Content Page

TINY xlr Cable Connectors ..................................... 4

TINY xlr Chassis Connectors and Adapters .......... 6

1/4'' Vertical Jacks ................................................ 8

1/4'' Phone Jacks .................................................. 10

1/4'' Phone Plugs .................................................. 12

3.5 mm Phone Plugs, Cable Jacks and Adapter ... 14

Phono "RCA" ......................................................... 16

DIN Connectors ..................................................... 18

Patch Box & Stage Boxes ...................................... 20

Dual Banana Plugs ................................................ 22

REAN

With the brand REAN, the world's leading supplier of

professional audio and video connectors – Neutrik AG –

offers another interesting product range.

Excellent cost-performance ratio, attractive design and

reliable functionality are the strengths of REAN.

Based on long-time know-how audio and video

connectors for professional applications are developed

and produced on up to date production facilities. An

efficient logistics system and a global sales network

make a high availability and short delivery times

possible. The REAN product range is an alternative

solution for cost sensitive applications.

REAN a brand of Neutrik AG

TINY xlr TINY xlr

47.5 [1.87“]

10.7 [0.42“]

3 pole 4 pole 5 pole

TINY xlr Cable Connectors

RT4FC-B-WRT3FC-B RT3MC-BRT4FCT-B

3, 4 and 5 pole versions available

Easy to assemble

Robust metal housing with best flex relief

Shielded system – high noise immunity

and EMI protection

Intuitive and rugged locking mechanism

provides secure locking system

Millionfold proven chuck type strain relief – up to

4.0 mm cable diameter

RT3FC-B

RT3FC-B-W

Keyed insert and strain relief to avoid mispositioning /

rotation of insert respectively cable

RT*FC-B-W: optional sealing boot (patent pending)

for water / sweat protection if mated with RT*MP

RT*FCT-B: screw locking design for outstanding rugged-

ness – fits with common rear mountable connectors

BRT-L: Accessory kit for cables from 4.0 – 5.0 mm

RT3FCT-B

44.3 [1.74“]

13.0

[0.52“]

RT3MC-B

47.5 [1.87“]

10.7

[0.42“]

Female Pin-Layouts (front view)

3 pole 4 pole 5 pole

Male Pin-Layouts (front view)

3 pole 4 pole 5 pole

Ordering Information

Type No. Description

Cable connectors

Female Male

RT3FC-B RT3MC-B 3 pole TINY cable connector, black metal shell, gold plated contacts

RT4FC-B RT4MC-B 4 pole TINY cable connector, black metal shell, gold plated contacts

RT5FC-B RT5MC-B 5 pole TINY cable connector, black metal shell, gold plated contacts

RT*FC-B-D RT*MC-B-D TINY cable connector, black metal shell, gold plated contacts; bulk packed, to be ordered in multiples of 100 pcs.

Cable connectors female water resistant

RT3FC-B-W 3 pole TINY female cable connector, black metal shell, water resistant boot, gold plated contacts

RT4FC-B-W 4 pole TINY female cable connector, black metal shell, water resistant boot, gold plated contacts

RT5FC-B-W 5 pole TINY female cable connector, black metal shell, water resistant boot, gold plated contacts

RT*FC-B-W-D TINY female cable connector, black metal shell, water resistant boot, gold plated contacts; bulk packed,

to be ordered in multiples of 100 pcs.

Cable connectors female screw locking

RT3FCT-B 3 pole TINY female cable connector with screw locking, black metal shell & nut, gold plated contacts

RT4FCT-B 4 pole TINY female cable connector with screw locking, black metal shell & nut, gold plated contacts

RT5FCT-B 5 pole TINY female cable connector with screw locking, black metal shell & nut, gold plated contacts

RT*FCT-B-D TINY female cable connector with screw locking, black metal shell & nut, gold plated contacts; bulk packed,

to be ordered in multiples of 100 pcs.

Accessories

BRT-L Bushing and chuck for cable diameters 4.0 – 5.0 mm

Specification

Electrical

Rated current per contact

Contact resistance

Insulation resistance

Dielectric strength

Mechanical

Lifetime

Cable O.D. range 2.0 – 4.0 mm 2.0 – 4.0 mm

Wiring solder contacts solder contacts

Max. wire size

Material

Bushing ABS ABS

Contacts

Contact plating Au plated Au plated

Insert PA 6 30% GR PA 6 30% GR

Shell (housing) ZnAl4Cu1 ZnAl4Cu1

Shell plating black black

Strain relief PVC PVC

Protection boot EPDM –

Locking nut – Al, black anodized

Environment

Operating temperature -30°C to +85°C -30°C to +85°C

Solderability complies with IEC68-2-20 complies with IEC68-2-20

Cable connectors

RT*FC-B*/RT*MC-B*

5 A

10 mΩ

1 GΩ

500 V rms

5'000 mating cycles

0.22 mm² / 24 AWG 0.22 mm² / 24 AWG

female CuSn6

/ male CuZn39Pb3

Screw locking

RT*FCT-B*

5 A

10 mΩ

1 GΩ

500 V rms

5'000 mating cycles

CuSn6

47.5 [1.87“]

10.7 [0.42“]

44.3 [1.74“]

13.0 [0.52“]

47.5 [1.87“]

10.7 [0.42“]

44.3 [1.74“]

13.0 [0.52“]

55.3 [2.18“]

18.8 [0.74“]

TINY xlr TINY xlr

3 pole 4 pole 5 pole

TINY xlr Chassis Connectors TINY xlr Adapters

RT3MP

RT4MPR

Front and rear mountable receptacles in 3, 4 and 5 pole

design

Watertight chassis connector, even in unmated condition

RT*MP provides water resistant connection if mated with

RT*FC-B-W

RT3MP

Panel Cutout

RA3MT-BRA3FT-B

Easy and fast solution to interconnect mini XLRs

Rugged metal housing

Mini XLR 3 pin to XLR-Male or XLR-Female

RA3FT-B

55.3 [2.18“]

18.8

[0.74“]

RA3MT-B

52.3 [2.06“]

Male Pin-Layouts (front view)

3 pole 4 pole 5 pole

18.8

[0.74“]

Ordering Information

Type No. Description

Chassis connectors

RT3MP 3 pole TINY male chassis connector, nickel metal housing, gold plated contacts, max. panel thickness: 6 mm

RT4MP 4 pole TINY male chassis connector, nickel metal housing, gold plated contacts, max. panel thickness: 6 mm

RT5MP 5 pole TINY male chassis connector, nickel metal housing, gold plated contacts, max. panel thickness: 6 mm

RT*MP-D TINY male chassis connector, nickel metal housing, gold plated contacts, max. panel thickness: 6 mm; bulk packed,

to be ordered in multiples of 100 pcs.

Chassis connectors rearmountable

RT3MPR 3 pole TINY rearmountable, male chassis connector, nickel metal housing, gold plated contacts, max. panel thickness: 3 mm

RT4MPR 4 pole TINY rearmountable, male chassis connector, nickel metal housing, gold plated contacts, max. panel thickness: 3 mm

RT5MPR 5 pole TINY rearmountable, male chassis connector, nickel metal housing, gold plated contacts, max. panel thickness: 3 mm

RT*MPR-D TINY rearmountable male chassis connector, nickel metal housing, gold plated contacts, max. panel thickness: 3 mm;

bulk packed, to be ordered in multiples of 100 pcs.

Adapters

RA3FT-B 3 pole adapter TINY male to female XLR, black metall shell, gold plated contacts

RA3MT-B 3 pole adapter TINY male to male XLR, black metall shell, gold plated contacts

Specification

Electrical

Rated current per contact

Contact resistance

Insulation resistance

Dielectric strength

Mechanical

Lifetime

Wiring solder contacts

Max. wire size

Material

Contacts CuZn39Pb3

Contact plating Au plated Au plated

Insert PA 6.6 30% GR PA 6 30% GR

Shell (housing) ZnAl4Cu1 ZnAl4Cu1

Shell plating nickel black

Environment

Operating temperature -30°C to +85°C -20°C to +65°C

Solderability complies with IEC68-2-20 –

Chassis connectors

RT*MP*

5 A –

10 mΩ

1 GΩ

500 V rms 500 V rms

5'000 mating cycles

0.22 mm² / 24 AWG

female CuSn6

Adapters

RA*T-B

≤

5 mΩ

1 GΩ

5'000 mating cycles

–

/ male CuZn39Pb3

1/4" Jacks 1/4" Jacks

RJ3VM RJ5VM

[0.46"]

11.60

Ø13.6

[1.22"]

31.0

[0.138"]

[0.063"]

3.5

[0.945"]

24.0

3/8”-32

1.6

[0.018"]

0.45

[0.157"]

0.4

-0.01

-0.09

[0.54"]

1 / 4 " Vertical Jacks

RJ3VM RJ5VM RJ5VI-D1RJ3VI-D1

Vertical PCB-mount – Fit's widely used PCB layout of existing vertical jacks

Space saving 1/4" jack – enables highest packing density

Circumferential contact arrangement – provides reliable switching function

Integrated body stop for the inserted 1/4" plug – ensures best conductivity independent from mating tip shape

Spring loaded ground contact – maintains superior contact integrity

RJ3VM RJ5VM

[0.157"]

[0.018"]

0.4

0.45

24.0

[0.945"]

[0.063"]

-0.01

-0.09

24.0

[0.945"]

1.6

3/8”-32

31.0

[1.22"]

3.5

[0.138"]

3/8”-32

31.0

[1.22"]

[0.157"]

0.4

-0.01

[0.138"]

3.5

[0.018"]

0.45

[0.063"]

-0.09

1.6

+ 16 hidden pages
