Net Safety Monitoring RM2 Operating Manual

MILLENNIUM
2-Channel
Rack Mount Controller
User Manual
Model:
RM2-ARD
covering
FIRE (F)/TOXIC (T)/COMBUSTIBLE (C)
Part number:
MAN-
0096 Rev 0
September 2008
Net Safety Monitoring Inc
TABLE OF CONTENTS
Important Information
Warranty Contact Information
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Fire Head ......................................................................................................... 1
ST Series Sensors ............................................................................................ 1
Combustible Sensors and Transmitters / Controllers.....
Step 1 — Install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Unpack ............................................................................................................. 2
Locate .................................................................................................................... 2
Figure 1: Dimensional Drawings ............................................................................. 2
Mount .................................................................................................................... 2
Step 2 — Wire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Field Installation .............................................................................................. 2
Configuration ........................................................................................................ 2
Settings ............................................................................................................. 2
Using Jumpers ....................................................................................................... 2
Relay Outputs .................................................................................................. 2
Current Outputs ............................................................................................... 2
Digital Outputs. ............................................................................................... 2
Figure 2: Analog/Relay/Digital RM2 System Board— Figure 3: ST Series Toxic Figure 4:
Figure 5: —Wiring ............................................................................. 4
Combustible Controller/Transmitter Fire head
SENSOR—Wiring ........................................................ 4
Step 3 — Operate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Start Up ............................................................................................................ 5
Normal Operation .................................................................................................. 5
Table 1: Normal Operation Indicators ..................................................................... 5
Operational Test .............................................................................................. 5
Front Panel ....................................................................................................... 5
Figure 6: RM2 Front Panel Functionality ................................................................ 5
LEDs ...................................................................................................................... 5
Channel LEDs ................................................................................................. 6
Common System LEDs ................................................................................... 6
Display .................................................................................................................. 6
Cal/Reset Button ................................................................................................... 6
RS-232 PC COMM port ........................................................................................ 6
Using the Front Panel ...................................................................................... 6
................................. 1
Wiring................................. 3
Wiring ..... ................. 4
Communication ................................................................................................6
RS-232 Communications Port ...............................................................................6
Terminal Software .................................................................................................6
Figure 7: Terminal Software—Setup Properties ...................................................... 6
Using Terminal Software .......................................................................................7
Figure 8: Terminal Software—Main Menu .............................................................. 7
Setting Options .................................................................................................7
Front Panel / Terminal Functionality
Power Down Mode ................................................................................................7
BYPASS Mode—
Permanent OFF ................................................................................................8
FIRE only .................................................................................8
Relay Options ...................................................................................................8
Review Relay Settings ........................................................................................... 8
Figure 9: Terminal Software—Relay Settings ........................................................ 8
Setting Relays—Terminal Software ......................................................................9
Setting Relays—Front Panel ................................................................................. 9
FIRE ...................................................................................................... 9
ST SERIES SENSORS/CONTROLLERS .................................................. 9
Select Display Language ................................................................................10
Calibration ......................................................................................................10
Calibration Procedure—ST Series SENSORS ................................................10
Figure 10: Calibration Procedure ........................................................................... 11
Abort Calibration ........................................................................................... 11
Calibration Failure/Interruption .....................................................................11
Reset ...............................................................................................................11
Manual Reset .......................................................................................................11
Remote Reset .......................................................................................................11
Step 4 — Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Event Logging ................................................................................................12
Setting Time and Date ...................................................................................12
Figure 11: Event Logging Menu ............................................................................12
Figure 12: Event Logging Display Menu ...............................................................12
Fire ..................................................................................................................13
Table 2: FIRE—Current Output, LEDs and Display Messages ...........................13
FIRE ONLY—Manual Visual Integrity (VI) Testing ..........................................14
Table 3: Manual Visual Integrity Testing—
FIRE ONLY—Force Alarm Output Test .............................................................14
ST Series Sensors ...........................................................................................15
Table 4: ST SERIES SENSORS—Current Output, LEDs and Display Messages 15
FIRE only ........................................14
Net Safety Monitoring Inc
Controllers/Transmitters ................................................................................ 16
Table 5: CONTROLLERS/TRANSMITTERS—Current Output, LEDs and Display
Messages ................................................................................................................ 16
Digital output form Modbus Set-up . . . . . . . . . . . . . . . . . . . . . . . . . .17
Hardware Setup......................................... ................................................................... 17
Figure 13: User interface for modbus setup............................................................. 17
Software Setup........................................... ................................................................... 18
Modbus Register definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Table 6: Status bit assignment for sensor type(Combustible, Toxic and Fire).......... 18
GAS: Modbus Register and Status bit assignment . . . . . . . . . . . . . .19
Table 7: Status bit assignment for Combustible sensor output conditions................ 19
Table 8: Status bit assignment for Toxic sensor(ST series) output conditions.......... 19
FIRE: Modbus Register and Status bit assignment . . . . . . . . . . . . .20
Table 9: Status bit assignment for Fire head output conditions.................................. 20
Table 9(cont’d): Status bit assignment for Fire head output conditions..................... 20
Step 5 — Maintain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
SENSORS—Periodic Response Test ................................................................... 21
Troubleshoot ..................................................................................................
21
How to Return Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Spare Parts/Accessories .................................................................................
Table 10: Part Numbering ......................................................................................
22 22
Appendix A: Electrostatic Sensitive Device (ESD) ........................23
Appendix B: Resistance Table (Ohms) ...........................................24
Appendix C: RM2 Specifications ....................................................25
Net Safety Monitoring Inc
IMPORTANT INFORMATION
This manual is for informational purposes only. Although every effort has been made to ensure the correctness of the information, technical inaccuracies may occur and periodic changes may be made without notice. Net Safety Monitoring Inc., assumes no responsibility for any errors contained within this manual.
If the products or procedures are used for purposes other than as described in the manual, without receiving prior confirmation of validity or suitability, Net Safety Monitoring Inc., does not guarantee the results and assumes no obligation or liability.
No part of this manual may be copied, disseminated or distributed without the express written consent of Net Safety Monitoring Inc.
Net Safety Monitoring Inc., products are carefully designed and manufactured from high quality components and can be expected to provide many years of trouble free service. Each product is thoroughly tested, inspected and calibrated prior to shipment. Failures can occur which are beyond the control of the manufacturer. Failures can be minimized by adhering to the operating and maintenance instructions herein. Where the absolute greatest of reliability is required, redundancy should be designed into the system.
Warranty
Net Safety Monitoring Inc., warrants its electronic assemblies for 36 months from date of purchase.
No other warranties or liability, expressed or implied, will be honoured by Net Safety Monitoring Inc.
Contact Net Safety Monitoring Inc., or an authorized representative for details.
We welcome your input at Net Safety Monitoring. If you have any comments please contact us at the phone/address below or visit our web site and complete our on-line customer survey: www.net-safety.com.
Contact Information
Net Safety Monitoring Inc. 2721 Hopewell Place NE Calgary, AB Canada T1Y 7J7 Telephone: (403) 219-0688 Fax: (403) 219-0694 www.net-safety.com E-mail: nsmsales@net-safety.com
Copyright © 2005 Net Safety Monitoring Inc. Printed in Canada
Net Safety Monitoring Inc
INTRODUCTION
RM2 SYSTEM
The RM2-ARD is a 2-channel, 4-20 mA input of Net Safety’s monitoring devices. Channel #1 independently and can be used for any combination of detectors, toxic gas se nsors or combustible sensor with transmitters. The
available outputs from this device are: 4-20 mA analog signal, relay and
digital for Modbus applications. For Modbus setup see pages 17-20.
Note: All three (3) outputs can be utilized at the same time.
monitor for use with a variety
and Channel #2 function
Net Safety’s fire
Fire Head
Net Safety’s UV/IRS, UVS, IRS, UVU-120-H2 and Phoenix IR3S fire detector heads can be used in conjunction with the RM2.
ST Series Sensors
A variety of Net Safety’s ST Series 4-20 mA Toxic gas sensors can be connected to the RM2.
Combustible Sensors and Transmitters / Controllers
Net Safety’s Uni-Tran and Millennium Combustible Gas Controllers or Transmitters can be used in conjunction with the RM2. Combustible sensors
should always be connected to transmitter or controller . The 4-20 output from
this combination then connected to the RM2.
Manual
The manual has been designed to make installation of the RM2 System easy. To ensure proper installation and usage follow the simple steps outlined in the following pages. Consult the manual provided with the detector device(s) being connected to the RM2 for specific information.
If you encounter any problems, consult the troubleshooting section or contact your sales representative.
Step 1 — INSTALL
Step 2 — WIRE
Step 3 — OPERATE
Step 4 — MONITOR
Step 5 — MAINTAIN
RM2-ARD 1
Net Safety Monitoring Inc.
STEP 1 — INSTALL
UNPACK
Carefully remove all components from the packaging. Check components against the enclosed packing list and inspect all components for obvious damage such as broken or loose parts. If you find any components missing or damaged, notify your representative or Net Safety Monitoring immediately.
Locate
Locate Fire Heads, Sensors, Controllers or Transmitters as per the manual provided with the specific product.
Figure 1: Dimensional Drawings
0.540"
8.566"
STEP 2 — WIRE
FIELD INSTALLATION
WARNING: Wiring codes and regulations may vary. Wiring must comply
with applicable regulations relating to the installation of electrical equipment and is the responsibility of the installer. If in doubt, consult a qualified official before wiring the system. The following figures illustrate the basic connections for a Fire Head, Sensor, Controller or Transmitter as well as information for external equipment.
Consult the manual for the specific Fire Head, Controller or Transmitter regarding further wiring information.
Configuration
Two Analog Input channels with Current Loop and Relay and Digital Output. Refer to Figure 2, "Analog/Relay/Digital RM2 System Board—Wiring", on page 3 for illustration.
SETTINGS
Once field wiring is complete, the Relay Contacts and the Isolated/Non-isolated analog outputs should be configured.
Using Jumpers
Place Jumper(s) over appropriate pins in order to set Relays Contacts as Open or Closed, and set Isolated or Non-isolated analog output. See Figure 2 on page 3.
Relay Outputs
The relay outputs have SPDT, form C, normally open/normally closed contacts rated for 5 Amps @ 30 V dc or 250 V ac. Each channel has two dedicated alarm relays and a fifth relay is a Common Fault relay.
0.690"
0.576"
0.059"
0.970"
Mount
The RM2 can be fitted into a cage and located in a Class 1, Division 2 location.
RM2-ARD 2
Current Outputs
A 4-20 mA dc analog current output (isolated/non-isolated) transmits information to other devices.
Digital Outputs
For digital output, connections to PLC (RTU) are made via terminals 19 and 20 (A and B)for Modbus communications. See page 3 and pages 17-20. RS 485 Bus Terminator Jumpers (JP9 and JP11) should be placed over jumper pins
for Modbus communication. The user should wire the system according to RS 485
convention and local Electrical codes.
Net Safety Monitoring Inc.
Figure 2: Analog/Relay/ Digital RM2 System Board
Wiring
Note: The Common System Fault Relay is fixed as Energized/Non-latching.
Refer to Table 2 on page 13, Table 4 on page 15 and Table 5 on page 16 for status indicators.
COMMON FAILURE FAULT
CHANNEL#1 FAULT LOW
CHANNEL#1 FIRE HIGH
CHANNEL#2 FAULT LOW
CHANNE #2 FIRE HIGH
+24 V Supply
4-20 mA Signal
Manual Visual Integrity (Fire ONLY)
Supply Common
+24 V Supply
4-20 mA Signal
Manual Visual Integrity (Fire ONLY)
Supply Common
FIREHEADS/SENSORS
TRANSMITTERS/CONTROLLERS
Digital output to PLC (RTU) Digital output to PLC (RTU)
Isolated Power +24V 4-20 mA Output CH#1 4-20 mA Output CH#2
RM2 Remote Reset
Main Power (+24V)
Supply Common
Earth Ground
R1
R2
R3
R4
A B
Relay contacts are jumper selectable as Normally OPEN or Normally CLOSED Position 1 & 2 = CLOSED Position 2 & 3 = OPEN (default Closed - 1 & 2)
RS 485 Bus
Termination jumpers
(JP 9 & JP 11)
Analog Output - Channel #1
Analog Output - Channel #2
Analog Outputs are jumper selectable as Position 1 & 2 = Non-isolated (default) Position 2 & 3 = Isolated dc (default Closed - 1 & 2)
Note: Connect Shield to Supply Common (COM). Refer to "Remote Reset—Wiring" on page 4 for instructions on wiring a Remote Reset button.
Note: For F
RM2-ARD 3
IRE HEAD and CONTROLLER/TRANSMITTER wiring, consult the manual provided with the fire or gas product for specific wiring instructions.
Net Safety Monitoring Inc.
Figure 3: ST Series Toxic SENSORWiring
RM2-ARD
To Multi-purpose Junction Box and terminal board for ST Series Sensors.
Refer to MAN-0081 for terminal designations when using the Net Safety Multi-purpose Junction Box
Examples of ST Series Sensors:
ST1200, ST1300, ST1500, ST1250 ST1600 and ST1800
Figure 4:
Combustible Controller/Transmitter
+24V / +24Vdc 4-20 / 4-20 O/P
COM / COMMON
Wiring
RM2-ARD
If sensor is separated from Combustible Transmitter/Controller, refer to the Net Safety Multi-purpose Junction Box manual (MAN-0081) for terminal designations.
Figure 5:
Fire head
White wire
Red wire
Blue wire
Black wire
Wiring
ST Series Sensor wire colour designation:
Red = R = +24 Vdc
Black = BLK = Sig(Signal)
Green = Ground
Note: For ST Series Toxic sensors, use shielded copper instrument wire
(minimum 18 AWG) for separations up to 500 feet; use 16 AWG for
Note: Refer to the F
wiring instructions. See MAN-0081 for terminal designations if the Net Safety Multi-purpose Junction Box is being used.
IRE HEAD or CONTROLLER/TRANSMITTER manual for
RM2-ARD
separations of 500 to 2000 feet. Consult the factory if greater distance required.
Remote Reset
Wiring
Note: To compensate for distance when remotely calibrating(sensor wired for
separation), decrease the tubing diameter or increase the calibration gas flow rate. Always confirm calibration at the sensor.
Note: Clears latched alarms for both RM2 channels.
RM2-ARD 4
Net Safety Monitoring Inc
STEP 3 — OPERATE
START UP
Once all terminal wiring and Jumper settings are complete, the RM2 may be powered up.
The time it takes the RM2 to power up is dependent on whether it is connected
to a Fire head , a transmitter/controller with sensor or directly to ST series sensor. For
C
ONTROLLERS
after the system has been powered up; current output is 3.0 mA. sensor is directly connected to it.
Note:
Channel types are defined at purchase and factory set.
Normal Operation
Once the warm-up routine has ended, normal operation begins as indicated in Table 1 .
Tab le 1 : Normal Operation Indicators
Type
Fire Head
ST Series Sensors
Controllers/ Transmitters
with sensor and
FIRE Heads ,
a 90 seconds routine will begin
the System Status LED blips green and
The unit will power up immediately when a
System Status LED
Channel 1 or 2 Display Message
NORM
Green Blip
00
ST series
Current Output
4.0 mA
Figure 6: RM2 Front Panel Functionality
Channel Type Identifier
(1 per channel)
(YELLOW) Functions as
Fault LED for Fire; Low Alarm for Gas
Calibration/Reset Button
(1 per channel)
System Fault LED
%LEL
CHANNEL
R1 R2
Cal/Reset
FIRE
CHANNEL
R3 R4
Cal/Reset
Fault Status
Scrolling Display
1
(1 per channel)
(RED) Functions as Alarm LED for Fire; High Alarm for Gas
2
System Status LED (also active during calibration)
Operational Test
Once normal operation has been established, consult the manual provided with the Fire Head, Sensor, Controller or Transmitter for instructions on operational testing.
RS-232
PC COMM
Model#: RM2-ARD
Serial Port PC Communication Interface RJ-11
Ensure that all safety precautions and regulatory requirements for the application are met.
LEDs
FRONT PANEL
The RM2 Front Panel contains convenient LEDs and displays to provide information regarding the RM2 status; the push button facilitates various settings/activities; and the RS-232 port supports communication with a PC.
RM2-ARD 5
There are two LEDs dedicated to each channel and two additional System LEDs. The LEDs will turn solid or flash depending upon the status of the RM2.
Refer to the section titled "Monitor" on page 12 and review the tables listing the various devices, LEDs and states.
Net Safety Monitoring Inc.
Channel LEDs
Two LEDs are dedicated to each channel and, depending on the type of detector connected (fire or gas), the LED indicates which relay has been tripped.
LED M
R1 or R3
R2 or R4
ARKED GAS CONNECTED FIRE CONNECTED LED COLOUR
LOW alarm FAULT alarm yellow HIGH alarm FIRE alarm red
Common System LEDs
A Fault and Status LED are provided and are common to both channels. The Status LED is also active during calibration.
Display
Each channel has a separate, 4-character scrolling display visible in most lighting conditions.
Cal/Reset Button
Each channel has a push button for calibration (ST SENSORS only), setting relay options, clearing latched alarms, turning channels on or off and bypassing channels.
RS-232 PC COMM port
The COMM port is an RJ-11 compatible, RS-232 suitable PC communications port for interfacing with the RM2 at the Front Panel (refer to "Communication" for details).
COMMUNICATION
RS-232 Communications Port
The RS-232 is compatible with standard terminal software which must be used to communicate with the RM2. The terminal software can be used to modify various options, set parameters and view the Event Log.
A RJ-11 compatible cable and DB9 connector are required to connect the RM2 serial port (refer to "Part Numbering" on page 22) to an interface device such as PDA or computer loaded with standard Terminal software.
WARNING:
Bypass.
Terminal Software
RS-232 compatible terminal software must be installed on the device communicating with the RM2 (i.e., computer, PDA, etc.). When creating a new connection definition, the appropriate COM port must be defined for proper communication to be established. The Properties for that port must be set as shown in Figure 7, "Terminal Software—Setup Properties", below.
Figure 7: Terminal Software
The Alarm System connected to the RM2 must be in
Setup Properties
Using the Front Panel
1. Ensure that the RM2 has been turned on and no fault is present.
2. Press and hold the Cal/Reset button until the message
Switch On
displays and the countdown 10 to 1 finishes.
3. An option will scroll across the display followed by the prompt
4. To select an option, momentarily press the Cal/Reset button at the
YES?
YES?
prompt.
5. If you do not wish to select that option wait until the next option appears and then select
6. A selection is acknowledged with a flashing
YES?
YES
.
7. If no option is selected, the RM2 returns to normal operation.
RM2-ARD 6
Net Safety Monitoring Inc
Using Terminal Software
1. Open terminal software and establish a connection.
2. Once connected, press Enter for Main Menu.
3. The Main Menu will display an entry for each channel plus Event Logging and Display Language as well as a serial and version number.
4. Enter a number 1, 2, 3, etc., and press Enter to make a selection from any menu.
5. Press Enter twice to return to the Main Menu.
Figure 8: Terminal Software
Main Menu
Front Panel / Terminal Functionality
Front Panel Terminal
Calibrate S
ENSOR*
Set and Review Relay settings
*
**
Set Sensor Range
Set Display Language
Reset Channel
Power Down mode per channel
Momentary BYPASS** mode per channel
*
*
*
Channel Permanent OFF
Define Channel Type
Event Logging - setup and review
Current Firmware version
* ST Series Sensors only; otherwise calibrate from Uni-Tran/Millennium
controller/transmitter.
** BYPASS mode is only available when both channel types are FIRE.
Power Down Mode
Each channel can be individually turned off from the Front Panel for maintenance.
*
*
*
*
*
*
WARNING:
When in power down mode, the RM2 channel will neither
alarm nor transmit current output.
1. Press and hold the Cal/Reset button on the Front Panel. Wait for the
SETTING OPTIONS
Options can be set from the Front Panel, the RS-232 Terminal interface or, in some cases, both.
Switch On
2. When
Power Down Channel YES?
Button.
3. The message press the Cal/Reset button to select. The RM2 channel is now powered
message and countdown (10-0) to complete.
displays press the Cal/Reset
Are you sure? YES?
displays. At the
YES?
prompt,
down.
WARNING: DO NOT interrupt setup from Front Panel by using Terminal software.
4. The message in power down mode.
Off
will continue to scroll on the display while the channel is
5. To return to normal channel operation, press the Cal/Reset button. Channels defined as
FIRE have a 90 second start delay prior to returning to normal
operation.
RM2-ARD 7
Net Safety Monitoring Inc
BYPASS Mode—FIRE only
When both Channels are defined as FIRE,eachchannelcanbeindividually placed into Bypass mode from the Front Panel for testing and detector replacement. When in Bypass mode, the channel relays will not trip nor will an output signal be transmitted.
Bypass mode is momentary; pressing the Cal/Reset Button will return the Channel to normal operation.
1. Press and hold the Cal/Reset button on the Front Panel. Wait for the
Switch On
2. When
Channel Bypass YES?
3. The message Cal/Reset button to select.
4. The message System Fault LED will turn Solid. Press the Cal/Reset Button at any time to return channel to
Permanent OFF
If a channel is not required, it can be permanently turned OFF using the Terminal Software.
1. Open terminal software and establish a connection.
2. Once connected, press Enter for Main Menu.
3. Select the Channel number to be turned off.
4. Enter 1 (sensor type) until =
Note: The Terminal Software must also be used to turn the Channel ON.
message and countdown (10-0) to complete.
displays press the Cal/Reset Button.
Are you sure?
Bypass Channel
NORM
.
displays. At the
will continue to scroll and the Yellow
Off is displayed.
YES?
prompt, press the
RELAY OPTIONS
Review Relay Settings
The current relay settings can be viewed using either the Terminal Software or the Front Panel. Use Cal/Reset button for either channel and select
Relay Settings
when using Front Panel; enter a channel number and
review displayed settings using Terminal Software.
Figure 9: Terminal Software
Current Setting for Channel #1
1) Sensor type=Fire
Fault Relay=Energized, Non Latching
High Alarm
2) Coil Status=De-Energized
3) Latch Status=Non Latching
Press 1->3, then press the Enter key
Current Setting for Channel #2
1) Sensor type=ST Series Fault Relay: Energized, Non Latching
High Alarm
2) Coil Status=De-Energized
3) Latch Status=Non Latching
4) High Alarm Level=40
Low Alarm
5) Coil Status=De-Energized
6) Latch Status=Non Latching
Relay Settings
default settings (fixed)
Refer to "FIRE" on page 9 for de­tails regarding these relay set­tings.
or Unitran/Millennium
default settings (fixed)
Refer to "ST SERIES SENSORS/ C
ONTROLLERS" on page 9 for
details regarding these relay settings.
Review
7) Low Alarm Level=20
8) Sensor Range=100
Press 1->8, then press the Enter key
Selectable 10, 20, 25, 50, 100, 200, 250, 500, 1000
Note: When switching Sensor Type, establish a new connection and reset all
options.
WARNING:
Do not attempt to setup the RM2 using the Terminal
Software if setup has already begun at Front Panel.
RM2-ARD 8
Net Safety Monitoring Inc
Setting Relays—Terminal Software
Set the Low and High Alarm relays for Gas as well as Sensor range. Set the High Alarm for Fire. The Fault Relay is fixed as Energized/Non-latching and cannot be changed.
WARNING:
The scale (PPM) of the sensor connected, with or without a
controller, must match the scale entered in the field Sensor Range.
1. Open terminal software and establish a connection.
2. Once connected, press Enter twice for Main Menu.
3. Enter a number 1 or 2 for the required Channel.
4. Enter the number for a setting. In most cases, entering a number will toggle between setting options; for alarm levels and range, a prompt will appear at the bottom of the screen
. Enter level/range and press Enter again to confirm
entry.
5. Press Enter twice to return to the Main Menu.
Setting Relays—Front Panel
FIRE
The High Alarm (Fire relay) can be set to Energized or De-Energized and Latching or Non-latching. The Fault Relay is fixed as Energized/Non-latching.
Step 1: Press and hold the Cal/Reset button on the Front Panel. Wait for the
Switch On
Step 2: When
Set Relay Options YES?
Reset Button.
Step 3: The message
display then shows
Energized YES?
setting when it displays. The flashing If no selection is made, the next option displayed.
Step 4: The message
Latching YES?
Cal/Reset Button to select the setting when it displays. The flashing
YES
confirms the selection.
Step 5: Once set, the RM2 will return to
message and countdown (10-0) to complete.
displays press the Cal/
High Alarm–––Coil Status
Energized YES?
and then
displays. The
De-
. Press the Cal/Reset Button to select the
YES
confirms the selection.
Latch Status
and then
displays. The display then shows
Non Latching YES?
NORM
.
. Press the
ERIES SENSORS/CONTROLLERS
ST S
There are two settings for the Alarm Relays: Low and High. The Coil Status, Latch Status and Alarm Level for the Low alarm are set first, followed by the High. The Fault Relay is fixed as Energized/Non-latching and cannot be changed.
Step 1: Press the Cal/Reset button, wait for countdown to finish and when
Set Relay Options YES?
Button again to select. The flashing
Step 2: The message
display then shows
Energized YES?
setting when it displays. The flashing
Step 3: The message
Latching YES?
Cal/Reset Button to select. The flashing
Low Alarm–––Coil Status
Energized YES?
. Press the Cal/Reset Button to select the
Latch Status
and then
displays press the Cal/Reset
YES
confirms the selection.
displays. The
and then
YES
confirms the selection.
De-
displays. The display then shows
Non Latching YES?
YES
confirms the
. Press the
selection.
Step 4: The message
Set Low
displays. Low alarm set-points are then displayed in varying increments (increment dependent upon defined sensor range). When the required level displays, press the Cal/Reset Button to select. The level chosen will flash to confirm the selection.
Step 5: The message
display then shows
Energized YES?
flashing
Step 6: The message
Latching YES?
Cal/Reset Button to select. The flashing
High Alarm–––Coil Status
Energized YES?
. Press the Cal/Reset Button to select. The
YES
confirms the selection.
Latch Status
and then
displays. The display then shows
Non Latching YES?
and then
YES
displays. The
De-
. Press the
confirms the
selection.
Step 7: The message
Set High
displays. High alarm set-points are then displayed in varying increments (increment dependent upon defined sensor range). The high alarm set-point is always higher than the low alarm level. When the required level displays, press the Cal/Reset Button to select. The level chosen will flash to confirm the selection.
Step 8: Once set, the RM2 will return to
00
.
RM2-ARD 9
Net Safety Monitoring Inc
SELECT DISPLAY LANGUAGE
The display language can only be set using the Terminal interface.
1. Open terminal software and establish a connection.
2. Once connected, press Enter twice for Main Menu.
3. The Main Menu will display.
4. Enter the number 4 to select
4) Display Language.
5. The language will change to Espanol then Francais and back to English each time 4 is entered.
6. Press Enter twice for Main Menu.
Note: The factory default is English.
CALIBRATION
WARNING: When using a combustible sensor with the RM2 , the
sensor has to be connected to a transmitter or controller. The 4-20 output
from this configuration is then connected to the RM2 as signal. Calibration
must be performed at the transmitter or controller NOT the RM2. Refer to the
Uni-Tran or Millennium transmitter manuals for calibration instructions. Use the
messages will appear at RM2.
ONTROLLERS /TRANSMITTERS to monitor display messages. Not all
C
Note: The ST Series S
1. Confirm successful power up of RM2
ENSORS must be calibrated from the RM2 Front Panel.
—Status LED Green Blip; no fault
indicated.
2. Press and Hold Cal/Reset Button until
Switch ON
and countdown
completes.
3. When
4. When
5. Wait for
Calibrate Sensor YES?
to select
YES?
Apply Clean Air
Apply 50% Span Gas
Selection will be confirmed by a flashing
displays, press the Cal/Reset Button
YES
displays apply clean air.
to display and apply specific gas at a
rate of 0.5 litres per minute.
6. The display will show the actual gas value at last calibration.
7. Remove span gas when the message
8. The message
Cal Complete
Remove Gas
displays.
will display when calibration is complete.
9. Apply zero gas (clean air) again to purge system.
Note: Always apply test gas after calibration to verify operation.
.
Calibration Procedure—ST Series SENSORS
WARNING: The calibration procedure requires approximately
5 minutes to complete. If gas is not applied at the appropriate time, a calibration failure may occur (refer to "Calibration Failure/Interruption" on page 11 for specific information).
For accurate performance, calibrate sensors using 50% span of the specific gas of concern. The concentration of gas, corresponding to 100% of full scale, is converted to a linear 4 to 20 mA output signal which can be powered from the primary dc supply of the instrument. Power up the unit for at least 4 hours BEFORE first calibration.
The following calibration procedure should be followed to ensure an accurate correlation between the 4 to 20 mA output signal and the gas concentration.
RM2-ARD 10
Net Safety Monitoring Inc
Figure 10: Calibration Procedure Abort Calibration
The Calibration procedure may be aborted. When the display shows
Display Shows
Action
Status LED and Current Output
50% Span Gas
calibration countdown 10-0 completes and the display returns to
Apply
, press and hold the Cal/Reset button until the abort
00
.
Calibrate Sensor YES?
Apply Clean Air
Apply 50% Span Gas
Calibrating Gas Value @
last calibration
Remove Gas
Cal Complete
00
Select
YES?
Apply clean (zero air)
Apply specific gas
Wait
Remove gas
Apply clean air to
purge system
Normal Operation
Status LED Solid Green / 3.0 mA
Status LED Fast Flash Red / 3.3 mA
Status LED Fast Flash Red / 3.3 mA
Status LED Solid Green / 3.6 mA
Status LED Solid Green / 3.6 mA
Status LED Blip / Green 4.0 mA
Calibration Failure/Interruption
If the calibration procedure fails, the Status LED alternates between Green and Red and the analog output changes back and forth from 3.0 to 3.3 mA. The message message
Fail Zero
Fail Span
is displayed if span gas is not applied or recognized; the
will display if the calibration process is interrupted.
The unit remains in a failed state until manually reset. After the Manual Reset, the unit will return to normal operation based on previous calibration values. See "Manual Reset" on page 11 for instructions.
RESET
Manual Reset
A Manual Reset is required to clear a latched relay alarm for individual channels. Simply press the specific Channel’s Cal/Reset Button, on the Front Panel of the RM2, to clear a latched alarm.
Remote Reset
The RM2 can be wired to an external device (refer to illustration"Remote Reset—Wiring" on page 4) so latched alarms for both channels may be remotely cleared.
RM2-ARD 11
Net Safety Monitoring Inc
STEP 4 — MONITOR
EVENT LOGGING
The Event Logging feature securely stores in protected RAM up to 1000 events. The time and date of each occurrence is recorded along with the channel, detector type and the associated alarm, fault or calibration event. A maximum of 1000 events are stored although as few as 10 events may be viewed at a time. When the 1000th event is reached, the first event stored will be removed.
In order to accurately track events, the time and date must first be set.
Setting Time and Date
Step 1: Open terminal software and establish a connection.
Step 2: Press Enter for Main Menu.
Step 3: Type 3 and press Enter to select
Step 4: Type 1 and press Enter to select
Step 5: Enter the hour (24 hours) and then minutes.
Use 2-digits for hour/minutes and separate with a space.
Step 6: Type 2 and press enter to select
Step 7: Enter the day/month/year using 2-digits for each and separate with
a space.
Step 8: Press Enter to confirm entry.
3) Event Log Menu.
1) Time.
2) Date.
Figure 11: Event Logging Menu
Event Logging Menu
1) Time (HH:MM)=14/04
2) Date (DD/MM/YY)=03/12/03
3) Display last 10 Events
4) Display All Events
Enter 1->4, then press the Enter key
Once the time and date have been set the RM2 will automatically and accurately track the alarm and fault conditions as well as other events such as sensor calibration.
Figure 12: Event Logging Display Menu
Time(HH:MM):14.12 - Date (DD/MM/YY):03/12/03 - Ch:02 Event: vi fault Time(HH:MM):14.12 - Date (DD/MM/YY):03/12/03 - Ch:02 Event: Warning!! Time(HH:MM):14.12 - Date (DD/MM/YY):03/12/03 - Ch:01 Event: high alarm Time(HH:MM):03.11 - Date (DD/MM/YY):03/17/03 - Ch:02 Event: fire Time(HH:MM):19.12 - Date (DD/MM/YY):05/02/03 - Ch:02 Event: fault Time(HH:MM):22.09 - Date (DD/MM/YY):06/22/03 - Ch:01 Event: high alarm Time(HH:MM):06.01 - Date (DD/MM/YY):08/11/03 - Ch:01 Event: calibrate
Press Enter Key to exit
Note: Press Enter at anytime to stop the scroll through all events.
RM2-ARD 12
Net Safety Monitoring Inc.
FIRE
Note: For Bypass mode, Both channels have to be configured for fire.
Tab l e 2 : F IR ECurrent Output, LEDs and Display Messages
RM2
P/OtnerruCsutatS
Channel 1 and 2
LEDs
R1 & R3
Fault
(yellow)
R2&R4
Fire
(red)
(yellow
Fault
System LEDs
Status
(red) (green)
--diloS--Am0eruliafmetsyS2MR
Fire Head Electronic failure 2.5 mA Solid off off - Blip
Internal Power Fault or system power out of range
<2.5 mA
Solid off Blip
Solid or off
Automatic VI Test Failure 2.5 mA Solid off off - Blip
Start up....... (90 seconds)
yaleDtratS
Background radiation source UV 6.0 mA off off off - Blip
Background radiation source IR 8.0 mA off off off - Blip
Early Warning - Intermittent radiation detected
16.0 mA off off off - Blip
RM2
Scrolled
Display Messages
pilB-ffoffoffoAm0edoMnwoDrewoP
last message
pilB-ffoffoffoAm0.3
Start Delay Millennium
pilB-ffoffoffoAm0.4noitarepOlamroN
pilB-diloSffoffoAm0.4edomssapyB
pilB-ffodiloSffoAm0.02demrifnoceriF
Channel Bypass
FIRE (flashes)
Off
*
Sensor Fault
Sensor Fault
VI Fault
NORM
UV Present
IR Present
Warning
* The last message displayed prior to the failure will remain on the display.
RM2-ARD 13
Net Safety Monitoring Inc
FIRE ONLY—Manual Visual Integrity (VI) Testing
The RM2 can be wired (using Terminal 13 for Channel 1 and Terminal 17 for Channel 2) so F
IRE HEAD Visual Integrity test results can be displayed and
monitored by the RM2.
WARNING:
Both Channels must be set to FIRE for VI Testing and the connected alarm system placed in bypass. The Phoenix IR3S cannot be wired for VI testing.
Step 1: Press and hold Channel #1 or #2 Cal/Reset button on the Front
Panel. Wait for the
Switch On
message and countdown (10-0) to
complete.
Step 2: When
Manual VI Test YES?
displays press the Cal/Reset
Button.
Step 3: After 5 seconds, the test lamp turns on for 30 seconds and analog
output drops to 3 mA.
Step 4: Refer to Table 3 below for the list of possible status messages for
the Visual Integrity Test.
Step 5: The VI Test message is displayed for 30 seconds or press and hold
the Cal/Reset Button until the VI display message flashes (approximately 10 seconds) to return to
NORM
before the
30 seconds.
Tab le 3 : Manual Visual Integrity Testing
FIRE only
egasseMyalpsiDsutatS
F
IRE ONLY—Force Alarm Output Test
The Force Alarm Output tests Relay contacts by switching relays for 2 seconds and stepping Analog output through the primary alarm levels. Tests are initiated from the RM2.
WARNING:
The connected alarm system must be placed in bypass
during the Force Alarm Output test.
Step 1: Press and hold Channel #1 or #2 Cal/Reset button on the Front
Panel. Wait for the
Switch On
message and countdown (10-0) to
complete.
Step 2: When
Force Alarm Output YES?
displays press the Cal/
Reset Button.
Step 3: When
Is it Safe to Activate Alarms? YES?
displays,
press the Cal/Reset Button.
Note: If you do not press
YES?
as this prompt, the RM2 will return to
normal operation.
Step 4: When
Step 5: When
Relays YES?
flashing
YES
confirms the selection. The message
displays, press the Cal/Reset Button. The
times during the Relay test and then return to
YES?
If
is not selected, the next option is displayed.
Analog OP? YES?
displays, press the Cal/Reset
On
NORM
will flash 4
.
Button. The RM2 will then test primary analog output responses and then return to
NORM
.
VI Fault
Optical surfaces require cleaning
Optical surfaces clean
Optical surfaces perfectly clean
RM2-ARD 14
FAI L
PASS
GOOD
BEST
Net Safety Monitoring Inc.
ST SERIES SENSORS
When calibrating a sensor, status is reflected by the System LEDs.
Tab le 4 : S T S
Start up.....
Apply calibration gas - 50% span 3.3 mA off off off
ERIES SENSORSCurrent Output, LEDs and Display Messages
RM2
P/OtnerruCsutatS
Channel 1 and 2
LEDs
R1&R3
R2 & R4
Low
(yellow)
High
(red)
(yellow)
Fault
System LEDs
Status
(red) (green)
(few seconds) 4.0 mA off off off - Blip
tluaFrosneS
Am5.2
Fast
Flash
Span is set, remove gas 3.6 mA off off off - Solid
Return to normal operation 3.6 mA off off off - Solid
Calibration procedure failed/interrupted 3.0 / 3.3 mA off off off Alternate
Am0.02-0.4>tneserpsaG
ON
(when set
point
reached)
ON
(when set
point
reached)
off - Blip
RM2
Display Messages
00
pilB-ffoffoffoAm0.4noitarepolamroN
pilB-ffoffoffoAm0edoMnwoDrewoP
--diloS--Am0eruliafmetsyS2MR
pilB-diloSffoffo
last message
Sensor Fault
pilB-diloSffoffoAm5.2)%01>(tfirdssecxE
diloS-ffoffoffoAm0.3rosneSetarbilaC
diloSffoffoffoAm0.3rianaelcylppA
-
Calibrate Sensor
Apply Clean Air
Apply 50% Span Gas
Cal. complete
1 to 100% full Scale
00
Off
*
Neg Drift
(gas value)
Remove gas
Fail Zero
Fail Span
(gas value)
* The last message displayed prior to the failure will remain on the display.
RM2-ARD 15
Net Safety Monitoring Inc.
CONTROLLERS/TRANSMITTERS
The RM2 receives and interprets the 4-20 current output sent by the Uni-Tran or the Millennium. Not all visuals alerts will appear at the RM2.
Note: For combustible configuration, calibration is done at the controller / transmitter not at the RM2.
Tab le 5 : C
ONTROLLERS/TRANSMITTERSCurrent Output, LEDs and Display Messages
Channel 1 and 2 LEDs System LEDs
RM2
Status Current O/P
R1 & R3
Low
(yellow)
R2 & R4
High
(red)
Fault
(yellow)
Status
(red) (green)
Start up......(90 seconds)
Start Delay Message is also displayed at the
ONTROLLER /
C
RANSMITTER
T
Normal operation
3.0 mA off off off Blip
4.0 mA off off off off Blip
on
Power Down Mode 0 mA off off off off Blip
RM2 System failure 0 mA off off Solid off off
Sensor Fault 2.5 mA off off Solid off Blip
Gas present >4.0-20.0 mA
ON
(when set point
reached)
ON
(when set point
reached)
off off Blip
RM2
Display Messages
Start Delay Millennium
00
Off
last message
Sensor Fault
1 to 100% full Scale
*
* The last message displayed prior to the failure will remain on the display.
RM2-ARD 16
Digital output from Modbus Set-up:
The RM2-ARD also allows digital output to be monitored by the user. Ensure that the proper connections are made when connecting the RM2­ARD output terminals 19 and 20 (marked ‘A’ and ‘B’) to PLC (RTU). For output bit assignments for Combustible and Toxic sensor see table 7 and table 8. For output bit assignment for Fire head see table 9.
Hardware Setup
Figure 13: User interface for Modbus setup
For Hyper Terminal connection: An RJ11 cable with DB9 (female) connector is used for RS-232 serial connection. Use the RJ 11 and DB9 (female) connector with a RS-232(male) to USB converter, if the computer doesn’t have a RS-232 serial connection.
User inputinterface for hyperterminal
Computer
RM2ͲARD
RJ11connection
OutputterminalA
OutputterminalB
Front of unit Rear of unit
Modbus RTU Slave Modbus RTU Master
Note: For Modbus communication, the user should wire the system according RS 485 conventions and adhere to local electrical codes.
 17
RM2ͲARD
PLC
A
B
USBorRS232serialinput

Software Setup
g
yp
(
,
)
Connect the Modbus output using baud rates of 4800, 9600,
14.4K,
19.2K, 28.8 K, 38.4K or 57.6 K bps.
Parity is none and Stop bit is 1.
Addresses are assigned by the user.
Modbus Register definitions
Four Modbus registers are utilized when setting
Registers for Flame detector configuration outputs only
40001 Scaled sensor output channel 1
40002 Scaled sensor output channel 2 40004 Status Bits channel 2(binary)
Registers
40001 and 40002
are only used to indicate output conditions for Flame detectors. See Table 9 on page 20.
Binary values of Registers 40003 and 40004 are used to indicate the type of sensor / detector being used. Registers 40003 and 40004 are also used to indicate outputs for gas sensors. (2 byte) assigned to registers 40003 and 40004, bit #’s 0, 1, 2 and 3 are utilized for sensor/ , while bit #’s 4, 5, 6 and 7 are used to indicate outputs for gas configurations.
detector type
See Tables 7 and 8 on page 19. Table 6 below shows the bits assigned for combustible sensor setup, toxic sensor and Flame detector.
Status bit assi
Table 6
Assigned Registers & Channel #
:
nment for sensor t
Channel is inactive(
turned off
)
up for digital output. They are as follows:
Registers for sensor / detector type and outputs from gas configurations
40003 Status Bits channel 1(binary)
With 16 bits
ŽŵďƵƐƟble
e
Status bits for Combustible set-up
Toxic and Fire
Status bits for Toxic sensor
(
ST series
Status bits for
)
Fire heads(Flame detector)
Register 40003
(Channel 1)
xxxx xxxx 0000
0000 xxxx xxxx 0000 0001 xxxx xxxx 0000 0010 xxxx xxxx 0000 0011
Bit 0 Bit 3
Register 40004
(Channel 2
)
xxxx xxxx 0000 0000 xxxx xxxx 0000
0001 xxxx xxxx 0000 0010 xxxx xxxx 0000 0011
Note: Outputs for gas configurations refer to power up and fault, as well as alarm conditions. Outputs for Falme detectors refer to power up, fault, background UV and IR detection, Instant fire warning and fire detection.
RM2-ARD
18
Note: The Status bits for
Oxygen (to be released soon) will be xxxx xxxx 0000
GAS: Modbus Registers and Status bit assignment
0100
Combustible gas detection: The table below shows the status registers and bit
assignments various outputs when Combustible gas
for
sensor (with transmitter) is connected to the RM2-ARD unit. Bits #’s 4 through 7 of registers 40003 and 40004 indicate the
Table 7: Status bit assignment for
Assigned Registers & Channel #
Register 40003 (Channel 1)
Register 40004
(
Channel 2
)
Toxic gas detection
Combustible
Power up
xxxx xxxx 0001 0001 xxxx xxxx 0010
xxxx xxxx 0001 0001 xxxx xxxx 0010 0001 xxxx xxxx
:
The table below shows the status regi
ŽŵďƵƐƟble (signal from LEL sensor and trĂŶƐŵŝƩĞr) output ĐŽŶĚŝƟons
Combustible
Sensor fault Low Alarm activated
0001
Combustible
xxxx xxxx 0100 0001 xxxx xxxx 0001
0100 0001 xxxx xxxx 0001
ster and bit assignments for various
Combustible High
Alarm activated
1000
1000
outputs when a Toxic (ST series) gas
Bit 4 Bit 7
sensor is connected to the RM2-ARD unit.
Table 8: Status bit
Assigned Registers & Channel #
assignment for Toxic sensor (ST series)
Toxic
Power up
Toxic (ST series)
Sensor fault
output
ĐŽŶĚŝƟons
Toxic
Low Alarm activated
Toxic
High
Alarm activated
outputs.
Register 40003 (Channel 1)
Register 40004 (Channel 2
RM2-ARD
xxxx xxxx
0001 0010 xxxx xxxx 0010 xxxx xxxx
0010
0010 xxxx xxxx
0100
1000
0010
Bit 4 Bit 7
xxxx xxxx 0001 0010 xxxx xxxx
)
0010 0010 xxxx xxxx
0100 0010 xxxx xxxx
1000 0010
19
FIRE: Modbus Registers and Status bit assignment
Fire detection: The table below shows the status registers and bit assignments for various outputs when a Fire head is connected to
the RM2-ARD unit. Outputs are indicated by address of 40001 and 40002 registers.
Table9:StatusbitassignmentforFireheadoutput conditions
Assigned Registers & Channel #
Register 40001 (Channel 1)
Register 40002
(Channel 2)
Fire head
Power up
xxxx 0000 0000 0001 xxxx 0000 0000 0100 xxxx 0000 0000 1000 xxxx 0000 0001 0000 xxxx 0000 0010 0000
xxxx 0000 0000 0001 xxxx 0000 0000 0100 xxxx 0000 0000 1000 xxxx 0000 0001 0000 xxxx 0000 0010 0000
Normal operation Fire head
fault
Background IR
Energy(8.0 mA)
Note: Status bits for output due to Self test failure (notyet used) will be xxxx xxxx 0000 0010
Table9(cont’d):StatusbitassignmentforFireheadoutput conditions
Assigned Registers & Channel #
Register 40001 (Channel 1)
Register 40002
(Channel 2)
Instant fire warning
xxxx 0000 0100 0000 xxxx 0000 1000 0000 xxxx 0001 0000 0000 xxxx 0010 0000 0000
xxxx 0000 0100 0000 xxxx 0000 1000 0000 xxxx 0001 0000 0000 xxxx 0010 0000 0000
Fire present
Channel bypassed, (available only if
both channel are set for fire)
Sensor power OFF (loss of power from
Fire head)
Background UV
Energy(6.0 mA)
Note: Channel bypass is only available if both channels are set for fire.
 20
RM2ͲARD
Net Safety Monitoring Inc
STEP 5 — MAINTAIN
SENSORS—Periodic Response Test
We recommend the sensors be verified or calibrated every 3 months. A typical response check involves the application of calibration gas to the sensor, then the observation of the response LEDs, analog output, display and external monitoring equipment. Be sure to prevent unwanted response of external monitoring devices and equipment during this procedure. If the response to calibration gas is within its specified accuracy then it is not necessary to perform a calibration. For example, when 50% of full scale is applied, the response is expected to be between 11.5 mA (47% of full scale) and 12.5 mA (53% of full scale). An additional consideration is the accuracy tolerance of the calibration gas which may be + or - a few percent. If the calibration gas is + or ­10% of full scale then the reading may be from 10.7 mA (42% of full scale) to
13.3 mA (58% of full scale).
TROUBLESHOOT
- Response to the input should be checked and, if necessary, calibration should be performed whenever any of the following occur. Refer to "Calibration" on page 10 for calibration instructions.
•Excess negative drift is indicated by 2.5 mA current output
•Sensor or controller/transmitter is connected or disconnected
•Long term or high concentration exposure to gas
- The RM2 is not designed to be repaired in the field. If a problem should develop, first calibrate the device and carefully check for faulty wiring. If it is determined that the problem is caused by an electronic failure, the device must be returned to the factory for repair. Refer "How to Return Equipment" on page 22 for detailed instructions.
- Apparent sensor failure (see "Calibration Failure/Interruption" on page 11) may occur if calibration process has begun but span gas is not applied when prompted or if span gas is removed during calibration process. Perform a manual reset (refer to "Manual Reset" on page 11) and re-calibrate sensor.
- If Front Panel buttons appear non-responsive when set up at Front Panel is interrupted by an attempt to also set up using Terminal). DOES NOT affect detection functionality.
recycle power. (Can occur
- Consult the manual supplied with the Fire Head, Millennium or Uni-Tran for further troubleshooting information.
RM2-ARD 21
Net Safety Monitoring Inc.
HOW TO RETURN EQUIPMENT
A Material Return Authorization number is required in order to return equipment. Please contact Net Safety Monitoring at (403) 219-0688 returning equipment or consult our Service Department to possibly avoid returning equipment.
If you are required to return equipment, include the following information:
1. A Material Return Authorization number (provided over the phone to you by Net Safety).
2. A detailed description of the problem. The more specific you are regarding the problem, the quicker our Service department can determine and correct the problem.
3. A company name, contact name and telephone number.
4. A Purchase Order, from your company, authorizing repairs or request for quote.
5. Ship all equipment, prepaid to:
Net Safety Monitoring Inc
2721 Hopewell Place NE Calgary, Alberta, Canada
T1Y 7J7
6. Mark all packages: RETURN for REPAIR
before
SPARE PARTS/ACCESSORIES
Table 10:Part Numbering
computer to front of RM2-ARD for event logging, downloading and configuring the unit.
M
rebmuNtraPytefaSteNnoitpircseD
TIK-MOC-2MRtit : Cable to connect KsnoitacinummoC
Waybills, for shipments from outside Canada, must state:
Equipment being returned for repair All charges to be billed to the sender
Also, please ensure a duplicate copy of the packing slip is enclosed inside the box indicating item 1-4 along with the courier and account number for returning the goods.
All Equipment must be Shipped prepaid. Collect shipments will not be accepted.
Pack items to protect them from damage and use anti-static bags or aluminum­backed cardboard as protection from electrostatic discharge.
RM2-ARD 22
Net Safety Monitoring Inc
Appendix A: E
LECTROSTATIC SENSITIVE DEVICE (ESD)
Electrostatic discharge (ESD) is the transfer, between bodies, of an electrostatic charge caused by direct contact or induced by an electrostatic field.
The most common cause of ESD is physical contact. Touching an object can cause a discharge of electrostatic energy occurs near electronic components, it can damage or destroy those components.
In some cases, damage is instantaneous and an immediate malfunction occurs. However, symptoms are not always immediate or seemingly normal for an indefinite period of time, followed by a sudden failure.
To eliminate potential ESD damage, review the following guidelines:
—ESD! If the charge is sufficient and
—performance may be marginal
• Handle boards by metal shields
components
• Wear grounded wrist or foot straps, or ESD shoes or heel grounders to
dissipate unwanted static energy
• Prior to handling boards, dispel any charge in your body or equipment
• Ensure components are transported and stored in static safe packaging
• When returning boards, carefully package in the original carton and static
protective wrapping
• Ensure ALL personnel are educated and trained in ESD Control Procedures
In general, exercise accepted and proven precautions normally observed when handling electrostatic sensitive devices.
A warning label is placed on the packaging, identifying product using electrostatic sensitive semiconductor devices.
taking care not to touch electronic
RM2-ARD 23
Net Safety Monitoring Inc.
Appendix B: RESISTANCE TABLE (Ohms)
Distance (Feet) AWG #20 AWG #18 AWG #16 AWG #14 AWG #12 AWG #10 AWG #8
100 1.020.640.400.250.160.100.06
200 2.031.280.800.510.320.200.13
300 3.051.921.200.760.480.300.19
400 4.062.551.611.010.640.400.25
500 5.083.202.011.260.790.500.31
600 6.093.832.411.520.950.600.38
700 7.11 4.47 2.81 1.77 1.11 0.70 0.44
800 8.125.113.212.021.270.800.50
900 9.145.753.612.271.430.900.57
1000 10.20 6.39 4.02 2.53 1.59 1.09 0.63
1250 12.70 7.99 5.03 3.16 1.99 1.25 0.79
1500 15.20 9.58 6.02 3.79 2.38 1.50 0.94
1750 17.80 11.20 7.03 4.42 2.78 1.75 1.10
2000 20.30 12.80 8.03 5.05 3.18 2.00 1.26
2250 22.80 14.40 9.03 5.68 3.57 2.25 1.41
2500 25.40 16.00 10.00 6.31 3.97 2.50 1.57
3000 30.50 19.20 12.00 7.58 4.76 3.00 1.88
3500 35.50 22.40 14.10 8.84 5.56 3.50 2.21
4000 40.60 25.50 16.10 10.00 6.35 4.00 2.51
4500 45.70 28.70 18.10 11.40 7.15 4.50 2.82
5000 50.10 32.00 20.10 12.60 7.94 5.00 3.14
5500 55.80 35.10 22.10 13.91 8.73 5.50 3.46
6000 61.00 38.30 24.10 15.20 9.53 6.00 3.77
6500 66.00 41.50 26.10 16.40 10.30 6.50 4.08
7000 71.10 44.70 28.10 17.70 11.10 7.00 4.40
7500 76.10 47.90 30.10 19.00 12.00 7.49 4.71
8000 81.20 51.10 23.10 20.20 12.70 7.99 5.03
9000 91.40 57.50 36.10 22.70 14.30 8.99 5.65
10 000 102.00 63.90 40.20 25.30 15.90 9.99 6.28
Note: Resistance shown is one way. This figure should be doubled when determining closed loop resistance.
RM2-ARD 24
Net Safety Monitoring Inc
Appendix C: RM2 SPECIFICATIONS
MILLENNIUM RM2-ARD (ANALOG / RELAY / DIGITAL)
Operating Voltage 10.5 Vdc to 32 Vdc
Power Consumption 12 Vdc nominal 150 mA/250 mA (1.8 W/3.0 W) de-energized/energized maximum 290 mA/3.48 W
Power Consumption 24 Vdc nominal 80 mA/130 mA (1.92 W/3.12 W) de-energized/energized maximum 160 mA/3.84 W
In-Rush Current
RM2-ARD without Sensors RM2-ARD with 2 UV/IRS connected
Low Alarm Energized High Alarm Energized
0.27A / 12 Vdc
0.15A / 24 Vdc
0.11A / 32 Vdc
Operating Temperature
Humidity Range 0-100% relative humidity, non-condensing
Chassis Material 16 gauge steel / powder coated or chromatic
Weight 2 lbs (0.9 kilograms)
Certifications
Current Outputs-2 channel
Relay Output-5 relays
Low Alarm De- Energized High Alarm De-Energized
0.23A / 12 Vdc
0.12A / 24 Vdc
0.09A / 32 Vdc
-40
°C to +80°C (-40F to +176F)
CSA and NRTL/C for hazardous locations. Class 1, Division 2, Groups A, B, C and D Factory Mutual (FM) certified to Class 3260 for performance in fire alarm systems
4 to 20 mA - Into a maximum loop impedance of 800 Ohms at 32 Vdc or 150 Ohms at 10.5 Vdc. Isolated or non­isolated loop supply.
Form C contacts rated 5 Amps at 30 Vdc / 250 V ac. Selectable energized/de-energized, latching/non-latching Fire Relay. Fault relay is factory set as energized, non-latching and can not be modified.
Low Alarm Energized High Alarm Energized
0.7A / 12 Vdc
0.42A / 24 Vdc
0.35A / 32 Vdc
In-Rush Current
Low Alarm De- Energized High Alarm De-Energized
0.7A / 12 Vdc
0.42A / 24 Vdc
0.34A / 32 Vdc
Digital Output
RM2-ARD 25
Digital output available via terminals 19 and 20 (A and B) for Modbus communication.
Net Safety Monitoring Inc., 2721 Hopewell Place NE
Calgary, Alberta, Canada T1Y 7J7 Telephone:
www.net-safety.com
E-mail:
nsmsales@net-safety.com
Fax: (403) 219-0694(403) 219-0688
Loading...
