Note
It may cause damage to the SD/MMC/MS card/USB
device and the unit when any memory card or USB
device is inserted or removed without turning off the
unit.
Safety precaution
1) Use only the supplied adaptor with Input 100-240V,
Output 5V.
2) Turn off power before cleaning. Use only a soft
cloth to clean the unit
Do not use liquid cleaners.
3) Avoid exposing the unit to extreme heat.
4) Do not disassemble the Digital Photo Frame,
otherwise it may result in electric shock and void
your warranty.
1
Page 3
Content
Note .............................................................................1
Safety precaution.......................................................1
Content........................................................................2
Introduction................................................................3
1、Features..........................................................3
2、Packaging Check List .....................................4
3、Specifications..................................................4
Product Diagram........................................................5
A. Top View...........................................................5
B. Front View........................................................5
C. Rear View ........................................................6
D. Side View.........................................................6
Using Your Digital Photo Frame...............................7
Viewing Modes.....................................................7
File Saving............................................................7
Technical Notes..........................................................8
Question/Troubleshooting Guide.............................8
2
Page 4
Introduction
Your new Digital Photo Frame lets you view digital
pictures from memory cards easily and quickly.
No computer or printer is needed
Includes convenient slide show mode, which starts
automatically when the Frame is turned on.
Supports many popular memory card types.
Easy to take with you to share photos with family and
friends anywhere.
A step beyond the traditio nal photo fram e. V iew tens or
even hundreds of digital photos without the need to
pay for printing.
1、Features
7 inch TFT LCD
Supports Secure Digital (SD), Multimedia Card (MM C),
Memory Stick (MS) memory card formats and USB
JUMP DRIVE
View the pictures from memory cards directly
Resolution: 480X234 pixels
Supports high-resolution photos
Automatic start of slide show
3
Page 5
2、Packaging Check List
Digital Photo Frame
User Manual
Quick Start Guide
AC Adaptor
3、Specifications
Panel Size 7 inches
Resolution 480X234
Brightness 200 CD/M²
Contrast 300
View Angle (U/D/L/R) (CR≥10)
Response Time 15ms Ton
Screen Size Mode 16:9
File Format Type JPEG
Max.Photo Size 10 mega pixels
Power Requirement 5V DC
Power Consumption <10 W
Operating Temperature
Storage Temperature
40/60/60/60
14~158℉ (-10~70℃)
-4~176℉(-20~80℃)
4
Page 6
Product Diagram
A. Top View
1. Button
Pause or resume the playback.
2. Button
Go to the previous picture.
3. Button
Go to the next picture.
4. Rotate Button
Rotate the current picture.
5. MODE Button
Change the display mode
B. Front View
among Pan Scan, Fill, Original
and Auto Fit.
Change the aspect ratio
between 16:9 and 4:3. (Press
and hold for a moment).
6. P-SAVE Button
Enter the power save mode.
Then press it again to exit the
power save mode.
1. LCD Screen
5
Page 7
C. Rear View
D. Side View
1. Stand
Support the Digital Photo Frame.
1. SD/MS/MMC Card Port
Insert SD/MS/MMC card into this port.
Or pull out the SD/MMC/MS card from the port.
2. USB Port
Connect USB device, such as USB flash disk.
3. DC 5V IN
Connect the supplied adaptor.
6
Page 8
Using Your Digital Photo Frame
Install the stand for tabletop display. Connect the AC adaptor.
Insert a memory card in the Digital Photo Frame (with the card’s
electrical contacts towards the front of the unit.). A slide show will
b
egin automatically.
To enter the power save, press the P-SAVE button.
Press the
briefly and the slide show will be stopped. The current photo will
remain on the screen until the button is pressed again, at which time
he slide show will resume.
t
T o display the previous or next picture, press the button.
The Rotate button allows photos to be turned proper viewing. Press
repeatedly to rotate the current picture clockwise:
0°
9
Viewing Modes
Press the MODE button to select display mode: Pan Scan, Fill,
Original and Auto Fit. Press the MODE button and hold for a moment
to change the aspect ratio between 16:9 and 4:3.
File Saving
Photos must be saved in the JPEG format in order to be viewed on
the Digital Photo Frame. Nearly all digital cameras will save in this
format by default. Photos that have been saved with certain image
editing programs can fail to display properly.
button, the word Pause will appear on the screen
180° 270°.
7
Page 9
Technical Notes
1. Your Digital Photo Frame is a sophisticated electronic device.
Do not drop or subject the unit to jarring or strong vibrations.
2. Avoid placing the Digital Photo Frame in areas of high humidity
or where it might be subjected to splashing.
3. The panel is made of plastic and can be easily damaged. Avoid
sharp objects.
4 . Use only a soft dry cloth to clean the screen.
Question/Troubleshooting Guide
This chapter presents some troubleshooting problems you may
encounter while using the device. Even if the following guide fails to
solve your problem, please do not disassemble the device, but leave
he problems to professional staff.
t
1.Question: What kind of photos does this device’s supports?
Answer: The Frame will display digital photos that are stored in the
JPEG format which is the standard format for nearly all digital
cameras. Some cameras allow images to be stored as TIFF or with
the Frame.
RAW files as well as JPEG. Only the JPEG format is compatible
2.Question: What should I do if the system does not respond
when the power is turned on?
Answer: Make sure the unit is properly connected to a power source.
Then turn it off, reconnect the power and turn it on again.
8
Page 10
3.Question: Why is the memory card not recognized?
Answer: The memory card might be inserted rearwards or is not
pushed in far enough. After inserting the memory card in the right
direction, if the card still cannot be read, please turn off the unit and
hen power it again.
t
9
Page 11
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with
limits for Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
3. Consult the dealer or an experience radio/TV technician for help.
10
Page 12
Nextar™ a trademark of Nextar (Hong Kong) Limited
Nextar may find it necessary to modify, amend or
otherwise change or update this manual.
We may reserve the right to do this at any time, without
any prior notice.
All specifications and features are subject to change
without notice.
© NEXTAR, INC. AND ITS AFFILIATES
LA VERNE, CA 91750. USA
All products distributed by Nextar, Inc.
Unless otherwise indicated
© 2005 Nextar (Hong kong) Limited. Nextar (Hong Kong) Limited
claims trademark rights in Nextar
product names and trademarks are the property of their
registered owners.
TM
. All other brand names,
1661 FAIRPLEX DRIVE
www.nextar.com
Made in China
