Net Safety™ Millennium

Air Particle Monitor (APM) Oil Mist Detector

Reference Manual

00809-0100-4077, Rev AE

September 2019

Important instructions

Because these products are sophisticated technical instruments, it is important that the owner and operation personnel must
strictly adhere both to the information printed on the product nameplate and to all instructions provided in this manual prior to
installation, operation, and maintenance.

WARNING

Follow instructions

Installing, operating, or maintaining this product improperly could lead to serious injury or death from explosion or exposure to
dangerous substances.

Comply with all information on the product, in this manual, and in any local or national codes that apply to the product.
Do not allow untrained personnel to work with this product.
The information in this document has been carefully checked and is believed to be entirely reliable with all the necessary

information included.
All individuals who have or will have responsibility for using, maintaining, or servicing the product must read this manual

carefully.

CAUTION

Equipment repairs

The detector is not field repairable due to the meticulous alignment and calibration of the sensors and the respective circuits. Do
not repair the detector in the field.

WARNING

Physical access

Unauthorized personnel may potentially cause significant damage to and/or misconfiguration of end users’ equipment. This could
be intentional or unintentional and needs to be protected against.

Physical security is an important part of any security program and fundamental to protecting your system. Restrict physical access
by unauthorized personnel to protect end users’ assets. This is true for all systems used within the facility.

2

Warranty

1. Limited Warranty . Subject to the limitations contained in Section 2 (Limitation of Remedy and Liability) herein, Seller
warrants that (a) the licensed firmware embodied in the Goods will execute the programming instructions provided by
Seller; (b) that the Goods manufactured by Seller will be free from defects in materials or workmanship under normal use
and care; and (c) Services will be performed by trained personnel using proper equipment and instrumentation for the
particular Service provided. The foregoing warranties will apply until the expiration of the applicable warranty period.
Sensors and detectors are warranted against defective parts and workmanship for 24 months from the date of purchase
and other electronic assemblies for 36 months from the date of purchase. Products purchased by Seller from a third party
for resale to Buyer (Resale Products) shall carry only the warranty extended by the original manufacturer. Buyer agrees
that Seller has no liability for Resale Products beyond making a reasonable commercial effort to arrange for procurement
and shipping of the Resale Products. If Buyer discovers any warranty defects and notifies Seller thereof in writing during
the applicable warranty period, Seller shall, at its option, (i) correct any errors that are found by Seller in the firmware or
Services; (ii) repair or replace FOB point of manufacture that portion of the Goods found by Seller to be defective; or (iii)
refund the purchase price of the defective portion of the Goods/Services. All replacements or repairs necessitated by
inadequate maintenance; normal wear and usage; unsuitable power sources or environmental conditions; accident;
misuse; improper installation; modification; repair; use of unauthorized replacement parts; storage or handling; or any
other cause not the fault of Seller are not covered by this limited warranty and shall be replaced or repaired at Buyer's sole
expense, and Seller shall not be obligated to pay any costs or charges incurred by Buyer or any other party except as may
be agreed upon in writing in advance by Seller. All costs of dismantling, reinstallation, freight, and the time and expenses
of Seller's personnel and representatives for site travel and diagnosis under this limited warranty clause shall be borne by
Buyer unless accepted in writing by Seller. Goods repaired and parts replaced by Seller during the warranty period shall be
in warranty for the remainder of the original warranty period or 90 days, whichever is longer. This limited warranty is the
only warranty made by Seller and can be amended only in a writing signed by an authorized representative of Seller. The
limited warranty herein ceases to be effective if Buyer fails to operate and use the Goods sold hereunder in a safe and
reasonable manner and in accordance with any written instructions from the manufacturers. THE WARRANTIES AND
REMEDIES SET FORTH ABOVE ARE EXCLUSIVE. THERE ARE NO REPRESENTATIONS OR WARRANTIES OF ANY KIND,
EXPRESSED OR IMPLIED, AS TO MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, OR ANY OTHER MATTER WITH
RESPECT TO ANY OF THE GOODS OR SERVICES.

Limitation of Remedy and Liability SELLER SHALL NOT BE LIABLE FOR DAMAGES CAUSED BY DELAY IN PERFORMANCE.

2.
THE REMEDIES OF BUYER SET FORTH IN THE AGREEMENT ARE EXCLUSIVE. IN NO EVENT, REGARDLESS OF THE FORM OF
THE CLAIM OR CAUSE OF ACTION (WHETHER BASED IN CONTRACT, INFRINGEMENT, NEGLIGENCE, STRICT LIABILITY,
OTHER TORT, OR OTHERWISE), SHALL SELLER'S LIABILITY TO BUYER AND/OR BUYER'S CUSTOMERS EXCEED THE PRICE TO
BUYER OF THE SPECIFIC GOODS MANUFACTURED OR SERVICES PROVIDED BY SELLER GIVING RISE TO THE CLAIM OR
CAUSE OF ACTION. BUYER AGREES THAT IN NO EVENT SHALL SELLER'S LIABILITY TO BUYER AND/OR BUYER'S CUSTOMERS
EXTEND TO INCLUDE INCIDENTAL, CONSEQUENTIAL OR PUNITIVE DAMAGES. THE TERM "CONSEQUENTIAL DAMAGES"
SHALL INCLUDE, BUT NOT BE LIMITED TO, LOSS OF ANTICIPATED PROFITS, REVENUE OR USE AND COSTS INCURRED,
INCLUDING WITHOUT LIMITATION FOR CAPITAL, FUEL AND POWER, AND CLAIMS OF BUYER'S CUSTOMERS.

3

4

Reference Manual

00809-0100-4077 September 2019

Introduction

1 Introduction

1.1 Models covered

The Net Safety™ Air Particle Monitor (APM) is an infrared optical detector used in
hazardous industrial applications to monitor ambient air for the presence of particulate
matter from products of combustion, such as carbon, air particulate matter, or ash.

The Net Safety Millennium Transmitter is an environmentally protected electronic
package contained within an explosion-proof housing. With its scrolling eight-character
display and status LEDs, it provides instructions and status alerts.

The Net Safety APM Sensor is mounted where airborne particles are anticipated to
accumulate, while the Net Safety Millennium Transmitter is located conveniently at eye
level.

The product is available in stainless steel (SS).

Models available are:

• MLP-AR-APM-OP-SS: APM, 4-20 mA analog output with alarm and fault relays, stainless

steel housing, CSA approved

• MLP-AR-APM-OP-SS-X: APM, 4-20 mA analog output with alarm and fault relays,

stainless steel housing, CSA, ATEX, and IECEx approved

1.2 Service support

You can get technical support for this product by contacting your local Emerson/Net
Safety representative or by contacting the Net Safety Technical Support department at:
Toll Free [phone] or [e-mail].

1.3 Return of material

To expedite the repair and return of this product, proper communication between the
customer and the factory is important.

Prerequisites

Before returning a product for repair, call [phone] (toll free) or email

[e-mail] for a Return Material Authorization (RMA) number.

On the return of the equipment, include the following information:

1. RMA number provided to you by Net Safety.

2. Company name and contact information.

3. Purchase order, from your company, authorizing repairs or request for quote.

Procedure

1. Ship all equipment, prepaid to:

Net Safety Millennium Air Particle Monitor 5

Introduction Reference Manual

September 2019 00809-0100-4077

Emerson Automation Solutions

6021 Innovation Blvd

Shakopee, MN 55379

2. Mark all packages with Return for Repair and include RMA number and type of return

(e.g., return for evaluation).
Pack items to protect them from damage and use anti-static bags or aluminum-

backed cardboard as protection from electrostatic damage.

Important

Ship all equipment prepaid. Emerson will not accept collect shipments.

1.4 Product recycling/disposal

Consider recycling equipment and packaging and dispose of them in accordance with
local and national legislations/regulations.

6 Emerson.com/Rosemount

Reference Manual

00809-0100-4077 September 2019

Install

2 Install

2.1 Unpack and inspect

Carefully remove all of the components from the packaging and verify them against the
enclosed packing list. Inspect all components for any obvious damage such as broken or
loose parts. If you find any components missing or damaged, notify your local Emerson
representative or the factory immediately. Figure 2-1 outlines the components supplied
with the Net Safety™ APM.

Figure 2-1: Net Safety APM Components

A. Housing cover
B. Net Safety Millennium housing
C. Junction box

D. ¾-in. national pipe thread (NPT)

E. ¾-in. NPT

F. Earth ground screw
G. ¾-in. NPT
H. Optical path

I. Net Safety Air particle monitor (APM)
J. Internal window/sensor chamber

K. Optical path protector plate. Uncrew to clean. Refer to Clean sensor for cleaning

instructions.

L. Net Safety Millennium faceplate

Net Safety Millennium Air Particle Monitor 7

Install Reference Manual

September 2019 00809-0100-4077

2.2 Locate sensor

Prior to the installation process, develop a location plan for placing the Net Safety APM
Sensor and Transmitter. Proper location of the sensor is essential for providing maximum
protection. The most effective placement and number of detectors vary depending upon
conditions. Consider the following points when planning the installation.

• Carefully locate the sensor in an area where particulate may potentially accumulate.

• Locate the sensor where it is safe from potential sources of contamination, such as oil

film, dirt, etc.

• Locate the transmitter where it will be accessible and visible.

• Mount the sensor so air currents allow particulate to flow into the optical path of the

sensor.

• If the particulate is expected to be moving horizontally due to air currents, orient the

sensor for maximum detection as shown in Figure 2-1.

• Avoid exposure to excessive heat or vibration whenever possible, because this can

cause premature failure of electronic devices.

• Seek advice from experts and refer to various regulatory publications that discuss

general guidelines for your industry.

• The detector works off of the principle of infrared energy being reflected off of

particulate matter passing through the optical path of the detector. Therefore, give
careful consideration when installing the detector to ensure that external infrared light
does not reach the sensing element.

Figure 2-2 illustrates a typical installation of a Net Safety APM sensor and transmitter. The

sensor is mounted separately from the transmitter using the supplied junction box. The
transmitter is located at eye level, while the sensor is located where particles are most
likely to accumulate. The conduit then connects the two devices.

8 Emerson.com/Rosemount

Reference Manual

00809-0100-4077 September 2019

Figure 2-2: Typical Installation

Install

A. Conduit connecting junction box and controller
B. Controller/transmitter mounted at eye level
C. Particulate matter

D. Junction box

E. Net Safety APM sensor positioned so air current allows particulate matter to flow into

sensor

F. Net Safety APM sensor

2.3 Dimensions

The following figures outline the dimensions of the Net Safety APM connected directly to
the Net Safety Millennium Transmitter (Figure 2-3) or when connected directly to the
multi-purpose junction box (Figure 2-4). There are three ¾-in. national pipe thread (NPT)
conduit entries available on the transmitter. Adapters for M20 and ½-in. NPT threads are
also available as spare parts.

Net Safety Millennium Air Particle Monitor 9

Install Reference Manual

September 2019 00809-0100-4077

Figure 2-3: Transmitter Dimensions

Dimensions in inches [millimeters].

A. ¾-in. female national pipe thread (FNPT) cable entry
B. ¾-in. FNPT cable

10 Emerson.com/Rosemount

Reference Manual Install

00809-0100-4077 September 2019

Figure 2-4: Junction Box and Sensor Dimensions

Net Safety Millennium Air Particle Monitor 11

Install

September 2019 00809-0100-4077

Reference Manual

Dimensions in inches [millimeters].

A. Bracket mounting holes (four places)

2.4 Mount

The sensor must be mounted directly to either a transmitter or to a separate junction box
through a ¾-in. national pipe thread (NPT) conduit entry. Both the transmitter and
junction boxes have mounting holes to allow mounting to a wall or pole as desired.
Mounting kit hardware is required when mounting the transmitter or junction box to a
pole. Contact your local Net Safety representative for detailed information on the pole
mounting kits.

Mount the transmitter at eye-level and make it easily accessible for monitoring and
maintenance purposes. Place the sensor where particles are likely to accumulate and
across the direction of the airflow to allow the particulates to pass through the optical
path. To prevent water damage, seal conduit at all points of entry to the transmitter or
junction box.

Emerson recommends mounting the sensor such that the air flow will pass through the
optical path of the sensor as shown in Figure 2-5.

12 Emerson.com/Rosemount

Reference Manual

00809-0100-4077 September 2019

Note

The detector works off of the principle of infrared energy being reflected off of particulate
matter passing through the optical path of the detector. Therefore, give careful
consideration when installing the detector to ensure that external infrared light does not
reach the sensing element.

Sudden bursts of infrared light may affect the detector; therefore, Emerson recommends
putting a time delay (between two and five seconds) into the monitoring system to
prevent nuisance alarms.

Figure 2-5: Net Safety APM Mounting Locations

Install

A. Net Safety APM sensor with junction box
B. Movement of air particulate matter
C. Net Safety APM sensor with junction box

D. Net Safety APM sensor with junction box

2.4.1

Net Safety Millennium Air Particle Monitor 13

Duct mount

Although the Net Safety™ Monitoring APM has been proven to detect particulate matter
travelling at speeds of up to 65.62 feet per second (20 meters per second), the detector is
virtually unaffected by the velocity of particulate and air that it is exposed to. Based on the
application and the speed of the particulate matter, you can perform a zero and adjust the
sensitivity settings to suit the application.

Net Safety recommends using the detector with the UDM-001 or UDM-002 sample draw
system to acquire a cross-sectional sample of air and particulate moving through ducts.

Install Reference Manual

September 2019 00809-0100-4077

The sample is drawn through perforations along the inlet pipe into a chamber where the
Net Safety APM is mounted. Particulate matter from the outlet pipe is then returned to the
duct. Refer to Figure 2-6 and the UDM-001/UDM-002 reference manual (MAN-0116) for
more information.

Figure 2-6: Air Flow Drawing

A. Duct surface
B. Conduit to controller
C. Junction box

D. Net Safety APM sensor

E. UDM-001/UDM-002 duct mount

F. Broken lines indicate direction of air flow
G. Direction of outlet air sample
H. Outlet pipe

I. Perforated sample draw tube (inlet pipe)
J. Direction of air sample flow

14 Emerson.com/Rosemount

Reference Manual

00809-0100-4077 September 2019

Install

2.5 Wire

2.5.1 Install in field

WARNING

Electrical shock

Electrical shock could cause death or serious injry

Ensure that only qualified personnel perform the installation.
Use extreme caution when making contact with the leads and terminals.
Do not open the transmitter, sensor, or junction box enclosure when in a classified area

or where an explosive atmosphere may be present unless the power to the transmitter
has been removed.

Avoid touching electronic components as they are susceptible to electrostatic
discharge (ESD). Refer to Electrostatic sensitive device for more information.

Avoid contact with the non-metallic enclosure label as contact may create an
electrostatic charging hazard.

2.5.2

NOTICE

Wiring codes and regulations may vary. ATEX requires that supply connections wiring
must be rated at least 5 °C above the maximum ambient temperature of 185 °F (85 °C).
Wiring must comply with all applicable regulations relating to the installation of electrical
equipment in a hazardous area and is the installer's responsibility. If in doubt, consult a
qualified official before wiring the system.

When separating the sensor from the transmitter, Emerson highly recommends the use of
shielded cable to protect against interference caused by extraneous electrical or
electromagnetic noise to meet mandatory CE mark electromagnetic compatibility (EMC)
requirements. In applications where the wiring is installed in conduit, do not use the
conduit for wiring to other equipment.

Seals

Emerson recommends using seals to further protect the system against any unwanted
water ingression and installing equipment according to applicable local electrical codes.
Emerson especially recommends seals for installations that use high-pressure or steam
cleaning devices in proximity to the transmitter and/or sensor.

• Emerson recommends water-proof and explosion-proof conduit seals to prevent water

accumulation within the enclosure.

• Locate seals as close to the device as possible and not more than 18 in. (46 cm) away.

• Explosion-proof installations may require an additional seal where conduit enters a

non-hazardous area. Ensure conformity with local wiring codes.

• When pouring a seal, use a fiber dam to assure proper formation of the seal. Never

pour seals at temperatures below freezing.

Net Safety Millennium Air Particle Monitor 15

Install Reference Manual

September 2019 00809-0100-4077

• Strip back the jacket and shielding of the cable to permit the seal to form around the

individual wires. This will prevent air, particles, and water leakage through the inside of
the shield and into the enclosure.

• Emerson recommends using explosion-proof drains and conduit breathers. In some

applications, alternate changes in temperature and barometric pressure can cause
breathing which allows moist air to enter and circulate inside the conduit. Joints in the
conduit system are seldom tight enough to prevent this breathing.

2.5.3 Separate sensor and transmitter

Since the sensor must be located where it will pick up particulate in an air flow and the
transmitter must be where it is easily reached, you may have to separate the transmitter
and sensor. Do this with the aid of the included sensor separation kit (SEP). This kit is
composed of a junction box and terminal strip. Refer to the Net Safety Multi-purpose

Junction Box manual (MAN-0081) for terminal designation.

The maximum separation distance between the sensor and the transmitter is limited by
the resistance of the connecting wiring, which is a function of the gauge of wire being
used. Net Safety recommends that sensor separation must not exceed 2,000 ft. (610 m)
while using 16 AWG (1.31 mm2) wire. Refer to Wire resistance table for wire gauges and
resistance values.

2.5.4

Note

When the sensor is separated from the transmitter, always ensure that the transmitter is
supplying the required voltage to the sensor terminals inside the junction box. If you are
not using a 4-20 mA signal, connect a jumper between the 4-20 terminal and the COM
terminal on the transmitter terminal board.

Assemble boards

There are three different fixed boards and a relay board which make up the PCB assembly.
Simply loosen the three locking standoffs, remove one board, insert the other board, and
tighten screws. The boards are susceptible to electrostatic discharge (ESD). Refer to

Electrostatic sensitive device for further information on proper handling of this

equipment.

16 Emerson.com/Rosemount

Reference Manual Install

00809-0100-4077 September 2019

Figure 2-7: Transmitter Module Boards

A. Terminal board
B. Option board
C. Sensor board

D. See Table 2-1

Table 2-1: Electromechanical Relay Board

PNO Fault Normally open

PCOM Common

PNC Normally closed

LNO Clean window (low) Normally open

LCOM Common

LNC Normally closed

HNO Alarm Normally open

HCOM Common

Net Safety Millennium Air Particle Monitor 17

Install

September 2019 00809-0100-4077

Table 2-1: Electromechanical Relay Board (continued)

HNC Normally closed

Reference Manual

2.5.5 Install to transmitter or junction box

The sensor is supplied with a ¾-in. national pipe thread (NPT) male conduit connection
and is intended to be mounted directly to an available ¾-in. NPT conduit entry on the
transmitter or remotely using the supplied junction box.

Tightly thread the sensor to the transmitter or junction box. Engage a minimum of seven
threads to ensure proper water ingress protection and the explosion proof rating of the
devices. Take proper care to ensure that no damage is caused to the wires on the sensor
and circuit board inside the transmitter and junction box.

Emerson recommends using conductive grease on the threads.

You can mount the sensor in a number of configurations to ensure that air particulate will
pass through the optical path of the sensor. Emerson recommends mounting the Net
Safety APM horizontally to ensure that build-up of dirt, dust, and debris will not affect the
operation of the sensor.

2.5.6

Rotate faceplate

In some applications, you may need to mount the transmitter in a non-standard
orientation. To accommodate such installations and ensure that the display will appear at
the correct angle for viewing, you can rotate the PCB assembly inside the transmitter’s
housing.

Figure 2-8 outlines non-standard orientations of the transmitter.

Figure 2-8: Non-standard Orientation

WARNING

Explosions

Do not open the transmitter, sensor, or junction box enclosure when in a classified area or
when an explosive atmosphere may be present unless the power to the transmitter has
been removed.

Refer to Figure 2-9 for the components in the transmitter housing. The boards may be
susceptible to ESD. Refer to Electrostatic sensitive device for further information on proper
handling of this equipment.

18 Emerson.com/Rosemount

Reference Manual

00809-0100-4077 September 2019

Install

Procedure

1. Remove the transmitter housing cover.

2. Turn the power to the transmitter off.

3. Unscrew both the knobs marked "Pull Here".

4. Lift the transmitter faceplate from the housing and allow to the faceplate to hang
from the ribbon cable.

5. Unscrew the two metal standoffs.

6. Carefully remove the PCB assembly from the housing.
The rotator plate is secured to the bottom of the housing and is accessible after the

PCB assembly has been removed.

7. Rotate the PCB assembly to the desired position and line up the standoffs with the
mounting holes.

8. Insert standoffs in the appropriate horizontal or vertical mounting holes.

9. Tighten standoffs to secure the PCB assembly.

10. Replace faceplate and tighten Pull Here knobs.

11. Return power to the detector and replace the housing cover.

Figure 2-9: PCB Assembly Rotated

A. Horizontal mounting holes
B. Faceplate
C. Ribbon cable

D. Standoffs

E. PCB assembly
F. Vertical mounting holes

Net Safety Millennium Air Particle Monitor 19

Install Reference Manual

September 2019 00809-0100-4077

2.5.7 General requirements

WARNING

Explosions

Do not open the transmitter, sensor, or junction box enclosure when in a classified area or
when an explosive atmosphere may be present unless the power to the transmitter has
been removed.

When connecting cable wires, use a small screwdriver to gently press down and hold the
spring connector open. Insert the appropriate wire into the open connector hole, releasing
the screwdriver to secure the wire as shown in Figure 2-10.

The connector accomodates wire sizes between 14 and 20 AWG.

Figure 2-10: Terminal Connection

2.5.8

Table 2-2: Sensor Wire Colors and Terminal Definition

Wire color White Blue Red Black Shield

Marking +24 Vdc Signal A Signal B COM(-) Shld

Function 10.5-32 Vdc

Wire sensor to transmitter

Connect the sensor wires to the transmitter as shown in Figure 2-11. Table 2-2 outlines the
wire colors and their purpose.

connection

Communication
signal A

Communication
signal B

Common / supply
ground

Earth ground

20 Emerson.com/Rosemount

Reference Manual

00809-0100-4077 September 2019

Figure 2-11: Sensor Wiring

Install

2.5.9

A. Terminal board
B. RST

+24 V
COM
4-20
ISO

C. White

Blue
Red
Black
Shield

D. Sensor wires

E. Sensor

F. Sensor board
G. Sensor terminals
H. Power terminals

Wire sensor to junction box

Sensor wiring side refers to wiring between the sensor and junction box. Transmitter
wiring side refers to wiring between the transmitter and junction box.

Net Safety Millennium Air Particle Monitor 21

Install Reference Manual

September 2019 00809-0100-4077

Figure 2-12: Junction Box Wiring (Model JB-MPD)

A. Resistor - 120 ohms
B. See Table 2-3
C. See Table 2-4

Note

Terminate the shield at earth ground at panel/PLC/DCS/RTU.

Table 2-3: Transmitter Wiring

Terminal Function/marking

1 (GND) Earth ground

2 Vdc (+)

3 COM (-)

4 Sig A

5 Sig B

6 Not used

7 Not used

Table 2-4: Sensor Wiring

Terminal Color Function

1 (GND) Green Earth ground

2 White Vdc (+)

3 Black COM (-)

4 Blue A (communication)

22 Emerson.com/Rosemount

Reference Manual Install

00809-0100-4077 September 2019

Table 2-4: Sensor Wiring (continued)

Terminal Color Function

5 Red B (communication)

6 N/A Not used

7 N/A Not used

2.5.10 Wire transmitter to control system

Connect the transmitter to the control system as shown in Figure 2-11. Table 2-5 outlines
the terminal marking and their purpose.

Table 2-5: Transmitter Connections

Marking Function

RST Remote reset

+24V 10.5-32 Vdc connection

COM Common/supply ground

4-20 Current loop output (mA)

+VISO +24 Vdc isolated 4-20 power

2.5.11 External ground

In order to ensure proper operation of the sensor, Emerson recommends connecting an
external ground to the grounding point on the enclosure. Refer to Figure 2-13 for
grounding connection location.

Net Safety Millennium Air Particle Monitor 23

Install Reference Manual

September 2019 00809-0100-4077

Figure 2-13: External Grounding Point

2.6 Current output

To set the current output, simply move the jumper located on the terminal board near the
power terminals, to the isolated or non-isolated current position. Refer to Figure 2-14.

Note

Unless otherwise specified, all models ship with this jumper in the non-isolated current
position (Pin 2 and Pin 3 jumped). Refer to Figure 2-14.

24 Emerson.com/Rosemount

Reference Manual Install

00809-0100-4077 September 2019

Figure 2-14: Jumper Locations

A. Jumper positions to set power source for current output.

Isolated and non-isolated current jumper - place jumper (shorting jack) over Pin 3 and
Pin 2 (default position) for non-isolated configuration (source).

B. Place jumper over Pin 1 and Pin 2 for remaining configurations. Refer to Figure 2-1.

2.7 Non-isolated and isolated power configurations

For current source using non-isolated configuration, the jumper must remain in the
default position (Pin 2 and Pin 3 jumped). The jumper is placed over Pin 1 and Pin 2 for
current sink using non-isolated configuration.

For isolated configuration using a separate power supply to isolate the current loop, the
jumper must be placed over Pin 1 and Pin 2 for source and sink. Refer to Figure 2-15,

Figure 2-16, Figure 2-17, and Figure 2-18.

Note the jumper position for each configuration.

Net Safety Millennium Air Particle Monitor 25

Install Reference Manual

September 2019 00809-0100-4077

Figure 2-15: Detector Non-Isolated Configuration (Source)

A. Isolated and non-isolated jumper pins

Figure 2-16: Detector Non-Isolated Configuration (Sink)

A. Isolated and non-isolated jumper pins

26 Emerson.com/Rosemount

Reference Manual

00809-0100-4077 September 2019

Install

Figure 2-17: Detector Isolated Configuration (Source)

A. Isolated and non-isolated jumper pins

Figure 2-18: Detector Isolated Configuration (Sink)

A. Isolated and non-isolated jumper pins

Net Safety Millennium Air Particle Monitor 27

Install Reference Manual

September 2019 00809-0100-4077

2.8 Installation checklist

Review the following checklist prior to turning the power on to the transmitter after
installation has been completed:

• Ensure that the transmitter and sensor are properly and firmly mounted.

• Ensure that stopping plugs are securely tightened on any unused conduit entries.

• Ensure that the transmitter and sensor are not obstructed, such that they are

accessible and the particulate matter is not inhibited from reaching the sensors optical
path.

• Ensure adherence to applicable local guidelines and requirements on wiring and

sealing of equipment in hazardous and non-hazardous areas.

• Ensure that proper shielding and grounding practices are adhered to and local codes

are being followed.

• Check system operational voltage and conditions and ensure that they are within the

applicable specifications of the transmitter and sensor.

• Verify wiring at all termination and junction points (transmitter, junction box, and

power supply).

• Ensure that the transmitter housing cover and sensor cap are tightly secured.

28 Emerson.com/Rosemount

Reference Manual

00809-0100-4077 September 2019

Operation

3 Operation

3.1 Transmitter components

WARNING

EXPLOSION

Do not open the transmitter, sensor, or junction box enclosure when in a classified area or
when an explosive atmosphere may be present unless the power to the transmitter has
been removed.

Figure 3-1 outlines the components on the transmitter, and the subsequent sections

provide explanations for each component.

Figure 3-1: Transmitter Layout

A. Display
B. Status LED
C. Setup button

D. Current output check,

E. On/Off switch
F. Magnetic reed switch

Net Safety Millennium Air Particle Monitor 29

Operation

September 2019 00809-0100-4077

Reference Manual

3.1.1 Display

The transmitter comes with a scrolling eight character display to show various status
messages and prompts.

Refer to Table 3-1 for the various display messages.

3.1.2 Status LED

The status LED provides a visual indication of the status of the transmitter and sensor.

Refer to Indications and outputs for specific status conditions of the LED.

3.1.3 On/Off switch

Use the On/Off switch to turn power to the transmitter and sensor on and off.

As the transmitter’s housing must be opened to access the On/Off switch, make sure to
de-classify the area where the transmitter is located prior to using the switch.

3.1.4

3.1.5

3.1.6

Setup button

The Setup button provides access to the transmitter's main menu, which in turn allows
options to be reviewed and set. You can also use the Setup button to zero the sensor.

As the transmitter’s housing must be opened to access the button, make sure to de­classify the area before using the button. Refer to Program for instructions on
programming the transmitter.

Magnetic reed switch

Emerson provides the magnetic reed switch to avoid opening the housing in an
environment where gas may be present.

The magnetic reed switch functions in the same manner as the Setup button but in a non­intrusive manner. The magnet comes permanently attached to the side of the transmitter.

Check current output

Emerson provides current output check test jacks to facilitate current loop measurements
without breaking external current loop. To take current loop measurements, ensure wiring
is correct and current loop is closed, and then follow the steps below:

Procedure

1. Set meter on mA scale and insert meter leads into test jacks.

2. Put external devices in bypass, if necessary, to avoid unwanted alarm response.

3. Perform simulated tests to check output.

4. Remove meter leads from test jacks and return external devices to normal.

30 Emerson.com/Rosemount

Reference Manual Operation

00809-0100-4077 September 2019

3.2 Indications and outputs

Table 3-1: Transmitter Indications

State Current output Status LED Display

Main menu entered 3.0 mA Solid green Main menu items

Normal operation 4.0 mA Green blip Clear

Startup delay 3.0 mA Slow red flash Start delay

Dirty optics 3.3 mA Fast red flash Dirty chamber

Particulate present 20 mA Red blip Alarm

Fault condition 2.5 mA Fast red flash Fault

Updating sensor 3.0 mA Slow red flash Busy

3.3 Alarms

3.3.1 Transmitter fault

To ensure proper response, the transmitter features self-testing circuitry that continuously
checks for problems. When power is applied, the system automatically begins a test to
ensure proper functionality.

During normal operation, the transmitter continuously monitors the signal from the
internal Net Safety™ APM source. If the transmitter determines that the Net Safety APM
program is not running correctly, it will reset the sensor.

3.3.2

Clean window/dirty chamber

Over an extended period, oily film or particulate build-up on the sensor window may
obscure the detector. When dirty, the Clean window alarm trips, the message Dirty

Chamber displays, the Status LED flashes fast red, and the current output is 3.3 mA.

Refer to Set sensitivity to define the clean window sensitivity and Clean sensor for
instructions on cleaning the Net Safety APM window.

Net Safety Millennium Air Particle Monitor 31

Operation Reference Manual

September 2019 00809-0100-4077

3.3.3 Particulate alarm

When particulate is present in the detector's chamber, the message Alarm displays, the
Status LED blips red, and the current output is 20.0 mA.

If the relay has been set to non-latching, the unit resets itself; if set to latching, a manual or
remote reset is required to clear the alarm condition. Refer to Reset.

Note

Sudden bursts of infrared light may affect the detector; therefore, Emerson recommends
that a time delay (between two and five seconds) be put into the monitoring system to
prevent nuisance alarms.

3.4 Reset

3.4.1 Remote reset

The detector is capable of remote reset.

A normally open push-button switch must be connected between the RST terminal and
the COM terminal on the terminal board. If relay is set to Latching, a remote reset is
possible.

3.4.2

Manual reset

If a relay is set to Latching, a manual reset is required to clear the alarm condition.

Simply place and hold the magnet against the reed switch or press and hold Setup for
three to five seconds. The detector returns to normal operation.

3.5 Normal

With no particulate present and no fault detected, the display reads Clear, Status LED
blips/blinks green, and the current output is 4.0 mA.

3.6 Outputs

3.6.1 Relays

All relay outputs have FORM-C SPDT contacts rated 5 amperes at 30 Vdc/250 Vac. Relays
are dry contacts.

32 Emerson.com/Rosemount

Reference Manual Operation

00809-0100-4077 September 2019

3.6.2 Current

The detector uses a 4-20 mA dc current output to transmit the alarm status and fault
conditions to other devices.

You can wire this output for isolated or non-isolated operation. A 4.0 mA output indicates
normal operation; a 20.0 mA output indicates that the alarm threshold has been
exceeded. Current output of 2.5 mA indicates the presence of a system fault. Current
output of 3.3 mA indicates a build-up of particulate in the sensor’s chamber or dirty
window. Refer to Indications and outputs for additional indications and outputs.

3.7 Sensor

3.7.1 Power up sensor

When the transmitter applies power to the sensor, a warm-up routine begins, and the
sensor is automatically tested to ensure proper functioning.

The warm-up time for the sensor is typically 150 seconds. After the warm-up cycle has
completed, the display reads Clear.

3.7.2

As part of the self-diagnostic routine of the transmitter, the analog output outputs 20 mA
on initial power up for a period not greater than 450 milliseconds. If routine power loss is
expected on the system, take appropriate actions to limit false alarm conditions due to
this diagnostic routine.

Sensor communication

The Net Safety APM sensor uses a proprietary protocol to communicate with the Net
Safety Millennium transmitter.

Never connect the Net Safety APM sensor to any device other than a Net Safety
Millennium transmitter. If any problems develop, please refer to Troubleshooting.

Net Safety Millennium Air Particle Monitor 33

Operation Reference Manual

September 2019 00809-0100-4077

34 Emerson.com/Rosemount

Reference Manual Program

00809-0100-4077 September 2019

4 Program

4.1 Main menu

The Main Menu provides access to various functional settings and viewing of current
settings. The following options/settings are available in the Main Menu.

• Set Zero

• Sensitivity Settings

• Review Relay Settings

• Set Relay Options

• Select Display Language

4.2 Access the main menu

There are two ways to access the Main Menu: the Setup button on the faceplate of the
transmitter or the magnetic reed switch.

• Press and hold the Setup button to access the Main Menu.

• Place and hold the magnet to the transmitter’s housing (10 o’clock position as shown

in Figure 3-1) to access the Main Menu.

4.3 Use the main menu

The following steps outline the actions required to navigate through the menu system.

Prerequisites

Ensure that the transmitter is turned on and that no fault is present. If a fault is present,
the menu system is not accessible.

Refer to Figure 4-1 for the programming flow chart for the transmitter.

Net Safety Millennium Air Particle Monitor 35

Program

September 2019 00809-0100-4077

Reference Manual

Figure 4-1: Programming Flowchart

Procedure

1. Press and hold Setup or hold the magnet next to the triangle on the faceplate as
shown in Figure 3-1 until the message Switch On displays and the countdown (10
to 0) finishes.
An option scrolls across the display followed by the prompt YES?

2. To set/view an option, press Setup or place the magnet to the reed switch at the

YES? prompt. If you do not wish to select that option, wait five (5) seconds until the

next option appears and then select YES?.
A selection is acknowledged with a flashing YES.

36 Emerson.com/Rosemount

Reference Manual Program

00809-0100-4077 September 2019

If no option is selected, the transmitter returns to the normal operational mode,
and the display reads Clear.

Important

When you enter the menu system, the current output changes to 3 mA. Ensure that
external systems are bypassed, as required, prior to entering the menu system.

4.3.1 Zero transmitter

If at any time the background particulate levels change, you may need to zero the
transmitter to the new levels. Emerson recommends zeroing every three months.

Important

After initial power-up, allow the unit to warm up for two to four hours before zeroing.

If the sensor has been in operation for a period of time, Emerson recommends that you
clean the window as outlined in Clean sensor.

Prerequisites

Be sure the Net Safety APM is energized up and is not indicating a fault (e.g., the display
reads Clear, the status LED is blinking green, and the current output is 4.0 mA). Prior to

zeroing, ensure that the air surrounding the transmitter is clean and free of particulate or
at the accepted background level for the specific application.

Procedure

1. Press and hold Setup or hold the magnet to the reed switch to enter the Main
Menu; wait for the countdown, from 10 to 0, to end.

2. Release Setup or remove the magnet from the reed switch.

The current output moves to 3.0 mA.

3. When Set Zero and then YES? is displayed, press Setup or use the reed switch to
select this option.

A flashing YES confirms your selection.

The Net Safety APM has now been zeroed, meaning that the existing level of air
contamination is considered normal.

Tip

If your application has a constant level of particulate present that is required to be ignored
by the transmitter, you can set the zero level with the known particulate present as shown
in Figure 4-2.

To further fine tune the detector's response for your requirements, adjust the sensitivity
settings accordingly. Refer to Set sensitivity.

Net Safety Millennium Air Particle Monitor 37

Program

September 2019 00809-0100-4077

Figure 4-2: Zero Level Setting

Reference Manual

4.3.2 Set sensitivity

You can set the detector to detect low, medium, or high sensitivity levels (with high being
the most sensitive). By default, the factory sets the sensitivity to high. Follow the steps
below to change the sensitivity.

Procedure

1. Press and hold Setup or hold the magnet to the reed switch to enter the Main
Menu; wait for the countdown, from 10 to 0, to end.

2. Release Setup or remove the magnet from the reed switch.

The current output moves to 3.0 mA.

3. When Sensitivity Settings and then YES? is displayed, press Setup or use the
reed switch to select this option.

A flashing YES confirms your selection.

4. The following three options display:

• Low Sensitivity YES?

• Medium Sensitivity YES?

• High Sensitivity YES?

38 Emerson.com/Rosemount

Reference Manual

00809-0100-4077 September 2019

5. When the required setting is displayed, press Setup button or use the reed switch to
select.
The selection is acknowledged with a flashing YES.

Program

4.3.3 Review relay settings

This is a read-only mode to provide a summary of the relay settings. You cannot change
the relay settings from this menu.

Procedure

1. Press and hold Setup or hold the magnet to the reed switch to enter the Main
Menu; wait for the countdown, from 10 to 0, to end.

2. Release Setup or remove the magnet from the reed switch.
The current output moves to 3.0 mA.

3. When Review Relay Settings and then YES? is displayed, press Setup or use
the reed switch to select this option.

A flashing YES confirms the selection, and the transmitter displays the settings.

4.3.4

Set relay options

This section outlines how to change the normal operation of the Clean Window and Alarm
relays.

Follow the steps below to alter the relay functions or refer to Figure 4-1.

Note

The Fault Alarm relay settings are fixed as normally Energized and Non-Latching and are
not adjustable within the menu system.

Procedure

1. Press and hold Setup or hold the magnet to the reed switch to enter the Main
Menu; wait for the countdown, from 10 to 0, to end.

2. Release Setup or remove the magnet from the reed switch.
The current output moves to 3.0 mA.

3. When Set Relay Options and then YES? are displayed, press Setup or use the
reed switch to select.

A flashing YES confirms your selection. The messages Set Clean Window Alarm
and then YES? are displayed.

4. Press Setup or use the reed switch to select this option.
The flashing YES confirms this selection. After you choose the Clean Window Alarm
option, the message Coil Status is displayed followed by Energized YES?.

5. To select that the relay be energized under normal conditions, press Setup or use
the reed switch to select this option.

To select that the relay be de-energized under normal conditions wait five seconds
for the next selection.

If you selected Energized, a flashing YES confirms the selection.

Net Safety Millennium Air Particle Monitor 39

Program

September 2019 00809-0100-4077

6. To select that the relay be de-energized under normal conditions, press Setup or
use the reed switch to select this option.

If the relay is setup as required, wait five seconds for the next selection.
If you selected De-energized, a flashing YES confirms the selection. The display now

shows Latch Status, followed by Latching YES?.

7. To select that the relay be latched in its alarm state, press Setup or use the reed
switch to select this option.

To select that the relay be non-latching, wait five seconds for the next selection.
If you selected Latching, a flashing YES confirms the selection.

8. To select that the relay be non-latching, press Setup or use the reed switch to select
this option.

If the relay is setup as required, wait five (5) seconds for the next selection.
If you selected Non-latching, a flashing YES confirms the selection. The messages

Set Alarm and then YES? are displayed.

Reference Manual

4.3.5

Select display language

This section outlines how to change the main display language to English, Spanish, or
French. Follow the steps below to change the display language.

Procedure

1. Press and hold Setup or hold the magnet to the reed switch to enter the Main
Menu; wait for the countdown, from 10 to 0, to end.

2. Release Setup or remove the magnet from the reed switch.
The current output moves to 3.0 mA.

3. When Select Display Language and then YES? are displayed, press Setup or
use the reed switch to select.

A flashing YES confirms your selection. The messages English and then YES? are
displayed.

4. Press Setup or use the reed switch to select this option.
The flashing YES confirms this selection.

5. If English is not the desired language, wait five seconds for the next selection.
The messages Espanol and then YES? are displayed.

6. Press Setup or use the reed switch to select this option.
The flashing YES confirms this selection.

7. If Spanish is not the desired language, wait five seconds for the next selection.
The messages Francais and then YES? are displayed.

8. Press Setup or use the reed switch to select this option.
The flashing YES confirms this selection.

9. If French is not the desired language, wait five seconds for the next selection.

40 Emerson.com/Rosemount

Reference Manual

00809-0100-4077 September 2019

Maintenance

5 Maintenance

5.1 Check response

Emerson recommends checking and testing the Net Safety™ APM at least once every three
months.

Procedure

1. Spray Smoke Detector Tester (or equivalent product) in the direction of the sensor.

CAUTION

Equipment damage

Overusing artificial particulate detector testers or spraying from too close a range
may cause an oily film to accumulate on the internal window, impairing the
operation of the detector.

Stand at least 2 ft. (0.6 m) away from the sensor when spraying the tester.

Typically, a one to two second burst is adequate to initiate an alarm.
When the alarm activates, the display reads Alarm, the Status LED flashes red, and

the current output is 20.0 mA to indicate detection of particulate matter or canned
contaminant.

2. After simulation, reset the alarm if latched as outlined in Reset and zero the Net
Safety Air Particle Monitor as per Zero transmitter in clean air free of particulates or
at the accepted particulate background level for the specific application.

5.2 Clean sensor

Clean the sensor routinely. The frequency of cleaning depends on the application and
environment where the sensor is installed.

When the Dirty Chamber or Clean Window Alarm message is displayed, the lens/
window and chamber require cleaning. Follow the steps below when cleaning.

Procedure

1. Turn off power to the transmitter.

2. Unscrew bolts at the end of circular plate and connecting rods.

3. Using conventional multi-purpose or glass cleaning solution, clean the inner sides of
the sensor chamber and front side of the lens/window.

Use a lint-free towel or sponge to apply the cleaning solution.

4. Ensure that there is no residue left on the lens or window.

5. Put the circular plate back into position, ensuring that the textured surface faces the
detector's window, and screw in the bolts at the end of the connecting rods.

6. Return power to the detector and check for normal operation.

Net Safety Millennium Air Particle Monitor 41

Maintenance Reference Manual

September 2019 00809-0100-4077

7. Complete the zero procedure (Zero transmitter) to establish new settings.
If problems develop and persist, contact the Net Safety Service department or refer

to Return of material.

5.3 Troubleshooting

Net Safety has not designed the Net Safety Millennium transmitter or the Net Safety APM
sensor to be repaired in the field. If a problem develops, carefully check for faulty wiring.

If you determine that the problem is caused by an electronic defect, return the device to
the factory for repair (refer to Service support and Return of material for instructions).

Perform regular checks on the unit every two to three months to ensure desired operation.
Refer to Check response for instructions.

5.4 Storage

Store the sensor and its electronic components/parts in locations free from dust and
moisture. Ensure that the storage temperature is well within the limits of the certified
temperatures of the equipment. See Specifications for storage temperatures.

5.5 Spare parts and accessories

Table 5-1: Spare Parts and Accessories

Description Part Number

Universal duct mount assembly with 3.3 ft.
(1 m) inlet sampling tube

Universal duct mount assembly with 4.9 ft. (1.5
m) inlet sampling tube

Universal duct mount assembly UDM-003

Magnet assembly HDW-0118

Replacement Millennium transmitter board ML7-TX700

Terminal board for JB-MPD JB-MPD-PCBA

316 stainless steel termination junction box JB-MPD-S

Conduit reducer - ¾ in. (19 mm) to M20 - nickel­plated brass

Conduit reducer - ¾ in. (19 mm) to M20 ­stainless steel

UDM-001

UDM-002

HDW-0148

HDW-0147

42 Emerson.com/Rosemount

Reference Manual Electrostatic sensitive device

00809-0100-4077 September 2019

6 Electrostatic sensitive device

Electrostatic discharge (ESD) is the transfer, between bodies, of an electrostatic charge
caused by direct contact or induced by an electrostatic field.

The most common cause of ESD is physical contact. Touching an object can cause a
discharge of electrostatic energy. If the charge is sufficient and occurs near electronic
components, it can damage or destroy those components. In some cases, damage is
instantaneous, and an immediate malfunction occurs. However, symptoms are not always
immediate; performance may be marginal or seemingly normal for an indefinite period of
time, followed by a sudden failure.

To eliminate potential ESD damage, review the following guidelines:

• Handle boards by the sides, taking care not to touch electronic components.

• Wear grounded wrist or foot straps, ESD shoes, or heel grounders to dissipate

unwanted static energy.

• Prior to handling boards, dispel any charge in your body or equipment by touching a

grounded metal surface.

• Ensure all components are transported and stored in ESD safe packaging.

• When returning boards, carefully package in the original carton and static protective

wrapping.

• Ensure all personnel are educated and trained in ESD control procedures.

• Clean off the housing with a damp cloth only.

In general, exercise accepted and proven precautions normally observed when handling
electrostatic sensitive devices.

Net Safety Millennium Air Particle Monitor 43

Electrostatic sensitive device Reference Manual

September 2019 00809-0100-4077

44 Emerson.com/Rosemount

Reference Manual Wire resistance table

00809-0100-4077 September 2019

7 Wire resistance table

Distance
feet (meters)

100 (30.5) 1.02 0.64 0.40 0.25

200 (61) 2.03 1.28 0.80 0.51

300 (91.4) 3.05 1.92 1.20 0.76

400 (121.9) 4.06 2.55 1.61 1.01

500 (152.4) 5.08 3.20 2.01 1.26

600 (182.9) 6.09 3.83 2.41 1.52

700 (213.4) 7.11 4.47 2.81 1.77

800 (243.8) 8.12 5.11 3.21 2.02

900 (274.3) 9.14 5.75 3.61 2.27

1,000 (304.8) 10.20 6.39 4.02 2.53

1,250 (381) 12.70 7.99 5.03 3.16

1,500 (457.2) 15.20 9.58 6.02 3.79

1,750 (533.4) 17.80 11.20 7.03 4.42

2,000 (609.6) 20.30 12.80 8.03 5.05

2,250 (685.8) 22.80 14.40 9.03 5.68

2,500 (762) 25.40 16.00 10.00 6.31

AWG #20

0.5 mm

2

AWG #18

0.8 mm

2

AWG #16

1.0 mm

2

AWG #14

2.0 mm

2

3,000 (914.4) 30.50 19.20 12.00 7.58

3,500 (1066.8) 35.50 22.40 14.10 8.84

4,000 (1219,2) 40.60 25.50 16.10 10.00

4,500 (1371.6) 45.70 28.70 18.10 11.40

5,000 (1524) 50.10 32.00 20.10 12.60

5,500 (1676.4) 55.80 35.10 22.10 13.91

6,000 (1828.8) 61.00 38.30 24.10 15.20

6,500 (1981.2) 66.00 41.50 26.10 16.40

7,000 (2133,6) 71.10 44.70 28.10 17.70

7,500 (2286) 76.10 47.90 30.10 19.00

8,000 (2438.4) 81.20 51.10 23.10 20.20

9,000 (2743.2) 91.40 57.50 36.10 22.70

10,000 (3048) 102.00 63.90 40.20 25.30

Resistance shown is one way. This figure must be doubled when determining closed loop
resistance.

Net Safety Millennium Air Particle Monitor 45

Wire resistance table Reference Manual

September 2019 00809-0100-4077

46 Emerson.com/Rosemount

Reference Manual Specifications

00809-0100-4077 September 2019

8 Specifications

Table 8-1: Electrical Specifications

Specification Value

Operating voltage range 10.5 to 32 Vdc

Power consumption 3.24 W max at 12 Vdc

3.6 W max at 24 Vdc

Current output 4-20 mA into a maximum loop impedance of 800 ohms at

32 Vdc or 150 ohms at 10.5 Vdc isolated or non-isolated
loop supply

Table 8-2: Environmental Specifications

Specification Transmitter Sensor Junction box

Storage temperature -40 to +185 °F (-40 to +85

°C)

Operating temperature -40 to +185 °F (-40 to +85

°C)

Relative humidity 0-100% relative humidity, non-condensing

-40 to +167 °F (-40 to +75
°C)

-40 to +167 °F (-40 to + 75
°C)

Material of construction

Stainless steel (SS316)

Table 8-3: Ingress Protection

Product Ingress protection rating

Transmitter • Type 4X

• IP66, IP67 (IECEx stainless steel)

Junction box • Type 4X

• IP67

Sensor • Type 4X

• IP65

-40 to +185 °F (-40 to +85
°C)

-40 to +185 °F (-40 to +85
°C)

Net Safety Millennium Air Particle Monitor 47

Specifications Reference Manual

September 2019 00809-0100-4077

Table 8-4: Weight

Product Weight

Transmitter Stainless steel: 7.0 lb (3.2 kg)

Sensor Stainless steel: 4.0 lb (1.8 kg)

Junction box Stainless steel: 3.5 lb (1.6 kg)

Distance between sensor and transmitter

Up to 2,000 ft. (610 m) with 16 AWG (1.31 mm2) wire

Warranty

Electronics: Three years

Sensors: Two years

48 Emerson.com/Rosemount

Reference Manual Certifications

00809-0100-4077 September 2019

9 Certifications

9.1 North American hazardous locations

9.1.1 Transmitter

Class I, Division 1, Groups B, C, and D T5

Class I, Zone 1 Ex d IIB+H2 T5 AL Version Only

-55 °C ≤ Ta ≤ +85 °C

Type 4X

9.1.2

9.1.3

Net Safety™ Air Particle Monitor sensor

Class I, Division 1, Groups B, C, and D T5

Class I, Zone 1, AEx db IIB+H2 T5 Gb

Ex db IIB+H2 T5 Gb

IP65, Type 4X

-40 °C ≤ Ta ≤ +75 °C

1. The ability of this apparatus to function properly in a hazardous environment has
not been tested by CSA.

Junction box (Model JB-MPD)

Class I, Division 1, Groups B, C, and D Class I Zone 1, AEx d/Ex d IIB+H2 T5

-50 °C ≤ Ta ≤ +85 °C

Type 4X, IP67

Net Safety Millennium Air Particle Monitor 49

Certifications Reference Manual

September 2019 00809-0100-4077

9.2 ATEX (-X model)

9.2.1 Transmitter

0598 II 2 G Ex db IIB+H2 T5, IP66

-40 °C ≤ Ta ≤ +85 °C

Presafe 16 ATEX 8594X

Special Conditions for Safe Use

1. All cable glands, blanking elements, and thread adapters must be suitably certified
as Ex d and maintain the IP66 rating of the enclosure.

2. To minimize the risk of electrostatic charge, provisions shall be made for adequate
grounding of equipment. Equipment shall be installed in such a manner that
accidental discharge should not occur.

3. For ambient temperature above 158 °F (70 °C), care shall be taken to select cable
that is suitably rated for the intended ambient temperature range.

9.2.2

9.2.3

4. Flameproof joints are not intended to be removed.

Net Safety Air Particle Monitor sensor

0598 II 2 G Ex db op is IIB+H2 T4 Gb

-40 °C < Ta < +75 °C

IP65

SIRA 17ATEX1242X

EN 60079-0:2012/A11:2013

EN 60079-1:2014

Special Conditions for Safe Use

1. The integral conductors shall be suitably mechanically protected and terminated in
a suitable certified terminal or junction facility.

2. It is the user's responsibility to ensure that the earth continuity of the equipment is
maintained via the mounting arrangement.

3. Flamepath joints are not intended to be repaired.

Junction box (Model JB-MPD)

0598 II 2 G Ex d IIB+H2 T5

-55 °C ≤ Ta ≤ +85 °C IP67

50 Emerson.com/Rosemount

Reference Manual Certifications

00809-0100-4077 September 2019

FM07ATEX0044

9.3 IECEx (-X model)

9.3.1 Transmitter (stainless steel)

Ex d IIB+H2 T5 Gb

-55 °C ≤ Ta ≤ +85 °C

Certificate Number: IECEx FMG 13.0035X

IEC 60079-0:2011/IEC 60079-1:2007/IEC 60529:2001

Consult the manufacturer if dimensional information on the flameproof joints is
necessary.

9.3.2

9.3.3

Net Safety Air Particle Monitor sensor

Ex db op is IIB+H2 T4 Gb

-40 °C ≤ Ta ≤ +75 °C

IP65

Certificate Number: IECEx SIR 17.0061X

IEC 60079-0:2011, 6th Edition

IEC 60079-1:2014, 7th Edition

IEC 60079-28:2015, 2nd Edition

Junction box (Model JB-MPD)

Ex d IIB+H2 T5 Gb

-55 °C ≤ Ta ≤ +85 °C

IP67

Certificate Number: IECEx FMG 14.0009X

IEC 60079-0:2011/IEC 60079-1:2007

Consult the manufacturer if dimensional information on the flameproof joints is
necessary.

Follow the manufacturer's instructions to reduce the potential of an electrostatic charging
hazard.

Net Safety Millennium Air Particle Monitor 51

Certifications Reference Manual

September 2019 00809-0100-4077

52 Emerson.com/Rosemount

Reference Manual Ordering information

00809-0100-4077 September 2019

10 Ordering information

The starred offerings (★) represent the most common options and should be selected for best
delivery. The non-starred offerings are subject to additional delivery lead time.

Option Description

MLP-AR-APM Net Safety™ Air Particle Monitor ★

Output

-OP-SEP Analog, relays ★

Housing style

-SS Stainless steel ★

Product certifications

CSA ★

-X ATEX flameproof ★

Note

Emerson Automation Solutions

6021 Innovation Blvd

Shakopee, MN 55379

Toll Free [phone]

F [phone]

Emerson.com/FlameGasDetection

Net Safety Millennium Air Particle Monitor 53

00809-0100-4077

Rev. AE

2019

GLOBAL HEADQUARTERS

Emerson Automation Solutions
Rosemount
6021 Innovation Blvd.
Shakopee, MN 55379

Toll Free [phone]
[phone]
[e-mail]

EUROPE

Emerson Automation Solutions
Neuhofstrasse 19a P.O. Box 1046
CH-6340 Baar
Switzerland

[phone]
[phone]
[e-mail]

Linkedin.com/company/Emerson-Automation-Solutions

twitter.com/rosemount_news

Facebook.com/Rosemount

youtube.com/RosemountMeasurement

MIDDLE EAST AND AFRICA

Emerson Automation Solutions
Emerson FZE
Jebel Ali Free Zone
Dubai, United Arab Emirates, P.O. Box 17033

[phone]
[phone]
[e-mail]

©

2019 Emerson. All rights reserved.

The Emerson logo is a trademark and service mark of Emerson Electric Co. Net Safety is a
mark of one of the Emerson family of companies. All other marks are the property of their
respective owners.

ASIA-PACIFIC

Emerson Automation Solutions
Asia Pacific Private Limited
1 Pandan Crescent
Singapore 128461
Singapore

[phone]
[phone]
[e-mail]
