Preface
Information in this document has been carefully checked for accuracy; however, no
guarantee is given as to the correctness of the co ntents. The information in this do cument is subject to change without notice. Thi s docume nt contains proprietary information protected by copyright. No part of this manual may be reproduced by any
mechanical, electronic or other means, in any form, without prior written permission
of the manufacturer.
All trademarks are the property of their respective owners.
Copyright© 2005. All Rights Reserved.
Safety Information
Please read the following safety instructions, and keep the user manual for later
reference.
• Use only the power adapter supplied with the product.
• Do not place the product near any source of heat o r expose it to direct sunlight.
• Do not attempt to connect any computer accessory or electronic product without instruction from qualified service personnel. It may result in risk of electric
shock.
• Do not expose the product to moisture. Never spill any liquids on the product.
• Do not place the product in regions with extreme temperatures.
Routine care
Wipe the product with a sof t cloth. Do not use abra sive powders or solvents, such as
benzene or thinner. When you leave the product unu sed for a long time, unplug the
AC adapter from the outlet.
● For the most up-to-date copy of the guide in English or a copy in German, French, Italian
or Spanish please visit:
http://www.neurostechnology.com/support
● Pour un exemplaire du guide d’utilisation en francais, consultez la page :
http://www.neurostechnology.com/support
● Per ottenere una copia del manuale utente in italiano, visitare:
http://www.neurostechnology.com/support
● Para obtener una copia de la guia del usuario en "Espanol" visite:
http://www.neurostechnology.com/support
● Ein Exemplar der deutschen Bedienungsanleitung finden Sie auf folgender Website:
http://www.neurostechnology.com/support
ii
Table of Contents
1 Overview
Features ................................................................................................ 1
Package contents .................................................................................. 2
About the Neuros MPEG-4 Recorder 2 ................................................. 3
Front view ..................................................................................... 3
Rear view ........................... ... ... .. ................................ .. ... ... .......... 3
About the remote control ....................................................................... 4
2 Getting started
Installing the remote control battery ...................................................... 7
Connecting power ................................................................................. 8
Turning on the Recorder 2 .................................................................... 8
Inserting the Compact Flash (CF) or 1"Micro Drive Card ...................... 9
Inserting the MS Duo/Pro Duo, MMC or SD Series Card..................... 10
Connecting to a TV (viewing only)........................................................ 11
Connecting to a TV, DVD player, VCR or camcorder (recording) ....... 12
Confirming / Selecting the correct TV output........................................ 13
3 Using the Neuros MPEG-4 Recorder 2
Viewing pictures .................................................................................. 15
Displaying images ............................................................ .......... 15
Photo Settings me nu ................ .. ................ ... .. ........................... 16
Slideshow ............................................................................. 16
Background music ................................................................ 17
Delete Files . .................. ................................... ..................... 17
Listening to music ................................................................................ 18
Playing audio .............................................................................. 18
Setting menu for Mu sic ................................................ ... ... .. ...... 19
Repeat .................................................................................. 19
Delete Files ................ .......................... .......................... ...... 19
Watching videos ................... .. .................................................. ........... 21
Playing videos ................................. .. .................................... ..... 21
Setting menu for Video ............................................................... 22
Repeat .................................................................................. 22
Delete Files . .................. ................................... ..................... 22
Recording video .................................................................... 24
Record menu ................................................................... ........... 24
Resolution .................................................................................. 24
Quality ........................................................................................ 24
iii
Quick setup .................................................................................24
Timer record ................ .. ... .. ................................................ .. ... ... 25
Programs .............................................................................. 25
Start and Stop Times ............................................................ 25
Frequency ...... .......... ........... .......... ........... .......... ........ ........... 26
Auto record .. ... .. .......................................................................... 26
Storage ....................................................................................... 26
Selecting the right recording resolution setting ................................... 27
Simple Record ...................................................................... 28
Setup menu .................................................................... .. ... .. .............. 29
Date and Time ...................................................................... 29
Language .............................................................................. 29
Format Disk .......................................................................... 30
TV Output ............................................................................. 30
Factory Reset ....................................... ................................ 30
File browsing ........................ .................................. ............................. 31
Data management settings menu .............................................. 31
Copy ..................................................................................... 32
Delete ................................................................................... 32
Playing back recorded files ................................................................. 33
Playing back files recorded with the Recorder 2 ................... ..... 33
I. Sony PSP .......... .. ............................................................. 33
II. Neuros 442 Protable Media player / Recorder .......... ....... 34
III. i-Pod Video ................. ... .. ................................ .. ... ... ........ 35
IV. Nintendo Game Boy M icr o .............................................. 42
V. Other Handhelds .............................................................. 43
4 Firmware Upgrade In st ruct io ns
Firmware Upgrade Instructions ........................................................... 45
5 Contact US
Contact Us............................................... ............................................. 47
6 Appendix
FCC Certification .................................................... ............................. 49
CE Notice (European Union) ............................................................... 50
Troubleshootin g ......... ............. ............. ............. ........... ............. ........... 51
Specifications ...................................................................................... 52
iv
1. Overview
Congratulations on purchasing the Neuros MPEG-4 Recorder 2.
Now you can enjoy quality multimedia anywhere you go and
record your favorite video programs from a variety of video
sources. The Recorder 2 also plays back your favorite audio
tracks, and displays photos and video on your TV.
Refer to this user manual for detailed descriptions about the product and instructions for using it.
Features
The Neuros MPEG-4 Recorder 2 allows you to:
• record video from a TV, DVD, VCR or camcorder
• display images (jpg, gif, and bmp formats)
• play audio files (mp3 and wma formats)
• play videos (ASF, AVI, MP4 formats)
Package contents
Package contents
Recorder 2
Power Adapter
Remote Control
NTSC
A
B
PAL
STORAGE
DISPLAY
RCA Video cables (x2) User Manual
User Manual
2
About the Neuros MPEG-4 Recorder 2
Refer to the following sections for information about the hardware
components of the Recorder 2.
Front view
Recording LED (
R
ed)
CF
About the Neuros MPEG-4 Recorder 2
Power LED
Rear view
IR
(Green )
DC Power AV Out AV In
Receiver
DC 5V
CF Card Slot
AV OUT
Memory Stick Pro
SD, MMC, Slot
AV IN
3
About the remote control
Icon Description
1. Turns on the power
Switches between NTSC and
2.
PAL system
3. Increases the volume
Enters the setting menu
About the remote control
(Note:settings menu options
4.
vary depending on when
selected)
5. Decreases the volume
1
2
3
4
5
6
7
8
9
10
11
12
STORAGE
NTSC
PAL
DISPLAY
A
B
6. Scrolls left
7. Mutes all sound
8. Zooms out
9. Start and stop recording
Rewinds playback of video
10.
and audio files
Switches between CF and
11.
Memory Stick/SD/MMC.
Turn on and off the on screen
12.
display
4
STORAGE
NTSC
PAL
DISPLAY
About the remote control
Icon Description
A
B
13
13. Returns to the top menu
14
15
16
14.
17
18
15. Returns to the previous menu
19
20
21
16. Scrolls up
22
23
24
17. Scrolls right
Repeats playback of selected
audio/video file.
18.
Confirms selection of menu
item
19. Zooms in
20. Scrolls down
Fast Forwards playback of
21.
video and audio files
Plays or pauses playback of
22.
photo, video and audio
Plays the next photo, video and
23.
audio files
Plays the previous photo, video
24.
and audio files
5
Sticker for Recording Setting
Before recording for target player (TV, PDA or PSP...), user can
refer to the sticker (as picture shows below) for the setting including resolution and quality.
Please refer to page 21 to setup the recording format.
Suggested Recording Resolutions
Economic
Normal Fine Super fine Legend
640X480
320X240
30fps
368X208
320X240
15fps
176X120
320X240
3GP
176X144
3GP
Please see www.neurostechnology.com / supporteddevices.asp and the manual of your playback device for details.
---
---
TV
PSP
iPod
PDA
S/Phone
Mobile
2. Getting started
This chapter describes the preliminary steps required to set up the
Recorder 2 and how to make connections before starting to use
the device.
Installing the remote control battery
Follow these instructions to insert the remote control battery:
1. Push in the clip at the side of the batte ry
holder.
2. Pull battery holder out.
3. Insert the battery as shown, while noting
the correct polarity.
4. Push battery holder and snap it in place.
Connecting power
Connect the power adaptor to the DCin socket on the rear panel of the
Recorder 2. Plug the other end of the
adaptor into a power outlet.
Connecting power
Turning on the Recorder 2
Once the Recorder 2 is plugged in, the green power LED turns on.
Press the button on the remote and the system turns on. Press
the button again to turn off the Recorder 2.
Note: the green light will remain on even if the Recorder 2 is
turned off, as long as the unit is connected to a power outlet.
8
Inserting the Compact Flash (CF) or 1"Micro
Drive Card
Push the CF card or Hitachi 1" Micro
Drive into the CF card slot until it is firmly
in place.
To remove the card, grip the CF card and
gently pull.
Inserting the Compact Flash (CF) or 1"Micro Drive Card
Note1:
The Hitachi 1"Micro Drive should be formatted using th e
Recorder 2 before using (See Page 22). This is to ensure that
the 1" Micro Drive has been formatted in the F AT16 format and
can therefore be recognized by the Recorder 2.
Note2:
File size is limited to 2 GB for the Hitachi 1" Micro Drive. This
is an inherent limitation of the FAT16 format. If you attempt to
record a file larger than 2 GB, the Recorder 2 will begin a second file once the 2 GB limit is reached. A small amount of data
may be lost while the Recorder 2 is transitioning to the second
file.
9
Inserting the MS Duo/Pro Duo, MMC or SD
Series Card
Insert the card into the card slot with the
metal contacts going in first and facing
up, until the card is firmly in place. The
beveled corner of the card must be away
from you and to the right as the card is
inserted.
To remove the ca rd, grip the card and
pull gently.
See diagram below for proper adapters:
Inserting the MS Duo/Pro Duo, MMC or SD Series Card
CF
LOCK
Adapter
MMC
512
MB
mobile
1.0
GB
RS-MMC
Lock
microSD/TransFlash
to SD Adapter
MS DUO
INSERT
Memory Stick Duo Adaptor
2.0
GB
10
1.0
PUSHPUSH
MB
128
GB
Connecting to a TV (viewing only)
Connect the A/V connectors (red, white, and
I
yellow) of the A/V cable, to the corresponding input sockets on the TV. Connect the
other end to the A V Out socket at the back of
the Recorder 2.Y ou will also need to set your
TV to the appropriate video channe l to see
the user interface and set up your recording
preferences (use the TV/video button on your remote--Just like
you would for a VCR).
The appropriate channel dedicated to the inputs you are plugged
N
Connecting to a TV (viewi ng only)
into varies. Please refer to your television's manual for details (or
try switching between channels)
Note: If the TV has only 1 video and 1 audio socket, insert the yellow connector in the video socket and the white connector in the
audio socket, leaving the red connector unused.
11
Connecting to a TV, DVD player, VCR or camcorder (recording)
Connect the A/V connectors (red, white, and yellow) of the A/V
cable to the corresponding output connectors on the cable box,
satellite receiver, VCR, DVD player, camcorder etc. Connect the
other end to the AV In socket at the back of the Recorder 2. Connect the second A/V cable to the A V Out socket of the R eco rder 2
and the corresponding input sockets on the TV as described in the
previous section.
I
N
ANTENNA IN
I
N
S-VIDEO
O
U
T
CHANNEL
34
Note: Most TVs do not have video output (only audio output). In
Connecting to a TV, DVD player, VCR or camcord e r (record ing )
this case, you won't be able to record directly from the TV.
Instead, record TV shows from the cable box, satellite receiver
box, or PVR (like T ivo). If you don't have cab le or satellite TV, you
can record from broadcast TV by plugging the video out from a
VCR into the A/V In on the Recorder 2, then plugging the A/V Out
from the Recorder 2 into the Video In on the TV.
12
Confirming/Selecting the correct TV output
Note: Different regions of the world use different TV output formats. For example, the U.S. uses NTSC and much of Europe
uses PAL. Depending on your region, you may need to change
the TV output from NTSC to PAL. If you have a color TV and only
black and white is visible when the Recorder 2 menu is visible (the
picture may also appear somewhat unstable), you may need to
change the TV output as detailed below. If colors are visible on
the menu screen, the TV output is already correct, and you can
skip this step. Changing the TV output is done by accessing the
Setup menu (see below) and changing the TV Output mode. If
Confirming/Selecting the cor rect TV output
you don't know what setting is used in your local region, you may
want to consult the user's guide for your TV set, but, if you have
any doubt, it will probably be easier to just follow the simple steps
below and use the format that makes the screen color and image
appear normal.
Note: Many TV sets in France use a different TV Output format
called Secam. This format is not currently supported by the
Recorder 2.
To determine the current TV Output setting and to change it (if
necessary):
Date M/D/Y
Time H:M:S
Language
Format Disk
TV Output
Upgrade Devic~
SETUP
07 / 21 / 2001
20 : 57 : 35
Dutch
CF
PAL
Upgrade
13
1. Highlight the Setup menu from the main menu screen using the
buttons.
2. Press to access the Setup menu options.
3. You should see TV Output as one of the options along the left
side. The currently selected format (NTSC or PAL) will be displayed across from it on the right. If this is the desired format, you
are finished with this step. Simply exit the menu by pressing the
button. If you want to change the format, scroll down to the TV
Output line using the buttons. Use the button to highlight
TV Output, then use the buttons to change the format.
Once the desired format is displayed, exit the menu by pressing
the button as above.
Confirming/Selecting the correct TV output
14
3. Using the Neuros MPEG-4
Recorder 2
Now that you have set up the Recorder 2, you are ready to start
using it to view your favorite images, listen to audio tracks, watch
videos, and record videos. This chapter provides detailed instructions for these tasks and for navigating through the OSD (On
Screen Display) menu.
Viewing pictures
<DCIM>
<MP_R001>
<MUSIC>
<PHOTO>
John_peel_~
_40896894_~
The Recorder 2 is able to display.JPG, .GIF and .BMP image file
formats.
Displaying images
To display still images:
1. Highlight the Photo menu icon using the buttons.
2. Press to access the fi le list.
3. Use the buttons to highlight the required file and press
the button to play the file.
Photo Settings menu
Slide Show
usic
Delete Files
MUSIC
Folder
On
Selected
Viewing pictur es
To access the Settings menu related to viewing photos, press the
while in the main Photo menu. The following three functions
will appear:
SLIDESHOW
To set up a photo slide show, follow the proce d ure below:
1. Use the buttons to scroll to and highlight the Slideshow option.
2. Use the buttons to Select ALL photos or only the photos in the FOLDER for the slideshow or to turn the slideshow
OFF.
3. Use the button to return to the menu.
4. Using the buttons, select a photo for the slide show by
pressing the button on the remote control. The screen
icon will change from to .
5. Press to play the slide show.
Note: If All is selected for the slide show then all pictures will
appear in the show. If Folder is selected then only those
16
images in the current folder are displayed. When turned
Off, only the current image is displayed.
6. While playing you can use and to zoom out and in on
the picture.
7. Pressing will show the following: File information, Background Volume, Current Date and Time, and the zoom
amount.
ACKGROUND MUSIC
B
1. Use the buttons to highlight the Music function.
2. Use the buttons to turn ON or OFF the background
Viewing pictures
music during the slide show
.
DELETE FILES
To delete a file:
1. In the main Photo menu, navigate through the folders and
scroll to highlight a photo file you wish to delete. Once a
photo file is highlighted, press to select it. You can tell
when a file is selected because the icon next to the file
changes to a double rectangle. More than one file can be
selected for deletion in a single session. Just highli ght and
select them one at a time. Y ou can de-select a highlighted file
by hitting a second time.
2. Once you have selected all the files you wish to delete, press
the button to display the Settings menu for the Photo
mode. Then scroll to Delete Files to highlight the word
"Selected", then press .
3. Use the keys to confirm YES or NO and press .
4. If multiple files are selected, they will all be deleted at once.
17
Listening to music
< _ _ >
Listening to music
MUSIC
The Recorder 2 is able to Play . WMA and .MP3 audio file formats.
Playing audio
To play an audio file:
1. Highlight the Audio menu icon and press to access the file
list.
2. Use the buttons to go to the desired file and press to
play the file.
While playing audio you can use the following functions:
Decrease volume Fast forward
Increase volume Rewind
Mute volume Play previous audio
18
track
Play the next audio
track
Setting menu for Music
Listening to music
Repeat
Delete Files
MUSIC
MUSIC
Folder
Selected
To access the Settings menu for Music press while in the main
Music menu. The following two functions are available:
Repeat
Use to Choose Off, Single, Folder or All, then press .
Select Off to turn the repeat function off, All repeats all tracks,
Single will repeat only a single track, and Folder will repeat all
tracks in the folder.
ELETE FILES
D
To delete a music file:
1. In the main Music menu, navigate through the folders and
scroll to highlight a music file you wish to delete. Once a file
is highlighted, press to select it. You can tell when a file is
selected because the icon next to the file changes to a double
rectangle. More than one file can be selected for deletion in a
single action. Just highlight and select them one at a time.
19
You can un-select a highlighted file by hitting a second
time.
2. Once you have selected all the files you wish to delete, press
the button to display the Settings menu for the Music
mode. Then scroll to Delete Files to highlight the word
"Selected", then press .
Listening to music
3. Use the keys to confirm YES or NO and press .
4. If multiple files are selected, they will all be deleted at once.
20
Watching videos
<MP_ROOT>
<MUSIC>
<PHOTO>
beer can c~
computer_h~
glass_pane~
VIDEO
The Recorder 2 is able to play.ASF, .AVI and .MP4 image file formats.
Watching videos
Playing videos
1. Highlight the Video menu and press to access the file list.
2. Use the to go to the required file and press to play
the file.
While playing the video, you can use the following functions:
Decrease volume Fast forward
Increase volume Rewind
Mute volume Play previous video
clip
Play next video clip
21
Setting menu for Video
Repeat
Delete Files
MUSIC
Folder
Selected
Watching videos
VIDEO
To access the Video Settings menu for Video, press while in
the main Video menu. The following two functions are avai lable:
Repeat
Use to choose between Off, Single, Folder or All Then
Press .
Note: Select Off to turn the repeat function off, Single to repeat
just the current selection, Folder to repeat all in the folder,
or All to repeat all videos.
ELETE FILES
D
To delete a video file:
1. In the main Video menu, navigate through the folders and
scroll to highlight a video file you wish to delete. Once a file is
highlighted, press to select it. You can tell when a file is
selected because the icon next to the file changes to a double
rectangle. More than one file can be selected for deletion in a
single session. Just highlight and select them one at a time.
22
You can un-select a highlighted file by hitting a second
time.
2. Once you have selected all the files you wish to delete, press
the button to display the Settings menu for the Video
mode. Then scroll to Delete Files to highlight the word
"Selected", then press .
3. Use the keys to confirm YES or NO and press .
4. If multiple files are selected, th ey will all be deleted at once.
You can un-select a highlighted file by hitting a second
time.
Watching videos
23
Recording video
Record menu
Resolution
Recording video
Quality
Quick Setup
Timer Record On
Auto Record Off
Storage CF
RECORDER
MUSIC
368x208
Normal
Off
Resolution
To select a resolution:
1. Highlig ht the record section and press to access the
Record Menu.
2. Use the to choose among the resolution settings.(see
"Selecting the rig ht recordi ng resolu tion setti ng "on p a ge 27").
Quality
To choose the quality of the recording,hi ghlight the quality menu
and use the buttons to choose either Normal or Economic in
320x240-15fps and 368x208 option. Use the buttons to choose
Super Fine, Fine, Normal or Economic in all other modes.
Quick setup
Use this when you want the Recorder 2 to shut off automatically
after a selected amount of time. Use the buttons to choose
between OFF, 1hr, 2hrs or 3hrs recording.
24
Timer record
Recording video
Off
MUSIC
CF00 00 00 00 2000
Save Exit
NextPrevious
01 02 03 04 05 06
CF00 00 2000 CF00 00
RECORDER
To access the timer record function, scroll down to highlight Timer
record and press the button.
The screen is divided into functional areas:
PROGRAMS
The Recorder 2 has 6 available recording programs. Use the following settings to setup each program.
Use the button to scroll between the programs and use the
button to select the program.
S
TART AND STOP TIMES
1. Use the button to move between the date and the time.
2. Press to highlight each section and then use the buttons to choose the appropriate number.
3. Press to complete.
25
FREQUENCY
The frequency function allows you to choose when this recording
is activated.
NOTE: The unit must be on for T imer Recording to work. The unit
will not turn on automatically for timer recording.
Recording video
1. Use the buttons to choose between OFF, Once, Daily
or Weekly.
2. Press to save.
Note: Timer recordings are deactivated while the Recorder 2 is
being used for playback. If recordings are scheduled while the
Recorder 2 is playing, a recording will not be initiated.
Auto record
Use the buttons to turn ON or OFF. If the auto record turns
on, it will automatically start to record when there is a video source
input and the recording will stop if the source is turned off. Or you
can press the button to stop the recording anytime.
Storage
Use the buttons to choose between Compact Flash MS,
MMC, SD cards or MS Duo memory cards.
26
Selecting the right recording resolution set ting
The 320x240,176x120 and the 640x480 modes record in a 4:3
aspect ratio (which is standard screen format found on regular
DVD's and most TV's). The 320 x 240-30fps mode is the resolution typical of most handhelds, and the files are fairly compact and
will play back on the greatest number of devices.
The 640x480 mode provides the highest resolution but al so
requires the most data storage space. It is generally only recommended when you plan to play back the recorded files on a TV or
laptop. The extra resolution is wasted on small screens like those
on handhelds. While some handhelds can handle the higher reso-
Recording video
lution 640x480 files (the Neuros 442 for one), many (like the PSP
and the iPod Video) don't have the capability to play them at all.
The 368x208 resolution setting is used when recording from video
sources that are in the wide-screen (16:9) format, and some people like to use it when recording for playback on wide-screen
handhelds like the Sony PSP (see "Playing back recorded files).
This format uses about the same amount of data as the 320x24015fps format. Note: If you record in the 368x208 format from a
source that isn't 16:9, the upper or lower portions of the video may
be clipped on playback. If recording from a TV, make sure it's in
the wide-screen format. If from a DVD player , make sure the DVD
is wide-screen format and also that the player's video output is set
to 16:9.
320 x 240-15fps is designed for PDAs and some Smartphones.
Please refer to your playback device's manual for details concerning supported formats and resolutions.
27
176x120, 320x240-3GP and 176x120-3GP are de signed for
Mobile Phones. Please refer to your Mobile Phones's manual for
details concerning supported formats and resolutions.
Note: As of the date of this printing, the PSP would not allow
Recording video
zooming on 368x208 resolution files. It is hopeful that Sony will
correct this shortcoming in future firmware revisions.
Suggested Recording Resolutions
Economic
640X480
320X240
30fps
368X208
320X240
15fps
176X120
320X240
3GP
176X144
3GP
Please see www.neurostechnology.com / supporteddevices.asp and the manual of your playback device for details.
Normal Fine Super fine Legend
---
---
S/Phone
Mobile
TV
PSP
iPod
PDA
Simple Record
Once you are satisfied with the settings for the Recorder 2
(resolution, recording quality, etc), you can do one-button manual
recording. First make sure your input source is turned on (and
turned to the proper channel if a cable or satellite TV box, PVR ,
etc),then:
1. Press the button to begin recording.
2. To finish recording press the button again.
3. Press the button to return to the Main menu.
4. To view the recorded file, see "Playing back recorder files".
Note:Recording will continue until the button is pressed the
second time or until the card is full unless the Quick Setup time is
set to stop recording after a desired amount of time (see "Quick
Setup above").
28
Setup menu
Setup menu
Date M/D/Y
Time H : M :S
Language
Format Disk
TV Output
Upgrade Devic~
SETUP
07 / 21 / 2001
20 : 57 : 35
English
CF
PAL
Upgrade
Factory Reset
SETUP
Reset
v01.03.0022
Scroll using the bu ttons to highlight the se tu p menu, then
press to enter. There are seven setup menu options.
ATE AND TIME
D
To change the date and time:
1. Press to highlight a selection.
2. Use the buttons to change the valu e.
3. Use the buttons to move betwe en fields.
4. Press when complete.
ANGUAGE
L
The default language of the Recorder 2 is English. If you wou ld
like to change it to the other available languages, follow these
instructions:
1. Go to the setup menu and press .
2. Using the down arrow go to the language bar.
3. Use the arrows to select the required la nguage.
4. Press to return to main menu.
29
FORMAT DISK
To form at the memory card:
1. To format the memory card, scroll down to the Format disk
Setup menu
section and Press .
2. Select YES to confirm formatting or NO to cancel.
TV O
UTPUT
To select the TV output:
1. Use the buttons to choose between NTSC or PAL.
2. The button on the remote control will provide the same
function.
ACTORY RESET
F
To restore all settings to the factory default:
1. To restore factory settings, scroll down to the Factory Reset
function section and press .
2. Select YES to confirm reset or NO to cancel.
30
File browsing
File browsing
<MP_ROOT>
<MUSIC>
<PHOTO>
beer can c~
computer_h~
glass_pane~
File Browser
< _ _ >
<101MNV01>
<PDA>
<TV>
The file browser allows you to view the contents of both the Compact Flash card and the MS/SD/MMC card at the same time.
By pressing you can select a file.
Data Management Settings menu
Copy
Delete Files
File Browser
MUSIC
Selected
Selected
To access the Data Management Settings Menu press . The
following two functions are available:
31
COPY
The files can be copied from CF card to MS, SD or MMC card or
vice versa. Also, the files can be copied to a different folder of the
same memory card.
File browsing
1. Files copied to a different memory card
In the File Browser, the left column is the source memory card
and right column is the destination. Switch the type of card in the
left column in the File Browser by pressing . Highlight a file
from the main menu, go to the Data Management Settings menu
highlight copy,then press .
2. Files copied to a different folder
Choose the same memory card by pressing . Highlight a file
from the main menu, go to the Data Management Settings menu,
highlight copy then press .
ELETE
D
1. Highlight a file from the main menu, go to the Data Management Settings menu highlight delete, then press .
2. You will be asked to confirm YES or NO. Press to confirm
your selection.
32
Playing back recorded files:
Playing back files recorded wit h the Reco rder 2.
Playing back recorded files:
You can use the Recorder 2 to record video for playback on the
TM
Sony PSP ,Neuros 442 portable media player / recorder , the iPod
TM
video, the Nintendo Gameboy Micro ,and many handheld s. The
TM
Recorder 2 files can also be played back on your PC or laptop
running any major operating system. Follow the steps below for
best results using the various playback devices.
I. Sony PSP
You must record using either the 320x240-30fps or the 368x208
format when recording for the PSP (the 640x480 setting will produce recordings that cannot be played on the PSP). The
320x240-30fps mode will produce a picture with a 4:3 aspect ratio
(like a regular TV). The PSP will playback these files in the 4:3
ratio, or you can use the zoom controls on the PSP to shape it to
fit the PSP's wide-format screen. The 368x208 mode will produce
a picture in the wide-screen format, so it is automatically in the
shape of the PSP screen. See page 24 for instructions on how to
select the recording resolution.
2. Before recording onto an MS (Pro) Duo Card with the
Recorder 2, you should first format the MS (Pro) Duo Card with
the PSP to be sure the recorded files will be recognized by the
PSP.
3. Once recording is complete, all you have to do is pop the MS
(Pro) Duo card out of the Recorder 2 and insert it into the Sony
PSP for playback.
Note: For files recorded in the 320x240-15fps mode, you can use
the zoom feature on the PSP to size the picture to best fit the PSP
33
screen. As of the date of this printing, the PSP would not allow
zooming on 368x208 resolution files. It is hopeful that Sony will
correct this shortcoming in future firmware revisions.
II. Neuros 442 Portable Media Player/Recorder
The Neuros 442 is a powerful portable media player that can both
play and record videos, photos, and music. Unlike many other
handhelds (including the PSP and the iPod Video), the 442 is
powerful enough to process even 640x480 files. This is important
Playing back recorded files:
because it means you can record a file one time that will have
near-DVD-quality resolution if played back on a TV (either with the
Recorder 2 or with the 442) and play the same file on the 442.
Although you can easily record files directly onto the 442, you may
also want to transfer recordings made with the Recorder 2 to the
442. To do that:
Play the file like you would any other on the 442 (see the 442
user's guide for details).
34
III. i-Pod Video
Note: Only files recorded in the 320x240-30fps or 368x208
modes can be played back on the iPod Video (the iPod Video cannot play any file with resolution greater than 480x480).
iPod Video Playback Procedure:
1. Install the "iTunes" drive r on your PC (if you are already using
iTunes with your iPod Video, you have already done this and can
skip this step).
Playing back recorded files:
2. Transfer files recorded previously on memory card (using the
Recorder 2) to your PC using a card reader (purchased separately). Simply slide the memory card into the card reader, then
plug the card reader into a USB slot on your PC. Then drag and
drop the video files from the card reader onto your hard drive.
3. Connect your iPod Video to your PC, then open the "iTunes"
Utility.
35
4.Click on the "Edit" drop-down menu on the iPod Video, then
select "Preferences".
5. When the window shown below appears, click on "Video" item.
Next select "Automatically update all videos", then confirm "OK".
Playing back recorded files:
6. Click on the "File" drop-down menu, then select "Add File to
Library".
36
7. Next, highlight the MPEG-4 video files you wish to load onto the
Playing back recorded files:
iPod Video.
37
Playing back recorded files:
8. Wait while the iTunes utility loads the selected files onto the
iPod.
38
9. When loading is complete, the loaded files will be listed in the
file category of iTunes.
Playing back recorded files:
10. Click on the "File" drop-down menu again, then select "Update
'Username's' iPod".
39
11. Safely disconnect the Video iPod from your PC by following
the steps below.
Playing back recorded files:
.
40
12. Enter the "Videos" mode of the iPod to play back the loaded
files.
Playing back recorded files:
13. Now you can enjoy the video programs YOU recorded, anytime and anywhere you want.
41
IV. Nintendo Game Boy Micro
The Nintendo Game Boy Micro can support MPEG-4 files with
resolution up to 640x 480, so it can play back recordings from all
Recorder 2 resolution settings (320x240-30fps, 368x208, and
640x480). However, if you intend to use the recordings only for
playback on small screens like the Micro (and not on larger
screens like TV), we recommend that you use the 320x240-30fps
mode to save storage space. The extra resolution with 640x480 is
more than can be seen on small screens and is therefore wasted.
Playing back recorded files:
To play files on the Game Boy Micro, you will need an SD card.
then use a Y an Micro Media Adapter (purchased separately -- see
below photo for reference) to play files fro m the SD ca rd on the
Game Boy Micro.
42
Nintendo Game Boy Micro
Play- Yan Micro Media Adapter
V. Other Handhelds (PDA's, Pocket PC's, etc.)
How files recorded with the Recorder 2 are transferred to a
handheld and whether or not they will play without conversion will
depend on the specific handheld. Files can be easily transferred
to those that will accept CF, MS, SD, MMC cards and mini-SD,
RS-MMC, T-Flash (in the same manner as for the PSP above.
Once the files are on the handheld, some may play right away.
Others may not. This is because, for various legal and technical
reasons specific to each device, the various handheld's support
various file formats and not others. These files may still be playable if the handheld owner can download certain software to their
Playing back recorded files:
device, or there may be software available to convert the files to a
format recognizable by the handheld when the files are on the PC
before being transferred to the handheld.
Neuros is continually working to make our products as compatible
with the various file formats as is legally possible, and the Neuros
customer support staff and community are very involved with helping each other work through issues like these. For more information and possible solutions, go to http://neurostechnolo gy.com/
and click on the Forums pull-down menu or the Support pull-down
menu.
43
4. Firmware Upgrade Instructions
Neuros may provide firmware upgrades from time to time to fix
bugs, add enhancements, etc. You can download these upgrades
(usually for free) by going to http://neurostechnology.com/support/
support.asp and following the links for upgrades. The date the latest firmware upgrade was posted will be shown for each Neuros
product. You can also see the version number by clicking on the
upgrade link.
If you aren't certain if you have the latest firmware version or not
on your Recorder 2, go to the Setup menu (as described below),
then scroll to the second page. The current firmware version number will be shown at the very bottom in the format: V.xx.xx.xxxx.
The higher the number after the 'V', the more recent the firmware
version. If the firmware version currently on your Recorder 2 is
older than the latest version on the Neuros web site, you can
update your firmware as follows:
1. Insert a memory card into a card reader (purchased separately)
and plug the card reader into a USB slot on your PC.
2. Go to the firmware download page on the Neuros website as
described above. Follow the instructions to download the latest
firmware version for the Recorder 2. Unzip and Save the new
vcr4800.bin file to the memory card (which will appear as USB
memory or something like that in Windows Explorer). Be sure to
save the file to the root directory of the memory card and not in
any folder or sub-folder.
3. Pull the memory card out of the card reader and insert it into the
Recorder 2.
4. Scroll to the Setup mode by pressing right arrows on the
remote, then select the Setup mode by pressing the button.
The Setup options should now be displayed.
5. Scroll through the Setup menu to highlight the Firmware
Upgrade option, then press the button to start the firmware
upgrade.
A "Clock" icon will appear on the screen while the firmware is
being upgraded. The clock icon will disappear and the Recorder 2
will turn off automatically, when the upgrade is complete.
6. Press the "Power" button on the remote controller to turn on the
Recorder 2.
7. Check out the firmware version at the bottom of the Setup
menu (as described above) to confirm that the new version is now
loaded.
8. Use the arrow to scroll to highlight the Factory Reset option.
9. Press the button on the remote to do reset the system.
10. You're done. Enjoy your new firmware
46
5. Contact Us
You really are important to us. Call us and you'll be amazed how
quickly and easily you'll be connected to a real live person with a
genuine interest in your satisfaction. Try it.
866-5-NEUROS (866-563-8767)
Please use the following e-mail addresses to reach individuals of
the Neuros team:
General Information or Comments: info@neurostechnology.com
Customer Support: support@neurostechnology.com
Media and Analysts Requests: pr@neurostechnology.com
Interested Retailers: sales@neurostechnology.com
Developer Inquiries: developer@neurostechnology.com
Gamma Group Feedback: gamma@neurostechnolo gy.com
Corporate Headquarters
Neuros Technology International, L.L.C.
650 W. Lake Street
Suite 330
Chicago, IL 60661
Phone: 312-756-0061
For additional information please visit the Neuros web site at
www.neurostechnology.com
47
48
6. Appendix
FCC Certification
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection agains t harmful
interference in a residential installation. Operation is subject to the
following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
You are cautioned that any change or modifications to the equipment not expressly appr ov ed by th e party responsible for compliance could void your authority to operate such equipment.
CE Notice (European Union)
Marking by the symbol indicates compliance of this recorder to the
EMC Directive of the European Union. Such marking ind icates
that this recorder meets the following technical standards:
EN 55013:2002+A1:2003-”Limits and methods of measurement of
radio disturbance characteristics of broadcast receivers and associated equipment”.
EN 55020-”Electromagnetic immunity of broadcast receivers and
associated equipment”.
EN 61000-3-3-"Electromagnetic compatibility (EMC) - Part3: Limits - Section3: Limitation of voltage fluctuations and flicker in lowvoltage supply systems for equipment with rated current up to and
including 16 A."
EN 60950-"Safety of Information Technology Equipment."
EN 60950-1:2001- "Safety of Information Technology Equipment."
IEC 60950-1:2001-"Safety of Information Technology Equipment."
C-tick ( Australian Regulation )
This recorder is compliance with the Australian regulation ( AS/
NZS CISPR13 : 2003 Class B ).
VCCI ( Japanese Regulation )
This recorder is compliance with Japanese regulation ( V-2/04.04
& V-3/05.04 ).
To determine which classification applies to your recorder, examine the FCC registration label located on the back panel of the
recorder.
50
Troubleshooting
Please visit the website www.neurostechnology.com to get
the latest trouble shooting information and FAQ about the
Recorder 2.
Symptom Possible cause Possible remedy
No video display. Unit has no power. Ensure that unit is
plugged in correctly. You
should see a green LED
on the front panel if it is
plugged in correctly.
Refer to “About the Neuros MPEG-4 Recorder 2”
on page 3.
Remote control not
functioning.
Memory card not
recognized by the
Recorder 2
Cable connecting A V Out
to video monitor is not
properly connected.
Obstruction in front of
infrared sensor on
Recorder 2.
Low battery power. Replace battery in the
Card not inserted
properly.
Refer to “Connecting to a
TV (viewing only)” on
page 11 for information.
Ensure that a line of sight
exists between the
remote control and the
sensor on the Recorder2.
remote control.
Refer to “Inserting the
Compact Flash (CF) or
1"Micro Drive Card” on
page 9 and “Inserting the
MS Duo/Pro Duo, MMC
or SD Series Card” on
page 10 for information
about proper handling of
memory cards. Never
force memory cards into
the Recorder 2.
51
Specifications
Video
encoder
Video
decoder
Application Formate
1) PSP
2) TV
3) iPod
4) PDA/
Smartphone
5) Mobile
Phone
1) MPEG-4 SP, MPEG-1 Layer 3 (MP3), 30 fps at D1
resolution
1) *QVGA (320x240); MPEG4+AACLC, 30fps
*368 x 208 (16:9); MPEG4+AAC-LC,
30 fps
2) (640x480); MPEG4+AAC-LC, 30fps
3) (320x240); MPEG4+AAC-LC, 30fps
4) (320x240); MPEG4+AAC-LC, 30fps
(320x240); MPEG4, 15fps
5) *RS, MMC, T-Flash, Min SD, Micro
SD, MMC mobile
*176x120;MPEG4+AAC-LC, 15fps
*320x240-3GP;MPEG4+AMR, 15fps
*176x144-3GP;MPEG4+AMR, 15fps
2) DivX 3.11 @ CIF resolution; 4.x; 5.x; 30 fps at D1
resolution
3) Quick time 6; MPEG-4 AAC-LC stereo, MP4 format
at D1 resolution
4) 3GP (MPEG4+AMR)15fps at 320x240 or 176x144
Resolution
File formats ASF, AVI, MP4, 3GP
Audio
decoder
Still image Codec JPEG decode (Baseline), BMP, GIF
Resolution Up to 16M pixels (4096 x 4096)
Thumbnails Supported when the photo has the EXIF header
Codec G.726 AMR
MP3 decoding @ 30-320 kb/s CBR & VBR
WMA
(animated not included)
Processing
Storage Memory
52
Zoom in, Zoom out 1x/2x/4x
card
CF card, MS Duo card, MS Pro
Duo(with adapter) card
SD series, MMC, MS card
TV system Video Out
Format
Power source External 5V AC/DC adaptor (100 ~ 240V, 1.4A)
Dimensions
and weight
Resolution/
Quality
640x480
Save Folder:
320x240-
30fps
Save Folder:
368x208
118 x 87 x 18 mm, 140g
Typical Recording Times on a 1GB Card
Economic Norm al Fine Super fine
251min
(384kbps)
TV
251min
(384kbps)
PSP defined
251min
(384kbps)
143min
(768kbps)
TV
143min
(768kbps)
PSP defined
143min
(768kbps)
11min
(1024kbps)
TV
94min
(1024kbps)
PDA-iPod
60min
(2048kbps)
TV
77min
(1535kbps)
PDA-iPod
Save Folder:
320x240-
15fps
Save Folder:
320x240-
15fps
Save Folder:
176x120
Save Folder:
PSP defined
502min
(96kbps)
PDA-
Smartphone
502min
(96kbps)
PDA-
Smartphone
502min
(64kbps)
Mobile
PSP defined
402min
(192kbps)
PDASmartphone
402min
(192kbps)
PDASmartphone
402min
(128kbps)
Mobile
N/A N/A
335min
(384kbps)
PDASmartphone
335min
(384kbps)
PDASmartphone
335min
(256kbps)
Mobile
201min
(768kbps)
PDASmartphone
201min
(768kbps)
PDASmartphone
201min
(512kbps)
Mobile
53
320x240-3GP
250min
143min
93min
77min(768kb
Save Folder:
176x144-3GP
Save Folder:
(192kbps)
Mobile
500min
(128kbps)
Mobile
(256kbps)
Mobile
400min
(192kbps)
Mobile
(384kbps)
Mobile
333min
(256kbps)
Mobile
ps)
Mobile
250min
(384kbps)
Mobile
54
Loading...
