Nextar NSBT007 Users Manual

Table of Contents

Introduction
Feature

Speaker Feature
Bluetooth AV Dongle Feat ur e

Specification

Speaker Section
Bluetooth AV Dongle Section

Unpacking
Appearance and Controls
Power Resource

Speaker
Bluetooth AV Dongle

Indicator
Operation

Using By Connecting with Bluetooth AV Dongle
Using By Connecting with Bluetooth Mobile phone
To finish music
Auto Connect

Precautions

About bluetooth speaker syste m
About bluetooth communication
Notes when using with mobile phone
Others

What is Bluetooth Technology?
Troubleshooting

No sound
Low sound level
Distorted sound
Cannot Pair
Delayed sound

1

2
2

3

3
4
5

6
7

10

12
13

Introduction

Thank you for purchasing NS -BT007.
Before using the unit, please read this manua l carefully, to obtain the best p ossible
performance from your speaker.
Please keep this manual for future reference.

This bluetooth speaker is uniquely designed to bring you great
a swimming pool. You can enjoy listening to music with your
MP 3, MP 4 or other bluetooth supported device.

Remark:
Bluetooth devices to be connected with this unit are required to support A 2 DP.

music, even if you are in

bluetooth mobile phone,

Feature

Speaker Feature

*Supports bluetooth technology
*Supports A 2DP /AVRCP

*Auto bluetooth connection
*Auto power off
*Waterproof and floats in water
*Powered by 4 X AA batteries

Bluetooth AV Dongle Feature

*Supports bluetooth transmission
*Built-in lithium battery
*USB power

2

Specifications

Speaker Section

-Bluetooth Version 1.2

-Class 2 (up to 3.3 feet)

-Support A 2 DP & AVRCP

-Maximum output power: 2 W X 2

-Compatible bluetooth profiles:
A 2 DP /AVRCP

-Power: 4 X AA batteries

- Usage Time: Up to 4 Hours
(The temperature or conditions of use has an effect on usage time)

- Dimension (L/W/H):

Approx. 15 2 x 15.2 x 1 3 9.6 4 mm

(5.985 x 5. 9 8 5 x 5. 5 in.)

Bluetooth AV Dongle Section

- Bluetooth Version 1. 2

- Class 2 (up to 10 meters)

- Supports A 2 DP & AVRCP

- Power: Built-in battery or USB cable

- Usage Time: Up to 4 Hours

- Dimension (L/W/H)
Approx. 152.13 x 152 .13 x 31.2 mm

(5.99 x 5.9 9 x 1. 23 in.)

Appearance and Controls

5
6

7
8

9

1 3

4

2

10

Unpacking

NS -BT007 package includes the following components:

USB Cable(1

MSin

Adaptor
User Manual(1
Product Registration Card(1

Bluetooth Speaker System

Bluetooth AV Dongle

3

Warranty Card (1)

Batteries (4)

)

)

)

1

Bluetooth Speaker

2

Bluetooth Dongle

3

Main Button

4

Speaker

5 Play/Pause

Play: Tap play button
Pause: Tap pause button (To resume music, tap play button again)

6 Previous Song/Volume Decrease

Previous song: Press and hold previous button for 1 second
Volume decrease: Tap Volume decrease button

7 Next Song/Volume Increase

Next song: Press and hold next song button for 1 second
Volume increase: Tap Volume increase button

8 Vent Hole

It is to stable the speaker sound quality.

9 Speaker Power/Pairing Button

Power on/off: Press and hold the power button for 3 seconds
Pairing: In off mode, press and hold power button for 8 seconds

10 Battery Compartment and Battery Door:

The battery door should be screwed tight.

Insert four AA batteries

.

4
