NEXCOM EBC 353 User Manual

NEXCOM International Co., Ltd.

Industrial Computing Solutions

Embedded Computing (3.5” CPU Board) EBC 353

User Manual

NEXCOM International Co., Ltd.

Published May 2012

www.nexcom.com

Content

Contents

Preface

Copyright ............................................................................................. iv

Disclaimer .............................................................................................. iv

Acknowledgements ............................................................................... iv

Regulatory Compliance Statements ........................................................ iv

Declaration of Conformity ...................................................................... iv

RoHS Compliance ................................................................................... v

Warranty and RMA ................................................................................ vi

Safety Information ................................................................................viii

Installation Recommendations ...............................................................viii

Safety Precautions .................................................................................. ix

Technical Support and Assistance ............................................................ x

Conventions Used in this Manual ............................................................ x

Global Service Contact Information ........................................................ xi

Package Contents ................................................................................. xiv

Ordering Information .............................................................................xv

Chapter 1: Product Introduction

Overview ................................................................................................1

Key Features ...........................................................................................1

Hardware Specifications ..........................................................................2

Knowing Your EBC 353 ..........................................................................4

Chapter 2: Jumpers and Connectors

Before You Begin ....................................................................................5

Precautions ............................................................................................5

Jumper Settings ......................................................................................6

Locations of the Jumpers and Connectors ............................................... 7

Jumpers .................................................................................................. 8

CMOS Clear Select ..............................................................................8

Power Mode Select ..............................................................................8

LVDS Power Select .............................................................................. 9

Panel Backlight Control Mode .............................................................9

Connector Pin Definitions .....................................................................10

External I/O Interfaces ........................................................................ 10

DVI-I ..............................................................................................10

COM1 Serial Port ...........................................................................10

USB0/1 Ports .................................................................................. 11

LAN1 Port ......................................................................................11

LAN2 Port .....................................................................................12

Internal Connectors ........................................................................... 13

SMBus Connector ..........................................................................13

Reset Button Connector ................................................................. 13

Power Button Connector ................................................................14

Speaker-out Connector ..................................................................14

Mic-in Connector ........................................................................... 15

Line-out Connector ........................................................................ 15

LED Connector ............................................................................... 16

SATA DOM Power Connector ........................................................16

SIM Card External Connector .........................................................17

PS/2 Keyboard/Mouse Connector ...................................................17

ii

EBC 353 User Manual

GPIO Connector ............................................................................ 18

Battery Connector .......................................................................... 18

SATA1 Connector ...........................................................................19

SATA2 Connector ...........................................................................19

SATA Power Connector ..................................................................20

COM2 Connector ..........................................................................20

COM3 Connector ..........................................................................21

COM4 Connector ..........................................................................21

CPU Fan Connector ........................................................................22

USB2/3 JST Connector ....................................................................22

USB4/5 JST Connector ....................................................................23

ATX Power Output Connector ........................................................23

LVDS Backlight Connector .............................................................. 24

LVDS Connector ............................................................................. 24

Mini-PCIe Slot ................................................................................25

PCI Slot .......................................................................................... 26

Sim Card Holder .............................................................................27

Block Diagram .................................................................................28

Board Dimensions ...........................................................................29

Chapter 3: BIOS Setup

About BIOS Setup ................................................................................. 30

When to Configure the BIOS .................................................................30

Default Configuration ........................................................................... 31

Entering Setup ...................................................................................... 31

Legends ................................................................................................ 31

BIOS Setup Utility .................................................................................. 32

Main .................................................................................................32

Advanced .......................................................................................... 34

Chipset ..............................................................................................40

Boot .................................................................................................. 42

Security .............................................................................................43

Save & Exit ........................................................................................44

Appendix A: Watchdog Timer

WDT Programming Guide .....................................................................45

Appendix B: GPI/O Programming Guide ....................47

Preface

PrefaCe

Copyright

This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM International Co., Ltd.

Disclaimer

The information in this document is subject to change without prior notice and does not represent commitment from NEXCOM International Co., Ltd. However, users may update their knowledge of any product in use by constantly checking its manual posted on our website: http://www.nexcom.com. NEXCOM shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of any product, nor for any infringements upon the rights of third parties, which may result from such use. Any implied warranties of merchantability or fitness for any particular purpose is also disclaimed.

Acknowledgements

EBC 353 is a trademark of NEXCOM International Co., Ltd. All other product names mentioned herein are registered trademarks of their respective owners.

Regulatory Compliance Statements

This section provides the FCC compliance statement for Class B devices and describes how to keep the system CE compliant.

Declaration of Conformity

FCC

This equipment has been tested and verified to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential area (domestic environment) is likely to cause harmful interference, in which case the user will be required to correct the interference (take adequate measures) at their own expense.

CE

The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques.

iv

EBC 353 User Manual

Preface

RoHS Compliance

NEXCOM RoHS Environmental Policy and Status Update

This publication, including all photographs, illustrations and software, is protected under international copyright

laws, with all rights reserved. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM International Co., Ltd.

RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1% or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium (Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.

In order to meet the RoHS compliant directives, NEXCOM has established an engineering and manufacturing task force to implement the introduction of green products. The task force will ensure that we follow the standard NEXCOM development procedure and that all the new RoHS components and new manufacturing processes maintain the highest industry quality levels for which NEXCOM are renowned.

The model selection criteria will be based on market demand. Vendors and suppliers will ensure that all designed components will be RoHS compliant.

How to recognize NEXCOM RoHS Products?

For existing products where there are non-RoHS and RoHS versions, the suffix “(LF)” will be added to the compliant product name.

All new product models launched after January 2006 will be RoHS compliant. They will use the usual NEXCOM naming convention.

v

EBC 353 User Manual

Preface

Warranty and RMA

NEXCOM Warranty Period

NEXCOM manufactures products that are new or equivalent to new in accordance with industry standard. NEXCOM warrants that products will be free from defect in material and workmanship for 2 years, beginning on the date of invoice by NEXCOM. HCP series products (Blade Server) which are manufactured by NEXCOM are covered by a three year warranty period.

NEXCOM Return Merchandise Authorization (RMA)

▪ Customers shall enclose the “NEXCOM RMA Service Form” with the

returned packages.

▪ Customers must collect all the information about the problems

encountered and note anything abnormal or, print out any on-screen messages, and describe the problems on the “NEXCOM RMA Service Form” for the RMA number apply process.

▪ Customers can send back the faulty products with or without accessories

(manuals, cable, etc.) and any components from the card, such as CPU and RAM. If the components were suspected as part of the problems, please note clearly which components are included. Otherwise, NEXCOM is not responsible for the devices/parts.

▪ Customers are responsible for the safe packaging of defective products,

making sure it is durable enough to be resistant against further damage and deterioration during transportation. In case of damages occurred during transportation, the repair is treated as “Out of Warranty.”

▪ Any products returned by NEXCOM to other locations besides the

customers’ site will bear an extra charge and will be billed to the customer.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is basic diagnostic fee and another is component (product) fee.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is basic diagnostic fee and another is component (product) fee.

System Level

▪ Component fee: NEXCOM will only charge for main components such as

SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistor, capacitor.

▪ Items will be replaced with NEXCOM products if the original one cannot

be repaired. Ex: motherboard, power supply, etc.

▪ Replace with 3rd party products if needed.

▪ If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

Board Level

▪ Component fee: NEXCOM will only charge for main components, such

as SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistors, capacitors.

▪ If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

vi

EBC 353 User Manual

Preface

Warnings

Read and adhere to all warnings, cautions, and notices in this guide and the documentation supplied with the chassis, power supply, and accessory modules. If the instructions for the chassis and power supply are inconsistent with these instructions or the instructions for accessory modules, contact the supplier to find out how you can ensure that your computer meets safety and regulatory requirements.

Cautions

Electrostatic discharge (ESD) can damage system components. Do the described procedures only at an ESD workstation. If no such station is available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis.

vii

EBC 353 User Manual

Preface

Safety Information

Before installing and using the device, note the following precautions:

▪ Read all instructions carefully.

▪ Do not place the unit on an unstable surface, cart, or stand.

▪ Follow all warnings and cautions in this manual.

▪ When replacing parts, ensure that your service technician uses parts

specified by the manufacturer.

▪ Avoid using the system near water, in direct sunlight, or near a heating

device.

▪ The load of the system unit does not solely rely for support from the

rackmounts located on the sides. Firm support from the bottom is highly necessary in order to provide balance stability.

▪ The computer is provided with a battery-powered real-time clock circuit.

There is a danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

Installation Recommendations

Ensure you have a stable, clean working environment. Dust and dirt can get into components and cause a malfunction. Use containers to keep small components separated.

Adequate lighting and proper tools can prevent you from accidentally damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following:

▪ A Philips screwdriver

▪ A flat-tipped screwdriver

▪ A grounding strap

▪ An anti-static pad

Using your fingers can disconnect most of the connections. It is recommended that you do not use needle-nose pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

viii

EBC 353 User Manual

Preface

Safety Precautions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a

damp cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a stable surface during installation. Dropping it or

letting it fall may cause damage.

7. The openings on the enclosure are for air convection to protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting

the equipment to the power outlet.

9. Place the power cord in a way so that people will not step on it. Do not

place anything on top of the power cord. Use a power cord that has been approved for use with the product and that it matches the voltage and current marked on the product’s electrical range label. The voltage and current rating of the cord must be greater than the voltage and current rating marked on the product.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service personnel:

a. The power cord or plug is damaged. b. Liquid has penetrated into the equipment. c. The equipment has been exposed to moisture. d. The equipment does not work well, or you cannot get it to work

according to the user’s manual. e. The equipment has been dropped and damaged. f. The equipment has obvious signs of breakage.

15. Do not place heavy objects on the equipment.

16. The unit uses a three-wire ground cable which is equipped with a third pin to ground the unit and prevent electric shock. Do not defeat the purpose of this pin. If your outlet does not support this kind of plug, contact your electrician to replace your obsolete outlet.

17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

ix

EBC 353 User Manual

Preface

CAUTION!

Technical Support and Assistance

1. For the most updated information of NEXCOM products, visit NEXCOM’s website at www.nexcom.com.

2. For technical issues that require contacting our technical support team or sales representative, please have the following information ready before calling: – Product name and serial number – Detailed information of the peripheral devices – Detailed information of the installed software (operating system,

version, application software, etc.) – A complete description of the problem – The exact wordings of the error messages

Warning!

1. Handling the unit: carry the unit with both hands and handle it with care.

2. Maintenance: to keep the unit clean, use only approved cleaning products or clean with a dry cloth.

3. CompactFlash: Turn off the unit’s power before inserting or removing a CompactFlash storage card.

Conventions Used in this Manual

Warning: Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself when performing a task.

CAUTION!CAUTION!

Caution: Information to avoid damaging components or losing data.

Note: Provides additional information to complete a task easily.

x

EBC 353 User Manual

Preface

Global Service Contact Information

Headquarters Taiwan

15F, No. 920, Chung-Cheng Rd., ZhongHe District, New Taipei City, 23586, Taiwan, R.O.C. Tel: +886-2-8226-7786 Fax: +886-2-8226-7782 http://www.nexcom.com.tw

USA NEXCOM USA

3758 Spinnaker Court Fremont, CA, 94538, USA Tel: +1-510-656-2248 Fax: +1-510-656-2158 http://www.nexcom.com

France NEXCOM France

Z.I. des Amandiers, 17, Rue des entrepreneurs, 78420 Carrières sur Seine, France Tel: +33 (0)1 71 51 10 20 Fax: +33 (0)1 71 51 10 21 http://www.nexcom.eu

Germany NEXCOM GmbH

Leopoldstraße Business Centre, Leopoldstraße 244, 80807 Munich, Germany Tel: +49-89-208039-278 Fax: +49-89-208039-279 http://www.nexcom.eu

Italy NEXCOM ITALIA S.r.l

Via Gaudenzio Ferrari 29, 21047 Saronno (VA), Italia Tel: +39 02 9628 0333 Fax: +39 02 9619 8846 http://www.nexcom.eu

United Kingdom NEXCOM EUROPE

10 Vincent Avenue, Crownhill Business Centre, Milton Keynes, Buckinghamshire MK8 0AB, United Kingdom Tel: +44-1908-267121 Fax: +44-1908-262042 http://www.nexcom.eu

xi

EBC 353 User Manual

Preface

China NEXCOM China

2F, Block 4, Venus Plaza, Building 21, ZhongGuanCun Software Park, No. 8, Dongbeiwang West Road, Haidian District, Beijing, 100193, China Tel: +86-10-8282-5880 Fax: +86-10-8282-5955 http://www.nexcom.cn

China-Shanghai Office

Room 1505, Greenland He Chuang Building, No. 450 Caoyang Rd., Shanghai, 200062, China Tel: +86-21-6150-8008 Fax: +86-21-3251-6358 http://www.nexcom.cn

China-Nanjing Office

Hall C, Block 17, Tian Xing Cui Lang Building, No. 49 Yunnan North Rd., Nanjing, 210018, China Tel: +86-25-8315-3486 Fax: +86-25-8315-3489 http://www.nexcom.cn

China-Wuhan Office

1-C1804/1805, Mingze Liwan, No. 519 South Luoshi Rd., Hongshan District, Wuhan, 430070, China Tel: +86-27-8722-7400 Fax: +86-27-8722-7400 http://www.nexcom.cn

China-Chengdu Office

9F, Shuxiangxie,Xuefu Garden, No.12 Section 1, South Yihuan Rd., Chengdu, 610061,China Tel: +86-28-8523-0186 Fax: +86-28-8523-0186 http://www.nexcom.cn

China-Shenzhen Office

Western Room 708, Block 210, Tairan Industry & Trading Place, Futian Area, Shenzhen, 518040, China TEL: +86-755-833 7203 FAX: +86-755-833 7213 http://www.nexcom.cn

xii

EBC 353 User Manual

Preface

Japan NEXCOM Japan

9F, Tamachi Hara Bldg., 4-11-5, Shiba Minato-ku, Tokyo, 108-0014, Japan Tel: +81-3-5419-7830 Fax: +81-3-5419-7832 http://www.nexcom-jp.com

xiii

EBC 353 User Manual

Preface

Package Contents

Before continuing, verify that the EBC 353 package that you received is complete. Your package should have all the items listed in the following table.

EBC 353 Cable Kit (P/N: 10E00035302X0)

Item Part Number Name Description Qty

1 60233ATA73X00 SATA CABLE ACMELUX:19922413 STANDARD L:300mm 1

2 60233DVI18X00

3 60233PS203X00

4 60233PW148X00 SATA POWER CABLE BEST:901-0405-300R HOUSING 4P TO HOUSING 5P L:300mm 1 5 60233SIO62X00 COMFORT CABLE CP:NEX-110819-01 UL2651 #28x9C-DB9+TU1001-10 L:200mm 2

6 60233USB59X00 USB CABLE EDI:262082060204-RS

EBC 353/354 CPU Cooler (P/N: 10E00035301X0)

Item Part Number Name Description Qty

1 5044440090X00 (H) THERMAL PAD APUS: 3A2015001001500 15x10x1.5mm XR-PE 1 2 5050300435X00 CPU HEATSINK FOR EBC352 SHYUNG SHUHN 58x40x37mm 5800RPM 12V 2510 3PIN L:120mm 1

DVI CABLE DVI-I TO DVI-I&D-SUB EDI:2A1292250101-RS EBC563IO PS2 KB/MS CABLE EDI:201061080201-RS

DVI Y CABLE DVI-I TO DVI-I L:100mm&D-SUB L:105mm 1

PS2 TO JST 8PIN 2.54mm L:200mm+-10mm 1

DUAL PORT USB CON TO JST 6PIN 2.0mm L:200+10mm

1

xiv

EBC 353 User Manual

Preface

Ordering Information

The following information below provides ordering information for EBC 353.

EBC353-2550 (P/N: 10E00035303X0) RoHS Compliant

Low power Embedded Board with Intel® Atom™ D2550 processor and based on Intel® integrated graphics engine w/ VGA/ 18-bit LVDS/ 6x USB2.0/ 4x COMs/ 1x Mini-PCIe/ 2x Gigabit LAN/ 2x SATA/ 1x PCI-104

xv

EBC 353 User Manual

Chapter 1: Product Introduction

ChaPter 1: ProduCt IntroduCtIon

Overview

Key Features

▪ Onboard Intel® Atom™ processor D2550 1.86GHz CPU

▪ Intel® NM10 Express chipset

▪ One 204-pin SO-DIMM socket supports up to 4 GB DDR3 800/1066 MHz

SDRAM

▪ Display: VGA & DVI-D & LVDS (1x DF13 20-pin 18-bit Single channel)

▪ 1x Mini-PCIe

▪ 1x PCI-104

▪ 2x Intel 82574L PCI Express Gigabit Ethernet

▪ 2x SATA

▪ 6x USB, 4-in/4-out GPIO, Mic-in, Line-out, Speaker-out

▪ Serial port: 3x RS232, 1x RS232/422/485 port

▪ Support AT/ATX mode and Single +12V DC input

1

EBC 353 User Manual

Chapter 1: Product Introduction

Hardware Specifications

CPU Support

▪ Intel® Atom™ processor D2550 1.86GHz CPU

Main Memory

▪ One 204-pin SO-DIMM socket supports up to 4 GB DDR3 800/1066 MHz

SDRAM

Chipset

▪ Intel® NM10 Express chipset

BIOS

▪ AMI BIOS ▪ Plug & Play support ▪ Advanced Power Management ▪ Advanced Configuration & Power Interface ▪ 8M bits SPI ROM

On-board LAN

▪ 2x Intel® PCI Express Gigabit Ethernet ▪ Support Boot From LAN (PXE) ▪ 2x RJ45 with LED

Display

▪ Intel® Atom™ processor D2550 integrated 3D graphics engine, which

enhances Gfx & Video, support DX10.1, OpenGL 3.0, Full HD Decode (MPEG2,VC1,AVC,H.264), delivers sophisticated graphics for large display application, dual independent display support at graphics base frequency up to 640MHz, and provides a wealth of options for high-resolution displays

▪ Analog VGA interface

– 1x VGA within DVI-I connector – resolution up to 1920x1200 75Hz

▪ DVI interface

– 1x DVI-I connector – Resolution up to 1920x1200

▪ LVDS interface

– Single (24bit) LVDS panel, resolution up to 1440 x 900 DF13 20-pin

LVDS connector for internal connection

▪ CCFL interface

– 1x CCFL for LCD Panel Backlight Inverter (Analog/ PWM dimming

support)

Audio

▪ Realtek ALC886 CODEC for High Definition ▪ 1x Mic-in and 1x Line-out Pin header

Expansion

▪ 1x Mini-PCIe ▪ 1x PCI-104

2

EBC 353 User Manual

Chapter 1: Product Introduction

I/O Interface

▪ Serial port: 4 ports

– COM1 support RS232 with DB9 connector – COM2 support RS232/422/485 with 10-pin box connector – COM3,4 support RS232 with 10-pin box connector

▪ USB 2.0: 6 ports

– 2 ports edge connector

– 4 ports by 2.0mm JST connector ▪ 8 GPIO lines via header (GPI 0~3 and GPO0~3) TTL Level (0/5 V) ▪ On-board Power LED and HDD Active LED Pin Header ▪ 1x 4-pin fan connector (for CPU) ▪ 1x Keyboard/Mouse pin header ▪ On board Buzzer/SMBus2.0/Reset SW/On & Off switch button

Edge I/O Interface

▪ 1x DVI-I connector ▪ 1x COM1 support RS232 with DB9 connector ▪ 1x dual stack USB connector ▪ 2x RJ45 with LED connector

Watchdog Timer

▪ Watchdog timeout can be programmed by software from 1 second to

255 seconds, and from 1 minute to 255 minutes (Tolerance 15% under

room temperature of 25°C).

System Monitor

▪ Monitoring of 4 voltages and 2 temperatures ▪ 4 Voltage (Vcore, +12V , +3.3V , 5V) ▪ 2 Temperatures (CPU, System) ▪ 1 Fan Speed detection

On-board RTC

▪ On-chip RTC with battery backup ▪ 1x External Li-Ion battery

Power Input

▪ Support AT and ATX mode

Power Requirements

▪ Power requirement: +12V DC Input ▪ One 4-pin power connector

Dimensions

▪ 3.5” ECX form factor/146mm (L) x 105mm (W) (5.7”x4.1”)

Environment

▪ Operating temperatures: 0°C to 60°C ▪ Storage temperature: -20°C to 85°C ▪ Relative humidity: Operating 10% to 90%, non-condensing

Storage

▪ 2x SATA port

Certifications

▪ CE approval ▪ FCC Class A

3

EBC 353 User Manual

Chapter 1: Product Introduction

Knowing Your EBC 353

Intel® NM10

+12V DC Input

COM2

COM1CPU FAN

SIM Card Slot

SATA 2COM3

SATA DOM

K/B Mouse

Battery Connector

SIM Card External

GPIO CMOS

SMBus Reset

Power

AT/ATX Select

Speaker-out

Mic-in

Line-out

LED

DVI-I LVDS

LVDS Backlight

SATA Power

SATA 1 USB2/3

4

USB1

LAN1 LAN2

USB4/5

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

ChaPter 2: JumPers and ConneCtors

This chapter describes how to set the jumpers and connectors on the EBC 353 motherboard.

Before You Begin

▪ Ensure you have a stable, clean working environment. Dust and dirt can

get into components and cause a malfunction. Use containers to keep

small components separated.

▪ Adequate lighting and proper tools can prevent you from accidentally

damaging the internal components. Most of the procedures that follow

require only a few simple tools, including the following:

– A Philips screwdriver

– A flat-tipped screwdriver

– A set of jewelers screwdrivers

– A grounding strap

– An anti-static pad

▪ Using your fingers can disconnect most of the connections. It is

recommended that you do not use needle-nosed pliers to disconnect

connections as these can damage the soft metal or plastic parts of the

connectors.

▪ Before working on internal components, make sure that the power is off.

Ground yourself before touching any internal components, by touching

a metal object. Static electricity can damage many of the electronic

components. Humid environments tend to have less static electricity than

dry environments. A grounding strap is warranted whenever danger of static electricity exists.

Precautions

Computer components and electronic circuit boards can be damaged by discharges of static electricity. Working on computers that are still connected to a power supply can be extremely dangerous.

Follow the guidelines below to avoid damage to your computer or yourself:

▪ Always disconnect the unit from the power outlet whenever you are

working inside the case.

▪ If possible, wear a grounded wrist strap when you are working inside the

computer case. Alternatively, discharge any static electricity by touching the bare metal chassis of the unit case, or the bare metal body of any other grounded appliance.

▪ Hold electronic circuit boards by the edges only. Do not touch the

components on the board unless it is necessary to do so. Don’t flex or stress the circuit board.

▪ Leave all components inside the static-proof packaging that they shipped

with until they are ready for installation.

▪ Use correct screws and do not over tighten screws.

5

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

Jumper Settings

A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open.

Refer to the illustrations below for examples of what the 2-pin and 3-pin jumpers look like when they are short (on) and open (off).

Two-Pin Jumpers: Open (Left) and Short (Right)

Three-Pin Jumpers: Pins 1 and 2 are Short

3

2

1

3

2

6

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

Locations of the Jumpers and Connectors

The figure below shows the location of the jumpers and connectors.

J1 J2

U7

262524232221201918161413121110

272930

31

VER:B

BZ1

4

1

AL AK AJ AH AG AE AD AC AB AA Y W V T P N M L K J H G F E D C B A

9875432

1

J6

CN6

2

1

119

H1

U2

19

24

1

18

13

6

7

12

30

31

2

11

102021

40

G

1

43

EBC353 4BE00353B1X10 MADE IN TAIWAN

CON1

1

H3

9

17

20

8

16

24

CN9

10

U4

48

49

64

1 16

4

1

7

CN8

1

6 2 7

JP14

1

10

1

10

33

32

17

MH5

U8

975

15

17

11

21

231325

19

JP13

1

2

1

6

5

3

1

7

CN7

5

9

8

43

31

J4

40

AE AD AA Y W V U T R N L K J H G F D C B A

1

3

J7

6

5

1

COM1

30

USB1

1

U1

21

20

11

10

RT2

U11

33

48

49 64

J8

1

CN2 J3CN1

9

17

10

MH4

JP2

7

1

8

JP3

52

JP1

1

5

2

6

2

1

J5

2

1

51

PA1

JP4

PD1

3

1

JP5

CN3

18

CN4

16

2

H2

1732

33

16

1

48

49

U12

6

8

12

4

8

7

10

11

37

48

1

12

9

2

1

36

25

24

13

U6

1732

16

64

1

CN5

12

8

7

10

11

3

1

17

151

JP6

3

1

JP7

2

1

JP8

2

1

JP9

3

15

JP10

1

JP11

4

1

PD30

JP12

4

9

2

H4

1

JP15

234

LAN2LAN1

7

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

Jumpers

CMOS Clear Select

Connector type: 1x3 3-pin header Connector location: JP4

1 3 1 3

Pin Settings

1-2 On Normal 2-3 On Clear BIOS

1-2 On: default

Pin Definition

1 NC 2 I_RTCRST# 3 GND

Power Mode Select

Connector type: 1x3 3-pin header Connector location: JP9

Pin Settings

1-2 On AT 2-3 On ATX

1-2 On: default

Pin Definition

1 I_PWRBT# 2 AT_PWRBT# 3 ATX_BOT

8

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

LVDS Power Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP14

1 3

Pin Definition

1 VCC3 2 PANEL1_VDD 3 VCC5

1-2 On: default

Panel Backlight Control Mode

Connector type: 2x3 6-pin header, 2.54mm pitch Connector location: JP13

2 6

1 5

Pin Definition

1 CCFLBKLTCTRL 2 CCFL_PWM 3 PL_BKLTCTRL 4 CCFLBKLTCTRL 5 P_BKLTCTRL 6 PWM_DUTY

1-3 On: Analog signal output for dimming control. (default)

3-5 On: PWM signal output for dimming control.

9

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

Connector Pin Definitions

External I/O Interfaces

DVI-I

Connector type: 1x3 3-pin header Connector location: JP4

Pin Definition Pin Definition

1 CH_TX2_N 2 CH_TX2_P 3 DVI_I_GND 4 NC 5 NC 6 DVI_I_DDC_C 7 DVI_I_DDC_D 8 VSYNC_VGA

9 CH_TX1_N 10 CH_TX1_P 11 DVI_I_GND 12 NC 13 NC 14 DVI_I_5V 15 DVI_I_GND 16 HPDET_I 17 CH_TX0_N 18 CH_TX0_P 19 DVI_I_GND 20 DDCCLK_VGA 21 DDCDATA_VGA 22 DVI_I_GND 23 CH_CLK_P 24 CH_CLK_N C1 RED_VGA C2 GREEN_VGA C3 BLUE_VGA C4 HSYNC_VGA

C5A VGADET C5B CRT_GND

MH1 CHASIS_GND MH2 CHASIS_GND

COM1 Serial Port

Connector type: DB-9 port Connector location: COM1

Pin Definition Pin Definition

1 SP1_DCD 2 SP1_RXD 3 SP1_TXD 4 SP1_DTR 5 GND 6 SP1_DSR 7 SP1_RTS 8 SP1_CTS 9 SP1_RI

10

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

USB0/1 Ports

Connector type: Dual USB port, Type A Connector location: USB1

Pin Definition Pin Definition

1 P5V_USB_P01 2 USBCON_0N

3 USBCON_0P 4 GND

5 P5V_USB_P01 6 USBCON_1N

7 USBCON_1P 8 GND

MH1 USB1_MTH_GND MH2 USB1_MTH_GND MH3 USB1_MTH_GND MH4 USB1_MTH_GND

LAN1 Port

Connector type: RJ45 port with LEDs Connector location: LAN

Pin Definition Pin Definition

1 LAN1M0P 2 LAN1M0N 3 LAN1M1P 4 LAN1M2P 5 LAN1M2N 6 LAN1M1N 7 LAN1M3P 8 LAN1M3N 9 LAN1_LEDACT# 10 LAN1_ACTPW

11 LAN1_LINK100# 12 LAN1_LINK1G#

MH1 CHASIS_GND MH2 CHASIS_GND

11

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

LAN2 Port

Connector type: RJ45 port with LEDs Connector location: LAN2

Pin Definition Pin Definition

1 LAN2M0P 2 LAN2M0N

3 LAN2M1P 4 LAN2M2P

5 LAN2M2N 6 LAN2M1N

7 LAN2M3P 8 LAN2M3N

9 LAN2_LEDACT# 10 LAN2_ACTPW

11 LAN2_LINK100# 12 LAN2_LINK1G#

MH1 CHASIS_GND MH2 CHASIS_GND

12

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

Internal Connectors

SMBus Connector

Connector type: 1x3 3-pin header 2.00mm-M-180 Connector location: JP6

Reset Button Connector

Connector type: 1x2 2-pin header, 2.00mm pitch Connector location: JP7

1

3

Pin Definition

1 SMBCLK_MAIN 2 SMBDATA_MAIN 3 GND

1 2

Pin Definition

1 I_SYSRST# 2 GND

13

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

Power Button Connector

Connector type: 1x2 2-pin header, 2.00mm pitch Connector location: JP8

1 2

Pin Definition

1 ATX_BOT 2 GND

Speaker-out Connector

Connector type: 1x5 5-pin header, 2.0mm pitch Connector location: JP10

1 5

Pin Definition

1 FRONT_L+ 2 FRONT_L3 AGND 4 FRONT_R+ 5 FRONT_R

14

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

Mic-in Connector

Connector type: 1x4 4-pin header, 2.0mm pitch Connector location: JP11

1 4 1 4

Pin Definition

1 MIC_L3 2 AGND 3 MIC_JD 4 LOUT_R3

Line-out Connector

Connector type: 1x4 4-pin header, 2.0mm pitch Connector location: JP12

Pin Definition

1 LOUT_L2 2 AGND 3 EXLINEOUT_JD 4 LOUT_R2

15

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

LED Connector

Connector type: 2x2 4-pin header, 2.0mm pitch Connector location: JP15

3 4

1 2

Pin Definition

1 PWRLEDP 2 GND 3 HDDLEDP 4 GND

SATA DOM Power Connector

Connector type: 1x4 4-pin header, 2.0mm pitch Connector location: JP12

2 1

Pin Definition

1 VCC5 2 GND

16

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

SIM Card External Connector

Connector type: 2x3 6-pin header, 2.0mm pitch Connector location: JP1

2 6

1 5

Pin Definition

1 UIM_PWR 2 GND 3 UIM_RESET 4 UIM_VPP 5 UIM_CLK 6 UIM_DATA

PS/2 Keyboard/Mouse Connector

Connector type: 2x4 8-pin header, 2.54mm Connector location: JP2

2 8

1 7

Pin Definition

1 5V_KB 2 5V_KB 3 KDAT_R 4 MDAT_R 5 KCLK_R 6 MCLK_R 7 KBMS_GND 8 KBMS_GND

17

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

GPIO Connector

Connector type: 2x5 10-pin header, 2.0mm pitch Connector location: JP3

2 10

1 9

Pin Definition

1 VCC5 2 GND 3 SIO_GPO24 4 SIO_GPI20 5 SIO_GPO25 6 SIO_GPI21 7 SIO_GPO26 8 SIO_GPI22 9 SIO_GPO27

10 SIO_GPI23

Battery Connector

Connector type: 1x2 JST, 2-pin header, 2.5mm pitch Connector location: J5

1 2

Pin Definition

1 GND 2 BAT_C

18

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

SATA1 Connector

Connector type: Standard Serial ATAII 7P (1.27mm, SATA-M-180) Connector location: CN7

1 7 1 7

Pin Definition

1 GND 2 SATA_TXP0_C 3 SATA_TXN0_C 4 GND 5 SATA_RXN0_C 6 SATA_RXP0_C 7 GND

SATA2 Connector

Connector type: Standard Serial ATAII 7P (1.27mm, SATA-M-180) Connector location: CN2

Pin Definition

1 GND 2 SATA_TXP1_C 3 SATA_TXN1_C 4 GND 5 SATA_RXN1_C 6 SATA_RXP1_C 7 GND

19

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

SATA Power Connector

Connector type: 1x4 4-pin Wafer, 2.54mm pitch Connector location: CN8

1 4

Pin Definition

1 +12V 2 GND 3 GND 4 VCC5

COM2 Connector

Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J4

10

1

Pin Definition Pin Definition Pin Definition

1 SP2_DCD 2 SP2_RXD 3 SP2_TXD 4 SP2_DTR 5 GND 6 SP2_DSR 7 SP2_RTS 8 SP2_CTS 9 SP2_RI

10 GND

RS422 Pin Definition

Pin Definition Pin Definition Pin Definition

1 TXD- 2 TXD+ 3 RXD+ 4 RXD- 5 GND 6 RTS7 RTS+ 8 CTS+ 9 CTS-

RS485 Pin Definition

Pin Definition Pin Definition Pin Definition

1

TXDRXD- RXD+ 4 Reserve

2

5 Reserve 6 Reserve 7 Reserve 8 Reserve 9 Reserve

TXD+ 3 Reserve

20

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

COM3 Connector

Connector type: 1x10 10-pin header 1.0mm pitch Connector location: J2

10

1

Pin Definition

1 SP3_DCD 2 SP3_RXD 3 SP3_TXD 4 SP3_DTR 5 GND 6 SP3_DSR 7 SP3_RTS 8 SP3_CTS 9 SP3_RI

10 GND

COM4 Connector

Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J1

10

1

Pin Definition

1 SP4_DCD 2 SP4_RXD 3 SP4_TXD 4 SP4_DTR 5 GND 6 SP4_DSR 7 SP4_RTS 8 SP4_CTS 9 SP4_RI

10 GND

21

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

CPU Fan Connector

Connector type: 1x4 4-pin Wafer, 2.54mm pitch Connector location: CN8

4

1

Pin Definition

1 GND 2 +12V 3 CPUFANIN_R 4 CPUFANOUT_R

USB2/3 JST Connector

Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J4

6

1

Pin Definition

1 P5V_USB_P23 2 USBCON_2N 3 USBCON_2P 4 USBCON_3N 5 USBCON_3P 6 GND

22

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

USB4/5 JST Connector

Connector type: 1x6 6-pin header, 2.0mm pitch Connector location: J8

6

1

Pin Definition

1 P5V_USB_P45 2 USBCON_4N 3 USBCON_4P 4 USBCON_5N 5 USBCON_5P 6 GND

ATX Power Output Connector

Connector type: 2x2 Aux power connector Connector location: CON1

1 2

3 4

Pin Definition

1 GND 2 GND 3 +12V 4 +12V

23

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

LVDS Backlight Connector

Connector type: 1x7 JST, 7-pin header, 2.5mm pitch Connector location: J6

7 1

Pin Definition

1 VCC5 2 V_INV(+12V) 3 V_INV(+12V) 4 BKLTCTRL 5 GND 6 GND 7 M_BKLTEN_R

LVDS Connector

Connector type: 2x10 20-pin header, 1.25mm pitch Connector location: CN6

1 19 2 20

Pin Definition Pin Definition

1 M_LVDSDDCCLK 2 M_LVDSDDCDATA 3 VCC_LCD 4 LVDS_CH_TX0_P 5 LVDS_CH_TX3_P 6 LVDS_CH_TX0_N 7 LVDS_CH_TX3_N 8 VCC_LCD

9 GND 10 LVDS_CH_TX1_P 11 LVDS_CH _CLK_P 12 LVDS_CH_TX1_N 13 LVDS_CH _CLK_N 14 GND 15 GND 16 V_INV(+12V) 17 LVDS_CH_TX2_P 18 V_INV (+12V) 19 LVDS_CH_TX2_N 20 GND

MH1 GND MH2 GND

24

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

Mini-PCIe Slot

Connector location: CN4

1 2

51 52

Pin Definition Pin Definition

1 I_WAKE# 2 +3VSB_MINI1 3 NC 4 GND 5 NC 6 1V5 7 MINICARD1CLKREQ# 8 NC

9 GND 10 NC 11 G_MINIPCIECLKN 12 NC 13 G_MINIPCIECLKN 14 NC 15 GND 16 NC 17 NC 18 GND 19 NC 20 MINICARD1DIS# 21 GND 22 I_SLOTPLTRST# 23 I_PERXN3 24 +3VSB_MINI1 25 I_PERXP3 26 GND

Pin Definition Pin Definition

27 GND 28 1V5 29 GND 30 SMB_CLK 31 I_PETXN3_C 32 SMB_DATA 33 I_PETXP3_C 34 GND 35 GND 36 MINI1USBN 37 GND 38 MINI1USBP 39 +3VSB_MINI1 40 GND 41 +3VSB_MINI1 42 NC 43 GND 44 NC 45 NC 46 NC 47 NC 48 1V5 49 NC 50 GND 51 NC 52 +3VSB_MINI1

25

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

PCI Slot

Connector type: 120-pin H:9.6mm 180D GOLD FLASH DIP 5V Connector location: CN5

PD30 PD1

PA1

Pin Definition Pin Definition Pin Definition Pin Definition

PA1 GND PB1 NC PC1 VCC5 PD1 PCIAD0 PA2 VIO PB2 PCIAD2 PC2 PCIAD1 PD2 VCC5 PA3 PCIPCIAD5 PB3 GND PC3 PCIAD4 PD3 PCIAD3 PA4 PCICBE#0 PB4 PCIAD7 PC4 GND PD4 PCIAD6 PA5 GND PB5 PCIAD9 PC5 PCIAD8 PD5 GND PA6 PCIPCIAD11 PB6 VIO PC6 PCIAD10 PD6 GND PA7 PCIAD14 PB7 PCIAD13 PC7 GND PD7 PCIAD12 PA8 VCC3 PB8 PCICBE#1 PC8 PCIAD15 PD8 VCC3

PA9 SERR# PB9 GND PC9 NC PD9 PAR PA10 GND PB10 PERR# PC10 VCC3 PD10 NC PA11 STOP# PB11 VCC3 PC11 LOCK# PD11 GND PA12 VCC3 PB12 TRDY# PC12 GND PD12 DEVSEL# PA13 FRAME# PB13 GND PC13 IRDY# PD13 VCC3 PA14 GND PB14 PCIAD16 PC14 VCC3 PD14 PCICBE#2 PA15 PCIAD18 PB15 VCC3 PC15 PCIAD17 PD15 GND

Pin Definition Pin Definition Pin Definition Pin Definition

PA16 PCIAD21 PB16 PCIAD20 PC16 GND PD16 PCIAD19 PA17 VCC3 PB17 PCIAD23 PC17 PCIAD22 PD17 VCC3 PA18 IDSEL0 PB18 GND PC18 IDSEL1 PD18 IDSEL2 PA19 PCIAD24 PB19 PCICBE#3 PC19 VIO PD19 IDSEL3 PA20 GND PB20 PCIAD26 PC20 PCIAD25 PD20 GND PA21 PCIAD29 PB21 VCC5 PC21 PCIAD28 PD21 PCIAD27 PA22 VCC5 PB22 PCIAD30 PC22 GND PD22 PCIAD31 PA23 REQ#0 PB23 GND PC23 REQ#1 PD23 VIO PA24 GND PB24 REQ#2 PC24 VCC5 PD24 GNT0 PA25 GNT#1 PB25 VIO PC25 GNT2 PD25 GND PA26 VCC5 PB26 PCICLK0 PC26 GND PD26 PCICLK1 PA27 PCICLK2 PB27 VCC5 PC27 PCICLK3 PD27 GND PA28 GND PB28 IRQD PC28 VCC5 PD28 PCIRST# PA29 +12V PB29 IRQA PC29 IRQB PD29 IRQC PA30 -12V PB30 REQ#3 PC30 GNT3 PD30 GND

26

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

Sim Card Holder

Connector location: CN3

C3 C2 C1

C7 C6 C8

Pin Definition

C1 UIM_PWR C2 UIM_RESET C3 UIM_CLK C4 GND C5 UIM_VPP C6 UIM_DATA

27

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

Block Diagram

M

IC-IN

Page 19

HEAD PHONE

Page 19

SPEAKER

Page 19

DVI-I CON

LVDS CON

0-1 - Rear

Page 20

2-3- internal

Page 20

4-5 - internal

Page 20

6 - Mini Card

Page 30

SATA0 HDD

SATA1 DOM

HDA_SDI0

Audio Codec ALC886

Page 19

AMP

TPS6047A4RHBR

Page 19

Page 14

Page 12 13

Page 21

HDA_SDI1

USB 2.0

SATA Gen2

80 port

VGA

LVDS

Page 28

HDMI

LPC Bus

PORT1 DDI PORT0 DDI

CedarView

Dual Core CPU

VGA

DX10.1 Graphics DDR3-800/1066

559 balls

22*22mm

Page 7-10

IHDA

x2 DMI 2 Lanes

2GB/s

)8( 0.2 BSU SDVL

SATA (2)

DMI

Tiger Point

PCH NM10

360 balls

17*17mm

Page 18-20

ICLADH CPL

Super I/O

ITE8783

Thermal Sensor *2 Voltages *4

Page 28 32

FAN *1

CK505 CLOCK GEN

DDR3

DDR3 800/1066

SPI 2MB

Page 21

SPI

PCIe x1

PCI-E *1(4)

PCI 32

PCI

Page 28

LAN 82574L

Mini PCIE

3G

PCI104

Page 6

DDR3 SO-DIMM

Page 11

1 Slot

Page 22

Page 24

Page 30

2 master

Page 29

COM1/3/4

RS-232

RS232/422/485

COM2

GPIO 4-IN/4-OUT

Giga LAN

Page 29

Page 30

Page 31

RJ45

Page 23

RJ45

Page 25

PS2

Page 32

28

EBC 353 User Manual

Chapter 2: Jumpers and Connectors

Board Dimensions

29

EBC 353 User Manual

Chapter 3: BIOS Setup

ChaPter 3: BIos setuP

This chapter describes how to use the BIOS setup program for the EBC 353. The BIOS screens provided in this chapter are for reference only and may change if the BIOS is updated in the future.

To check for the latest updates and revisions, visit the NEXCOM Web site at www.nexcom.com.tw.

About BIOS Setup

The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor your system to suit your individual work needs. It is a ROM-based configuration utility that displays the system’s configuration status and provides you with a tool to set system parameters.

These parameters are stored in non-volatile battery-backed-up CMOS RAM that saves this information even when the power is turned off. When the system is turned back on, the system is configured with the values found in CMOS.

With easy-to-use pull down menus, you can configure such items as:

▪ Hard drives, diskette drives, and peripherals

▪ Video display type and display options

▪ Password protection from unauthorized use

▪ Power management features

The settings made in the setup program affect how the computer performs. It is important, therefore, first to try to understand all the setup options, and second, to make settings appropriate for the way you use the computer.

When to Configure the BIOS

▪ This program should be executed under the following conditions:

▪ When changing the system configuration

▪ When a configuration error is detected by the system and you are

prompted to make changes to the setup program

▪ When resetting the system clock

▪ When redefining the communication ports to prevent any conflicts

▪ When making changes to the Power Management configuration

▪ When changing the password or making other changes to the security

setup

Normally, CMOS setup is needed when the system hardware is not consistent with the information contained in the CMOS RAM, whenever the CMOS RAM has lost power, or the system features need to be changed.

30

EBC 353 User Manual

Chapter 3: BIOS Setup

Default Configuration

Most of the configuration settings are either predefined according to the Load Optimal Defaults settings which are stored in the BIOS or are automatically detected and configured without requiring any actions. There are a few settings that you may need to change depending on your system configuration.

Entering Setup

When the system is powered on, the BIOS will enter the Power-On Self Test (POST) routines. These routines perform various diagnostic checks; if an error is encountered, the error will be reported in one of two different ways:

▪ If the error occurs before the display device is initialized, a series of beeps

will be transmitted.

▪ If the error occurs after the display device is initialized, the screen will

display the error message.

Powering on the computer and immediately pressing <Del> allows you to enter Setup. Another way to enter Setup is to power on the computer and wait for the following message during the POST:

Legends

Key Function

Moves the highlight left or right to select a menu.

Moves the highlight up or down between sub¬menus or fields.

Exits the BIOS Setup Utility.

Scrolls forward through the values or options of the highlighted field.

Scrolls backward through the values or options of the highlighted field.

Selects a field.

Displays General Help.

Load previous values.

Load optimized default values.

TO ENTER SETUP BEFORE BOOT PRESS

Ctrl

Press the key to enter Setup:

+

Alt

+

31

Saves and exits the Setup program.

Press <Enter> to enter the highlighted sub¬menu

EBC 353 User Manual

Chapter 3: BIOS Setup

Scroll Bar

When a scroll bar appears to the right of the setup screen, it indicates that there are more available fields not shown on the screen. Use the up and down arrow keys to scroll through all the available fields.

Submenu

When “” appears on the left of a particular field, it indicates that a submenu which contains additional options are available for that field. To display the submenu, move the highlight to that field and press .

BIOS Setup Utility

▪ Once you enter the AMI BIOS Setup Utility, the Main Menu will appear

on the screen. The main menu allows you to select from several setup functions and one exit. Use arrow keys to select among the items and press to accept or enter the submenu.

Main

The Main menu is the first screen that you will see when you enter the BIOS Setup Utility.

Advanced Chipset Boot SecurityMain

BIOS Information BIOS Vendor Core Version Compliency Bios Version Build Date and Time

Intel RC Version

System Date System Time

Access Level

American Megatrends

4.6.5.1 UEFI 2.3; PI 1.2 E353-002 01/09/2012 15:21:01

[Thu 01/12/2012] [17:10:13]

Administrator

Save & Exit

Intel Reference Code version

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

32

EBC 353 User Manual

Chapter 3: BIOS Setup

Intel RC Version

Displays the Intel Reference Code version.

Main

INTEL CEDARVIEW INTEL MRC INTEL NM10 INTEL P-UINT INTEL IGFX VBIOS INTEL ACPI

0.9.0-1

1.00

1.6.0 012 1053

0.9.0-1

Intel Reference Code version

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

System Date

The date format is <day>, <month>, <date>, <year>. Day displays a day, from Monday to Sunday. Month displays the month, from January to December. Date displays the date, from 1 to 31. Year displays the year, from 1999 to 2099.

System Time

The time format is <hour>, <minute>, <second>. The time is based on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays seconds from 00 to 59.

Access Level

Displays the access level of the current user in the BIOS.

33

EBC 353 User Manual

Chapter 3: BIOS Setup

Advanced

The Advanced menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference.

Setting incorrect field values may cause the system to malfunction.

Advanced Chipset Boot SecurityMain

Legacy OpROM Support

Launch Lan1 PXE OpROM

Launch Lan2 PXE OpROM



CPU Conguration



IDE Conguration



USB Conguration



Super IO Conguration



H/W Monitor

[Disabled]

Save & Exit

Enable or Disable Boot Option for Lan1.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Launch LAN1/2 PXE OpROM

Enables or disables the boot option for legacy network devices connected to LAN1 and LAN2.

34

EBC 353 User Manual

Chapter 3: BIOS Setup

CPU Configuration

This section is used to configure the CPU.

Advanced

CPU Conguration

Processor Type EMT64 Processor Speed System Bus Speed Rat io Status Actual Ratio System Bus Speed Processor Stepping Microcode Revision L1 Cache RAM L2 Cache RAM Processor Core Hyper-Threading

Hyper-Threading

Execute Disable Bit Limit CPUID Maximum

Intel(R) Atom(TM) CPU Supported 2132 MHz 533MHz 16 16 533 MHz 30661 262 2x56 k 2x 512k Dual Supported

[Enabled]

[Enabled] [Disabled]

Hyper-threading

Disable or Enable hyper-threading technology.

Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology).

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Limit CPUID Maximum

The CPUID instruction of some newer CPUs will return a value greater than 3. The default is Disabled because this problem does not exist in the Windows series operating systems. If you are using an operating system other than Windows, this problem may occur. To avoid this problem, enable this field to limit the return value to 3 or lesser than 3.

Execute Disable Bit

When this field is set to Disabled, it will force the XD feature flag to always return to 0. XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3).

35

EBC 353 User Manual

Chapter 3: BIOS Setup

IDE Configuration

This section is used to configure the IDE drives.

Advanced

SATA Port0 SATA Port1

SATA Controller(s)

Congure SATA as

Not Present Not Present

[Enabled]

[AHCI]

SATA Ports (0-3) Device Names if Present and Enabled.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Configure SATA As

IDE This option configures the Serial ATA drives as Parallel ATA physical

storage device.

RAID This option allows you to create RAID or Intel Matrix Storage

configuration on Serial ATA devices.

AHCI This option configures the Serial ATA drives to use AHCI (Advanced

Host Controller Interface). AHCI allows the storage driver to enable the advanced Serial ATA features which will increase storage performance.

SATA Controller(s)

Enables or disables SATA ports 0-3.

USB Configuration

This section is used to configure the USB.

Advanced

USB Conguration

USB Devices: None

Legacy USB Support

EHCI Hand-off Device reset time-out

[Enabeld]

[Disabled] [20 sec]

Enables Legacy USB support. AUTO option disables legacy Support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

USB Configuration

Displays the detected USB devices.

Legacy USB Support

Enable Enables Legacy USB. Auto Disables support for Legacy when no USB devices are connected. Disable Keeps USB devices available only for EFI applications.

EHCI Hand-Off

This is a workaround for OSs that does not support EHCI hand-off. The EHCI ownership change should be claimed by the EHCI driver.

36

EBC 353 User Manual

Chapter 3: BIOS Setup

Super IO Configuration

This section is used to configure the serial ports.

Advanced

Super IO Conguration

Super IO Chip



Serial Port 0 Conguration



Serial Port 1 Conguration



Serial Port 2 Conguration



Serial Port 2 Conguration

IT8783F

Super IO Chip

Displays the Super I/O chip used on the board.

Set Parameters of Serial Port O (COMA)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Serial Port 0 Configuration

This section is used to configure serial port 0.

Advanced

Serial Port 0 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port Max Baud Rate

[Enabled]

IO=3F8h; IRQ=4;

[IO=3F8h; IRQ=4;] [115200 bps]

Serial Port

Enables or disables the serial port.

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Change Settings

Selects an optimal setting for the Super IO device.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

37

EBC 353 User Manual

Chapter 3: BIOS Setup

Serial Port 1 Configuration

This section is used to configure serial port 1.

Advanced

Serial Port 1 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port 1 Mode Onboard Serial Port Max Baud Rate

[Enabled]

IO=2F8h; IRQ=3;

[IO=2F8h; IRQ=3;] [RS232] [115200 bps]

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Onboard Serial Port 1 Mode

Select this to change the serial port mode to RS232, RS422 or RS485.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

Serial Port 2 Configuration

This section is used to configure serial port 2.

Advanced

Serial Port 2 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port Max Baud Rate

[Enabled]

IO=3F8h; IRQ=7;

[IO=3F8h; IRQ=7;] [115200 bps]

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

38

EBC 353 User Manual

Chapter 3: BIOS Setup

Serial Port 3 Configuration

This section is used to configure serial port 3.

Advanced

Serial Port 3 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port Max Baud Rate

[Enabled]

IO=2F8h; IRQ=6;

[IO=2F8h; IRQ=6;] [115200 bps]

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

H/W Monitor

This section is used to monitor hardware status such as temperature, fan speed and voltages.

Advanced

PC Health Status

CPU Temperature System Temperature CPU FAN Speed CPU: Vcore +3.3V +5V +12V

: +34C : +24C : 6368 RPM : +1.168V : +3.264V : +5.017V : +11.827V

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

CPU Temperature

Detects and displays the current CPU temperature.

System Temperature

Detects and displays the current system temperature.

CPU FAN Speed

Detects and displays the current CPU fan speed.

CPU: Vcore

Detects and displays the output voltages.

39

EBC 353 User Manual

Chapter 3: BIOS Setup

Chipset

This section gives you functions to configure the system based on the specific features of the chipset. The chipset manages bus speeds and access to system memory resources.



Host Bridge



South Bridge

Advanced Chipset Boot SecurityMain

Save & Exit

Host Bridge Parameters

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Host Bridge

This section is used to configure the host bridge features.

Chipset



Intel IGD Conguration

******* Memory Information *******

Memory Frequency Total Memory DIMM#0 DIMM#1

1067 MHz(DDR3) 4096 MB Not Present 4096 MB

Cong Intel IGD Settings.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Intel IGD Configuration

Configures the options for Intel IGD function.

Memory Information

Detects and displays information on the memory installed in the system.

40

EBC 353 User Manual

Chapter 3: BIOS Setup

South Bridge

This section is used to configure the south bridge features.

Chipset

Azalia Controller

SMBus Controller

Hight Precision Event Timer Conguration

Hight Precision Timer

Restore AC Power Loss

[HD Audio]

[Enabled]

[Last State]

Azalia Controller

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Azalia Controller

Enables or disables the Azalia HD audio.

Restore AC Power Loss

Power Off When power returns after an AC power failure, the system’s

power is off. You must press the power button to power-on the system.

Power On When power returns after an AC power failure, the system

will automatically power-on.

Last State When power returns after an AC power failure, the system

will return to the state where you left off before power failure occurs. If the system’s power is off when AC power failure occurs, it will remain off when power returns. If the system’s power is on when AC power failure occurs, the system will power-on when power returns.

SMBus Controller

Enables or disables the SMBus controller.

High Precision Timer

Enables or disables the high precision event timer.

41

EBC 353 User Manual

Chapter 3: BIOS Setup

Boot

This section is used to configure the boot features.

Advanced Chipset Boot SecurityMain

Boot Conguration

Setup Prompt Timeout

Boothup NumLock State

Quiet Boot

CMS16 Module Version

GateA20 Active Option ROM Messages Interrupt 19 Capture

1

[On]

[Disabled]

07.65

[Upon Request] [Force BIOS] [Disabled]

Setup Prompt Timeout

Selects the number of seconds to wait for the setup activation key. 65535(0xFFFF) denotes indefinite waiting.

Save & Exit

Number of seconds to wait for setup activation key.

65535(0xFFFF) means indenite

waiting.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Quiet Boot

Enabled Displays OEM logo instead of the POST messages. Disabled Displays normal POST messages.

Gate A20 Active

Upon Request GA20 can be disabled using BIOS services Always Does not allow disabling GA20. This option is useful when an RT code is executed above 1M.

Option ROM Messages

Selects the display mode for Option ROM. The options are Force BIOS and Keep Current.

Interrupt 19 Capture

When enabled, it allows the optional ROM to trap interrupt 19.

Boot Option Priorities

Adjust the boot sequence of the system. Boot Option #1 is the first boot device that the system will boot from, next will be #2 and so forth.

Bootup NumLock State

This allows you to determine the default state of the numeric keypad. By default, the system boots up with NumLock on wherein the function of the numeric keypad is the number keys. When set to Off, the function of the numeric keypad is the arrow keys.

42

EBC 353 User Manual

Chapter 3: BIOS Setup

Security

Advanced Chipset Boot SecurityMain

Password Description

If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup. If ONLY the User’s password is set, then this is a power on password and must be entered to boot or enter Setup. In Setup the User Will have Administrator rights. The password length must be in the following range: Minimum length 3 Maximum length 20

Administrator Password

User Password

Save & Exit

Set Administrator Password

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Administrator Password

Select this to reconfigure the administrator’s password.

User Password

Select this to reconfigure the user’s password.

43

EBC 353 User Manual

Chapter 3: BIOS Setup

Save & Exit

Advanced Chipset Boot SecurityMain

Save Changes and Exit

Discard Changes and Exit Save Changes and Reset

Discard Changes and Reset

Save Options

Save Changes Discard Changes

Restore Defaults Save as User Defaults

Restore User Defaults

Boot Override

Lanuch EFI Shell from lesystem device

Save Changes and Exit

To save the changes and exit the Setup utility, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes. You can also press <F4> to save and exit Setup.

Discard Changes and Exit

To exit the Setup utility without saving the changes, select this field then press <Enter>. You may be prompted to confirm again before exiting. You can also press <ESC> to exit without saving the changes.

Save & Exit

Exti system setup after saving the changes.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Save Changes and Reset

To save the changes and reset, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Discard Changes and Reset

To exit the Setup utility without saving the changes, select this field then press <Enter>. You may be prompted to confirm again before exiting.

Save Changes

To save changes and continue configuring the BIOS, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Discard Changes

To discard the changes, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes to discard all changes made and restore the previously saved settings.

Restore Defaults

To restore the BIOS to default settings, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Save as User Defaults

To use the current configurations as user default settings for the BIOS, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Restore User Defaults

To restore the BIOS to user default settings, select this field then press <Enter>. A dialog box will appear. Confirm by selecing Yes.

Boot Override

To bypass the boot sequence from the Boot Option List and boot from a particular device, select the desired device and press <Enter>.

Launch EFI Shell from filesystem device

To launch EFI shell from a filesystem device, select this field and press <Enter>.

44

EBC 353 User Manual

Appendix A: Watchdog Timer

aPPendIx a: WatChdog tImer

WDT Programming Guide

EBC353 Watch Dog Function Configuration Sequence Description:

Step1. See “SetupWDT” procedure #Setup Watchdog Timer Environment

Step2. See “TimeBaseWDT” procedure #Initial Watchdog Timer. Users can select second or minute.

Star

Step3. See “TimeCountWDT” procedure #Set Watchdog Timer Time-out Value. Users can set time-out value.

Step4: See ExitSetup procedure #Exit Setup Environment

End

45

EBC 353 User Manual

Appendix A: Watchdog Timer

=============================================== SetupWDT PROC mov dx, 2eh mov al, 087h out dx, al nop nop mov al, 01h out dx, al nop nop mov al, 55h out dx, al nop nop out dx, al ;Write operations to special address port (2E) for entering MB PnP Mode.

mov al, 07h out 2eh, al mov al, 07h ;Select logical device for Watch Dog. out 2fh, al ret SetupWDT ENDP

out 2fh, al ret TimeBaseWDT ENDP

=============================================== TimeCountWDT PROC mov al, 73h ;WDT Time-out register. out 2eh, al mov al, 03h ;Here!! Set count 3. out 2fh, al ret TimeCountWDT ENDP =============================================== ExitSetup PROC mov al, 02h out 2eh, al mov al, 02h out 2fh, al ret ExitSetup ENDP ===============================================

=============================================== TimeBaseWDT PROC mov al, 72h out 2eh, al mov al, 10h ;Set WDT reset upon PWROK or al, 80h ;Here!! set 80h for second, set 00h for minute

46

EBC 353 User Manual

Appendix B: GPI/O Programming Guide

aPPendIx B: gPI/o ProgrammIng guIde

EBC 353 GPIO

EBC353 Watch Dog Function Configuration Sequence Description:

PIN Description PIN Description

1 +5V 2 GND 3 GPO24 4 GPI20 5 GPO25 6 GPI21 7 GPO26 8 GPI22 9 GPO27 10 GPI23

IO base address : A00h Bit0 : GPI20 Bit1 : GP I21 Bit2 : GP I22 Bit3 : GP I23 Bit4 : GPO24 Bit5 : GPO25 Bit6 : GPO26 Bit7 : GPO27

1. Read/Write GPIO data by I/O port A04h

47

EBC 353 User Manual
