3GHD-OE-2-SFP
Dual SD/HD/3G-SDI optical to electrical converter
with long haul optical SFP
User manual
Rev. C
Nevion
Nordre Kullerød 1
3241 Sandefjord
Norway
Tel: +47 33 48 99 99
nevion.com
3GHD-OE-2-SFP Rev. C
Nevion Europe
P.O. Box 1020
3204 Sandefjord, Norway
Support phone 1: +47 33 48 99 97
Support phone 2: +47 90 60 99 99
Nevion USA
1600 Emerson Avenue
Oxnard, CA 93033, USA
Toll free North America: (866) 515-0811
Outside North America: +1 (805) 247-8560
E-mail: support@nevion.com
See http://www.nevion.com/support/ for service hours for customer support globally.
Rev.
Repl.
Date
Sign
Change description
C B 2015-03-26
AD
Figure 14: Fiber connections added
B A 2014-09-01
MMI
Ready for product release
A - 2014-06-20
AD
Initial document
Nevion Support
Revision history
Current revision of this document is the uppermost in the table below.
nevion.com | 2
3GHD-OE-2-SFP Rev. C
Contents
Revision history ........................................................................................................ 2
1 Product overview ................................................................................................... 4
2 Specifications ........................................................................................................ 5
2.1 General ......................................................................................................................... 5
2.2 Optical Inputs ................................................................................................................ 5
2.3 Electrical Outputs .......................................................................................................... 5
2.4 Standards ...................................................................................................................... 5
3 Configuration ......................................................................................................... 6
3.1 Multicon Gyda configuration .......................................................................................... 6
3.2 Configuration through DIP settings ................................................................................ 7
3.2.1 Re-clocker mode ........................................................................................................ 8
3.2.2 Display optical input power ......................................................................................... 8
3.2.3 Automatic change over ............................................................................................... 9
3.2.4 Single converter configuration example .....................................................................10
3.2.5 Dual converter configuration example .......................................................................10
3.2.6 Dual converter with changeover configuration example ................................ .............12
4 Connections ........................................................................................................ 13
4.1 Mounting the connector module ...................................................................................13
4.2 Terminal format support ...............................................................................................13
5 Operation ............................................................................................................. 15
5.1 Module status ...............................................................................................................15
5.1.1 Multicon Gyda status interface ..................................................................................15
5.2 GPI ALARM – Module Status Outputs ..........................................................................16
5.2.1 GPI connections ........................................................................................................16
5.3 Front panel – Status monitoring ...................................................................................16
General environmental requirements for Nevion equipment .................................. 18
Product Warranty.................................................................................................... 19
Appendix A Materials declaration and recycling information .................................. 20
A.1 Materials declaration ....................................................................................................20
A.2 Recycling information ...................................................................................................20
nevion.com | 3
3GHD-OE-2-SFP Rev. C
1 Product overview
The Flashlink 3GHD-OE-2-SFP is a dual multi bit-rate optical to electrical converter module
providing high performance media conversion for various signal formats from 19.4Mbps up
to 2970Mbps. Unmatched signal accuracy, even in critical applications with pathological
signal patterns makes the 3GHD-OE-2-SFP the first choice for all optical transport demands.
The 3GHD-OE-2-SFP can transport all SD, HD and 3G signal formats in addition to DVB-ASI
and SMPTE310M. It performs optical refreshing and signal re-clocking, which is selectable
on application. The optical inputs are embedded in optional SFP module, which makes the
module configurable to application specific needs. The open system platform of Nevion
Flashlink system allows easy interoperability with third party fiber optical systems.
The 3GHD-OE-2-SFP unit has also three electrical outputs for each converter, which reduces
the need for additional DA’s.
Figure 1 Block diagram of the 3GHD-OE-2-SFP dual converter
nevion.com | 4
3GHD-OE-2-SFP Rev. C
2 Specifications
2.1 General
Power +5V DC / 3.5W, max
Control Control system for access to setup and module status with
BITE (Built-In Test Equipment)
Temp. range 0 to +40 °C
2.2 Optical Inputs
Number of inputs 2
Transmission circuit fiber Single mode 9/125um
Connector LC/UPC, single mode
Optical wavelength ~1260-1620nm
Optical sensitivity See manual for installed SFP
Optical overload See manual for installed SFP
Detector damage threshold See manual for installed SFP
2.3 Electrical Outputs
Number of outputs 6 (3 per converter)
Connector BNC
Impedance 75 ohm
Return loss >15dB @ 5-1485MHz
>10dB 1485-2970MHz
Peak to peak signal level 800mV +/- 10%
Signal polarity 1 inverting, 2 non-inverting (per converter)
2.4 Standards
Supported standards for electrical and optical ports:
SMPTE292M, SMPTE259M, SMPTE297M, SMPTE305.2M, SMPTE310M, SMPTE424M,
DVB-ASI EN50083-9.
nevion.com | 5
3GHD-OE-2-SFP Rev. C
3 Configuration
Configuration of this card can either be done from Multicon Gyda element manager or locally
on the card by dipswitches.
3.1 Multicon Gyda configuration
Below is a snapshot from the Multicon Gyda interface.
Figure 2 Configuration tab
nevion.com | 6
3GHD-OE-2-SFP Rev. C
Switch #
Label
Function, DIP=OFF
Function, DIP=ON
Comment
1
EQ1
Not used
2
EQ2
Not used
3 Not used
4
Latch
Latched
Non-latched
Select if changeover
is latched or nonlatched
5
Main
Optical input 1 is
main
Optical input 2 is main
Select’s main input to
changeover
6
Level
LED’s normal
operation
All LED’s showing
optical input power
DOP
See Table 2
Displaying optical
input power
7
Port
Optical input 1
Optical input 2
Selects which optical
input to be used for
dip 7/DOP
8
OVR
GYDA control.
Configuration with
GYDA
Override GYDA
control. Configuration
with DIP switch
Select configuration
from GYDA
9
RCL1
Reclocker 1 bypass
Reclocker 1 enabled
Sets reclocker mode
for output 1
10
CHO1
Change over
disabled
Change over enabled
Enables change over
for output 1
11
SEL1
Optical input 1
Optical input 2
This setting are
overridden if DIP 10
(CHO1) is enabled
12 Not used
3.2 Configuration through DIP settings
The 3GHD-OE-2-SFP can support a number of different broadcast formats. The correct
configuration can either be set with the two Dipswitches on the card or through the GYDA
Control System. The layout is shown in the drawing below with the DIP switches to the upper
left position.
Figure 3 3GHD-OE-2-SFP board layout
Table 1: DIP settings.
nevion.com | 7
3GHD-OE-2-SFP Rev. C
13
RCL2
Reclocker 2 bypass
Reclocker 2 enabled
Sets reclocker mode
for output 2
14
CHO2
Change over
disabled
Change over enabled
Enables change over
for output 2
15
SEL2
Optical input 1
Optical input 2
This setting are
overridden if DIP 14
(CHO2) is enabled
16 Not used
All DIP switches are off when pointing towards the release handle.
3.2.1 Re-clocker mode
The re-clocker can be set to re-clock or bypass from DIP#9 and DIP#13 or from GYDA.
When re-clocker is set to re-clock mode jitter from signal is removed. Accepted bitrates is
270, 1483.5, 1485, 2967 and 2970Mbps.
When re-clocker is set to bypass the converter accepts all bitrates between 2 to 2970Mbps.
Note that in this mode the jitter is not removed and this can cause problems for equipment
following the converter.
3.2.1.1 Transparency
This converter only looks at the bitrates and not the content. This means that any signal with
correct bitrates is converted. The product is transparent to data in the ancillary space like
embedded audio.
3.2.2 Display optical input power
The LED’s can be used as an optical power meter. This is practical under installation of the
module. The power measurement is not accurate but can be used as an indication of optical
power strength. Remember to turn this function of after installation. When all LEDs are green
the optical input power is more than -6.5dBm. When all LEDs are off input power is below 25dBm.
The DOP (Display of Optical input Power) can only be turned on from the DIP. DOP is turned
on by DIP#6.
nevion.com | 8
3GHD-OE-2-SFP Rev. C
Optical input power
Status LED
LOS/lock1 LED
LOS/lock2 LED
More than -6.5dBm
Green
Green
Green
Green
-7.0dBm to –8.5dBm
Yellow
Green
Green
Green
-9.0dBm to –10.5dBm
Red
Green
Green
Green
-11.0dBm to –12.5dBm
Green
Green
Green
-13.0dBm to –14.5dBm
Yellow
Green
Green
-15.0dBm to –16.5dBm
Red
Green
Green
-17.0dBm to –18.0dBm
Green
Green
-18.5dBm to –19.0dBm
Yellow
Green
-19.5dBm to –20.0dBm
Red
Green
-21.0dBm to –22.0dBm
Green
-23.0dBm to –24.0dBm
Yellow
Below -25dBm
Red
Table 2 Displaying optical input power
3.2.3 Automatic change over
Dual optical converter has an automatic change over module. This module has the possibility
to have an automatic change over on the input. This can be used in redundancy systems
where the user wants automatically switch to a backup port when the main input loses signal.
This function can be selected with DIP#10 and Dip#14. Each converter can be configured to
be main and backup input by DIP#5 or from GYDA.
3.2.3.1 Trigger condition
Loss of optical power trigs the automatic change over. When the main input lose optical
power the backup input is selected. When the backup input is active an alarm is displayed in
GYDA. When the main input optical power is restored the converter switches immediately
back to main input and alarm is restored.
Note that bit error or loss of lock on re-clocker does not trigger the automatic
change over.
nevion.com | 9
3GHD-OE-2-SFP Rev. C
Optical input
O2
O2
I/O2
O1
O1
I/O1
Reclocker 2
3G/HD/SD-SDI
Reclocker
3G/HD/SD-SDI
EQ1
EQ2
Latch
Main
Port
OVR
ON
1
8
RCL1
CHO1
SEL1
RCL2
CHO2
SEL2
ON
1
8
Level
Optical input
O2
O2
I/O2
O1
O1
I/O1
EQ1
EQ2
Latch
Main
Port
OVR
ON
1
8
RCL1
CHO1
SEL1
RCL2
CHO2
SEL2
ON
1
8
Level
Optical input 1
O2
O2
I/O2
O1
O1
I/O1
Reclocker 2
3G/HD/SD-SDI
Reclocker 1
3G/HD/SD-SDI
EQ1
EQ2
Latch
Main
Port
OVR
ON
1
8
RCL1
CHO1
SEL1
RCL2
CHO2
SEL2
ON
1
8
Level
Optical input 2
Optical input 1
O2
O2
I/O2
O1
O1
I/O1
Reclocker 2
3G/HD/SD-SDI
Reclocker 1
3G/HD/SD-SDI
EQ1
EQ2
Latch
Main
Port
OVR
ON
1
8
RCL1
CHO1
SEL1
RCL2
CHO2
SEL2
ON
1
8
Level
Optical input 2
3.2.4 Single converter configuration example
Figure 4 Single OE converter with reclocker
Figure 5 Single OE converter with reclocker in bypass
3.2.5 Dual converter configuration example
Figure 6 Dual OE converter, standard setup
nevion.com | 10
Figure 7 Dual OE converter, input swap
3GHD-OE-2-SFP Rev. C
Optical input 1
O2
O2
I/O2
O1
O1
I/O1
Reclocker 2
3G/HD/SD-SDI
Reclocker 1
3G/HD/SD-SDI
EQ1
EQ2
Latch
Main
Port
OVR
ON
1
8
RCL1
CHO1
SEL1
RCL2
CHO2
SEL2
ON
1
8
Level
Optical input 2
Optical input 1
O2
O2
I/O2
O1
O1
I/O1
Reclocker 2
3G/HD/SD-SDI
Reclocker 1
3G/HD/SD-SDI
EQ1
EQ2
Latch
Main
Port
OVR
ON
1
8
RCL1
CHO1
SEL1
RCL2
CHO2
SEL2
ON
1
8
Level
Optical input 2
Figure 8 Dual OE converter with DA, input 1
Figure 9 Dual OE converter with DA, input 2
nevion.com | 11
3GHD-OE-2-SFP Rev. C
Optical input 1
O2
O2
I/O2
O1
O1
I/O1
Reclocker 2
3G/HD/SD-SDI
Reclocker 1
3G/HD/SD-SDI
EQ1
EQ2
Latch
Main
Port
OVR
ON
1
8
RCL1
CHO1
SEL1
RCL2
CHO2
SEL2
ON
1
8
Level
Optical input 2
Change
over
Optical input 1
O2
O2
I/O2
O1
O1
I/O1
Reclocker 2
3G/HD/SD-SDI
Reclocker 1
3G/HD/SD-SDI
EQ1
EQ2
Latch
Main
Port
OVR
ON
1
8
RCL1
CHO1
SEL1
RCL2
CHO2
SEL2
ON
1
8
Level
Optical input 2
Change
over
Optical input 1
O2
O2
I/O2
O1
O1
I/O1
Reclocker 2
3G/HD/SD-SDI
Reclocker 1
3G/HD/SD-SDI
EQ1
EQ2
Latch
Main
Port
OVR
ON
1
8
RCL1
CHO1
SEL1
RCL2
CHO2
SEL2
ON
1
8
Level
Optical input 2
Change
over
3.2.6 Dual converter with changeover configuration example
Figure 10 Changeover on all output, optical 1 as main
Figure 11 Changeover on all output, optical 2 as main
Figure 12 Changeover on output 1, optical 1 as main. Optical 2 on output 2
nevion.com | 12
3GHD-OE-2-SFP Rev. C
4 Connections
The 3GHD-OE-2-SFP has a dedicated connector module; 3GHD-EO-2-C1. This module is
mounted at the rear of the sub-rack. The layout of the module is shown in the figure below.
Figure 13 Connector module for 3GHD-OE-L-2-SFP
Figure 14: Fiber connections
4.1 Mounting the connector module
The details of how the connector module is mounted, is found in the user manual for the subrack frame FR-2RU-10-2.
This manual is also available from our web site: http://www.nevion.com
4.2 Terminal format support
The different input and output ports on 3GHD-OE-2-SFP can support a number of formats.
The table below show which signal formats are supported on the selected terminals.
Unused inputs should be terminated to avoid alarms triggered by noise.
nevion.com | 13
3GHD-OE-2-SFP Rev. C
Terminal
Function
Supported Format
Mode
OPT1
OPT2
Optical input
SDI, DVB-ASI,
SMPTE310, Transparent
Input
I/O1
I/O2
O1
O2
Electrical Output
Reclocked DA output
SDI, DVB-ASI, Transparent
Output
O1––
O2––
Electrical Output
Reclocked DA inverted
output
SDI, Transparent
Output
GPI ALARM
Open Collector Alarms
Wired alarms
OC Output
Table 3 Signal support
nevion.com | 14
3GHD-OE-2-SFP Rev. C
5 Operation
5.1 Module status
The status of the module can be monitored in three ways.
1. GYDA System Controller (optional).
2. GPI at the rear of the sub-rack.
3. LED’s at the front of the sub-rack.
Of these three, the GPI and the LED’s are mounted on the module itself, whereas the GYDA
System Controller is a separate module giving detailed information on the card status.
5.1.1 Multicon Gyda status interface
Figure 15 Dual converter status tab
The on-board temperature measurement is a feature used for monitoring
variations in temperature over time and can be accessed thru SNMP. The
absolute value of the temperature measurement has little value of its own as it
does not reflect the temperature inside the electronics nor the ambient frame
temperature.
nevion.com | 15
3GHD-OE-2-SFP Rev. C
Signal
Name
Pin #
Mode
Status
General error status for the module.
Pin 1
Open Collector
This is normally
closed.
LOS1
Loss of signal on input 1.
Pin 2
Open Collector
LOS2
Loss of signal on input 2.
Only for dual converter
Pin 3
Open Collector
Ground
0V / gnd pin.
Pin 8
0V.
5.2 GPI ALARM – Module Status Outputs
These outputs can be used for wiring up alarms for third party control systems. The GPI
outputs are open collector outputs, sinking to ground when activated. The GPI connector is
shown in figures below.
Electrical maximums for GPI outputs:
Max current: 100mA
Max voltage: 30V
5.2.1 GPI connections
3GHD-EO-SFP module GPI pinning:
Figure 16 GPI connector
5.3 Front panel – Status monitoring
The status of the module can be easily monitored visually by the LED’s at the front of the
module. The LED’s are visible through the front panel as shown in the figure below.
nevion.com | 16
3GHD-OE-2-SFP Rev. C
Diode \ State
Red LED
Yellow LED
Green LED
No light
Status
Module is faulty, or
module is
initializing.
N/A
Module is OK
Module power is OK
Module has no
power
LOS/LOCK1
No input signal on
electrical output 1.
Input signal on
electrical output
1 but reclocker
not in lock.
Input signal on
electrical output 1
and reclocker in
lock.
LOS/LOCK2
No input signal on
electrical output 2.
Input signal on
electrical output
1 but reclocker
not in lock.
Input signal on
electrical output 1
and reclocker in
lock.
Figure 17 Front panel LED’s
The 3GHD-OE-2-SFP has 3 LED’s each showing a status corresponding to the GPI pinning.
When DIP#3 is on the LED’s are used as an optical power meter.
Table 4 Front panel LED’s
nevion.com | 17
3GHD-OE-2-SFP Rev. C
1.
The equipment will meet the guaranteed performance specification under the
following environmental conditions:
-
Operating room temperature
range:
0°C to 45°C
-
Operating relative humidity range:
<90% (non-condensing)
2.
The equipment will operate without damage under the following environmental
conditions:
-
Temperature range:
-10°C to 55°C
-
Relative humidity range:
<95% (non-condensing)
General environmental requirements for Nevion equipment
nevion.com | 18
3GHD-OE-2-SFP Rev. C
Product Warranty
The warranty terms and conditions for the product(s) covered by this manual follow the
General Sales Conditions by Nevion, which are available on the company web site:
www.nevion.com
nevion.com | 19
3GHD-OE-2-SFP Rev. C
組成名稱
Part Name
Toxic or hazardous substances and elements
鉛
Lead
(Pb)
汞
Mercury
(Hg)
镉
Cadmium
(Cd)
六价铬
Hexavalent
Chromium
(Cr(VI))
多溴联苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
3GHD-OE-2-SFP
O O O O O
O
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is
below the limit requirement in SJ/T11363-2006.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials used
for this part is above the limit requirement in SJ/T11363-2006.
Appendix A Materials declaration and recycling
information
A.1 Materials declaration
For product sold into China after 1st March 2007, we comply with the “Administrative Measure
on the Control of Pollution by Electronic Information Products”. In the first stage of this
legislation, content of six hazardous materials has to be declared. The table below shows
the required information.
This is indicated by the product marking:
A.2 Recycling information
Nevion provides assistance to customers and recyclers through our web site
http://www.nevion.com/. Please contact Nevion’s Customer Support for assistance with
recycling if this site does not show the information you require.
Where it is not possible to return the product to Nevion or its agents for recycling, the following
general information may be of assistance:
Before attempting disassembly, ensure the product is completely disconnected from
power and signal connections.
All major parts are marked or labeled to show their material content.
Depending on the date of manufacture, this product may contain lead in solder.
Some circuit boards may contain battery-backed memory devices.
nevion.com | 20
Loading...
