Nevion WDM-2-MkII User Manual

WDM-2-MkII

2-channel WDM – Wave Length Division Muliplexer

Single Mode

User manual

Rev. A

Nevion

Nordre Kullerød 1
3241 Sandefjord
Norway
Tel: [phone]

nevion.com

WDM-2-Mk2 Rev. A

Nevion Europe
P.O. Box 1020

3204 Sandefjord, Norway
Support phone 1: [phone]
Support phone 2: [phone]

Nevion USA

1600 Emerson Avenue

Oxnard, CA 93033, USA

Toll free North America: [phone]

Outside North America: +1 (805) 247-

8560

E-mail: [e-mail]

See http://www.nevion.com/support/ for service hours for customer support globally.

Rev.

Repl.

Date

Sign

Change description

A 0 2015-05-13

MB

Cover page update; DoC removed; no other
changes to content

0 - 2012-05-23

MR

Initial version

Nevion Support

Revision history

Current revision of this document is the uppermost in the table below.

nevion.com | 2

WDM-2-Mk2 Rev. A

Contents

Revision history ...................................................................................................................... 2

1 Product overview ................................................................................................................. 4

2 Specifications ................................................................................................ ...................... 5

2.1 WDM-2 ............................................................................................................................. 5

2.1.1 Optical ........................................................................................................................... 5

2.1.2 Electrical ........................................................................................................................ 5

3 Mounting the CWDM module into frame .............................................................................. 6

4 Connections ...................................................................................................................... 10

5 Laser safety precautions ................................................................................................... 12

General environmental requirements for Nevion equipment ................................................. 13

Product Warranty ................................................................................................................. 14

Appendix A Materials declaration and recycling information ................................................. 15

A.1 Materials declaration ...................................................................................................... 15

A.2 Recycling information ..................................................................................................... 15

nevion.com | 3

WDM-2-Mk2 Rev. A

WDM

1310nm

1550nm

Common optical port

1310nm+1550nm

WDM-2

2-Channel WDM SM

1 Product overview

Figure 1 Block diagram of the WDM module operation

The Flashlink 2-Channel WDM is a wavelength division multiplexer / demultiplexer
module. The unit is passive and there is no need for power or control. The WDM is
bitrate and format transparent; meaning SDI, Ethernet and SDH/SONET is supported.
The WDM can be used for uni- directional and bi-directional application.

The optical multiplexing is made for the 2nd and 3rd optical windows (1310nm and
1550nm).

The WDM has a 1310nm, a 1550nm and a combined WDM port allowing 2 optical
signals to be multiplexed on a single fiber.

The product comes with 2 SC/UPC fiber patch cords to connect the modules together.
The product is available in the following versions:

nevion.com | 4

WDM-2-Mk2 Rev. A

Optical wavelength:

2nd & 3rd opt. window (1310nm & 1550nm)

Optical band pass:

1295-1325nm & 1535-1565nm

Transmission circuit fiber:

9/125um Single Mode

Connector:

SC/PC
(Please be aware that SC/UPC is not an official

standard though it is often used to specify better
return loss parameters than SC/PC)

Return loss:

better than 40dB w/Single Mode fiber

Insertion loss:

< 2dB incl. connectors (<1,2dB typ.)

Isolation:

> 17dB

Directivity:

> 50dB

Power:

None

Control:

None

2 Specifications

2.1 WDM-2

2.1.1 Optical

2.1.2 Electrical

nevion.com | 5

WDM-2-Mk2 Rev. A

3 Mounting the CWDM module into frame

The CWDM filter must be mounted in a Flashlink sub rack. This is done from the rear.
Do not use force when inserting the CWDM filter. The module’s main board has a
special design to utilize both card rails in the FL sub rack. In order to enter the lower
rail before sliding the unit into its final position, please follow the method shown in the
pictures below.

(Please note that the pictures show a not relevant product with similar mechanical
solution).

Figure 2 Enter the module with angle

nevion.com | 6

WDM-2-Mk2 Rev. A

Figure 3 PCB tag inside the power bus PCB

Figure 4 Opposite side of PCB tag

nevion.com | 7

WDM-2-Mk2 Rev. A

Figure 5 Adjust to normal position

Figure 6 Slide the module to final position using both card rails

nevion.com | 8

WDM-2-Mk2 Rev. A

Figure 7 Module mounted in frame

nevion.com | 9

WDM-2-Mk2 Rev. A

4 Connections

Figure 8 WDM-2 mounted in a Flashlink subrack

The WDM-2 is a self-contained module where the connector module is attached to the
box protecting the optical component. The modules shall be mounted from the rear of
the frame.

nevion.com | 10

WDM-2-Mk2 Rev. A

Figure 9 Overview of the connector module

nevion.com | 11

WDM-2-Mk2 Rev. A

1

5 Laser safety precautions

These are guidelines to limit hazards from laser exposure.
All the available EO units in the Flashlink range include a laser.
Therefore this note on laser safety should be read thoroughly even though there is no

laser onboard this product.
The lasers emit light at wave lengths between 1271 nm and 1611 nm. This means that

the human eye cannot see the beam, and the blink reflex cannot protect the eye. (The
human eye can see light between 400 nm to 700 nm).

A laser beam can be harmful to the human eye (depending on laser power and
exposure time). Therefore:

Be careful when connecting / disconnecting fiber pigtails (ends).
Never look directly into the pigtail of the laser/fiber.
Never use microscopes, magnifying glasses or eye loupes to look into a

fiber end.
Use laser safety goggles blocking light between 1271 nm and at 1611 nm

Instruments exist to verify light output power: Power meters, IR-cards etc.
Flashlink features:
The FR-2RU-10-2 is classified as Class 1 laser product according to EN 60 825-

1:94/A11:96, and CFR Ch1 (1997) Part 1040.10.
If the front panel is removed, the FR-2RU-10-2 is classified as Class 1 laser product

according to EN 60 825-1:94/A11:96, and class IIIb according to CFR Ch1 (1997) Part

1040.10.
Maximum output power1: 17 mW
Operating wavelengths: > 1260 nm

Max power is for safety analysis only and does not represent device performance.

nevion.com | 12

WDM-2-Mk2 Rev. A

1.

The equipment will meet the guaranteed performance specification under the
following environmental conditions:

-

Operating room temperature
range:

0°C to 50°C

-

Operating relative humidity range:

<90% (non-condensing)

2.

The equipment will operate without damage under the following environmental
conditions:

-

Temperature range:

-10°C to 60°C

-

Relative humidity range:

<95% (non-condensing)

General environmental requirements for Nevion equipment

nevion.com | 13

WDM-2-Mk2 Rev. A

Product Warranty

The warranty terms and conditions for the product(s) covered by this manual follow the
General Sales Conditions by Nevion, which are available on the company web site:

www.nevion.com

nevion.com | 14

WDM-2-Mk2 Rev. A

組成名稱

Part Name

Toxic or hazardous substances and elements

鉛

Lead

(Pb)

汞

Mercury

(Hg)

镉

Cadmium

(Cd)

六价铬

Hexavalent

Chromium

(Cr(VI))

多溴联苯

Polybrominated

biphenyls

(PBB)

多溴二苯醚

Polybrominated

diphenyl ethers

(PBDE)

WDM-2-Mkll

O O O O O

O

O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for
this part is below the limit requirement in SJ/T11363-2006.

X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous
materials used for this part is above the limit requirement in SJ/T11363-2006.

Appendix A Materials declaration and recycling
information

A.1 Materials declaration

For product sold into China after 1st March 2007, we comply with the “Administrative

Measure on the Control of Pollution by Electronic Information Products”. In the first
stage of this legislation, content of six hazardous materials has to be declared. The
table below shows the required information.

This is indicated by the product marking:

A.2 Recycling information

Nevion provides assistance to customers and recyclers through our web site

http://www.nevion.com/. Please contact Nevion’s Customer Support for assistance with

recycling if this site does not show the information you require.
Where it is not possible to return the product to Nevion or its agents for recycling, the

following general information may be of assistance:

 Before attempting disassembly, ensure the product is completely disconnected

from power and signal connections.

 All major parts are marked or labeled to show their material content.
 Depending on the date of manufacture, this product may contain lead in solder.
 Some circuit boards may contain battery-backed memory devices.
