Next KUBIX User Manual

V201609

Time Coherent Systems

USER MANUAL

NEXT Series - User Manual

www.next-proaudio.com

- 1 -

CONTENTS

INTRODUCTION - 2 -

UNPACKING - 2 -

KUBIX SERIES OVERVIEW - 2 -

SAFETY FIRST - 3 -

RIGGING AND SUSPENSION SAFETY CONSIDERATIONS - 4 -

KUBIX FAMILY - 5 -

PASSIVE SPEAKERS - 6 -

K5 / K5+ - 6 -

K8 / K12 - 6 -

ACTIVE SPEAKERS - 7 -

K8A/K12A/K10sA POWER MODULE AND DSP - 7 -

K12sA POWER MODULE AND DSP - 8 -

AMPLIFIER BLOCK DIAGRAMS - 9 -

KUBIX ACCESSORIES - 10 -

KUBIX APPLICATION EXAMPLES - 11 -

STANDALONE - 11 -

SUBWOOFER + SATELLITE - 12 -

POWER CABLE SELECTING - 13 -

TROUBLESHOOTING - 13 -

K5(+) / K8(A) / K12(A) – Disassembly procedure - 14 -

K10s(A) / K12s(A) – Disassembly procedure - 14 -

TECHNICAL SPECIFICATIONS - 15 -

K5/K5+ - 15 -

K8/K8A - 16 -

K12/K12A - 17 -

K10s/K10sA - 18 -

K12s/K12sA - 19 -

WARRANTY - 20 -

CONTACTS - 21 -

NEXT Series - User Manual

www.next-proaudio.com

- 2 -

V201609

INTRODUCTION

Thank you for purchasing a NEXT-proaudio KUBIX loudspeaker system. The NEXT-proaudio
KUBIX series has been designed to cover almost all install applications such as nightclubs, bars,
restaurants, convention centres, hotels, museums and houses of worship in an extreme-compact
enclosure. Thanks to the coaxial loudspeaker mounting, is possible to have a time coherent system
response throughout the venue. With KUBIX series, the NEXT-proaudio’s engineering team, developed
the most powerful and compact series providing high performance and sound fidelity. This manual
will provide you with useful and important information about your KUBIX element. Please devote some
time reading this manual, and keep it at hand for future reference. NEXT-proaudio is concerned with
your safety and well-being, so please follow all instructions and heed all warnings. Also, a better
understanding of some specific features of the KUBIX series will help you to operate it to its full
potential. With a continuous evolution of techniques and standards, NEXT-proaudio, reserves the right
to change the specifications of its products without early warning. For the most current data, please
visit our website: www.next-proaudio.com

UNPACKING

NEXT-proaudio KUBIX Series are built in Europe (Portugal) by NEXT-proaudio, according to the
highest quality standards and thoroughly inspected before they leave the factory. When unpacking
your KUBIX unit, please examine it carefully for any signs of possible transit damage and inform your
dealer immediately if any such damage has occurred.

It is suggested that you retain the original packaging so that the speaker can be repacked in
the future if necessary. Please note that NEXT-proaudio and its authorized distributors cannot accept
any responsibility for damage to any returned product through the use of non-approved packaging.

When the product has reached the end of its useful life, please dispose of it responsibly through
a recycling centre.

KUBIX SERIES OVERVIEW

NEXT-proaudio engineered the new KUBIX series of self-powered and passive speaker
cabinets, specifically for installations, musicians and DJs who want the state-of-the-art in acoustics
and electronics. The family currently consists of three full-range cabinets, with drivers comprehended
between 5” and 12”. The coaxial full-range models are complemented by two high-performance
subwoofers of 10” and 12” – all elements are available in active and passive versions.

This speaker line employs premium-quality lightweight plywood with an hardening, durable,
and scratch-resistant coating. The KUBIX range of loudspeakers use two-way, full-range, coaxial
drivers. The active enclosures are powered by integrated, lightweight Class-D or Class AB audio
amplifiers with DSP, specially engineered to provide high impact, balanced, rich and transparent
sound at any volume. The passive enclosures are fitted with a very accurate and optimised crossover
for the best frequency and phase response. This series is made up of speakers and subwoofers that
bind together forming the perfect combination. Several combinations of speakers and subwoofers can
be done in order to satisfy your needs. The active speakers feature a variety of factory presets that
allow you to use it like a plug n’ play perfect solution for any kind of venue.

NEXT Series - User Manual

www.next-proaudio.com

- 3 -

SAFETY FIRST

Please pay close attention to this chapter. Failure to comply with these instructions may
result on injury or death.

NEXT-proaudio KUBIX systems are capable of producing extremely high

sound pressure levels and should be used with care. Hearing loss is
cumulative and can result from levels above 90dB if people are exposed for
a long period. Never stand close to loudspeakers driven at high levels.

DANGER – HEARING DAMAGE

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER

NO USER SERVICEABLE PARTS INSIDE

REFER SERVICE TO QUALIFIED PERSONNEL

NEXT Series - User Manual

www.next-proaudio.com

- 4 -

V201609

• Do not use your KUBIX unit near any sources of water, like swimming pools, lakes, water

streams, exposed to rain, high humidity environments or any other source of water or moisture.

• Use only a soft dry cloth to clean your KUBIX unit.

• Never place your KUBIX unit in a way that prevents air flow near the amplifier. A minimum

clearance distance of 6cm (2.5 in) should be kept between the amplifier and any near surface.

• Never use your KUBIX unit too close to any heat source, such as radiators, or any other device

that produces heat.

• Place cables in a way that they do not present a trip hazard.

• Do not place any objects on top of the stack, they can fall accidentally and cause injuries.

• Do not attempt to move the enclosures while connected.

• Do not attempt to service the KUBIX unit beyond what is described in this manual. All other

service or repair of this product should be carried only by qualified personnel.

• To prevent electric shock, do not use any extension cord, receptacle or other outlets where the

blades of the connectors cannot be fully inserted.

• Precautions should be taken to prevent grounding failure or polarity switch.

• It is advised to unplug the KUBIX unit during storms or when not in use for a long period of

time.

RIGGING AND SUSPENSION SAFETY CONSIDERATIONS

KUBIX Series enclosures were designed for installation applications; it means that can be suspended
by aid of the threaded inserts provided or using the recommended brackets. These enclosures are
internally fitted with steel corner reinforcement brackets to ensure that each cabinet is strong enough
to be hung from its top.

• Before rigging or suspending NEXT-proaudio KUBIX systems, inspect all components

and all hardware for any signs of damage or missing parts. If you find any damaged,
corroded or deformed parts, do not use them, replace them immediately.

• Do not use hardware that isn’t load rated or that its rating is not enough to handle the

system’s weight with a good safety factor (minimum 4:1).

• Suspended systems installation should only be carried out by qualified personnel.

• Always use adequate protective clothing and equipment to prevent possible injuries.

• Be sure you understand all local and national regulations regarding equipment

installation.

NEXT Series - User Manual

www.next-proaudio.com

- 5 -

KUBIX FAMILY

Model

Spk.

Size

Freq. Resp. Dispersion Power

K5/K5+ 5”

70Hz/100Hz

to 18kHz

80º Conical 200W

K8(A) 8”

59Hz to

18kHz

100º Conical 500W

K12(A) 12”

44Hz to

18kHz

80º Conical 700W

K10s(A) 10”

37Hz to

500Hz

Omnidirectional 500W

K12s(A) 12”

38Hz to

500Hz

Omnidirectional 1400W

NEXT Series - User Manual

www.next-proaudio.com

- 6 -

V201609

PASSIVE SPEAKERS

K5 / K5+

K5 is the smallest cabinet of KUBIX family. Available in two different passive versions, K5 and
K5+, are the best solutions for small venues such as conference rooms, theatres, museums and
restaurants. The K5 model is a full-range loudspeaker with a low frequency response beyond the
70Hz. The K5+ is a similar cabinet to K5 with higher sensitivity and a frequency response above
110Hz. In order to complement the audible spectrum, NEXT-proaudio highly recommends to use this
cabinet with a KUBIX series subwoofer. On the image below is represented the K5(+)’s rear panel.

K8 / K12

K8 and K12 are passive full-range loudspeakers with an incredible frequency response even
at low frequencies. Thanks to its advanced built-in crossover filter, the loudspeakers can be plugged
in directly to a power amplifier without any digital processing. However, NEXT-proaudio recommends
the use of a digital signal processor (LMS242 or DP240) for an optimal system response according
to the venue and the playback content. Because of being a coaxial loudspeaker, that avoids
interferences between the LF driver and the HF driver, it can be the perfect solution for DJ monitoring,
drum fills, and also small venues where the listener is located near to the sound source. On the image
below is represented the K8’s rear panel. The K12’s rear panel is similar to this one.

NEXT Series - User Manual

www.next-proaudio.com

- 7 -

ACTIVE SPEAKERS

All the KUBIX series cabinets were designed to achieve a simple to use and deploy versatile
system. The ACTIVE units belonging to this series are qualified to be completely plug n’ play, featuring
a power amplifier with DSP.

K8A/K12A/K10sA POWER MODULE AND
DSP

Here is a brief description of the amplifier panel:

1- Signal Input/Output
2- Level Adjustment Potentiometer
3- Preset Selector
4- RS485 Communication Interface
5- List of Available Presets
6- AC Mains Power Input/Output
7- Power On/Off Switch

NEXT-proaudio chose a 2 Channel Switched Mode Class AB
amplifier with DSP to power K8A, K12A and K10sA. On K8A
and K12A models the amplifier delivers 400W to the woofer
and 100W to the high frequency driver. The K10sA model
has a satellite output (Neutrik NL4) with 100W keeping 400W
to power its own 10” low frequency driver at maximum
efficiency.

1

2

3

4
5

6

7

Never operate the KUBIX series

Speakers in a way that maintains the
Limiter Led consistently on.

Full-Range Speakers Preset List (K8A/K12A):

0- Flat: Flat frequency response
1- Flat (HP 80Hz): Flat frequency response with High-pass filter at 80Hz 24dB/Oct Linkwitz-Riley
2- Music: Frequency response adapted for music reproduction (SPL level boosted at low frequencies and ear
compensation, due to high SPL levels, at the mid-high frequency range)
3- Music (HP 80Hz): Frequency response adapted for music reproduction High-pass filter at 80Hz 24dB/Oct
Linkwitz-Riley
4- Vocal: Frequency response adapted for voice speech. (High Pass Filter at 90Hz and EQing for an improved
intelligibility)
5- Loudness: Is a setting, intended to be used at low listening levels, that increases the level of the high and
low frequencies compensating the ear’s low sensitivity
6 / 7- User Defined: Free memory for user storage

NEXT Series - User Manual

www.next-proaudio.com

- 8 -

V201609

K12sA POWER MODULE AND DSP

1- Signal Input/Output
2- Level Adjustment Potentiometer
3- Preset Selector
4- RS485 Communication Interface
5- List of Available Presets

6- Satellite Output
7- AC Mains Power Input/Output
8- Protection Circuit Breaker
9- Power On/Off Switch

Capable of delivering very high power, the K12sA, is equipped with a 2 Channel Switched Mode
Class D amplifier with DSP. Internally bridged, 2 channel of 550W each, play an extraordinary power
performance when powering the 12” low frequency driver with 1100W. Thanks to a satellite output
with 550W, located on the amplifier’s panel, it is possible to easily connect an external passive
speaker, or group of speakers, as long as the minimum total impedance doesn’t reach below 4Ω.
When connected to the computer, with SOUNDWARE software, the user can easily control the output
satellite volume and delay and equalize the input channel.

Subwoofers Preset List (K10sA/K12sA):

0- Deep (LP80Hz): Low-pass filter at 80Hz 24dB/Oct Linkwitz-Riley
1- Punch (LP100Hz): Low-pass filter at 100Hz 24dB/Oct Linkwitz-Riley
2- Extended (LP120Hz): Low-pass filter at 120Hz 24dB/Oct Linkwitz-Riley
3- No LP: No Low-pass filter used (can be defined by user)
4- Sub+Satellite (Flat): Flat frequency response with the satellite designated on “Programmed Satellite” label
5- Sub+Satellite (Music): Frequency response adapted for music reproduction with the satellite designated on
“Programmed Satellite” label (Ear compensation, due to high SPL levels, at the mid-high frequency range)
6 / 7- User Defined: Free memory for user storage (OUTPUT is muted by default)

7 8 9 5 4 3 2 1 6

Never operate the KUBIX series

Speakers in a way that maintains the
Limiter Led consistently on.

NEXT Series - User Manual

www.next-proaudio.com

- 9 -

AMPLIFIER BLOCK DIAGRAMS

K8A/K12A/K10sA Amplifier Block Diagram

K12sA Amplifier Block Diagram

NEXT Series - User Manual

www.next-proaudio.com

- 10 -

V201609

KUBIX ACCESSORIES

U-Bracket

Wall/Ceiling/Floor/Mic

Stand Mounting

K5/K5+

Adjustable Wall

Bracket

Wall/Ceiling Mounting K5/K5+

Corner Fixer for
Adjustable Wall

Bracket

Corner Mounting K5/K5+

U-Bracket Wall/Ceiling Mounting K8/K8A

U-Bracket Wall/Ceiling Mounting K12/K12A

1

2 3 4

4

NEXT Series - User Manual

www.next-proaudio.com

- 11 -

KUBIX APPLICATION EXAMPLES

STANDALONE

The KUBIX installation series provides a wide range of accessories for standalone applications.
In the picture above are represented the different kind of wall mounting systems available; the
speakers can be used either on horizontal or vertical orientation. All the KUBIX series cabinets are
also ready to be suspended by mean of chains, only replacing the screw for an eye bolt. In the picture
below are described the U-Bracket applications on a microphone stand or directly on the floor.

2

4 3 1

1

NEXT Series - User Manual

www.next-proaudio.com

- 12 -

V201609

SUBWOOFER + SATELLITE

Able to deliver an extremely high output and dynamics for its size, K5, is one of the best
solutions for small venues. When used with the K10sA or K12Sa, active subwoofers, it becomes the
perfect solution for any kind of audio reinforcement and reproduction. K10sA can power 1 x K5(+)
and K12sA can power up to 2 x K5(+). The K12sA operating with K8 can be the perfect solution for
medium venues where the high SPL with sound clarity is needed.

It is also possible to operate the KUBIX series with other NEXT-proaudio models. On the image
above is represented an HFA115s, from HFA Series, powering a K12. By simply laying the speaker
on the top of the subwoofer it will automatically set a 15º angle that perfectly aligns the listener ears
with the centre of the sound source for the best listening experience. This set up can be used as an
excellent DJ monitoring or as a perfect drum fill for the most exigent drummers.

NEXT Series - User Manual

www.next-proaudio.com

- 13 -

POWER CABLE SELECTING

Selecting a cable consists of calculating the correct cable section (size) in relation to the load
impedance and the required cable length. A small cable section will increase its serial resistance,
which will induce power-loss and response variations (damping factor).

The following table indicates, for 3 common sizes, a cable length with a maximum serial
resistance equal to 4% of the load impedance (damping factor = 25):

Cable section

Maximum Length related to load impedance

8Ω

4Ω

1.5 mm²

12 m [40 ft]

6 m [20 ft]

2.5 mm²

20 m [64 ft]

10 m [32 ft]

4 mm²

32 m [104 ft]

16 m [52 ft]

TROUBLESHOOTING

Simple troubleshooting does not require sophisticated measurement equipment and can be
easily undertaken by users. The technique should be to segment the system in order to identify the
faulty system component: signal source, controller, amplifier, loudspeaker or cable? Most installations
are multi-channel. It is often the case that one channel works and others do not. Trying different
combinations of system elements can usually help to isolate and locate the fault.

Some cabinet faults can be quite easily identified and corrected by the user. A simple sweep with
a sine wave generator can be very helpful though it MUST be made at a fairly low level to prevent
damage to the speakers. A sine wave sweep can help find:

• Vibrations due to loose screws.

• Air-leak noises: check that no screws are missing, particularly where the accessories attach

to the cabinet.

• Vibrations due to a front grille badly positioned on the quick release fixings.

• Foreign object that has fallen into the cabinet after repair or through the ports.

• Internal connection wires or absorbing material touching the loudspeaker diaphragm: check

by removing the bass loudspeaker.

• Loudspeaker not connected or phase reversed following a previous inspection, test or repair.

In case of excessive heat (self-powered versions), due to a fan malfunction, the amplifier will
decrease the output power in order to cool. The amplifier will not stop working. This operation mode
is signed with blinking of LIMIT/PROT led.

If you need to disassemble any of this series loudspeaker, please follow the disassembly
procedure described below. Do not attempt to service the KUBIX unit beyond what is described in this
manual. All other service or repair of this product should be carried only by qualified personnel.

NEXT Series - User Manual

www.next-proaudio.com

- 14 -

V201609

K5(+) / K8(A) / K12(A) – Disassembly procedure

Pre-requisite: 4mm hex bit

1. Carefully remove the front grille by simply pulling it from the enclosure, exposing the loudspeaker

2. Remove the loudspeaker’s screws with help of the hex bit

3. Remove the loudspeaker and disconnect the LF and HF cables

K10s(A) / K12s(A) – Disassembly procedure

Pre-requisite: Phillips screwdriver, 4mm hex bit

1. Remove the rear panel or amplifier’s screws using a Phillips screwdriver

2. Carefully remove the amplifier module from the enclosure and disconnect the power connector on
the back. In case of being the passive version just remove the rear panel and disconnect the cables
from the loudspeaker

3. On the ACTIVE version there is a vibrancy isolation box that must be disassembled unscrewing 4
screws using a Phillips screwdriver; Remove the 2 pieces of the anti-vibrancy box door

4. Remove the loudspeaker’s screws (from the inside) with help of the hex bit

5. Remove the loudspeaker

NEXT Series - User Manual

www.next-proaudio.com

- 15 -

TECHNICAL SPECIFICATIONS

K5/K5+

TECHNICAL
SPECIFICATIONS

K5 K5+

Speaker Type

Passive Coaxial Reflex Speaker

Frequency Response (-6dB)

112Hz - 18.000Hz

150Hz – 18.000Hz

Low Frequency Extension (-10dB)

70Hz

100Hz

Sensitivity (1W@1m)

91dB (Full-Space)

93dB (Full-Space)

Recommended HPF.

65Hz 125Hz

Calculated Max. SPL (Cont./Peak)

114dB / 117dB (Full-Space) 116dB / 119dB (Full-Space)

Components

LF: 1 x 5” / 1.7” Voice Coil B&C Custom Speaker

HF: 1 x 1” / 1” Voice Coil Custom B&C Compression Driver

Directivity (-6dB)

80º Conical

Program Power

200W

Nominal Impedance

8Ω

Recommended Amplifier

MA900

Construction

10mm Multi-laminate Birch Plywood, Screwed and Glued

Finish

Black Textured Scratch Resistant Paint (also available in other colours

and finishing)

Grille

Perforated Steel with Acoustically Transparent Fabric

Connectors

2 x Neutrik NL4 ; 2 x Screw Terminal

Dimensions (W x H x D)

170 x 170 x 187 mm (6.69 x 6.69 x 7.36 in)

Net Weight

3.3 kg (7.28 lb)

NEXT Series - User Manual

www.next-proaudio.com

- 16 -

V201609

K8/K8A

TECHNICAL
SPECIFICATIONS

K8 K8A

Speaker Type

Passive Coaxial Reflex Speaker ACTIVE Coaxial Reflex Speaker

Frequency Response (-6dB)

67Hz – 18.000Hz 67Hz – 18.000Hz

Low Frequency Extension (-10dB)

59Hz 59Hz

Sensitivity (1W@1m)

96dB (Full-Space)

Recommended HPF.

56Hz

Calculated Max. SPL (Cont./Peak)

123dB / 126dB (Full-Space) 122dB / 125dB (Full-Space)

Components

LF: 1 x 8” / 2” Voice Coil B&C Custom Speaker

HF: 1 x 1” / 1.7” Voice Coil B&C Custom Compression Driver

Directivity (-6dB)

100º Conical

Program Power

500W

Nominal Impedance

8Ω

Recommended Amplifier

MA1700

Amplifier Technology
LF Power (RMS)
HF Power (RMS)

2 Channel Switched Mode Class

AB with DSP (500W)

400W

100W

Construction

15mm Plywood, Screwed and Glued

Finish

Black Textured Scratch Resistant Paint (also available in other colours

and finishing)

Grille

Perforated Steel with Acoustically Transparent Fabric

Connectors

2 x Neutrik NL4

Signal: 2 x XLR

Power: 2 x PowerCON

Data: 2 x RJ45

Dimensions (W x H x D)

397 x 264 x 281 mm (15.63 x 10.39 x 11.06 in)

Net Weight

10.8 kg (23.81 lb) 12.2 kg (26.9 lb)

NEXT Series - User Manual

www.next-proaudio.com

- 17 -

K12/K12A

TECHNICAL
SPECIFICATIONS

K12 K12A

Speaker Type

Passive Coaxial Reflex Speaker ACTIVE Coaxial Reflex Speaker

Frequency Response (-6dB)

53Hz – 18.000Hz 53Hz – 18.000Hz

Low Frequency Extension (-10dB)

44Hz 44Hz

Sensitivity (1W@1m)

98dB (Full-Space)

Recommended HPF.

44Hz

Calculated Max. SPL (Cont./Peak)

126.5dB / 129.5dB (Full-Space) 124dB / 127dB (Full-Space)

Components

LF: 1 x 12” / 3” Voice Coil B&C Custom Speaker

HF: 1 x 1.4” / 3” Voice Coil B&C Custom Compression Driver

Directivity (-6dB)

80º Conical

Program Power

700W

Nominal Impedance

8Ω

Recommended Amplifier

MA3200

Amplifier Technology
LF Power (RMS)
HF Power (RMS)

2 Channel Switched Mode Class

AB with DSP (500W)

400W

100W

Construction

15mm Plywood, Screwed and Glued

Finish

Black Textured Scratch Resistant Paint (also available in other colours

and finishing)

Grille

Perforated Steel with Acoustically Transparent Fabric

Connectors

2 x Neutrik NL4

Signal: 2 x XLR

Power: 2 x PowerCON

Data: 2 x RJ45

Dimensions (W x H x D)

450 x 354 x 361 mm (17.72 x 13.94 x 14.21 in)

Net Weight

15.6 kg (34.39 lb) 17.2 kg (37.92 lb)

NEXT Series - User Manual

www.next-proaudio.com

- 18 -

V201609

K10s/K10sA

TECHNICAL
SPECIFICATIONS

K10s K10sA

Speaker Type

Passive Reflex Subwoofer ACTIVE Reflex Subwoofer

Frequency Response (-6dB)

44Hz – 500Hz 44Hz – X-Over

Low Frequency Extension (-10dB)

37Hz 37Hz

Sensitivity (1W@1m)

99dB (Half-Space)

Recommended HPF.

34Hz

Calculated Max. SPL (Cont./Peak)

126dB / 129dB (Half-Space) 125dB / 128dB (Half-Space)

Components

LF: 1 x 10” / 2.5” Voice Coil Long Excursion Custom Speaker

Program Power

500W

Nominal Impedance

8Ω

Recommended Amplifier

MA2300

Amplifier Technology

2 Channel Switched Mode Class

AB with DSP (500W)

Power to Int. Speaker (Sub)

(RMS)

400W

Power to Ext. Speaker (Sat)

(RMS)

100W

Construction

15mm Plywood, Screwed and Glued

Finish

Black Textured Scratch Resistant Paint (also available in other colours

and finishing)

Grille

Perforated Steel with Acoustically Transparent Fabric

Connectors

2 x Neutrik NL4

Signal: 2 x XLR

Power: 2 x PowerCON

Sat. Output: 1 x Neutrik NL4

Data: 2 x RJ45

Dimensions (W x H x D)

350 x 436 x 389 mm (13.78 x 17.17 x 15.31 in)

Net Weight

12.9 kg (28.44 lb) 15.9 kg (35.05 lb)

NEXT Series - User Manual

www.next-proaudio.com

- 19 -

K12s/K12sA

TECHNICAL
SPECIFICATIONS

K12s K12sA

Speaker Type

Passive Reflex Subwoofer ACTIVE Reflex Subwoofer

Frequency Response (-6dB)

43Hz – 500Hz 43Hz – X-Over

Low Frequency Extension (-10dB)

38Hz 38Hz

Sensitivity (1W@1m)

101dB (Half-Space)

Recommended HPF.

42Hz

Calculated Max. SPL (Cont./Peak)

132.5dB / 135.5dB (Half-Space) 131.5dB / 134.5dB (Half-Space)

Components

LF: 1 x 12” / 3.5” VC Neodymium Long Excursion B&C Custom Speaker

Program Power

1400W

Nominal Impedance

8Ω

Recommended Amplifier

MA6000

Amplifier Technology

2 Channel Switched Mode Class D

with DSP (1650W)

Power to Int. Speaker (Sub)

(RMS)

1000W

Power to Ext. Speaker (4Ω Sat)

(RMS)

550W

Construction

15mm Plywood, Screwed and Glued

Finish

Black Textured Scratch Resistant Paint (also available in other colours

and finishing)

Grille

Perforated Steel with Acoustically Transparent Fabric

Connectors

2 x Neutrik NL4

Signal: 2 x XLR

Power: 2 x PowerCON

Sat. Output: 1 x Neutrik NL4

Data: 2 x RJ45

Dimensions (W x H x D)

490 x 436 x 370 mm (19.29 x 17.17 x 15.31 in)

Net Weight

18.1 kg (39.9 lb) 22 kg (48.5 lb)

NEXT Series - User Manual

www.next-proaudio.com

- 20 -

V201609

WARRANTY

NEXT-proaudio’s products are warranted, by NEXT-proaudio, against manufacturing defects
in materials or craftsmanship over a period of 5 years for the passive loudspeakers, and 2 years for
all other products counting from the date of original purchase. The original receipt of purchase is
mandatory for warranty validation purposes, and the product must have been bought from a NEXT­proaudio authorized dealer.

The warranty can be transferred to a subsequent owner during the warranty period; however,
this cannot extend the warranty period beyond the original warranty period of five years from the
original date of purchase stated on the NEXT-proaudio’s invoice.

During the warranty period NEXT-proaudio will, at its own discretion, either repair or replace
a product which prove to be defective provided that the product is returned in its original packaging,
shipping prepaid, to an authorized NEXT-proaudio service agent or distributor.

NEXT-proaudio cannot be held responsible for defects caused by unauthorized modifications,
improper use, negligence, exposure to inclement weather conditions, act of God or accident, or any
use of this product that is not in accordance with the instructions provided by this manual and/or
NEXT-proaudio. NEXT-proaudio is not liable for consequential damages.

This warranty is exclusive and no other warranty is expressed or implied. This warranty does
not affect your statutory rights.

NEXT Series - User Manual

www.next-proaudio.com

- 21 -

CONTACTS

In case of any doubts or any information just:

Write us:
NEXT-proaudio
Rua da Venda Nova, 295
4435-469 Rio Tinto
Portugal

Contact us:
Tel. [phone]
Fax. [phone]

Send an e-mail:
[e-mail]

Search our website:
www.next-proaudio.com

Follow us on:

Facebook: facebook.com/nextproaudio
Instagram: instagram.com/nextproaudio
LinkedIn: linkedin.com/company/next-proaudio
Twitter: twitter.com/next_proaudio
Youtube: youtube.com/user/NEXTmanufacturer
