NETIS SYSTEMS WF2402R Users Manual

WF-2402

Quick Installation Guide

netis 150Mbps Wireless-N

Broadband Router

V1.1

2010-09-24

150Mbps Wireless-N Broadband Router Quick Installation Guide

1. Check Your Package Contents

The following items should be found in your package:

¾ 150Mbps Wireless-N Broadband Router
¾ Power adapter
¾ Quick Installation Guide
¾ CD-Rom
¾ Ethernet cable

Make sure that the package contains above items. If any of the above items is missing or
damaged, please contact the store you bought this product from.

2. Before You Begin

Minimum Requirements:

¾ Broadband (DSL/Cable) modem and service with Ethernet port
¾ 802.11n b/g/n wireless adapter or Ethernet adapter and cable for each computer
¾ Internet Explorer® 5.0, Firefox® 2.0 or Safari® 1.4 or higher

1

150Mbps Wireless-N Broadband Router Quick Installation Guide

3. Hardware Installation

Figure 3-1

¾ Attach one end of an Ethernet cable to your computer’s Ethernet port, and the other end to
one of the LAN ports of your router.
¾ Connect another Ethernet cable from your Cable/DSL modem to the WAN port of your
router.
¾ Connect the single DC output connector of the power adapter to the power jack on the back
of the router and plug the Power Adapter into an AC outlet.

4. LED Indicators

Figure 4-1

LED Function

2

150Mbps Wireless-N Broadband Router Quick Installation Guide

Power on

SYS Flashing

On WAN Connection normal

WAN

Flashing Data transmitting

On LAN Connection normal

LAN

Flashing Data transmitting

Router system running
WPS working (orange)

5. Configure Your Computer

You can manage the 150Mbps Wireless-N broadband router through the Web browser- based
configuration utility. To configure the device via Web browser, at least one properly
configured computer must be connected to the device via Ethernet or wireless network. The
router is configured with the default IP address of 192.168.1.1 and subnet mask of

255.255.255.0 and its DHCP server is enabled by default.
Here we use Windows XP for example. If your network settings are not already set and
you need to complete this step, the configurations are similar for the other operating
systems.
¾ Open My Computer on your desktop or through the Start menu, right click on My

Network Places in the Other Places menu to the left and select Properties. Right click

on your Local Area Connection in the window that appears and select Properties. In the
properties window that appears, under “This connection uses the following items:” select
Internet Protocol (TCP/IP) and then click the Properties button below.

3

150Mbps Wireless-N Broadband Router Quick Installation Guide

Figure 5-1

¾ Select obtain an IP address automatically and obtain DNS server address
automatically, click OK

Figure 5-2

¾ Back in the previous window, click OK
