Technical Data Sheet
RFID reader
CTU-M
CTU-Mxx-man-eng-v2.pdf
series
Fig. 1 CTU-M2R
ATTENTION! THIS CONFIDENTIAL DOCUMENT IS PROPERTY OF NETRONIX
SP. Z O.O.
DISTRIBUTION OF THIS DOCUMENT IN ANY WAY WITHOUT SPECIAL PERMISSION OF ITS
OWNER IS STRICTLY FORBIDDEN
1. INTRODUCTION ............................................................................................. 5
2. GENERAL SPECIFICATION........................................................................... 6
3. DIMENSION, TERMINAL DESCRIPTION....................................................... 7
4. MODULE SETTINGS BY ON-BOARD SWITCH............................................. 8
5. TRANSMISSION PROTOCOLS...................................................................... 8
5.1. RS-232/485 TRANSMISSION PROTOCOL ................................................ 8
5.2. Protocol for I2C transmission............................................................................. 8
5.2.1. Data exchange algorithm ............................................................................... 8
5.2.2. Timings............................................................................................................ 10
5.3. Protocol for 1WIRE (Dallas) bus...................................................................... 10
5.4. Wiegand protocol ................................................................................................ 12
5.5. Key management................................................................................................. 13
5.5.1. Key loading into dynamic key memory....................................................... 13
5.5.2. Key loading to key static memory ............................................................... 14
5.6. Commands for communication with transponder ..................................... 14
5.6.1. On/off switching of reader field.................................................................... 14
5.6.2. Selecting one of many transponders.......................................................... 15
5.6.3. Logging by means of Dynamic Key Buffer to selected sector of
transponder......................................................................................................................... 16
5.6.4. Logging by means of Static Key Buffer to selected sector of
transponder......................................................................................................................... 16
5.6.5. Reading-out the content of transponder block.......................................... 17
5.6.6. Writing the content of transponder block ................................................... 17
5.6.7. Copying the content of transponder block into other block..................... 18
5.6.8. Writing the page content into Mifare UL .................................................... 18
5.6.9. Reading the page content in Mifare UL ..................................................... 19
5.6.10. Writing values to transponder block ....................................................... 19
5.6.11. Reading-out the values from transponder block................................... 20
5.6.12. Increasing the value included in transponder block ............................. 20
5.6.13. Decreasing the value included in block transponder ........................... 21
5.6.14. Setting the transponder in field into sleep mode .................................. 21
5.7. Reader inputs and outputs ............................................................................... 22
5.7.1. Writing the output state................................................................................. 22
5.7.2. Reading the input state................................................................................. 22
5.7.3. Writing the settings to any port.................................................................... 23
5.7.4. Reading-out the configuration of freely selected port .............................. 25
5.8. Access password ................................................................................................ 25
5.8.1. Logging to reader........................................................................................... 25
5.8.2. Changing the password................................................................................ 26
5.8.3. Logging out of the reader ............................................................................. 26
5.9. Operating the transponder internal memory ............................................... 27
5.9.1. Reading-out the transponder number from memory................................ 27
5.9.2. Writing the transponder name to memory ................................................. 27
5.10. Operating the built-in access control ........................................................ 27
5.10.1. Writing the configuration of access control............................................ 27
5.10.2. Reading-out the configuration of access control .................................. 28
5.10.3. Writing the “automatic read” configuration............................................. 28
5.10.4. Reading-out the configuration of automatic device.............................. 30
5.10.5. Setting the date and time ......................................................................... 30
5.10.6. Reading-out the date and time ................................................................ 30
5.11. Configuring the UART serial interface....................................................... 31
5.11.1. Writing the configuration of serial port.................................................... 31
5.11.2. Reading the configuration of serial interface......................................... 31
5.12. Managing the events ...................................................................................... 32
5.12.1. Setting the event recorder........................................................................ 32
5.12.2. Reading the event recorder ..................................................................... 33
5.12.3. Reading the counters related to event memory. .................................. 33
5.12.4. Reading the events ................................................................................... 34
5.13. MAD – Mifare Application Directory ........................................................... 35
5.13.1. Card MAD formatting ................................................................................ 35
5.13.2. Adding the application to MAD directory................................................ 35
5.13.3. Pursuing the sector for given application............................................... 36
5.13.4. Pursuing the next sector of application .................................................. 36
5.14. Other commands ............................................................................................. 37
5.14.1. Remote reset of reader............................................................................. 37
5.14.2. Reading-out the reader software............................................................. 37
5.14.3. Change buzzer volume............................................................................. 37
5.15. Code meanings in response frames .......................................................... 38
6. MEANING OF SYMBOLS USED IN THE SPECIFICATION ......................... 38
7. MECHANISM OF MASTER ID ...................................................................... 38
8. RESET TO DEFAULT SETTINGS ................................................................ 39
9. OPERATION EXAMPLE OF TRANSPONDER............................................. 39
CTU
-
Mxx
NETRONIX CTU-Mxx
5
1. Introduction
CTU-M device series is OEM miniature RFID card reader operating at frequency of
13,56 MHz
Main features:
• Support of Mifare S50, S70, Ultralight, Desfire
• built-in antenna
• card memory with build-in lock driver,
• lots of communication interfaces type, depend on version (see table below)
• Built-in relay and buzzer
• Built-in push-button for reset to default settings
• 2 configurable inputs/outputs
• Two-state outputs control
• Read-out of two-state input
• changeable format of sending ID
• MAD functionality
• Data password protected
• Software update via serial interface using NEFIR program
CTU-M reader series
Module type
GPIO
Card memory
Event memory
Relay
Power supply
RS-232
CTU-M2R*
CTU-M4R
CTU-M5N*
CTU-M5R
CTU-M2RM
40
40
40
40
1000 4000
7-16
7-16
5
5
7-16
* - standard version, rest of version for special order
INTERFACES
RS-485
RS-232TTL
SPI
I2C
WIEGAND
1WIRE
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
6
2. General specification
Supported functionality depending on transponder / card type:
Transponder
type
ID number
read-out
Full write and read-out of memory blocks
S50 YES YES
S70 YES YES
Ultralight YES YES
Desfire YES NO
CTU-Mxx module parameters
Supply voltage (M2R, M4R model) 7-16 V
Supply voltage (M5R model ) 4,5 - 5,5 V
Max. supply current 120 mA
Rated operation radio frequency of module 13,56MHz
Working temperature
-20°c - +65°c
Max. relay current 2A
Appr. read distance for S50 7 cm
Max. output current for GPIO 20mA
Transmission parameters for
RS232/RS485/RSTTL
2400, 4800, 9600, 19200, 38400, 57600,
115200 bps,
8 data bits, 1 stop bit, no parity
compliant with „Netronix Protocol”
Address on I2C bus 0xC0
1WIRE family code,address (configurable) 0x01,0x01
WIEGAND number of bits 37
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
7
67 mm
3. Dimension, terminal description
4xφ3
67 mm
79.5mm
2 14
1 13
79.5 mm
Rys.2 top side view
Pin no. Description
1
RS232RX, RS485B, RSTTL_RX, 1WIRE, MOSI,
SDA
2 RS232TX, RS485A, RSTTL_TX, MISO
3 SCK, SCL
4 CS
5 MCLR
6 GND
7 VCC
8 GPIO 1
9 GPIO 2
10 GND
11 NC
12 NC
13 RELAY 1
14 RELAY 2
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
8
4. Module settings by on-board switch
Two function of build-in switch:
• configure to factory settings – press button for 8 seconds
• change interface and RFID transponder type – press button in schematic:
STEP
1 MENU1 – interface
Number of press 1
2 3 4 5 6
- RS232/485 SPI WIEGAND 1WIRE I2C
selection*
2 Triple beep
* - type of interface depends on CTU-M model
5. Transmission protocols
5.1. RS-232/485 transmission protocol
In this data sheet RS-232/485 protocol has been confined to descriptions of
commands, responses and their parameters. Header and CRC control sum exist
always and are compliant with full “Netronix Protocol” document.
Command frame:
Header C_CommandName Response_parameters1…n CRC
Response frame:
Header C_CommandName+1 Response_parametrers…m OperationCode CRC
RS protocol operation can be tested by means of development tools including free of
charge “FRAMER” software”.
5.2. Protocol for I2C transmission
5.2.1. Data exchange algorithm
A module configured depending on table showed on point 4. operates in I2C
interface mode in following sequences:
1. Master (external device) writes command with parameters if necessary into slave
device (CTU module)
2 The command is performed (immediately after receiving byte sent quantity declared
in frame)
3. Master device reads response, its parameters and operation code. In case of
receiving busy byte 0xCB, repeat attempt to read the response after ca. 1 ms
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
9
(N bytes)
START
0b110000a0
STOP
TAK
NIE
(commands connected with write to/and read from transponders can last up to 100
ms).
We write inquiry-command to CTU module:
START
SLAVE ADDRESS (1B)
0
NUMBER OF BYTES(1B)
COMMAND (1B)
PARAMETERS (0...n B)
The „number of bytes” field must contain information on byte quantity sent directly
“command” fields and “parameters”.
We have then:
START
SLAVE ADDRESS (1B)
1
Number of bytes N or 0xCB
PARAMETERS + OPERATION CODE
STOP
I2C SEND
I2C SEND:
Number of bytes,command,[data]
I2C SEND:
Wait 1ms
I2C START
I2C SEND:
0b110000a1
Wait for ACK
I2C READ 1 byte:N
N= 0xCB ?
Receive N bytes
I2C SEND
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
10
5.2.2. Timings
Module sends and receives data at 400 kHz clock frequency considering
timings showed below.
Note 2: Reader keeps in low state first clock pulse of each byte sent until
proper state is placed on SDA line.
5.3. Protocol for 1WIRE (Dallas) bus.
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
11
Family code ID1…ID5 Address CRC
1 byte 5 bytes 1 byte 1 bytet
ID1...5 – unique ID number of transponder
CRC_DAL- check sum of data send
The format conforms 1-WIRE Dallas (e.g.. DS1990A). It means, that described
module could be used as a replacement of DS1990A drop.
During operation, a module tries to read-out transponder periodically. If it fails (no
successful read-out), module does not response for pulses sent from 1-WIRE master
unit. Bus does not "see" the module, which corresponds with lack of reader applying, it
means applying the DS1990A drop to drop reader. If module reads out the
transponder, the module starts to send data via 1-WIRE bus.
Calculate the CRC value
According to DS1990A specification C value is calculated from equation
x^8+x^5+x^4+1 with initial value equal to 0x00. The CRC is calculated on basis of all
frame bytes excluding the last one.
An example of CRC value calculation procedure written in C language
unsigned char CalcCRCDallas(unsigned char *SourceAdr)
{
unsigned char i,k,In,CRC=0;
for(i=0;i<7;i++)
{
In=*SourceAdr;
for(k=0;k<8;k++)
{
if((In^CRC)&1) CRC=((CRC^0x18)>>1)|0x80;
else CRC=CRC>>1;
In>>=1;
}
SourceAdr++;
}
return(CRC);
}
where *SourceAdr is beginning flag of data buffer
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
12
......
DATA1
DATA0
H level
5.4. Wiegand protocol
The format conforms WIEGAND protocol specification for N bits. During operation,
a module tries to read-out transponder periodically. If it fails (no successful read-out),
module does not send data (bus does not "see" the module). If module reads out the
transponder, the module starts to send data via Wiegand bus.
Pulse sequence from left to right.
L level
H level
L level
1 1 0 0 1 ............. 1 0 0 encoding DATA
......
Total number of pulses (level L) is equal to N. The first being bit sent complements up
to parity the bits from first half of total bits. The last bit N complements up to non-parity
the bits from second half of bits being sent.
It means, that two bits out of N bits assure the transmission correctness. Information is
being sent is written by means bits 2 to N-1, it gives N information bits.
Check sums for bit sequence:
for even N:
EXXXXXXXXXXXXYYYYYYYYYYYYO
or for odd N:
EXXXXXXXXXXXXXXXXXX..................
..................YYYYYYYYYYYYYYYYYYO
Where:
E = bit complementing up to parity
O = bit complementing up to non-parity
X = mask for parity calculation
Y = mask for non-parity calculation
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
13
5.5. Key management
Key management feature includes key loading to internal key memory. For security
reasons, these keys cannot be red-out.
To maintain the highest level of data security, employed a particular philosophy
of working with these keys.
It allows unit or person who possesses the highest level of confidence to load a
key. Such loading operation can be made one time only, or very rarely.
Reader operation in given application is based on using a key not directly, but on
recalling key number, to login to sector.
The result is that, in substance, key does not appear in data bus in given application.
Additionally, a user is advised to make sure key should have proper access
rights to sectors. This is accomplished by card initialization process, where new
confidential keys are loaded to cards with proper access rights, which are assigned to
these keys.
Keys A and B are assigned to each sector.
Commands C_LoadKeyToSKB and C_LoadKeyToDKB load these keys to reader
memory without information on key type (A or B).
During logging to sector, user has to input as a parameter value of 0xAA or 0xBB, if he
wants, the key which is being recalled would be treated as an A or B.
5.5.1. Key loading into dynamic key memory
Dynamic memory features of automatic content delete in case of supply decay. The
memory can be overwritten many times.
Command frame:
Header C_LoadKeyToDKB Key1…6 CRC
Where:
Parameter name Parameter description Value range
C_LoadKeyToDKB Key loading to key dynamic memory 0x14
Key1…6 6-byte code whichever
Response frame:
Header C_LoadKeyToDKB +1 OperationCode CRC
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
14
switching the
switching the
5.5.2. Key loading to key static memory
Important feature of static memory is that in case of supply decay, data stored in it will
not be lost. The memory can be overwritten many times.
Command frame:
Header C_LoadKeyToSKB Key1…6, KeyNo CRC
Where:
Parameter name Parameter description Value range
C_LoadKeyToSKB Key loading to key static memory 0x16
Key1…6 6-byte key whichever
KeyNo
Key number.
It possible to load 32 different keys to a reader.
0x00…0x1f
Response frame:
Header C_LoadKeyToSKB +1 OperationCode CRC
5.6. Commands for communication with transponder
5.6.1. On/off switching of reader field
Command frame:
Header C_TurnOnAntennaPower State CRC
Where:
Parameter name Parameter description Value range
C_TurnOnAntennaPower On/off switching of reader field 0x10
0x00 –
State On state
field off
0x01 –
field on
Response frame:
Header
C_TurnOnAntennaPower
+1
OperationCode CRC
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
15
Selecting one of
ponder
by
Number of collisions during one transponder
This figure can be equal to the transponder
quantities, which are in the field simultaneously,
5.6.2. Selecting one of many transponders
Command frame:
Header C_Select RequestType CRC
Where:
Parameter name
Parameter
description
Values
C_Select
many transponders
0x12
0x00 - Standard selecting from group of
transponders, which are not in standmode
0x01 - Selecting from group of
RequestType
Type of trans
selection
transponders, which are in reader field.
Response frame:
Header C_Select +1 ColNo, CardType, ID1…….IDn OperationCode CRC
Where:
Parameter
name
Parameter description Meaning
selecting.
ColNo
and which are not in stand-by state.
0x50 – S50
0x70 – S70
CardType Type of selected transponder
0x10 – Ultra Light
0xdf – Des Fire
ID1…IDn Unique number of transponder
ID1 – LSB,
IDn – MSB
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
16
Transponder sector number, to
Key type, which is inside internal
Transponder sector number, to
l
5.6.3. Logging by means of Dynamic Key Buffer to selected sector of
transponder
To complete logging successfully, it is important after any input of the reader, to reload
the Dynamic Key Buffer.
Command frame:
Header C_LoginWithDKB SectorNo, KeyType, DKNo CRC
Where:
Parameter name Parameter description Value range
C_LoginWithDKB Logging to sector 0x18
SectorNo
KeyType
which user wants to login.
Dynamic Key Buffer.
0x00 – 0x0f (s50)
0x00 – 0x27 (s70)
0xAA – key of A type
0xBB – key of B type
DKNo Dynamic key number 0x00
Response frame:
Header C_LoginWithDKB +1 OperationCode CRC
5.6.4. Logging by means of Static Key Buffer to selected sector of
transponder
To complete logging successfully, it is important to load Static Key Buffer first.
Command frame:
Header C_LoginWithSKB SectorNo, KeyType, SKNo CRC
Where:
Parmeter name Parameter description Value range
C_LoginWithSKB Logging to sector 0x1a
SectorNo
KeyType
which user wants to login.
Key type, which is inside interna
Static Key Buffer.
0x00 – 0x0f (s50)
0x00 – 0x27 (s70)
0xAA – key of A type
0xBB – key of B type
SKNo Static Key number 0x00…0x1F
Response frame:
Header
C_LoginWithSKB +1 OperationCode CRC
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
17
out of transponder
Block number within given
Write of transponder block
Block number within given
Data, which are to be written
5.6.5. Reading-out the content of transponder block
Command frame:
Header C_ReadBlock BlockNo CRC
Where:
Parameter name Parameter description Value range
C_ReadBlock
Readblock content
0x1e
BlockNo
sector
**Sector and block numeration
Response frame:
Header C_ReadBlock +1 Data1….. Data16 OperationCode CRC
Where:
Parameter name Parameter description Value range
Data1…. Data16 Red-out of data from transponder block
5.6.6. Writing the content of transponder block
Command frame:
Header C_WriteBlock BlockNo, Data1….. Data116 CRC
Where:
Parameter name Parameter description Value range
C_WriteBlock
BlockNo
Data1…. Data16
Response frame:
Header C_WriteBlock +1 OperationCode CRC
NETRONIX .
content
sector
into transponder block.
0x1c
**Sector and block numeration
whichever
CTU
-
Mxx
NETRONIX CTU-Mxx
18
ng the content of
transponder block into other
5.6.7. Copying the content of transponder block into other block
Command frame:
Header C_CopyBlock SourceBlockNo, TargetBlockNo CRC
Where:
Parameter name Parameter description Value range
Copyi
C_CopyBlock
0x60
block
SourceBlockNo Source block
TargetBlockNo Target block for data
**Sector and block numeration
Response frame:
Header C_CopyBlock +1 OperationCode CRC
5.6.8. Writing the page content into Mifare UL
Command frame:
Header C_WritePage4B PageAdr, Data1...4 CRC
Where:
Parameter name Parameter description Value range
C_WritePage4B Writing the page content into Mifare UL 0x26
PageAdr Page number in transponder 0x00…0x0f
Data1...4 Data, which are to be written whichever
Response frame:
Header C_WritePage4B +1 OperationCode CRC
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
19
out of following
four pages should start. If PageAdr>0x????,
out process of pages, which are
out of data from four subsequent
Block number within given sector,
**Sector and block
Declared block number including the
BackupBlockNo has no influence for
system operation, but user
can/should make the Value copy by
**Sector and block
The Value, which is written to
5.6.9. Reading the page content in Mifare UL
Command frame:
Header C_ReadPage16B PageAdr CRC
Where:
Parameter name Parameter description Value range
C_ReadPage16B Read-out of page content in Mifare UL 0x28
Page address, from which read-
PageAdr
starts read-
0x00…0x0f
present at memory beginning.
Response frame:
Header
C_ReadPage16B
+1
Data1…16 OperationCode CRC
Where:
Parameter name Parameter description Value range
Data1…16
Redpages.
whichever
5.6.10. Writing values to transponder block
Command frame:
Header C_WriteValue BlockNo, BackupBlockNo,Value1...4, CRC
Where:
Parameter name Parameter description Value range
C_WriteValue Write of values to transponder block. 0x34
BlockNo
into which the Value will be written.
Value copy.
BackupBlockNo
himself.
Value1...4
NETRONIX .
numeration
numeration
whichever
CTU
-
Mxx
NETRONIX CTU-Mxx
20
lue from
Block number within given sector,
**Sector and block
out Value from transponder
Block number, which can include
Increasing the value included in
Block number within given sector, in
**Sector and block
transponder block.
Response frame:
Header C_WriteValue +1 OperationCode CRC
5.6.11. Reading-out the values from transponder block
Command frame:
Header C_ReadValue BlockNo CRC
Where:
Parameter
name
C_ReadValue
Parameter description Value range
Read-out of the Va
transponder block.
0x36
BlockNo
from which the Value will be red-out.
numeration
Response frame:
Header C_ReadValue+1 Value1...4, BackupBlockNo OperationCode CRC
Where:
Parameter name Parameter description Value range
Value1...4
BackupBlockNo
Redblock.
the Value copy.
**Sector and block
numeration
5.6.12. Increasing the value included in transponder block
To execute a command successfully, format of data included in declared block should
be “Value” format.
Command frame:
Header C_IncrementValue BlockNo, Value1...4 CRC
Where:
Parameter name Parameter description Value range
C_IncrementValue
BlockNo
NETRONIX .
transponder block.
which the Value will be modified.
0x30
numeration
CTU
-
Mxx
NETRONIX CTU-Mxx
21
Value, which is being added to
existed real value of block
Decreasing the Value included in
Block number within given sector,
ich is being
subtracted from existed real value
Setting the transponder in field into sleep
Value1...4
transponder.
Response frame:
Header
C_IncrementValue
+1
OperationCode CRC
5.6.13. Decreasing the value included in block transponder
To execute a command successfully, format of data included in declared block should
be “Value” format.
Command frame:
Header C_DecrementValue BlockNo, Value1...4 CRC
Where:
Parameter name Parameter description Value range
C_DecrementValue
BlockNo
transponder block.
in which the Value will be modified
0x32
**Sector and block
numeration
The Value, wh
Value1...4
whichever
of block transponder.
Response frame:
Header C_DecrementValue+1 OperationCode CRC
5.6.14. Setting the transponder in field into sleep mode
To set transponder to sleep mode, select it first.
Command frame:
Header C_Halt CRC
Parameter name Parameter description Value range
C_Halt
mode.
Response frame:
Header
NETRONIX .
C_Halt+1 OperationCode CRC
0x40
CTU
-
Mxx
NETRONIX CTU-Mxx
22
5.7. Reader inputs and outputs
Reader has inputs and outputs which are configurable. Inputs are controlled
directly from microcontroller outputs. Output load current is up to 20 mA.
5.7.1. Writing the output state
Command frame:
C_WriteOutputs IONo, State
Where:
Parameter name
Parameter description Value range
C_WriteOutputs Output state write 0x70
IONo
I/O port number. The port should
be configured as an output
0x1..0x7 for UW-U4R
0x1..0xC for UW-U4G
State Requested output state 0x00 or 0x01
Response frame:
C_WriteOutputs +1 Operation Code
5.7.2. Reading the input state
Command frame:
C_ReadInputs IONo
Where:
Parameter name Parameter description Value range
C_ReadInputs Input state reed-out 0x72
IONo
I/O port number.
Should be configured as an input.
0x0..0x7 dla UW-U4R
0x0..0xC dla UW-U4G
Response frame:
C_ReadInputs +1 State,[COUNTER] Operation Code
Where:
Parameter name Parameter description Value range
State Input state which has been red
Counter
Counter state for counter type
input.
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
23
„0”
„1”
INTERF
↓
INTERF
Base card
Each card
TypeOfOutput
0
1
t2
t0
t1
00
01
10
5.7.3. Writing the settings to any port
t2
t0
t1
TOGGLE
ConfByte1 - BIT 1
t2=Hold-UP x 100ms
tn=nTime x 100ms
ConfByte1 - BIT 3:2
ConfByte1 - BIT 0
IOn
Command frame:
Header C_SetIOConfig IONo, IOConfigData1…n CRC
If we set a port as output, IOConfigData1…n parameters are as below:
Dir, ConfByte1, TypeOfOutput, Hold-up, 0Time, 1Time
Where:
Parameter
name
C_SetIOConfig Writing the configuration of every port
IONo
Parameter description Value range
0x50
I/O port number, which is to be
configured
0x0..0x4
Dir Port direction 0x00 – output
ConfByte1
One byte in which:
BIT0 assigns output type as normally
open or normally closed.
BIT 1 determines reaction method of
each output as sensitive for
simulation changing (slope sensitive)
0-level sensitive
1-slope sensitive
ConfByte1 Bit 0
0-Normally closed
1-Normally open
ConfByte1 Bit 1
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
24
or as sensitive for simulation state
(state sensitive).
BIT3:2 determines operation method
of output referring to trigger signal
state.
00 – rectangular wave
generator
01- directly
10 – output state change
ConfByte1 Bit 3:2
0x00 – permanently off
0x01 – permanently on
0x02 – driven via serial
interface
0x03 – driven via serial with
automatic reset(edge
emulation)
TypeOfOutput
Source of driving signal
0x04 – driven by internal
access control mechanism
ACM.
This output is driven in case of
applying the card to reader,
which is written into internal
card base.
0x05 – set in case of applying
freely selected card to reader.
Time of maintaining the on state after
actuation stopped. This time is
specified as:
Hold-up x 100 ms
Hold-up
During “hold-up” time, it is possible to
configure the output, whish is able to
generate rectangular wave. By
means of following parameters are
configured “Logic 1” time and “Logic
0” time:
0Time Logic 0 time
1Time Logic 1 time
If we set a port as a input, IOConfigData1…n parameters would be as below:
Dir, Triger, TypeOfInput, Delay,
Where:
Parameter name Parameter description Value range
C_SetIOConfig
Writing the configuration of freely selected
port.
0x50
IONo I/O port number, which is to be configured. 0x00,0x01,0x07
Dir Port direction 0x01 – input
TypeOfInput Input type 0x03
Delay Delay 0x00
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
25
5.7.4. Reading-out the configuration of freely selected port
Command frame:
Header C_GetIOConfig IONo CRC
Where:
Parameter name
C_GetIOConfig
IONo
Reading-out the configuration of freely selected
I/O port number, which configuration is to be
Parameter description Value range
port.
red-out.
0x52
0x00…0x05
Response frame:
Header C_GetIOConfig +1 IOConfigData1…n OperationCode CRC
Where:
Parameter name Parameter description Value range
IOConfigData1…n
This is the same, as in case of configuration
write.
Some I/O of CTU-M reader has no possibility to toggle port direction.
To accomplish proper configuration, input proper direction option to given port.
LIST OF EXISTING PORTS, WHICH CAN BE DRIVEN IN UW-M4R
Port number
Direction Description
0 input/output GPIO1
1 input/output GPIO 2
2 output RELAY
3 output BUZZER
Response frame:
Header C_SetIOConfig +1 OperationCode CRC
5.8. Access password
5.8.1. Logging to reader
Command frame:
Header C_LoginUser Data1…n, 0x0 CRC
Where:
Parameter name
Parameter description Value range
C_LoginUser Logging to reader 0xb2
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
26
Any from range: 0x01…0xff.
Data1…n This is any byte string
String length, which can be 0 to
8 bytes
0x00
Logic Zero, which terminates a
string.
0x00
Response frame:
Header C_LoginUser +1 OperationCode CRC
5.8.2. Changing the password
Command frame:
Header C_ChangeLoginUser Data1…n, 0x0 CRC
Where:
Parameter name Parameter description Value range
C_ChangeLoginUser
Password change 0xb4
Any from range:
Data1…n
This is any byte string, which will form
valid access password.
0x01…0xff.
String length, which
can be 0 to 8 bytes
0x00 Logic Zero, which terminates a string. 0x00
If =0x00, a reader will not be protected by password. At any moment, there is possible
to set new password later on, to protect the reader by it.
Response frame:
Header C_ChangeLoginUser+1 OperationCode CRC
5.8.3. Logging out of the reader
This command sets latest password as an invalid.
Command frame:
Header C_LogoutUser CRC
Parameter name Parameter description Value range
C_LogoutUser Logging out of the reader. 0xd6
Response frame:
Header C_LogoutUser +1 OperationCode CRC
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
27
5.9. Operating the transponder internal memory
5.9.1. Reading-out the transponder number from memory
Command frame:
Header
C_CardMemoryRead
AdrL, AdrH CRC
Where:
Parameter name Parameter description Value range
C_CardMemoryRead
Read-out of transponder number from
memory.
0x20
AdrL, AdrH Younger and older byte respectively. 0x0000…0x01fd
Response frame:
Header C_CardMemoryRead+1 ID1(L)….ID5(H), Right OperationCode CRC
Where:
Parameter name Parameter description Value range
ID1(L)….ID5(H) Five bytes of transponder number
Right Access rights to given transponder 0x01
5.9.2. Writing the transponder name to memory
Command frame:
Header C_CardMemoryWrite AdrL, AdrH, ID1(L)….ID5(H), Right CRC
Where:
Parameter name Parameter description Value range
C_CardMemoryWrite Write of transponder number into memory. 0x22
AdrL, AdrH Younger and older byte respectively 0x00…0x01fd
ID1(L)….ID5(H) Five bytes of transponder number Any of five bytes
Right
Access rights or function performed by
transponder.
0x01
Response frame:
Header C_CardMemoryWrite+1 OperationCode CRC
Where:
5.10. Operating the built-in access control
5.10.1. Writing the configuration of access control
Command frame:
Header C_AccesControlConfigWrite Mode CRC
Where:
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
28
Parameter name Parameter description Value range
C_AccesControlConfigWrite
Mode
Write of access control
configuration.
Operation mode of control
access module.
0x74
0x00 – module disabled
0x01 – module enabled
Response frame:
C_AccesControlConfigWrite+1 OperationCode CR
Header
C
5.10.2. Reading-out the configuration of access control
Command frame:
Header C_AccesControlConfigRead CRC
Where:
Parameter name Parameter description Value range
C_ AccesControlConfigRead
Read-out of access control
configuration.
0x76
Response frame:
Header C_AccesControlConfigRead+1 Mode OperationCode CRC
Where:
Parameter name Parameter description Value range
Mode
Operation mode of access control
module.
0x00 – module disabled
0x01 – module enabled
5.10.3. Writing the “automatic read” configuration
This command sets operation method of automatic device, reading the unique
transponder number UID.
The reader described below makes possible to hold-on operation of automatic
device for a while, in case of suitable transmission via serial interface.
If the reader will operate in mixed mode i.e.:
- automatic reading device UID is enabled and:
- master device (computer, controller) communicates with reader or with transponders
via reader,
it is required, to configure the reader correctly, so in case of communication with a
reader or transponder, automatic reading device would hold-on its operation.
Command frame:
Header
C_SetAutoReaderConfig ATrig, AMode, AOfflineTime, ASerial, Abuzz CRC
Where:
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
29
Parameter name Parameter description Value range
C_SetAutoReader
Config
ATrig
AOfflineTime
ASerial
AMode
Writing the automatic device
configuration.
Defines, when automatic reading
device UID will operate.
Lack of transmission time on
interface bus
T= AofflineTime * [100ms]
Lack of transmission can concern
to any commands (Atrig=2), or
commands for communication
with transponder (Atrig=3).
Commands for communication
with transponder:
C_TurnOnAntennaPower
C_Select
Automatic sending the UID
transponder number, after
reading it automatically from
transponder.
Selection the format of sending
number
8 bits:
MSB LSB
R R H CR R E I A
0x58
0-automatic device disabled
permanently
1-automatic device enabled
permanently
2=enabled automatically in case of
transmission lack on interface for a
time longer than AOfflineTime
3=enabled automatically, in case of
no recall of communication
commands with transponder for a
time longer than AOfflineTime
0x00…0xff
0-never
1-for the first applying the
transponder only
2-sends all
R Reserved, always 0
CR=1
Number which is ended with
line end mark CR+LF
information extended with
E=1
cards umber in filed and card
type
I=1 Number in reversed order
A=1
Number sent in ASCII format
H=0
A=0
H=0
A=0
H=1
Number sent in Nertonix
format
Number sent in binary format
0-never
1-for the first applying the
transponder only
2-indicates all
ABuzz
Automatic indication of reading by
means of buzzer, after automatic
UID read-out from transponder.
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
30
Response frame:
Header C_ SetAutoReaderConfig +1 OperationCode CRC
5.10.4. Reading-out the configuration of automatic device
Command frame:
Header C_ GetAutoReaderConfig CRC
Where:
Parameter name Parameter description Value range
C_GetAutoReaderConfig
Read-out of automatic device
configuration.
0x5a
Response frame:
Header
C_ GetAutoReader
Config +1
ATrig, AOfflineTime, ASerial,
Abuzz,Amulti
OperationCode CRC
Where:
The meaning of response parameters is the same as described before.
5.10.5. Setting the date and time
Following setting has no influence for reader operation today.
Command frame:
Header C_SetRtc Year, Month, Day, Hour, Minute, Second CRC
Where:
Parameter name Parameter description Value range
C_SetRtc Date and time set-up 0xb8
Year year 0…99
Month month 1…12
Day day 1…31
Hour hour 0…23
Minute minute 0…59
Second second 0…59
Response frame:
Header C_SetRtc +1 OperationCode CRC
5.10.6. Reading-out the date and time
Command frame:
Header
C_GetRtc CRC
Where:
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
31
Parameter name Parameter description Value range
C_GetRtc Read-out of date and time 0xb6
Response frame:
Header C_GetRtc+1
Year, Month, Day, Hour, Minute,
Second
OperationCode CRC
Where:
The meaning of response parameters is the same as described before.
5.11. Configuring the UART serial interface
5.11.1. Writing the configuration of serial port
Command:
C_SetInterfaceConfig Mode, Adr, Baudrate
Where:
Parameter name Parameter description Value range
C_SetInterfaceConfig
Serial interface configuration write 0x54
Mode 0x01
Adr Address on RS-485 bus 0x01…0xfe
0x01=2400 bps
0x02=4800 bps
0x03=9600 bps
Baudrate Data baud rate on RS-485 bus
0x04=19200 bps
0x05=38400 bps
0x06=57600 bps
0x07=115200 bps
Response:
C_SetInterfaceConfig +1 OperationCode
5.11.2. Reading the configuration of serial interface
Command:
C_ GetInterfaceConfig
Where:
Parameter name Parameter description Value range
C_GetInterfaceConfig
Serial interface configuration read-out 0x56
Odpowiedź:
C_ GetInterfaceConfig +1 Mode, Adr, Baudrate OperationCode
Where:
The meaning of response parameters is the same as described before.
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
32
5.12. Managing the events
The CTU-MxxM series readers has equipped with event memory of capacity
4400 records. Reason of event can be operation related to card or state changing on
reader outputs. The readers does not have RTC clock with battery back-up. After
supply failure, clock is reset to defaults: date: 1 January 2000, time: 00:00:00. Event
counter is not reset.
5.12.1. Setting the event recorder
Command frame:
Header C_SetEventTrig CardTrig, IO1Trig CRC
Wherein:
Parameter name Parameter description Value range
C_SetEventTrig
0x7C
CardTrig
In1Trig-In4Trig
Setting the event masking 0x7C
Masking the events related to card
(see below)
Masking the events related to inputs
(see below)
0x00 - 0xFF
0x00-0xFF
Response frame:
Header C_SetEventTrig+1 OperationCode CRC
Masking byte of events related to card
Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1
Reserve Out of
memory
Card
removal
Card
adding
Reserve Master
card
Outside
base card
Inside
base
card
E.g. byte 0x25(00100101) means that events will be written in case of:
inside base card has been red-out,
card written as master has been written,
inside base card has been removed
Masking bytes related to inputs state change
Byte Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1
IO1Trig IO[3]F IO[3]R IO[2]F IO[2]R IO[1]F IO[1]R IO[0]F IO[0]R
Bits IO[n]R denote reaction to the input n positive slope,
Bits IO[n]F denote reaction to the input n negative slope
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
33
E.g. In4Trig-In1Trig configuration byte sequence: 0x00,0x31,0x40,0x08, causes, that
events will be written in case of:
−
Any state change of input with index 10 occurs
−
Positive slope appears on input with index 8
−
Positive slope appears on input with index 7
−
Negative slope appears on input with index 1
During configuring the event triggers, decide which port is configured as an input. Do
not configure events for those I/O’s, which are outputs.
To guarantee correctness of event write process, time between two subsequent
triggers must be longer than 20 ms.
5.12.2. Reading the event recorder
Command frame:
Header C_GetEventTrig CRC
Wherein:
Parameter name Parameter description Value range
C_GetEventTrig
0x7E
Reading the configuration of event recorder 0x7E
Response frame:
Header C_GetEventTrig+1 CardTrig, In1Trig OperationCode CRC
5.12.3. Reading the counters related to event memory.
Command frame:
Header C_GetEventParam CRC
Wherein:
Parameter name Parameter description Value range
C_GetEventParam
0x78
Reading the configuration of event recorder 0x78
Response frame:
Header
C_GetEvent
Param+1
CapL, CapH, PointerL,
PointerH,TotB3,TotB2,TotB1,TotB0
OperationCode CRC
CapH:CapL – two-byte value, which defines event memory capacity.
PointerH:PointerL – two-byte value, which marks from first free event.
TotB3:TotB2:TotB1:TotB0 – four-byte value, which defines number of events recorded
from the moment of counter reset.
Events are recorded in sequence from index 0 up to Cap-1. In the moment memory
gets full, the counter is being “overturned”, and older inputs are overwritten.
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
34
Out of
Example:
If using C_GetEventParam command, we have red that event memory capacity is
4400 inputs; the total value of input events is 5678. For instance, if we want to read
the event with no. 5600, event index event of interest will be 5678-4400=1278.
If we want to read the last event, we can use Pointer value. The last event index will
be Pointer-1.
5.12.4. Reading the events
Command frame:
Header C_GetEvent EvNoL, EvNoH CRC
Wherein:
Parameter name Parameter description Value range
C_GetEvent
0x7a
Reading the event 0x7a
EvNoL,EvNoH LSB and MSB of event index
Response frame:
Header C_GetEvent+1
YY,MM,DD,hh,mm,ss,type,
B1,B2,B3,B4,B5
OperationCode CRC
YY,MM,DD – year, month, day of event occurrence
hh,mm,ss - hour, minute, second of event occurrence
type - event type
Depending on value “type” the 8-th bit of byte, there are distinguished two
assignments:
Bit8 Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1
0 – card
memory
Removed Added reserved Master Outside
base
Inside
base
1 -inputs reserved reserved reserved N4 N2 N1 N0
N4:N0 –number of input, on which event trigger signal appeared.
If given event was related to card, the B1-B5 bytes comprise card ID number.
B1 B2 B3 B4 B5
UID1 UID2 UID3 UID4 UID5 (Unique)
If event is related to input change, B1-B5 bytes comprise information regarding
input state, and have format:
B1 B2 B3 B4 B5
IO0 IO1 IO2 IO3 Reserved Reserved Reserved Reserved
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
35
Number of sector, in which the application is
5.13. MAD – Mifare Application Directory
5.13.1. Card MAD formatting
Command frame:
Header C_FormatMad Type, Infobyte CRC
Wherein:
Parameter name Parameter description Value range
C_FormatMad
0xA8
Type
Infobyte Mark in emitent sector (default 0x00) 0x00-0x1F
Response frame:
Header C_FormatMad+1 OperationCode CRC
Notes:
Before you run C_FormatMad command:
• switch AutoReader mode off (using C_SetAutoReaderConfig command)
• load the keys (default 0xff,0xff,0xff,0xff,0xff,0xff)
• turn antenna supply on (using C_TurnOnAntennaPower)
• select the cart (using C_Select command)
• login to sector with number 0, using key of AA type
Formatting to MAD 0xA8
1 - MAD1 (15 sectors)
2 – MAD2 (30 sectors)
0x01,0x02
5.13.2. Adding the application to MAD directory
Command frame:
Header C_AddApplication LSB, MSB, Sector CRC
Wherein:
Parameter name Parameter description Value range
C_AddApplication Adding application 0xAA
LSB LSB of application number 0x00 - 0xFF
MSB MSB of application number 0x00 - 0xFF
Sector
to be present
0x01-0x0F :MAD1
0x01-0x1F :MAD2
Response frame:
Header C_AddApplication+1 OperationCode CRC
Notes:
Application number should be other than 0x0000
Before you run C_AddApplication command:
• switch AutoReader mode off (using command C_SetAutoReaderConfig)
• load the keys (default 0xff,0xff,0xff,0xff,0xff,0xff)
• turn antenna supply on (using C_TurnOnAntennaPower command)
• select the card (using C_Select command)
• login to sector with number 0, using key of AA type
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
36
5.13.3. Pursuing the sector for given application
Command frame:
Header C_GetSectorMad LSB, MSB CRC
Wherein:
Parameter name Parameter description Value range
C_GetSectorMad
0xAC
Pursuing the sector 0xAC
LSB LSB of application number 0x00 - 0xFF
MSB MSB of application number 0x00 - 0xFF
Response frame:
Header C_GetSectorMad+1 Sector OperationCode CRC
Notes:
Before you run C_GetSectorMad command:
switch AutoReader mode off (using C_SetAutoReaderConfig command)
• load the keys (using 0xff,0xff,0xff,0xff,0xff,0xff)
• turn antenna supply on (using C_TurnOnAntennaPower command)
• select the card (using C_Select command)
• login to sector with number 0, using key of AA type
If response byte is 0x00, it will mean, that given application is not present in MAD
catalogue.
5.13.4. Pursuing the next sector of application
Command frame:
Header C_GetSectorMadNext LSB, MSB CRC
Wherein:
Parameter name Parameter description Value range
C_GetSectorMad Pursuing the next sector 0xAE
Response frame:
Header C_GetSectorMadNext+1 Sector OperationCode CRC
Notes:
Before you run C_GetSectorMadNext command, perform sector searching operation
using C_GetSectorMad, command, of which pursuing result was other than 0.
If response byte is 0x00, it will mean, than no more sectors have been found for given
application.
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
37
5.14. Other commands
5.14.1. Remote reset of reader
Command frame:
Header C_Reset CRC
Where:
Parameter name Parameter description Value range
C_Reset Remote reader reset 0xd0
Response frame:
Header C_Reset +1 OperationCode CRC
5.14.2. Reading-out the reader software
Command frame:
Header C_FirmwareVersion CRC
Where:
Parameter name Parameter description Value range
C_FirmwareVersion Read-out of reader software version 0xfe
Response frame:
Header C_FirmwareVersion+1 Data1…..n OperationCode CRC
Where:
Data1…n is sequence of dots, which are written as an ASCII codes.
5.14.3. Change buzzer volume
Use this command to set and store setting in EEPROM memory.
Command frame:
Header C_BuzzerConfig volume CRC
Gdzie:
Parameter name Parameter description Value range
C_BuzzerConfig 0xD8
volume Buzzer volume value 0x00-0x0a
Response frame:
Header C_BuzzerConfig+1 OperationCode CRC
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
38
5.15. Code meanings in response frames
Operation code name Description Value
OC_Error Error 0x00
OC_ParityError Parity error 0x01
OC_RangeError Parameter range error 0x02
OC_LengthError Data quantity error 0x03
OC_ParameterError Parameter error 0x04
OC_Busy Internal modules are busy at the moment. 0x05
OC_NoACKFromSlave No internal communication 0x22
OC_CommandUnknown
OC_WrongPassword Wrong password or last password terminated i.e.
OC_NoCard No transponder 0x0a
OC_BadFormat Wrong data format. 0x18
OC_FrameError Transmission error. Noise occurrence possible. 0x19
OC_NoAnswer No response from transponder. 0x1E
OC_TimeOut Operation time out. No transponder in reader field
OC_Successful Operation completed successfully. 0xff
Unknown command 0x07
0x09
automatic LogOut occurred.
0x16
possible.
6. Meaning of symbols used in the specification
**Sectors and block numeration
For S50 cards:
SectorNo=0x00…0x0f
BlockNo=0x00…0x03
For S70 cards:
SectorNo=0x00…0x20 BlockNo=0x00…0x03
SectorNo=0x21…0x27 BlockNo=0x00…0x0f
7. Mechanism of Master ID
Master ID mechanism is based on principle the quick adding/removing of user card
to/out of reader memory by means of „master card”.
If you want to register a card as a „master card”, it is required to clear card
memory first by means of reset function to factory defaults.
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
39
After clearing the memory, apply selected card to module, whenever you like. This
moment, the card becomes “master card”. It is impossible to remove or add the
master card by means of other card.
If you want to register a card as a “user card”, apply “master card” to reader first,
and next during five seconds, apply registered card.
If you want to remove “user card” from memory, apply “master card” to reader
first, and next during five seconds apply card which is being removed.
After applying to a reader the “user card”, the reader enables electric output, which
has been programmed as a controlled by internal access control mechanism.
8. Reset to default settings
To restore default settings, connect reset terminal with ground for 2 s or longer. During
restoring the defaults following reader parameters are fixed:
Parameter name or functionality Value or setting
Address on serial bus 0x01
Baud rate on serial bus 9600 bps
Access password 0x0 - no password
Port 0 Common purpose input
Port 1 Common purpose input
Port 2 lock “on” indication
Port 3 lock “on” indication
“Autoreader” configuration 0x2,0x14,0x1,0x1,0x01,0xff
Transponder type Unique
Whole internal memory of transponders with
Master card
0xff 0xff 0xff 0xff means “memory
cleared”
9. Operation example of transponder
After correct connection of reader and achieving the bi-directional communication
between the reader and master computer, it is possible to perform read-out and write
operation of transponder memory.
Following operation assumes, that reader is in default condition, and applied S50
card is in default condition too. It means this card has full access rights and both 0xff ff
ff ff ff ff keys.
Logging to the reader is to make changes in its factory configuration.
C_LoginUser, 0x31, 0x32, 0x33, 0x34, 0x00
Because during manual experiments, time between subsequent commands sent via
serial interface is large and reaches values from some second to some minutes, it is
required to disable internal UID automatic read-out device.
It should be done by means of command:
NETRONIX .
CTU
-
Mxx
NETRONIX CTU-Mxx
40
SetAutoReaderConfig with parameters: 0x00, 0x00, 0x00, 0x00.
To read-out the transponder, first load key to key memory.
So load the key to SKB, by means of:
C_LoadKeyToSKB, 0xff, 0xff, 0xff, 0xff, 0xff, 0xff, 0x00
Enable the field.
TurnOnAntennaPower, 0x01
Apply transponder to reader.
Select transponder
C_Select, 0x00
Login to e.g. sector 3.
C_LoginWithSKB, 0x03, 0xAA, 0x00
Read-out 2nd block content in 3rd sector.
C_ReadBlock, 0x02
If all Operation Codes in response frames were marked as OC_Successful, so
obtained values are the values which have been red-out from the block.
Latest news concerning to
products
http://www.netronix.pl/
NETRONIX .
Loading...
