Nextar N3-506 User Manual

TABLE OF CONTENTS

Safety precautions................................................................................................................................................3

Introduction...........................................................................................................................................................3

Features ...............................................................................................................................................................4

Packaging Check List ...........................................................................................................................................4

Product Diagram...................................................................................................................................................4

Charge the battery................................................................................................................................................ 5

Using Your Digital Photo Frame ...........................................................................................................................9

Technical Notes................................................................................................................................................133

Question/Trouble-shooting Guide.....................................................................................................................143

Specifications .....................................................................................................................................................15

FCC Compliance ..............................................................................................................................................166

- 2 -

Safety precautions

1) Use only the supplied Input 100-240V, Output 5V adapter.

2) Turn off power before cleaning. Use only a soft cloth to clean the unit. Do not use liquid cleaners.

3) Avoid exposing the unit to extreme heat.

4) Disassembling the Digital Photo Frame may result in electric shock and will void your warranty.

Introduction

Your new Digital Photo Frame is a convenient and innovative way to display your digital photos.

With it, you can easily view digital photos directly from your camera’s memory card; no computer or

printer required.

It supports all of the most popular memory card types on the market, including SD, MMC and MS.

The Digital Photo Frame is light and portable; take it with you anywhere to share photos with family

and friends.

This Digital Photo Frame is a step beyond the traditional photo frame. View and keep on display

tens or even hundreds of digital photos without the need to pay for printing.

- 3 -

Features

②

● Shows sharp photos on a 3.5 inch LCD display

● Supports SD, MMC MS memory card formats

● Displays photos from memory cards

● Renders in a smooth and clear resolution of 320X240 pixels

● Offers a variety of display features, including a slide show mode

Packaging Check List

● Digital Photo Frame ● USB Cable ● User Manual

● Power Adaptor ● Wallet Holder ● Quick Start Guide

Product Diagram

A. Fron t View

①

① LCD Display

B. Bottom View

② Reset button

- 4 -

D. Left View E. Left View

③

④

③ USB Port: Connect

to a computer through

the USB cable or to an

electronic socket

through the power

adaptor
④ Memory Card Slot:

Used for inserting an

SD/MMC/MS card.

⑤
⑥

⑦
⑧

⑨
⑩

⑤ POWER: Press and hold

to turn on or off the device.

⑥ ENTER: Confirm selection
⑦ ESC: Return to the

previous screen.

⑧ UP: Go to the previous


⑨ DOWN: Go to the next


⑩ MODE: Start slide show

Charge the battery

The device features built-in rechargeable battery for portable use. It may take 3 hours to fully

charge it, and each full charge can be used continuously for about 2.5 hours.

You can charge the battery by either of:
z Connecting to AC Adaptor

(1) Connect the AC adaptor and the device with the USB cable.

(2) Insert the AC adaptor to an electronic socket.

- 5 -

z Connecting to Computer

Connect it to a computer through the provided USB cable. The battery is charged once the

connection is successful.

Select to download

files from computer.

Select to see the

charging progress.

If you want to see the charging progress, press the UP/DOWN button to select the option at the
right and then press the ENTER button to confirm. You should see an animating battery icon at the

top right corner. The icon should stop animating once the charge is full.

Transfer files between computer and the device

z Download photos from computer to the device

The device has built-in memory for the storing images. With the Photo Manager, you can transfer

- 6 -
