Netopia CLI 874 User Manual

Command Line Interface Commands Reference

Firmware Version 8.7.4

Motorola Netopia® ENT-Series Routers

2 Command Line Interface Commands Reference

used to make any derivative work (such as translation, transformation or adaptation) without written permission from Motorola, Inc.

Motorola reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of Motorola to provide notiﬁcation of such revision or change. Motorola provides this guide without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and ﬁtness for a par ticular purpose. Motorola may make improvements or changes in the product(s) described in this manual at any time. MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Ofﬁce. Microsoft, Windows, Windows Me, and Windows NT are either trademarks or registered trademarks of Microsoft Corporation in the U.S and/or other countries. Macintosh is a registered trademark of Apple, Inc. Firefox is a registered trademark of the Mozilla Foundation. All other product or service names are the property of their respective owners.

Motorola, Inc. 1303 East Algonquin Road Schaumburg, Illinois 60196 USA

Firmware Version 8.7.4

Part Number

Motorola part number 6160028-00-24

Contents 3

Chapter 1 — Introduction.......................................................... 1-1

New Commands in Firmware Version 8.7.4...................... 1-1

Syntax Notation ............................................................. 1-2

Interface Naming Conventions ........................................ 1-3

Security (Conﬁguration Access) ....................................... 1-3

Entering and Editing Commands...................................... 1-3

Online Help ................................................................... 1-5

Chapter 2 — Motorola Netopia® Router CLI Commands ............. 2-1

Conﬁguration Access Commands .................................... 2-3

MAC Address Security Commands....................... 2-12

System Heartbeat Conﬁguration Commands.................. 2-13

Tiered Conﬁguration Access Commands ........................ 2-15

Interface Conﬁguration Commands ............................... 2-16

Additional LAN conﬁguration command ................ 2-16

Ethernet Interface conﬁguration commands ......... 2-18

Virtual LAN (VLAN) conﬁguration commands......... 2-36

RADIUS Authentication Proﬁle conﬁguration

commands ........................................................ 2-39

NetBIOS conﬁguration commands ....................... 2-41

Generic WAN Interface conﬁguration commands... 2-43

Restricted WAN Interface conﬁguration

commands ........................................................ 2-44

ISDN WAN Interface conﬁguration commands ...... 2-45

ADSL WAN Interface conﬁguration commands ...... 2-49

SDSL WAN Interface conﬁguration commands...... 2-51

Priority Queuing (TOS bit) Commands .................. 2-55

Differentiated Services (Diffserv) commands....... 2-56

PVCs................................................................. 2-58

DSL Line Type Interface Conﬁguration Commands 2-61

T1 WAN Interface conﬁguration commands .......... 2-62

T1 Statistic and Diagnostic commands................ 2-65

Unprotected Services Conﬁguration Commands ............. 2-68

4 Command Line Interface Commands Reference

IGMP Conﬁguration Commands..................................... 2-70

Global IP Conﬁguration Commands................................ 2-73

DHCP Gen-Options, Option Groups, and Option Filtersets

Commands.................................................................. 2-77

DHCP Gen-Options commands ............................ 2-77

DHCP Option Groups commands......................... 2-81

DHCP Option Filtersets commands...................... 2-82

Wireless Conﬁguration Commands ................................ 2-86

Wireless Privacy Commands (new and revised) .... 2-91

Wireless Multiple SSID Commands ..................... 2-93

Wireless MultiMedia (WMM) Conﬁguration

Commands........................................................ 2-96

ARP Conﬁguration Commands....................................... 2-97

ARP and Bridge timeout settings ......................... 2-98

Scheduled Connections Conﬁguration Commands .......... 2-98

Default Proﬁle Conﬁguration Commands ...................... 2-100

Frame Relay Conﬁguration Commands......................... 2-101

Miscellaneous Commands.......................................... 2-103

IP Network Address Translation (NAT) Commands......... 2-110

NAT Application Layer Gateway Commands ........ 2-114

Backup Conﬁguration Commands................................ 2-115

Serial port modem backup conﬁguration

commands ...................................................... 2-118

RADIUS Authentication Conﬁguration Commands ......... 2-119

TACACS+ Authentication Conﬁguration Commands ....... 2-120

IP Filterset Conﬁguration Commands ........................... 2-121

Hardware Acceleration Conﬁguration Commands.......... 2-123

Global IPSec/IKE Conﬁguration Commands.................. 2-124

IKE Dead Peer Detection .................................. 2-129

Xauth conﬁguration commands ......................... 2-130

Current Restrictions ................................................... 2-131

Chapter 3 — Motorola Netopia® Router Connection

Proﬁle Commands ................................................3-1

Contents 5

Connection Proﬁle Commands ........................................ 3-2

Note on Connection Proﬁle numbering sequence.. 3-10

PPTP commands................................................ 3-18

Manual connect/disconnect commands .............. 3-19

Backup conﬁguration commands......................... 3-19

RIP-2 MD5 conﬁguration commands .................... 3-19

IP NAT Passthrough Commands .......................... 3-20

Stateful Inspection Commands ........................... 3-21

L2TP Connection Proﬁle Conﬁguration Commands 3-22 GRE Connection Proﬁle Conﬁguration Commands . 3-23

CompuServe Login............................................. 3-24

IPSec/IKE ......................................................... 3-26

Chapter 4 — Motorola Netopia® Router Text Conﬁguration

Upload ................................................................. 4-1

TFTP Text Conﬁguration Upload Overview ......................... 4-1

SNMP ................................................................. 4-1

VT100 Menu Console........................................... 4-1

VT100 Command Line Console ............................. 4-2

Example Text Conﬁguration File....................................... 4-3

Chapter 5 — CLI Error Messages ..............................................5-1

Negative errors.............................................................. 5-1

Fatal system errors .............................................. 5-1

Parsing or tokenizing errors .................................. 5-1

Fatal syntax errors ............................................... 5-2

Voice command errors ....................................... 5-10

Fatal access control errors ................................. 5-11

Positive errors ............................................................. 5-11

Index of Commands ................................................................. 1-13

6 Command Line Interface Commands Reference

Introduction 1-1

Chapter 1

Introduction

This

Command Line Interface Commands Reference

Command Line Interface for the Motorola Netopia® router family. It provides information required to conﬁgure the router ﬁrmware and troubleshoot problems using the Command Line Interface.

This document is intended for small ofﬁce, home ofﬁce, and remote ofﬁce users, and other networking professionals who administer networks using Motorola Netopia® routers.

contains information on the syntax and use of the

Note:

version is noted, the commands given are supported on all platforms.

Restrictions among ﬁrmware versions are noted in the body of this document. Where no ﬁrmware

New Commands in Firmware Version 8.7.4

Firmware Version 8.7.4 adds new and revised commands for the following:

IP multicast to layer 2 unicast mapping. See “IGMP Conﬁguration Commands” on page 2-70.

■

Change backup timer from minutes to seconds. See “Backup Conﬁguration Commands” on page 2-115.

■

Support for router-generated packets with source address outside of local member range for IPSec force all tunnels. See “Unprotected Services Conﬁguration Commands” on page 2-68.

Enhanced VLAN Support and conﬁguration changes. See “Virtual LAN (VLAN) conﬁguration commands” on

■

page 2-36.

■

DHCP Filterset, Option Groups, DHCP Generic Options support. See “DHCP Gen-Options, Option Groups,

and Option Filtersets Commands” on page 2-77.

1-2 Command Line Interface Commands Reference

Syntax Notation

The command descriptions use formatted text to indicate various attributes of each command. The syntax is as follows:

Required keywords and commands that must be typed literally are in

■

Optional elements are enclosed in square brackets “[]”.

■

Mutually exclusive elements are contained in braces “{}” and separated by vertical bars “|”. Arguments for which you supply values are in

■

Examples of commands you type and the results of those commands are in the

■

An element that may be repeated one or more times is followed by a superscripted plus sign

■

An element that may be repeated zero or more times is followed by a superscripted asterisk

italics

boldface

courier

typeface.

“+”.

“*”.

Introduction 1-3

Interface Naming Conventions

A number of commands described in this document require you to identify the router inter face to be affected by the command. This requires specifying both an interface type (denoted (denoted id).

The

intf-type

argument may be replaced with one of the following keywords:

intf-type

) and an interface index

adsl | aux

If a command is not speciﬁc to a particular WAN interface type, the the more speciﬁc

Note:

The id argument can be replaced with 0, 1, or 2, as follows:

■

So, for example, the ethernet hublet is identiﬁed as “interface ethernet 0”. In some contexts, only a WAN interface may be speciﬁed, in which case the command syntax will specify

equipment.

For IDSL interfaces, use the keyword

means the motherboard

means the WAN 1 slot

means the WAN 2 slot

. The

wan-id

dds

ethernet

intf-type

argument can be replaced by either 1 (the WAN 1 slot) or 2 (the WAN 2 slot) on R-Series

must be speciﬁed.

isdn

sdsl

| t1 |

intf-type wan

wan

serial

may be speciﬁed; otherwise,

wan-id

instead of the more general

Security (Conﬁguration Access)

If the device is password-protected, the device requires you to enter a name and password before you can access the menu-based or command line console interface. See the section “Conﬁguration Access

Commands” on page 2-3.

Entering and Editing Commands

The device’s console user interface comes up in Menu mode by default. In this mode you use the arrow, Escape, and Return/Enter keys to navigate through a series of screens. To invoke the command line at any time, type Menu mode type Control-N again.

Control-N

. The console will erase the window, and you will be presented with a # prompt. To return to

1-4 Command Line Interface Commands Reference

The following table provides a description of keys that can be used when entering and editing commands. Control indicates the Control key, which must be pressed simultaneously with the associated letter key. Escape indicates the Escape key, which must be pressed and released ﬁrst, followed by its associated letter key. Keys are not case-sensitive.

Command Editing Keys and Functions

Key Function

Control-A Moves the cursor to the beginning of the command line.

Control-E Moves the cursor to the end of the command line.

Control-K Deletes all characters from the cursor to the end of the

command line.

Control-N Invokes the command line interface from the menu console.

Invokes the menu console from the command line interface.

Control-U Deletes all characters from the cursor back to the beginning of

the command line.

Control-W Deletes the word to the left of the cursor.

Escape B Moves the cursor back one word.

Escape D Deletes from the cursor to the end of the word.

Escape F Moves the cursor forward one word.

Introduction 1-5

Online Help

Beginning with Firmware Version 8.6, online help is available to prompt you when entering commands. If you enter a partial or incorrect command, the help facility displays prompts to aler t you to the correct syntax for the command. The help facility offers expected keywords from which to select, and an explanation of error messages.

Example:

If you enter the partial command the command is successfully entered.

#show snmp ; error 103: incomplete command ; acceptable next keywords: ; authentication ; community ; heartbeat-interval ; notify ; system ; trap #show snmp authentication ; error 103: incomplete command ; next keyword must be: ; traps #show snmp authentication traps ; error 103: incomplete command ; next keyword must be: ; enable #show snmp authentication traps enable snmp authentication traps enable no

show snmp

, the help facilty will prompt you with the appropriate keywords until

1-6 Command Line Interface Commands Reference

Motorola Netopia® Router CLI Commands 2-1

Chapter 2

Motorola Netopia® Router CLI Commands

This chapter describes the syntax of the supported command set of the Motorola Netopia® R-series, 4000-series, and 3000 Enterprise-series Router families.

“Conﬁguration Access Commands” on page 2-3

■

“MAC Address Security Commands” on page 2-12

“System Heartbeat Conﬁguration Commands” on page 2-13

■

“Tiered Conﬁguration Access Commands” on page 2-15

■

“Interface Conﬁguration Commands” on page 2-16

“Additional LAN conﬁguration command” on page 2-16

■

“Ethernet Interface conﬁguration commands” on page 2-18

■

“Ethernet Interface Stateful Inspection Commands” on page 2-22 “Virtual LAN (VLAN) conﬁguration commands” on page 2-36

■

“RADIUS Authentication Proﬁle conﬁguration commands” on page 2-39 “NetBIOS conﬁguration commands” on page 2-41

■

“Generic WAN Interface conﬁguration commands” on page 2-43

■ “Restricted WAN Interface conﬁguration commands” on page 2-44

■ “ISDN WAN Interface conﬁguration commands” on page 2-45

■ “ADSL WAN Interface conﬁguration commands” on page 2-49

■ “SDSL WAN Interface conﬁguration commands” on page 2-51

■ “Priority Queuing (TOS bit) Commands” on page 2-55

■ “Differentiated Services (Diffserv) commands” on page 2-56

■ “PVCs” on page 2-58

■ “DSL Line Type Interface Conﬁguration Commands” on page 2-61

■ “T1 WAN Interface conﬁguration commands” on page 2-62

■ “T1 Statistic and Diagnostic commands” on page 2-65

■ “Unprotected Services Conﬁguration Commands” on page 2-68

■ “IGMP Conﬁguration Commands” on page 2-70

■ “Global IP Conﬁguration Commands” on page 2-73

■ “DHCP Gen-Options, Option Groups, and Option Filtersets Commands” on page 2-77

■ “Wireless Conﬁguration Commands” on page 2-86

2-2 Command Line Interface Commands Reference

■ “ARP Conﬁguration Commands” on page 2-97

■ “Scheduled Connections Conﬁguration Commands” on page 2-98

■ “Default Proﬁle Conﬁguration Commands” on page 2-100

■ “Frame Relay Conﬁguration Commands” on page 2-101

■ “Miscellaneous Commands” on page 2-103

■ “IP Network Address Translation (NAT) Commands” on page 2-110

■ “Backup Conﬁguration Commands” on page 2-115

■ “Serial port modem backup conﬁguration commands” on page 2-118

■ “RADIUS Authentication Conﬁguration Commands” on page 2-119

■ “TACACS+ Authentication Conﬁguration Commands” on page 2-120

■ “IP Filterset Conﬁguration Commands” on page 2-121

■ “Hardware Acceleration Conﬁguration Commands” on page 2-123

■ “Global IPSec/IKE Conﬁguration Commands” on page 2-124

■ “IKE Dead Peer Detection” on page 2-129

■ “Xauth conﬁguration commands” on page 2-130

■ “Current Restrictions” on page 2-131

Conﬁguration Access Commands

date xx/yy/zz show date

exit

preferences changes immediate { yes | no } show preferences changes immediate no preferences changes immediate

preferences check vci { yes | no }

preferences console default { menu | cli } show preferences console default

preferences console timeout seconds no preferences console timeout show preferences console timeout

Motorola Netopia® Router CLI Commands 2-3

preferences date format { mm/dd/yy | dd/mm/yy | yy/mm/dd } show preferences date format

preferences output format { terse | verbose } show preferences output format

preferences output mask { bits | dotted-quad } show preferences output mask

preferences time format { am-pm | 24-hour } show preferences time format

security password no security password

snmp authentication traps enable [ yes | no ] no snmp authentication traps enable show snmp authentication traps enable

snmp community { ro | read-only no snmp community [ ro | read-only | rw | read-write ] [string]

| rw | read-write } string

2-4 Command Line Interface Commands Reference

Conﬁguration Access Commands (cont. 1)

snmp heartbeat-interval interval show snmp heartbeat-interval no snmp heartbeat-interval

snmp notify type [ v1-trap | v2-trap | inform ]

snmp system contact string show snmp system contact no snmp system contact

snmp system location string show snmp system location no snmp system location

snmp system name string show snmp system name no snmp system name

snmp system trap source address [ lan | wan ]

system syslog enable { yes | no } no system syslog enable show system syslog enable

system syslog host-name hostname no system syslog host-name show system syslog host-name

system syslog facility facility show system syslog facility

system syslog log-violations { yes | no } no system syslog log-violations show system syslog log-violations

system syslog log-accepts { yes | no } no system show system syslog log-accepts

syslog log-accepts

Conﬁguration Access Commands (cont. 2)

system syslog log-attempts { yes | no } no system syslog log-attempts show system syslog log-attempts

telnet { hostname | ip-addr } [ port value ] [ source ip_addr ] show telnet sessions

telnet suspend [ a... z ] show telnet suspend

telnet resume [ 1... 6 ]

telnet terminate [ 1... 6 ]

telnet server port [ port number ] show telnet server port

time hh:mm [ am | pm ] show time

Motorola Netopia® Router CLI Commands 2-5

user name password no user name [password]

MAC Address Security Commands

security mac-auth mode [ disabled | allow-list | deny-list ] show security mac-auth mode

security mac-auth wireless-only [ yes | no ] show security mac-auth wireless-only

security mac-auth mac-deny MAC-addr show security mac-deny

security mac-auth mac-allow MAC-addr show security mac-auth mac-allow

2-6 Command Line Interface Commands Reference

The preferences command allows you to customize certain aspects of the command line interface. Preference settings persist across restarts, and are speciﬁc to the user name, if any, you used to authenticate yourself before issuing the preferences command. If no users are deﬁned, no authentication is required, and preference settings are global.

date xx/yy/zz show date

These commands allow you to set or display the current date for the router’s system clock.

exit

The exit command terminates your current console session. If you are connected via telnet or a modem, the connection will be closed. If you are logged in via the serial console, you will return to the command line or menu-based console based on your default console setting. (See the preferences console default command on

page 2-6.) In either case, you will be prompted either with a login prompt (if one or more users are deﬁned), or

the initial prompt for the selected console interface (if no users are deﬁned).

preferences changes immediate { yes | no } show preferences changes immediate no preferences changes immediate

These commands allow you to specify whether or not WAN conﬁguration changes will take effect immediately. When you specify no, any changes you make to the WAN conﬁguration (except NAT) will not take effect until the router is reset.

Note: The router will reboot immediately when the value of the changes immediate preference item changes.

No warning is given.

preferences check vci { yes | no }

Note: This command is supported beginning with ﬁrmware version 8.2.

This command allows you to set the VCI to any value in the CLI, menu, or SNMP. The ability to set a VCI to 0 – 31 is not normally permitted. This command allows you to override this check and allow a VCI of value 0 – 31.

preferences console default { menu | cli } show preferences console default

The preferences console default command speciﬁes the console interface that will be presented to the user on subsequent logins. When set to menu (the default), the user will be presented with the menu-based console interface on subsequent logins. When set to cli, the user will be presented with the command line console interface on subsequent logins. If the preferences console default command is issued and there are no users deﬁned, the setting will determine the console interface that will be presented to all newly established console sessions (via either the serial console port or via telnet).

Motorola Netopia® Router CLI Commands 2-7

preferences console timeout seconds no preferences console timeout show preferences console timeout

These commands control the command-line and menu-based console auto logout. Note that the no preferences console timeout command sets the timeout to zero, which disables the timeout.

The command:

no preferences console timeout

is equivalent to:

preferences console timeout 0

Example:

preferences console timeout 300

preferences date format { mm/dd/yy | dd/mm/yy | yy/mm/dd } show preferences date format

These commands allow you to set or display your date formatting preferences for the router’s system clock.

preferences output format { terse | verbose } show preferences output format

The preferences output format command affects the format of the output from show commands. When set to verbose (the default), the output from show commands is formatted as a valid command line interface command that could be entered at a command prompt. When set to terse, the output from show commands is

not formatted as a valid command line interface command that could be entered at a command prompt, but rather includes only the value of the requested attribute. The terse mode may be more useful if the output will be processed by a computer rather than a human being.

Example:

#preferences output format verbose #show interface ethernet 0 ip address interface ethernet 0 ip address 192.168.1.1/24 #preferences output format terse #show interface ethernet 0 ip address

192.168.1.1/24

2-8 Command Line Interface Commands Reference

preferences output mask { bits | dotted-quad } show preferences output mask

The preferences output mask command affects the format of the output from those show commands that display an IP address together with a subnet mask. When set to bits (the default), the IP address and subnet mask are output in preﬁx notation – i.e., an IP address in dotted-quad notation followed by a slash followed by the number of consecutive ones-bits in the subnet mask – whereas when set to dotted-quad, the IP address and subnet mask are output as two consecutive dotted-quads.

Example:

#preferences output mask bits #show interface ethernet 0 ip address interface ethernet 0 ip address 192.168.1.1/24 #preferences output mask dotted-quad #show interface ethernet 0 ip address interface ethernet 0 ip address 192.168.1.1 255.255.255.0

preferences time format { am-pm | 24-hour } show preferences time format

These commands allow you to set or display your time formatting preferences for the router’s system clock.

security password

Enter old password: old password Enter new password: new password Re-enter password: new password

no security password

Enter old password:old password

These commands let you set and delete the Security Options screen password. After you enter the command the console prompts you for the existing password if you have one, then it prompts you to enter and re-enter a new password (eleven characters maximum). The no command will prompt you for a password if there was one, and will then delete that password.

snmp authentication traps enable [ yes | no ] no snmp authentication traps enable show snmp authentication traps enable

These commands allow you to enable, disable, or show the status of SNMP authentication traps.

snmp community { ro | read-only | rw | read-write } string no snmp community [ ro | read-only | rw | read-write ] [string]

These commands allow you to add or delete the SNMP community Read-Only and Read-Write strings.

Motorola Netopia® Router CLI Commands 2-9

snmp heartbeat-interval interval show snmp heartbeat-interval no snmp heartbeat-interval

Note: These commands are supported beginning with ﬁrmware version 8.2.

These commands allow you to set, show, or delete the SNMP heartbeat interval. A single conﬁguration item governs heartbeat traps, the time interval between traps. Permitted values are 0 – 65535 minutes. A value of zero, the default, means the trap is disabled. This value can be conﬁgured by the CLI and SNMP. When the interval value is set to a positive number, a trap is sent immediately and the new (or same) interval value takes effect.

snmp notify type [ v1-trap | v2-trap | inform ]

Note: This command is supported beginning with ﬁrmware version 8.4.2.

This command allows you to set the type of SNMP traps that the system will generate: v1, v2(c), or, beginning with Firmware Version 8.4.2, inform.

snmp system contact string show snmp system contact no snmp system contact

These commands set, display, or clear the router's SNMP system contact (sysContact) string.

snmp system location string show snmp system location no snmp system location

These commands set, display, or clear the router's SNMP system location (sysLocation) string.

snmp system name string show snmp system name no snmp system name

These commands set, display, or clear the router's SNMP system name (sysName) string.

snmp system trap source address [ lan | wan ]

Note: This command is supported beginning with ﬁrmware version 8.5.

This command allows you to specify whether the source address for SNMP traps should be on the LAN or the WAN. When this parameter is set to lan, all SNMP v2 and inform traps use the source IP address of the primary LAN interface. Otherwise, the IP address of the WAN interface is used.

system syslog enable { yes | no } no system syslog enable show system syslog enable

Note: These commands are supported beginning with Firmware Version 8.2.

2-10 Command Line Interface Commands Reference

These commands allow you to enable, disable, or show the status of logging of system events for reporting by a Syslog client. By default, all events are logged in the event history. By using the syslog commands that follow to set each event descriptor to either yes or no, you can determine which ones are logged and which are ignored.

system syslog host-name hostname no system syslog host-name show system syslog host-name

Note: These commands are supported beginning with Firmware Version 8.2.

These commands allow you to specify, disable, or show the status of the syslog server’s address either in dotted decimal format or as a DNS name up to 64 characters.

system syslog facility facility show system syslog facility

Note: These commands are supported beginning with Firmware Version 8.2.

These commands allow you to specify or show the UNIX syslog Facility. facility values may be "local0" through "local7".

system syslog log-violations { yes | no } no system syslog log-violations show system syslog log-violations

Note: These commands are supported beginning with Firmware Version 8.2.

These commands allow you to enable, disable, or show whether violations are logged or ignored.

system syslog log-accepts { yes | no } no system syslog log-accepts show system syslog log-accepts

Note: These commands are supported beginning with Firmware Version 8.2.

These commands allow you to enable, disable, or show whether acceptances are logged or ignored.

system syslog log-attempts { yes | no } no system syslog log-attempts show system syslog log-attempts

Note: These commands are supported beginning with Firmware Version 8.2.

These commands allow you to enable, disable, or show whether connection attempts are logged or ignored.

Motorola Netopia® Router CLI Commands 2-11

telnet { hostname | ip-addr } [ port value ] [ source ip_addr ] show telnet sessions

Note: These commands are supported beginning with Firmware Version 8.7.

These commands allow you to initiate or show up to six telnet sessions from the command line without returning to the console menu interface. Using the command line, you can resume sessions star ted by the console menu and vice versa.

Example:

#show telnet sessions

#1 192.168.1.253 #2 192.168.1.91 #3 10.8.200.16 #4 no active session #5 no active session #6 no active session

telnet suspend [ a... z ] show telnet suspend telnet resume [ 1... 6 ] telnet terminate [ 1... 6 ]

Note: These commands are supported beginning with Firmware Version 8.7.

These commands allow you to suspend telnet sessions indicated by alphabetic letter, a through z, from the command line.

Telnet sessions speciﬁed by number, 1 through 6, may be resumed or terminated. The show command displays telnet sessions that have been previously suspended using the suspend

command.

telnet server port [ port number ] show telnet server port

These commands allow you to set or display the TCP port on which the router is currently listening for incoming telnet management sessions. If you change the port number, the router will immediately stop accepting new sessions at the old port number, and only accept incoming sessions on the new port number. All sessions currently connected to the old por t number will remain connected. Allowed values for por t number are 1 65535, except for 80 and 1723.

time hh:mm [ am | pm ] show time

These commands allow you to set or display the current time for the router’s system clock.

2-12 Command Line Interface Commands Reference

MAC Address Security Commands

Note: These commands are supported beginning with ﬁrmware version 8.5.

security mac-auth mode [ disabled | allow-list | deny-list ] show security mac-auth mode

These commands allow you to conﬁgure or display the global MAC authentication mode. If set to allow-list, all non-matching unicasts will be dropped. If set to deny-list, all matching unicasts will be dropped.

security mac-auth wireless-only [ yes | no ] show security mac-auth wireless-only

These commands allow you to restrict or display the restricted status of MAC address authentication. If set to yes, the MAC authentication applies only to the wireless interface, on models so equipped. If set to no, packets received at all interfaces on the LAN are subject to the MAC ﬁltering table.

security mac-auth mac-deny MAC-addr show security mac-deny

These commands allow you to specify or display the MAC address for hosts on the wired or wireless LAN (if so restricted) whose source or destination MAC address will cause the router to ﬁlter their packets.

security mac-auth mac-allow MAC-addr show security mac-auth mac-allow

Note: Wireless MAC authentication commands are also supported. See “Wireless Conﬁguration Commands”

on page 2-86.

Motorola Netopia® Router CLI Commands 2-13

System Heartbeat Conﬁguration Commands

Note: The commands in this section are supported beginning with ﬁrmware version 8.5.

System Heartbeat Conﬁguration Commands

heartbeat enable { yes | no } show heartbeat enable

heartbeat protocol { udp | tcp } show heartbeat protocol

heartbeat client-por t por t show heartbeat client-por t

heartbeat interval time (in seconds) show heartbeat interval time

heartbeat count count show heartbeat count

heartbeat sleep-time time (in seconds) show heartbeat sleep-time

heartbeat server port por t show heartbeat server port

heartbeat server address address show heartbeat server address

heartbeat server url url show heartbeat server url

heartbeat interval contact-email email_address show heartbeat interval contact-email

heartbeat interval location location show heartbeat interval location

reset heartbeat

2-14 Command Line Interface Commands Reference

heartbeat enable { yes | no } show heartbeat enable

These commands allow you to enable, disable, or show the status of the system heartbeat. Once a unit is conﬁgured and restarted, the WAN link is up and the WAN IP address is established, the

heartbeat will begin executing and sending its payloads (or establishing its connection in the case of TCP). A special case is when the ip-server address is on the LAN. In this case, the payloads will be routed to the LAN side address, but only after the WAN link and WAN IP addresses have been established.

If, at any time during the heartbeat sequence, the link state changes – which means, for example, that there is a layer 1 disconnect or a change in the IP layer parameters from a DHCP acquisition or a renegotiated PPP session – the sequence will restart. You can also restart the sequence manually. In addition, in TCP mode once the connection has been established, the sequence will be restarted any time the remote server closes it.

heartbeat protocol { udp | tcp } show heartbeat protocol

These commands allow you to specify or show the protocol to be used for the system heartbeat, udp or tcp. The heartbeat is a state machine:

■ If you select udp, there are no connections to the server. If the server address is known, it simply sends

the payloads in UDP.

■ If you select tcp, it tries to connect to the server address, and keeps trying to connect for 20 attempts at

thirty-second intervals. If a connection is not established, it sleeps for a minimum of either 30 minutes, or whatever is programmed as the sleep-time. See below.

heartbeat client-por t por t show heartbeat client-por t

These commands allow you to specify or show the client port to be used for the system heartbeat.

heartbeat interval time (in seconds) show heartbeat interval

These commands allow you to specify or show the heartbeat interval. in seconds.

heartbeat count count show heartbeat count

These commands allow you to specify or show the heartbeat count within the speciﬁed interval.

heartbeat sleep-time time (in seconds) show heartbeat sleep-time

These commands allow you to specify or show the heartbeat sleep time, in seconds, during which the system will wait before retrying a failed connection attempt, if tcp is the speciﬁed protocol.

heartbeat server port por t show heartbeat server port

These commands allow you to specify or show the heartbeat server port number.

Motorola Netopia® Router CLI Commands 2-15

heartbeat server address address show heartbeat server address

These commands allow you to specify or show the heartbeat server IP address. Beginning with Firmware Version 8.5.1, the address can also be a DNS name of up to 63 characters.

heartbeat server url url show heartbeat server url

These commands allow you to specify or show a heartbeat server URL.

heartbeat interval contact-email email_address show heartbeat interval contact-email

These commands allow you to specify or show an email address to be placed into the heartbeat Xml payload.

heartbeat interval location location show heartbeat interval location

These commands allow you to specify or show a location to be placed into the heartbeat Xml payload.

reset heartbeat

This command allows you to restart the heartbeat sequence.

Tiered Conﬁguration Access Commands

superuser name password show superuser no superuser

user name password [ { wan | lan | cp | nat | pvc | global | subnet | voice | no-web | no-telnet }*] show user no user name

superuser name password show superuser no superuser

These commands allow you to create, show, or delete a Superuser. You can only conﬁgure a Superuser if no authorized users exist. There can be but one Superuser. The Superuser can change any attributes of any user, including itself. However, even the Superuser cannot see what the password for a user is – the show command will display 5 asterisks regardless of its actual length.

2-16 Command Line Interface Commands Reference

user name password [ { wan | lan | cp | nat | pvc | global | subnet | no-telnet }*] show user no user name

These commands allow a Superuser to create, show, or delete a user and his/her access privileges. A user can change only his/her own password, and cannot change their access privileges. If a Superuser creates a new user, this user inherits the privileges of the ﬁrst non-Superuser, or has the default access privileges of lan | subnet | nat | cp | global if there is no non-Superuser conﬁgured.

Permissible modiﬁers are:

wan

lan

nat

pvc

global

subnet

no-telnet

WAN interface(s) conﬁguration

LAN (Ethernet id) interface conﬁguration

connection proﬁle (and default proﬁle) conﬁguration

Network Address Translation conﬁguration. This includes the ability to conﬁgure NAT attributes in connection proﬁles.

ATM PVC and Frame DLCI conﬁguration

other parameters, such as console preferences. This includes ping and traceroute functionality.

LAN (Ethernet 0) interface ip subnet conﬁguration

Prevents Telnet access.

Interface Conﬁguration Commands

Additional LAN conﬁguration command

Note: Beginning with Firmware Version 8.4.2, the ﬁrmware includes support for creating additional logical

local area networks. When used in combination with VLANs (see “Virtual LAN (VLAN) conﬁguration commands”

on page 2-36), you can maintain separate functional end-to-end networks to support such services as

voice-over-IP, point-of-sale applications, or audio and video ser vices.

Multiple logical IP LAN support allows you to create additional IP routed LAN interfaces (ALANs). You can add, edit, or delete Additional LANs similarly to Connection Proﬁles on the WAN connection. You then associate physical or logical Ethernet-encapsulated interfaces, such as wired Ethernet por ts, wireless SSIDs, and ATM RFC 1483 bridged VCs by attaching the ALAN to a VLAN containing these interfaces.

The additional LAN IP routed interfaces duplicate all the same parameters that apply to the primary LAN interface, such as DHCP servers, ﬁltersets, multicast forwarding, and RIP. You can conﬁgure up to six ALANs.

Motorola Netopia® Router CLI Commands 2-17

interface ethernet id [ yes | no ]

This command allows you to create or delete an additional LAN (ALAN) of id id. If you create an ALAN, you must provision it with the same parameters that apply to the primary LAN.

Example:

interface ethernet 2 yes

interface ethernet 2 tag "Telecommuter"

interface ethernet 2 enable yes

interface ethernet 2 ip address 3.0.0.1/8

interface ethernet 2 ip rip receive both

interface ethernet 2 ip rip transmit no

interface ethernet 2 ip multicast-fwd no

interface ethernet 2 address-serve enable no

interface ethernet 2 address-serve clients none

interface ethernet 2 address-serve dhcp lease-time 1

interface ethernet 2 address-serve gateway default 3.0.0.1/8

interface ethernet 2 address-serve mode server

interface ethernet 2 address-serve netbios mode enable no

interface ethernet 2 address-serve netbios mode type b-node

interface ethernet 2 address-serve netbios scope enable no

interface ethernet 2 address-serve netbios name-server enable no

interface ethernet 2 address-serve netbios name-server address 0.0.0.0

interface ethernet 2 address-serve range 3.0.0.100 3.0.0.199

interface ethernet 2 mac address 00:00:c5:fa:dd:04

2-18 Command Line Interface Commands Reference

Ethernet Interface conﬁguration commands

Ethernet Interface Conﬁguration Commands

interface ethernet id ip address [{ ip-addr/ mask-bits | ip-addr mask | secondary }] no interface ethernet id ip address [{ ip-addr/mask-bits | ip-addr mask | secondary }] show interface ethernet id ip address

interface ethernet id ip dhcp client mode { standard | copper-mountain | cmn } show interface ethernet id ip dhcp client mode

interface ethernet id ip multicast-fwd { yes | no } no interface ethernet id ip multicast-fwd show interface ethernet id ip multicast-fwd

interface ethernet id ip igmp-version { v1 | v2 | v3 } show interface ethernet id ip igmp-version

interface ethernet id mac address { MAC-address | default } show interface ethernet id mac address

interface ethernet id mode { autonegotiate | 100full | 100half | 10full | 10half | 100full-ﬁxed | 100half-ﬁxed | 10full-ﬁxed | 10half-ﬁxed } show interface ethernet id mode

interface ethernet id ip nat enable { yes | no } no interface ethernet id ip nat enable show interface ethernet id ip nat enable

interface ethernet id ip nat map-list list-tag no interface ethernet id ip nat map-list show interface ethernet id ip nat map-list

interface ethernet wan-id ip nat passthrough enable { yes | no } no interface ethernet id ip nat passthrough enable show interface ethernet id ip nat passthrough enable

interface ethernet wan-id ip nat passthrough dhcp enable { yes | no } no interface ethernet wan-id ip nat passthrough dhcp enable show interface ethernet wan-id ip nat passthrough dhcp enable

Motorola Netopia® Router CLI Commands 2-19

Ethernet Interface Conﬁguration Commands (continued)

interface ethernet wan-id ip nat passthrough dhcp mac-address { mac-address } show interface ethernet wan-id ip nat passthrough dhcp mac-address

interface ethernet id ip nat server-list list-tag no interface ethernet id ip nat server-list show interface ethernet id ip nat server-list

interface ethernet id ip netbios proxy enable { yes | no } no interface ethernet id ip netbios proxy enable show interface ethernet id ip netbios proxy enable

interface ethernet id pppoe enable { yes | no } no interface ethernet id pppoe enable show interface ethernet id pppoe enable

show interface ethernet id statistics show interface ethernet id stats

interface ethernet id ip ﬁlterset fs-id no interface ethernet id ip ﬁlterset show interface ethernet id ip ﬁlterset

2-20 Command Line Interface Commands Reference

Ethernet Interface RIP Conﬁguration Commands

interface ethernet id ip rip exclude-wan-routes no interface ethernet id ip rip exclude-wan-routes show interface ethernet id ip rip exclude-wan-routes

interface ethernet id ip rip receive { no | v1 | v2 | both | v2-md5 } no interface ethernet id ip rip receive show interface ethernet id ip rip receive

interface ethernet id ip rip transmit { no | v1 | v2broadcast | v2multicast | v2broadcast-md5 | v2multicast-md5 } no interface ethernet id ip rip transmit show interface ethernet id ip rip transmit

interface ethernet id ip rip auth key id no interface ethernet id ip rip auth key id show conﬁg interface ethernet id ip rip auth key

interface ethernet id ip rip auth key id start date date show interface ethernet id ip rip auth key id start date

interface ethernet id ip rip auth key id start time time show interface ethernet id ip rip auth key id start time

interface ethernet id ip rip auth key id end date date show interface ethernet id ip rip auth key id end date

interface ethernet id ip rip auth key id end time time show interface ethernet id ip rip auth key id end time

interface ethernet id rip auth key id end time mode { inﬁnite | date } show interface ethernet id ip rip auth key id end time mode

interface ethernet id rip auth key id key <string>

Motorola Netopia® Router CLI Commands 2-21

Ethernet Interface IP Address Serving Commands

interface ethernet id address-serve clients { any | none | { bootp | dhcp | macip | wan }+ } no interface ethernet id address-serve clients { any | { bootp | dhcp | macip | wan }+ } show interface ethernet id address-serve clients

interface ethernet id address-serve dhcp enable { yes | no } no interface ethernet id address-serve dhcp enable show interface ethernet id address-serve dhcp enable

interface ethernet id address-serve dhcp dns [ 1 | 2 ] ip-addr

interface ethernet id address-serve dhcp lease-time hours show interface ethernet id address-serve dhcp lease-time

interface ethernet id address-serve dhcp option 150 address www.xxx.yyy.zzz no interface ethernet id address-serve dhcp option 150 address www.xxx.yyy.zzz show interface ethernet id address-serve dhcp option 150 address

show interface ethernet id address-serve dhcp addresses

show interface ethernet id ip dhcp client status

interface ethernet id ip dhcp client [ renew | release ]

interface ethernet id address-serve dhcp next-server ip-addr

interface ethernet id address-serve gateway { gw-ip-addr | default { ip-addr/mask-bits | ip-addr mask } } show interface ethernet id address-serve gateway

interface ethernet id address-serve helper ip-addr no interface ethernet id address-serve helper [ip-addr] show interface ethernet id address-serve helper

interface ethernet id address-serve mode { relay | server } show interface ethernet id address-serve mode

interface ethernet id address-serve range { auto | from-addr to-addr } no interface ethernet id address-serve range from-addr to-addr show interface ethernet id address-serve range

interface ethernet id address-serve { no | off | on | yes } no interface ethernet id address-serve show interface ethernet id address-serve

2-22 Command Line Interface Commands Reference

Ethernet Interface Stateful Inspection Commands

interface ethernet id ip state-insp enable { yes | no | on | off } no interface ethernet id ip state-insp show interface ethernet id ip state-insp enable

interface ethernet id ip state-insp router-access { yes | no | on | off } no interface ethernet id ip state-insp router-access show interface ethernet id ip state-insp router-access

interface ethernet id ip state-insp tcp-seq-diff diff show interface ethernet id ip state-insp tcp-seq-diff

interface ethernet id ip state-insp deny-frag { yes | no | on | off } no interface ethernet id ip state-insp deny-frag show interface ethernet id ip state-insp deny-frag

interface ethernet id ip state-insp xposed-list xposed-list_name no interface ethernet id ip state-insp xposed-list show interface ethernet id ip state-insp xposed-list

Ethernet Interface Static Client Address Translation Commands

interface ethernet lan_inter face_id scat enable [ yes | no ] show interface ethernet lan_inter face_id scat enable

Motorola Netopia® Router CLI Commands 2-23

Ethernet Interface VRRP Commands

interface ethernet id ip vrrp vrouter id vrid vrid show interface ethernet id ip vrrp vrouter id vrid

interface ethernet id ip vrrp vrouter id vrip ip-addr show interface ethernet id ip vrrp vrouter id vrip

interface ethernet id ip vrrp vrouter id priority [ 1... 255 ] show interface ethernet id ip vrrp vrouter id priority

interface ethernet id ip vrrp vrouter id adv-intvl [ 1... 255 ] show interface ethernet id ip vrrp vrouter id adv-intvl

interface ethernet id ip vrrp vrouter id preempt-mode enable [ no | yes | on | off ] show interface ethernet id ip vrrp vrouter id preempt-mode enable

interface ethernet id ip vrrp vrouter id enable [ no | yes | on | off ] show interface ethernet id ip vrrp vrouter id enable

no interface ethernet id ip vrrp vrouter id

show interface ethernet id ip vrrp wan-monitor enable [ { yes | no | on | off } ] show interface ethernet id ip vrrp wan-monitor enable

interface ethernet id ip vrrp master-dhcp-srv enable [ { yes | no | on | off } ] show interface ethernet id ip vrrp master-dhcp-srv enable

interface ethernet id ip vrrp dhcp-gateway ip-addr show interface ethernet id ip vrrp dhcp-gateway

2-24 Command Line Interface Commands Reference

These commands allow you to set, delete, or show the IP subnet(s) of an Ethernet interface. If the keyword secondary is speciﬁed in the ﬁrst command, the subnet is appended to the list of subnets (assuming that all of the allowed subnets have not yet been conﬁgured– the router supports up to eight). If the keyword secondary is not speciﬁed, the primary subnet conﬁguration is replaced with the speciﬁed values. The mask may be speciﬁed either as a slash followed by the number of one-bits in the mask, or as a dotted quad.

The no interface ethernet id ip address command allows you to delete a particular subnet, all secondar y subnets, or all subnets associated with the speciﬁed Ethernet interface.

Examples:

The following are equivalent ways to set the primary subnet of the Ethernet interface to 192.168.1.1 with a Class C subnet mask:

interface ethernet 0 ip address 192.168.1.1/24

interface ethernet 0 ip address 192.168.1.1 255.255.255.0

To set a secondary subnet of the Ethernet interface to 207.1.1.16/28 (with four host bits):

interface ethernet 0 ip address 207.1.1.16/28 secondary

To delete a particular subnet from the list of subnets, specify the particular subnet:

no interface ethernet 0 ip address 207.1.1.16/28

To delete all secondary subnets:

no interface ethernet 0 ip address secondary

To delete all subnets:

no interface ethernet 0 ip address

To show the IP subnets of the Ethernet interface:

show interface ethernet 0 ip address

interface ethernet id ip dhcp client mode { standard | copper-mountain | cmn } show interface ethernet id ip dhcp client mode

These commands allow you to set or show the router’s DHCP mode, whether standard or copper-mountain. The connection proﬁle, default proﬁle, and IP conﬁguration structures now include a dhcp client mode setting

that selects between the standard RFC 2131 standards-based mode of operation (the default), and the cop- per-mountain or cmn proprietary mode of operation.

Motorola Netopia® Router CLI Commands 2-25

When the DHCP client is activated on a RFC1483 MER interface, it examines the dhcp client mode in the associated connection proﬁle (or the default proﬁle there was no explicitly conﬁgured connection proﬁle). If the dhcp client mode speciﬁes standard, the DHCP client initializes the htype and hlen ﬁelds in the header of its DHCP requests to the appropriate values for an RFC1483 MER interface (htype = 1 and hlen = 6). If the dhcp client mode speciﬁes copper-mountain or cmn, the DHCP client initializes the htype and hlen ﬁelds in the header of its DHCP requests to zero.

When the DHCP client is activated on an Ethernet WAN interface, it examines the dhcp client mode in the associated IP conﬁguration structure, and behaves as described above for the RFC1483 MER DHCP client.

Note: cmn is accepted as a synonym for copper-mountain.

interface ethernet id ip multicast-fwd { yes | no } no interface ethernet id ip multicast-fwd show interface ethernet id ip multicast-fwd

These commands allow you to set, disable, or show the multicast forwarding behavior on the speciﬁed Ethernet interface.

interface ethernet id ip igmp-version { v1 | v2 | v3 } show interface ethernet id ip igmp-version

These commands allow you to set or show the IGMP version to be used on the speciﬁed Ethernet interface. Beginning with Firmware version 8.7, v3 is the default.

interface ethernet id mac address { MAC-address | default } show interface ethernet id mac address

The ﬁrst command allows you to set the MAC Address for the speciﬁed interface. You can return it to the default by typing in a MAC Address consisting of all zeros or by typing default. The show command applies to the LAN of all models, as well as the WAN on Ethernet WAN models.

interface ethernet id mode { autonegotiate | 100full | 100half | 10full | 10half | 100full-ﬁxed | 100half-ﬁxed | 10full-ﬁxed | 10half-ﬁxed } show interface ethernet id mode

Note: These commands are supported beginning with ﬁrmware version 8.2.

These commands allow you to set or show the Ethernet speed and duplex conﬁguration to be used on the speciﬁed Ethernet interface. These commands only apply to 3300-Series products, single port Ethernet interface on either LAN or WAN. The default is auto-negotiation.

2-26 Command Line Interface Commands Reference

interface ethernet id ip netbios proxy enable { yes | no } no interface ethernet id ip netbios proxy enable show interface ethernet id ip netbios proxy enable

These commands allow you to enable, disable, or show the NetBIOS proxy status for the speciﬁed Ethernet interface. The NetBIOS proxy enables the ability to forward Windows Networking NetBIOS broadcasts. This is useful for, for example, a Virtual Private Network, in which you want to be able to browse the remote network to which you are tunnelling, as part of your Windows Network Neighborhood.

Routed connections, such as VPNs, can not use NetBEUI to carry the Network Neighborhood information. They need to use NetBIOS, because NetBEUI cannot be routed. This feature will allow browsing the Network Neighborhood without any additional workstation conﬁguration.

Note: Microsoft Network browsing is available with or without a Windows Internet Name Ser vice (WINS)

server. Shared volumes on the remote network are accessible with or without a WINS server. Local LAN shared volumes that have Port Address Translation (PAT) applied to them are not available to hosts on the remote LAN. For tunnelled trafﬁc, NAT on the WAN has no effect on the Microsoft Networking trafﬁc.

interface ethernet id address-serve dhcp enable { yes | no } no interface ethernet id address-serve dhcp enable show interface ethernet id address-serve dhcp enable

These commands allow you to enable, disable, or show the DHCP IP address serving behavior of the speciﬁed Ethernet interface. These commands do not affect the DHCP server mode. Consequently, if the router is set to DHCP relay these commands have no effect.

The show interface ethernet id address-serve dhcp command may also include the following keywords: available, leased, offered, and reserved. These return the count of client IP addresses in their respective states.

Examples:

show interface ethernet 0 address-serve dhcp report available

show interface ethernet 0 address-serve dhcp report leased

show interface ethernet 0 address-serve dhcp report offered

show interface ethernet 0 address-serve dhcp report reserved

interface ethernet id address-serve dhcp dns [ 1 | 2 ] ip-addr

Note: This command is supported beginning with ﬁrmware version 8.5.

This command allows you to specify the IP addresses of primary and secondary DNS servers served to the client for this interface. If they are not speciﬁed, the globally conﬁgured (or derived) DNS addresses are ser ved to the client instead.

These DNS addresses are not used internally by the router; the globally conﬁgured DNS addresses are used instead.

Motorola Netopia® Router CLI Commands 2-27

Note: These commands are supported beginning with ﬁrmware version 8.6.

These commands allow you to conﬁgure, remove, or show up to four TFTP IP addresses per ALAN to be served via option 150.

interface ethernet id ip rip exclude-wan-routes no interface ethernet id ip rip exclude-wan-routes show interface ethernet id ip rip exclude-wan-routes

Note: These commands are supported beginning with ﬁrmware version 8.7.

These commands allow you to specify, disable, or show the status of broadcasting WAN routes via RIP. This is available only if rip transmit is enabled for the interface. The default is no, but if enabled, will drop any RIP routes with non-LANside information from RIP updates sent over the inter face.

interface ethernet id ip rip receive { no | v1 | v2 | both | v2-md5 } no interface ethernet id ip rip receive show interface ethernet id ip rip receive

These commands allow you to set, delete, or show the RIP receive behavior of the speciﬁed Ethernet interface.

Example:

show interface ethernet 0 ip rip receive

interface ethernet id ip rip transmit { no | v1 | v2broadcast | v2multicast | v2broadcast-md5 | v2multicast-md5 }

no interface ethernet id ip rip transmit show interface ethernet id ip rip transmit

These commands allow you set, delete, or show the RIP transmit behavior of the speciﬁed Ethernet interface.

Examples:

show interface ethernet 0 ip rip transmit

interface ethernet id ip rip auth key id no interface ethernet id ip rip auth key id show conﬁg interface ethernet id ip rip auth key

These commands allow you to create, delete, or show the RIP-2 Authentication key(s) on the speciﬁed interface.

2-28 Command Line Interface Commands Reference

interface ethernet id ip rip auth key id start date date show interface ethernet id ip rip auth key id start date

These commands allow you to set or show a start date for the RIP-2 Authentication key(s) on the speciﬁed interface.

interface ethernet id ip rip auth key id start time time show interface ethernet id ip rip auth key id start time

These commands allow you to set or show a start time for the RIP-2 Authentication key(s) on the speciﬁed interface.

interface ethernet id ip rip auth key id end date date show interface ethernet id ip rip auth key id end date

These commands allow you to set or show an end date for the RIP-2 Authentication key(s) on the speciﬁed interface. The acceptable year range is from 1904 – 2039.

interface ethernet id ip rip auth key id end time time show interface ethernet id ip rip auth key id end time

These commands allow you to set or show an end time for the RIP-2 Authentication key(s) on the speciﬁed interface.

interface ethernet id rip auth key id end time mode { inﬁnite | date } show interface ethernet id ip rip auth key id end time mode

These commands allow you to set or show the end time mode for the RIP-2 Authentication key(s) on the speciﬁed interface. date speciﬁes that an expiration date and time will be used; inﬁnite speciﬁes that the key will never expire.

interface ethernet id rip auth key id key <string>

These commands allow you to assign a RIP-2 Authentication key. Keys must be manually entered and must consist of 1 – 16 ASCII characters each.

interface ethernet id pppoe enable { yes | no } no interface ethernet id pppoe enable show interface ethernet id pppoe enable

These commands allow you enable, disable, or show the PPP over Ethernet behavior of the speciﬁed interface.

show interface ethernet id statistics show interface ethernet id stats

These commands allow you to display statistics for the speciﬁed Ethernet interface, including receive frames, octets, and errors, and transmit frames, octets, and errors.

Motorola Netopia® Router CLI Commands 2-29

interface ethernet id ip ﬁlterset fs-id no interface ethernet id ip ﬁlterset show interface ethernet id ip ﬁlterset

These commands allow you to enable, disable, or show an IP ﬁlterset identiﬁed by fs-id on the speciﬁed Ethernet interface. fs-id is speciﬁed as an ASCII string corresponding to the name of a ﬁlterset. See “IP Filterset

Conﬁguration Commands” on page 2-121 for more information.

interface ethernet id ip nat enable { yes | no } no interface ethernet id ip nat enable show interface ethernet id ip nat enable

These commands allow you to enable, disable, or show the Network Address Translation behavior for the speciﬁed WAN interface.

interface ethernet id ip nat map-list list-tag no interface ethernet id ip nat map-list show interface ethernet id ip nat map-list

These commands allow you to set, delete, or show a NAT map list for the speciﬁed WAN interface.

interface ethernet wan-id ip nat passthrough enable { yes | no } no interface ethernet id ip nat passthrough enable show interface ethernet id ip nat passthrough enable

Note: These commands are supported beginning with ﬁrmware version 8.2.

These commands allow you to enable, disable, or show the NAT passthrough behavior for the speciﬁed WAN interface. The IP passthrough feature allows for a single LAN PC to have the router’s public address assigned to it, in addition to providing PAT (NAPT) via the same public IP address for all other hosts on the private LAN subnet.

interface ethernet wan-id ip nat passthrough dhcp enable { yes | no } no interface ethernet wan-id ip nat passthrough dhcp enable show interface ethernet wan-id ip nat passthrough dhcp enable

Note: These commands are supported beginning with ﬁrmware version 8.2.

These commands allow you to enable, disable, or show the NAT passthrough DHCP behavior for the speciﬁed WAN interface. This governs DHCP addressing for the passthrough host.

interface ethernet wan-id ip nat passthrough dhcp mac-address { mac-address } show interface ethernet wan-id ip nat passthrough dhcp mac-address

Note: These commands are supported beginning with ﬁrmware version 8.2.

These commands allow you to set or show the NAT passthrough DHCP MAC address for the speciﬁed WAN interface. This speciﬁes the MAC address of the passthrough host.

2-30 Command Line Interface Commands Reference

interface ethernet id ip nat server-list list-tag no interface ethernet id ip nat server-list show interface ethernet id ip nat server-list

These commands allow you to set, delete, or show a NAT server list for the speciﬁed WAN interface.

interface ethernet wan-id mac address { MAC-address | default } show interface ethernet wan-id mac address

The ﬁrst command allows you to set the MAC Address for the WAN on a WAN Ethernet Router. You can return it to the default by typing in a MAC Address consisting of all zeros or by typing default. The show command applies to the LAN of all models, as well as the WAN on the R9100 and R910.

interface ethernet id address-serve clients { any | none | { bootp | dhcp | macip | wan } } no interface ethernet 0 address-serve clients { any | { bootp | dhcp | macip | wan }+ } show interface ethernet 0 address-serve clients

The interface ethernet id address-serve clients command allows you to conﬁgure the types of clients that may request IP addresses from the address ser ver. If you specify the keyword any, the address server will accept requests from clients of any type supported by the router. Otherwise, you may specify one or more of the keywords bootp, dhcp, macip, or wan, in which case the address server will accept requests from only the speciﬁed types of clients. If you specify the keyword none, the address server will not accept requests from clients of any type.

The no interface ethernet id address-serve clients command removes the speciﬁed client types from those from which the address server will accept requests.

interface ethernet id address-serve dhcp lease-time hours show interface ethernet id address-serve dhcp lease-time

These commands allow you to set or show the address serving DHCP lease time to any number of hours, up to and including 168 (one week). The default DHCP lease time is one hour.

show interface ethernet id address-serve dhcp addresses

Note: This command is supported beginning with ﬁrmware version 8.5.

This command allows you to display the ethernet IP addresses being served via DHCP, and the host name of the served device, if available.

interface ethernet id ip dhcp client [ renew | release ]

Note: This command is supported beginning with ﬁrmware version 8.5.

This command allows you to renew or release the ethernet WAN IP address lease being served via DHCP.

interface ethernet id address-serve dhcp next-server ip-addr

Note: This command is supported beginning with ﬁrmware version 8.5.

Motorola Netopia® Router CLI Commands 2-31

This command speciﬁes the IP address of the next server in the boot process, typically a Trivial File Transfer Protocol (TFTP) server.

show interface ethernet id ip dhcp client status

Note: This command is supported beginning with ﬁrmware version 8.5.

This command allows you to display the status of the ethernet WAN being served via DHCP. It displays:

IP Address IP Subnet Mask

IP Gateway DHCP server

DNS server 1 DNS server 2 (if any)

Lease Expiration

interface ethernet id address-serve gateway { gw-ip-addr | default { ip-addr/mask-bits | ip-addr mask } } show interface ethernet id address-serve gateway

This command allows you to specify the gateway IP address that will be served to clients requesting an address via an address serving protocol that can serve a gateway address. You may specify a gateway IP address for each Ethernet subnet for which you have conﬁgured an address-ser ving pool. (See the description of the interface ethernet id address-serve range command on page 2-32.)

If you specify the keyword default, you must also specify an Ethernet subnet; the gateway IP address for the speciﬁed subnet will be reset to its default value. The default gateway IP address for a particular subnet is either the router's default gateway (if that gateway is on the speciﬁed subnet) or the router's address on the subnet.

interface ethernet id address-serve helper ip-addr no interface ethernet id address-serve helper [ip-addr] show interface ethernet id address-serve helper

These commands allow you to conﬁgure or display the addresses of up to four remote DHCP servers to which the router will forward DHCP requests when it is acting as a DHCP relay agent. The interface ethernet id

address-serve helper command adds the speciﬁed IP address to the ser ver list. The no interface ethernet id address-serve helper command removes the speciﬁed IP address from the server list; if you omit the IP

address, all conﬁgured DHCP server IP addresses are removed.

Examples:

#show interface ethernet 0 address-serve helper #interface ethernet 0 address-serve helper 10.0.0.1 #interface ethernet 0 address-serve helper 20.0.0.1 #interface ethernet 0 address-serve helper 30.0.0.1 #no interface ethernet 0 address-serve helper 20.0.0.1 #show interface ethernet 0 address-serve helper interface ethernet 0 address-serve helper 10.0.0.1

2-32 Command Line Interface Commands Reference

interface ethernet 0 address-serve helper 30.0.0.1 #

interface ethernet id address-serve mode { relay | server } show interface ethernet id address-serve mode

These commands allow you to specify or display the address serving mode for the speciﬁed Ethernet interface. The keyword relay causes the router to act as a DHCP relay agent. The keyword server enables address serving from one or more locally conﬁgured address pools.

Examples:

#interface ethernet 0 address-serve mode server #show interface ethernet 0 address-serve mode interface ethernet 0 address-serve mode server #

interface ethernet id address-serve range { auto | from-addr to-addr } no interface ethernet id address-serve range from-addr to-addr show interface ethernet id address-serve range

This command conﬁgures a pool of IP addresses for use by the address server. You may specify one address pool for each conﬁgured Ethernet subnet (primary and secondary). The total number of addresses in all conﬁgured pools may not exceed 512 addresses.

If you specify the keyword auto instead of an IP address range, the router will automatically conﬁgure IP address pools for each conﬁgured Ethernet subnet. An automatically conﬁgured pool will include one-half of the number of addresses available in the corresponding subnet, and will be located in the opposite half of the subnet from the router's IP address on the subnet. If the total number of addresses required would exceed the maximum of 512 total addresses, the 512 available addresses will be allocated on a pro-rata basis across all pools.

interface ethernet id address-serve { no | off | on | yes } no interface ethernet id address-serve show interface ethernet id address-serve

These commands enable, disable, or display the status of address-serving for the speciﬁed Ethernet interface.

Stateful Inspection Conﬁguration Commands

See also:

■ “Stateful Inspection Commands” on page 3-21 for Connection Proﬁle commands.

■ “Stateful Inspection Commands” on page 2-85 for Global Stateful Inspection commands.

Motorola Netopia® Router CLI Commands 2-33

Note: The commands in this section are supported beginning with ﬁrmware version 8.2.

interface ethernet id ip state-insp enable { yes | no | on | off } no interface ethernet id ip state-insp show interface ethernet id ip state-insp enable

These commands allow you to set, disable, or show the status of stateful inspection for the speciﬁed interface. This option is disabled by default. Stateful inspection prevents unsolicited inbound access when NAT is disabled.

interface ethernet id ip state-insp router-access { yes | no | on | off } no interface ethernet id ip state-insp router-access show interface ethernet id ip state-insp router-access

These commands allow you to set, disable, or show the status of default mapping to router for the speciﬁed interface.

interface ethernet id ip state-insp tcp-seq-diff diff show interface ethernet id ip state-insp tcp-seq-diff

These commands allow you to set or show TCP sequence difference acceptable for the speciﬁed interface. The TCP sequence number difference maximum allowed value is 65535. If the value of tcp-seq-diff is 0, it means that this check is disabled.

interface ethernet id ip state-insp deny-frag { yes | no | on | off } no interface ethernet id ip state-insp deny-frag show interface ethernet id ip state-insp deny-frag

These commands allow you to set, disable, or show whether fragmented packets are received for the speciﬁed interface.

interface ethernet id ip state-insp xposed-list xposed-list_name no interface ethernet id ip state-insp xposed-list show interface ethernet id ip state-insp xposed-list

These commands allow you to set, disable, or show the status of a stateful inspection exposed address list for the speciﬁed interface. Exposed address lists are similar to NAT server lists. Exposed addresses in the list will not be subject to stateful inspection and hence unsolicited inbound trafﬁc will be allowed to these addresses.

These are active only if NAT is disabled on the proﬁle.

2-34 Command Line Interface Commands Reference

Ethernet Interface Static Client Address Translation Commands

Note: The commands in this section are supported beginning with ﬁrmware version 8.5.

interface ethernet lan_inter face_id scat enable [ yes | no ] show interface ethernet lan_inter face_id scat enable

These commands allow you to enable, disable, or show the status of static client address translation on the speciﬁed LAN interface. This feature allows a statically addressed host whose address falls outside of the LAN subnet(s) to simply plug in and get online without any manual conﬁguration on either the host or the Motorola Netopia® Router.

If scat enable is set to yes, statically addressed LAN hosts that have an address outside of LAN subnets will be able to communicate via the Router’s WAN interface to the Internet.

Supported static IP address values must fall outside of the Router's LAN subnet(s).

Ethernet Interface VRRP Commands

Note: The commands in this section are supported beginning with ﬁrmware version 8.5.

A Virtual Router is a software abstraction consisting of a group of two or more hardware routers protecting one or more IP addresses. One of the routers is designated as the Master, while the others are backups. VRRP is a protocol that provides redundancy to routers within a local area network by allowing alternate paths for a PC without changing the IP address or MAC address by which the PC knows its gateway.

A Virtual Router cannot be enabled unless it is populated with a Virtual ID and a Virtual IP address. The Virtual Router index starts from 1 (one). Two virtual routers can be conﬁgured per LAN inter face.

interface ethernet id ip vrrp vrouter id vrid [ 1... 255 ] show interface ethernet id ip vrrp vrouter id vrid

These commands allow you to specify or display an ID (vrid) for the Virtual Router. vrid values may be in the range 1 – 255.

interface ethernet id ip vrrp vrouter id vrip ip-addr show interface ethernet id ip vrrp vrouter id vrip

These commands allow you to specify or display an IP address for the Virtual Router.

interface ethernet id ip vrrp vrouter id priority [ 1... 255 ] show interface ethernet id ip vrrp vrouter id priority

These commands allow you to specify or display a priority for the Virtual Router. The default value is 100, if not the owner of the virtual IP address. priority values may be in the range 1 – 255.

interface ethernet id ip vrrp vrouter id adv-intvl [ 1... 255 ] show interface ethernet id ip vrrp vrouter id adv-intvl

These commands allow you to specify or display an advertisement interval in seconds. The default value is one second; adv-intvl values may be in the range 1 – 255.

Motorola Netopia® Router CLI Commands 2-35

interface ethernet id ip vrrp vrouter id preempt-mode enable [ no | yes | on | off ] show interface ethernet id ip vrrp vrouter id preempt-mode enable

These commands allow you to enable, disable, or display the status of preempt mode. The default is enabled.

interface ethernet id ip vrrp vrouter id enable [ no | yes | on | off ] show interface ethernet id ip vrrp vrouter id enable

These commands allow you to enable, disable, or display the status of the Virtual Router.

no interface ethernet id ip vrrp vrouter id

This command allows you to delete a Virtual Router.

show interface ethernet id ip vrrp wan-monitor enable [ { yes | no | on | off } ] show interface ethernet id ip vrrp wan-monitor enable

These commands allow you to enable, disable, or display the status of the WAN monitor.

interface ethernet id ip vrrp master-dhcp-srv enable [ { yes | no | on | off } ] show interface ethernet id ip vrrp master-dhcp-srv enable

These commands allow you to enable, disable, or display the status of the DHCP behavior. The Virtual Router can either serve or relay DHCP only if it is in Master state.

interface ethernet id ip vrrp dhcp-gateway ip-addr show interface ethernet id ip vrrp dhcp-gateway

These commands allow you to specify or display the Virtual Router DHCP gateway IP address.

2-36 Command Line Interface Commands Reference

Virtual LAN (VLAN) conﬁguration commands

Note: See also “RADIUS Authentication Proﬁle conﬁguration commands” on page 2-39 and “Additional LAN

conﬁguration command” on page 2-16.

VLAN Conﬁguration Commands

vlan id by [ port-based | global ] no vlan id

vlan id name name

vlan id network { none | lan | eth2 | eth3 | eth4 | eth5 | eth6 | eth7 }

vlan id id { 1 .. 4094 } (supported in V8.6.1)

vlan id 8021x authproﬁle { authproﬁle tag name | authproﬁle id } no vlan id 8021x authproﬁle

vlan id interface eth { 1 | 2 | 0/1 | 0/...n } tag { yes | no }

[ tos-priority { off | on -} ] [ iptos-promote { off | on } ] [ authproﬁle { name | id } ] [ inter-vlan-routing { group-1... group-8 } enable { yes | no } ]

no vlan id interface eth { 1 | 2 | 0/1 | 0/...n }

vlan id interface ssid n tag { yes | no } no vlan id interface ssid n

vlan id interface usb 0 tag { yes | no } no vlan id interface usb 0

vlan id interface cp n tag { yes | no } no vlan id interface cp n

show conﬁg vlan { id }

vlan id by [ port-based | global ] no vlan id

These commands allow you to create or delete a VLAN speciﬁed by id and designate it either port-based or global. You can create up to 16 VLANs.

Motorola Netopia® Router CLI Commands 2-37

vlan id name name

This command allows you to assign a free-form name name to a VLAN speciﬁed by id.

vlan id network { none | lan | eth2 | eth3 | eth4 | eth5 | eth6 | eth7 }

This command allows you to deﬁne what additional LAN (ALAN) network is associated with the VLAN speciﬁed by id.

vlan id id { 1 .. 4094 }

This command allows you to change the VLAN ID, which will effectively require you to refer to the VLAN by its new VID after issuing this command.

Beginning with Firmware Version 8.7, a VID of zero (0) is permitted on the Ethernet WAN port only.

vlan id 8021x authproﬁle { authproﬁle tag name | authproﬁle id }

This command allows you to enable 802.1x authentication for the VLAN speciﬁed by id. This option is only supported on Router models with VGx technology or single Ethernet port models. If you are conﬁguring a VLAN for a Motorola Netopia® Router model with VGx technology (wired or wireless), you can specify a RADIUS server authentication proﬁle for user authentication. This command allows you to associate a VLAN with an 802.1x RADIUS authentication proﬁle. You must create an authentication proﬁle, if you have not already done so. See

“RADIUS Authentication Proﬁle conﬁguration commands” on page 2-39.

Note: If you enable 802.1x for a VLAN that includes a wireless SSID, you must set wireless privacy to

WPA-802.1x as well. See “Wireless Privacy Commands (new and revised)” on page 2-91. If multiple SSIDs are

split across several VLANs, the VLANs must either:

• all have 802.1x enabled with WPA-802.1x enabled in Wireless Privacy, or

• have the VLANs set to 802.1x disabled and wireless privacy set to some other privacy setting. In that case wireless privacy can be any setting. Wireless does not currently suppor t separate privacy modes per SSID. When enabling WPA-802.1x, wireless will default to the RADIUS conﬁguration (see “RADIUS Authentication Proﬁle conﬁguration commands” on

page 2-39), unless it is part of a VLAN. If it is part of a VLAN it will use the VLAN authentication proﬁle's

speciﬁed RADIUS server.

vlan id interface eth { 1 | 2 | 0/1 | 0/...n } tag { yes | no } [ tos-priority { off | on -} ] [ iptos-promote { off | on } ] [ authproﬁle { name | id } ] [ inter-vlan-routing { group-1... group-8 } enable { yes | no } ] no vlan id interface eth { 1 | 2 | 0/1 | 0/...n }

These commands allow you to create or delete a VLAN speciﬁed by id on an Ethernet interface indicated by its interface number. The option eth 1 = Ethernet LAN; eth 2 = Ethernet WAN, where applicable. If the Motorola Netopia® Router model is a non-VGx model, the only available Ethernet port is numbered 0/1; for multiple managed-switch VGx models the number n is the number of the physical Ethernet port.

■ tos-priority - allows you to enable or disable packet prioritization based on any 802.1p priority bits in the

VLAN header to prioritize packets within the Router’s internal queues, according to DiffServ priority

2-38 Command Line Interface Commands Reference

mapping rules.

■ iptos-promote - allows you to enable or disable the translation of 802.1p priority bits to and from the

IP-TOS header bit ﬁeld. When enabled, write any 802.1p priority bits into the IP-TOS header bit ﬁeld for received IP packets on this port destined for this VLAN; and write any IP-TOS priority bits into the 802.1p priority bit ﬁeld for tagged IP packets transmitted from this port for this VLAN. All mappings between Ethernet 802.1p and IP-TOS are made according to a pre-deﬁned QoS mapping policy.

■ authproﬁle - allows you to associate this VLAN with an 802.1x authentication proﬁle speciﬁed by name or

id.

■ inter-vlan-routing - (supported beginning with Firmware Version 8.7.4) when set to yes, allows you to

associate this VLAN with an inter-VLAN routing group such that the speciﬁed VLAN can communicate with another VLAN in the same group. VLANS that are not associated with the same inter-VLAN routing group cannot communicate with each other.

vlan id interface ssid n tag { yes | no } no vlan id interface ssid n

These commands allow you to create or delete a port-based VLAN speciﬁed by id on a wireless SSID, if available, indicated by its SSID number.

vlan id interface usb 0 tag { yes | no } no vlan id interface usb 0

These commands allow you to create or delete a port-based VLAN speciﬁed by id on the Router’s USB port, if available.

vlan id interface cp n tag { yes | no } no vlan id interface cp n

These commands allow you to create or delete a port-based VLAN speciﬁed by id on the Router’s console port, if available, indicated by its port number n.

show conﬁg vlan { id }

This command allows you to display the conﬁguration of all VLANs or a particular VLAN speciﬁed by id.

Motorola Netopia® Router CLI Commands 2-39

RADIUS Authentication Proﬁle conﬁguration commands

Note: The commands in this section are supported beginning with Firmware Version 8.4.2.

Authentication Proﬁle Conﬁguration Commands

authproﬁle id [ yes | no ]

authproﬁle id tag string

authproﬁle id remote server string

authproﬁle id remote secret string

authproﬁle id alternate server string

authproﬁle id alternate secret string

authproﬁle id radius identiﬁer string

authproﬁle id radius port { 1 ...65535 }

show conﬁg authproﬁle id

authproﬁle id [ yes | no ]

This command allows you to create or delete an authentication proﬁle identiﬁed by id containing relevant information to access a RADIUS server. You associate the proﬁle with a VLAN using the vlan 8021x authproﬁle command (page 37).

authproﬁle id tag string

This command allows you to name an authentication proﬁle identiﬁed by id with a free-form name of up to 32 characters.

authproﬁle id remote server string

This command allows you to specify the RADIUS server’s IP address or fully qualiﬁed server name.

authproﬁle id remote secret string

This command allows you to specify the RADIUS server CHAP secret.

authproﬁle id alternate server string

This command allows you to specify an alternate RADIUS server, if available.

2-40 Command Line Interface Commands Reference

authproﬁle id alternate secret string

This command allows you to specify the alternate RADIUS server CHAP secret.

authproﬁle id radius identiﬁer string

This command allows you to specify the RADIUS Network Access Server (NAS) identiﬁer. The default NAS identiﬁer is an ASCII representation of the server’s base MAC address.

authproﬁle id radius port { 1 ...65535 }

This command allows you to specify the RADIUS server’s port number. Ordinarily, the RADIUS server port number is 1812. If you are using a different port number, enter it here.

show conﬁg authproﬁle id

This command allows you to display the conﬁguration of an authentication proﬁle identiﬁed by id.

Motorola Netopia® Router CLI Commands 2-41

NetBIOS conﬁguration commands

NetBIOS Conﬁguration Commands

interface ethernet 0 address-serve netbios mode type { b-node | p-node | m-node | h-node } show interface ethernet 0 address-serve netbios mode type

interface ethernet 0 address-serve netbios mode enable { yes | no } no interface ethernet 0 address-serve netbios mode enable show interface ethernet 0 address-serve netbios mode enable

interface ethernet 0 address-serve netbios scope enable { yes | no } no interface ethernet 0 address-serve netbios scope enable show interface ethernet 0 address-serve netbios scope enable

interface ethernet 0 address-serve netbios scope name domain-name show interface ethernet 0 address-serve netbios scope name

interface ethernet 0 address-serve netbios name-server enable { yes | no } no interface ethernet 0 address-serve netbios name-server enable show interface ethernet 0 address-serve netbios name-server enable

interface ethernet 0 address-serve netbios name-server address xxx.xxx.xxx.xxx [secondary] show interface ethernet 0 address-serve netbios name-server address

interface ethernet 0 address-serve netbios mode enable { yes | no } no interface ethernet 0 address-serve netbios mode enable show interface ethernet 0 address-serve netbios mode enable

These commands allow you to enable, delete, or show the router’s IP address serving capability on the Ethernet interface in NetBIOS mode.

interface ethernet 0 address-serve netbios mode type { b-node | p-node | m-node | h-node } show interface ethernet 0 address-serve netbios mode type

These commands allow you to set or show the router’s NetBIOS mode type of IP address serving on the Ethernet interface.

interface ethernet 0 address-serve netbios scope enable { yes | no } no interface ethernet 0 address-serve netbios scope enable show interface ethernet 0 address-serve netbios scope enable

These commands allow you to set, delete, or show whether NetBIOS scope is enabled.

2-42 Command Line Interface Commands Reference

interface ethernet 0 address-serve netbios scope name domain-name show interface ethernet 0 address-serve netbios scope name

These commands allow you to set or show the domain name under which the NetBIOS scope is enabled.

These commands allow you to set, delete, or show whether a NetBIOS name server address is served to NetBIOS clients.

interface ethernet 0 address-serve netbios name-server address xxx.xxx.xxx.xxx [secondary] show interface ethernet 0 address-serve netbios name-server address

These commands allow you to set or show the IP address of the NetBIOS name server. If the keyword secondary is speciﬁed and there is no primar y WINS ser ver the command will be rejected as

CLI_NO_CFG_SUPPORT_ERR, with the error message "; error 2: not supported with current conﬁguration“.

Motorola Netopia® Router CLI Commands 2-43

Generic WAN Interface conﬁguration commands

Note: For possible values of intf-type, refer to “Interface Naming Conventions” on page 1-3. Generic WAN

Interface Commands may be applied to any router WAN interface by specifying the intf-type wan together with the appropriate interface id. Alternatively, you can specify the more speciﬁc intf-type if you choose.

Generic WAN Interface Conﬁguration Commands

interface intf-type id dle { hdlc | ppp [{vcmux | vcmultiplexed | llcsnap}] | rfc1483 [{ bridged | routed }] | r fc1490 } show interface intf-type id dle

show interface intf-type id statistics show interface intf-type id stats

show interface wan id status

interface wan 0 tracking { yes | no }

Restricted WAN Interface Conﬁguration Commands

interface { adsl | ethernet | isdn | sdsl } id pppoe enable { yes | no } no interface { adsl | ethernet | isdn | sdsl } id pppoe enable show interface { adsl | ethernet | isdn | sdsl } id pppoe enable

interface { adsl | sdsl } id pvc { id | tag } { yes | no }

interface { adsl | sdsl } id pvc { id | tag } pcr num show interface { adsl | sdsl } id pvc { id | tag } pcr

interface intf-type id dle { hdlc | ppp [{vcmux | vcmultiplexed | llcsnap}] | rfc1483 [{ bridged | routed }] | r fc1490 } show interface intf-type id dle

These commands allow you to set or show the global data link encapsulation type of the interface speciﬁed by intf-type id. At this time you can generally think of the data link encapsulation of interface 1 as the global data link encapsulation of the router itself.

Note: atmfuni is accepted as a synonym for rfc1483 and frame-relay is accepted as a synonym for rfc1490.

For ppp, the default mode is vcmux. For rfc1483, the default mode for frame-based SDSL (R7100) inter faces is bridged, while the default mode for cell-based SDSL (R7200) interfaces is routed.

Example:

interface wan 1 dle frame-relay

2-44 Command Line Interface Commands Reference

show interface intf-type id statistics show interface intf-type id stats

These commands allow you to display statistics for the speciﬁed interface, including receive frames, octets, and errors, and transmit frames, octets, and errors. For switched ISDN interfaces, the statistics are broken down by channel.

show interface wan id status

Note: This command is supported beginning with ﬁrmware version 8.5.

This command allows you to view the general status of the WAN. It displays:

■ Interface type

■ MAC address

■ IP Address

■ Status (Down, Activating, or Connected)

interface wan 0 tracking { yes | no }

For D-Series CSU/DSU equipment, this command allows you to track or not track the primary interface speed. Specifying yes means the primary interface (AUX) speed will be tracked, which is the default. Changing this to no currently means that we will be running at 1.5 MHz.

Restricted WAN Interface conﬁguration commands

These commands allow you enable, disable, or show the PPP over Ethernet behavior of the speciﬁed interface.

interface { adsl | sdsl } id pvc { id | tag } { yes | no }

This command allows you to enable or disable a Permanent Virtual Circuit (PVC) on the speciﬁed ADSL or SDSL interface.

interface { adsl | sdsl } id pvc { id | tag } pcr num show interface { adsl | sdsl } id pvc { id | tag } pcr

These commands allow you to assign or show a Peak Cell Rate value (PCR) on a speciﬁed Permanent Virtual Circuit (PVC) on an ADSL or SDSL interface.

Motorola Netopia and Constant Bit Rate (CBR). You can conﬁgure these classes of service on a per VC basis. The default ATM class of service is UBR for data. The ATM class of service is not conﬁgurable for voice virtual circuits.

routers support two ATM classes of service for data connections: Unspeciﬁed Bit Rate (UBR)

Motorola Netopia® Router CLI Commands 2-45

UBR VC: No conﬁguration is needed for UBR VCs. CBR VC: One parameter is required for CBR VCs, the Peak Cell Rate pcr that applies to the VC. This value should be between 1 and the line rate. You set this value according to speciﬁcations deﬁned by your service provider.

ISDN WAN Interface conﬁguration commands

ISDN WAN Interface Conﬁguration Commands

Generic ISDN

interface isdn id line type { switched | leased | idsl-ascend | idsl-cmn } show interface isdn id line type

show interface isdn id status [ b1 | b2 ]

Permanent ISDN (IDSL) only

interface isdn id imux mode { mlppp | dml } show interface isdn id imux mode

interface isdn id speed { b1 | b2 | 2b | 2b+d } show interface isdn id speed

Switched ISDN only

interface isdn id switch japanntt | uk-euro }

interface isdn id dn { 1 | 2 } string no interface isdn id dn { 1 | 2 } show interface isdn id dn { 1 | 2 }

interface isdn id spid { 1 | 2 } string no interface isdn id spid { 1 | 2 } show interface isdn id spid { 1 | 2 }

interface isdn id imux mode { mlppp | dml } show interface isdn id imux mode

These commands allow you set or show the ISDN interface IMUX bonding mode: Multilink PPP or DML (for Copper Mountain Networks central ofﬁce equipment).

Example:

interface isdn 1 imux mode dml

{ auto | ni1 | 5esspttopt | 5essmultipt | dms100 | ts013 | euroisdn |

2-46 Command Line Interface Commands Reference

interface isdn id line type { switched | leased | idsl-ascend | idsl-cmn } show interface isdn id line type

These commands allow you set or show the ISDN interface mode: switched, leased, idsl-ascend (IDSL for Lucent/Ascend Communications central ofﬁce equipment), or idsl-cmn (IDSL for Copper Mountain Networks central ofﬁce equipment).

Example:

interface isdn 1 mode leased

show interface isdn id status [ b1 | b2 ]

This command allows you display the status of the speciﬁed ISDN/IDSL interface. For a switched ISDN interface, you may specify the optional keyword b1 or b2, in which case the status of the speciﬁed B-channel is displayed rather than the status of the interface itself.

For a leased ISDN/IDSL interface, the possible status strings and their meanings are:

Status String Meaning

Inactive The interface is not yet active.

Waiting for rate negotiation The interface is in the process of sensing the data rate

conﬁgured for the IDSL line at the central ofﬁce. This status applies only to an interface set to idsl-cmn mode, in which the router can sense the data rate automatically.

Backup recovery in progress The interface is in the process of recovering back to the

primary interface from a backup interface after a failure.

Connected at xxx Kbps The interface is connected to the DSLAM or other end device at

the speciﬁed data rate. (xxx will be one of 64, 128, or 144.)

For a switched ISDN interface, the possible status strings and their meanings are:

Status String Meaning

Inactive The interface is not yet active.

Active The interface is active, and this is an interface that does not

require SPIDs.

Active, n of m SPIDs registered

The interface is active, and this is an interface that requires SPIDs. n indicates the number of SPIDs that have been successfully registered so far, and m indicates the total number of SPIDs to be registered. If n is less than m, the device is still in the process of registering some of the SPIDs.

Motorola Netopia® Router CLI Commands 2-47

Status String Meaning

Active, n of m SPIDs registered (p failed)

The interface is active, and this is an interface that requires SPIDs. n indicates the number of SPIDs that have been successfully registered so far, m indicates the total number of SPIDs to be registered, and p indicates the number of SPIDs that failed registration. If the sum of n and p is less than m, the device is still in the process of registering some of the SPIDs.

For one of the B-channels of a switched ISDN interface, the possible status strings and their meanings are:

Status String Meaning

Inactive The associated interface is not yet active.

Idle The channel is not currently in use.

Speech Call The channel is in use by a speech call.

64 Kbps Data Call The channel is in use for a 64 Kbps data call.

56 Kbps Data Call The channel is in use for a 56 Kbps data call.

3.1 Khz Call The channel is in use for a 3.1 Khz call.

Example:

#show interface isdn 1 status Connected at 144 Kbps

interface isdn id speed { b1 | b2 | 2b | 2b+d } show interface isdn id speed

These commands, which apply only to permanent ISDN (i.e., IDSL), allow you to set or show the data rate (and B Channel usage) of the ISDN line. b1 means use Channel B1 at 64 Kbps, b2 means use Channel B2 at 64 Kbps, 2b means use both Channels B1 and B2 at 128 Kbps, and 2b+d means use all three channels at 144 Kbps.

interface isdn id switch { auto | ni1 | 5esspttopt | 5essmultipt | dms100 | ts013 | euroisdn | japanntt | uk-euro }

This command allows you to change the ISDN switch type. This command applies only to switched ISDN. The only currently suppor ted id is 1, which identiﬁes the ISDN inter face in the WAN 1 slot of the Motorola Netopia

router. The WAN 2 slot (id 2) cannot be populated with an ISDN wanlet at this time, and the Motherboard (id 0) is incapable of supporting ISDN internally.

Under many circumstances it is unnecessary to explicitly set the switch type, particularly in Europe. This is because for “S/T” ISDN routers the default switch type is euroisdn, and for “U” ISDN routers the default switch type is ni1.

2-48 Command Line Interface Commands Reference

auto is appropriate only in the United States and allows the router to auto-determine the switch type, SPIDs, and directory numbers (DNs).

uk-euro sets the switch type to Euro-ISDN, and as a side effect sets the console’s clock time display type to 24 hour (i.e., “17:45” instead of “5:45 PM”).

Example:

The command to set the switch type of the wanlet for the correct value in Japan is:

interface isdn 1 switch japanntt

interface isdn id dn { 1 | 2 } string no interface isdn id dn { 1 | 2 } show interface isdn id dn { 1 | 2 }

These commands allow you to set, change, delete, or show the directory numbers associated with the speciﬁed ISDN interface. These commands apply only to switched ISDN. The only currently suppor ted id is 1. The string parameter can contain up to 32 characters. Non-dialable characters are allowed (and are ignored).

Example:

interface isdn 1 dn 1234567

interface isdn id spid { 1 | 2 } string no interface isdn id spid { 1 | 2 } show interface isdn id spid { 1 | 2 }

These commands allow you to set, change, delete, or show the SPIDs associated with the speciﬁed ISDN interface. These commands apply only to switched ISDN. The only currently suppor ted id is 1. The string parameter can contain up to 23 characters. Illegal characters are allowed (for instance, for formatting) and are ignored by the interface.

ADSL WAN Interface conﬁguration commands

ADSL WAN Interface Conﬁguration Commands

interface adsl id pvc vpi-value vci-value show interface adsl id pvc

show interface adsl id status show interface adsl id statistics

interface adsl id signaling-mode { fdm | echo-cancellation } show interface adsl id signaling-mode

interface adsl id trellis-coding { yes | no } show interface adsl id trellis-coding no interface adsl id trellis-coding

interface adsl id pvc vpi-value vci-value show interface adsl id pvc

Motorola Netopia® Router CLI Commands 2-49

These commands allow you to set, change, or show the PVC VPI and VCI values associated with the ADSL WAN interface.

show interface adsl id status

This command allows you to display the status of the speciﬁed ADSL interface. For an ADSL interface, the possible status strings and their meanings are:

Status String Meaning

Connected at xxx rx / yyy tx Kbps The interface is connected to the DSLAM at the speciﬁed

speeds, where xxx is the downstream (receive) speed and yyy is the upstream (transmit) speed, each in Kbps.

Activation Backoff The ADSL interface is between connection attempts.

Down The ADSL interface is not yet initialized.

No signal from DSLAM The ADSL interface is not detecting a signal from a DSLAM.

show interface adsl id statistics

Note: This command is supported beginning with ﬁrmware version 8.5.

2-50 Command Line Interface Commands Reference

This command allows you to display statistics for the speciﬁed ADSL interface:

Receive frames Receive octets

Receive errors Transmit frames

Transmit octets Transmit errors

interface adsl id signaling-mode { fdm | echo-cancellation } show interface adsl id signaling-mode

These commands allow you to set or show the signalling mode on an ADSL interface. fdm = Frequency Division Multiplexing.

interface adsl id trellis-coding { yes | no } show interface adsl id trellis-coding no interface adsl id trellis-coding

These commands allow you to set, show, or disable trellis encoding on the speciﬁed ADSL interface.

Motorola Netopia® Router CLI Commands 2-51

SDSL WAN Interface conﬁguration commands

SDSL WAN Interface Conﬁguration Commands

interface sdsl id clock source { internal | network } show interface sdsl id clock source

interface sdsl id clock rate rate-speciﬁcation show interface sdsl id clock rate

interface sdsl id operation mode { generic | lucent | nokia-eoc-fast | nokia-ﬁxed | paradyne | nortel | newbridge } [ default ] show interface sdsl id operation mode

interface sdsl id pvc vpi-value vci-value show interface sdsl id pvc

interface sdsl id region { annexa | annexb } show interface sdsl id region

interface { sdsl | isdn } id rfc1973 dlci { 16 .. 991 } show interface { sdsl | isdn } id rfc1973 dlci

interface { sdsl | isdn } id rfc1973 enable { yes | no } no interface ethernet { sdsl | isdn } id rfc1973 enable show interface { sdsl | isdn } id rfc1973 enable

interface { sdsl | isdn } id rfc1973 lmi { none | lmi | ccitt | ansi | annexa | annexd } no interface { sdsl | isdn } id rfc1973 lmi show interface { sdsl | isdn } id rfc1973 lmi

show interface sdsl id status

interface sdsl id clock source { internal | network } show interface sdsl id clock source

These commands allow you to set, change, or show the clock source associated with the SDSL WAN interface.

Note: These commands apply only to frame-based SDSL (R7100) interfaces.

2-52 Command Line Interface Commands Reference

interface sdsl id clock rate rate-speciﬁcation show interface sdsl id clock rate

These commands allow you to set, change, or show the data rate associated with the SDSL WAN interface.

Note: The permissible values for rate-speciﬁcation depend on the type of SDSL WAN interface. For

frame-based SDSL (R7100) interfaces, rate-speciﬁcation may be replaced with:

{ 160 | 208 | 320 | 416 | 784 | 1040 | 1568 }

For cell-based SDSL (R7200) interfaces, rate-speciﬁcation may be replaced with:

{ 144...2320 } [{ hunt | locked }]

See the table on the next page for possible rate speciﬁcations. Also, data rate is accepted as a synonym for clock rate.

Motorola Netopia® Router CLI Commands 2-53

interface sdsl id operation mode { generic | lucent | nokia-eoc-fast | nokia-ﬁxed | paradyne | nortel | newbridge } [ default ] show interface sdsl id operation mode

Note: These commands apply only to ATM-based SDSL interfaces.

If the optional default token is included in the command, various WAN interface parameters will be set to appropriate default values, given the particular mode setting. The parameters and their values are enumerated in the table below. In addition, the data rates accepted by the interface sdsl id data rate command depend on what the operation mode is, and correspond to the values available from the Data Rate pop-up menu on the SDSL Line Conﬁguration screen in the menu console. These acceptable data rates are enumerated below as well.

Nokia Lucent Paradyne Nortel Newbridge

VPI

VCI

RFC 1483

Mode

Data Rate

Mode

Clock Source

DLE

Data Rates

00000

38 35 35 38 38

Routed Routed Routed Routed Routed

384k 784k 784k 1536k 2320

HUNT LOCKED LOCKED LOCKED LOCKED

Network Network Network Network Network

rfc1483 rfc1483 rfc1483 rfc1483 rfc1483

192k 384k 768k 1152k 1536k

144k 160k 192k 208k 272k 384k 400k 416k 528k 768k 784k 1040k 1152k 1168k 1536k 1552k 1568k 2320k

144k 272k 400k 528k 784k 1168k 1552k 2320k

144k 160k 192k 208k 272k 384k 400k 416k 528k 768k 784k 1040k 1152k 1168k 1536k 1552k 1568k 2320k

200K 400k 784k 1168k 1552k 2320k

2-54 Command Line Interface Commands Reference

Note that setting the mode value to generic will not change any other WAN interface module parameter; thus, the following command:

interface sdsl 1 operation mode generic default

will be rejected as a syntax error.

interface sdsl id pvc vpi-value vci-value show interface sdsl id pvc

These commands allow you to set, change, or show the PVC VPI and VCI values associated with the SDSL WAN interface.

interface sdsl id region { annexa | annexb } show interface sdsl id region

These commands allow you to specify or show the region setting for devices that support multiple (North American/non-North American) regions.

Note: These commands apply only to cell-based SDSL (R7200) interfaces.

interface { sdsl | isdn } id rfc1973 dlci { 16 .. 991 } show interface { sdsl | isdn } id rfc1973 dlci

These commands allow you to set or show an RFC 1973 DLCI for the SDSL or ISDN WAN interface. Note that the only WAN interface modules that currently support RFC 1973 are the U/ISDN (31xx) and Copper

Mountain SDSL (71xx). Attempts to set or show RFC 1973 parameters on any other WAN interface module will return an error.

interface { sdsl | isdn } id rfc1973 enable { yes | no } no interface { sdsl | isdn } id rfc1973 enable show interface { sdsl | isdn } id rfc1973 enable

These commands allow you to enable, disable, or show RFC 1973 (PPP) behavior on the SDSL or ISDN WAN interface.

interface { sdsl | isdn } id rfc1973 lmi { none | lmi | ccitt | ansi | annexa | annexd } no interface { sdsl | isdn } id rfc1973 lmi show interface { sdsl | isdn } id rfc1973 lmi

These commands allow you to specify, disable, or show the RFC 1973 (PPP) Local Management Interface (LMI) type on the SDSL or ISDN WAN interface.

The keywords ccitt and annexa are synonyms, as are the keywords ansi and annexd.

Motorola Netopia® Router CLI Commands 2-55

show interface sdsl id status

This command allows you to display the status of the speciﬁed SDSL interface. For a cell-based SDSL (R7200) interface, the possible status strings and their meanings are:

Status String Meaning

Connected at xxx Kbps The interface is connected to the DSLAM at the speciﬁed

speed.

Trying xxx Kbps The SDSL interface is attempting to connect to the DSLAM at

the speciﬁed speed.

Activation Backoff The SDSL interface is between connection attempts.

Down The SDSL interface is not yet initialized.

No signal from DSLAM The SDSL interface is not detecting a signal from a DSLAM.

Priority Queuing (TOS bit) Commands

Priority Queuing Conﬁguration Commands

interface { adsl | sdsl | t1 | serial } id priority-queuing enable { yes | no } no interface { adsl | sdsl | t1 | serial } id priority-queuing enable show interface { adsl | sdsl | t1 | serial } id priority-queuing enable

These commands allow you to enable, disable, or show the priority queuing (TOS) setting for the speciﬁed WAN interface.

2-56 Command Line Interface Commands Reference

Differentiated Services (Diffserv) commands

Note: The commands in this section are supported beginning with Firmware Version 8.4.2.

Diffserv Conﬁguration Commands

diffserv enable [ yes | no ]

This command allows you to enable or disable Differentiated Services (diffserv) for controlling Quality of Service (QoS) queue priority.

diffserv ratio [ 79 - 100 ]

This command allows you to set the low-high ratio to regulate the level of packets allowed to be pending in the low priority queue.

diffserv rule id name string

This command allows you to create a custom rule speciﬁed by id with the name string. If your applications do not provide Quality of Service (QoS) control, rules allow you to deﬁne streams for some protocols, port ranges, and between speciﬁc end point addresses.

diffserv rule id protocol [ tcp | udp | icmp | other ]

This command allows you to specify the protocol for the rule id: tcp, udp, icmp, or other. other is appropriate for rules on protocols with non-standard port deﬁnitions. IPSEC and PPTP are common examples. If you specify other protocol, you must provide its actual protocol number, with a range of 0 – 255.

Motorola Netopia® Router CLI Commands 2-57

diffserv rule id priority [ off | assure | expedite ]

This command allows you to specify the priority for the rule id: off, assure, or expedite. This is the Quality of Service setting for the rule, based on the TOS bit information. The following table outlines the TOS bit settings and behavior:

QoS Setting TOS Bit Value Behavior

off TOS=000 This custom rule is disabled. You can activate it by selecting one of

the two settings below. This setting allows you to pre-deﬁne ﬂows without actually activating them.

assure TOS=001 Use normal queuing and throughput rules, but do not drop packets

if possible. Appropriate for applications with no guaranteed delivery mechanism.

expedite TOS=101 Use minimum delay. Appropriate for VoIP and video applications.

diffserv rule id direction [ outbound | inbound | both ]

This command allows you to specify the direction of the ﬂow: outbound, inbound, or both. For TCP or UDP protocols, you can optionally specify a range of ports.

diffserv rule id start-por t [ 0 - 49151 ]

This command allows you to specify the starting port in the range for the rule id for TCP or UDP protocols.

diffserv rule id end-port [ 0 - 49151 ]

This command allows you to specify the ending port in the range for the rule id for TCP or UDP protocols.

diffserv rule id inside-ip x.x.x.x

This command allows you to specify the inside IP address for the rule id. For outbound ﬂows, specify an IP address on your LAN. For inbound ﬂows, this setting is ignored.

diffserv rule id outside-ip y.y. y.y

This command allows you to specify the outside IP address for the rule id. If you want trafﬁc destined for and originating from a certain WAN IP address to be controlled, enter the IP address here. If you specify all-zeroes, the outside address check is ignored.

For outbound ﬂows, the outside address is the destination IP address for trafﬁc; for inbound packets, the outside address is the source IP address.

2-58 Command Line Interface Commands Reference

PVCs

Note: The commands in this section are supported beginning with ﬁrmware release 8.3.1.

PVC Conﬁguration Commands

interface { adsl | sdsl } id pvc { id | tag } no interface { adsl | sdsl } id pvc { id | tag } show interface { adsl | sdsl } id pvc { id | tag }

interface { adsl | sdsl } id pvc { id | tag } tag tag show interface { adsl | sdsl } id pvc { id | tag } tag

interface { adsl | sdsl } id pvc { id | tag } enable { yes | no } no interface { adsl | sdsl } id pvc { id | tag } enable show interface { adsl | sdsl } id pvc { id | tag } enable

interface adsl id pvc { id | tag } qos { ubr | cbr | vbr } show interface adsl id pvc { id | tag } qos

interface { adsl | sdsl } id pvc { id | tag } vpi vpi-val show interface { adsl | sdsl } id pvc { id | tag } vpi

interface { adsl | sdsl } id pvc { id | tag } vci vci-val show interface { adsl | sdsl } id pvc { id | tag } vci

interface { adsl | sdsl } id pvc { id | tag } cp { proﬁle-id | proﬁle-tag | default } show interface { adsl | sdsl } id pvc { id | tag } cp

interface { adsl | sdsl } id pvc { id | tag } no interface { adsl | sdsl } id pvc { id | tag } show interface { adsl | sdsl } id pvc { id | tag }

These commands allow you to set, disable, or show a permanent virtual circuit. You can specify an optional circuit tag of up to 14 ASCII characters. The tag is used only to identify the circuit for management purposes, and has no signiﬁcance on the wire; it is merely a convenience to aid in selecting circuits from lists. The default circuit name is “Circuit <n>”, where <n> is replaced with a single decimal ASCII digit (between one and eight) corresponding to the circuit’s position in the list of up to eight circuits.

tag

interface { adsl | sdsl } id pvc { id | tag } tag tag show interface { adsl | sdsl } id pvc { id | tag } tag

These commands allow you to set or show a permanent virtual circuit identiﬁed by tag.

Motorola Netopia® Router CLI Commands 2-59

enable

interface { adsl | sdsl } id pvc { id | tag } enable { yes | no } no interface { adsl | sdsl } id pvc { id | tag } enable show interface { adsl | sdsl } id pvc { id | tag } enable

These commands allow you to enable, disable, or show a permanent virtual circuit.

interface adsl id pvc { id | tag } qos { ubr | cbr | vbr } show interface adsl id pvc { id | tag } qos

Note: These commands are supported beginning with Firmware Version 8.2.

These commands allow you to specify or show the Quality of Service (QoS) type – Unspeciﬁed Bit Rate (ubr) or Constant Bit rate (cbr) – for the speciﬁed PVC. Beginning with Firmware Version 8.3.3, the vbr argument is also supported.

Variable Bit Rate (vbr) is characterized by:

• a pcr (Peak Cell Rate) value, which is a temporary burst, not a sustained rate, and

• an scr (Sustained Cell Rate) value, and

• an mbs (Maximum Burst Size/Burst Tolerance) value. mbs is the maximum number of cells that can be transmitted at the peak cell rate and should be less than, or equal to the Peak Cell Rate, which should be less than, or equal to the line rate. VBR has two sub-classes: a. VBR non-real-time (VBR-nrt): Typical applications are non-real-time trafﬁc, such as IP data trafﬁc. This class yields a fair amount of Cell Delay Variation (CDV).

b. VBR real time (VBR-rt): Typical applications are real-time trafﬁc, such as compressed voice over IP and video

conferencing. This class transmits cells with a more tightly bounded Cell Delay Variation. The applications follow CBR.

vpi and vci

interface { adsl | sdsl } id pvc { id | tag } vpi vpi-val show interface { adsl | sdsl } id pvc { id | tag } vpi

These commands allow you to set or show the Virtual Path Identiﬁer value vpi for a permanent virtual circuit.

interface { adsl | sdsl } id pvc { id | tag } vci vci-val show interface { adsl | sdsl } id pvc { id | tag } vci

These commands allow you to set or show the Virtual Channel Identiﬁer value vci for a permanent virtual circuit.

The vpi and vci allow you to conﬁgure the Virtual Path Identiﬁer and Virtual Channel Identiﬁer which together identify the ATM permanent virtual circuit used between the router and the remote device. The values conﬁgured for these items must match those conﬁgured in the remote device for data to ﬂow between the devices. The vpi may be set to any value between zero (0) and 255.

2-60 Command Line Interface Commands Reference

proﬁle

interface { adsl | sdsl } id pvc { id | tag } cp { proﬁle-id | proﬁle-tag | default } show interface { adsl | sdsl } id pvc { id | tag } cp

These commands allow you to set or show the connection proﬁle assigned to the speciﬁed PVC.

Note: default means that the router will use the ﬁrst appropriate connection proﬁle or the Default Proﬁle if an

appropriate connection proﬁle is not found.

Motorola Netopia® Router CLI Commands 2-61

DSL Line Type Interface Conﬁguration Commands

interface dsl id line type { g.shdsl | sdsl-atm | sdsl-hdlc | idsl-cmn | idsl-leased | idsl } show interface dsl id line type

These commands allow you to set or show the line type for the speciﬁed DSL interface.

2-62 Command Line Interface Commands Reference

T1 WAN Interface conﬁguration commands

T1 WAN Interface Conﬁguration Commands

interface t1 id buildout { auto | 0-0.6 | 7.5 | 15.0 | 22.5 } show interface t1 id buildout

interface t1 id channels

count integer [ start integer ] [ { alternating | contiguous } ] [ rate { 56 | 64 | 56k | 64k | Nx56k | Nx64k } ]

show interface t1 id channels

interface t1 id clock source { internal | network } show interface t1 id clock source

interface t1 id dle { ppp | hdlc | rfc1490 } show interface t1 id dle

interface t1 id ds0-autodetect { yes | no } show interface t1 id ds0-autodetect no interface t1 id ds0-autodetect

interface t1 id framing { d4 | esf } show interface t1 id framing

interface t1 id encoding { ami | b8zs } show interface t1 id encoding

interface t1 id operation line type { normal | copper-mountain } show interface t1 id operation line type

interface t1 id prm-enable { yes | no } show interface t1 id prm-enable no interface t1 id prm-enable

interface t1 id rfc1973 enable { yes | no } show interface t1 id rfc1973 enable no interface t1 id rfc1973 enable

Motorola Netopia® Router CLI Commands 2-63

T1 WAN Interface Conﬁguration Commands (continued)

interface t1 id rfc1973 dlci { 16..991 } show interface t1 id rfc1973 dlci

interface t1 id rfc1973 lmi { annexa | annexd | ansi | ccitt | lmi | none } show interface t1 id rfc1973 lmi no interface t1 id rfc1973 lmi

interface t1 id buildout { auto | 0-0.6 | 7.5 | 15.0 | 22.5 } show interface t1 id buildout

These commands set or display the line buildout for the speciﬁed T1 WAN interface.

interface t1 id channels count integer [ start integer ] [ { alternating | contiguous } ] [ rate { 56 | 64 | 56k | 64k | Nx56k | Nx64k } ] show interface t1 id channels

These commands set or display which DS0 channels are utilized on the speciﬁed T1 WAN interface, and the rate of those DS0 channels. The count clause is always required. The start clause is required unless the count clause speciﬁes 24 channels, in which case if the start clause is not present, the star ting channel number is assumed to be channel 1. If neither the alternating nor the contiguous keyword is speciﬁed, the contiguous keyword is assumed unless the line encoding is AMI and the count clause speciﬁes two or more channels, in which case the alternating keyword is assumed. The rate clause is always optional. If the rate clause is not present, the value Nx64k is assumed, unless the line encoding is AMI, the count clause speciﬁes two or more channels, and the contiguous keyword is speciﬁed, in which case the value Nx56k is assumed.

interface t1 id clock source { internal | network } show interface t1 id clock source

These commands set or display the clock source for the speciﬁed T1 WAN interface.

interface t1 id dle { ppp | hdlc | rfc1490 } show interface t1 id dle

These commands set or display the data link encapsulation (DLE) for the speciﬁed T1 WAN interface.

Note: frame-relay is accepted as a synonym for rfc1490.

interface t1 id ds0-autodetect { yes | no } show interface t1 id ds0-autodetect no interface t1 id ds0-autodetect

These commands allow you to set, show, or disable DS0 channel auto-detection on the speciﬁed T1 interface.

2-64 Command Line Interface Commands Reference

interface t1 id framing { d4 | esf } show interface t1 id framing

These commands set or display the framing mode for the speciﬁed T1 WAN interface.

interface t1 id encoding { ami | b8zs } show interface t1 id encoding

These commands set or display the line encoding for the speciﬁed T1 WAN interface.

Note: If this command changes the line encoding from b8zs to ami and there are two or more contiguous

Nx64k channels in use, the channel data rate will be changed to Nx56k.

interface t1 id operation line type { normal | copper-mountain } show interface t1 id operation line type

These commands set or display the operation mode for the speciﬁed T1 WAN interface. The keyword

copper-mountain should be speciﬁed when connected to a Copper Mountain DSLAM T1 line card; the keyword normal should be speciﬁed in all other situations.

interface t1 id prm-enable { yes | no } show interface t1 id prm-enable no interface t1 id prm-enable

These commands set or display whether or not ANSI PRMs are sent on the speciﬁed T1 WAN interface.

interface t1 id rfc1973 enable { yes | no } show interface t1 id rfc1973 enable no interface t1 id rfc1973 enable

These commands set or display whether or not PPP in Frame Relay (RFC1973) is enabled on the speciﬁed T1 WAN interface.

interface t1 id rfc1973 dlci { 16..991 } show interface t1 id rfc1973 dlci

These commands set or display the DLCI used for PPP in Frame Relay (RFC1973) on the speciﬁed T1 WAN interface.

interface t1 id rfc1973 lmi { annexa | annexd | ansi | ccitt | lmi | none } show interface t1 id rfc1973 lmi no interface t1 id rfc1973 lmi

These commands set or display the Local Management Interface (LMI) type for PPP in Frame Relay (RFC1973) on the speciﬁed T1 WAN interface.

Motorola Netopia® Router CLI Commands 2-65

T1 Statistic and Diagnostic commands

T1 Statistic and Diagnostic Commands

show interface t1 id errors { current | interval 1..96 | total }

interface t1 id diagnostic mode { local loopback | normal | remote loopback | send { all ones | blue alarm | loopback } }

show interface t1 id diagnostic mode

show interface t1 id line status

show interface t1 id loopback mode

show interface t1 id loopback status

show interface t1 id errors { current | interval 1..96 | total }

This command displays the error statistics for the speciﬁed T1 WAN interface for a particular 15-minute interval during the previous 24-hour period, or the total for the past 24 hours. Specifying the keyword current displays the error statistics for the current 15-minute interval. Specifying the keyword interval followed by an integer between 1 and 96 displays the error statistics for a prior 15-minute inter val. Inter val 1 is the most recently completed 15-minute interval, while interval 96 is the interval completed 23 hours and 45 minutes prior to interval 1. Specifying the keyword total displays the total error statistics for the last 24 hours.

Example:

#show interface t1 1 errors interval 1 15 minutes ending 16:32:44 Errored Seconds 001 Unavailable Seconds 000 Severely Errored Seconds 001 Bursty Errored Seconds 001 Loss of Frame Count 000 Bipolar Violation Count 001

#show interface t1 1 errors total 24 hours ending 16:32:44 Errored Seconds 001 Unavailable Seconds 000 Severely Errored Seconds 001 Bursty Errored Seconds 001 Loss of Frame Count 000

2-66 Command Line Interface Commands Reference

Bipolar Violation Count 001

#show interface t1 1 errors current Current Interval elapsed time 02:45 Errored Seconds 002 Unavailable Seconds 000 Severely Errored Seconds 001 Bursty Errored Seconds 001 Loss of Frame Count 000 Bipolar Violation Count 000

interface t1 id diagnostic mode { local loopback | normal | remote loopback | send { all ones | blue alarm | loopback } } show interface t1 id diagnostic mode

This command sets or displays the diagnostic mode for the speciﬁed T1 interface. Specifying local loopback puts the near end in local payload loopback mode. Specifying remote loopback instructs the far end to put itself in payload loopback mode. Specifying send all ones or send blue alarm (which are synonyms) causes the near end to start sending an all-ones pattern, which puts the far end in the red alarm state, causing it to send back a yellow alarm. Specifying send loopback causes the near end to begin sending loopback packets. Specifying normal cancels the effect of any previous diagnostic mode command.

After issuing the diagnostic mode send loopback command, the loopback progress can be monitored by issuing the loopback status command (see below).

Motorola Netopia® Router CLI Commands 2-67

show interface t1 id line status

This command displays the line status on the speciﬁed T1 interface. This will display one of the following strings:

Red Alarm Yellow Alarm Blue Alarm Normal Operation

show interface t1 id loopback mode

This command displays the loopback mode of the speciﬁed T1 interface. This will display one of the following strings:

Layer 1 Activation Not Present Local Payload Loopback Enabled Remote Line Loopback Enabled Remote Payload Loopback Enabled Clear - No Loopback Enabled

show interface t1 id loopback status

This command displays the progress of the loopback test on the speciﬁed T1 interface. This will display one of the following strings:

Loopback Not Active PASS (xxxxx good, yyyyy bad packets) FAIL (xxxxx good, yyyyy bad packets)

Examples:

#show interface t1 1 loopback status Loopback Not Active #interface t1 1 diagnostic mode send loopback #show interface t1 1 loopback status PASS (00255 good, 00000 bad packets) #show interface t1 1 loopback status FAIL (00000 good, 00256 bad packets)

2-68 Command Line Interface Commands Reference

Unprotected Services Conﬁguration Commands

Note: These commands are supported beginning with Firmware Version 8.7.4.

When using an IPSec force-all tunnel, Unprotected Services supports router-generated packets with a source IP address outside the local member range. It works by applying a source address to an internally-generated router service, and speciﬁes whether the service should not be routed by default over the force-all IPSec tunnel.

This permits supporting multiple authentication proﬂes with multiple tunnels, as well as supporting authentication proﬁles that point to a RADIUS server on the LAN interface. Other applications such as TACACS+, SNMP, syslog, NTP and heartbeat are not forced over the tunnel.

Unprotected Services Conﬁguration Commands

service interface [ ip_address | cp | ethernet ] [ number ] show service interface [ cp | ethernet ] [ number ] no service interface

service unprotected [ yes | no ] show service unprotected no service unprotected

service interface [ ip_address | cp | ethernet ] [ number ] show service interface [ cp | ethernet ] [ number ] no service interface

These commands allow you to specify, show, or disable the application of a source address to an internally generated router service, such that the service should not be routed by default over a force-all IPSec tunnel.

Applicable internally-generated router ser vices are: RADIUS, TACACS+, SNMP, syslog, NTP and hear tbeat.

■ interface speciﬁes from where the trafﬁc is to be sourced.

■ For cp or ethernet, the router will look up its interface address, reducing the chance of error.

■ If you enter an ip_address that is not a local interface address, the service may either fail to function or the

router will override the invalid address. It will then use the inter face with a route to the server for the service.

If no is used with the commands, the value goes back to the default 0.0.0.0 and no.

Note: Only primary Ethernet interfaces are supported; ALANs are not suppor ted.

Examples:

remote-server interface 100.110.112.113 remote-server interface cp 3 remote-server interface ethernet 0 remote-server unprotected yes

Motorola Netopia® Router CLI Commands 2-69

remote-server unprotected no

service unprotected [ yes | no ] show service unprotected no service unprotected

These commands allow you to specify, show, or disable whether or not a ser vice is "unprotected."

unprotected indicates whether trafﬁc will be sent over a force-all IPSec tunnel or not. All services default to unprotected no, meaning that they will be routed over the IPSec tunnel, unless set to yes.

The no default enhances security since it requires user intervention to prevent the service from being routed over the IPSec tunnel.

If no is used with the commands, the value goes back to the default 0.0.0.0 and no.

Examples:

■ RADIUS, TACACS+

The remote-server conﬁguration controls the settings for both TACACS+ and RADIUS servers.

remote-server interface 0.0.0.0 remote-server unprotected no

■ SNMP

By default, SNMP services use the primary WAN interface, thus no interface selection is required.

■ syslog

system syslog interface 0.0.0.0 system syslog unprotected no

■ NTP

ip ntp interface 0.0.0.0 ip ntp unprotected no

■ heartbeat

heartbeat uses the primary WAN interface, thus no inter face selection is required.

heartbeat unprotected no

If the service fails, a message will be added to the event log. This message has the format;

[service] failed. Could not open socket

2-70 Command Line Interface Commands Reference

IGMP Conﬁguration Commands

Note: These commands are supported beginning with Firmware Version 8.5.1. IGMP Version 3 is supported

beginning with Firmware Version 8.7.

IGMP Conﬁguration Commands

igmp version ( v1 | v2 | v3 ) show igmp version

igmp snooping [ yes | no ] no igmp snooping show igmp snooping

igmp robustness value no igmp robustness show igmp robustness

igmp query-intvl value no query-intvl show query-intvl

igmp query-response-intvl value no query-response-intvl show query-response-intvl

igmp last-member-query-intvl value show igmp last-member-query-intvl

igmp last-member-query-count value show igmp last-member-query-count

igmp fast-leave [ yes | no ] no igmp fast-leave show igmp fast-leave

show igmp group

igmp wireless-m2u [ on | off ]

igmp version ( v1 | v2 | v3 ) show igmp version

These commands allow you to set or show the querier's (LAN's) maximum IGMP version that will be used.

Motorola Netopia® Router CLI Commands 2-71

Beginning with Firmware version 8.7, v3 is the default.

igmp snooping [ yes | no ] no igmp snooping show igmp snooping

These commands allow you to enable, disable, or show the status of the Motorola Netopia® Router’s ability to “listen in” to IGMP trafﬁc. IGMP “snooping” is a feature of Ethernet layer 2 switches that “listens in” on the IGMP conversation between computers and multicast routers. Through this process, it builds a database of where the multicast routers reside by noting IGMP general queries used in the querier selection process and by listening to other router protocols.

From the host point of view, the snooping function listens at a port level for an IGMP repor t. The switch then processes the IGMP report and starts forwarding the relevant multicast stream onto the host's port. When the switch receives an IGMP leave message, it processes the leave message, and if appropriate stops the multicast stream to that particular port. Basically, customer IGMP messages although processed by the switch are also sent to the multicast routers.

igmp robustness value no igmp robustness show igmp robustness

These commands allow you to specify or show the Motorola Netopia® Router’s degree of sensitivity to lost packets. IGMP can recover from robustness minus 1 lost IGMP packet. The default value is 2. The range is 2 –

255.

igmp query-intvl value no query-intvl show query-intvl

These commands allow you to specify or show the amount of time in seconds between IGMP General Query messages sent by the querier router. The default query inter val is 125 seconds. The range is 10s – 600s.

igmp query-response-intvl value no query-response-intvl show query-response-intvl

These commands allow you to specify or show the maximum amount of time in tenths of a second that the IGMP router waits to receive a response to a General Query message. The default quer y response inter val is 10 seconds and must be less than the query interval. The range is 5 deci-sec – 255 deci-sec; the default is 100 deci-sec.

igmp last-member-query-intvl value show igmp last-member-query-intvl

These commands allow you to specify or show the amount of time in deci-seconds that the router waits to receive a response to a Group-Speciﬁc Query message, when igmp-version is set to v2 or v3..

igmp last-member-query-count value show igmp last-member-query-count

These commands allow you to specify or show the number of Group-Speciﬁc Query messages sent.

2-72 Command Line Interface Commands Reference

igmp fast-leave [ yes | no ] no igmp fast-leave show igmp fast-leave

These commands allow you to specify or show the status of the non-standard procedure fast-leave to decrease the time to detect that a group has no more members.

show igmp groups

This command allows you to display the IGMP Snooping table.

igmp wireless-m2u [ on | off ]

Note: This command is supported beginning with Firmware Version 8.7.4.

This command allows you enable or disable wireless multicast-to-unicast if igmp snooping is set to yes. The router replaces the multicast MAC-address with the physical MAC-address of the wireless client. If there is

more than one wireless client interested in the same multicast group, the router will revert to multicasting the stream immediately. When one or more wireless clients leave a group, and the router determines that only a single wireless client is interested in the stream, it will once again unicast the stream.

Global IP Conﬁguration Commands

ip dns { 1 | 2 } ip-addr no ip dns [ { 1 | 2 } [ip-addr] ] show ip dns [ { 1 | 2 } ]

ip domain-name string no ip domain-name [string] show ip domain-name

ip gateway ip-addr no ip gateway ip-addr show ip gateway

backup gateway ip-addr no backup gateway ip-addr show backup gateway

Motorola Netopia® Router CLI Commands 2-73

ip ntp period value no ip ntp period show ip ntp period

ip ntp servers ip-addr1 ip-addr2 no ip ntp servers show ip ntp servers

ip ntp timezone value no ip ntp timezone show ip ntp timezone

ip route { ip-addr/mask-bits | ip-addr mask } gw-ip-addr [{ high | low }] [advertise [{no | distance}] [{enable | disable}] no ip route { ip-addr/mask-bits | ip-addr mask } gw-ip-addr show ip route [{ static | ip-addr | ip-addr/mask-bits | ip-addr mask }]

2-74 Command Line Interface Commands Reference

Global IP Conﬁguration Commands (continued)

ip state-insp udp-timeout value show ip state-insp udp-timeout

ip state-insp tcp-timeout value show ip state-insp tcp-timeout

ip state-insp dos-detect value show ip state-insp dos-detect

ip state-insp xposed-addr { [server-list-tag start-ip-addr end-ip-addr] }

{ [protocol start-port end-port] }

no ip state-insp xposed-addr { [server-list-tag] } show ip state-insp xposed-addr abc

ip dns { 1 | 2 } ip-addr no ip dns [ { 1 | 2 } [ip-addr] ] show ip dns [ { 1 | 2 } ]

These commands allow you to set, change, delete, or show the router’s primary and secondary domain name server addresses.

ip domain-name string no ip domain-name [string] show ip domain-name

These commands allow you to set, change, delete, or show the domain name of the router. string can be up to 64 characters in length and may contain only valid domain name characters (alpha-numeric characters, dot ("."), and dash ("-"). Note that email addresses contain the at symbol ‘@’ and are not valid domain names.

ip gateway ip-addr no ip gateway ip-addr show ip gateway

These commands allow you to set, change, delete, or show the router’s default gateway.

backup gateway ip-addr no backup gateway ip-addr show backup gateway

This command allows you to set, change, delete, or show the router’s default backup gateway.

Motorola Netopia® Router CLI Commands 2-75

ip ntp period value no ip ntp period show ip ntp period

Note: These commands are supported beginning with Firmware Version 8.3.3.

These commands allow you to set, disable, or display the setting of a Network Time Protocol (NTP) server’s NTP Update Interval for the router. The value should be entered in HHHH:MM format.

ip ntp servers ip-addr1 ip-addr2 no ip ntp servers show ip ntp servers

Note: These commands are supported beginning with Firmware Version 8.3.3.

These commands allow you to set, disable, or display the Host Name or IP Address of a Network Time Protocol (NTP) server you want to specify for the router. You can also specify an alternate NTP ser ver Host Name or IP Address, separated by a space.

ip ntp timezone value no ip ntp timezone show ip ntp timezone

Note: These commands are supported beginning with Firmware Version 8.3.3.

These commands allow you to set, disable, or display your time zone. You can specify the time zone as + or Greenwich Mean Time (GMT), or as the standard abbreviation of your zone, if it has one.

For example: GMT -8:00 Paciﬁc Standard Time can be entered as pst. The following table shows some standard time settings.

GMT -10:00 Hawaii Standard Time GMT +3:30 Tehran

GMT -9:00 Alaska Standard Time GMT +4:00 Russia Zone 3

GMT -8:00 Paciﬁc Standard Time GMT +4:30 Kabul

GMT -7:00 Mountain Standard Time GMT +5:00 Russia Zone 4

GMT -6:00 Central Standard Time GMT +5:30 India

GMT -5:00 Eastern Standard Time GMT +6:00 Russia Zone 5

GMT -4:00 Atlantic Standard Time GMT +7:00 Russia Zone 6

GMT -3:30 Newfoundland GMT +8:00 W. Australia Std.

Time

GMT -2:00 Mid-Atlantic Time GMT +9:00 Japan Standard Time

GMT -1:00 Azores Time GMT +9:30 Adelaide, Darwin

GMT +0:00 Greenwich Mean Time GMT +10:00 E. Aust. Std. Time

2-76 Command Line Interface Commands Reference

GMT +1:00 Central Europe Time GMT +11:00 Russia Zone 10

GMT +2:00 Eastern Europe Time GMT +12:00 Russia Zone 11

GMT +3:00 Moscow time (MSK)

ip route { ip-addr/mask-bits | ip-addr mask } gw-ip-addr [{ high | low }] [advertise [{no | distance}] [{enable | disable}]

no ip route { ip-addr/mask-bits | ip-addr mask } gw-ip-addr show ip route [{ static | ip-addr | ip-addr/mask-bits | ip-addr mask }]

The ip route and no ip route commands allow you to add, change, or delete static routes. The show ip route static form of the show ip route command displays the conﬁgured static routes (including invalid or disabled

ones), while the other forms of the show ip route command display the router's IP routing table (including any installed (i.e., valid and enabled) static routes).

The destination network may be speciﬁed as an IP address and mask in either preﬁx or dotted-quad notation. gw-ip-addr is the IP address of the next-hop router, and should be on one of the router's directly connected IP subnets.

The keywords high and low control the priority of the static route relative to an identical route learned via RIP. A static route with high priority (the default) takes precendence over an identical route learned via RIP, while an identical route learned via RIP takes precedence over a static route with low priority.

The keyword advertise controls whether or not the router will advertise (redistribute) the static route via RIP. The keyword advertise may be followed by a RIP metric (distance) between 1 (the default) and 15 inclusive.

If the show ip route command includes an optional IP address or IP address and mask, the route, if any, in the IP routing table that pertains to the speciﬁed destination network, subnetwork, or host address is displayed.

Examples:

ip route 192.168.2.0/24 192.168.1.123 low advertise

no ip route 192.168.2.0 255.255.255.0 192.168.1.123

show ip route

show ip route static

Note: Beginning with Firmware Version 8.2, the ip route commands will no longer show or set static routes

that are default gateways. They will only operate on direct routes (IP address and mask are non-zero). The default gateway routes are now meant to be handled with two commands: 1) ip gateway, which conﬁgures the Primary Default Gateway, and 2) backup gateway, which conﬁgures the Backup Default gateway.

Motorola Netopia® Router CLI Commands 2-77

DHCP Gen-Options, Option Groups, and Option Filtersets Commands

DHCP Gen-Options commands

ip dhcp gen-option tag option 1..255 [ data-type { ascii | hex | dotted-decimal } ] [ data data ] ip dhcp gen-option tag data-type { ascii | hex | dotted-decimal } ip dhcp gen-option tag data { data_of_the_correct_format_given_data-type }

ip dhcp gen-option tag priority { low | high } show ip dhcp gen-option tag priority { low | high } no ip dhcp gen-option tag

ip dhcp gen-option tag option 1..255 [ data-type { ascii | hex | dotted-decimal } ] [ data data ]

This command allows you to specify a DHCP generic option set speciﬁed by tag of one to 15 characters. You can specify up to 20 gen-options. Each can contain up to 100 bytes of data, up to a maximum of 912 bytes of options data total, although, in practical terms, the CLI’s 80-character limit will restrict it to fewer. An option speciﬁed by a gen-option will be served only if the client requests it.

The following table shows the formats and sizes for known options, and whether or not you can conﬁgure a

gen-option of that type.

Option Data Format

0 Empty 0 No 1 IP mask 4 Yes 2 Unsigned 4 byte integer 4 Yes 3 - 11 IP address list Multiples of 4 Yes 12 String (up to 100 characters) N Yes 13 Unsigned 2 byte integer 2 Yes 14 - 15 String (up to 100 characters) N Yes 16 Unsigned 4 byte integer 4 Yes 17 String (up to 100 characters) N Yes 18 String (up to 100 characters) N Yes 19 - 20 Flag 1 Yes 21 IP address & mask list Multiples of 8 Yes 22 Unsigned 2 byte integer 2 Yes

Data Size (bytes)

Can Conﬁgure

2-78 Command Line Interface Commands Reference

Option Data Format

23 Unsigned 1 byte integer 1 Yes 24 Unsigned 4 byte integer 4 Yes 25 Unsigned 2 byte integer list Multiples of 2 Yes 26 Unsigned 2 byte integer 2 Yes 27 Flag 1 Yes 28 IP address 4 Yes 29 - 31 Flag 1 Yes 32 IP address 4 Yes 33 IP address and mask list Multiples of 8 Yes 34 Flag 1 Yes 35 Unsigned 4 byte integer 4 Yes 36 Flag 1 Yes 37 Unsigned 1 byte integer 1 Yes 38 Unsigned 4 byte integer 4 Yes 39 Flag 1 Yes 40 String (up to 100 characters) N Yes 41 - 42 IP address list Multiples of 4 Yes 43 Vendor-speciﬁc String Yes 44 - 45 IP address list Multiples of 4 Yes 46 Unsigned 1 byte integer 1 Yes 47 String (up to 100 characters) N Yes 48 - 49 IP address list Multiples of 4 Yes 50 IP address 4 No 51 Unsigned 4 byte integer 4 No 52 Unsigned 1 byte integer 1 No 53 Unsigned 1 byte integer 1 Yes 54 IP address 4 Yes 55 String (up to 100 characters) N No 56 String (up to 100 characters) N Yes 57 Unsigned 2 byte integer 2 Yes 58 - 59 Unsigned 4 byte integer 4 No 60 String (up to 100 characters) N Yes 61 String (up to 100 characters) N No 62 String (up to 100 characters) N Yes 63 Complex N No 64 String (up to 100 characters) N Yes

Data Size (bytes)

Can Conﬁgure

Motorola Netopia® Router CLI Commands 2-79

Option Data Format

65 IP address list Multiples of 4 Yes 66 - 67 String (up to 100 characters) N Yes 68 - 76 IP address list Multiples of 4 Yes 77 Pascal string list (length byte + data) N Yes 78 - 79 Complex N No 80 Empty 0 No 81 Complex N No 82 Sub-option list N Yes 83 Complex N No 84 Undeﬁned ?? Yes 85 IP address list Multiples of 4 Yes 86 - 87 Unicode String Multiples of 2 Yes 88 Encoded DN list N Yes 89 IP address list Multiples of 4 Yes 90 Complex N No 91 - 97 Undeﬁned/Weakly deﬁned ?? Yes 98 String (up to 100 characters) N Yes 99 - 115 Undeﬁned/Weakly deﬁned ?? Yes 116 Flag 1 Yes 117 Unsigned 2 byte integer list Multiples of 2 Yes 118 IP address 4 Yes 119 Encoded DN list 2 N Yes 120 Encoded DN list or IPAddress list N Yes 121 - 125 Complex N No 126 - 127 Undeﬁned N Yes 128 IP address list Multiples of 4 Yes 129 - 223 Undeﬁned/Weakly deﬁned ?? Yes 224 - 254 Private Use N Yes 249 (note) Microsoft uses this instead of 121 N Yes 255 Empty 0 No

Data Size (bytes)

Can Conﬁgure

ip dhcp gen-option tag data-type { ascii | hex | dotted-decimal }

This command allows you to specify the DHCP gen-option data type: ascii, hex or dotted-decimal.

2-80 Command Line Interface Commands Reference

ip dhcp gen-option tag data { data_of_the_correct_format_given_data-type }

This command allows you to specify the gen-option data.

■ If the data-type is ascii, then any printable character

■ If the data-type is hex, then an even number of hex characters (e.g. “0123456789AbcdEf”

■ If the data-type is dotted-decimal, then a series of numbers between 0 and 255, separated by a period (.).

IP addresses are generally represented in this form.

ip dhcp gen-option tag priority { low | high } show ip dhcp gen-option tag priority { low | high } no ip dhcp gen-option tag

These commands allow you to set, display, or disable whether the default handling behavior for a particular option should be overridden by the speciﬁed gen-option. For most options this is irrelevant, but at least the following options are handled in the router outside the context of gen-options:

OPTION_SUBNETMASK 1

OPTION_ROUTER 3

OPTION_DNSSERVER 6

OPTION_DOMAINNAME 15

OPTION_BCASTADDR 28

OPTION_ETHERNETENCAP 36

OPTION_NTPSERVERS 42

OPTION_NBNSNAMESERVERS 44

OPTION_NBTCPNODETYPE 46

OPTION_NBTCPSCOPE 47

OPTION_LEASETIME 51

OPTION_RENEWALTIME 58

OPTION_REBINDINGTIME 59

OPTION_VID_VENDOR_SPECIFIC (vendor identity) 125

OPTION_TFTP_SERVER_ADDR 150

Note: In most cases overriding the CPE default behavior is not recommended. Also, if the CPE can, but does

not, serve an option in the above list, corresponding low-priority gen-options will be used to ser ve it.

Motorola Netopia® Router CLI Commands 2-81

DHCP Option Groups commands

ip dhcp option-group tag [ gen-option gen_option_tag ] show ip dhcp option-group tag no ip dhcp option-group tag [ gen-option gen_option_tag ]

interface ethernet id address-serve dhcp default-option-group option_group_tag show interface ethernet id address-serve dhcp default-option-group no interface ethernet id address-serve dhcp default-option-group

ip dhcp option-group tag [ gen-option gen_option_tag ] show ip dhcp option-group tag no ip dhcp option-group tag [ gen-option gen_option_tag ]

These commands allow you to set, display, or disable one of up to eight DHCP Option Groups. Each Option Group can have a name of between 1 and 15 characters. The name is used in the DHCP ﬁlterset syntax to choose what group of gen-options is to be served to a particular DHCP Client.

Option Groups refer to gen-options; they do not contain them. Deleting a gen-option from an option group does not delete the option. Adding a gen-option to an option-group does not preclude it from being added to another option-group.

These commands allow you to set, display, or disable the option group speciﬁed by option_group_tag as the default.

2-82 Command Line Interface Commands Reference

DHCP Option Filtersets commands

Support for DHCP option ﬁltering is provided via the ﬁlterset settings.

DHCP Option Filtersets commands

ip dhcp-ﬁlterset fs-tag [ ﬁlter { new | last | id {1..8} }

[ type { dhcp-option | hw-address | requested-option } ] [ dhcp-option { 1..255 } ] [ { match-str string_w_wildcards ('*' or '?') } | { [ start-address mac-address ] [ end-address mac-address ] } } ] [ match-action { pass | discard | continue } ] [ match-pool ip-addr ] [ match-option-group { none | opt-group-tag } ] [ absent-action { pass | discard | continue } ] [ absent-pool ip-addr ] [ absent-option-group { none | opt-group-tag } ] ]

show ip dhcp-ﬁlterset [ fs-tag [ [ﬁlter ] { last | { id 1..8 } } ] ] ] no ip dhcp-ﬁlterset [ fs-tag [ [ ﬁlter ] { last | {id 1..8 } } ] ] ]

interface ethernet id address-serve dhcp ﬁlterset fs-tag show interface ethernet id address-serve dhcp ﬁlterset no interface ethernet id address-serve dhcp ﬁlterset

bridge-dhcp-ﬁlterset fs-tag show bridge-dhcp-ﬁlterset no bridge-dhcp-ﬁlterset

ip dhcp-ﬁlterset fs-tag [ ﬁlter { new | last | id {1..8} }

show ip dhcp-ﬁlterset [ fs-tag [ [ﬁlter ] { last | { id 1..8 } } ] ] ] no ip dhcp-ﬁlterset [ fs-tag [ [ ﬁlter ] { last | {id 1..8 } } ] ] ]

These commands allow you to specify, display, or disable a DHCP ﬁlterset named fs-tag.

Motorola Netopia® Router CLI Commands 2-83

A ﬁlter can be identiﬁed by its ones-based index, [e.g.] 1, or with the special new keyword. Subsequent modiﬁcations to this ﬁlter, assuming no more ﬁlters have been added to the ﬁlter set yet, must be done by referring to the ﬁlter either by id (1), or by the other special keyword last. Subsequent ﬁlters can be added using either new or by the next integer ﬁlter id. You can always specify the last ﬁlter in the set by using last. It is an error to attempt to create a new ﬁlter whose id is not 1 greater than the id of the last ﬁlter.

Up to two ﬁltersets can be added. Your router supports a single LAN DHCP server instance, but an additional ﬁlterset is available for use when bridging, to block undesired DHCP trafﬁc. Up to 8 rules can be created in the ﬁlterset, which are evaluated in order.

■ type: The rule can either specify an option and option contents dhcp-option, a client hardware address

range hw-address, or an option the client is requesting requested-option. By default a rule is of type dhcp-option.

■ dhcp-option: (1..255 ) If the ﬁlter is of type dhcp-option or requested-option, the dhcp-option information

determines which DHCP option is speciﬁed. See page 2-77 for a table of DHCP options.

■ match-str: The match-str string_w_wildcards will be compared against the DHCP DISCOVER option data.

This string can contain multiple “*” and “?” wildcard substitutions. This is supported only if the ﬁlter is of type dhcp-option.

■ start-address/end-address: a client hardware address range. This is supported only if the ﬁlter is of type

hw-address.

■ match-action:

■ If set to pass, the match-pool parameter is used to assign a pool start address, or 0.0.0.0 to pass

unchanged. DHCP packets matching the option string will pass.

■ If set to discard, DHCP packets matching the option string will be blocked.

■ If set to continue, the remaining rules in the ﬁlter will execute.

■ match-pool: Speciﬁes the start IP address of the range within a DHCP pool where that range will be used to

allocate an address if the wildcard matches. The value 0.0.0.0 means regular processing; 255.255.255.255 means discard.

■ match-option-group: Speciﬁes an option group identiﬁed by opt-group-tag, or none for the match-action

parameter.

■ absent-action: As with match-action, absent-action describes the action taken if the matching DHCP

option was not found, using the absent-pool parameter to provide the necessary pool start address.

Note: absent is NOT the opposite of match. The absent- part of the rule is taken if the speciﬁed option is

absent.

■ absent-pool: Speciﬁes the start IP address of the range within a DHCP pool where that range will be used

to allocate an address if the option in the DHCP packet is not present. The value 0.0.0.0 means regular processing; 255.255.255.255 means discard.

■ absent-option-group: Speciﬁes an option group identiﬁed by opt-group-tag, or none for the absent-action

parameter.

2-84 Command Line Interface Commands Reference

interface ethernet id address-serve dhcp ﬁlterset fs-tag show interface ethernet id address-serve dhcp ﬁlterset no interface ethernet id address-serve dhcp ﬁlterset

These commands allow you to set, display, or disable a DHCP ﬁlterset speciﬁed by fs-tag for the Ethernet interface speciﬁed by id.

bridge-dhcp-ﬁlterset fs-tag show bridge-dhcp-ﬁlterset no bridge-dhcp-ﬁlterset

These commands allow you to set, display, or disable a DHCP ﬁlterset speciﬁed by fs-tag for use when bridging.

Motorola Netopia® Router CLI Commands 2-85

Stateful Inspection Commands

Netopia CLI 874 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Chapter 1

Introduction

New Commands in Firmware Version 8.7.4

Syntax Notation

Interface Naming Conventions

Entering and Editing Commands

Online Help

Chapter 2

Motorola Netopia® Router CLI Commands

MAC Address Security Commands

Priority Queuing (TOS bit) Commands

Differentiated Services (Diffserv) commands

PVCs

T1 Statistic and Diagnostic commands

DHCP Gen-Options, Option Groups, and Option Filtersets Commands

DHCP Gen-Options commands

DHCP Option Groups commands

DHCP Option Filtersets commands
