FEATURES

CAMERA PARTS & CONTROLS

IN VEHICLE INSTALLATION

POSITIONING YOUR DASH CAM / ACCESSORIES

POLARISING FILTER

12 - 13

14 - 17

EMERGENCY SOS - FLOW DIAGRAM

EMERGENCY SOS FREQUENTLY ASKED QUESTIONS

CONNECT APPS (MYNEXTBASE CONNECT™ & ALEXA BUILT-IN)

VIDEO MODE / FOLDER SELECTION / PHOTO

PLAYBACK MODE - VIDEO

PLAYBACK MODE - VIDEO EDITING

PLAYBACK MODE - PROTECT & DELETE

MYNEXTBASE CONNECT

MYNEXTBASE PLAYER™ - OVERVIEW

MYNEXTBASE PLAYER™ - EDITING

MYNEXTBASE CLOUD™

ALEXA BUILT-IN

WHAT3WORDS™

PC CONNECTION

CHANGING MOUNT ATTACHMENTS

FIRST TIME USE

FIRST TIME USE - SCREENS

MENUS / VIDEO SETTINGS

VIDEO SETTINGS (CONT.)

SETUP SETTINGS

SETUP SETTINGS (CONT.) / DRIVER ASSISTANCE

DRIVER ASSISTANCE (EMERGENCY SOS)

22 - 23

FIRMWARE UPDATE INFORMATION

TV CONNECTION

NEXTBASE™ SD CARDS

FREQUENTLY ASKED QUESTIONS

CE MARK INFORMATION / SOFTWARE LICENSE AGREEMENT

WARRANTY / ONLINE & INTERNATIONAL PURCHASES

MORE NEXTBASE PRODUCTS / SERVICES / SOFTWARE

DASH CAM RANGE FUNCTIONS

46 - 47

Precautions

Cautions on Using this Product

Please read this manual carefully before operation and keep it for future reference. It will be helpful should you encounter any operational problems.

WARNING:

CAUTION:

LCD:

WEEE:

CHOKING

HAZARD:

Do not expose this product to rain, moisture or water under any circumstances, doing so may result in the risk of electric shock or fire.

To reduce the risk of electric shock, do not perform any servicing other than that contained in the instruction manual unless you are qualified to do so. Have the unit serviced by a qualified service technician if; The unit has been exposed to rain or water. The unit does not seem to operate normally. The unit exhibits a marked change in performance.

A Liquid Crystal Display (LCD) screen is a multilayer complex component, containing 1,229,760 pixels. Pixels can however fail during normal product life. 1 pixel = 0.0000008% failure rate, and one pixel failure per year of operation is considered normal and not a cause for concern.

Disposal of Waste Electrical and Electronic Equipment and/or Batteries by users in private households in the European Union. This symbol on the product or on the packaging indicates that this cannot be disposed of as household waste. You must dispose of your waste equipment and/or battery by handing it over to the applicable take-back scheme for the recycling of electronic equipment and/or batteries. For more information please contact your local household waste disposal office.

Some Products may contain components that are small enough to be swallowed. Please keep out of reach of children.

1. Ensure that the windscreen is free of dirt or grease before placing mount upon it.

2. Do not obscure the view of the road ahead or impede the deployment of any airbags in the event

of an accident.

3. When not in use, please disconnect the car adaptor from both the 12/24Vdc outlet in your vehicle and the device itself.

4. Only clean the device with a soft dry cloth, for tough dirt, apply some neutral detergent diluted in 5 to 6 parts water to a soft cloth. Please note that alcohol, thinner, benzene etc could cause damage to the paint or coatings.

5. Avoid making contact with the lenses as damage may be caused.

6. If required clean the glass lens carefully using spectacle lens cleaning fluid on a soft cloth only.

7. The video recordings made by this Dash Cam are intended for personal use only.

8. Publication of the recordings on Youtube, the internet or other methods are subject to the

Data Protection Act and the requirements thereof must be adhered to. If the Dash Cam is to be used within a commercial environment, i.e. truck use, then the CCTV regulation apply also, in addition to the Protection Act regulations. This includes labelling to identify the use of CCTV is taking place, the omission of Audio recording and informing the relevant authorities of who controls the data.

9. Video playback upon the device which is visible to the driver is prohibited or restricted in some countries or States. Please adhere to these laws.

10. Whilst driving, do not adjust the controls of your device as this is a distraction to driving.

11. Before using the device on your windscreen, check the state and local laws and ordinances where

you drive. Some laws prohibit or restrict the placement of objects on the windscreen of a motor vehicle. IT IS THE USER'S RESPONSIBILITY TO MOUNT THE DEVICE IN COMPLIANCE WITH ALL APPLICABLE LAWS AND ORDINANCES. Always mount your Nextbase device in a location that does not obstruct the driver's view of™ the road. Nextbase does not assume any responsibility for any fines, penalties, or damages of your Nextbase device. Nextbase accepts no responsibility for any damage or injury caused when the dash cam is in use.

12. Before you can use your Dash Cam, it is essential to make sure it is fully charged. Connect your Dash Cam via the USB port to a home power source such as a PC or home USB socket for approximately 2 hours.

Distractions can lead to accidents, and the risk of injury or death. Always keep your eyes on the road, and keep aware of your surroundings.

Product Warnings

Failure to heed the following warnings could result in an accident or collision resulting in death or serious injury.

Distraction Warning

This device is intended to enhance the situational awareness when used properly. If used improperly, you could become distracted by the display, which could lead to an accident causing serious personal injury or death. DO NOT seek to access the information stored on the device or change the device settings whilst driving. Information stored on the device should be reviewed only when your vehicle is stationary, and you are parked in a safe place in compliance with local laws. The device settings should only be changed when your vehicle is stationary, and you are parked in a safe place in compliance with local laws. Always maintain awareness of your surroundings and do not stare at the display or become distracted by the display. Focusing on the display could cause you to miss obstacles or hazards. Use the device at your own risk.

Video playback upon devices with display which are visible to the driver, is prohibited or restricted in some Countries or States. Please adhere to these laws.

Vehicle Installation Warnings

When installing the device in a vehicle, do not place the device where it obstructs the driver's view of the road or interferes with vehicle operating controls, such as the steering wheel, foot pedals, or transmission levers. Do not place unsecured on the vehicle dashboard. Do not place the device in front of or above any airbag.

Battery Warnings

Lithium-ion batteries are used in most Nextbase™ devices. If these guidelines are not followed, batteries may experience a shortened life span or may present a risk of damage to the device, fire, chemical burn, electrolyte leak, and/or injury.

- Do not disassemble, modify, remanufacture, puncture, or damage the device or batteries.

- Do not remove or attempt to remove the non-user replaceable battery.

- Do not expose the device to fire, explosion, or other hazard.

- Do not expose the device to rain or water.

Magnet Warnings

Both the Dash Cam and its mount may contain magnets. Under certain circumstances, magnets may cause interference with some internal medical devices, including pacemakers and insulin pumps. Devices and mounts that contain magnets should be kept away from such medical devices. Magnets may cause damage to some electronic devices, including hard drives in laptop computers and bank / credit or membership cards. Use caution when devices and mounts that contain magnets are near electronic devices or bank / credit or membership cards.

Usage Precautions

Notices

Failure to heed the following precautions could result in personal injury or property damage, or negatively impact the device functionality.

Battery Precaution

- Do not immerse or expose the Dash Cam or batteries to rain, water or other liquids.

- Do not leave the device exposed to a heat source or in a high-temperature location, such as in the sun or in an unattended vehicle. To prevent the possibility of damage, remove the Dash Cam from the vehicle or store it out of direct sunlight, such as in the glove box.

- Do not operate the Dash Cam outside of the following temperature range: from -20° to 45°C (from -4° to 113°F).

- When storing the Dash Cam for an extended time period, store within the following temperature range: from 0° to 25°C (from 32° to 77°F).

- Do not use a power and/or data cable that is not approved or supplied by Nextbase™.

- Contact your local waste disposal department to dispose of the Dash Cam/batteries in accordance with applicable local laws and regulations.

Windshield Mounting Legal Restriction Precaution

Before using the Dash Cam on your windshield, check the state and local laws and ordinances where you drive. Some laws prohibit or restrict the placement of objects on the windshield of a motor vehicle. IT IS THE USER'S RESPONSIBILITY TO MOUNT THE DEVICE IN COMPLIANCE WITH ALL APPLICABLE LAWS AND ORDINANCES. Always mount your Nextbase Dash Cam in a location that does not obstruct the driver's view of the road. Nextbase does not assume any responsibility for any fines, penalties, or damages that may be incurred as a result of any state or local law or ordinance relating to the use of your Nextbase Dash Cam.

Camera Legal Requirements Precaution

In some jurisdictions it could be considered an invasion of privacy rights to take or publicly display photographs or videos of people or their vehicles using this product. It is your responsibility to know and comply with applicable laws and rights to privacy in your jurisdiction and in any jurisdiction in which you may use this device. Video recordings made by this Dash Cam should be for personal use only.

Publication of the recordings on YouTube, the internet or other methods is subject to the data protection legislation and the requirements thereof must be adhered to. Such data protection legislation may prohibit the use and dissemination by you of Dash Cam footage or may impose restrictions on it – we recommend that you check the legal requirements with your legal advisor before disseminating any Dash Cam footage.

If the Dash Cam is to be used within a UK commercial environment, i.e. truck use, then the CCTV regulations apply in addition to the Data Protection Act regulations. This includes labelling to identify the use of CCTV is taking place, the omission of Audio recording and informing the relevant authorities of who controls the data. For use in a commercial environment in non-UK countries, please refer and adhere to local regulations and requirements. For non-UK operation, specific legal requirements may apply where Dash Cams are to be used in a commercial or employment context - again, we recommend that you check the legal requirements with your legal advisors prior to commencing use of Dash Cams in commercial or employment contexts.

G Sensor Notice

The G Sensor within the Dash Cam measures forces exerted upon it, with reference to one g which is the nominal force exerted upon us when stationary on the earth's surface. The G Sensor will also trigger to protect any recording currently in progress, if a pre-determined threshold of force is exceeded. The G Sensor protection will be adversely affected if the Dash Cam is NOT mounted in the vertical direction i.e. with the lens pointing to or from the direction of travel. G Force information derived from a G Sensor is not warranted to be totally accurate at all times, as it is derived from the G Sensor through a sampling method over time. The precision of the G Sensor value recorded depends upon when the acceleration took place at the instance of the sample taken. The thresholds to trigger the video protection rely upon a trigger value being exceeded between two successive samples, in any one of the three G Sensor axis. If the Automatic G Sensor protection does NOT trigger during an event, then the Protect button should be pressed, in order to protect the file. Protecting the file can also be performed using the Playback function upon the Dash Cam (models with LCD screens), or indeed through the MyNextbase Connect™ App for applicable Wi-Fi models.

Product Compliance Information

Innovation, Science, and Economic Development Canada Compliance

This device complies with Innovation, Science and Economic Development Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: this device may not cause interference, and(1) this device must accept any interference, including interference that may cause undesired(2) operation of the device.

Radio Frequency Band and Power Information

Hereby, Portable Multimedia Limited declares that the radio equipment type Series 2 Dash Cam is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.nextbase.com/certifications/

Product Wireless Information

2400–2483.5 MHz: Wi-Fi (Max 16.3 dBm), 5150–5250.5 MHz: Wi-Fi (Max 25mW), BT (Max 6.0 dBm), BLE (Max 6.0 dBm).

RF Exposure Information (MPE)

This device meets the EU requirements and the International Commission on Non-Ionising Radiation Protection (ICNIRP) on the limitation of exposure of the general public to electromagnetic fields by way of health protection. To comply with the RF exposure requirements, this equipment must be operated in a minimum of 20 cm separation distance to the user.

FCC Statement

FCC Identiﬁer

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment oﬀ and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment to an outlet on a circuit diﬀerent from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

- This appliance and its antenna must not be co-located or operated conjunction with any other antenna or transmitter.

- A minimum separation distance of 20cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements.

The FCC Identifier (FCC ID) is available as an E-label within your Dash Cam’s System Info pages.

To view the FCC ID please follow the steps below:

Step 1: Step 2:

Connect Apps

Press the ‘Menu’ button to enter

Press the ‘Setup’ button.

the Dash Cam’s menu system.

Step 3:

Swipe through the menu pages

and select System Info.

Model: Firmware: Serial No: FCC ID: Battery Status:

System Info

2AOT9-NBDVR622GW

The FCC Identiﬁer (FCC ID) is

seen as above.

622GW

Rxx.x

123456789

Charging

Note:

- The Regulatory Information (inc. the FCC ID) is embedded with the Dash Cam’s firmware, applied to

the gift box and included within this User Manual.

- The FCC ID cannot be changed by the user.

FCC CAUTION:

This product does not contain any user-serviceable parts. Repairs should only be made by an authorised Nextbase™ service centre. Unauthorized repairs or modiﬁcations could result in permanent damage to the equipment, and void your warranty and your authority to operate this device under Part 15 regulations.

FCC - Supplier’s Declaration of Conformity Statement

SUPPLIER'S DECLARATION OF CONFORMITY (47 CFR Section 2.906).

We; Tank Design (The responsible party, who must be located in the United States)

Hereby, Declare that the essential requirements set out in the 47 CFR Sections 2.906 of FCC, have been fully fulfilled on our product with indication below:

1. Applicant's Info

Company Name: Portable Multimedia Ltd Mailing Address : Unit 2, Caerphilly Business Park, Van Road, Caerphilly. CF83 3ED. UK Contact : Graham Lambert Tel : +44 02920 866429 Email Address : support@nextbase.com

2. Product Info

Product Name : Dash Cam Model No. : NBDVR622GW Brand Name : Nextbase

3. Applied Standard

Standards E-CFR Title 47 Part 15 Subpart B—Unintentional Radiators: 2018

5. FCC Marking

6. Responsibilities and obligations

Strictly follow the FCC rules of 2.906, 2.908, 2.909.

7. Applicant's Authorisation

Company Name: Portable Multimedia Ltd Mailing Address : Unit 2, Caerphilly Business Park, Van Road, Caerphilly. CF83 3ED. UK Contact person : Graham Lambert Signature: Email Address : support@nextbase.com Tel : +44 02920 866429 Date : TBC

8. Responsible party in US. Company name: Tank Design Mailing Address: 158 Sidney Street, Cambridge, MA 02139, United States Contact person : Mr Scott Watts Signature: Email address : SWatts@tankdesign.com Tel : (617) 388-8380 Date : TBC

Report No. TBC

4. Test Firm Used to Take Measurements:

Name : Waltek Services (Shenzhen) Co., Ltd. Address : 1/F, Fukangtai Building, West Baima Rd Songgang Street, Baoan District, Shenzhen, Guangdong, People's Republic of China, 518105 Contact Name : Philo Zhong Tel : +86 755 8355 1033 802 Email : CB@waltek.com.cn Designation No. : TBC FRN : TBC

A full list of certifications can be found at https://www.nextbase.com/certifications/

Declaration of Conformity

We, Portable Multimedia Limited.

Dorna House Two. 52 Guildford Road, West End, Surrey. GU24 9PW United Kingdom

Declare under sole responsibility that the products:-

Product Name: NEXTBASE In Car Cam Model number: NBDVR622GW

To which this declaration relates, is in conformity with the following standards,

2014/30/EU (EMC Directive) EN 55032:2015 EN 55035:2017 EN 61000-3-2:2014 EN 61000-3-3:2013 EN 60950-1: 2006 + A11:2009+A1 2010+A12:2011+A2:2013 (LVD) 2011/65/EU + EU 2015/863 (RoHS directive) 2012/19/EU (WEEE Directive) EC 1907/2006 (REACH) IEC 61000 -4-2:2008 IEC61000-4-3:2006+A1:2007+A2:2010 IEC 61000-4-4:2012, IEC 61000-4-5:2014, IEC 61000-4-6:2013 IEC 61000-4-8:2009, IEC 61000-4-11:2004+A1:2017 EN 301 489-1 V2.2.1: 2019-03 EN 301 489-17 V3.2.0:2017-03 EN 301 489-19 V2.1.1: 2019-04 EN 300 328 V2.1.1: 2016-11 (BT3.0, BT4.0 & Wi-Fi) 2014/53/EU & EN 62311:2008 (RED) ETSI EN 303 413 V1.1.1: 2017-06 (GNSS)

Supplementary information: This product complies with the requirements above and carries the CE mark accordingly.

Caerphilly, United Kingdom

(Place of issue)

TBC

(Date of issue)

Declaration of Conformity

Graham Lambert

(Name of authorised person)

(Technical Director)

(Signature of authorised person)

Telephone +44 2920 866429

Product Speciﬁcation

Model Number / Name

Power Requirements

Power Supply

Sensor Resolution

Lens Type / Angle / Aperture

Recording Resolution

Screen Size

Screen Resolution

Screen Ratio

Card Reader

SD Card (Recommended Type)

SD Card Recorded File Capacity (based on default settings. Recording times are reduced with Rear Cam attached)

Recording Format

Internal Battery

GPS

Unit Dimensions (mm)

Unit Weight

Amazon, Alexa and all related logos are trademarks of Amazon.com Inc or its affiliates The Bluetooth™ word mark and logos are registered trademarks owned by Bluetooth SIG. Windows is a registered trademark of Microsoft Corporation in the United States and other countries. Android is a trademark of Google Inc in the United States and in other countries. 2015 Google Inc. All rights reserved. Google Maps™ mapping service is a trademark of Google Inc. Mac is a registered trademark of Apple Inc in the United States and in other countries. iOS is a trademark or registered trademark of Cisco in the United States and in other countries. Wi-Fi is a registered mark of Wi-Fi Alliance Corporation. microSD and the microSD logo are trademarks of SD-3C, LLC. MyNextbase Player™, MyNextbase Cloud™, and Click&Go PRO™ are registered trademarks of Portable Muultimedia Ltd.

NBDVR622GW

5V / 1.5A

12-24Vdc Car Power Cable (supplied) Fuse Type: 32mm / 2A Output: 5Vdc

Hardwire Kit also available to purchase for a hidden, permanent power supply.

8MP (3840 x 2160)

6G / 140° / F1.3

3840×2160 @ 30 FPS day & night

960 (W) X 480 (H) pixels

16:9

MicroSD, U3, up to 128GB

8-128GB SDHC / SDXC, U3 For best results, use a Nextbase branded SD card.

8GB MicroSD = 20 minutes of recording 16GB MicroSD = 45 minutes of recording 32GB MicroSD = 90 minutes of recording 64GB MicroSD = 180 minutes of recording 128GB MicroSD = 360 minutes of recording

MP4

Lithium-Polymer 3.7V / 320mAh (approx. 15 mins recording time) Battery design allows the 'Auto Power Off' feature to function in event of power loss within the vehicle. It is not intended as an alternative power source to replace the supplied car power cable.

Dual System

94 x 53 x 45

125g

Package Contents

Please check the contents of your Nextbase™ Dash Cam product.

Click & Go Powered Mounts

Nextbase 622GW Dash Cam

Your Dash Cam to record

the road ahead.

Suction & Adhesive

attachments for you

to choose between.

Car Power Cable (4m) USB Connection Cable 622GW Quick Start Guide

622 GW

Charge your Dash Cam in car

using the Car Power Cable.

Connect your Dash Cam to a PC. Quickly get your Dash Cam

up and running using

Quick Start Guide.

Cable Tidy Tool

Use the Cable Tidy Tool to

stow the power cable within

the lining of your car.

Product appearance may differ slightly to that shown above.

Product Features

Thank you for purchasing this Nextbase Dash Cam product, in this section we will outline some of the features available with this Dash Cam.

HD Recording Capability with Enhanced Image Stabilisation

Ultra Clear 4K recording at 30 FPS, to record the road ahead. Inbuilt polarising ﬁlter reduces windscreen reﬂection and glare. Enhanced Image Stabilisation greatly reduces vibrations from your vehicle and provide a super smooth, crystal clear image, allowing you to see more details in your recordings.

Super Slow Motion

When recording in 1080P at 120 FPS you will be able to view your video in Super Slow Motion. This feature is ideal to help identify what happens in an incident and capture details such as number plates.

Enhanced Night Vision & Extreme Weather Mode

Your 622GW Dash Cam automatically detects light levels and enhances the image as its being recorded, allowing for clearer night-time recordings while Extreme Weather Mode allows you to “see through fog” and could prove vital in identifying critical details in low visibility conditions.

HD Touch Panel Display

Bright, clear, high deﬁnition 3" screen with IPS technology for a wide viewing angle.

Click & Go Pro Powered Mount

Our exclusive Click and Go Pro powered magnetic car mount to easily install and remove your Dash Cam with just one hand. Supplied with both adhesive and suction ﬁttings.

G Sensor / File Protection

In the event of an impact the device will automatically 'protect' the recording, stopping the ﬁle from being over-written. This can also be performed manually, by pressing the ‘protect’ button. Individual ﬁles can also be 'protected' when viewed within playback mode.

Inbuilt GPS and ‘what3words’

Inbuilt GPS to keep track of your journeys. By partnering with what3words we can provide you with your exact location to a 3m square location. In the event of an incident, this location can be shared with the emergency services to quickly and precisely locate you.

Automatic Start / Stop Technology

As soon as the vehicle ignition is turned on, your Dash Cam will start to record automatically. When the ignition is turned oﬀ, the Dash Cam will perform an automatic shutdown process.

Intelligent Parking Mode

Intelligent Parking Mode triggers recording automatically when motion is detected, keeping your car safe when parked.

Built-in Microphone & Speaker

Record audio to compliment the video recordings.

MyNextbase™ Suite

MyNextbase Connect App - View, manage and upload videos, set up Alexa and Emergency SOS features. MyNextbase Cloud - Upload your video to the Nextbase server to get a shareable link to send to friends, insurers, and social media. MyNextbase Player - Playback software for viewing, managing, editing, and sharing your videos.

Alexa Built-In

Operate your Dash Cam through Alexa voice control (must have Alexa app installed; see page 40 for installation and usage details).

Dash Cam Accessories

Your Dash Cam can be ﬁtted with a range of Nextbase accessories to enhance your recordings, including Rear Facing Cameras to record the road behind you, or the interior of your vehicle. See the Nextbase Accessories Manual on for more ininformation.www.nextbase.com

Camera Parts and Controls

See below to identify the parts and controls of your Dash Cam

Dust Cover

Mounting point located under the dust cover. Regulatory markings (CE, FCC, RCM, WEEE) can also be found underneath the dust cover.

Camera Lens

Wide angle 140º view.

Speaker

Integrated speaker for audio playback.

LEDs

Top: Blue

- The Blue LED will be on while the Dash Cam is charging. It will turn off when charging is complete, even if the Dash Cam is still plugged in. Bottom: Red

- The Red LED is permanently on while the Dash Cam is active. It will flash while recording.

Protect Button

Press whilst recording to protect the current file in event of an emergency situation. When in the menus, or in playback mode, pressing this will also act as a Back button.

Note:

- When the 'Protect' function is activated a file containing 15 seconds prior to the incident

and 30 seconds after is written to the Protected folder.

Screen

3" Inch High Resolution Screen. Tap the centre of the screen to take a photo. This applies while recording and while in video mode. If a Rear Cam is attached, touch the centre of the Front Facing view to take a photo. This will save 2 photos, one from the Front Facing camera, and one from the Rear Facing camera.

Microphone

Integrated microphone for audio recording.

Camera Parts and Controls (cont.)

See below to identify the parts and controls of your Dash Cam

USB Cover

USB port located under the dust cover.

Light Sensor

When Screen Dimming is turned ON in the Setup Menu, the screen brightness is automatically adjusted relative to the ambient light levels.

Reset Button

Press to force a hard restart of the Dash Cam.

Power Button

Press and hold for 2 seconds to turn the Dash Cam On/Off. Short press, acts as a back button when in the Menus.

MicroSD Card Slot

Insert the MicroSD card here, taking care that the gold contacts are facing towards the rear of the Dash Cam.

HD-Out/Rear Cam Input

Connection point for the Rear Cameras and TV Connection, see page 44.

Polarising Filter

Reduces the glare on the windscreen to help record clearer videos. See page 19 for setup information.

In Vehicle Installation

Please follow the instructions below for the first-time installation of the Dash Cam. For day to day use, simply remove the camera from the mount as required.

1. Insert MicroSD Card

Insert a suitable MicroSD card (U3 Type) in to the Dash Cam, taking care that the gold contacts are facing towards the LCD screen side of the Dash Cam. Push the memory card until it clicks into place.

622 GW

Note:

- Use the edge of a small coin (or similar object) to push the memory card in place if required. Take care that card has 'clicked' into place, a second push inwards will release the memory card.

- For best results, we recommend using Nextbase branded SD cards.

- Do not remove or insert the memory card when the Dash Cam is turned on. This may damage the memory card, or recordings within.

2. Remove dust cover from the Dash Cam

Remove the dust cover that is located on the front of the Dash Cam to gain access to the mounting point.

To remove the dust cover, lift the cover away from the body of the Dash Cam.

Note:

- If the Dash Cam is not to be used for a period of time replace the dust cover to help keep the components free of dust or other contaminants.

3. Attach the mount to the Dash Cam

622 GW

Place the mount in space under the dust cover on the Dash Cam. Once in place, magnets within the mount and camera will hold the two parts together.

See page 20 for more information on changing mounts attachments.

In Vehicle Installation (cont.)

4. Connect car power cable

Connect the supplied car power cable to the Dash Cam Mount’s USB port. Do NOT connect the power cable to the USB port on the Dash Cam.

5 Plug the power cable into the 12-24Vdc outlet of your vehicle

The Dash Cam will automatically power on and start recording once power is available. In some vehicles this will be when connections are made, for others the Dash Cam will power on once the ignition has been turned on.

Also available to purchase is a Nextbase™ Hardwire Kit. This connects your Dash Cam directly to the vehicle’s fusebox to power it leaving your 12Vdc outlet available for Phone / Sat Nav charging. The Nextbase Hardwire Kit includes the necessary 12-24Vdc to 5Vdc convertor and battery protection circuitry. See page 9-10 of the Nextbase Accessories Manual for further information.

Route the power cable around the windshield to the 12-24Vdc socket, ensuring that your view is not obstructed, and that the cable is not a distraction. Use the cable fitting tool (bottom, left) included with your Dash Cam to more easily open the lining of your vehicle, within which you can stow the cable. See page 18, ‘Positioning your Dashcam’ for more details.

Note:

- Do NOT wire the Dash Cam directly to a 12Vdc supply by cutting the cigarette plug off the end of the cable, or permanent damage will result.

12-24Vdc

The above diagram is for illustration purposes only.

Cable Tidy Tool (included with your Dash Cam)

In Vehicle Installation (cont.)

6 Remove the adhesive cover layer

Peel back the red cover layer to expose the adhesive surface, ready to mount on your windscreen.

7 Straighten the Dash Cam

Ensure that the Dash Cam is horizontal and faces straight out of the windscreen. Ensure that objects on the Dash Cam display appear level, and adjust as required.

8 Attach the Dash Cam to the windscreen

When you are satisfied with the placement and orientation of the Dash Cam, firmly place the mount on the windscreen.

+ 36 hidden pages

NextBase 622GW User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
