NewLine HD 12v User guide

Digital High Defintion 230/12V Satellite

Receiver

User Manual

Important Safety Instructions

1. Read these instructions

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that
produce heat.

8. Operate this product only from the type of power source indicated
on the label. If you are not sure of the type of power connected to
your home, consult your local power company. Disconnect the
unit from the mains before any maintenance or installation
procedure.

9. Protect the mains cord from damage and stress.

10. Only use attachments /accessories specified by the manufacturer.

11. Unplug this apparatus during lightning storms or when unused for

long periods of time.

12. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, in
cluding damage to the mains cord or plug, if the unit has been ex
posed to liquid or moisture, has been dropped or is not operating
correctly.

13. Do not impede the air flow into the unit by blocking the ventilation
slots.

14. Attention should be drawn to the environmental aspects of battery
disposal.

15. Use the apparatus in moderate climate.
WARNING: To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture
WARNING: The batteries shall not be exposed to excessive heat such as

directsun light, fire, etc.

Warning:

• The apparatus shall not be exposed to dripping or splashing and that no objects lled
with liquids, such as vases, shall be placed on the apparatus.

• The MAINS plug or an appliance coupler is used as the disconnect device, the dis
connect device shall remain readily operable

• The batteries shall not be exposed to excessive heat such as sunshine, re or the
like.

This symbol indicates that dangerous voltages constituting a risk of electric
shock are present within this unit.

This Symbol indicates that there are important operating and maintenance inst­ructions in the literature accompanying this unit.

This Symbol indicates that this product incorporates double insulation between
hazardous mains voltage and user accessible parts.
When servicing use only identical replacement parts.

Package Contents

Before installation, please check the contents of the package.
The package should contain the following items:

1) DVB-S2 Receiver x1 pcs

2) Remote Control x1 pcs

3) AAA Battery for the Remote Control x1 pair

4) User Manual x1 pcs

5) 12/230V Power Adapter x1 pcs

6) 12V mobile Adapter x1 pcs

7) external Infrarot Sensor x1 pcs

8) CVBS Adapter x1 pcs

Table of Contents

Front and Rear Panel
Remote Control
System Connection
Satellite Setting
Channel Scan
Basic Operation
Program Setting
Picture Setting
Channel Search
Time Setting
Option
System Setting
USB
Time shift and Recording
Timer
EasyFind
Troubleshooing

Technical Specications

Notice About Recycling
Declaration of Conformity

1
2
4
5
7
8
8
9

10

11
11

11
13
14
15
15
23
24
25
25

Front and Rear Panel

1. Front panel

2.Rear panel

1 2 3 4 5 6 7

1. LNB IN: This socket connects to your satellite antenna.

2. LNB OUT:

3. USB: For Software upgrade and media playback

4. IR Sensor: Used to Receive the signal from Remote Control.

5. HDMI: High definition audio and video output used to connect to a

HDMI device.

6. CVBS/L/R: Connector for the analog output with the delivered
chinch cable.

7. 12V: Power Connector

1

Remote Control

POWER: Switch the receiver in and out of Standbymode.
0-9: Numeric keys.
CH-/CH+: Program changing keys.
MENU: Display main menu on TV screen, and

press again to disappear menu.

OK: To conrm current setting, or display channel

list in no-menu mode.

VOL-/VOL+: To increase / decrease volume.
EPG: Shows the Electronic Program Guide
FAV: Displays your favorite channel list.

Press FAV again to access to the other favorite lists.

V-FORMAT: Switch the HDMI resolutions.
RECALL: Go back to the previous viewed channel.
RED/GREEN/YELLOW/BLUE: Used to navigate bet-

ween pages in teletext mode
and special functions in Menu or EPG.
TTX: Switch in Teletext, if current channel has this option,
and use EXIT key to quit Teletext
SUB-T: Display subtitle options (availability depends on
the channel).
LANG: Change the Audio Language and Left/Right
channel (availability depends on the channel).

EXIT: Use this key to quit current menu.
INFO: Displays information about the current channel.
TV/RADIO: Switch between Digital Radio and Digital TV

mode.

MUTE: To switch audio output on/off.
PAGE+/PAGE-: To navigate inside the menus.
ASPECT: Switches Aspect Ration such as 4:3 / 16:9.
TIMESHIFT: Use to start Time shift function.
TIMER: Use to access ON/OFF Timer directly.
PVR: Use to access recorded content in USB drive.
GOTO: Go to desired time in multimedia le.

2

REPEAT: Repeat play multimedia le.

Installing the Batteries

Remove the battery cover from the rear of the Remote Control and place
2xAAA size batteries inside the compartment.
Please make sure the battery polarities match the polarity markings inside
The compartment.

Using the Remote Control

To use the Remote Control, point it towards the external IR Sensor of the Digital Set
Top Box.
The Remote Control has a range of up to 6 metres from the Set Top Box at an
Angle of up to 60 degrees.

The Remote Control will not operate if its path is blocked.

Sunlight or very bright light will decrease the sensitivity of the
Remote Control.

3

System connection

For a basic connection from your Set Top Box to your television set, you can
use the CVBS Adapter. For a higher quality connection use a direct HDMI connection.

Connect an audio amplier you have to use also the CVBS Adapter for L/R Audio.

Satellite Setting

(1) Preparation:

You will have to know the following parameter to make a successful channel
Scanning.

The satellite orientation.
If you have more than one antenna or one antenna with more than one LNB,
You will have to know which type of switch (Toneburst od DISEqC) is employs
And to which port each Antenna LNB is connected.
For a Unicable/SCR EN50494, you will have to know which IF-Channel is
Available and its corresponding frequency.

Please ask the installer if any of the parameter is not known.

4

Example:

A satellite antenna orients satellite ASTRAS 19.2° and has a “universal” or
“Digital” LNB. We recommend the pre-programmes list in this case.
If you would not like to use the pre-programmed list, the common setup for
ASTRA 19.2° is as followed:

Satellite: 019.2E Astra 1H.
LNB Type: 09750 / 10600
LNB Voltage: 13/18V
22KHz: AUTO
Toneburst: None
DiSEqC 1.0: None
DiSEqC 2.0: None
Motor: None

(2) Process:

On the left side of the screen there is a list of satellites which is pre­Programmed. Settings of the chosen satellite is displayed on the right side.

Process:

Select the rst satellite to be set up with UP/DOWN.
Press the OK button. The chosen satellite is marked with a hook, conrming

this satellite will be considered in the coming channel scan
Press the button RIGHT to access to the right side.
Select the option with UP/DOWN and change the parameter with
LEFT/RIGHT.

Press Menu after dening all parameters for this satellite to get back to the

Left side.
If your satellite system can receiver signals from a number of satellites,

Select a further satellite with UP/DOWN. Press OK and dene the parameter

On the right side.
Repeat this procedure for all satellites available for your receiver.

Notes:
After a correct setting, an approximate value of the signal quality will be
Shown on the lower part of the menu.
If a satellite is missing on the list, press the Red button. A dialogue window
will appear, input the value for longitude, east/west and frequency and
choose “Blind Scan” in the coming channel san. If you add a satellite to the
list, there will be no display of the signal quality for this satellite, in spite of
correct setting. Signal quality can only be displayed for satellites saved
under the transponder list.
Press GOTO to display the transponder of the chosen satellite. Add new
Transponder with the RED button and mark the transponder for channel scan
With OK.

5
