NETIS SYSTEMS WF2111R Users Manual

WF-2111

150Mbps Wireless-N USB Adapter

User Manual

V1.1

2011-05-25

WF-2111 User manual

Certification

FCC CE

FCC Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not ins talled and use d in accordance with th e instructions, may
cause harmful interference to radio communic ations. However, there is no guar antee that interference
will not occur in a particular installation. If this equipment does cause harmful in terferen ce to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation b etween the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment. (Example- use
only shielded interface cables when connecting to computer or peripheral devices)

FCC Radiation Exposure Statement

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
This equipment complies with Part 15 of the FCC Rules. Operatio n is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any inter ference r ece ived, i ncl uding int erferen ce that may cause undesir ed
operation.

Caution!

The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user authority to operate the
equipment

- 2 -

WF-2111 User manual

Package Contents

The following items should be found in your package:

¾ 150Mbps Wireless-N USB Adapter
¾ Quick Installation Guide
¾ CD-Rom

Make sure that the package contains above items. If any of the above items is missing or damaged,
please contact the store you bought this product from.

- 3 -

WF-2111 User manual

Content

1 INTRODUCTION .......................................................................................................... ................ ‐5‐

1.1 PRODUCTOVERVIEW .......................................................................................................................... ‐5‐

1.2 MAINFEATURES ................................................................................................................................‐5‐

1.3 STANDARDS ......................................................................................................................................‐5‐

1.4 WORKINGENVIRONMENT....................................................................................................................‐5‐

1.5 SYSTEMREQUIREMENTS ......................................................................................................................‐6‐

2 DRIVERANDHARDWAREINSTALLATION .................................................................................... ‐7‐

2.1 DRIVERANDSOFTWAREINSTALLATION...................................................................................................‐7‐

2.2 INSERTTHEADAPTER ..........................................................................................................................‐9‐

3 SYSTEMCONFIGURATION ......................................................................................................... ‐11‐

3.1 GENERAL ........................................................................................................................................‐11‐

3.2 PROFILE..........................................................................................................................................‐13‐

3.2.1 Add.................................................................................................................................... ‐13‐

3.2.2 Remove ............................................................................................................................. ‐15‐

3.2.3 Edit.................................................................................................................................... ‐16‐

3.2.4 Duplicate........................................................................................................................... ‐17‐

3.2.5 Setdefault......................................................................................................................... ‐18‐

3.3 AVAILABLENETWORK .......................................................................................................................‐18‐

3.4 STATUS ..........................................................................................................................................‐20‐

3.5 STATISTICS ......................................................................................................................................‐20‐

3.6 WI‐FIPROTECTSETUP ......................................................................................................................‐21‐

4 THEACCESSPOINTMODE......................................................................................................... ‐24‐

4.1 GENERAL ........................................................................................................................................‐24‐

4.2 ADVANCED .....................................................................................................................................‐26‐

4.3 STATISTICS ......................................................................................................................................‐27‐

4.4 ICS................................................................................................................................................‐28‐

5 TROUBLESHOOTING.................................................................................................................. ‐29‐

- 4 -

WF-2111 User manual

1 Introduction

1.1 Product Overview

This 150Mbps Wireless-N Adapter is a powerful USB 2.0 Adapter that installs quickly and easily
with PCs. The Adapter can be used in ad hoc mode to connect directly with other wireless
adapters for peer-to-peer file sharing, or in infrastructure mode to connect with a wireless access
point or router. The adapter connects with 802.11n networks at up to 150Mbps, and is backwards
compatible with 54Mbps 802.11g or 11Mbps 802.11b devices. In every mode, your wireless
connection can be protected so your data stays secure.

1.2 Main Features

¾ Supports 150Mbps transmission rates
¾ Complies with IEEE 802.11b, 802.11g and 802.11n standards for 2.4GHz Wireless LAN
¾ USB 2.0
¾ Meets 64/128-bit WEP, WPA, and WPA2 security standards
¾ Compatible with Windows 2000/XP/Vista/7
¾ Low power consumption
¾ Easy to install and configure
¾ WPS enabled

1.3 Standards

¾ 802.11b/g/n
¾ 802.11i

1.4 Working Environment

Temperature

¾ 0° to 40° C (operating)
¾ -40° to 70° C (storage)

Humidity

¾ 10% to 90 % non-condensing (operating)
¾ 5% to 90% non-condensing (storage)

- 5 -

WF-2111 User manual

1.5 System Requirements

¾ Available USB 1.1 or USB 2.0 slot
¾ 300 MHz processor and 32 MB of memory
¾ CD-ROM drive
¾ An 802.11b/g/n access point (for Infrastructure Mode) or another 802.11b/g/n wireless

adapter (for Ad Hoc; Peer-to-Peer networking mode.)

¾ Microsoft® Windows® 7, V i sta™, XP, 2000 SP4

- 6 -

WF-2111 User manual

2 Driver and Hardware Installation

2.1 Driver and Software Installation

¾ Insert the Driver and Utility CD-ROM into the CD-ROM driver.
¾ The Wizard should run automatically. If not, click the Start button and choose Run. In the

field that appears, enter D:\autorun.exe (if ‘’D’’ is the letter of your CD-ROM drive).

¾ Click Install Driver & Utility for USB Wireless Adapter on the Wireless Client

Configuration Utility dialogue box, and then select the installing language from the next
screen and click Next button.

¾ Click Next

Figure 2-1

- 7 -

WF-2111 User manual

¾ Click Install to start installing

Figure 2-2

Figure 2-3

¾ Follow the InstallShield Wizard steps, and click Finish when done.

- 8 -

WF-2111 User manual

Figure 2-4

¾ Now your PC or notebook will restart automatica lly.

2.2 Insert the Adapter

The 150Mbps Wireless-N USB Adapter supports up to 150 Mbps transfer rate. This card is fully
compliant with the specifications defined in IEEE802.11n standard. It is designe d to complement
USB2.0 computers and supports Windows2000/XP/2003/Vista/7.

Figure 2-5

Install Wireless USB Adapter

¾ Power on your PC, let the operating system boot up completely, and log in succeed.
¾ Hold the adapter and insert it into a USB slot.

- 9 -
