MA968 operation manual
Customer Service Number: 1.800.938.9886
Website: www.nextar.com
Catalogue
Warning and Cautions
Product illustration and accessories
Function introduction
Connect MP3 player to PC
LED Mode
How to charge the battery of the MP3 player
Installation procedure of WIN98 driver
Battery life
Technical parameters
2
3
4
5
5
6
6
6
7
Warning & Cautions
Do not use the mp3 player in hot, cold, dusty and humid environments.
Do not drop the player, or expose to direct sunlight, other source of heat for a long
period of time.
Please charge the mp3 player when it has the following instance:
The Red and Green LED blinks continuously.
The mp3 player turns off automatically.
It does not work when you press any buttons.
Do not disconnect the device suddenly when it is being formatted or during
uploading and downloading. Otherwise there may be errors occurring in the software.
Do not attempt to service the unit.
When the Red and Green LED blinks alternately during the "play" mode, it is a
indication of low battery and the player will be automatically power off after another
five to ten minutes of play.
- 2 -
1. Product illustration and accessories:
A. Illustration:
Volume(Previous song)
B. Accessories:
Dual wire of data and charge
Volume+
(Next song)
Driver CD
-
V
O
L
+
On/Off
EQ
EQ
Dual Jack of Data and Charge
Sponge Cover
User's Manual
- 3 -
Definition of button function:
* Press Shortly PS press the button 1 second
* Press and Hold PH press the button 2 seconds
For example "On/Off button".
2. Function introduction:
A. On/Off Button: Power On, Play, Pause and Power Off
Power On: To turn on the unit PH the "On/Off button" for about 3 seconds and the
Green LED will come on, now the unit is in the "idle" mode. Then PS the On/Off button
again to enter "play" mode. The Green LED will keep blinking continueously during
"Play" mode.
Pause: Press the "On/Off " button during the "Play" mode, the player will enter
"Pause" mode. By press the button again the player will revert back to "Play" mode.
Power Off: PH the "On/Off "button to switch off. The unit will automatically power off
after 30 seconds.
B. EQ Button: Effect adjustment
PS the "EQ" button during the play mode to select different music mode, it will
change from one to the next: Normal, Rock, POP, Classic, Soft, Jazz, Dbb.
Note: The EQ function can only be judged from the sounds.
C. Volume+, Volume-: Select the songs and adjust the voice
PS the "Volume+, Volume-" in "play" mode to shift from the previous and next song
PH the button to turn up or down the volume when it is in "play" mode.
- 4 -
3. Connect MP3 Player to PC:
Connect the mp3 player to the PC via the USB cable, the red and green LED is
constantly on. The Green LED will be constantly on and when the Red LED blinks it is
indicating transferring the data.
Download and Delete files: After connecting the MP3 Player to PC, click "My
Computer" to find "Portable Disc" and then drag or copy the files that you want to
download or upload to the required folder.
This MP3 Player can also store many other files and be used as a portable memory
device.
4. LED Mode:
Mode
Playing Mode
Low battery Mode
Charging battery
(USB Mode)
Fully Charged
(USB Mode)
No File For Playing
Transferring Data
Red LED
0.5 second blinks alternately (blinks 0.5 seconds per each time)
Blinks according to the speeds
of transferring
Off
Constantly on
Off
LED Mode
Green LED
Blinks 1 second per each time
Constantly onConstantly on
Off
0.5 seconds blinks per each time
and switch off after 3 times
Constantly on
- 5 -
5. How to charge the battery of the MP3 Player:
a. When the MP3 Player is connected to PC, the Red and Green LED will be constantly
on. When the Green LED will be off and red LED is blinks constantly the charge is
completed.
b. The MP3 Player should be fully charged every time so as to extend the battery life
and the playing time of the MP3 Player.
c. Transfer of data can be carried out during charging of the MP3 Player.
6. Installation procedure of WIN98 driver:
If the operating system of your PC is or older than WIN98, please install the driver
using the following procedures:
Put the CD-ROM in the CD driver and double click to open the CD-ROM. Choose MP3
Driver/setup.
7. Battery life:
Please pull out the power cable after the battery is fully charged so as to extend
the battery life and playing time.
- 6 -
8. Technical parameters:
Music Format:
Port Mode:
EQ Mode:
Playing time:
Battery Voltage:
Output Power:
Headphone Output Power:
Frequency Response:
Battery Charge Time:
Working Current:
Capacity of the memory: 64M-1G(inside)
Info/noise ratio:
Dimensions:
Headphone Impedance:
MP1/MPMP2/MP3/WMA/WAV/ASF/WMV
USB 2.0 Protocol. (FS)
POP, Classic, Soft, Jazz, Dbb, Rock, Normal
Can continuously play music for about 350-400
minutes after fully charged.
3.7V Rechargeable Li-Ion Battery.
55mw.
5 mw.
20Hz - 20Khz.
About 3 Hours
35-40 mA
86dB
43mm*12mm
16 *2
