Neutrik NA2-IO-DLINE User Manual

INNOVATIVE
SOLUTIONS

™

NA2-IO-DLINE

Interface

Line I/O Dante

INNOVATIVE
SOLUTIONS

2

Neutrik Headquarters in Schaan, Principality of Liechtenstein

3

NA2-IO-DLINE

Line I/O to Dante™ Interface

Connect your legacy audio gear to the Dante™ world

Connect analog audio equipment to a DanteTM network
Heavy duty adapter for rugged stage conditions
Lockable audio and network connections
Convert up to two analog line signals to a DanteTM network
Feed non DanteTM ready amplifiers, speakers or mixing desks with signals from the
DanteTM network
Mixed mode
Requires a Power over Ethernet switch or a PoE injector (802.3 af/at; class 1)
AES67 compliant

Rack mountable

What is it?

The NA2-IO-DLINE is an end-of-network
device. It is a breakout box which allows two
channels of audio to be integrated into a
Dante™ network. Simultaneously, NA2-IO-DLINE
converts a Dante™ stream into analog audio
signals. Hence, it is possible to use this tiny box
to feed analog audio signals into the Dante™
network while at the same time receiving a mix
from another Dante™ source.

NA2-IO-DLINE is designed for harsh stage
conditions. It therefore features lockable chassis
connectors for both the audio and network
connections. For fixed installations, the rubber
protection can be removed. With optional
mounting brackets or a rack panel, the box can
be mounted below tables, in floor boxes, or in
equipment racks.

NA2-IO-DLINE
