NEUTRIK PCON NK H075 Datasheet

Circular Connectors

117

innovative solutions superior quality

Content Page

powerCON TRUE1 Series ............................................. 120

Ordering Information ................................................ 121

Accessories ................................................................ 121

powerCON Series ...................................................... 124

Ordering Information ................................................ 125

Accessories ................................................................ 125

powerCON 32 Amp Series ......................................... 126

Ordering Information ............................................... 126

Technical Data powerCON ......................................... 127

nanoCON Series ........................................................ 128

Ordering Information ................................................ 129

miniCON Series ......................................................... 130

Ordering Information ................................................ 131

neutriCON Series ....................................................... 132

Ordering Information ................................................. 133

Assembly Tools .......................................................... 134

Technical Data ........................................................... 135

118

NEUTRIK®, opticalCON®, neutriCON®, miniCON®,
nanoCON®, powerCON®, Profi®, speakON®, silentPLUG®,
crystalCON®, etherCON®, rearTWIST®, XIRIUM®, DIWA®
are registered trademarks of Neutrik AG.

innovative solutions I superior quality

Introduction

The Neutrik® circular connector program is a range of metal,
multi-pole connectors specifically designed for industrial
applications. These series provide a variety of male and fema­le cable connectors and receptacles that can be terminated
by soldering and crimping or to printed circuit boards. An
easy to use and reliable quick-lock system ensures a perfect
connection and cannot be released accidentally. The circular
connectors offer Neutrik

®

unique chuck type strain relief and

reinforced housing for robust dependability.

The Neutrik

®

industrial connector range also features a uni­que power connector for single phase applications up to 32
Amps.

Further features are:

- Number of contacts is 1 to 12

- Self-locking system

- Robust all-metal housing

- Front or rear mounting

- Chuck and crimp type strain relief

- Gold plated contacts

- Solder or crimp termination

- Printed circuit board mounting

- Excellent shielding (crimp type strain relief)

The main areas of applications are in the measurement, test
and control, automotive and machine tool industry as well as
medical technique.

www.neutrik.com

119

81.1 [55]

81.1 [3.19“]

Ø

23.6 [.93“]

Ø

28.4 [1.12“]

71-75 [2.80-2.95“]

Ø

26.5 [1.043“]

Ø

25 [0.94“]

38.3

[1.51“]

5.7

[.224“]

4.5

[.177“]

2.5

[.098“]

71-75 [2.80-2.95“]

Ø

26.5 [1.043“]

powerCON powerCON

UL recognized

Ergonomic quick
lock

Bushing with secure
key and sealing

Overmolded ready
made cable

powerCON TRUE1 – Lockable 16 A single phase connector

NAC3FX-W NAC3MX-W NAC3MPXNAC3FPX NAC3PX

• True mains connector with breaking capacity (CBC)

• Lockable 16 / 20 A single phase connector

• Complete system with inlet and outlet connectors

• Unique duplex chassis connector – combines inlet and

outlet coupler

• IP 65 – water resistant ready-made cord sets

• ENEC certified according to IEC 60320

• Easy and reliable locking system

• UL recognized components

Screw terminals 1/4" flat tabs ENEC certified

NAC3MPX

Ø

26 [1.024“]

LIECHTENSTEIN

Ø 3.4

[.134“]

[1.220“]

31.0

38.2

[1.504“]

4.5

[.177“]

[0.929“]

23.6

Ø

2.5

[.098“]

NAC3MX-W

NAC3FPX

120

26.5 [1.043“]

Ø

71-75 [2.80-2.95“]

innovative solutions I superior quality

NAC3PX

[.098“]

2.5

[1.51“]

[.177“]

38.3

4.5

[1.394“]

35.4

Ø

23.6 [.93“]

61.0

28.0

LIECHTENSTEIN

Ø

28.4 [1.12“]

[2.402“]

[1.102“]

[.224“]

5.7

Ordering Information

Cable Connector

NAC3FX-W Mains cable connector, female CBC, screw terminals, IP 65
NAC3MX-W Mains cable connector, male CBC, screw terminals, IP 65

Chassis Connector

NAC3FPX Mains chassis connector female CBC, 1/4" flat tab terminals, power outlet
NAC3FPX-ST Mains chassis connector female CBC, screw terminals, power outlet
NAC3MPX Mains chassis connector male CBC, 1/4" flat tab terminals, power inlet
NAC3PX Mains chassis duplex, 1/4" flat tab terminals

Accessories

SCDP-* SCNAC-PX SCNAC-FPX SCNAC-MPX

SCDP-* D-Size sealing gaskets, colour coding (
SCNAC-PX Sealing cover duplex IP 65
SCNAC-FPX Sealing cover for NAC3FPX
SCNAC-MPX Sealing cover for NAC3MPX

Connector Assignment

APPLIANCE INLET

POWER IN POWER IN

NAC3FX-W or NKPF

APPLIANCE OUTLET

POWER OUT

NAC3MPX

(Connector)

NAC3FPX

APPLIANCE COMBINATION CABLE EXTENTION

*: 0- black, 2- red, 4- yellow, 5- green, 6- blue, 9- white)

INLET OUTLET

NAC3PX

NAC3FX-W or NKPF

(Connector)

POWER OUT

NAC3MX-W or NKPM

(Plug connector)

NAC3MX-W or NKPM

(Plug connector)

NAC3MX-W or NKPM

(Plug connector)

www.neutrik.com

121

NAC3MXW

20

____
250

NAC3MXW

20

____
250

powerCON powerCON

Specification

READY-MADE POWER CORDS

Ready-made overmolded power cord in protection class
IP 65. The cable utilizes standard duty cord with 3 conductors
with cross section 1.5 mm

2

or 12 AWG.
Cables are equipped with Neutrik TRUE1 powerCON
NAC3FXW and NAC3MXW for extention cables or with an

International Cord

International Power Cord 16 A / 250 VAC

International Power Cord 16 A / 250 VAC

open end for termination of local connectors for "power in"
supply cables. Overmolded local connectors on request.
Cables are available in different lengths.

Current rating 16 A

Voltage rating 250 VAC

Cable type / color / Nom. O.D. H07RN-F3G1.5 / black / 9.6 mm

Conductor size 3 x 1.5 mm

Standard length

2 m, 3 m, 5 m

Plug / end termination Neutrik NAC3FXW / stripped open end

Approvals ENEC, VDE

Part Number e.g. NKPF-NC-A-3

Current rating 16 A

Voltage rating 250 VAC

Cable type / color / Nom. O.D. H07RN-F3G1.5 / black / 9.6 mm

Conductor size 3 x 1.5 mm

Standard length

2 m, 3 m, 5 m

Plug / end termination Neutrik NAC3FXW / SCHUKO RA

Approvals ENEC, VDE

Part Number e.g. NKPF-SR-A-3

2

2

International Extension Cord 16 A / 250 VAC

Current rating 16 A

20

____

NAC3MXW

250

Voltage rating 250 VAC

Cable type / color / Nom. O.D. H07RN-F3G1.5 / black / 9.6 mm

Conductor size 3 x 1.5 mm

Standard length

0.5 m, 1 m, 1.5 m

2

Plug / end termination Neutrik NAC3FXW / Neutrik NAC3MXW

Approvals ENEC, VDE

Part Number e.g. NKPF-M-A-0.5

122

innovative solutions I superior quality

NAC3MXW

20

____
250

NAC3MXW

20

____
250

NAC3MXW

20

____
250

NAC3MXW

20

____
250

Cable Part Number Breakdown

NKPF - X - Y - 3

Neutrik Power Cord

F ............ NAC3FXW

M ........... NAC3MXW

TERMINATION 2. END

M ........... NAC3MXW

NC .......... Stripped open end

S ............ Schuko Straight

SR .......... Schuko Right Angle

N1 .......... Nema 5-20

US Cord

US Power Cord 20 A / 250 VAC

US Power Cord 20 A / 250 VAC

LENGTH in m

CABLE TYPE

A ........... H07RN-F3G1.5

B ............ H05VV-F3G1.5

C ............ SJTOW 12AWG

D ............ SJOOW 12AWG

Current rating 20 A

Voltage rating 250 VAC

Cable type / color / Nom. O.D. SJTOW / black / 11.3 mm

Conductor size 3 x 12 AWG

Standard length

2 m, 3 m, 5 m

Plug / end termination Neutrik NAC3FXW / stripped open end

Approvals UL, cUL

Part Number e.g. NKPF-NC-C-5

US Extension Cord 20 A / 250 VAC

Current rating 20 A

Voltage rating 250 VAC

Cable type / color / Nom. O.D. SJTOW / black / 11.3 mm

Conductor size 3 x 12 AWG

Standard length

2 m, 3 m, 5 m

Plug / end termination Neutrik NAC3FXW / NEMA 5/15

Approvals UL, cUL

Part Number e.g. NKPF-N1-C-3

Current rating 20 A

20

____

NAC3MXW

250

Voltage rating 250 VAC

Cable type / color / Nom. O.D. SJTOW / black / 11.3 mm

Conductor size 3 x 12 AWG

Standard length

0.5 m, 1 m, 1.5 m

Plug / end termination Neutrik NAC3FXW / Neutrik NAC3MXW

Approvals UL, cUL

Part Number e.g. NKPF-M-C-1

www.neutrik.com

123

powerCON powerCON

Quick lock Neutrik hologram 3/16" flat tabs Locking area on

chassis connector

powerCON – Locking 3 Pole Power Connectors

NAC3FCA NAC3MPA-1 NAC3FCB NAC3MPB-1

• Lockable 3 pole equipment (AC) connector with contacts for

line, neutral and premating safety ground

• High current capacity, rated at 20 A / 250 V ac

• Colour coded for easy identification, powerCON offers power-in

(blue) and power-out (grey) versions with different keying to

avoid the possibility of intermating

• Fast and easy locking system

• Extremely robust and reliable

• Excellent cable retention

• UL, cUL recognized components (file no. E 135070)

VDE certified (Reg. No. 6360),

SEV approved (No. 96.1 10096)

• New latch design for easier handling and secure locking

• Branded with unique hologram – guarantees genuine and

authentic Neutrik product

• Coupler for linking cables (couples NAC3FCA to NAC3FCB)

NAC3FCA(B)

NAC3MPA(B)-1

NAC3MM-1

NAC3MM-1

124

innovative solutions I superior quality

Ordering Information

NAC3FCA Cable connector, quick lock with securing lever, A-type for power inlet, screw terminals
NAC3MPA-1 Air tight chassis connector, A-type for power inlet, flat tab terminals, blue
NAC3MPA-1-

WOT

Chassis connector, power-out, 3/16'' flat tab terminals, blue, without insulation divider
NAC3FCB Cable connector, quick lock with securing lever, B-type for power outlet, screw terminals
NAC3MPB-1 Air tight chassis connector, B-type for power outlet, flat tab terminals, grey
NAC3MPB-1-

WOT

Chassis connector, power-out, 3/16'' flat tab terminals, grey, without insulation divider

NAC3MM-1 Coupler for linking cables (couples NAC3FCA to NAC3FCB)

Accessories

NDL NLFASTON SCL SCDR Example: NAC3MPA-1 + SCDR SCDX SCDP-*

NDL dummyPLUG for powerCON 20 A chassis connector
NLFASTON FASTON® receptacle for tabs with "positive lock" for use with NL4MP, NL4MPR, NL8MPR, Pack of 100 pcs.
SCL Plastic sealing cover to protect the connectors against dust and moisture
SCDR Rear end protection cover for D-size chassis connectors
SCDP-* D-Size sealing gaskets, colour coding (*: 0- black, 2- red, 4- yellow, 5- green, 6- blue, 9- white)
SCDX Hinged cover seals D-size chassis connectors, IP 42 rated

KEYWAYS:

With the two non-interchangeable types of connectors (A type and B type) it is impossible to produce a short circuit. Mating
connectors (combination) are identified by mechanical keyways and by color.

NAC3FCA

NAC3MPA-1

NAC3FCB

NAC3MPB-1

ATTENTION

The technical data of the powerCON connectors refer to connectors without breaking capacity, meaning connecting devices not to
be engaged and disengaged in normal use when live or under load.

www.neutrik.com

125

powerCON Technical Data powerCON

Robust metal
housing

Screw-type terminals

powerCON 32 A Connectors

NAC3FC-HC NAC3MP-HC

• Locking single phase AC appliance coupler

• High current capacity (32 A rated)

• Fast and easy locking system

• Excellent cable handling and protection

• Extremely robust and reliable

• 250 V ac, 32 A single-phase (for ambient temperatures

up to 35 °C)

• Premating contact for protective earth

• Locking system to prevent unintentional disengagement

• Cable O.D. range: 8 – 20 mm

• Wiring with screw-type terminals for wires 2.5 to 6.0 mm

(AWG 14 – 10)

NAC3FC-HC

NAC3MP-HC

2

Ordering Information

NAC3FC-HC Cable connector, quick lock with securing lever, screw terminals
NAC3MP-HC Fast and easy locking system, screw-type terminals

126

innovative solutions I superior quality

Specification powerCON powerCON 32 A powerCON

TRUE1 Series Series

Electrical

Number of contacts: 2 + PE 





Rated current per contact: 20 A rms 1) 20 A rms 32 A rms
Rated voltage: 250 V ac



Dielectric strength: 4 kV dc 

≤

Contact resistance:

Insulation resistance after
damp heat test (IEC 68-2-30):

Mechanical

Retention method: Quick lock

3 mΩ



>

0.1 GΩ

























Cable O.D. range: 6 – 12 mm 6 – 15 mm 8 – 20 mm
Wiring: Cable: screw type terminals



2.5 mm2 / 12 AWG 2.5 mm2 / 14 AWG

or soldering



Chassis: flat tabs for Faston (4.8 x 0.5 mm) -

(6.35 mm x 0.8 mm)

or soldering

Solderability complies with IEC 68-2-20:

Material

Housing cable connector:

 - -





PA 6 30% GR PA 6 30% GR PA 6 30% GR





2.5 – 6 mm2 / 14-10 AWG

















-

Housing receptacle: PA 6.6 30% GR PA 6.6 30% GR PA 6.6 25% GR
Insert: PA 6.6 30% GR PA 6 30% GR PA 6.6 25% GR
Contacts: Female: CuSn0.2 CuZn39Pb3 CuZn39Pb3

Male: CuNi1Si0.2 CuNi1Si0.2 CuSn0.2
Contact surface: 2 µm Ag plated 4 µm / 2 µm Ag plated 4 µm Ag
Chuck POM:









Environmental

Flammability: UL 94 HB

-





plug housing

UL 94 V-0  * *
Temperature range: -30 °C to +80 °C 





Protection class (mated): IP 65 IP 20 IP 2X unmated
Safety Requirements EN / IEC61984:

-





IEC 60320:  - -

1)

: Appliance coupler acc. IEC 60320 limited to 16 A ac

* : Receptacle

FASTON® is a trademark of AMP Inc.

www.neutrik.com

127

nanoCON nanoCON

Connector locking PCB receptacle Panel mount receptacle

nanoCON – 3 Pole Subminiature Connectors

NP3F-H NP3M-VNSC3F NR3M-S NR3F-S

• World's smallest circular lockable multipole connector

• Robust metal housing with gold plated contacts

• Male and female receptacles for vertical or horizontal PCB

mount or solder termination

• Cable connector and receptacle with interchangeable male

and female inserts

• Reliable and versatile in applications like medical equipment,

control systems, sensors or audio applications such as

miniature and wireless microphones and portable mixers

• Pre-mating contact 1

M 1:1

NSC3F(M)

NR3F(M)-S

NP3F(M)-H

128

innovative solutions I superior quality

Ordering Information

Female Male

NSC3F Cable connector, chuck principle, solder contacts NSC3M Cable connector, chuck principle, solder contacts
NR3F-S Chassis connector panel mount, solder contacts NR3M-S Chassis connector panel mount, solder contacts
NP3F-H Chassis connector horizontal PCB mount NP3M-H Chassis connector horizontal PCB mount
NP3F-V Chassis connector vertical PCB mount NP3M-V Chassis connector vertical PCB mount

Ordering Information for modular nanoCON system

NSC3F

NSC3M

NP3F-H

NP3M-H

NP3F-V

NP3M-V

NR3F-S

NR3M-S

Contact Arrangement

Male Female

23

G

G

23

www.neutrik.com

129

miniCON miniCON

Push Pull locking Gold solder contacts Horizontal PCB mount

miniCON – 12 Pole Miniature Connectors

MSCM12 MRF12 MRF12-HMMC* (modular system)

• Up to 12 pole miniature connector

• Complete set or modular system

• Push-pull self-locking system

• Precisely machined, rugged all metal design

• Fully loaded male and female receptacles for horizontal or

vertical PCB mount

• Gold plated contacts, crimp or solder, velour chromium

housing

• Special crimp type strain relief establishes an ideal coaxial

connection of the cable shield to the connector shell for best

EMC shielding

• Easy assembly: contact soldering in disassembled condition

avoids awkward wiring of wight density contacts

• Interchangeable insert (male-female)

MSCF(M)12 (+MSRC)

MPF(M)12-V

MRF(M)12

MPF(M)12-H

130

innovative solutions I superior quality

Ordering Information for complete miniCON set

Complete set (consisting of housing, insert, 12 contacts and chuck for cable connector)

Female Male

MSCF12 Cable connector, chuck principle, solder contacts MSCM12 Cable connector, chuck principle, solder contacts
MRF12 Receptacle panel mount, solder contacts MRM12 Receptacle panel mount, solder contacts
MPF12-H Receptacle horizontal PCB mount MPM12-H Receptacle horizontal PCB mount
MPF12-V Receptacle vertical PCB mount MPM12-V Receptacle vertical PCB mount

MPF(M)12-V MPF(M)12-HMSCF(M)12

Ordering Information for modular miniCON system

MPC

MPS

MBC

MBS

MBC

MBS

MMI

MFI

MPC

MPS

MRMMRF MSRC

Reduction
ferrule 1

Reduction
ferrule 2

MSC

MMC

Housing and insert pre-assembled, contacts must be ordered separately.

Modular system

Female Male

MFI Insert for cable connector MMI Insert for cable connector
MBC Crimp contacts for cable connector and receptacle MPC Crimp contacts for cable connector and receptacle
MBS Solder contacts for cable connector and receptacle MPS Solder contacts for cable connector and receptacle
MRF Receptacle housing and insert pre-assembled MRM Receptacle housing and insert pre-assembled
MMC Cable connector extension, incl. chuck (for male and female)
MSC Cable connector housing, incl. chuck (for male and female)
MSRC Set of strain relief crimp version (consisting of crimp ferrule & reduction ferrule 1 + 2, tools see page 130)

www.neutrik.com

131

neutriCON neutriCON

Push Pull locking All metal housing Colored bushing

available

neutriCON – Versatile Circular Connectors

• Complete set or modular system for any desirable configuration

• Contact configuration can be selected from 1 to 8 contacts

• Special crimp type strain relief establishes an ideal circum-

ferential connection of the cable shield to the connector shell

as required by best EMC working practice

• Precise and robust all metal housing absorbs vibration forces

and protects contact inserts

• Easy, fast and screwless assembly

• Push-pull self-locking system

ORP8F-NiOSC8F MC8M-Ni ORP8M

OSC8F / OSC8M

MODULAR SYSTEM

Polarization

Housing: Two variants of metal polarizing guides (90° and 180°).

Coding 90°

Coding 180°

Insert: The male and female insert can be assembled in all three

housings.

132

innovative solutions I superior quality

MC8 + SR8A/B + insert

ORP8F / ORP8M

Ordering Information for complete neutriCON set

Complete set (consisting of housing, insert, 8 contacts and chuck for cable connector)

OSC8F Female cable connector, chuck principle, black housing, solder contacts
OSC8F-Ni Female cable connector, chuck principle, nickel housing, solder contacts
OSC8M Male cable connector, chuck principle, black housing, solder contacts
OSC8M-Ni Male cable connector, chuck principle, nickel housing, solder contacts
ORP8F Female panel mount receptacle, black housing, solder contacts
ORP8F-Ni Female panel mount receptacle, nickel housing, solder contacts
ORP8M Male panel mount receptacle, black housing, solder contacts
ORP8M-Ni Male panel mount receptacle, nickel housing, solder contacts

Ordering Information for modular neutriCON system

Cable Connector:

Receptacle:

Modular system

Female Male

FI8 Insert for cable connector and receptacle MI8 Insert for cable connector and receptacle
BS1 Solder contact PS1 Solder contact
BC1 Crimp contact PC1 Crimp contact
BP1 PCB contact PP1 PCB contact
SC8 Cable housing, black coated, 180° coding MC8 Mating cable housing, black coated, 180° coding
SC8-Ni Cable housing, nickel coated, 180° coding MC8-Ni Mating cable housing, nickel coated, 180° coding
SC81 Cable housing, black coated, 90° coding MC81 Mating cable housing, black coated, 90° coding
SC81-Ni Cable housing, nickel coated, 90° coding MC81-Ni Mating cable housing, nickel coated, 90° coding
SC8W Cable housing, black coated, 180° coding, waterproof multipin connector according IP54
RP8 Receptacle, black coated, 180° coding
RP8-Ni Receptacle, nickel coated, 180° coding
RP81 Receptacle, black coated, 90° coding
RP81-Ni Receptacle, nickel coated, 90° coding
SR8 Bushing and chuck type strain relief (standard)
SR8A Crimp type strain relief for cable O.D. 3 – 3.8 mm (Hex crimp 5.41 mm acc. IEC 803, see also page 130)
SR8B Crimp type strain relief for cable O.D. 6 – 7 mm (Hex crimp 7.01 mm acc. IEC 803, see also page 130)
SR8W Bushing and chuck type strain relief for waterproof solution IP 54
BSP-* Coloured boot, available in 10 resistor colours

* color coding: 0 - Black, 1- Brown, 2 - Red, 3 - Orange, 4 - Yellow, 5 - Green, 6 - Blue, 7 - Violet, 8 - Grey, 9 - White

www.neutrik.com

133

Assembly Tools Technical Data

Crimptool

Crimptool HX-CONTACT

DMC crimptool AFM8
acc. M22520/2-01

MPOS-*

MPOS-*

Modified DMC positioner (K155) Contact
positioner helds contact in position when
crimping.

Contact and connector assembly

®

Crimptool HX-R-BNC DIE-R-BNC-*Neutrik

neutriCON - Ordering Information Assembly Tools

Cable O.D. / Wire Crimptool Die/Positioner HEX-Size/Standard

SR8A Strain relief 3 – 3.8 mm HX-R-BNC DIE-R-BNC-PJ 5.41 mm / IEC 803
SR8B Strain relief 6 – 7 mm HX-R-BNC DIE-R-BNC-PS 7.01 mm / IEC 803
BC1 Female crimp contact AWG 22 – 26 HX-CONTACT MPOS-BC1 No. 5 / M22520/2-01
PC1 Male crimp contact AWG 22 – 26 HX-CONTACT MPOS-PC1 No. 5 / M22520/2-01

HEX crimptool Neutrik® DIE's for various HEX sizes.

miniCON - Ordering Information Assembly Tools

Cable O.D. / Wire Crimptool Die/Positioner HEX-Size/Standard

MSRC Crimp ferrule only 4.5 – 6 mm HX-R-BNC DIE-R-BNC-PDC* 6.47 mm / IEC 803
MSRC Crimp ferrule & reduction ferrule 1 3.3 – 4.4 mm HX-R-BNC DIE-R-BNC-PDC* 6.47 mm / IEC 803
MSRC Crimp ferrule & reduction ferrule 2 2.5 – 3.2 mm HX-R-BNC DIE-R-BNC-PDC* 6.47 mm / IEC 803
MBC Female crimp contact 24 AWG / 0.22 mm2 HX-CONTACT MPOS-MBC No. 5 / M22520/2-01
MPC Male crimp contact 24 AWG / 0.22 mm2 HX-CONTACT MPOS-MPC No. 5 / M22520/2-01

*: DIE-R-BNC-PJ or PS also possible

134

innovative solutions I superior quality

Specification nanoCON miniCON neutriCON

Series Series Series

Electrical

Number of contacts: 3 12

(1-12 modular system)

8

(1-8 modular system)
Rated current per contact: 2 A 3 A 7.5 A (solder), 5 A (crimp)
Rated voltage: 50 V ac 50 V ac 50 V ac
Dielectric strength: 1000 V dc 1000 V dc 1500 Vdc
Contact resistance:

Insulation resistance after
damp heat test (IEC 68-2-30):

Mechanical



≤

12 mΩ

>

1 GΩ

≤

8 mΩ

>

500 MΩ

≤

5 mΩ

>

500 MΩ

Retention method: latch Push-pull Push-pull
Cable O.D. range: 3.4 mm max. 3 – 5 mm (grey chuck) 3 – 7 mm
5 – 7 mm (white chuck) 3 – 3.8 mm (SR8A)

2.5 – 6 mm 6 – 7 mm (SR8B)

(crimp version MSRC)

Wiring:

0.14 mm

for stranded wire for crimp for crimp

Solderability complies with IEC 68-2-20: 

Material

0.2 mm2 / 24
for solid wire

26

AWG





AWG

0.5 mm2 / 20

2

0.22 mm2 0.14 - 0.34 mm

for solder

24

AWG





AWG

1.0 mm2 / 18
for solder

22 - 26



AWG

AWG

2

Housing cable connector:

CuSn4Pb4Zn4 ZnAl4Cu1 / CuZn39Pb3 ZnAl4Cu1

gal Ni or black chrome
Housing receptacle: CuZn39Pb2 ZnAl4Cu1 ZnAl4Cu1,

gal Ni or black chrome

Insert: PETP PA 6.6 PBTP 15% GR
Contacts: CuZn35Pb2 CuZn35Pb2 (solder) CuZn35Pb2 (solder)

CuZn39Pb3 (crimp) CuZn39Pb3 (crimp)

CuSn6
Contact surface: 0.5 µm Au 0.2 µm AuCo 0.3 µm Au hard

alloy over 2 µm Ni

Chuck POM:

Environmental



Flammability: UL 94 HB - ­Flammability: UL 94 V-0
Temperature range: -30 °C to +80 °C















-









Protection class (mated): IP 40* IP 5X IP 5X
Safety Requirements EN/IC61984:

*: Recep tacle

®

is a trademark of AMP Inc.

FASTON

- - -

www.neutrik.com

135

136

innovative solutions I superior quality
