NewMar torrey pine 2008 User Manual

Welcome to the Newmar Family!

Welcome to the exciting world of recreational vehicle traveling and the
growing Newmar family. Congratulations on your purchase of a Newmar
product. We sincerely thank you for choosing Newmar as your recreational
vehicle. We hope that you will enjoy many miles of traveling. Your new
vehicle was built with care using today’s technology and old world
craftsmanship. We, at Newmar, strive to build vehicles that are safe,
dependable, and comfortable to provide you with years of carefree, pleasant
traveling.

Please read the Newmar Limited Warranty and all other component warranties
that apply to the equipment installed on your unit. Carefully read both the
instructions in this Owners Guide and the booklets supplied by the component
manufacturers for important operation, safety, and maintenance
requirements/information. Your dealer should be consulted should you have
any questions. If your dealer is unable to answer the questions to your
satisfaction he will refer you to our staff for assistance. Our customers are
extremely important to us and we will make every effort necessary to ensure
your satisfaction.

The limited warranties issued by component manufacturers require periodic
service and maintenance. The owner s failure to provide this service and/or
maintenance will result in the loss of warranty coverage. Be sure to file the
appropriate registration card with the component manufacturer as described
with the individual instruction booklets to activate the warranties on the
components within your Newmar RV. This Owner s Guide should be kept in
your vehicle for quick reference. Take time to get acquainted with your unit
and how it operates. Again, thank you and welcome to the Newmar family.

Newmar Corporation

This guide, along with the Companion Video Owner’s Guide, has been
provided by Newmar Corporation solely for the purpose of providing
instructions about the operation and maintenance of this vehicle and its
components. Nothing in this manual creates any warranty, either expressed
or implied. The only warranty offered by Newmar Corporation is set forth
in the written limited warranty that applies to this vehicle.

Instructions are included in this manual for operating some of the components
that are standard on this vehicle. Instructions are also given for components
that are options and may not appear on all vehicles. For more detailed
information on components refer to the individual manufacturers operating
instructions contained in the Owner s Information Package.

The limited warranties issued by component manufacturers require periodic
service and maintenance. The owner s failure to provide this service and/or
maintenance will result in the loss of warranty coverage. The owner should
review the Newmar Corporation limited warranty and other manufacturers
limited warranties of all components applicable to this vehicle. To activate
the warranties on the components within your Newmar recreational vehicle,
be sure to file the appropriate registration card with the component
manufacturer as described with the individual instruction booklet.

The Video Owner’s Guide, that accompanies this printed Owners Guide,
contains a wealth of information you will find useful as you enjoy your coach.
When inserted into a DVD player, the “Main Menu” will allow you to navigate
through the options and accessories until you find the exact information
on your coach. For example, to obtain operating instructions on the specific
refrigerator in your unit, from the “Main Menu” select the “Appliances”
section. A menu of appliances will appear, from which you would select
“Refrigerators”. Once in the “Refrigerators” section, you will select the make
and model your unit is equipped with. Video information for operating the
accessory or appliance will follow.

Additional information is also contained on the DVD that can be accessed
by your computer if equipped with a DVD ROM. Simply insert the DVD
into your computers DVD ROM drive, and select from the “Technical Service
Information” menu, or the “Prints and Diagrams” menu. Under the “Prints
and Diagrams” menu you will find a listing of the different brands and models
Newmar manufactures. Select your brand and model, then select your specific
floorplan from the list provided. When opened in this manner, floorplan

specific prints for your unit can be accessed and, if needed, printed off for
your use. Adobe® Acrobat® Reader® is required to view the diagrams.
Download the latest version free at www.adobe.com.

Throughout this guide, reference is made to the following terms: Warning,
Caution, and Important. These terms indicate important information that must
be understood and followed. The definitions of these terms are:

WARNING

Emphasizes an area in which personal injury or even death could result from
failure to follow instructions properly. Mechanical damage may also occur.

CAUTION

Failure to observe a caution can cause damage to the equipment or unit.
Personal injury is unlikely.

IMPORTANT

This will provide additional information to make a step easier or clearer.

Chapter 1

SERVICE INFORMATION

CUSTOMER ASSISTANCE ............................ 3

COMPONENT PART SUPPLIERS .................. 3

Accessories .................................................................... 3

Air Conditioning .............................................................. 4

Appliances ..................................................................... 4

Electrical ........................................................................ 4

Exterior ........................................................................... 5

Heating ........................................................................... 5

TO OUR VALUED CUSTOMERS:................... 6

2008 Torrey Pine Fifth Wheel by Newmar 1:1

1:2 2008 Torrey Pine Fifth Wheel by Newmar

CUSTOMER ASSISTANCE

Newmar Corporation ...................................................... 1-800-731-8300

COMPONENT PART SUPPLIERS

Accessories

Back Up Monitor Atlanta DTH .................... 770-451-9777

A. S. A. Inc. ..................... 574-266-1886

C.T.D ............................... 800-777-4856

Total Vision Products ...... 520-623-0790

Back Up Monitor (Panasonic) Mito ................................. 888-433-6486

CB Radio (Cobra) Tri Star Distributing ......... 800-456-3340

Computer TripTek River Park, Inc. ................ 800-442-7717

Furniture (Upholstered) Flexsteel Industries .......... 563-556-7730

International .................... 714-535-7272

Grill, Electric Tabletop Meco ................................ 800-251-7558

Internet System (Trac-Net) River Park, Inc. ................ 800-442-7717

Navigation Mito ................................. 888-433-6486

Navigation (DVD) C.T.D. .............................. 800-777-4856

Roof Vent FanTastic Vent Corp. ....... 800-521-0298

Ventline ............................ 574-848-4491

Security System Nagy Fleet Net Inc. .......... 574-262-4479

Stereo AM/FM Odyssey ............................ 800-877-0521

River Park, Inc. ................ 800-442-7717

Stereo (Audiovox) A. S. A. Inc. ..................... 574-266-1886

Stereo (Pioneer) C.T.D. .............................. 800-777-4856

Stereo (Sony)

TV Antenna The Winegard Co. ............ 800-288-8094

Television (Magnavox) Midwest Sales ................. 574-287-3365

Television (RCA) Tri Star Distributing ......... 800-456-3340

Television (Sony) River Park, Inc. ................ 800-442-7717

Television (Zenith) Odyssey ............................ 800-877-0521

Television (LCD Monitor) KADP A. S. A. Inc. ..................... 574-266-1886

River Park, Inc. ................ 800-442-7717

2008 Torrey Pine Fifth Wheel by Newmar 1:3

Satellite Dish The Winegard Co. ........... 800-288-8094

Satellite Dish (Datron) A. S. A. Inc. ..................... 574-266-1886

Satelllite Dish (KVH) River Park, Inc. ................ 800-442-7717

VCR (RCA) Collins & Company ......... 574-848-1118

VCR (Sony) River Park, Inc. ................ 800-442-7717

Air Conditioning

Dash Air Evans Tempcon ............... 800-354-7088

Roof Air Dometic ............................ 800-544-4881

Basement Air Suburban Mfg. ................ 800-659-2138

Appliances

Dishwasher, 18” (Frigidaire) Frank-lin Premiums ......... 866-213-9397

Dishwasher, 24” Midwest Sales ................. 574-287-3365

Freezers Norcold ............................ 800-543-1219

Ice Makers U-Line .............................. 800-779-2547

Microwave (Dometic) Dometic ............................ 800-544-4881

Microwave (GE) Collins & Company ......... 574-848-1118

Range Atwood-Greenbrier .......... 815-877-5700

Magic Chef ...................... 515-792-7000

Refrigerator Dometic ............................ 800-544-4881

Norcold ............................ 800-543-1219

Water Heater Atwood Mobile Prod. ...... 815-877-5700

Suburban Mfg. ................. 800-659-2138

Vehicle Systems ............... 800-685-4298

Washer/Dryer, 1-piece Splendide ......................... 800-736-4127

Washer/Dryer, 2-piece Whirlpool ......................... 800-442-1111

Electrical (tires and batteries separately warranted)

Batteries - 12Volt Interstate .......................... 800-872-4100

Batteries - 6 Volt Interstate .......................... 888-772-3600

Converter IOTA ................................ 877-682-4682

Generators Generac ............................ 800-747-1530

Onan ................................. 800-888-6626

1:4 2008 Torrey Pine Fifth Wheel by Newmar

Power Tech ...................... 800-760-0027

Inverters Xantrex ............................ 800-446-6180

Exterior

Awning & Hardware A & E ............................... 800-544-4881

Carefree of Colorado ....... 800-621-2617

Girard ............................... 800-382-8442

Axle & Components Axle.................................. 574-295-1900

Hitch (CA & DP) Hidden Hitch .................... 877-869-6787

Jacks (CA & DP) H W H Corporation ......... 800-494-3213

Jacks (FW & TT) Atwood Mobile Prod. ...... 815-877-5700

Rubber Suspension Mor-Ryde, Inc. ................. 574-293-1581

Steps, Electrical (KS DP) Fleming (SCS) ................. 800-275-7524

Steps, Electrical Kwikee Products .............. 800-736-9961

Steps, Manual Hickory Springs Mfg. ...... 501-646-6161

Elkhart Tool and Die ....... 574-295-8500

Tires Goodyear .......................... 800-227-1999

RFD Components ............ 574-295-3939

Heating

Furnaces Atwood Mobile Prod. ...... 815-877-5700

Suburban Mfg. ................. 800-659-2138

Furnace, Aqua-Hot & Hydro-Hot Vehicle Systems ............... 800-685-4298

Please note that your Newmar Limited Warranty is activated only after Newmar
has received a signed Warranty Registration Form from your selling dealer.
If it has been more than 60 days since the purchase of your new coach and you
have not received your Newmar Owner’s Warranty Card, please contact your
selling dealer or the Newmar Warranty Department at 800-731-8300.

2008 Torrey Pine Fifth Wheel by Newmar 1:5

TO OUR VALUED CUSTOMERS:

If, for any reason, you have a problem obtaining satisfactory and timely
warranty service that may substantially impair the use, value or safety of
your Newmar product, please call us on our toll free line at 800-731-8300
so that we may attempt to resolve your concerns.

All of the information contained in this brochure is believed to be accurate
at the time of publication. However, it may be necessary to make revisions
and Newmar reserves the right to make any such changes without notice
or obligation. Please refer to the component information literature provided
in the Owner’s Information Packet for specific warranty details for the
components applicable to your recreational vehicle.

NEMAWMAR CORPORATION

355 N DELAWARE ST

PO BOX 30

NAPPANEE, IN 46550-0030

www.newmarcorp.com

1:6 2008 Torrey Pine Fifth Wheel by Newmar

Chapter 2

GENERAL & SAFETY INFORMATION

Delivery .......................................................................... 3

Dealer Responsibilities .................................................. 3

Customer Responsibilities ............................................. 3

Major Equipment Manufacturers .................................... 4

Recreational Vehicle Limited Warranty .......................... 5

Warranty Service ........................................................... 6

Owner’s Information Package ........................................ 6

Reporting Safety Defects ............................................... 6

Safety Precautions ......................................................... 6

Customer Relations ....................................................... 7

Information Sheet ........................................................... 7

Recommended Service Center Listing .......................... 8

IMPORTANT RV TIRE INFORMATION ........ 19

READ AND UNDERSTAND THE FOLLOWING
INFORMATION BEFORE TAKING YOUR FIRST TRIP

IN YOUR RV! .............................................. 19

Safety Precautions ....................................................... 20

Towing ......................................................................... 20

Propane Gas ................................................................ 20

Propane Gas System General Information .................. 20

Propane Regulator ....................................................... 22

Propane Distribution Lines ........................................... 22

Precautions & Recommendations ................................ 22

Fire Safety .................................................................... 23

Fire Extinguishers ........................................................ 23

Smoke Detector ........................................................... 24

Emergency Exit Window .............................................. 24

Weight Information ....................................................... 24

Weighing the Unit ......................................................... 25

Hitching Fifth Wheels ................................................... 26

Campsite Parking ......................................................... 27

Second Owner Information .......................................... 28

2008 Torrey Pine Fifth Wheel by Newmar 2:1

2:2 2008 Torrey Pine Fifth Wheel by Newmar

Delivery

Throughout the manufacturing process, your vehicle has been inspected by
our qualified technicians. However, our final inspection at the factory is not
to be the last one. The pre-delivery inspection and systems check your dealer
performs are the final inspections done to the unit prior to you receiving your
new coach. Your dealer is also available to assist you in understanding the
limited warranties and completing any necessary forms to activate the
warranties for the various appliances and accessories installed in your unit.

Dealer Responsibilities

1. A pre-delivery inspection and systems check. Thoroughly inspecting

the vehicle and the operation of the factory installed components.

2. A customer walk through. This is done to familiarize the customer with

the vehicle, its systems and components, and their operation.

3. Delivery of the Owner’s Information Package. This package contains
the warranty cards and registrations for the vehicle and factory installed
components that carry a separate warranty. The detailed operating and
maintenance instructions on these components are also included in this
package.

4. Assisting the customer in completing the component registration forms,

at the customer’s request. To avoid loss of warranty coverage, the dealer
should review the limited warranty provisions with the customer stressing
the importance of filing warranty cards and registrations to the component
manufacturers within the prescribed time limit.

5. Providing the customer with information regarding warranty and non-

warranty work on the vehicle and its separately warranted components
whether the customer is in or out of the area.

Customer Responsibilities

The customer is responsible for regular and proper maintenance of the vehicle.
Properly maintaining your vehicle will prevent conditions arising from neglect
that are not covered by your Newmar limited warranty. The maintenance
guidelines in this manual and any other applicable manual should be followed.
It is your responsibility and obligation to return the vehicle to an authorized
dealer for repairs and service.

2008 Torrey Pine Fifth Wheel by Newmar 2:3

To assist you in avoiding problems with your vehicle, we recommend you do
the following:

A. Read the warranty. Go over it thoroughly with your dealer.

B. Inspect the vehicle. Do not accept delivery until you have gone through

the unit with the dealer. Newmar has provided a check list to be used
during retail delivery. Check each item on the list and make sure the
dealer does the same. Do not sign this checklist until you have done this.

NOTE: The sales literature versus actual specifics to the vehicle’s
measurements, weights, or quantities may vary.

C. Ask questions about anything that you do not understand concerning

your recreational vehicle.

D. When taking delivery, set an appointment for adjustments. This

appointment should be approximately two (2) weeks after you accept
delivery.

E. Responsible Use. Your vehicle is designed to be used for recreational

or temporary living purposes. It is not designed to be used as a full-time
residence or for commercial use. Commercial use means using as a
business asset such as a mobile office or using the vehicle for lease/rental
purposes.

Major Equipment Manufacturers

A & E Awnings ................................................ 800-544-4881

Atlanta DTH, Inc. ............................................. 770-451-9777

Atwood Mobile Product ................................... 815-877-5700

A.S.A. Inc. ........................................................ 574-266-1886

Carefree of Colorado ........................................ 800-621-2617

Collins & Company .......................................... 574-848-1118

Dexter Axle ..................................................... 574-295-1900

Dometic, Duo Therm ........................................ 800-544-4881

Elkhart Tool & Die ........................................... 574-295-8500

Evans Tempcon ................................................ 800-354-7088

FanTastic Vent Corp. ....................................... 800-521-0298

Flexsteel Industries ........................................... 563-556-7730

Ford Motor Company ...................................... 800-444-3311

Freightliner Custom Chassis ................ 800-FTL-HEPropane

Gekotek Electronics (Monitor Panel) ............... 714-738-3551

Generac Generators ......................................... 800-747-1530

Goodyear Tires ................................................ 800-227-1999

HWH Corporation ............................................ 800-494-3213

Hickory Springs Mfg. ....................................... 501-646-6161

Hidden Hitch .................................................... 877-869-6787

2:4 2008 Torrey Pine Fifth Wheel by Newmar

IOTA ................................................................ 877-682-4682

Interstate Batteries - 12 Volt ............................. 800-872-4100

Interstate Batteries - 6 Volt ............................... 888-772-3600

KVH Industries ................................................ 401-847-3327

Kwikee Products .............................................. 800-736-9961

Magic Chef ....................................................... 515-792-7000

Midwest Sales & Service.................................. 574-287-3365

Mito .................................................................. 888-433-6486

Mor-Ryde, Inc. ................................................. 574-293-1581

Nagy Fleet Net, Inc. ......................................... 574-262-4479

Norcold ............................................................ 800-543-1219

Onan Generators ............................................... 800-888-6626

Pioneer .............................................................. 800-777-4856

PowerTech Generators ..................................... 800-760-0027

Putnam Hitch .................................................... 517-369-2165

Quest Corp. ....................................................... 800-877-0521

RFD Components ............................................. 574-295-3939

Scope Seating ................................................... 574-295-6016

SeaLand Technology ........................................ 800-321-9889

Sears ................................................................ 800-359-2000

Sony .................................................................. 800-222-7669

Spartan Motors ................................................. 800-543-4277

Splendide Washer/Dryer .................................. 800-736-4127

Suburban Mfg. .................................................. 423-775-2131

Thetford Toilet ................................................. 800-521-3032

U-Line Ice Maker ............................................. 800-779-2547

Villa International ............................................. 714-535-7272

Vehicle Systems ............................................... 800-685-4298

Ventline (Range Hood) .................................... 574-848-4491

Winegard Antenna Systems ............................. 800-288-8094

Workhorse Custom Chassis .............................. 877-946-7731

Xantrex ............................................................. 800-446-6180

Recreational Vehicle Limited Warranty

The Newmar Corporation Limited Warranty was provided to you by your
selling dealer prior to purchase. Please refer to this document when inquiring
about the Newmar Warranty. To receive an additional copy, please write to:

Newmar Corporation,
Warranty Department,
P.O. Box 30,
Nappanee, IN 46550-0030.

2008 Torrey Pine Fifth Wheel by Newmar 2:5

Warranty Service

Warranty service required needs to be completed during the term of the
warranty. Service work performed after the expiration of the Newmar one (1)
year warranty WILL NOT be covered by the warranty.

Owner’s Information Package

Included in this package are valuable documents about your vehicle and its
components and systems. The Newmar Owner’s Guide does not cover every
possible detail of equipment, standard and/or option, installed on or in your
vehicle. Consulting the booklets and instruction manuals in this package will
help you safely operate, maintain, and troubleshoot these items. Read all of the
information and understand the safety and operating instructions included in
the Owner’s Information Package. To assure full warranty coverage, it is
essential that all maintenance instructions are followed.

Reporting Safety Defects

If you believe that your vehicle has a significant defect which could cause a
crash or could cause injury or death, you should inform the National Highway
Traffic Safety Administration (NHTSA) and Newmar Corporation.

To contact NHTSA, you may either call the Auto Safety Hotline toll free at
1-888-327-4236 (TTY #1-800-424-9153) or write to: NHTSA, 400 Seventh
Street, S.W., Washington, DC 20590. NHTSA also has established a website
where you can contact them:

http://www.safecar.gov

Safety Precautions

Read and understand all of the instructions and precautions in this owner’s
guide before towing your new travel trailer or fifth wheel. Listed below are
some safety precautions that must be adhered to while your vehicle is in
motion. These precautions, as well as others that involve possible damage
to equipment, are also listed in the appropriate areas in this manual.

2:6 2008 Torrey Pine Fifth Wheel by Newmar

Customer Relations

If you wish to schedule maintenance work, schedule service work, or to order
parts you should notify your local authorized Newmar Service Center to set up
an appointment. If you are unsure of the location of your closest Authorized
Newmar Service Center, see the listing in the manual. You may also write to:

Newmar Corporation
Warranty Department
72185 C.R. 3
P.O. Box 30
Nappanee, IN 46550-0030

Information Sheet

There are two main numbers used to identify the vehicle. The Vehicle
Identification Number (VIN) is the legal identification of the completed
vehicle. The VIN is the number used by the state for vehicle registration.
The Newmar Serial Number is a six-digit number that is needed whenever
making an appointment for service or ordering parts through your Newmar
Dealer or Service Center. This number can be found on the placard in the
wardrobe closet wall and on the Customer Care card received from Newmar.

Below is a sample of the Information Sheet.

1. The Newmar Serial Number

2. Year/Brand/Type/Floorplan

3. Vehicle Identification Number (VIN)

4. Manufacturer, Model

and Serial Number of
factory installed
equipment.

2008 Torrey Pine Fifth Wheel by Newmar 2:7

RECOMMENDED SERVICE CENTER LISTING

ALABAMA

MADISON RV CENTER
1707 JORDAN LANE N.W.
HUNTSVILLE AL 35816
Phone [phone]
Fax [phone]

MILLICAN RV AMERICA
36115 US HWY. 280
SYLACAUGA AL 35150
Phone [phone]
Fax [phone]

ALASKA

A & M RV CENTER ­2225 E. 5TH AVE.
ANCHORAGE AK 99501
Phone [phone]
Fax [phone]

KAREN’S RV SERVICE CENTER
1850 VIKING DRIVE
ANCHORAGE AK 99501
Phone [phone]
Fax [phone]

ARIZONA

BEAUDRY RV COMPANY
3200 EAST IRVINGTON RD.
TUCSON AZ 85714
Phone [phone]
Fax [phone]

ED HANNON RV CENTER
3735 E. IRVINGTON ROAD
TUCSON AZ 85714
Phone [phone]
Fax [phone]

MOHAVE RV REPAIR
4144 S. HWY. 95, STE. B
FORT MOHAVE AZ 86426
Phone [phone]
Fax [phone]

ROBERT CRIST RV
2025 E. MAIN STREET
MESA AZ 85213
Phone [phone]
Fax [phone]

RV PEDDLER
4710 E. HWY. 80
YUMA AZ 85365
Phone [phone]
Fax [phone]

STAR VALLEY RV

255248 E. HWY. 260
PAYSON AZ 85541
Phone [phone]
Fax [phone]

SUN CITY RV INC.
9045 NORTHWEST GRAND AVE.
PEORIA AZ 85345
Phone [phone]
Fax [phone]

ARKANSAS

OUTDOOR LIVING CENTER

HWY. 7 SOUTH
P.O. BOX 1081
RUSSELLVILLE AR 72801
Phone [phone]
Fax [phone]

CALIFORNIA

ALPINE RECREATION SLS & SVC
19380 MONTEREY ROAD
MORGAN HILL CA 95037
Phone [phone]
Fax [phone]

DAVE ALTMANS RV
1201 BALDWIN PARK BLVD.
BALDWIN PARK CA 9170
Phone [phone]
Fax [phone]

DAVE ALTMANS RV
22020 RECREATION ROAD
CARSON CA 90745
Phone [phone]
Fax [phone]

DAVE ALTMANS RV
1313 RV CENTER DRIVE
COLTON CA 92324
Phone [phone]
Fax [phone]

EL MONTE RENT’S INC.

12818 FIRESTONE BLVD.
SANTA FE SPRINGS CA 90670
Phone [phone]
Fax [phone]

2:8 2008 Torrey Pine Fifth Wheel by Newmar

GIANT RV

1300 E. SANTO ANTONIO DR.
COLTON CA 92324
Phone [phone]
Fax [phone]

GIANT RV

2200 W. FRONTAGE ROAD
CORONA CA 92882
Phone [phone]
Fax [phone]

GIANT RV

6441 BURT ROAD
IRVINE CA 92618
Phone [phone]
Fax [phone]

GIANT RV

8646 SEPULVEDA BLVD.
NORTH HILLS CA 91343
Phone [phone]
Fax [phone]

GIANT RV

9150 BENSON AVE.
MONTCLAIR CA 91763
Phone [phone]
Fax [phone]

GIANT RV

24700 MADISON AVE.
MURRIETA CA 92562
Phone [phone]
Fax [phone]

GIANT RV

77-840 VARNER ROAD
PALM DESERT CA 92211
Phone [phone]
Fax [phone]

HAPPY DAZE RV

1199 EL CAMINO AVE.
SACRAMENTO CA 95815
Phone [phone]
Fax [phone]

HOLLAND MOTOR HOMES
7490 COPLEY PARK PLACE
SAN DIEGO CA 92111
Phone [phone]
Fax [phone]

MANTECA TRAILER & CAMPER
1990 E. YOSEMITE AVE.
MANTECA CA 95336
Phone [phone]
Fax [phone]

McMAHON’S RV
6441 BURT ROAD #10
IRVINE CA 92618
Phone [phone]
Fax [phone]

PAUL EVERT’S RV COUNTRY
3633 S. MAPLE
FRESNO CA 93725
Phone [phone]
Fax [phone]

RV PEDDLER

8730 GOLDEN STATE HWY.
BAKERSFIELD CA 93308
Phone [phone]
Fax [phone]

TEMECULA VALLEY RV
28897 FRONT STREET
TEMECULA CA 92590
Phone [phone]
Fax [phone]

COLORADO

ALL STARS RV REPAIR

5989 W. LOUVIERS ST.
LOUVIERS CO 80131
Phone [phone]
Fax [phone]

CENTURY RV INC.

4000 N. VALLEY DRIVE
LONGMONT CO 80504
Phone [phone]
Fax [phone]

J D L TRAILER SALES

2734 LAKE AVENUE
PUEBLO CO 81004
Phone [phone]
Fax [phone]

MOUNTAIN STATES RV
14300 E. COLFAX AVENUE
AURORA CO 80011
Phone [phone]
Fax [phone]

PIKE’S PEAK TRAVELAND
4815 E. PLATTE AVE.
COLORADO SPRINGS CO 80915
Phone [phone]
Fax [phone]

2008 Torrey Pine Fifth Wheel by Newmar 2:9

CONNECTICUT

DAVE’S RV CENTER

2 INDUSTRIAL PLAZA ROAD
DANBURY CT 06810
Phone [phone]
Fax [phone]

DELAWARE

PARKVIEW RV CENTER

5511 DUPONT PARKWAY
SMYRNA DE 19977
Phone [phone]
Fax [phone]

SLICERS CAMPING TRAILERS

773 S. DUPONT HWY.
NEW CASTLE DE 19720
Phone [phone]
Fax [phone]

FLORIDA

DICK GORE’S RV WORLD
14590 DUVAL PLACE WEST
JACKSONVILLE FL 32218
Phone [phone]
Fax [phone]

FREIGHTLINER OF SO. FLORIDA
1699 N. US 1
FORT PIERCE FL 34950
Phone [phone]
Fax [phone]

HARBERSON SWANSTON LLC
17028 US HWY. 19 NORTH
CLEARWATER FL 33764
Phone [phone]
Fax [phone]

HARBERSON SWANSTON LLC
2112 US 19 NORTH
HOLIDAY FL 34691
Phone [phone]
Fax [phone]

INDEPENDENCE RV
12705 W. COLONIAL DRIVE
WINTER GARDEN FL 34787
Phone [phone]
Fax [phone]

INDIAN RIVER RV INC.
1698 N. CENTRAL AVE.
SEBASTIAN FL 32958
Phone [phone]
Fax [phone]

INTERNATIONAL RV WORLD
25199 HWY. 27
LAKE WALES FL 33859
Phone [phone]
Fax [phone]

LAND YACHTS
1414 COMMERCE LANE
P.O. BOX 1840
JUPITER FL 33468
Phone [phone]
Fax [phone]

LEISURE TYME RV

1490 HWY. 98 WEST
MARY ESTHER FL 32569
Phone [phone]
Fax [phone]

LEISURE TYME RV
6428 PENSACOLA BLVD.
PENSACOLA FL 32505
Phone [phone]
Fax [phone]

NORTH TRAIL RV CENTER
5270 ORANGE RIVER BLVD.
FORT MYERS FL 33905
Phone [phone]
Fax [phone]
www.northtrailrv.com

TRAVEL EASY SALES & SERVICE
4299 HWY. 441 SOUTH
OKEECHOBEE FL 34974
Phone [phone]
Fax [phone]
www.traveleasyrv.com

GEORGIA

DICK GORE’S RV WORLD INC.
250 LONGWOOD DRIVE
RICHMOND HILL GA 31324
Phone [phone]
Fax [phone]

www.dickgoresrvworld.com

SAGON MOTORHOMES
172 VAN MAR BLVD.
JACKSON GA 30233
Phone [phone]
Fax [phone]

IDAHO

BODILY RV II, INC.
4409 CHINDEN BLVD.
GARDEN CITY ID 83714
Phone [phone]
Fax [phone]

2:10 2008 Torrey Pine Fifth Wheel by Newmar

ILLINOIS

COLLIER RV CENTER
7373 HARRISON AVE.
ROCKFORD IL 61112
Phone [phone]
Fax [phone]

EHRHARDT’S TRAILER SALES
776 W. OAKTON ST.
DES PLAINES IL 60018
Phone [phone]
Fax [phone]

LARRY’S TRAILER SALES
HWY. 148 NORTH
ZEIGLER IL 62999
Phone [phone]
Fax [phone]

R & S SALES & SERVICE
218 S. LAKE OF THE WOODS
MAHOMET IL 61853
Phone [phone]
Fax [phone]
www.rsrvsales.com

BROWN & BROWN
1400 LOCKE DRIVE
BRADLEY IL 60915
Phone [phone]
Fax [phone]

INDIANA

BASDEN’S AMERICAN RV

600 E. BASELINE ROAD
EVANSVILLE IN 47735
Phone [phone]
Fax [phone]

DON’S CAMPER SALES
U.S. 41 S. BOX 373
BOSWELL IN 47921
Phone [phone]
Fax [phone]

HART CITY RV CENTER LLC
2300 S. NAPPANEE STREET
ELKHART IN 46517
Phone [phone]
Fax [phone]

INDY RV CENTER

457 KNIGHT DR.
GREENWOOD IN 46142
Phone [phone]
Fax [phone]

INTERNATIONAL RV WORLD
2300 S. NAPPANEE STREET
ELKHART IN 46517
Phone [phone]
Fax [phone]

PREMIER RV INC.

1400 LEISURE WAY
CLARKSVILLE IN 47129
Phone [phone]
Fax [phone]

TOM STINNETT HOLIDAY RV

520 MARRIOTT DRIVE
CLARKSVILLE IN 47129
Phone [phone]
Fax [phone]

WALNUT RIDGE TRAILER SALES

87 N. CR 300 WEST
NEW CASTLE IN 47362
Phone [phone]
Fax [phone]

WETNIGHT RV SLS & SERVICE

4401 US 41 NORTH
TERRE HAUTE IN 47805
Phone [phone]
Fax [phone]

IOWA

AUTORAMA RV CENTER
2227 SE 14TH
DES MOINES IA 50320
Phone [phone]
Fax [phone]

CHEYENNE CAMPING CENTER
2960 PLAINVIEW ROAD
WALCOTT, IA 52773
Phone [phone]
Fax [phone]

HEROLD TRAILER SALES
1806 W. 2ND AVE., HWY. 92 WEST
INDIANOLA IA 50125
Phone [phone]
Fax [phone]

WALKER TRAILER SALES INC.
HWY. 122 WEST, BOX 633
NORA SPRINGS IA 50458
Phone [phone]
Fax [phone]

2008 Torrey Pine Fifth Wheel by Newmar 2:11

KANSAS

A & R
16685 ORCHARD LANE
STILWELL KS 66085
Phone [phone]
Fax [phone]

HARPER CAMPERLAND
1200 E. 10TH
GREAT BEND KS 67530
Phone [phone]
Fax [phone]

HARPER CAMPERLAND
117 W. 14TH
HARPER KS 67058
Phone [phone]
Fax [phone]
www.harpercamperland.com

JAYHAWK CAMPER SALES
24105 W. 43RD
SHAWNEE KS 66226
Phone [phone]
Fax [phone]

KENTUCKY

BLUEGRASS RV
1675 NORTH BROADWAY
LEXINGTON KY 40505
Phone [phone]
Fax [phone]

SUMMIT RV SALES INC.

6917 US 60
ASHLAND, KY 41102
Phone [phone]
Fax [phone]

YOUNGBLOOD RV CENTER INC.
2132 STATE ROUTE #45 NORTH
MAYFIELD KY 42066
Phone [phone]
Fax [phone]

LOUISIANA

DIXIE RV SUPERSTORES

10241 DESTINATION DRIVE
HAMMOND LA 70403
Phone [phone]
Fax [phone]

MILLER RV
12912 FLORIDA BLVD.
BATON ROUGE LA 70815
Phone [phone]
Fax [phone]

SOUTHERN RV INC.
3625 INDUSTRIAL DRIVE
BOSSIER CITY LA 71112
Phone [phone]
Fax [phone]

MAINE

MOUNTAIN ROAD RV
31 MOUNTAIN ROAD
SABATTUS ME 04280
Phone [phone]
Fax [phone]

MARYLAND

BECKLEY’S CAMPING CENTER
11109 ANGLEBERGER ROAD
THURMONT MD 21788
Phone [phone]
Fax [phone]

MASSACHUSETTS

BOB’S CAMPER & RV
2810 HANCOCK ROAD
WILLIAMSTOWN MA 01267
Phone [phone]
Fax [phone]

STEARNS RV SALES
71 MECHANIC ST.
BELLINGHAM MA 02019
Phone [phone]
Fax [phone]

MICHIGAN

BEECH GROVE TRAILER SALES
51439 M 40 NORTH
MARCELLUS MI 49067
Phone [phone]
Fax [phone]

GENERAL TRAILER SALES
12410 DIXIE HWY.
BIRCH RUN MI 48415
Phone [phone]

GENERAL TRAILER SALES
17277 RACHO ROAD
BROWNSTOWN TWP MI 48192
Phone [phone]
Fax [phone]

GENERAL TRAILER SALES

24583 N. RIVER ROAD
MT. CLEMENS MI 48043
Phone [phone]
Fax [phone]

2:12 2008 Torrey Pine Fifth Wheel by Newmar

GENERAL TRAILER SALES
5300 HIGHLAND ROAD
WATERFORD MI 48327
Phone [phone]
Fax [phone]

GENERAL TRAILER SALES
476 RENO DRIVE
WAYLAND MI 49348
Phone [phone]
Fax [phone]

GENERAL TRAILER SALES
48500 12 MILE ROAD
WIXOM MI 48393
Phone [phone]
Fax [phone]

HILLTOP RV SUPERSTORE

2905 N. LINCOLN ROAD
ESCANABA MI 49829
Phone [phone]
Fax [phone]

INTERNATIONAL RV WORLD
2717 E. DELTA ROAD
BAY CITY MI 48706
Phone [phone]
Fax [phone]

KITSMILLER RV
1211 N. CEDAR
MASON MI 48854
Phone [phone]
Fax [phone]

MIDWAY MOTOR HOMES
5590 S. DIVISION AVE.
GRAND RAPIDS MI 49548
Phone [phone]
Fax [phone]

MODERN TRAILER SALES
7834 S. DIVISION AVE.
GRAND RAPIDS MI 49548-2110
Phone [phone]
Fax [phone]

MINNESOTA

OAK LAKE CAMPGROUND

52777 HOFFMAN DRIVE
KERRICK, MN 55756
Phone [phone]
Fax [phone]

STEINBRING MOTORCOACH
3710 S. HWY. 29
ALEXANDRIA MN 56308
Phone [phone]
Fax [phone]

STENZEL’S CAMPERS
4701 HWY. 169
ELMORE MN 56027
Phone [phone]
Fax [phone]

MISSISSIPPI

AMERICAN RV CENTERS, INC.

8150 CRAFT ROAD
OLIVE BRANCH MS 38654
Phone [phone]
Fax [phone]

RV REPAIR & SALES
4749 HWY. 80 WEST
JACKSON MS 39209
Phone [phone]
Fax [phone]

RV REPAIR & SALES

4749 HWY. 80 WEST
JACKSON MS 39209
Phone [phone]
Fax [phone]

MISSOURI

BEN’S RECREATIONAL VEHICLES

RT. B BOX 167
CANTON MO 63435
Phone [phone]
Fax [phone]

CAPETOWN R V SALES
I 55 & AIRPORT ROAD
CAPE GIRARDEAU MO 63702
Phone [phone]
Fax [phone]

COACHLIGHT RV SALES
5327 S. GARRISON AVE.
CARTHAGE MO 64836
Phone [phone]
Fax [phone]

FRANK REED RV
HWY. 47 NORTH
ST. CLAIR MO 63077
Phone [phone]
Fax [phone]

K C TRAILER SALES
11520 S. 71 HWY.
KANSAS CITY MO 64137
Phone [phone]
Fax [phone]

2008 Torrey Pine Fifth Wheel by Newmar 2:13

MONTANA

BOZEMAN MOTORS INC.
2900 N. 19
BOZEMAN MT 59718
Phone [phone]
Fax [phone]

BRETZ RV & MARINE
RESERVE STREET AT I-90
4800 GRANT CREEK ROAD
MISSOULA MT 59808
Phone [phone]
Fax [phone]

TH

AVE.

NEBRASKA

RICH & SONS CAMPER SALES
5112 S. ANTELOPE DRIVE
GRAND ISLAND NE 68803
Phone [phone]
Fax [phone]

NEVADA

WHEELERS LAS VEGAS RV
13175 LAS VEGAS BLVD. SOUTH
LAS VEGAS NV 89044
Phone [phone]
Fax [phone]

NEW HAMPSHIRE

C.H. DANA RV INC.
628 WOODSVILLE RD.
MONROE NH 03771-3328
Phone [phone]
Fax [phone]

CAMPERS INN OF KINGSTON
146 ROUTE 125
KINGSTON NH 03848
Phone [phone]
Fax [phone]

MOUNTAIN VALLEY RECREATION

410 MAIN STREET
GORHAM NH 03581
Phone [phone]
Fax [phone]

NEW JERSEY

SCOTT MOTOR COACH SALES
1133 ROUTE 88
LAKEWOOD NJ 08701
Phone [phone]
Fax [phone]

WHITE HORSE LEISURE INC.
980 N. BLACK HORSE PIKE
WILLIAMSTOWN NJ 08094
Phone [phone]
Fax [phone]

NEW MEXICO

AMERICAN HOLIDAY RV
9999 CENTRAL N.E.
ALBUQUERQUE NM 87123
Phone [phone]
Fax [phone]

AMERICAN RV CENTERS, LLC
11810 CENTRAL S.E.
ALBUQUERQUE NM 87123
Phone [phone]
Fax [phone]

NEW YORK

ALL AMERICAN RV/BARRETT
674 QUAKER ROAD
QUEENSBURY NY 12804
Phone [phone]
Fax [phone]

ALPIN HAUS SKI SHOP INC.
1863 ROUTE 5S
AMSTERDAM NY 12010
Phone [phone]
Fax [phone]

ALPIN HAUS SKI SHOP INC.
103 SITTERLY ROAD
CLIFTON PARK NY 12065
Phone [phone]
Fax [phone]

BALLARDS CAMPING CENTER
S - 5849 SOUTHWESTERN BLVD.
HAMBURG NY 14075
Phone [phone]
Fax [phone]

JOURNEYTIME TRAILERS INC.
940 MIDDLE COUNTRY ROAD
SELDEN NY 11784
Phone [phone]
Fax [phone]

SEVEN O’S
7917 DEVAUL ROAD
KIRKVILLE NY 13082
Phone [phone]
Fax [phone]

2:14 2008 Torrey Pine Fifth Wheel by Newmar

WES TRAILER SALES
6166 ROUTE 25
WADING RIVER NY 11792
Phone [phone]
Fax [phone]

WILKINS RV INC.
1099 ALMOND ROAD
HORNELL NY 14843
Phone [phone]
Fax [phone]

WRATTEN TRAILER SALES LLC
9209 ROUTE 11 SOUTH
ADAMS NY 13605
Phone [phone]
Fax [phone]

NORTH CAROLINA

HOWARD RV CENTER
6811 MARKET STREET
WILMINGTON NC 28405
Phone [phone]
Fax [phone]

OLD TOWN CAMPER SALES
5109 NORTH CAUSEWAY DRIVE
WINSTON - SALEM NC 27106
Phone [phone]
Fax [phone]

TOM JOHNSON CAMPING CTR.
6700 SPEEDWAY BLVD.
CONCORD NC 28027
Phone [phone]
Fax [phone]

TOM JOHNSON CAMPING CTR.
1885 US 70 WEST
MARION NC 28752
Phone [phone]
Fax [phone]

NORTH DAKOTA

CAPITAL RV CENTER

1900 N. BISMARCK EXPY
BISMARK ND 58501
Phone [phone]
Fax [phone]

ARBOGAST RV DEPOT
3540 SOUTH COUNTY ROAD 25A
TROY OH 45373
Phone [phone]
Fax [phone]

BEGGS RV CENTER
11197 CLEVELAND AVE NW
P.O. BOX 545
UNIONTOWN OH 44685
Phone [phone]
Fax [phone]

www.beggsmotorhomes.com

BEGGS RV CENTER

6075 DRESSLER ROAD NW NORTH
CANTON OH 44720
Phone [phone]
Fax [phone]

COLERAIN RV

3491 STRUBLE ROAD
CINCINNATTI OH 45251
Phone [phone]
Fax [phone]

FARBER MOTORS
5858 SCARBOROUGH BLVD.
COLUMBUS OH 43232
Phone [phone]
Fax [phone]

YONAKS INC.
46293 BELMONT CENTERVILLE
BELMONT OH 43718
Phone [phone]
Fax [phone]

OKLAHOMA

DAVE’S CLAREMORE RV
24655 SOUTH HWY. 66
CLAREMORE OK 74019
Phone [phone]
Fax [phone]

LEE’S RV CITY
13111 N. BROADWAY EXT.
EDMOND OK 73083-6250
Phone [phone]
Fax [phone]

OHIO

AMOS MOTOR & RV
109 S MAIN STREET
BRADNER OH 43406
Phone [phone]
Fax [phone]

2008 Torrey Pine Fifth Wheel by Newmar 2:15

OREGON

AL’S TRAILER SALES OF SALEM
31873 OLD HWY. 34
TANGENT OR 97389
Phone [phone]
Fax [phone]

CARRIER & SONS RV SERVICE
29525 AIRPORT ROAD
EUGENE OR 97402
Phone [phone]
Fax [phone]

EUGENE RECREATION SALES
1700 HWY. 99 NORTH
EUGENE OR 97402
Phone [phone]
Fax [phone]

LARRY’S RV INC.

20630 GRANDVIEW DR.
BEND, OR 97701
Phone [phone]
Fax [phone]

OLINGER TRAVEL HOMES

6503 ALEXANDER
HILLSBORO OR 97123

Phone [phone]
Fax [phone]
www.olingertravelhomes.com

OLINGER TRAVEL HOMES

24000 NE SANDY BLVD.
PORTLAND OR 97060
Phone [phone]
Fax [phone]

THE RV CORRAL
1890 HWY. 99 NORTH
EUGENE OR 97402
Phone [phone]
Fax [phone]

TRIPLE A RV CENTER INC.
938 CHEVY WAY
MEDFORD OR 97504
Phone [phone]
Fax [phone]

PENNSYLVANIA

ANSLEY RV
1280 ROUTE 764
DUNCANSVILLE PA 16635
Phone [phone]
Fax [phone]

COUNCIL CUP TRAILER SALES
ROUTE 239
WAPWALLOPEN PA 18660
Phone [phone]
Fax [phone]

HAROLD’S RV CENTER
7514 BETH BATH PIKE
BATH PA 18014
Phone [phone]
Fax [phone]

TOM SCHAEFFER’S CAMPING AND
TRAVEL CENTER, INC.

1236 POTTSVILLE PIKE
SHOEMAKERSVILLE PA 19555
Phone [phone]
Fax [phone]

RHODE ISLAND

ARLINGTON RV SUPER CENTER
966 QUAKER LANE
EAST GREENWICH RI 02818
Phone [phone]
Fax [phone]

SOUTH CAROLINA

JOHN’S RV SALES & SERVICE
242 GLASSMASTER ROAD
LEXINGTON SC 29072
Phone [phone]
Fax [phone]

TONY’S RV PARTS & SERVICE
130 POND BRANCH RD
LEXINGTON SC 29073
Phone [phone]
Fax [phone]

TENNESSEE

BUDDY GREGG MOTOR HOMES
11730 SNYDER ROAD
KNOXVILLE TN 37933
Phone [phone]
Fax [phone]

SHADRACK WATERSPORTS INC.
2537 VOLUNTEER PARKWAY
BRISTOL TN 37620
Phone [phone]
Fax [phone]

TEXAS

AMERICAN RV CENTERS, LLC

8805 NORTH DESERT BLVD.
ANTHONY TX 79821
Phone [phone]
Fax [phone]

CAMPER COACHES LTD.
1701 SOUTH LOOP 289
LUBBOCK TX 79423
Phone [phone]
Fax [phone]

2:16 2008 Torrey Pine Fifth Wheel by Newmar

EAST TEXAS RV SALES
P.O. BOX 250
KIRBYVILLE TX 75956
Phone [phone]
Fax [phone]
RON HOOVER CO.
29277 I.H. 10 WEST
BOERNE TX 78006
Phone [phone]
Fax [phone]

RON HOOVER CO.

101 EXPRESSWAY 83
DONNA TX 78537
Phone [phone]
Fax [phone]

RON HOOVER CO.
16465 KATY FREEWAY
HOUSTON, TX 77094
Phone [phone]
Fax [phone]

RON HOOVER CO.
1510 W. MARKET STREET
ROCKPORT TX 78382
Phone [phone]
Fax [phone]

VOGT MOTOR HOMES
5624 AIRPORT FREEWAY
FORT WORTH TX 76117
Phone [phone]
Fax [phone]

UTAH

TRAVEL VILLAGE

4360 S. STATE
MURRARY UT 84107
Phone [phone]
Fax [phone]

VERMONT

VT COUNTRY CAMPER SALES
1498 ROUTE 2
E. MONTPELIER VT 05651
Phone [phone]
Fax [phone]

VIRGINIA

CHEEK & SHOCKLEY RV’S INC

2600 MECHANICSVILLE PIKE
RICHMOND VA 23223
Phone [phone]
Fax [phone]

KOOGLER SALES & SERVICE

2247 JEFFERSON HWY.
FISHERSVILLE VA 22939
Phone [phone]
Fax [phone]

WASHINGTON

CHIEF’S RV CENTER

1120 N. 28TH AVE.
PASCO WA 99302
Phone [phone]
Fax [phone]

WATT’S RV CENTER
22401 88
KENT WA 98031
Phone [phone]
Fax [phone]

WESTERN MOTOR COACH
19303 HWY. 99
LYNNWOOD WA 98036
Phone [phone]
Fax [phone]

TH

AVE.

WEST VIRGINIA

TRAILER CITY INC.
2045 FAIRMONT AVE.
FAIRMONT WV 26554
Phone [phone]
Fax [phone]

WISCONSIN

A O K RV SALES
5723 FREITAG DRIVE
MENOMONIE WI 54751
Phone [phone]
Fax [phone]

FINNEGANS RV
205 PARK AVE.
BELOIT WI 53511
Phone [phone]
Fax [phone]

HORN’S SALES & SERVICE
8120 S. FRONTAGE ROAD
SHEBOYGAN WI 53081
Phone [phone]
Fax [phone]

WYOMING

EASTSIDE MOTORS & RV’S INC.
1200 E. SECOND ST.
GILLETTE WY 82717
Phone [phone]
Fax [phone]

2008 Torrey Pine Fifth Wheel by Newmar 2:17

JOLLEY ROGERS RV
6102 E. HWY. 30
CHEYENNE WY 82001
Phone [phone]
Fax [phone]

ALBERTA

MAJESTIC RV WORLD
2777 SUNRIDGE BLVD. NE
CALGARY AB T1Y 3C2
Phone [phone]
Fax [phone]

VELLNER LEISURE PRODUCTS
1890 49 AVENUE
RED DEER AB T4R 2N7
Phone [phone]
Fax [phone]

WOODY’S RV WORLD
1702 49TH AVENUE
RED DEER AB T4R 2N7
Phone [phone]
Fax [phone]

BRITISH COLUMBIA

MIDTOWN RV LTD.
310 INDUSTRIAL AVE. WEST
PENTICTON BC V2A 9B3
Phone [phone]
Fax [phone]

TRAVELAND RV SUPERCENTER
20529 LANGLEY BY PASS
LANGLEY BC V3A 5E8
Phone [phone]
Fax [phone]

TRIANGLE RV CENTRE LTD.
10299 MC DONALD PARK ROAD
SIDNEY BC V8L 5X7
Phone [phone]
Fax [phone]

MANITOBA

WALT’S TRAILER SALES LTD.
5195 PORTAGE AVE.
HEADINGLY MB R4H 1E1
Phone [phone]
Fax [phone]

NOVA SCOTIA

FRASERWAY RV CENTRE LTD.
212 ROCKY LAKE DRIVE
BEDFORD NS B4A 2T7
Phone [phone]
Fax [phone]

ONTARIO

1000 ISLANDS RV CENTRE INC.

409 COUNTY ROAD #2
GANANOQUE ON K7G 2V4
Phone [phone]

Fax [phone]

RV WAREHOUSE

65 REIVE BLVD.
COOKSTOWN ON L0L 1L0
Phone [phone]
Fax [phone]

WILLIAM PATTERSON RV SALES

28359 PIONEER LINE
DUTTON ON N0L 1JO
Phone [phone]
Fax [phone]

QUEBEC

MOTORISES LE BLANC SAGUENAY,
INC.

1950 DES LAURENTIDES BLVD.
VIMONT LAVAL PQ H7M 2Y2
Phone [phone]
Fax [phone]

SASKATCHEWAN

MANITOBA

WALT’S TRAILER SALES LTD.
5195 PORTAGE AVE.
HEADINGLY MB R4H 1E1
Phone [phone]
Fax [phone]

#1 RV CENTRE LTD.
HWY. #1 EAST & THATCHER DR.
MOOSE JAW SK S6H 4N9
Phone [phone]
Fax [phone]

2:18 2008 Torrey Pine Fifth Wheel by Newmar

IMPORTANT RV TIRE INFORMATION

READ AND UNDERSTAND THE FOLLOWING INFORMATION
BEFORE TAKING YOUR FIRST TRIP IN YOUR RV!

WARNING

Routine maintenance on your RV is important, but it cannot be overstated
just how critical proper tire maintenance is to the safety, operation, and
durability of your new unit.
To insure your tires are operating safely, regular inspection of your tires,
and checking of tire pressures is absolutely mandatory. FAILURE TO

FOLLOW PROPER INFLATION GUIDELINES MAY RESULT IN TIRE
FAILURE, WHICH, UNDER CERTAIN CIRCUMSTANCE CAN CAUSE LOSS
OF VEHICLE CONTROL OR ACCIDENTS THAT MAY RESULT IN PROPERTY
DAMAGE, BODILY INJURY, AND / OR DEATH.

For safe operation and maximum weight carrying capacity, it is imperative
that the tires be inflated to and maintained at the listed tire pressures on
the Federal ID Tag that is affixed to the interior wall just behind the driver’s
seat in motorhomes, and to the lower front corner of the road side sidewall
on fifth wheel trailers. Below is a sample of the Federal ID Tag you will find
with your RV.

IT IS PARAMOUNT TO THE SAFE OPERATION OF THE VEHICLE TO
MAINTAIN PROPER TIRE PRESSURES. TIRE PRESSURES SHOULD BE
CHECKED AND ADJUSTED BEFORE AND AFTER EACH TRIP, AND
SHOULD ALWAYS BE CHECKED AND ADJUSTED WITH THE TIRES COLD.
NEVER ADD OR RELEASE PRESSURE FROM THE TIRES WHEN THEY
ARE HOT (AFTER HAVING DRIVEN A MILE OR MORE).
For additional information on your tires, contact the Newmar Corporation.

2008 Torrey Pine Fifth Wheel by Newmar 2:19

SAFETY PRECAUTIONS

Towing

While driving on slippery surfaces, use care when accelerating or decelerating.
Skidding and loss of vehicle control may be the result of abrupt changes in
speed.

Driving through water deep enough to wet the brakes may affect the stopping
distance or cause the vehicle to pull to one side. If you have driven through
deep water, check the brake operation in a safe area to be sure they have not
been affected. Never operate a vehicle if a difference in braking efficiency
is noticeable.

Extreme terrain and adverse weather may affect the handling and/or
performance of your vehicle.

Propane Gas

While the Propane tanks must be removed before refilling, it is recommended
that all pilot lights are extinguished and appliances turned off. Smoking is also
prohibited at this time. Exhaust gases, which contain carbon monoxide (an
odorless, colorless, and poisonous gas), are produced by burned gasoline,
diesel or Propane gas in items such as the range, tow vehicle engine, generator
engine, refrigerator, furnace, and water heater. These fumes should not be
inhaled.

An open flame is never to be used to test for Propane gas leaks. All protective
covers and caps must be replaced after filling the Propane system. Once the
Propane valve is closed, securely latch the Propane door. Propane gas and
natural gas are not interchangeable. Never connect natural gas to the Propane
gas system.

The use of equipment such as wood and charcoal grills and stoves inside this
recreational vehicle may cause fires or asphyxiation.

Propane Gas System General Information

A warning label has been placed near the Propane gas container(s). This label
reads:

2:20 2008 Torrey Pine Fifth Wheel by Newmar

Over filling the Propane gas container can result in uncontrolled gas flow,
which can cause fire or explosion. A properly filled container will hold
approximately 80 percent of its volume as liquid Propane gas.

The Propane gas system components in your unit have been approved for use
in camping vehicles by a nationally recognized testing laboratory. Propane gas
is a clean-burning dependable fuel when properly handled. The Propane gas
tank(s) mounted on your unit contain liquid petroleum gas under high pressure.
The liquid gas vaporizes as the fuel is used and passes through the tank valve
to a regulator that automatically reduces the pressure. The low-pressure gas is
then distributed to the appliances through the pipe manifold system. Appliance
lighting problems are commonly caused by an improperly adjusted gas
regulator. Never attempt to reset the regulator yourself. Have an authorized
service technician make any necessary adjustments. We recommend that you
have the Propane gas system checked by an authorized service technician at
least once a year, and after every extended trip. Although the manufacturer and
dealer test carefully for leakage, travel vibrations could loosen fittings. Leaks
can be easily found by applying leak detector solutions at the connections.
If leak detector solution is not available, a soapy water solution made with dish
soap can be used. Tightening the fitting usually stops any leaks. If this does not
work, shut off the main gas valve at the tank and immediately consult an
authorized technician for repairs. If a leak is suspected, the identifying odor
smells similar to rotten eggs (sulfur). Never test for a leak by lighting a match
or have an open flame where you suspect leaking gas.

WARNING

DO NOT FILL CONTAINER(S) TO MORE THAN 80 PERCENT OF CAPACITY.

WARNING

Propane gas containers, gasoline or other flammable liquids shall not be placed
or stored inside the vehicle because fire or explosion may result. Propane gas
containers are equipped with safety valves that relieve excessive pressure by
discharging gas into the atmosphere.

2008 Torrey Pine Fifth Wheel by Newmar 2:21

Propane Regulator

The regulator acts as the heart for the Propane gas system. The Propane gas in
the tank is under high pressure. The regulator reduces the pressure of this gas
so that it is safe to use with the various appliances in your unit. If corrosion is
noticed, contact a qualified Propane gas service technician. Do not adjust the
regulator. It is factory preset. Adjustments are to be made by a qualified
Propane service technician using specialized equipment. Propane gas
regulators must always be installed with the diaphragm vent facing downward.
Regulators that are not in compartments have been equipped with a protective
cover. Make sure that the regulator vent faces downward and that the cover is
kept in place to minimize the vent blockage that could result in excessive gas
pressure causing fire or explosion.

Propane Distribution Lines

The primary manifold is a black steel pipe running the length of your unit.
Most secondary lines leading to gas appliances are made of copper tubing with
flare fittings. If any of the gas lines rupture, do not attempt to splice them.
Always run a new line. We recommend gas distribution work be performed by
an authorized service technician. The main valve at the Propane tank must be
closed when removing or servicing any gas appliance. This will prevent
dangerous gas leakage that could result in an explosion and possibly serious
injury. If a leak is suspected, have the systems inspected and repaired by a
qualified service technician.

WARNING

Shut off the main gas valve at the tank when the camping vehicle is not in use.
Also, shut off the valve when refueling to avoid potential danger from pilot lights
igniting fuel fumes. Some appliances, such as the refrigerator, water heater, and
furnace, have DSI (direct spark ignition) boards so it is important that you turn
the appliances off when the Propane gas is off. The ignition in the appliances
will continue to spark even if there is no Propane gas available.

Precautions & Recommendations

• Inspect the Propane fill valve for foreign materials before refueling.

• Shut the pilot lights off prior to refueling Propane gas tanks.

• Never check for gas leaks with an open flame (match, etc.).

2:22 2008 Torrey Pine Fifth Wheel by Newmar

• Gas lines should be visually inspected periodically.

• Have the gas system inspected yearly and before and after extended

trips.

• The gas system should be inspected and repaired by qualified

technicians only.

Fire Safety

The possibility of fire exists in all areas of life, and the recreational life-style
is no exception. Recreational vehicles are complex machines. They are made
up of many materials, some of which are flammable. Like most hazards, the
possibility of fire can be minimized, if not totally eliminated. This is done by
recognizing the danger and practicing common sense safety and maintenance
habits. For safety reasons, your unit is furnished with both a fire extinguisher
and a smoke alarm.

Fire Extinguishers

The fire extinguisher is rated for Class B (grease, gasoline, diesel fuel,
flammable liquids) and Class C (electrical) fires. These are the most common
types of fires in vehicles. Read the operator’s manual and the instructions on
the fire extinguisher. Be sure to know how and when to use the extinguisher
and where it is located. Fire extinguishers are mechanical, pressurized devices.
Care must be exercised when they are handled. They must be maintained as
the operator’s manual instructs for proper and safe operation. The extinguisher
should be inspected at least once a month. More frequent inspections may be
required if the extinguisher is exposed to the weather or to possible tampering.
Do not test the extinguisher by partially discharging. Doing this will cause a
loss of pressure.

If a fire occurs in the vehicle, evacuate the vehicle as quickly and as safely as
possible. Consider the cause and the severity of the fire and the risk involved
before trying to extinguish it. If the fire is major or fuel fed, move away from
and stand clear of the vehicle and wait for emergency assistance to arrive.

WARNING

The Propane system in your recreational vehicle is designed for liquefied
petroleum gas only. Never attempt to connect natural gas or butane gas in this
system.

2008 Torrey Pine Fifth Wheel by Newmar 2:23

Smoke Detector

The battery powered smoke detector is mounted on the ceiling in the living
area of the unit. Read the operating instructions for details on the testing and
care for this important safety device. Test the smoke detector after the unit has
been in storage, before each trip, and at least once a week during use. The
detector should never be disabled because of nuisance or false alarm from
cooking smoke or a dusty furnace. Ventilate the unit with fresh air and the
alarm will shut off.

Never disconnect or remove the battery from the smoke alarm. The battery
should be replaced once a year or when the low battery signal sounds.

Emergency Exit Window

In the bedroom or slide out of the unit, there may be an emergency exit
(egress) window. This window is designed to be used as an additional exit in
emergency situations. It can be easily identified by the red handle and the red
EXIT label. To open the egress window, lift the handle and push outward on
the window. The window can be closed by pulling the window shut and
lowering the handle in the down or locked position.

Weight Information

Below is a sample of a weight information label which may appear in your
unit.

2:24 2008 Torrey Pine Fifth Wheel by Newmar

Weighing the Unit

The following definitions are given to help in communications of issues
of weight and your unit.

GAWR: Gross Axle Weight Rating is the maximum permissible weight for

an axle.

GCWR: Gross Combination Weight Rating is the value specified by the

manufacturer of the vehicle as the maximum allowable loaded weight of
this motorhome and any towed trailer or towed vehicle.

GVWR: Gross Vehicle Weight Rating is the maximum permissible weight

of this fully loaded motorhome. The GVWR is equal to or greater than the
sum of the Unloaded Vehicle Weight plus the Cargo Carrying Capacity.

UVW: Unloaded Vehicle Weight is the weight of this motorhome as built

at the factory with full fuel, engine oil, and coolants. The UVW does not
include cargo, fresh water, Propane gas, or dealer installed accessories.

CCC: Cargo Carrying Capacity is equal to GVWR minus each of the

following: UVW, full fresh (potable) water weight (including water
heater), full Propane-Gas weight and SCWR.

GVW: Gross Vehicle Weight is the weight of the unit with all items and

supplies that are loaded into the unit at any point in time.

SCWR: Sleeping Capacity Weight Rating is the manufacturer’s designated

number of sleeping positions multiplied by 154 pounds (70 kilograms).

NOTE: The sales literature may give approximates or standards. Each

individual unit may weigh differently based on the factory and/or dealer
options added. To assure the accuracy of your weights be sure the unit is
always level during weighing. The unit has been built to comply with the
component suppliers recommended limits and give you a realistic CCC.
When loading the unit, distribute the items so that not all of the weight is
added to one area of the unit. If you have questions as to what the weight
of the unit is after it has been loaded, take the unit to a drive-on scale or
use individual wheel scales and verify that the weights are within the
limits of those specified for the unit. When weighing the unit, follow these
instructions. Failure to follow these instructions may give an erroneous
weight reading.

1. Pull the unit onto the scales shown in Fig. 1. This is the total weight of

the unit. To do this, put the front jacks down far enough to take all of the
weight off of the tow vehicle and onto the scales. Make sure that only the
trailer is on the scales. Record the weight. This is the GVW and should
not exceed the GVWR supplied by Newmar for the unit.

2008 Torrey Pine Fifth Wheel by Newmar 2:25

2. Hook up to the unit and be sure, again, that there is no part of the tow

vehicle on the scales as shown in Fig 2. Weigh the unit with only the
trailer tires on the scales. Record the weight. This is the total weight on
the axles. When this amount is subtracted from the GVW (first reading),
the difference is the hitch weight. To achieve the approximate weight on
each axle, divide the weight from Fig. 2 by the number of axles. This
amount should not exceed the GAWR of the unit. For example 9,360
pounds with 2 axles is 4,680 pounds per axle or approximately 2,340
pounds per tire.

Hitching Fifth Wheels

Hooking the fifth wheel will become quite simple after a little practice. Follow
the steps listed below.

1. Adjust the fifth wheel jacks until the trailer is at the height level for

hooking to the tow vehicle.

2. Place wheel chocks behind the wheels of the coach.

IMPORTANT

Your fifth wheel is equipped with electrically activated trailer brakes. Make sure
the proper brake controls are installed and in working order before traveling. Be
sure that there is a positive and negative line from the battery of the tow vehicle
to the seven-way plug on the fifth wheel. This will assure that there is adequate
electrical current to the braking system at all times.

3. Release the fifth wheel lock handle.

4. Align the tow vehicle so the fifth wheel will accept the kingpin.

5. Back the tow vehicle slowly into the fifth wheel until the kingpin engages

in the fifth wheel lock, automatically locking.

6. Verify that the lock is closed.

7. Connect the electrical pigtail between the fifth wheel and the tow vehicle.

8. Connect the break away switch line. Be sure the break away switch cable

is not attached to any part of the tow vehicle hitch assembly. Make sure
there is enough slack in the break-away cable to allow for turning.

9. Adjust the mirrors on the tow vehicle.

10. Check all of the lights on the fifth wheel and the tow vehicle (running

lights, brake and tail lights, turn signal lights, and back up lights).

11. Pick up and store the wheel chocks.

2:26 2008 Torrey Pine Fifth Wheel by Newmar

12. Check the inside of the coach to verify that everything is stored properly,

vents are closed, all of the doors and drawers are shut, and the TV
antenna lowered. Close the entrance door and retract the steps.

13. Raise the fifth wheel jacks so the entire hitch load is on the tow vehicle.

The jacks should be about 2 off of the ground. Do not raise the jacks
completely until you have tested the brake control. This will also test the
hook-up.

14. Pull the unit forward and apply the hand control for the trailer brakes to

be sure they are operating properly.

15. Completely raise the fifth wheel jacks.

Campsite Parking

If the campground does not have drive through sites, it is recommended to stop
near the site and inspect it for slopes or uneven areas. Carefully back into the
site. Watch for low-hanging limbs, posts, large rocks or other obstacles. Back
in so the site is on the driver’s left. This will enable the driver to watch the rear
of the unit. Maneuver the vehicle into position before backing into the site.
Back up slowly, using the side mirrors as a guide or with the assistance of
another person outside, guiding the parking procedure.

Place the tow vehicle in park and turn off the ignition. Block all of the trailer
wheels with wheel chocks. Side to side leveling should be done by using shims
under the tires on the low side of the unit after it has been backed into the site.
This must be done before disconnecting the trailer from the tow vehicle. Lower
the stabilizing jacks, if installed. Connect the 120 volt shore power to the unit.
Open the Propane gas valves at the Propane tanks. Connect the fresh water
supply and sanitize the water systems (see Chapter 11), if necessary. Connect
the waste drain hose to the sewer hookup. Start the refrigerator, water heater,
and furnace, if needed. Light the oven pilot light, if applicable. Remember that
the refrigerator will not operate efficiently if the unit is not level.

2008 Torrey Pine Fifth Wheel by Newmar 2:27

SECOND OWNER INFORMATION

Newmar Corporation strives to keep the most accurate and current customer
information on file.

If you purchased this unit new, we have your information from the registration
form on file. However, if you purchased this unit as used, then we asked that
you complete the following information and mail it, or fax it, to us so that we
can be certain that our records are updated.

Upon receipt of this form, we will send you a warranty registration card. This
card is to be presented when you are having warranty work done on your unit
at an authorized Newmar Service Center. Please note the date of purchase on
the card will reflect that of the original date the vehicle was purchased, and is
the date applicable warranties originated.

If you have any questions, please contact a Newmar representative.

Today’s Date _______________ Newmar Coach #_______________

Year/Brand/Type ____________ VIN #________________________

Customer Full Name _________________________________

Customer Full Address _________________________________

_________________________________

_________________________________

Purchased from _________________________________

Address _________________________________

_________________________________

Send to: Newmar Corporation

Attention Service Department

PO Box 30

Nappanee, IN 46550

Fax # [phone]

2:28 2008 Torrey Pine Fifth Wheel by Newmar

Chapter 3

HVAC, APPLIANCES & ACCESSORIES

HEATING & AIR CONDITIONING ................. 3

Air Conditioning ........................................................... 3

Furnace ......................................................................... 4

Propane Bottles ........................................................... 5

Propane Bottle Filling .................................................. 6

Propane Leak Detector ................................................ 6

Propane Regulator ....................................................... 7

MAJOR APPLIANCES ................................... 7

Refrigerator .................................................................. 7

Microwave ..................................................................... 8

Range Hood .................................................................. 9

Range ............................................................................ 9

Television Antenna .................................................... 10

Television ................................................................... 11

Video Control Center ................................................. 12

Cable & Telephone Jack ............................................ 12

Satellite Prep .............................................................. 12

Stereo / Surround Sound System ............................. 12

Water Heater ............................................................... 13

Water Heater Storage ................................................ 13

Pressure Relief Valve ................................................ 14

Washer/Dryer (Optional) ............................................ 14

Ceiling Fan .................................................................. 15

Central Vacuum System (optional) .......................... 15

2008 Torrey Pine Fifth Wheel by Newmar 3:1

3:2 2008 Torrey Pine Fifth Wheel by Newmar

HEATING & AIR CONDITIONING

Air Conditioning

The roof mounted central air conditioner installed on your unit will operate
only when the unit is supplied with 120 volt AC power from the power cord or
the optional generator. The air conditioner circuit breaker must be in the ON
position for it to work. The unit may be equipped with two air conditioners, if
an option package was installed. Park the vehicle in the shade with the drapes
or blinds closed for the best performance. Set the thermostat to the desired
temperature while keeping the doors and windows closed. Keep in mind that
air conditioners use a large portion of the available electric power.

RV parks may experience low voltage on days with high heat or humidity.
This is commonly referred to as a brown out. A brown out may trip the air
conditioner circuit breaker. The circuit breaker protects your air conditioner
motor from damage and is necessary during low voltage conditions. The
tripping breaker is not a fault in your electrical system. The cool air from the
air conditioner is ducted throughout the coach through the cool air ceiling
ducts. Warm air is returned to the air conditioner through return air ceiling
ducts. Below is the thermostat that controls the air conditioner. It also controls
the furnace. Simply select the desired temperature. The blower will cycle
automatically, or you may choose low, medium or high fan settings.

Step One: Select

“system” to be used
(cool or furnace).*

Step Two: Select fan

mode (“on” runs
constantly, “auto”
cycles fan on and off
with A/C or furnace).

Step Three: Select fan

speed (“Hi” or “Lo”).

Step Four: Select

desired temperature.

*Expect a 2-minute delay for compressor to start.

2008 Torrey Pine Fifth Wheel by Newmar 3:3

Furnace

The furnace(s) installed in your unit is a forced-air furnace fueled by Propane
gas. If your unit is equipped with two furnaces, the living area furnace is
controlled by the air conditioner wall thermostat that controls the heating, and
cooling of the unit. The furnace installed in the bath/bedroom area is controlled
by the thermostat in the bedroom. The heat is supplied to the unit through
ducts in the floor. The furnace will not operate properly if the air flow at the
floor registers, or the air return to the furnace, is blocked by personal or
storage items. Storage under the cabinets should be done carefully to prevent
crushing or damaging the furnace ducting or blocking of the cold air return.
Smoke and fumes may be created as a result of the residual burn off of the
manufacturing compounds that are sometimes present the first time the furnace
is used. This is normal.

To minimize the smoke and fumes, the initial lighting of the furnace should
be done with the windows and doors open. Continue until the residue is
completely burned off. To operate, set the thermostat to the desired
temperature setting and turn the thermostat to the on position. Allow 60
seconds for the furnace to begin operating. To shut down the furnace, turn the
thermostat to the off position. After the furnace has been turned off, the fan
will run for approximately 60 seconds to cool down.

For your safety, do not use gasoline or other flammable liquids in the vicinity
of the furnace or any other appliance. Clean the complete furnace and air tube
passageways periodically to remove dust, lint, etc. Check the gas system for
leaks at least once a year. Check and clean the blower wheel annually. On the
exterior of the coach you will find a furnace cover. There are no owner
serviceable parts on the furnace. This cover should be removed by authorized
service technicians only. The furnace should be thoroughly cleaned before the
start of each heating season. Any debris in the system may restrict air flow for
combustion, bind the combustion air impeller, or prevent the blower motor
from running properly. Also, check the burner pilot orifices for debris. Lint
accumulations may cause the blower to become unbalanced, vibrate, restrict
the ability of the blower to move air. If lint is blown into the heat exchanger,
it may cause odors or create a fire hazard. Contact an authorized service
technician for annual cleaning. Consult the manufacturer’s operating
instructions in your Owner’s Package for further information.

3:4 2008 Torrey Pine Fifth Wheel by Newmar

WARNING

Use caution when washing the exterior of your vehicle. Water should not be
sprayed directly into the furnace vent. If water is forced beyond the rain baffles
into the furnace vent, rusting of the furnace could occur. This could also cause
improper combustion.

WARNING

Never attempt to modify this furnace. Fire, explosion, asphyxiation, or carbon
monoxide poisoning may occur. If the furnace malfunctions, consult a trained
service technician.

Propane Bottles

This unit is equipped with two 30# Propane bottles. Two 40# Propane bottles
may be installed as an option. These bottles are controlled with an automatic
pressure regulator. The Propane bottles contain liquid petroleum gas under
high pressure. As the fuel is used, the liquid gas vaporizes and passes through
the tank valve to a regulator that automatically reduces the pressure. The low­pressure gas is then distributed to the appliances throughout the pipe manifold
system. Improperly adjusted regulators are the major cause of appliance
lighting problems. Never attempt to reset the regulator. This is to be done by a
qualified service technician. While in high altitudes or extreme cold weather
a gas shortage may be experienced. Using one appliance at a time can help
adjust to this problem.

It is recommended to have the Propane system inspected by an authorized
service technician at least once a year and after every extended trip. This
system is tested by both the manufacturer and the dealer. Leaks can be caused
by travel vibrations, therefore routine inspections are recommended.

The primary gas manifold is a black steel pipe running the length of the unit.
All secondary lines leading to the gas appliances are made of copper tubing
with flare fittings. If any of these lines rupture do not attempt to splice them.
Always have a new line ran. Gas distribution work must be performed by an
authorized service technician. When removing or servicing any gas appliance,
close the main gas valve at the Propane bottles. This will prevent dangerous

2008 Torrey Pine Fifth Wheel by Newmar 3:5

gas leakage that could result in an explosion and possible serious injury. If a
gas leak is suspected, have the system inspected and repaired by a qualified
service technician as soon as possible.

Propane Bottle Filling

Do not fill the bottles to more than 80 percent of capacity. Fire or

explosion may be the result of uncontrolled gas flow from an overfilled

tank.

WARNING

The main gas valve must be shut when the vehicle is not in use. Shut the valve
off when refueling to avoid potential danger from pilots lights igniting fuel fumes.
Gas valves on appliances with direct spark ignition (DSI) should also be in the
off position. Do not store Propane, gasoline, diesel, or other flammable liquids
inside the vehicle. Fire or an explosion could be the result of ignoring this
warning.

WARNING

Portable fuel burning appliances are not safe for heating inside the recreational
vehicle. Asphyxiation or carbon monoxide poisoning can occur.

The presence of moisture in Propane fuel causes the regulators to freeze. The
moisture will pass through the cylinder valve and into the regulator where
freezing occurs. To help prevent the regulator from freezing, always keep the
tank control valve closed when not in use, even when the tank is empty, to
prevent moisture from collecting on the inside. If moisture becomes a problem,
consult an authorized Propane service center for assistance.

Propane Leak Detector

Liquid Propane (Propane) Gas is heavier than air and will settle to the lowest
point of the room, which is generally on the floor of your coach. Because of
this, the Propane detector installed in your coach is located near the floor. The
detector is also sensitive to other fumes, such as hair spray, which contain
butane as the propellant. Butane, like propane, is heavier than air and will
settle to the floor level where it may be detected. When this occurs, press the
reset button to stop the alert sound for 60 seconds.

3:6 2008 Torrey Pine Fifth Wheel by Newmar

The detector is equipped with a sensor activation strip. This strip must be
removed for the detector to operate properly. This should have been done
during the dealer’s Pre-Delivery Inspection. Please check the detector to verify
that the activation strip has been removed. Please consult your Propane
detector User’s Guide for more detailed information.

WARNING

Never check gas lines for leaks with an open flame. Do not check for leaks
using ammoniated or chlorinated household type detergents. These detergents
can cause cracks to form on the metal tubing and brass fittings. Take the unit to
a qualified Propane gas service technician to find and repair the leak. Keep the
tank valve closed and all of the appliances turned off when the unit is stored. If
any of the Propane gas valves do not close leak-tight by hand, consult a service
technician.

Propane Regulator

The regulator is the heart of the Propane system. The regulator reduces the
pressure of the gas so it is safe to use with various appliances. Regulators are
equipped with a vent. In the event excess pressure builds up in the body of the
regulator, a relief mechanism vents it to the atmosphere. It will vent until the
pressure returns to the normal range. The vent must be kept clean and clear of
obstructions or corrosion. A clogged vent could cause the failure of
components. Contact a qualified Propane technician if corrosion or obstruction
is noticed.

MAJOR APPLIANCES

Refrigerator

Before starting the refrigerator, verify that the main Propane gas valve is in the
on position. The refrigerator is equipped with a semi-automatic energy selector
(AES) control system. It can be set to select either 120 volt or Propane gas
operation, automatically, if desired. A 12 volt power supply must be available
for the electronic control panel to function. The shore line must be plugged in,
or the optional generator running, to operate in the 120 volt mode. The main
Propane gas valve must be open for operation in the Propane mode. To start
the refrigerator, press the main power ON/Off button to the ON position.

To use the 2-way Auto Mode, push the AUTO/GAS mode selector into the
ON position. If 120 volt is available, the AC mode indicator light will be

2008 Torrey Pine Fifth Wheel by Newmar 3:7

illuminated designating AC operation. If 120 volt is not available, the gas
mode indicator light will be illuminated. The control system will automatically
switch to gas operation. To operate on gas only, push the AUTO/GAS mode
selector until the gas indicator light has lit. After 45 seconds, the burner should
be ignited and operating normally. The initial start up may take longer than 45
seconds in order to allow the air to be purged from the gas line. If the gas does
not ignite within 45 seconds, the check indicator light will illuminate and the
gas mode light will go off. If the check indicator light illuminates and the gas
mode indicator light is off, then the controls have failed to ignite the burner in
the gas mode. When the check indicator light is on, press the main power
ON/OFF button to the off position to reset. Do not continue to reset the gas
operation if the check indicator light continues to illuminate after several tries.
The thermostat on the refrigerator controls the gas and electric operation. This
eliminates the necessity of resetting the temperature each time a different
energy source is used. Press the temperature selector button until the light at
the desired setting is illuminated. After the initial start up, the thermostat
should be moved from the coldest setting to the desired setting, which is
usually mid range. An optional feature on the refrigerator is the addition of an
icemaker. For detailed operating instructions, please consult the manufacturer
owner’s manual in the Owner’s Information Packet.

WARNING

Most Propane gas appliances used in recreational vehicles are vented to the
outside of the vehicle. When parked close to a gasoline pump it is possible that
the gasoline fumes could enter this type of appliance and ignite the burner flame
causing a fire or explosion. Use caution when refueling.

Microwave

Standard in your unit is a 22" microwave oven. As an option, your unit may
be installed with a 30” convection microwave with a three burner cooktop.
All of the microwave ovens installed by Newmar operate in the same manner.
The microwave’s control panel is the touch pad type. Simply enter the
temperature, mode, and cooking time desired. For instructions on how
to operate any of the special features on the microwave oven, please refer to
the microwave owner’s manual in your Owner’s Information Package.

3:8 2008 Torrey Pine Fifth Wheel by Newmar

If the microwave contains the range hood, the hood is controlled by the
microwave control panel. Refer to the microwave owner’s manual for further
instruction on the hood operation.

Range Hood

A range hood may be incorporated into the microwave. The microwave’s
control panel operates the range hood functions. This range hood has both
a fan and a light for your convenience. The fan has two speeds which are low
and high. Simply select the desired setting from the microwave’s control panel.
For further detailed information on the hood operation, refer to the microwave
Owners Manual.

Range

Your unit may be equipped with a three burner recessed range with a glass
oven door and electronic ignition. There are different models used in the
Newmar product line with different types of controls. To light the burners
on some models, turn the control knob to turn the gas on. Wait a couple of
seconds, then push the red spark button until a flame appears. On other
models, after the gas control has been turned on, turn the spark control knob
until a flame appears. All burner controls operate counter clockwise and have
to be pushed inward in order to turn. On units with an oven, the oven control
must also be pressed inward before turning. To light the oven, push in the oven
control knob and rotate counter clockwise to the PILOT ON position. Light the
oven pilot light located at the back left-hand side of the oven burner. The oven
pilot may be slow in lighting due to initial air in the gas line. The oven pilot
has been factory adjusted. No further adjustments are necessary. To extinguish
the oven pilot, push in the oven control knob and turn clockwise to the “Off”
position. For further instructions, please refer to the oven manufacturer
owner’s manual in your Owner’s Information Package.

Your range may be equipped with a bi-fold range cover that matches your
countertop material. This cover helps to protect the burners when they are not
in use. Before cooking on the range top, the cover must be in the full upright
and folded position, preventing the cover from falling on the range top during
cooking. Never close the cover while the burners are in use and do not use the
cover as a griddle or cooking surface. Never use the range while the RV is
moving and remember to close the bi-fold cover when the range top is not
in use.

2008 Torrey Pine Fifth Wheel by Newmar 3:9

For further instructions, please refer to the oven manufacturer owner’s manual
in your Owner’s Information Package.

The following warning label has been placed in the cooking area to remind the
user to provide an adequate supply of fresh air for combustion:

WARNING

It is not safe to use cooking appliances for comfort heating. Cooking appliances
need fresh air for safe operation. Before operation:

1. Open overhead vent or turn on an exhaust fan.

2. Open a window.
Unlike homes, the amount of oxygen supply is limited due to the size
of the recreational vehicle. Proper ventilation when using the cooking
appliance(s) will avoid dangers of asphyxiation. It is especially important that
cooking appliances not be used for comfort heating as the danger
of asphyxiation is greater when the appliance is used for long periods
of time.

The following label has been placed in the vehicle near the range area:

If You Smell Gas:

1. Extinguish any open flames, pilot lights, and all smoking materials.

2. Do not touch electrical switches.

3. Shut off the gas supply at the tank valve(s) or gas supply connection.

4. Open doors and other ventilating openings.

5. Leave the area until the odor clears.

6. Have the gas system checked and leakage source corrected before using
again.

Television Antenna

A TV antenna with a power booster is installed in your coach and is designed
for reception of all color and black-and-white channels. If the reception is
poor, you should verify that the power switch is in the “ON” position and that
all of the connectors are tight. If poor reception still occurs, consult your
authorized dealer.

To raise the antenna into the operating position, turn the elevating crank
(clockwise) in the “UP” direction, about 13 turns, or until some resistance to
turning is noticed. On the power booster, turn the switch to “ON” in order to
amplify the signal being received. Once in the “UP” position, rotate the

3:10 2008 Torrey Pine Fifth Wheel by Newmar

antenna to receive the best picture.
This is done by pulling down on the
directional handle with both hands
until it disengages from the ceiling
plate and then rotating it until
reception has improved. The antenna
must be lowered before moving the
vehicle. To lower, rotate the
directional handle until the pointer is
aligned with the pointer on the ceiling
plate. Turn the elevating crank
(counter-clockwise) in the “DOWN”
direction, about 13 turns, or until some resistance to turning is noticed. The
antenna is now locked and in the travel position. Your unit may be equipped
with one exterior antenna jack and two interior antenna jacks.

CAUTION

Under no circumstances should you lower the antenna in any position except
the travel position.

Television

The coach is cable ready and may be equipped with a color television in the
entertainment center located in the living room. An option may be to install
a DVD player and/or to have a color television installed in the bedroom. The
televisions, if installed, are powered by 120 volt electricity. Your unit must be
plugged into shore power, or have the optional generator running, in order for
the television to work. The operation is similar to most televisions used in the
home. The main unit has the basic ON/OFF, VOL(ume) UP and DOWN,
CH(annel) UP and DOWN, and Menu buttons. The remote control has these
in addition to many other function keys. Please consult your television owner’s
manual for further information. There are two interior jacks and one exterior
jack installed for televisions to receive the antenna signal. An optional exterior
television jack on the door-side of the coach is available. Your unit may also
be pre-wired for a satellite system.

2008 Torrey Pine Fifth Wheel by Newmar 3:11

CAUTION

Under no circumstances should you lower the antenna in any position except
the travel position.

Video Control Center

This control center provides
input for a DVD player, and
distribution of that DVD
signal to all the televisions
and the VCR in the RV. It also allows the freedom to view any of the input
sources (antenna, satellite, VCR, DVD, etc.) simultaneously and /or
independently on each TV in the unit.

Cable & Telephone Jack

Cable television jacks are featured on your unit. An interior jack may be
installed where specified and another jack may be an exterior jack located
in the electric compartment. An additional feature in this unit is the telephone
hook up. This includes the connector for the incoming telephone line and one
telephone outlet inside the unit.

Satellite Prep

Your unit has been prepped at the factory for use with a DSS satellite system.
In the entertainment center you will find connections for RG6 dish connection
to a DSS receiver, and a phone jack to connect to the receiver for “Pay-Per­View” programming. The RG6 cable runs to an exterior connector where the
dish can be set on a tripod for ease of adjustment.

Stereo / Surround Sound System

The standard stereo installed in your unit is a Surround Sound / DVD / CD /
AM/FM Stereo system. There are speakers located throughout the coach for
your listening pleasure, with a remote mounted subwoofer for enhanced audio
quality. For detailed information on the operating instructions, please refer to
the manufacturer’s owner’s manual in the Owner’s Information Package.

3:12 2008 Torrey Pine Fifth Wheel by Newmar

Water Heater

area for gas. Be sure to smell next to the floor because some gas is heavier
than air and will settle Before lighting the water heater fill the fresh water
system. Purge any air from the water heater by opening all hot water faucets
until water flows steadily from each one. The water heater installed in this unit
is a ten-gallon gas/electric model with direct spark ignition (DSI). This water
heater operates on Propane gas or 120 volt electricity. It is important to read all
of the safety information provided in the water heater manufacturer operation
manual in the Owner’s Information Packet. This appliance does not have a
pilot light. It is equipped with an ignition device which automatically lights the
burner. Do not try to light the burner by hand. Before lighting, smell all around
the appliance on the floor. Consult the Operation Manual for further
instructions if a gas leak is noticed. The gas valve is fully automatic, no
adjustments are necessary. Read the safety information provided in the
Operation Manual before lighting the appliance. Turn off all electrical power
to the water heater. Turn the gas supply to the OFF position. Wait five minutes
for the gas to clear the area. If you smell gas, STOP! Following the safety
instructions in the Operations Manual. If gas odor is not noticed than turn the
gas supply to the ON position. Turn on the electrical supply to the water
heater. Inside the unit there is a switch marked WATER HEATER. Turn the
switch to the ON position. There will be a 15 second purge before the unit will
spark. If the burner does not light on the first try, there will automatically be
two more tries for ignition before it will lock out. Each ignition cycle will have
a 15 second purge. If lock out occurs before the main burner lights, turn the
switch to OFF, wait five seconds and turn the switch to ON again. This will
re-start the ignition cycle. The initial start-up of the water heater may require
several ignition cycles before all of the air is purged from the gas lines.

WARNING

Do not light the water heater until it is filled with water. There is a switch on the
exterior of the water heater labeled Electric. This switch must be in the ON
position for the water heater to work in the electric mode.

Water Heater Storage

When storing your unit for the winter months, the water heater must be drained
to prevent damage from freezing. The first step is to turn off all electrical

2008 Torrey Pine Fifth Wheel by Newmar 3:13

power and Propane gas going to the water heater. The water pump must also
be turned off. Open both the hot and cold water faucets to drain the lines. Open
the drain on the water heater. Drain the entire water system. When preparing
the unit for use after it has been stored, make certain the water system,
including the water heater has been filled before re-lighting the water heater.
Failure to fill the water heater before lighting may damage the water heater
and void the warranty.

Pressure Relief Valve

The temperature and pressure relief valve is designed to open if the
temperature of the water within the heater reaches 210 F, or if the water
pressure in the heater reaches 150 pounds. Recreational vehicle water systems
are closed systems and during the water heating cycle the pressure build-up in
the water system may reach 150 pounds. When this pressure is reached, the
pressure relief valve will open and water will drip from the valve. This
dripping will continue until the pressure is reduced to below 150 pounds, and
the valve closes. This condition is normal and does not indicate a defective
relief valve.

WARNING

Do not plug the relief valve under any circumstances.

WARNING

Do not store any combustible materials or liquids near or adjacent to the water
heater.

Washer/Dryer (Optional)

The preparation for a washer and dryer is a standard feature on this product.
However, the installation of a two piece washer and dryer is part of the various
option packages available. The washer and dryers used by Newmar function
as those in a home, operating on 120 volt electricity. For more detailed
information on the operating instructions, read the appliance owner’s manual
in the Owner’s Information Package.

3:14 2008 Torrey Pine Fifth Wheel by Newmar

CAUTION

The gray tank valve must be in the open position when operating the washing
machine.

Ceiling Fan

In the living room area you may find a ceiling fan. This operates on 120 volt
electricity. The fans three speeds (low, medium and high) can move air in two
directions, up and down. Moving the air up in the summer months, the fan will
help circulate the cool air from the air conditioner. By moving the air down,
the fan will help circulate the warm air from the furnace in the winter months.

Central Vacuum System (optional)

A central vacuum system is available as an option. This system allows you to
vacuum the interior of your unit using provided attachments through a port in
the floor. For convenience, the system is mounted in the basement, and allows
for easy removal of dust and contaminants.

2008 Torrey Pine Fifth Wheel by Newmar 3:15

Chapter 4

CABINETS, FURNITURE & INTERIOR
FEATURES

CABINETS .................................................... 3

FURNITURE.................................................. 4

Living Room Area ........................................................ 4

Bedroom Area .............................................................. 4

INTERIOR FEATURES .................................. 5

Flooring ......................................................................... 5

Ceiling ........................................................................... 5

Window Treatment ....................................................... 5

2008 Torrey Pine Fifth Wheel by Newmar 4:1

4:2 2008 Torrey Pine Fifth Wheel by Newmar

CABINETS

The cabinetry in your RV is constructed on-site at the Newmar Production
Facility. Oak hardwood raised panel doors are standard throughout the unit.
Brass door and drawer handles give the interior an added touch of elegance.
The standard cabinets in your unit are finished in oak vinyl veneer. Your unit
may be equipped with the optional hardwood cabinetry in a variety of finishes.
Your cabinetry was designed with function and convenience in mind, and was
built to exacting standards by modern craftsmen.

Brass door and drawer handles give the interior an added touch of class.
The silverware drawer may contain a molded silverware divider tray for added
storage convenience.

Storage is an important factor to all RV owners. Keeping this in mind, the
cabinetry is structured to provide as much storage as possible. In the bedroom,
the bed platform lifts to provide an additional, convenient storage area. A strap
is provided to help raise the bed. Once the bed platform is lifted, it is held open
by pressurized struts to allow hands-free access.

A countertop with a color coordinated edge is installed in the kitchen.
To clean, wipe with a damp cloth and for dried on spots or rings, wipe with a
damp cloth and a mild liquid soap. Strong chemicals and solvents may damage
the surface and should be wiped up immediately, then rinse the surface with
water.

Avoid cutting directly on the countertop surface, avoid excessive heat,
and keep harmful chemicals away to avoid countertop surface damage. The
cabinetry throughout the unit can be cleaned with commercial furniture cleaner
or polish. As with any wood product, do not saturate the cabinets with water
or any other liquid. Be certain to wipe up spills as they occur to avoid staining.

The drawer directly in front of the kitchen and lavatory sink does not pull out,
but rather flips down. This provides
a storage tray for dish cloths, scouring
pads, washcloths, etc. Metal drawer
guides may be on all of the drawers
throughout the unit. These guides
provide a smooth opening and closing
of the drawers. To open a drawer, lift

2008 Torrey Pine Fifth Wheel by Newmar 4:3

up slightly and pull open. This mechanism will prevent the drawers from
unintended opening while traveling.

FURNITURE

Living Room Area

A standard feature in the kitchen area is the free-standing dinette. This includes
a hardwood table and four chairs. The chair seats and backs are designed with
a coordinating upholstery fabric to match your decor. Optional is a
combination desk/dinette table with two folding chairs and two fixed chairs
or a hidden leaf dinette table.

Depending upon the floor plan of your unit, the standard sofa will either be
a Magic Bed or Hide-Abed sleeper sofa. As an option, an air mattress may
be included for the Hide-A-Bed sofa. The magic bed sofa converts into a
sleeping area by holding and pulling up on the bottom cushion while pushing
down on the back cushion. Before converting the hide-a-bed sofa, extend the
slide out (see Chapter 5 for slide out instructions) to make room for the bed.
Once the room is extended, remove all of the seat cushions. Next, take hold
of the handle on the bed mechanism and pull to extend. Expand the bed to the
fully-open position by unfolding the foot portion of the bed. All of the sofas
are upholstered in decor-matching fabric. If you have any questions regarding
the warranty on this sofa, contact the sofa manufacturer.

Depending on the floorplan of your unit, one or two large recliners may
be installed in the living room. Optional are one or two leather/vinyl large
recliners or one two small leather/vinyl recliners. One or two leather/vinyl
recliners with an ottoman, a sofa coffee table, or a chair end table may also
be optional features in the living room.

Bedroom Area

The standard mattress in the bedroom is a 60" x 80" queen size bed.
A luxurious pillow top mattress may be an option in lieu of the standard
mattress. For best results, it is recommended that the bedspread be DRY
CLEANED ONLY.

On each side of the bed you may find wardrobe closets. Lights may be
installed in these closets for your convenience.

4:4 2008 Torrey Pine Fifth Wheel by Newmar

INTERIOR FEATURES

Flooring

The floor covering throughout the living room and bedroom of the unit is
nylon tufted cut loop carpeting. In the Owner’s Information Package you will
find literature supplied by the carpet manufacturer. This information will be
helpful in maintaining and extending the life of the carpet. Please refer to this
information for the carpet care and cleaning instructions. The flooring
throughout the kitchen and bath area is simulated plank. Ceramic floor tile
or 12”marble-like tiles are optional throughout these areas. Simple vacuuming
is all that is necessary to remove loose dirt and debris for everyday cleaning.
Mop occasionally, using a minimal amount of water. For more thorough
cleaning, mop with a mixture of soap-free household cleaner and water
(vinegar and ammonia both work well). Be careful not to saturate the floor
with water; this could damage the flooring. Abrasive cleansers and scouring
pads can scratch and damage the surface also.

Ceiling

The ceiling in this unit is covered with a padded vinyl ceiling headliner. The
recommended cleaning procedure is to use a soft cloth and a mild detergent.

Window Treatment

The window treatment throughout this unit, except in the kitchen, is pleated
day/night window shades and lambrequins. These shades have two sections.
The first section visible when closing the shade is the “DAY” section. This
material is translucent. Sunlight passes easily through the material into the
unit. The second visible section is the “NIGHT” section. This material is a
heavier, more opaque material. Very little to no light passes through it. It is
generally used in the evening or when more privacy is desired. If any curtains
are installed in this unit, cleaning instructions are DRY CLEAN ONLY.
Water-based products are not recommended for cleaning fabrics. Water-based
products may cause excessive shrinkage or fading. The kitchen window is
equipped with a mini-blind.

2008 Torrey Pine Fifth Wheel by Newmar 4:5

Chapter 5

ELECTRICAL FEATURES

Electrical Systems ......................................... 3

General Information ..................................................... 3

Breaker Boxes .............................................................. 4

Batteries ........................................................................ 4

Battery Inspection & Care ........................................... 4

Battery Disconnect Switch .......................................... 5

120 Volt Receptacles ................................................... 6

Ground Fault Circuit Interrupt Receptacle ................ 6

Wiring Connector ......................................................... 7

Generator Prep (Optional) ........................................... 7

Generator (Optional) .................................................... 7

Solar Prep (optional) .................................................... 7

2008 Torrey Pine Fifth Wheel by Newmar 5:1

5:2 2008 Torrey Pine Fifth Wheel by Newmar

ELECTRICAL SYSTEMS

WARNING

Use of “Adapter” cords with the RV shore power cord.

All Newmar units are manufactured with a 50 amp electrical breaker box and
electrical system. To provide the correct amperage into the RV and to assure
the operation is as designed, it is important that they be plugged into the correct
type of properly grounded receptacle. The receptacle MUST be properly
grounded to insure safe, proper operation of all electrical components.

NEWMAR CORPORATION DOES NOT RECOMMEND USE OF “ADAPTER”,
“CHEATER”, OR “DOG BONE” STYLE CONNECTORS THAT WILL adapt or
MODIFY THE EXISTING SHORE POWER CORD TO A DIFFERENT STYLE
OF OUTLET. USE OF THIS TYPE OF ADAPTER WILL GREATLY REDUCE
THE AMOUNT OF AVAILABLE CURRENT IN THE UNIT, AS WELL AS
CREATE THE POTENTIAL FOR ELECTRICAL FAILURE AND / OR FIRE.
NEWMAR CORPORATION CANNOT ASSUME LIABILITY FOR FAILURES
OCCURING TO THE RV, ITS ELECTRICAL SYSTEM, OR ANY OF ITS
COMPONENTS FROM THE USE OF ANY ELECTRICAL ADAPTER.

General Information

There are two electrical systems in your coach. They are the 12 volt DC
system and the 120 volt AC system. Most standard appliances require 120 volt
electricity while the majority of the lighting used in recreation vehicles is
powered by 12 volt electricity. The power for the 12 volt system is supplied by
the coach batteries. The power for the 120 volt system is supplied by the power
cord when the unit is connected to an outside power source or by the generator,
if so equipped. When connected to shore power, the standard 55 amp power
converter will automatically charge the batteries as well as convert 120 volts
into 12 volts. To connect the unit to 120 volt shore power, first make sure all
of the breakers are in the off position. This is done to avoid a power surge.
Unwind the power cord from the electrical compartment. The standard
electrical service for fifth wheels is 50 amps. Check to make sure the pins in
the outlet are oriented correctly, that they match the power cable, and that they
are in good condition. If there is a circuit breaker switch at the plug, it should
be turned OFF before making the connection. Insert the plug completely into
the outlet and turn the circuit breaker on. Close, and lock the electrical
compartment door to keep the contents clean, dry, and secure. Close the cover

2008 Torrey Pine Fifth Wheel by Newmar 5:3

on the power box, if equipped, to avoid an unintended disconnection, and to
keep contents clean. Switch the main breaker to the ON position. The 120 volt
system will energize all 120 volt circuits and outlets when the main breaker is
turned on.

Breaker Boxes

The 120 volt and 12 volt breaker boxes are generally located in the cabinet
above the toilet, but the location varies with each floorplan. Circuit breakers
and fuses are installed to protect the electrical system from overloading. Do
not attempt to change the circuitry or add appliances yourself. Please consult
an authorized Newmar Service Center.

Batteries

Any 12 volt battery you install in your unit is warranted by the battery
manufacturer. Two six volt batteries (wired in series) may be installed instead
for longer life. They are used to operate the 12 volt items in the unit. The
batteries also operate the water heater’s electronic ignition, landing jacks, etc.
In-line breakers protecting these circuits are found near the batteries. If the tow
vehicle is equipped with a charge line, the tow vehicle’s electrical system will
charge the coach batteries while in transit. The power converter, if installed,
automatically charges the coach batteries when the unit is connected to a 120
volt outside power source. A battery disconnect switch is provided with your
unit.

Battery Inspection & Care

Remember, when a battery is not used for an extended period of time, it may
lose its charge. Periodic charging of the battery during storage of the unit will
increase the life of the battery. Check the external condition of the battery
periodically. Look for cracks in the cover and case. Check the vent plugs and
replace them if they are cracked or broken. Keep the battery clean.
Accumulations of acid film and dirt may permit current flow between the
terminals, which could drain the battery. To clean, wash the battery with a
diluted solution of baking soda and water to neutralize any acid present. Rinse
thoroughly with clean water. Foaming around the terminals or on top of the
battery is a sign that acid is being neutralized. Avoid getting the baking soda
solution in the battery.

Secure all vent caps. Dry the battery cables and terminals. Do not use grease
on the bare metal inside the cable terminals to prevent corrosion. Grease can

5:4 2008 Torrey Pine Fifth Wheel by Newmar

act as an insulator. Electricity will not flow through it. A plastic ignition spray
will protect the terminals after they have been cleaned. When storing the unit
for a short period of time, the battery should be disconnected from the coach to
prevent draining. When not using your unit for an extended period of time, the
battery should be removed and stored in a warm place. Mark the cables,
positive and negative, for easy identification. Batteries are not to be stored on
concrete floors. The battery may require periodic charging during storage. If
the unit is to be stored for a long period of time, it is recommended that all the
batteries inside the unit be removed from clocks, radios, smoke alarms, etc.
This will prevent unnecessary drain and corrosion of the batteries. The coach
battery is a deep cycle RV/marine battery. This type of battery consumes water
and must be filled periodically. Please be sure to check the battery water level
on a regular basis, particularly after extended periods of heavy use where
frequent charging can cause more boiling of the fluid in the battery. Battery
electrolyte or distilled water can be used to fill batteries in most cases, but be
certain to consult the owner’s manual supplied by the battery manufacturer for
specifics regarding the batteries in your unit.

Battery Disconnect Switch

The Battery Disconnect Switch is a red colored handle located in the restroom
adjacent to the 12 volt DC distribution panel. This switch enables you to
disconnect the batteries from the DC electrical circuits in the coach for short to
mid term storage purposes, and for servicing convenience.

If the batteries will be stored for an extended time (three or more months), it is
a good idea to remove them from the RV and store them as outlined above.

WARNING

Do not allow the battery fluid to contact your skin, eyes, fabric, or painted
surfaces. The fluid could cause serious personal injury or property damage.
Wear eye protection when working with any battery.

CAUTION

Disconnect the 120 volt electrical power cord and the negative terminal from the
coach batteries before working on the electrical system.

2008 Torrey Pine Fifth Wheel by Newmar 5:5

WARNING

Remove rings, metal watch bands and other metal jewelry before working
around batteries. Use caution when using metal tools. If a tool contacts a battery
terminal or metal connected to it, a short circuit could occur which could cause
personal injury, explosion or fire.

120 Volt Receptacles

For your convenience, there are 120 volt receptacles located throughout the
interior of the unit. There may also be exterior outlets located on the doorside
of the coach. These receptacles require the three-pin plugs that provide proper
grounding to protect you from electrical shock. Do not use an adapter, cheater,
or extension cord that breaks the continuity of the ground circuit to the ground
pin. Never remove the ground pin from a plug in order to connect it to a two
pronged ungrounded outlet. Never operate the camping vehicle with an
electrical short. An electrical short may cause the exterior of the unit to shock
you when touched. If you feel even the slightest shock, disconnect the unit
from the 120 volt power source. It is usually a break in the grounding circuit.

The grounding circuit must be continuous from the frame to the

distribution panel, to the power cord, to the earth ground.

Ground Fault Circuit Interrupt Receptacle

The 120 volt electrical outlets in the kitchen and bath area are ground fault
circuit interrupt (GFCI) protected receptacles. The electrical outlets located in
the slide out may be wired through the kitchen GFCI. The exterior electrical
outlets are wired through the bathroom GFCI. If an item plugged into a slide
out or outside receptacle is not working, check for a tripped GFCI in the
kitchen or bathroom. These outlets protect the user from ground faults between
a hot wire and ground. The GFCI will not reduce the shock hazard if the short
is between a neutral and hot wire, or two hot load wires. The GFCI should be
tested at least once a month. The 120 volt electrical system must be on in order
to test the GFCI. The reset button needs to be pushed in all of the way before
starting the test. Push the test button. This will cause the reset button to pop
out which means that the protected circuits have been disconnected. Push the
reset button back in until a click is heard. This will reactivate the protected
circuit. If the GFCI is working properly the reset button will remain in the IN
position.

5:6 2008 Torrey Pine Fifth Wheel by Newmar

Wiring Connector

The wiring connector installed on all Newmar towable units is the standard
seven pin connector. The 12 volt or 6 volt battery in the tow vehicle supplies
power to the trailer’s electric brakes, tail lights, brake lights, turn lights, etc.
through this connector. Below is the diagram of the tow plug. This view is
looking into the tow vehicle receptacle. As stated above, this is a standard
seven pin pigtail.

Left Turn Signal . . . . . . . .Red

Right Turn Signal . . . . . . .Brown

Clearance . . . . . . . . . . . .Green

Ground . . . . . . . . . . . . . .White

Back Up Lights . . . . . . . .Yellow

Charge . . . . . . . . . . . . . .Black

Brakes . . . . . . . . . . . . . . .Blue

Generator Prep (Optional)

This option must be installed before the
generator option. With this option, the
remote start wire is installed in the unit
along with the automatic change over
switch and carbon monoxide detector.

Generator (Optional)

As an option, a generator may be added. With the installation of the generator,
your unit may have a 50 amp automatic changeover switch. When the
generator is running, it will produce 120 volt power. This will supply
electricity to the appliances and 120 volt lights in the unit when not connected
to shore power. There is an hour meter on the generator. The meter tracks the
number of hours the generator has been running. This information is important
for routine maintenance. For further instructions on the generator operation
and maintenance, please refer to the generator manufacturer operator’s manual
located in the Owner’s Information Package.

Solar Prep (optional)

Your unit may be equipped with “Solar Panel Prep”. This package provides
wiring routed from the roof down into the battery compartment. On the roof,
the wiring (one red and one white wire) is located just below the surface of the
roof, and is marked with a sticker to aid in locating it.

2008 Torrey Pine Fifth Wheel by Newmar 5:7

The wires are routed through the walls down into the Battery Compartment,
where they can be attached to the batteries or coach circuitry as necessary.

5:8 2008 Torrey Pine Fifth Wheel by Newmar

Chapter 6

EXTERIOR FEATURES

EXTERIOR FEATURES ................................. 3

Exterior Sides ............................................................... 3

Security Lights (Optional) ........................................... 3

Jacks ............................................................................. 3

Stabilizer Jacks ............................................................ 4

Electric Stabilizer Jacks (Optional) ............................ 4

Roof ............................................................................... 5

Steps ............................................................................. 5

Electric Steps (Optional) ............................................. 5

Windows ....................................................................... 6

Doors ............................................................................. 6

Vents ............................................................................. 6

AWNINGS ..................................................... 7

Side Awning ................................................................. 7

Extending ...................................................................... 7

Retracting ..................................................................... 7

Window Awning (Optional) ......................................... 8

Extending ...................................................................... 8

Retracting ..................................................................... 8

Spare Tire Carrier ......................................................... 9

2008 Torrey Pine Fifth Wheel by Newmar 6:1

6:2 2008 Torrey Pine Fifth Wheel by Newmar

EXTERIOR FEATURES

Exterior Sides

The exterior sides of this unit are constructed of gel-coated fiberglass. To add
to this feature, the end caps are also gel-coated fiberglass. Clean the fiberglass
material with a mild cleanser and warm water. Use only soft cloths. Using stiff
bristle brushes may cause scratches in the fiberglass surface. Please note,
Newmar is NOT responsible for weathering/oxidation of gel-coated surfaces.

Security Lights (Optional)

Optional are exterior security lights. One or two may be installed on each side
of the coach for added protection. If installed, the switch for these lights may
be located inside the front entrance door.

Jacks

Fifth wheel units may be equipped with 12 volt electrical jacks. As an option,
hydraulic leveling jacks with touch panel control may be installed. Before
using the jacks, read and closely follow the operation instructions provided
by the jack manufacturer. To lift the unit for uncoupling, drop the pad tube
by removing the lock pin. Re-pin the hole that places the foot pad closest
to the ground to compensate for variations in the terrain between the jacks.
Push the toggle switch to the DOWN position and hold until the jack raises
the unit to the desired height.

To raise the jacks after coupling, push the toggle switch to the UP position
and hold until the jacks are fully retracted. Release the toggle switch as the
lock pin in the inner ram tube nears the end of the outside tube to avoid
unnecessary wear on the motor clutch. Remove the lock pins and raise the
pad tubes, re-pinning them in the highest possible position.

CAUTION

When the jacks reach their maximum extended or retracted length or maximum
load, you will hear a clicking noise. This is the slip clutch built into the motor to
prevent jack overextension or retraction. Release the toggle switch as soon as
you hear the clicking. Continued operation with the clutch slipping can damage
the jacks.

2008 Torrey Pine Fifth Wheel by Newmar 6:3

CAUTION

Before raising the jacks, make sure the hitch is securely latched by applying the
trailer brakes and slowly pulling the tow vehicle forward. The unit should prevent
the tow vehicle from moving.

These jacks can be operated manually, if necessary. Insert the hand crank into
the alignment tube until the end engages with the crank shaft. Turn the crank
handle counter clockwise to raise the trailer. Remove and store the crank
handle. To raise the jacks after coupling, rotate the crank handle clockwise.
Retract as far as possible with the crank handle, then remove the lock pin and
raise the pad tube and re-pin it in the highest possible position. Please refer to
the jack manufacturer operation instructions for further assistance. The snaps
for the fifth wheel jacks may be featured on this model.

CAUTION

Before moving the trailer, crank up the stabilizer jacks to the fully closed
position. Tighten 1/4 turn to secure the jacks in the travel position. This will help
prevent the stabilizers from working open due to road vibration. Do not use
stabilizer jacks to lift the unit.

Stabilizer Jacks

Fifth wheel units may also be equipped with one pair of stabilizer jacks.
As an option, an extra pair of stabilizer jacks or power twin jacks may be
installed. The operation of the stabilizer jack is fairly simple. First park the
vehicle on level ground. Block the wheels using tire chocks to prevent the unit
from moving. Level the front and the back of the unit using the landing gear.
Crank the stabilizers down on the low side first, this will bring the trailer to a
fine level position. Re-tighten the stabilizers on the low side of the unit, if
necessary. Do not use stabilizer jacks to lift the unit.

Electric Stabilizer Jacks (Optional)

In place of the manual stabilizer jacks, an electric stabilizer jack assembly
may be optioned. For further instructions on the operation of these, refer to the
manufacturer operator’s manual in the Owner’s Information Packet.

6:4 2008 Torrey Pine Fifth Wheel by Newmar

Roof

This unit is manufactured with a 7mm rubber roof material. Optional is a gel­coated fiberglass roof and top wrap. Proper care and routine maintenance of
your roof is necessary for trouble-free performance. On this model, the ladder
is an optional feature. The ladder will assist you in gaining access to the roof
for routine inspections and maintenance.

Steps

Triple entrance door steps may be installed on your unit. If so, these steps
may be the manual fold-down type of steps. To extend the step, first release
the locking latch. Once the latch is released, pull the step pivot section out and
down by the step cross member bar. Next, release the second step by pulling
the step up and straight outward until it locks into position. Then pivot the
third and final step out and down. For retracting the step, reverse the
procedure. Keep all step pivot points lubricated with a quality grease-based
spray lubricant for smooth operation.

Electric Steps (Optional)

Installation of the electric triple entrance steps may be an optional feature on
fifth wheel units. These are installed in place of the standard manual steps.
Operation for the electrical entrance door step is as follows;

1. With the entrance door open, turn the step power switch on.

2. Close the door. The step should retract and lock in the up position.

3. Open the door. The step should extend and lock in the down position with

the under step light on.

4. Turn the step power switch off. The step should remain in the extended

position when the door is closed. Turning off the power with the step
retracted will hold the step in a retracted position as well.

CAUTION

If the vehicle is towed with the step in the extended position, there is the
possibility of causing major damage to both the step and the vehicle.

WARNING

Be careful not to get any fingers or clothing near the pivot action of the step.

2008 Torrey Pine Fifth Wheel by Newmar 6:5

Windows

In the bedroom of the unit, one window will be marked EXIT. This window is
an emergency escape, or egress, window. To open in case of an emergency, lift
the red handles at the bottom of the window and push out. The windows
installed in the fifth wheel units may be the radius torque, tinted safety glass
style. These windows are also referred to as jalousie windows. Optional may
be the double pane tinted safety glass windows.

Doors

The entrance door to fifth wheels is a radius door equipped with a dead bolt
lock and lighted steps for added security. The door can be held open with the
door stop. With the door open, simply lift the “T” section on the door and
place it in the holder on the exterior sidewall of the unit. Next to the entrance
door, a lighted, acrylic assist handle may be optional. If installed, this handle
will assist anyone entering the unit.

Vents

In the kitchen area, an optional feature may be the 12 volt vent equipped with
a rain sensor on the roof hood. Anytime the vent is open and it senses rain, it
will automatically close. The vent is controlled by the wall thermostat. Once
powered ON and the desired temperature is selected, the vent will run until the
preset temperature is reached. When the temperature is reached, the vent will
automatically shut off. Do not leave the fan in active mode while the unit is in
storage or unattended for long periods of time. High winds or other unusual
conditions or obstructions may prevent the vent from closing resulting in
leakage, which could cause serious damage.

In the bath area a vent may be installed that operates on 12 volt electricity.
This vent will be controlled by an on/off switch on the wall. Optional may be
a vent with a rain sensor. If this is installed, it would be in place of the standard
vent and located above the tub/shower.

A skylight may be an optional feature in the bathroom. If installed, it may
be located above the tub/shower.

6:6 2008 Torrey Pine Fifth Wheel by Newmar

AWNINGS

Side Awning

A patio awning is a standard feature on your coach. To operate, follow these
instructions:

Extending

1. Loosen the black adjustment lock knob behind each main arm. Flip the

travel lock latches up.

2. Using the provided pull rod, reach up and pull the locking lever forward

or down to release the awning.

3. Hook the rod into the loop of the pull strap and pull the awning all the

way out.

4. Slide one rafter arm up until it snaps into place. Push down on the main

arm to remove slack from the fabric, and tighten the black adjustment
knob. Repeat on other side.

5. Slide the pull strap to the right end of the roller and wrap it around the

main arm.

6. Pull up on the lift handle and raise the arm assembly to the desired height.

Swing handle in, and allow the lock button to snap into one of the holes.
Repeat on the other side.

7. Press the release lever at the bottom end of one main arm, pull the arm

assembly outward to a vertical position, and readjust height. Repeat on
other side. Drive provided stakes through holes of each patio foot into the
ground.

8. During rain, lower one end to allow water to flow off.

(See the awning manufacturers instructions for additional operating and
maintenance details and precautions).

Retracting

1. Pull the stakes from the ground, swing the arm toward the vehicle, and

snap the patio foot into the bracket. Repeat on the other side.

2. Raise the lift handle to release the lock button. Lower the main arm to the

stop plug. Swing the handle in to engage the lock button in a hole. Repeat
on other side.

3. Loosen black adjustment knob, lift slider catch, and slide the rafter arm

down to the bottom of the main arm. Leave the black adjustment knob
loose. Repeat on other side.

2008 Torrey Pine Fifth Wheel by Newmar 6:7

4. Grasp the pull strap and pull toward you. Flip the locking lever to the

ROLL UP position. Hold the awning in the down position until you are
ready to roll up the awning.

5. Slide the pull strap to the center and using it to control speed, allow the

awning to return to the side of the vehicle. Allow the strap to wind
diagonally to prevent a bulge in the fabric.

6. Tighten the black adjustment knob and flip the travel lock latch down.

Repeat on other side.

The awning is now ready for travel.

CAUTION

The awning will try to roll up as soon as the locking lever is flipped to the ROLL
UP position.

CAUTION

Whenever heavy or prolonged rain or wind is anticipated, or you will leave the
awning unattended, it is best to close the awning. Damage as a result of
weather is not covered by warranty.

Window Awning (Optional)

A window awning may be an optional feature on fifth wheels. To operate
these, use the following instructions:

Extending

1. Grasp the loop on the pull strap and pull down to extend the awning.

Then hook the loop onto the window strap hanger.

Retracting

1. Remove loop on the pull strap from the window strap hanger.

2. Slowly allow the awning to roll back to the closed position by feeding

the pull strap upwards and diagonally. This prevents the strap from
building up and creating a bulge in the fabric.

3. The window awning is now ready for travel with no further locking

required.

6:8 2008 Torrey Pine Fifth Wheel by Newmar

CAUTION

Do not release the strap as the window awning is under tension and may snap
back against the vehicle.

Spare Tire Carrier

Your unit has a spare
tire mounted under
the front of the unit,
between the landing
gear. This tire is
raised and lowered
via a crank
mechanism that
extends from under
the unit on the door
(curb) side. Attach
the provided handle
and crank the tire down, or up as necessary. Be sure the spare time is securely
positioned for travel, and regularly check the air pressure in the tire to be
certain it is ready for use at all times.

2008 Torrey Pine Fifth Wheel by Newmar 6:9

Chapter 7

PLUMBING & BATH FEATURES

FRESH WATER SYSTEM .............................. 3

Kitchen Sink ................................................................. 3

Bath Sink, Shower & Accessories .............................. 3

Monitor Panel ............................................................... 3

Monitor Panel Calibration ........................................... 3

Water Pump .................................................................. 4

City Water Hook-Up ..................................................... 5

Fresh Water Tank Fill ................................................... 5

Sanitizing ...................................................................... 5

Water Filtration System ............................................... 7

Water Heater By-Pass System .................................... 7

Fresh Water Lines ........................................................ 8

WASTE WATER SYSTEM .............................. 9

General Information ..................................................... 9

Toilet ............................................................................. 9

P-Traps .......................................................................... 9

Black Water Holding Tank ......................................... 10

Gray Water Holding Tank .......................................... 10

Waste Water Disposal ............................................... 10

Camping with Sewer Hook-Up .................................. 11

No Fuss Flush ............................................................ 12

2008 Torrey Pine Fifth Wheel by Newmar 7:1

7:2 2008 Torrey Pine Fifth Wheel by Newmar

FRESH WATER SYSTEM

Kitchen Sink

The kitchen sink installed in your unit may be an acrylic, double-bowl sink
equipped with two sink covers to provide additional counter space when the
sink is not in use. Cleaning care consists of washing with mild detergents and
a soft cloth. Avoid using S.O.S. type cleaning pads because they may scratch
the surface. The faucet in the kitchen may be a single-handle faucet equipped
with a pullout spout.

Bath Sink, Shower & Accessories

The sink in the bathroom may be a porcelain sink. Use care when cleaning to
avoid scratching the surface. The brass bathroom accessories in fifth wheel
units include a towel bar, tissue holder, towel ring, and robe hook. The shower
installed is a fiberglass combination tub/shower with a glass shower door. An
assist handle may be installed in the tub/shower as an optional feature.

Monitor Panel

The monitor panel allows you to check the approximate levels in the fresh,
gray, and black water holding tanks, and the battery condition. The monitor
panel is generally located in the bathroom. Simply press the button of the item
to check its status. The empty indicator light will always light when the button
is pressed. If the tank is full, all of the lights will be on. Lights are sequential,
and indicate the level in approximately 1/4 tank increments. For example: If
the tank selected is approximately 1/2-full, then the indicator lights E, 1/4, and
1/2 will be lit. On the right hand side of the monitor panel is the water pump
switch. This switch controls the power going to the water pump, turning it
either on or off.

Monitor Panel Calibration

The monitor panel comes to you factory calibrated for accuracy and should not
need to be adjusted. In the event that the system does not read accurately, then
re-calibration may be necessary. The procedure for re-calibration is simple:

1. Fill the tank to be re-calibrated.

2. Using the adjustment tool enclosed in the Owner’s Package (or any small

flat-bladed screw driver) simultaneously push the button for that tank and

2008 Torrey Pine Fifth Wheel by Newmar 7:3

rotate the adjustment screw located above the button and behind the face
plate counter-clockwise until some of the lights turn off in sequence.

3. Slowly rotate the adjustment screw clockwise until the full light is

completely on. Repeat this procedure as necessary for the remaining tanks.
The system is now calibrated properly.

Water Pump

The water pump is self priming and totally automatic, operating on demand
whenever water is required. The water pump is used to pressurize the fresh
water system when the unit is not connected to city water. To start the pump,
follow these instructions:

1. Fill or partially fill the fresh water supply tank.

2. Open the kitchen and bathroom faucets.

3. Turn the water pump switch on and allow the water to fill the water line

and the hot water heater.

4. Close each faucet after it delivers a steady stream of water (close the cold

water first). Leave the hot water faucets on until they also deliver a steady
stream of water. This will ensure that the water heater is filled with water.

5. The water pump should stop running once all faucets are closed.

6. The pump is now ready for automatic operation. The pump will run when

a faucet is opened and stop when a faucet is closed.

7. Never allow the pump to run for long periods of time without water in the

supply tank. Pump damage or blown fuses may result.

If water doesn’t flow when a faucet is turned on while using the demand
system, use the following trouble shooting chart.

SITUATION SOLUTION

Pump running — no water 1. Fill tank

2. Clear the water line to the pump

Pump doesn't run 1. Check the pump switch

2. Check the 12 volt fuses

3. Check the electrical connections

4. Check the battery

All of the water should be drained from the fresh water system when the unit
is not in use for more than one week. For more detailed information regarding

7:4 2008 Torrey Pine Fifth Wheel by Newmar

the water pump, refer to the water pump manufacturer’s brochure in your
Owner’s Packet.

City Water Hook-Up

When connecting your unit to city water, be certain to use a water hose
manufactured and labeled for potable water. This will ensure that the hose
will not alter the taste of the water. To hook the city water supply to the unit,
connect one end of the hose to the city water supply. This will usually be a
faucet or valve similar to your garden hose valve at home. Turn the city water
supply on for a few seconds in order to clear the line. Once the hose has been
flushed, turn the supply off. Connect the other end of the hose to the city water
connections. Turn on the water supply and open all of the faucets to clear the
air from the lines in the unit. Once air pockets have been purged from the
water lines and water flows freely, close all of the faucets. The city water
supply is under pressure, therefore the water pump is not necessary when
connected to city water. Once the city water fill valve is opened, water is
supplied to the fresh water system including the hot water heater, faucets,
and stool. To disconnect from the city water supply, close the spigot valve and
remove the hose from the city water supply. Disconnect the hose from the
city water connection and store the hose in the water compartment.

Fresh Water Tank Fill

The fresh water tank is filled via the “gravity” fill connection located on the
side of your unit. Open the door to access the gravity fill, and add water as
desired. Since there is not an automatic shut-off for the fresh water tank fill,
check the level from the monitor panel while filling the unit. The excess water
will be vented from an overflow vent pipe onto the ground when the tank
capacity has been reached. This pipe is installed in the fresh water tank to
prevent tank rupture from overfilling. All of the water should be drained from
the fresh water system when the unit is not in use for more than one week.

Whenever possible, drain the fresh water tank before traveling. Water in the
tank will reduce the carrying capacity of the unit.

Sanitizing

To assure complete disinfecting of your fresh water system, it is recommended
that the following procedure be followed on a new system, on one that has not
been used for a length of time, or one that may have become contaminated.

2008 Torrey Pine Fifth Wheel by Newmar 7:5

This procedure is also recommended before long periods of storage, such as
over the winter months:

1. Drain the fresh water tank by opening the drain valves. There is one valve

per water tank. All of the faucets should be in the closed or off position.

2. Prepare a chlorine solution using one gallon of water and 1⁄4 cup of

chlorine bleach (5% sodium hypo-chlorite solution). Prepare enough
of the chlorine solution to administer one gallon of solution for every
15 gallons of tank capacity. For sanitizing this unit, prepare 41/2 gallons
of the chlorine solution. This mixture puts a 50 PPM (parts per million)
residual chlorine concentration in the water system that will act as a quick
kill dosage for harmful bacteria, viruses and slime forming organisms.
Concentrations higher than 50 PPM may damage the water lines and/or
tank.

3. Once the fresh water tank is empty, close the drain valves on the water

tank.

4. Pump the chlorine solution into the tank. This is done by placing the

winterizing hose into the chlorine solution. Close the valve from the fresh
water tank to the pump and open the valve from the solution to the pump.
Turn the tank fill valve from city water to tank fill. Turn on the water
pump until all of the solution is pumped into the fresh water tank.

5. Turn off the water pump. Close the valve to the solution. Open the valve

from the tank to the water pump. Fill the water tank with the city water
tank fill (or by using the same method as was used to put the sanitizing
solution into the tank). Remove the water filter (from the drink dispenser
faucet, if installed) and install the by-pass pipe to allow the sanitizing
solution access to the faucet. Open each faucet in turn including the
kitchen faucet, bath faucet, inside and outside shower, turning on both
the hot and cold, and flushing the stool until all of the air has been purged
from the pipes and the water runs freely. The entire system will then be
filled with the sanitizing solution.

6. Allow the 50 PPM disinfecting solution to stand in the system at least four

hours.

7. Drain the system and flush with fresh water. The water system needs to be

flushed with clean water repeatedly, if necessary, until there is no chlorine
taste or smell left in the system. To remove any excessive chlorine taste
or odor that might remain, prepare a solution of one quart vinegar to five
gallons of water. Allow this solution to agitate in the tank for several days
by vehicle motion. Drain the solution and refill the tank with clean water.

7:6 2008 Torrey Pine Fifth Wheel by Newmar

Water Filtration System

Your unit may b equipped
with a fresh water filtration
system. This system uses
extruded carbon filter
cartridges to remove
sediment and certain
impurities from the
incoming water supply. The
filter assembly is located in
the basement water
compartment.

To replace the filter cartridge, turn off the water supply to the RV (at the city
water connection). Unscrew the filter canister by rotating it clockwise.
Replacement filter cartridges are available through your Authorized Newmar
Dealer; have them order part number 03738.

Insert the new filter cartridge, positioning it so the opening in the bottom of
the filter seats on the molded ring at the bottom of the canister. Reattach the
canister to the filter housing by rotating the canister in a counter clockwise
direction. When replacing the filter, make certain the rubber “O-Ring” seal
is properly positioned in its groove in the cartridge housing. An improperly
seated or missing seal will cause leakage around the perimeter of the filter
housing. Use caution not to over tighten the canister when attaching it back
to the housing.

IMPORTANT

DO NOT ALLOW WATER TO FREEZE IN THE WATER FILTER CANISTER.

Freezing will crack and permanently damage the filter housing and associated
plumbing. ALWAYS REMOVE THE FILTER CARTRIDGE PRIOR TO

WINTERIZATION. RV Antifreeze will render the filter element unusable.

Water Heater By-Pass System

The water heater by-pass valve is located at or near the water heater. By
closing the water heater supply valve and opening the by-pass valve you can
divert water away from the water heater. This is done when winterizing your

2008 Torrey Pine Fifth Wheel by Newmar 7:7

unit. Using the by-pass will keep antifreeze out of the water heater when
winterizing the system.

Before disinfecting the fresh water system, remove the water filter and install
the by-pass pipe to allow water access to the drink dispenser faucet, if
installed. The water filter is located under the kitchen sink. The filter will
remove chlorine, dirt, and other matter. It will also eliminate most phenol
(or similar) odors and tastes while delivering sparkling, taste free water for
drinking and cooking. The filter is connected only to the cold water line that
is attached to the drink faucet. The filter is not guaranteed to remove the tastes
and odors of iron and sulfur. To remove these tastes you will need to chlorinate
the water. Replacement filters are available that will filter iron and sulfur. Ask
your dealer or RV supply center about acquiring an iron and sulfur filter. If
you are traveling in an area where the water has a high iron and sulfur content,
then add 1 tablespoon of chlorine bleach to every 10 gallons of water in your
tank. This will precipitate the iron or sulfur so that the filter can remove it. If
you are at a site where the unit is hooked up to city water, you will not be able
to chlorinate the system because the water flows straight to your faucets and
not through the fresh water tank. Filters should be changed every 6 - 12
months depending on the quality and quantity of water that is used in your
unit.

Fresh Water Lines

Vibration and flexing during traveling can cause pipes and fittings to work
loose. Check all of the plumbing connections for leaks on a yearly basis. If the
water pump runs when all faucets are turned off, check for a leak. Be sure the
drain valves are closed. Connections at the kitchen and bathroom faucets
normally seal with hand tightening and a half turn with a wrench. If a fitting
leak persists, disconnect it completely and check for mineral deposits or
foreign material on the sealing surfaces. Clean the surfaces thoroughly and
reinstall the fitting. Take the coach to an authorized service center for repairs
if the system continues to leak. Follow the winterizing instructions given in
Chapter 14 to reduce the risk of leaks caused by cracks from freezing pipes.
Freezing damage can be extensive and expensive.

7:8 2008 Torrey Pine Fifth Wheel by Newmar

WASTE WATER SYSTEM

General Information

The waste drainage system was designed to provide adequate and safe storage
and/or disposal of waste materials. All of the material used in the making of
this system are tested by a nationally recognized testing laboratory. The
drainage system uses ABS plastic piping and fittings connected to the sinks,
toilet, and holding tanks. This provides for their drainage to an outside
termination.

The unit should be reasonably level for best operation of the system. There are
two separate waste systems. The gray water system is for waste water from the
sinks and shower. The black water system is generally for sewage waste from
the stool. Each tank has its own control valve and both tanks drain through the
sewer drain hose.

Toilet

The stool operates with water from either the fresh water tank with the water
pump on or the city water supply. Before using the stool, add water to the
bottom of the tank. Refer to the BLACK W ATER TANK instructions in this
chapter. The stool flushes wastes directly into the black water holding tank.
The stool uses high velocity water injection to produce a swirl effect in the
bowl. The greatest problem that causes stool solids to build up in the holding
tank is lack of liquids. When using your stool, it is wise to fill the stool 3/4 full
of water. This will help to wash the solids away from directly below the stool
and to ensure complete dumping of the holding tank. Depending upon the
model installed, water can be added to the stool bowl by lifting up on the lever.
To flush the stool, push down on the lever until water swirls. The stool
requires little maintenance. Use an approved non-abrasive cleaner to clean
the bowl. Spraying the bowl sealing blade with a silicone spray will retain
the original smooth operating condition. Check the complete instruction and
trouble shooting guide in the stool manufacturer’s owner’s manual provided in
the Owner’s Information Packet.

P-Traps

Each of the sink drains, the shower drain, and the washing machine drain
(if equipped) has a water trap (P-Trap) to prevent holding tank odors from
entering the coach. These traps must have water in them in order to work.

2008 Torrey Pine Fifth Wheel by Newmar 7:9

While traveling, the water may splash out of the sink and shower drains. While
stored, the water may evaporate allowing an odor to enter the coach. If this
occurs, run water from the faucet into the drain, allowing water to fill the trap.

Black Water Holding Tank

The black water, or sewage, holding tank is located directly beneath the toilet.
Before using the stool, you will need to treat the tank with water that is mixed
with an odor controlling chemical. These chemicals are readily available at any
RV supply store. Be careful not to spill the chemical on your hands, clothing
or the carpet because it may cause a permanent stain. Pull the toilet levers
forward to allow the chemical to mix with the toilet water. Continue pulling
the toilet levers until at least one inch of solution is directly under the toilet.
Release the levers and the waste tank is ready for use.

Gray Water Holding Tank

The gray water holding tank is located in the underbelly of the unit. It is
primarily used for the drainage from the kitchen and bath sinks and the
shower.

Waste Water Disposal

Both of the holding tanks terminate in a valve arrangement that permits
draining each tank separately or together. It is recommended to drain the black
water tank before the gray water tank. This will allow the water from the gray
tank to wash the black water residue from the drain lines and hose. The valves
that open to release the water are called gate valves. The blade that closes the
opening in the sewer drain pipes is connected to the T-handle to release the
contents of the tank(s) when pulled. The sewer line must be securely capped
during self-containment use to prevent leakage of waste material onto the
ground or pavement. Do not pull the holding tank gate valve open when the
protective cap is installed on the pipe. Always drain the tank into an acceptable
sewer inlet or dump station.

CAUTION

Use only approved RV odor controlling chemicals in the holding tanks. Products
containing ammonia and petroleum will damage the ABS plastic holding tanks
and seals.

7:10 2008 Torrey Pine Fifth Wheel by Newmar

Whenever possible, drain the holding tanks prior to traveling. The carrying
capacity of your unit will be reduced if water is left in the black or gray tanks.

The holding tanks should only be drained when they are at least 3/4 full. Doing
this provides sufficient water to allow the complete flushing of waste materials
in the drain lines and hose. If the tanks are not 3/4 full, add enough water to
allow for sufficient flushing. To empty the waste water tanks, connect the
adapter to the drain hose. Use the adapter supplied with your unit. If the
adapter is lost or broken, one can be purchased from most RV supply stores.

Once you have placed the adapter on the drain hose, it can remain there for
the life of the hose. Unscrew the cap off the drain. Connect the hose with the
adapter in place to the drain fitting. Open the gate valve all the way by pulling
on the T-handle. The tank will start to drain as soon as the T handle is pulled.
After you have drained the black water tank, immediately drain the gray water
tank. Doing this helps to flush the black water from the sewage hose.

When both of the tanks are empty, flush them with a fresh water rinse before
you close the valves. The gray tanks are easily flushed by pouring a couple
of gallons of water into a sink drain. Prime the system with an odor control
chemical following the directions above for preparing the system for use. The
drain outlet is engineered for quick release of the drain hose adapter. Always
close the gate valves and secure the end cap to prevent leakage while in transit.
After draining, add enough water to the black water tank to cover the bottom.
When using dump stations for draining the holding tanks, please keep other
travelers in mind. Practice good housekeeping. Leave the dump stations in
good order. Above all, do not pollute.

Camping with Sewer Hook-Up

When camping at parks with sewer hook-up, it is important to keep the black
water holding tank gate valve closed at all times, except when dumping. The
gray tank can be kept open while hooked to a sewer connection but again, the
black water tank must be kept closed. This is done so that an ample supply of
liquid remains in the tank to provide a smooth flow through the gate and drain
valve when dumping. Sufficient liquid in the tank causes a swirling action that
should take any accumulated solid wastes with it. Accumulation of solid
wastes in the black water tank can be avoided by keeping the gate valve closed

2008 Torrey Pine Fifth Wheel by Newmar 7:11

when connected to the sewer hook-up. If the valve is left open, solid wastes
may accumulate in the tank. This may eventually result in costly repairs.

CAUTION

The gray tank valve must be in the open position when operating the optional
washing machine.

WARNING

Holding tanks are an enclosed sewer system and must be drained into an
approved dump station. Both black and gray water holding tanks must be
drained and rinsed thoroughly on a regular basis in order to prevent the
accumulation of harmful or toxic materials.

No Fuss Flush

This unit may be equipped with a flushing system for the holding tanks. When
draining your sewer tank, attach a water hose to the Sewer Spray hookup.
After the tank is drained, leave the gate valve open and open the water valve to
allow water to spray inside the sewage tank. This will clean the inside of the
tank of any debris that may be left inside the tank. After this is done,
disconnect the water hose and close the gate valve. When unsure if any solids
are still left inside the tank, fill the sewage tank with approximately ten gallons
of water through the stool. Then, as you travel, the agitation of the water
should help liquefy any solids left in the tank. You can dump the sewage tank
again at your next destination.

CAUTION

Do not use the same hose for the No Fuss Flush that is used for filling the fresh
water tank.

7:12 2008 Torrey Pine Fifth Wheel by Newmar

Chapter 8

SLIDE OUT FEATURES

SLIDE OUT FEATURES ................................ 3

General Instructions .................................................... 3

Extending the Slide Out Room ................................... 4

Retracting the Slide Out Room ................................... 4

MANUAL EXTENSION AND RETRACTION ... 5

Shaft end-mounted motors ......................................... 5

Shaft center-mounted motors ..................................... 5

Operating Precautions ................................................ 6

2008 Torrey Pine Fifth Wheel by Newmar 8:1

8:2 2008 Torrey Pine Fifth Wheel by Newmar

SLIDE OUT FEATURES

WARNING

Read the following slide out room instructions before activating the switch.

CAUTION

The slide outs can be operated without utilizing the leveling system, but is
recommended to have the unit as level as possible.

General Instructions

IMPORTANT

The slide out room should be inspected for alignment every six (6) months. If
alignment is necessary, have the room adjusted.

1. The slide out room can be stopped at any time by activating the slide out

switch. The room will reverse directions each time the switch is activated.

2. If the slide out room stops before reaching the full “OUT” or “IN”

position, the slide out controller may need adjustment.

3. To adjust the slide out controller, turn the adjustment screw clockwise to

increase the power and counter-clockwise to decrease the power.

CAUTION

Move the adjustment screw in small increments. Try moving the slide out room
again. Use caution. There is a potential for component or structural damage if
the screw is adjusted too high.

IMPORTANT

This screw does not adjust the slide out room speed. It sets the amount of
power required to move the room against the mechanical stops.

2008 Torrey Pine Fifth Wheel by Newmar 8:3

Extending the Slide Out Room

1. The windows on the end of the slide out room must be closed before

moving the room in either direction.

2. Before extending or retracting the room, look for and remove any

obstructions.

3. Move the driver’s chair forward before moving the slide out room in

either direction.

4. Disengage the lock arms by pulling down on the center of the arm using

the lock arm release tool, as required.

5. Activate the slide out switch. Once fully extended, the room will

automatically stop. The indicator light will be lit while the room is
traveling.

Retracting the Slide Out Room

1. Activate the slide out switch. When fully retracted, the room will

automatically stop. The indicator light will be lit while the room is
traveling.

2. Before moving the coach, engage the lock arms by pushing the arm

up into the locked position using the lock arm tool, as required.

IMPORTANT

On units equipped with manual lock arms, it is important to release the switch
as soon it has pulled tight and stopped moving. Current will be applied to the
slide out motor as long as you hold the switch. Automatic resetting circuit
protection is incorporated to minimize the chance of failures from not releasing
the button at the end of room travel, but timely releasing of the button before the
circuit protection engages is highly recommended.

8:4 2008 Torrey Pine Fifth Wheel by Newmar

MANUAL EXTENSION AND RETRACTION

Shaft end-mounted motors

If the motor is mounted on the ends of the
slide out shaft, use the following
directions:

1. Access must be gained to the

TRANS-TORQUE bushing coupling
at the end of the slide out gear motor.

2. Using a 1/2" drive – 11/2" open end wrench and a 1/2" drive ratchet

wrench, loosen the 11/2" nut. This will require approximately 11/2 turns.
The nut is a standard right hand thread. After the initial release, the nut
will turn for a partial turn, and then will release again as you turn the
wrench. This second release is required to loosen the TRANS-TORQUE
bushing from the shaft.

Shaft center-mounted motors

If the unit is equipped with the K-900 slide out motor which is mounted near
the center of the slide out room, use the following directions:

1. Access must be gained to the slide out motor located in the center of the

slide out room.

2. The manual extension or retraction

requires only a 5/8" socket and
ratchet wrench. By placing the
socket on the 5/8" hex nut located
on the gear box of the K-900 motor,
the slide out can be moved in either
direction by turning the hex nut.

3. If the slide out does not move by

using the hex nut, the room can also
be extended or retracted by using
the procedure described for the
shaft end- mounted motors. If the
room is moved using this method,
the correct torque on the 11⁄2"
trans-torque nut is 125 foot pounds
maximum.

2008 Torrey Pine Fifth Wheel by Newmar 8:5

IMPORTANT

The TRANS-TORQUE bushing must be re-tightened to re-couple the slide out
gear motor before moving the coach. This will hold the slide out room in place.
The correct torque on the 11/2" TRANS-TORQUE bushing is 110 foot pounds
maximum. The correct torque on the 11/2" TRANS-TORQUE bushing of the K­900 motor (center shaft motor) is 125 foot pounds maximum.

Slide outs with either the center or end mounted motors can be moved by
pushing the room the full length of its travel in either direction. This method
will require the assistance of at least two people.

Operating Precautions

WARNING

Before extending the slide out, make certain that there is a minimum of five (5)
feet of clear space on the slide out side of the unit. Prior to extending the room,
be sure to unlock the slide out locking arms. Make sure there are no
obstructions either inside or outside the unit that may interfere with the slide out
extension. Tree branches, bushes or telephone poles can cause extensive
damage to the exterior of the unit.

8:6 2008 Torrey Pine Fifth Wheel by Newmar

Chapter 9

ROUTINE MAINTENANCE

EXTERIOR CARE .......................................... 3

Washing ........................................................................ 3

Waxing .......................................................................... 3

Seals .............................................................................. 4

Striping & Decals ......................................................... 4

Rubber Roof Care & Maintenance .............................. 5

Battery Inspection & Care ........................................... 6

INTERIOR CARE ........................................... 7

Carpet ............................................................................ 7

Fabrics .......................................................................... 8

Wall and Ceiling ........................................................... 9

Woodwork ..................................................................... 9

Counter Tops ................................................................ 9

Accessories ................................................................ 10

Detectors .................................................................... 10

Condensation ............................................................. 10

ROUTINE MAINTENANCE .......................... 11

Every Trip ................................................................... 11

Every Three (3) Months ............................................. 11

Every Six (6) Months .................................................. 12

Annually ...................................................................... 12

Winterizing .................................................................. 12

Cold Weather Use ...................................................... 14

E-Z Lube Axles ........................................................... 14

Mor/Ryde RE Suspension ......................................... 15

2008 Torrey Pine Fifth Wheel by Newmar 9:1

9:2 2008 Torrey Pine Fifth Wheel by Newmar

EXTERIOR CARE

IMPORTANT

Damage caused by improper or unapplied maintenance is not covered by your
Newmar Limited Warranty.

Washing

The exterior of your new camping vehicle is made of pre-finished aluminum
and/or fiberglass. Frequent washings and thorough cleanings are required to
prevent damage to the vehicle finish after exposure due to damaging salts,
calcium chloride, road tar, tree sap, insects and other foreign material. Damage
caused by exposure to these items is not covered by your Newmar Limited
Warranty. Never wash the vehicle in direct sunlight, while the vehicle is hot or
with hot water. Build up of mud and dirt under the body can cause damaging
rust on steel parts. Corrosive materials, such as those used for ice and snow
removal and dust control, also accumulate on the underside of the vehicle.
These materials should be removed by spraying the underbelly regularly with
water, especially areas where mud and other foreign materials collect. The
chance of corrosion can be minimized by frequent washings of the vehicle.
When washing the vehicle, make certain that the undercarriage and the wheel
wells are cleaned, as well as the exterior of the coach. Do not use strong soaps
or detergents for washing the vehicle. Always use a mild soap in warm water,
a commercially prepared product for automotive finishes or your local car
wash. Be careful when using a pressure-type washer to avoid loosening any
exterior decals or sealants, etc. After washing, carefully inspect the caulking
around window frames and vents and any other joints that may have separated.
If re-caulking is necessary, it is relatively simple, and it is considered routine
maintenance which is the responsibility of the owner.

IMPORTANT

Never use a strong solvent, such as lacquer thinner or harsh abrasives, on any
of the exterior painted surfaces.

Waxing

The exterior finish will require a routine waxing. When water will not bead
and roll off a freshly washed vehicle, a new coat of wax is needed. Wax not

2008 Torrey Pine Fifth Wheel by Newmar 9:3

only improves the appearance of the vehicle, but it also protects the finish
against oxidation and corrosive materials. The recommended type of wax is
one that is compatible with painted or gel-coated fiberglass finishes, and
contains a UV (ultra-violet) inhibitor. Buffing with a polishing compound will
improve a dull or discolored finish.

Seals

The seals around doors, windows, vents, slide out trim and external seams
should be checked at least twice a year. In addition, the roof seams should be
inspected twice a year for cracking or peeling. If deterioration is noted during
a routine maintenance inspection, reseal the seams or seals with an approved
sealant to prevent leaks. Your dealer can perform the resealing inspections and
work for you. It is recommended that a Newmar Authorized Service Center
perform these inspections, and reseal when necessary.

Proper Sealants for Application

Plas-T-Cote ....................................Metal or fiberglass roof

Surebond #SB-140 .........................Rubber laminated to metal roof

and all skylights.

Carlisle #502-LSW .........................Rubber roof over wood Base

Self Leveling Sealant

Silicone Sealant ............................To cover butyl and other

sealants; not to be used as the
main sealant

Parbond .........................................To seal across tops of

windows, etc. on exterior
where silicone is not used

Striping & Decals

The striping and decals on your vehicle require little maintenance. Treat these
as you would any painted surface on your vehicle. Wash them with mild soap
and warm water, or any retail car soap. Never wash the vehicle in direct
sunlight, while the vehicle is hot or with hot water. Rinse thoroughly to
prevent soap residue accumulation. Use caution with high pressure wash
nozzles. Keep them at least 18 inches from the edge of the decals. High
pressure water may cause the decals to loosen and peel. Test small sections
of decals when using any type of cleaning solution.

9:4 2008 Torrey Pine Fifth Wheel by Newmar

IMPORTANT

When using a polishing compound that does not contain a wax preservative,
reapplying a coat of hard wax after polishing is recommended.

Rubber Roof Care & Maintenance

Proper care and maintenance of your recreational vehicle, including your
rubber roof, is important for trouble-free performance. Normal maintenance
is simple and easy, and does not require special materials. Keep the roof clean.
Clean the roof at least four (4) times annually. For normal cleaning:

1. Use RC100 Dicor Synthetic Roof & General Purpose cleaner or a mild

laundry detergent.

CAUTION

Do not use general purpose cleaners or conditioners containing petroleum
solvents, harsh abrasives or citric-based cleaners. You may cause irreparable
damage to your roof.

2. Rinse the complete roof with clean water to remove any loose dirt or

debris.

3. Using a medium bristle brush, along with your selected cleaner mixed

with water, scrub the entire roof. Rinse thoroughly with clean water to
avoid residue build up on the roof or sidewalls of the vehicle.

4. For more difficult stains, you may use cleaning materials mentioned

above in a more concentrated mixture. For stubborn stains, use of a cloth
dampened with household bleach. Household bleach can be used (fully
concentrated) and allowed to soak in stubborn stain areas, then scrubbed
with a medium bristle brush or rag. Rinse thoroughly. DO NOT pour the
bleach on the roof and allow it to run down the sides of the vehicle.
Concentrated bleach may damage the graphics.

2008 Torrey Pine Fifth Wheel by Newmar 9:5

Battery Inspection & Care

WARNING

Remove rings, metal watch bands and other metal jewelry before working
around batteries. Use caution when using metal tools. If a tool contacts a battery
terminal or metal connected to it, a short circuit could occur which could cause
personal injury, explosion or fire.

WARNING

Use caution when working on top of your vehicle. The wet roof membrane may
be extremely slippery.

IMPORTANT

Do not use solvents such as acetone, MEK, toluene, etc. on the decals. Any
solvent including alcohol may soften or smear colors. Do not use lacquer thinner
or paint on decals. Do not overcoat the decals with clear paint. Do not allow
gasoline or other fuels to drip or stay on the decals for any length of time. If this
occurs, immediately flush the area with water.

Remember, when a battery is not used for an extended period of time, it may
lose its charge. Periodic charging of the battery during storage of the unit will
increase the life of the battery. Check the external condition of the battery
periodically. Look for cracks in the cover and case. Check the vent plugs and
replace them if they are cracked or broken. Keep the battery clean.
Accumulations of acid film and dirt may permit current flow between the
terminals, which could drain the battery. To clean, wash the battery with a
diluted solution of baking soda and water to neutralize any acid present. Rinse
thoroughly with clean water. Foaming around the terminals or on top of the
battery is a sign that acid is being neutralized. Avoid getting the baking soda
solution in the battery. Secure all vent caps. Dry the battery cables and
terminals. Do not use grease on the bare metal inside the cable terminals to
prevent corrosion. Grease can act as an insulator. Electricity will not flow
through it. A plastic ignition spray will protect the terminals after they have
been cleaned.

9:6 2008 Torrey Pine Fifth Wheel by Newmar

When storing the unit for a short period of time, the battery should be
disconnected from the coach to prevent draining. As an option, your unit may
be equipped with a battery disconnect switch. Simply push the switch to the
STORE position when storing your unit. To use the unit again, simply push
the switch to the USE position. If the unit is not equipped with a disconnect
switch, disconnect the cables directly from the battery.

When not using your unit for an extended period of time, the battery should be
removed and stored in a warm place. Mark the cables, positive and negative,
for easy identification. Batteries are not to be stored on concrete floors. The
battery may require periodic charging during storage. If the unit is to be stored
for a long period of time, it is recommended that all the batteries inside the unit
be removed from clocks, radios, smoke alarms, etc. This will prevent
unnecessary drain and corrosion of the batteries. The coach battery is a deep
cycle RV/marine battery. This type of battery consumes water and must be
filled periodically. Please be sure to check the battery water level on a regular
basis. Consult the owner’s manual supplied by the battery manufacturer.

WARNING

Do not allow the battery fluid to contact your skin, eyes, fabric, or painted
surfaces. The fluid could cause serious personal injury or property damage.
Wear eye protection when working with any battery.

CAUTION

Disconnect the 120 volt electrical power cord and the negative terminal from the
coach batteries before working on the electrical system.

INTERIOR CARE

Carpet

A weekly routine of vacuuming the carpet and fabrics throughout the vehicle
is recommended. Doing this will prevent an accumulation of dirt that can
detract from the materials appearance and shorten its life. Remember to empty
or replace vacuum bags before they become half full. In carpet areas that
receive the most sunlight, close the curtains frequently to prevent fading. And
act quickly when anything is spilled or dropped on the carpet. Included in the

2008 Torrey Pine Fifth Wheel by Newmar 9:7
