netis Wireless Dual Band Router
Quick Installation Guide
R
1.Package Contents
*
WF2710, WF2710D, WF2722,WF2722D, WF2780, WF2780D, WF2891, WF2891D,etc.
* The product model shown in this QIG is WF2710, as an example.
This QIG is for all netis wireless dual band routers, including models- WF2471, WF2471D,
Power Adapter
Ethernet Cable
Wireless Dual Band Router
QIG
neti s Wirel ess Dua l Band Ro uter
Quic k Insta llati on Guid e
netis Wireless Dual Band Router Quick Installation Guide
1
2.Hardware Connection
2.1. Power off your Modem.
2.2. Connect the WAN port on netis Router to the Modem's LAN port with an Ethernet cable.
2.3. Connect your computer to one of the LAN ports on netis Router with an Ethernet cable.
2.4. Power on your Modem.
2.5. Plug the provided Power Adapter into the PWR jack of netis Router and the other end to
a standard electrical socket. Then wait for one minute.
CABLE
CABLE
LINE IN
POW ER
xDSL/C able Modem
Notebo ok with wirele ss ne twork adapte r
Computer wit h wired net work adap ter
5
POWER
netis Wireless Dual Band Router Quick Installation Guide
2
3.Configure the Router via Web
Management Page
3.1. Set the IP address of the wired network adapter on your computer
as“Automatic” or “DHCP”.
For Windows 8/ 7/Vista
1) Go to “Settings” (Win 8)/ “Start” (Win 7/Vista)> “Control Panel”.
2) Left-click on “Network and Internet”> “Network and Sharing Center”> “Change
adapter settings” (Win 8/7)/ “Manage network connections” (Win Vista).
3) Right-click on “Local Area Connection” and left-click on “Properties”.
4) Double-click on “Internet Protocol Version 4 (TCP/IPv4)”.
5) Select “Obtain an IP address automatically” and “Obtain DNS server address
automatically” then left-click on “OK”.
For Windows XP/2000
1) Go to “Start”> “Control Panel”.
2) Left-click on “Network and Internet Connections”> “Network Connections”.
3) Right-click on “Local Area Connection” and left-click on “Properties”.
4) Double-click on “Internet Protocol (TCP/IP)”.
5) Select “Obtain an IP address automatically” and “Obtain DNS server address
automatically” then left-click on “OK”.
For MAC OS
1) Click on the “Apple” menu> “System Preferences”.
2) Click on the “Network” icon.
3) Click on “Ethernet” in the left side box and click on “Advanced” in the lower right corner.
4) In the top options, select “TCP/IP”.
5 )In the pull-down menu next to “Configure Ipv4”, select “Using DHCP”.
6) Click “OK” then “Apply”.
3.2. Open your browser and type 192.168.1.1 in the address field to visit
router's web management page.
192.168.1.1
netis Wireless Dual Band Router Quick Installation Guide
3
1) In “Quick Setup” page, select your Internet Connection Type.
If “DHCP (Cable Modem)” is selected, the router will automatically receive the IP
parameters from your ISP (Internet Service Provider).
If “Static IP” is selected, please enter the IP Address/Subnet Mask/Default
Gateway/DNS Servers given by your ISP.
If “PPPoE” is selected, please enter the Username and Password given
by your ISP.
2) Under Wireless Setup, configure your wireless network name (SSID) and
password.
3) Left-click on “Save” to make your settings take effect.
3. 3. Select the language as you need on the top box,default is in English.
Tip 1:
IP address: 192.168.1.1
2.4G default SSID: netis_2.4G_XXXXXX 5G default SSID: netis_5G_XXXXXX
Default wireless password: password
(XXXXXX: Last 6 digits of LAN MAC Address)
Tip 2:
You can click on button on the top for other Internet
connection types and further settings.
netis Wireless Dual Band Router Quick Installation Guide
4
How do I restore my netis Router's configuration to its default settings?
With the router powered on, use a pin to press and hold the Default button
on the rear panel for 8 to 10 seconds before releasing it. The router will
reboot and all configurations are back to factory default.
Q
A
4.Troubleshooting
What can I do if my Internet cannot be accessed?
1) Check to verify the hardware connections are correct.
Please refer to the “Hardware Connection” step.
2) Login to netis Router's web management page and ensure that you
set the correct Internet Connection Type.
For cable modem users, please configure “MAC Clone” additionally.
Q
A
On the left-side menu, left-click on > “Network”> “WAN”.
And in the middle page, left-click on “Advanced”> “MAC Clone” and
then “Save” it.
NETIS SYSTEMS CO., LTD.
www.netis-systems.com
MADE IN CHINA
Technical Support:
USA/ Canada:
Toll Free: +1 866 71 network (+1 866 716 3896)
E-mail: usa_support@netis-systems.com
Other Regions:
E-mail: support@netis-systems.com
3) Reboot the modem first and then netis Router. Wait for one minute
before you check the Internet again.
4) If Internet access is not available, please connect your computer
directly to your modem and try the Internet again.
If the Internet is still not working, please contact your ISP for further help.
Router Inalámbrico de Doble Banda netis
Guía de Instalación Rápida
R
1.Contenido del Empaque
Adaptador de alimentación
Cable Ethernet
Router inalámbrico de
Doble Banda
Guía de Instalación Rápida
Guía de Instalación Rápida del Router Inalámbrico de Doble Banda netis
1
2.Conexión del Hardware
2.1. Apague el Módem.
2.2. Conecte el puerto de red de área amplia (WAN) del Router netis al puerto de red de
área local (LAN) del módem con un cable Ethernet.
2.3. Conecte su ordenador a uno de los puertos de red de área local (LAN) del router
netis con un cable Ethernet.
2.4. Encienda el Módem.
2.5. Conecte el adaptador de alimentación suministrado en el conector de alimentación
(PWR) del router netis y el otro extremo a una toma de corriente estándar. Luego,
espere durante un minuto.
CABLE
CABLE
ENTRAD A
DE LINEA
ALIMEN TACIÓN
XDSL / Cable de Mo dem
portát il (notebook ) con e l adaptador
de red ina lámbrica
5
ALIMEN TACIÓN
*
incluidos los modelos- WF2471, WF2471D, WF2710, WF2710D, WF2722,WF2722D,
WF2780, WF2780D, WF2891, WF2891D, etc.
*El ejemplo del modelo del producto que se muestra en esta Guía de Instalación Rápida es
WF2710.
Esta guía de instalación rápida es para todos los router inalámbricos netis de doble banda,
ordena dor con el adapt ado r
de red por c able
neti s Wirel ess Dua l Band Ro uter
Quic k Insta llati on Guid e
