※ Voice dialing (if supported by cell phone)
※ Last call redialing
※ Automatic reconnection
※ Volume control and mute function
※ DSP technology for noise reduction and echo cancellation
※ Call transfer between cell phone and NXBT-001 during conversation
※ Bluetooth audio streaming (A2DP and AVRCP)
※ Supports up to 8 Bluetooth devices in pairing memory
※ Can be charged with a 12 volt adaptor or with the built-in solar panel.
NXBT-001
Car Charger
Windshield Mount
Suction Cups
1
4
5
Front
USB jac k
Mic
2
3
1
Multifunction button:
Pairing,
Answer/End/Reject Call,
Voice Dialing,
Last Number Redialing,
2
Volume Up
Tra ns fe rr in g Ca ll ,
Playing Forward
A2DP
3
4
Volume Down
Mute
Playing Back
LED Indicator
5
Met al S he et
Sol ar M od ule
Bac k
It is recommended that the hands-free car kit be positioned and installed on
the windshield in front of the driver's shoulder, as shown in the picture below.
Step 1:
Stick the Windshield
Mount to the windshield
WARNING: Install the Hands-free Car Kit out of the way of any Air Bags for
safety reason
CHARGING THE NXBT-001
Using the car charger
Please charge the NXBT-001 before its first use. When charging, a red LED will
be displayed. When the device is fully charged the light will switch off.
Using solar power
Direct the solar panel on the back of the hands-free car kit toward the sun. the
operating time will be extended continuously without any additional charge
required by the car charger.
Step 2:
Insert the bluetooth
car kit
Step 3: OK
Warning: Do not attempt to charge the hands-free car kit with any charger other
than the one provided. Using another charger may damage or destroy the handsfree car kit.
Low battery indicator
When the battery is less than 3.5V, the device will make a sound and a red LED
will flash thrice every 30 seconds.
TURNING THE NXBT-001 ON
Press and hold the button for 3 seconds to turn the NXBT-001 on. You will
hear an audio cue of "Do Re Mi Fa".
TURNING THE NXBT-001 OFF
Press and hold the button for 5 seconds to turn the NXBT-001 off. You will
hear an audio cue of "Fa Mi Re Do".
PAIRING THE NXBT-001
Initial pairing
! With the NXBT-001 OFF, press and hold the button for 5 seconds. You
will hear a BEEP sound, and red & blue LED lights will flash .
! Use your cell phone to search for Bluetooth devices.
! Select "NXBT-001" on your cell phone.
! Your cell phone will request a password. Enter "0000".
! Your cell phone will show that pairing is now complete.
! The NXBT-001 will stand by if the pairing is not successful within 5 minutes.
Auto reconnection
When the NXBT-001 turns off while connected to a cell phone, it will
automatically reconnect to the cell phone when it is turned back on. (Both
devices must be within the required range of 33 feet / 10m.)
When the NXBT-001 and your cell phone are separated by a distance of 33 feet
(10 meters) or more, the NXBT-001 and cell phone will disconnected. When they
are brought back within the required distance, the NXBT-001 will automatically
reconnect with the cell phone.
alternately
MAKING A PHONE CALL
Dialing with the cell phone
With the NXBT-001 on and paired with your cell phone, dial your cell phone as
you would normally.
Voice Dialing
With the NXBT-001 on and paired with your cell phone, press the button
once. After you hear the audio signal, state the desired name.
Note: Your cell phone must support Voice Dialing.
Last Call Redialing
With the NXBT-001 on and paired with your cell phone, press and hold the
button for 2 seconds, the last dialed number will be redialed.
Note: Do not press the button for more than 2 seconds as the NXBT-001
will turn off.
ANSWERING A PHONE CALL
Press the button once when the cell phone rings.
ENDING A PHONE CALL
Press the button once when the conversation has ended.
REJECTING A PHONE CALL
Press and hold the button for 2 seconds to reject an incoming call.
OPTIONS AVAILABLE DURING A CALL
TRANSFER CALL BETWEEN YOUR CELL PHONE AND THE NXBT-001
Press and hold the button for 2 seconds during your conversation. You will
hear a BEEP sound and the call will transfer between your cell phone and the
NXBT-001.
HAND-HOLD MODE
This device supports hand-hold mode. If you don't want to use the loudspeaker,
you can turn the volume to the lowest level and use the NXBT-001 as you using
your cell phone.
VOLUME CONTROL
With the NXBT-001 on and paired with your cell phone, press or to
adjust the volume.
MUTE
To activate the mute function, press and hold the button for 2 seconds
during a phone call. This will mute your voice to the other party.
To release the mute function, press and hold the button for 2 seconds
again.
Audio Player
If you are using a phone that supports A2DP and your phone is already
connected with the NXBT-001, you can use the NXBT-001 to play the music
stored in your cell phone.
PLAY, PAUSE AND RESUME
Use the button to play, pause and resume your music.
STOP
Press and hold the button for 2 seconds to stop your music.
SKIP FUNCTION
Press and hold the button for 2 seconds to skip forward one track. Press
and hold the button for 2 seconds to skip back one track.
ANSWER A CALL WHILE MUSIC IS PLAYING
If there is a phone call the music will be stopped automatically. It will be started
automatically once the phone call has ended.
SUMMARY OF BUTTON FUNCTIONS
Functions Status Action
Power on Power off Press the button for 3s
Power off Power on Press the button for 5s
Pairing Power off Press the button for 5s
Voice dialing Idle Briefly press the button
Answering a call Ringing Briefly press the button
Ending a call Talking Briefly press the button
Rejecting a call Ringing Press the button for 2s
Last number redialing Idle Press the button for 2s
Transferring a call Talking Press the button for 2s
Mute on Talking Press the button for 2s
Mute off Mute on Press the button for 2s
Volume up Talking Briefly press the button
Volume down Talking Briefly press the button
Music play Idle Briefly press the button
Pausing music Playing music Briefly press the button
Stopping music Playing music Press the button for 2s
Skip forward Playing music Press the button for 2s
Skip back Playing music Press the button for 2s
Status
Power on
Power off
Pairing
Connected
Not connected
Charging
Charging completed
Low battery
LED indication
The blue LED indicator flashes twice
The red LED indicator flashes twice
The red & blue LED indicator flash alternately
The blue LED indicator flashes once every 3 seconds
The blue LED indicator flashed once every 2 seconds
The red LED indicator on
The LED indicator off
The red LED indicator flashes thrice every 30 seconds
SPECIFICATIONS
Specifications
Bluetooth Core Specification: .......................................V2.0+EDR
Supported Profile: .........................................................HSP, HFP, A2DP，AVRCP
Frequency Range: ........................................................2.402GHz-2.480GHz
Working Range: ............................................................≤33ft /10m
Charging Time: ..............................................................car charger: 2 hours
.......................................................................................solar panel: 17hours
Talking Time: .................................................................10 hours
Standby Time: ...............................................................250 hours
Dimension: ....................................................................94*54*11mm
Weight: ..........................................................................55g
This manual was correct and complete at the time of printing. However,
specifications and updates can occur at any time without prior notice. No part of
this manual may be copied, republished, reproduced, transmitted, or distributed
in any way without the prior written consent of Nextar, Inc. Any unauthorized
distribution of this manual is expressly forbidden.
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply with limits for Class
B digital devices, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on. The user is
encouraged to try to correct the interference through one or more of the
following measures:
1. Reorient or relocate the receiving antenna. 2. Increase the separation
between the equipment and the receiver. Connect the equipment to an outlet on
a circuit different from that to which the receiver is connected. 3. Consult the
dealer or an experienced radio/TV technician for help.
TM
Nextar is a trademark of Nextar (Hong Kong) Limited.
Nextar may find it necessary to modify, amend or otherwise change or update this
manual. We reserve the right to do this at any time, without any prior notice. All
specifications and features are subject to change without notice. All screen shots
shown are simulated and may not represent the actual screen on production units
sold to consumers.
For instruction manuals, updated drivers or other information, be sure to visit our
website at:
www.nextar.com
