Page 1
Universal WiFi Extender Powerline Edition
(XAVN2001)
User Manual
350 East Plumeria Drive
San Jose, CA 95134
USA
January 2013
202-10998-01
Page 2
Universal WiFi Extender - Powerline Edition (XAVN2001)
Support
Thank you for selecting NETGEAR products.
After installing your device, locate the serial number on the label of your product and use it to register your product
at
https://my.netgear.com. You must register your product before you can use NETGEAR telephone support.
NETGEAR recommends registering your product through the NETGEAR website. For product updates and web
support, visit
Phone (US & Canada only): 1-888-NETGEAR.
Phone (Other Countries): Check the list of phone numbers at
http://support.netgear.com/general/contact/default.aspx.
http://support.netgear.com.
Trademarks
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of
NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change
without notice. © NETGEAR, Inc. All rights reserved.
2
Page 3
Contents
Chapter 1 Getting Started
Chapter 2 Using NETGEAR genie
Hardware Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
LED and Feature Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
How the WiFi Extender Fits into Your Network . . . . . . . . . . . . . . . . . . . . . . 8
Set Up the Powerline Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Set Up a New Powerline Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Add the WiFi Extender to an Existing Powerline Network . . . . . . . . . . . 11
Set Up the WiFi Extender Wireless Network . . . . . . . . . . . . . . . . . . . . . . . 12
Method A: Use NETGEAR genie for Wireless Setup . . . . . . . . . . . . . . . 12
Method B: Use WPS for Wireless Setup . . . . . . . . . . . . . . . . . . . . . . . . 15
Join the WiFi Extender Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . 16
Method A: Join the Wireless Network Manually . . . . . . . . . . . . . . . . . . . 16
Method B: Join the Wireless Network Using WPS . . . . . . . . . . . . . . . . . 16
Powerline Network Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Use the Security Button to Set the Encryption Key . . . . . . . . . . . . . . . . . . 17
Install NETGEAR genie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
The Powerline Utility Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Security Icon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
View the Link Rate between Powerline Devices . . . . . . . . . . . . . . . . . . . . 24
Change the Name of a Powerline Device. . . . . . . . . . . . . . . . . . . . . . . . . . 25
Turn LEDs Off or On. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Set the Powerline Encryption Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Reset a Device to Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . 28
Add a Device to the Powerline Network . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Change the Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Access NETGEAR Web genie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Configure Advanced Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Update the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Chapter 3 Troubleshooting
Basic Functioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Troubleshooting Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
If You Do Not See All Your Devices with the NETGEAR genie . . . . . . . . . 38
If You Do Not See the Powerline Icon on Your Network Map . . . . . . . . . .38
Symantec Endpoint Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Appendix A Supplemental Information
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3
Page 4
Universal WiFi Extender - Powerline Edition (XAVN2001)
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Appendix B Notification of Compliance
Index
4
Page 5
1. Getting Started
This chapter describes your Universal WiFi Extender (XAVN2001) and how your WiFi extender
fits into a home network. It also explains the security features and how to secure your Powerline
network with a private encryption key.
This chapter includes:
• Hardware Features
• How the WiFi Extender Fits into Your Network
• Set Up the Powerline Network
• Set Up the WiFi Extender Wireless Network
• Join the WiFi Extender Wireless Network
• Powerline Network Security
• Use the Security Button to Set the Encryption Key
For more information about the topics covered in this manual, visit the NETGEAR support
website at
http://support.netgear.com.
1
5
Page 6
Universal WiFi Extender - Powerline Edition (XAVN2001)
Universal WiFi Extender – Powerline Edition
(XAVN2001)
Ethernet cable
Factory
Reset
button
On/Off
switch
Ethernet
port
Security
button
Ethernet
LED
Wireless
LED
Power
LED
Powerline LED
Hardware Features
The package includes a Universal WiFi Extender (XAVN2001) and an Ethernet cable.
Figure 1. Package contents
Figure 2. Universal WiFi Extender - Powerline Edition (XAVN2001)
Getting Started
6
Page 7
Universal WiFi Extender - Powerline Edition (XAVN2001)
LED and Feature Descriptions
Table 1. LED descriptions
Item Description
Power LED • Solid green. The electrical power is on.
• Blinking green. The device is in the process of setting up security.
• Amber. Power saving mode. If the Ethernet port is inactive for more than 10 minutes, the
device enters power saving mode. Power saving mode is disabled by default.
• Off. There is no electrical power or the LEDs have been turned off using NETGEAR genie.
Powerline LED • Solid. The device is connected to a Powerline network.
• Off. The device has not found any other compatible Powerline devices using the same
encryption key.
The Pick A Plug feature lets you pick the electrical outlet with the fastest link rate, indicated by
the color of the LED:
Green. Link rate > 80 Mbps
(Fast)
Wireless LED • Solid green. The wireless radio is on.
• Off. The wireless radio is off.
Ethernet LED • Solid green. The Powerline device is connected through the Ethernet port to a
powered-on Ethernet device.
• Off. There is no Ethernet connection.
Amber. Link rate > 50 and
< 80 Mbps (Medium)
Red. Link rate < 50 Mbps
(Slow)
Buttons
• Factory Reset. Use the Factory Reset button to return your Powerline device to its
factory default settings. Press the Factory Reset button for 2 seconds, and then release
it.
• Security. The Security button has the following three functions:
- Once the Powerline devices are active, you can use the Security button to secure
your Powerline network with a private encryption key. See
Set the Encryption Key on page 17.
- You can use the Security button to automatically create a wireless network on the
WiFi extender that has the same wireless settings as your wireless router or gateway.
Method B: Use WPS for Wireless Setup on page 15.
See
- The Security button provides an easy way (WPS) for your wireless computer or
device to join the WiFi extender wireless network. See
Network Using WPS on page 16.
Use the Security Button to
Method B: Join the Wireless
• On/Off. Use the On/Off switch to turn the device on and off.
Getting Started
7
Page 8
Universal WiFi Extender - Powerline Edition (XAVN2001)
Ethernet Port
The WiFi extender uses an Ethernet port to convert a standard electrical wall outlet into a
high-speed wired network connection. You can use the wired network connection to bring
Internet connectivity to any device with an Ethernet port, such as a computer, game console,
Blu-ray™ player, smart TV, HD set-top box, or network DVR.
Product Label
The product label is on the back of the device. The label shows unique details specific to your
device, including the following information.
• Model number
• Powerline MAC address
• Ethernet/wireless MAC address
• Serial number
• Device password
• WPS security PIN
• Default wireless network name (SSID)
• Default network key (wireless network password)
How the WiFi Extender Fits into Your Network
You can use one or more WiFi extenders to extend wireless and wired Internet access
throughout your home.
A Powerline network consists of two or more compatible Powerline devices that communicate
with each other using your electrical power lines. One of the Powerline devices is connected
with an Ethernet cable to your router so that the Powerline network is linked to your local area
network (LAN). Connecting one Powerline device to your router allows all the Powerline
devices on the Powerline network to communicate with the router and use its Internet
connection.
If your home network includes a wireless router or gateway, you can use the WiFi extender to
extend the coverage of your existing wireless network or to create a second wireless
network. If you have a wired router or gateway, the WiFi extender can use your wired Internet
connection to create a wireless network in your home.
Getting Started
8
Page 9
Universal WiFi Extender - Powerline Edition (XAVN2001)
Reset
Reset
Room 1
Room 2
Room 3
Powerline
Powerline
WiFi extender
The following illustration shows a Powerline network with one Powerline device in Room 1, a
second Powerline device in Room 2, and a WiFi extender (XAVN2001) in Room 3.
Figure 3. WiFi extender (XAVN2001) connected to a Powerline network and wireless network
To form a Powerline network, you need at least two compatible Powerline devices (including
the WiFi extender).
For best performance, plan the locatio
• Use
an electrical outlet that is not controlled by a wall switch to avoid accidentally turning
n of your Powerline devices.
off the power to the outlet.
• A
void plugging Powerline products into electrical outlets that are located near appliances
that consume a lot of power, such as washers, dryers, or refrigerators. Interference from
these appliances might prevent Powerline products from working correctly or reduce
Powerline network performance.
• Do not p
Connecting a Powerline product to one of these devices might prevent the product from
working correctly or reduce Powerline network performance.
lug Powerline products into a power strip, extension cord, or surge protector.
Getting Started
9
Page 10
Universal WiFi Extender - Powerline Edition (XAVN2001)
WiFi extender
Set Up the Powerline Network
You can set up a new Powerline network that includes the WiFi extender or you can add the
WiFi extender to an existing Powerline network.
Set Up a New Powerline Network
Different Powerline models can share the same Powerline network. All NETGEAR Powerline
AV products are compatible.
To set up a new Powerline network:
1. Make su
re that your wired Ethernet connections are
working. If you have an existing wireless network,
make sure that it is connected to the Internet.
First
Powerline
device
Reset
2. Plug the first
3. Plug the WiFi extend
4. (Opt
5. W
a. On
a computer that is connected to your router or
gateway using an Ethernet cable, open a web
browser and navigate to a web page.
b. On
a computer or device that is connected to your
wireless network, open a web browser and
navigate to a web page.
Powerline device (sold separately) into a
wall outlet near your router or gateway. Then, connect
the device to the LAN port on your router or gateway
using an Ethernet cable.
er into a wall outlet where you need
wireless coverage.
ional) You can use the provided Ethernet cable to
connect the WiFi extender to an Ethernet port on a computer,
game console, Blu-ray player, or other peripheral device.
The Powerline devices attempt to detect each other and
form a Powerline ne
twork.
ait for each Powerline device to be recognized by the
Powerline network. This process could take as little as 5
seconds or up to 80 seconds.
When the Power and Powerline LEDs stop blinking, the
process is comple
te. If the Powerline LEDs are green or
amber, the devices are successfully connected to the
Powerline network. A red Powerline LED indicates a slow
link rate. In this case, move the Powerline device to
another electrical outlet with a faster connection.
et up the WiFi extender wireless network as explained in Set Up the WiFi Extender
6. S
Wireless Network on
page 12.
Getting Started
10
Page 11
Universal WiFi Extender - Powerline Edition (XAVN2001)
WiFi extender
Add the WiFi Extender to an Existing Powerline Network
If you have an existing Powerline network, make sure one of the Powerline devices is
connected to your router or gateway so that the Powerline network is linked to your local area
network (LAN). Your existing Powerline network must have two or more compatible
Powerline devices that communicate with each other.
To add the WiFi extender to an existing Powerline network:
f you used the Security buttons or NETGEAR genie to secure your Powerline network,
1. I
press the Factory Reset button for 2 seconds on each Powerline device to return it to
its factory default settings.
This is the quickest way to allow your new WiFi extender to communicate with the other
Powerline devices.
2.
Plug the WiFi extender into a wall outlet where you need
wireless coverage.
3. (Optional)
connect the WiFi extender to an Ethernet port on a
computer, game console, Blu-ray player, or other peripheral
device.
You can use the provided Ethernet cable to
4. W
5. S
The Powerline devices attempt to detect each other and
orm a Powerline network.
f
ait for each Powerline device to be recognized by the
Powerline network. This process could take as little as 5
seconds or up to 80 seconds.
When the Power and Powerline LEDs stop blinking, the
p
rocess is complete. If the Powerline LEDs are green or
amber, the devices are successfully connected to the
Powerline network. A red Powerline LED indicates a slow
link rate. In this case, move the Powerline device to
another electrical outlet with a faster connection.
et up the WiFi extender wireless network as explained in Set Up the WiFi Extender
Wireless Network on p
age 12.
Getting Started
11
Page 12
Universal WiFi Extender - Powerline Edition (XAVN2001)
Set Up the WiFi Extender Wireless Network
You can use either NETGEAR genie or Wi-Fi Protected Setup (WPS) to setup the WiFi
extender (XAVN2001) wireless network.
your router does not have a WPS button or if you are not sure, use Method A.
• If
• If
your router has a WPS button, use Method B.
Method A: Use NETGEAR genie for Wireless Setup
To use NETGEAR genie to manually configure the wireless settings of your WiFi
extender:
1. On
2. T
3. Lau
4. Click Network M
a computer that has Internet access, download and install NETGEAR genie. See
Install NETGEAR genie on p
emporarily connect the computer to the Ethernet port on the WiFi extender using the
provided Ethernet cable.
nch NETGEAR genie in one of two ways:
• Click the NETGEAR ge
• Select S
tart > All Programs > NETGEAR genie.
ap or select it from the list of menu items on the left.
age 21.
nie shortcut icon on your desktop.
Getting Started
12
Page 13
Universal WiFi Extender - Powerline Edition (XAVN2001)
5. Click the Powerline icon on the Network Map screen. The Powerline Utility screen displays.
6. On the Powerline Utility screen, right-click the XAVN2001 icon.
7. On
the pop-up menu that displays, select Wireless configuration.
Getting Started
13
Page 14
Universal WiFi Extender - Powerline Edition (XAVN2001)
The following screen displays:
8. Enter the following wireless settings:
• Wireless Netw
• Wireless
ork Name (SSID)
Security Type
• Passphrase
If you want to clone your existing
wireless network, enter the same wireless settings that
your router or gateway uses.
If you want to create a new wireless n
9. Click Apply
10. Wh
en you are finished with the wireless settings, disconnect the Ethernet cable from the
to save your changes.
etwork, enter new wireless settings.
WiFi extender.
Note: To configure advanced wireless settings, see Access NETGEAR
Web genie on page 31.
Getting Started
14
Page 15
Universal WiFi Extender - Powerline Edition (XAVN2001)
Method B: Use WPS for Wireless Setup
If your wireless router or gateway has a WPS (Wi-Fi Protected Setup) button, you can use
this method for wireless setup. The WPS button might be labeled WPS or it could look similar
to
To use the WPS button on your wireless router or gateway to clone your existing
wireless network:
or .
1. Pre
ss and hold the Security button on the WiFi extender for about 10 seconds, and
then release it. The Wireless LED starts blinking.
2. Press the WPS but
ton on the wireless router or gateway.
When the Wireless LED stops blinking and lights solid green, the cloning is finalized.
You now have two wireless networks with the same settings (SSID and password). When
re roaming in your house, your wireless device (laptop, tablet, or smartphone)
you a
switches from one network (router or gateway) to the other (WiFi extender), depending
on the signal quality.
Getting Started
15
Page 16
Universal WiFi Extender - Powerline Edition (XAVN2001)
Join the WiFi Extender Wireless Network
You can connect your wireless devices (such as a laptop or game console) to your WiFi
extender wireless network in one of two ways.
your wireless computer or device does not have a WPS button or if you are not sure,
• If
use Method A.
• If
your wireless computer or device has a WPS button, use Method B.
Method A: Join the Wireless Network Manually
To join the wireless network manually:
1. On
2. Loo
3. Enter th
your wireless computer or device, launch the software that manages your wireless
network connections. The software scans for all wireless networks in your area.
k for the WiFi extender wireless network and select it. The default wireless network
name (SSID) is printed on the product label. If you changed this setting, look for the
network name that you used.
e network key (wireless network password). The default network key is printed on
the product label. If you changed this setting, enter the network key that you used.
Method B: Join the Wireless Network Using WPS
If your wireless computer or device has a WPS (Wi-Fi Protected Setup) button, you can use
this method to join the WiFi extender wireless network. The WPS button might be labeled
WPS or it could look similar to
To join the wireless network using WPS:
1. Press the WPS butto
2. Press and hold the Security but
LED starts blinking.
When the Wireless LED stops blinking and lights solid green, the wireless device is
securely connected to
n on your wireless computer or device.
the WiFi extender.
or .
ton for about 2 seconds, and then release it. The Wireless
Getting Started
16
Page 17
Universal WiFi Extender - Powerline Edition (XAVN2001)
Reset
Powerline Network Security
A Powerline network consists of two or more Powerline devices using the same network
encryption key. Securing your network is crucial. By encrypting the information that you send
over the Powerline network, you help to keep it secure from hackers. If you do not set up
security on your network, anyone nearby with a Powerline network can potentially use his or
her connection to gain access to your network and information that you send over the
Internet. This concern is especially relevant in settings such as apartment buildings, office
buildings, dorm rooms, and other more populated areas.
You can use either the Security button on the Powerline device or NETGEAR genie to secure
your Powerline
network.
• Use th
private encryption key. See Use the Security Button to Set the Encryption Key on
page 17.
• Use NETGEAR ge
that you specify. See Install NETGEAR genie on p
e Security button on the Powerline device to automatically generate a random
nie to configure your Powerline network with a private encryption key
age 21.
Use the Security Button to Set the Encryption Key
Note: A Powerline device can generate a random private encryption key
only once. If you want to generate a new random key, first reset the
Powerline devices to their factory default settings. Either press the
Factory Reset button for 2 seconds, then release it, or use the
NETGEAR genie factory reset feature. (See
Factory Default Settings on page 28.)
You can use the Security button to replace the default encryption key with a random private
ncryption key. The default encryption key is HomePlugAV.
e
To set the encryption key:
Reset a Device to
1. Make sure t
Verify that the Power and Powerline LEDs on each device are lit solid green.
hat all of the Powerline devices that you want to configure are plugged in.
Getting Started
17
Page 18
Universal WiFi Extender - Powerline Edition (XAVN2001)
CAUTION:
Reset
Reset
Do not press the Security button on the Powerline devices until the Power
and Powerline LEDs on each Powerline device are lit solid green. Pressing
the Security button too soon can temporarily disable Powerline
communication. If Powerline communication is disabled, reset the
Powerline device to its factory default settings. (Press the Factory Reset
button for 2 seconds, then release it).
2. Press the Security button on the first Powerline device for 2 seconds.
• Th
• Th
e Power LED starts blinking after you release the button.
e Powerline device automatically creates a new, randomly generated encryption
key that all other Powerline devices on the network will use.
At this point, the Powerline devices canno
3. Wit
hin 2 minutes of pressing the Security button on the first Powerline device, press the
t communicate with each other.
Security button on the second Powerline device for 2 seconds. You must press both
Security buttons within 2 minutes.
• Th
• Th
e Power LED starts blinking after you release the button.
is process allows the second Powerline device to use the same private encryption
key as the first device so that they can communicate.
When the Power LEDs stop blinking and the Powerline LEDs are lit solid green, the two
devices can communicate over the Powerline network in a secure way.
Getting Started
18
Page 19
Universal WiFi Extender - Powerline Edition (XAVN2001)
Note: This process works for only one pair of Powerline devices at a time.
If you have more than two Powerline devices, repeat this process for
each additional Powerline device to be configured.
The devices retain security settings even if they are unplugged.
Getting Started
19
Page 20
2. Using NETGEAR genie
This chapter explains how to install NETGEAR genie and use it to manage your Powerline
network. NETGEAR genie works with all Powerline devices.
You can use NETGEAR genie to manage a local Powerline device that is connected to your
computer with an Ethernet cable and also to manage other Powerline devices on the same
network.
This chapter includes:
• Install NETGEAR genie
• The Powerline Utility Screen
• View the Link Rate between Powerline Devices
• Change the Name of a Powerline Device
• Turn LEDs Off or On
• Set the Powerline Encryption Key
2
• Reset a Device to Factory Default Settings
• Add a Device to the Powerline Network
• Change the Wireless Settings
• Access NETGEAR Web genie
• Configure Advanced Wireless Settings
• Update the Firmware
20
Page 21
Universal WiFi Extender - Powerline Edition (XAVN2001)
Install NETGEAR genie
NETGEAR genie allows you to set a private encryption key for your Powerline network and
manage devices on your Powerline network.
You can manage the Powerline network using any computer that is connected to your
werline network, wirelessly or through an Ethernet cable. All devices on a Powerline
Po
network can be managed from one computer.
Note: If you already have NETGEAR genie installed on your computer,
you must reinstall the latest version to get support for Powerline
products.
NETGEAR genie is a free download available from the NETGEAR website.
To install NETGEAR genie on your computer:
1. L
aunch an Internet browser and visit http://support.netgear.com.
2. Click the For Home tab.
3. In the search box, type
4. Select NETGEA
5. Click the Do
6. Run the
Click Finish to complete the setup.
file that you downloaded and follow the setup prompts to install NETGEAR genie.
R genie from the downloads list.
wnload button to download NETGEAR genie to your computer.
xavn2001v2 and press Enter.
Using NETGEAR genie
21
Page 22
Universal WiFi Extender - Powerline Edition (XAVN2001)
The NETGEAR genie shortcut icon displays on your desktop.
7. Launch NETGEAR genie in one of two ways:
• Click the NETGEAR ge
nie shortcut icon on your desktop.
• Select S
tart > All Programs > NETGEAR genie.
The Powerline Utility Screen
The Powerline Utility screen is where you view and manage your Powerline network.
To navigate to the Powerline Utility screen:
1. On
2. From t
a computer that is connected to your Powerline network, launch NETGEAR genie.
he NETGEAR genie Home screen, click Network Map on the dashboard or select it
from the list of menu items on the left.
Using NETGEAR genie
22
Page 23
Universal WiFi Extender - Powerline Edition (XAVN2001)
Refresh
icon
Device
information
Powerline
icon
Security icon
Device
icon (XAVN2001)
3. On the Network Map screen, click the Powerline icon to view all the devices on your
Powerline network. The Powerline Utility screen displays.
• For management options, right-click the icon of the device that you want to manage.
• If all devices a
re not shown, click the Refresh icon to update the screen.
• Move your mo
use over an icon of a device to view more information about the device.
Security Icon
You can click the Security icon on the Powerline Utility screen to go to the Security
screen.
• If the Powerline devices are secured using the default encryption key, the
unlocked Security icon displays.
• If the
See Set the Powerline Encryption Key on p
Powerline devices are secured using a private encryption key, the locked
Security icon displays.
age 26 for more information about how to
set the encryption key for your Powerline devices.
Using NETGEAR genie
23
Page 24
Universal WiFi Extender - Powerline Edition (XAVN2001)
View the Link Rate between Powerline Devices
To view the link rate between your Powerline devices:
On the Powerline Utility screen, click the icon of the
A pop-up screen displays.
device whose link rate you want to view.
• Tx. The rate at which the device is transmitting data.
• Rx. Th
e rate at which the device is receiving data.
Using NETGEAR genie
24
Page 25
Universal WiFi Extender - Powerline Edition (XAVN2001)
Change the Name of a Powerline Device
Powerline devices are identified by their model number and name. NETGEAR genie detects
any Powerline devices that are connected to the Powerline network and displays them on the
Powerline Utility screen. If you did not name the device, no name appears below the model
number of the device.
To name a Powerline device on your Powerline network:
1. On the
2. On th
A pop-up screen displays advising you that connectivity will be temporarily lost while the
device is being renamed.
3. Click OK. The follo
Powerline Utility screen, right-click the icon of the device that you want to name.
e pop-up menu that displays, select Device Name.
wing screen displays:
4. Enter a new name for the Powerline device and click OK to save your changes.
Using NETGEAR genie
25
Page 26
Universal WiFi Extender - Powerline Edition (XAVN2001)
Turn LEDs Off or On
You can turn off or turn on the LEDs of any device on your Powerline network.
To turn the LEDs off or on:
1. On
2. On the pop-up menu that
3. Click OK.
4. Click OK.
the Powerline Utility screen, right-click the icon of the device.
displays, select either Turn LED off or Turn LED on.
A pop-up screen displays advising you that connectivity will be temporarily lost while the
LEDs are being reset.
A message displays indicating that the operation was successful.
Set the Powerline Encryption Key
Powerline devices on the same Powerline network use the same encryption key. The factory
default encryption key is HomePlugAV.
In locations such as apartment buildings or office b
electrical power lines that you use for your Powerline network. To protect your Powerline
network from unwanted access, you can use NETGEAR genie to set a private encryption key
for your Powerline devices. Make sure that all of your Powerline devices use the same
encryption key so that they can communicate with each other.
If you forget your private encryption key, you can reset the encryption key to the factory
lt key, HomePlugAV. See Reset a Device to Factory Default Settings on p
defau
Using NETGEAR genie
uildings, other people might use the same
age 28.
26
Page 27
Universal WiFi Extender - Powerline Edition (XAVN2001)
To set the encryption key:
1. On the Powerline Utility screen, right-click the icon of a Powerline device in your
network.
2. On th
e pop-up menu that displays, select Security. The Security screen displays.
The top section of the Security screen shows information about each device that
NETGEAR genie detects.
• Device Na
me. The list of Powerline devices that NETGEAR genie detects after
completing a device scan. The device name is listed as un-named by default, but you
can change it to a descriptive name, such as Office or Master Bedroom. (See Change
the Name of a Powerline Device on
• Mod
• MAC Addres
el. The model number of the Powerline device.
s. The MAC address of the Powerline device. This information is on the
page 25.)
product label, which might not be visible when the device is plugged in.
• Device Password. If your
computer is not connected locally (with an Ethernet cable)
to the device that you want to configure, you must enter the device password. The
device password is on the product label.
3. Select th
4. Select an encryp
• Cre
e check box next to each device that you want to configure.
tion key option for your Powerline devices:
ate a new Encryption Key. To set your own private encryption key, type the key
that you want to use in the field.
• Use defa
ult Encryption Key. When you select this option, the factory default
encryption key automatically displays in the field. The factory default encryption key is
HomePlugAV.
Using NETGEAR genie
27
Page 28
Universal WiFi Extender - Powerline Edition (XAVN2001)
Note: If your computer is not connected locally (with an Ethernet cable) to
the device that you want to configure, you must enter the device
password. The device password is printed on the product label on
the back of the device.
5. Click the Apply Security to Selected Devices button.
When the encryption key is set, a message displays indicat
successful.
6. Click OK.
ing that the operation was
Reset a Device to Factory Default Settings
This option resets the encryption key of a Powerline device to the factory default key,
HomePlugAV.
Note: If your Powerline network uses a private encryption key, resetting a
Powerline device to its factory default settings disconnects the
device from the network. To avoid disconnecting your computer from
the network, reset all other Powerline devices on the network before
you reset the device that is connected to your computer.
To reset a device to its factory default settings:
1. On
2. On the pop-up menu that
the Powerline Utility screen, right-click the icon of the device.
displays, select Factory Reset.
A pop-up screen displays advising you that connectivity will be temporarily lost while the
device is being reset.
3. Click OK.
4. Click OK
A message displays asking you to confirm the reset.
to reset the device. A message indicates whether the operation succeeded.
Using NETGEAR genie
28
Page 29
Universal WiFi Extender - Powerline Edition (XAVN2001)
Add a Device to the Powerline Network
If you are adding a device to your Powerline network and your network uses the default
encryption key, all you need to do is plug the new device into a power outlet.
If your Powerline network uses a private encryption key, there are two ways to set the
security:
ou can use the Security button to add the new device to your network. See Use the
• Y
Security Button to Set the Encryption Key on p
• Y
ou can use NETGEAR genie to add the new device to your network, as described in the
following procedure.
To add a Powerline device to the Powerline network using NETGEAR genie:
age 17.
1. Plug the Powerline d
2. Use the
computer.
3. Inst
4. Launch
The Powerline Utility Screen on p
5. On th
the new device.
provided Ethernet cable to connect the Powerline device to an Ethernet port on your
all NETGEAR genie on the computer. (See Install NETGEAR genie on page 21.)
NETGEAR genie on the computer and navigate to the Powerline Utility screen. (See
e Powerline Utility screen, click the Refresh icon. Wait for NETGEAR genie to detect
evice into a wall outlet near your computer for initial setup.
age 22.)
6. Right-click the icon of the device.
7. On th
8. Set the encryption key for the device. ( See Set the
9. On the
e pop-up menu that displays, select Security.
Powerline Encryption Key on p
same encryption key that your
Powerline Utility screen, click the Refresh icon.
Verify that all the devices on your Powerline network
appear on the screen. It might take a minute or two for
NETGEAR genie to detect all devices on the network.
age 26.) Be sure to enter the
other Powerline devices use.
Using NETGEAR genie
29
Page 30
Universal WiFi Extender - Powerline Edition (XAVN2001)
Change the Wireless Settings
You can use NETGEAR genie to view the current wireless settings or to change them.
To change the wireless settings for your XAVN2001 WiFi extender:
1. On
2. On the pop-up menu that
the Powerline Utility screen, right-click the XAVN2001 icon.
displays, select Wireless configuration.
The Wireless Setting screen displays:
3. Manually enter the wireless settings or automatically copy your router’s wireless settings.
• Option 1: Man
a. In the Wire
for the WiFi extender network (the network broadcast from the WiFi extender).
b. Select a se
c. Enter a p
d. Click Apply to
ually enter the wireless settings.
less Network Name (SSID) field, enter the name that you want to use
tting from the Wireless Security Type drop-down list.
assword (network key).
save your changes.
Using NETGEAR genie
30
Page 31
Universal WiFi Extender - Powerline Edition (XAVN2001)
• Option 2: Automatically copy your router’s wireless settings.
a. On the
The WiFi extender automatically detects and copie
your router or gateway uses.
b. Scroll down and click Apply
Wireless Setting screen, click the Search my NETGEAR Router button.
s the wireless settings that
to save your changes.
Access NETGEAR Web genie
You can use NETGEAR genie to manage basic settings on your Powerline devices. To
configure more advanced settings on individual Powerline devices, use NETGEAR web
genie.
To access the web genie for an individual Powerline device:
aunch NETGEAR genie from a computer that is
1. L
connected to your Powerline network.
2. On the Powerline Utility screen, right-click the icon of the
device that you want to configure.
3. On th
e pop-up menu that displays, select the IP address of
the device.
Note: You can also access the web genie by clicking the IP address at the
bottom of the Wireless Settings screen.
Your Internet browser launches and a login window displays:
4. Ente
r admin for the user name and password for the password, both in lowercase letters.
Using NETGEAR genie
31
Page 32
Universal WiFi Extender - Powerline Edition (XAVN2001)
Note: The web genie password is different from the device password and
network key printed on the product label.
The default web genie user name and password are admin a
nd
password. You can change the default password using the web
genie.
The web genie for the device displays in your browser window.
You can use the web genie to reboot the device, configure advanced wireless settings,
update your device firmware, and more.
Using NETGEAR genie
32
Page 33
Universal WiFi Extender - Powerline Edition (XAVN2001)
Configure Advanced Wireless Settings
You can use NETGEAR web genie to configure the advanced wireless settings of your WiFi
extender, including the wireless mode and channel.
To configure the advanced wireless settings of your WiFi extender:
1. L
og in to the web genie for your WiFi extender. See Access NETGEAR Web genie on
page 31.
2. From the menu on the
displays:
left, select Setup > Wireless Settings. The following screen
3. Change the settings for the wireless network that the WiFi extender broadcasts:
• Ena
• Name (SSID). Th
• Region. T
• Channel.
• Mod
4. In the Secu
WiFi extender wireless network to use.
• None. Th
• WP
• WP
5. Click App
ble SSID Broadcast. When this check box is selected, any wireless computer or
device can discover your wireless network name.
e wireless network name. You can type in a new name to customize
your WiFi extender network.
he country or region where the WiFi extender is located.
The wireless channel for the network.
e. The wireless mode.
rity Options section of the screen, select the type of security that you want the
is option disables wireless security and allows any wireless computer or
device to join your wireless network.
A2-PSK [AES]. WPA2 is the most secure option, but some older computers and
devices do not support this standard. In the field that displays, type the passphrase
(network key) that you want the WiFi extender wireless network to use.
A-PSK [TKIP] + WPA2-PSK [AES]. This option can be used with computers and
devices that support WPA or WPA2. In the field that displays, type the passphrase
(network key) that you want the WiFi extender wireless network to use.
ly to save your changes.
Using NETGEAR genie
33
Page 34
Universal WiFi Extender - Powerline Edition (XAVN2001)
Click
Check
WARNING!
Update the Firmware
You can use NETGEAR web genie to update the firmware on your WiFi extender.
To update your WiFi extender firmware:
1. Log in to the web
genie for your WiFi extender. See Access NETGEAR Web genie on
page 31.
2. From
the menu on the left, select Maintenance > Firmware Update.
The following screen displays:
3. Click the Check button.
If new firmware is available, the web genie finds it.
the pop-up screen that displays, click Yes and follow the prompts to upload the new
4. In
firmware to the WiFi extender.
When uploading firmware to the WiFi extender, do not interrupt
the web browser by closing the window, clicking a link, or loading
a new page. If the browser is interrupted, it could corrupt the
firmware.
When the upload is complete, your WiFi extender restarts. The firmware update process
typically takes about 1 minute. Read the firmware release notes to determine whether you
need to reconfigure the WiFi extender after updating the firmware. You can find the firmware
release notes by searching for your product at http://support.netgear.com.
Using NETGEAR genie
34
Page 35
3. Troubleshooting
This chapter provides information to help you diagnose and solve problems that you might
encounter. If you do not find the solution here, check the NETGEAR support site at
http://support.netgear.com for product and contact information.
This chapter includes:
• Basic Functioning
• Troubleshooting Tips
• If You Do Not See All Your Devices with the NETGEAR genie
• If You Do Not See the Powerline Icon on Your Network Map
3
35
Page 36
Universal WiFi Extender - Powerline Edition (XAVN2001)
Basic Functioning
After you plug in the Powerline device, the following sequence of events should occur:
1. The Power LED lights.
2. After approximately 10 seconds, verify the following:
• The Power LED is solid green. The device is powered on.
• If the device is connected to a Powerline network, the Powerline LED is lit.
• If the Powerline device is connected through the Ethernet port to a powered-on
Ethernet device, the Ethernet LED is lit.
Troubleshooting Tips
The Factory Reset and Security buttons are on the side panel of the Powerline device.
• Pressing the Factory Reset button longer than 2 seconds does not reset the device.
• Pressing the Security button longer than 2 seconds does not activate security.
LEDs
The LEDs indicate activity and can be used for troubleshooting.
LEDs Are Off When the Powerline Device Is Plugged In
• Make sure that power is supplied to the electrical outlet.
• If power is supplied and the LEDs stay off, someone might have used NETGEAR
genie to turn off the LEDs. Use NETGEAR genie to check whether the LEDs are
turned off. If they are, then use the genie to turn them back on. See
On on page 26.
Power LED
• Off. There is no electrical power.
- Make sure that power is supplied to the electrical outlet and the Powerline device is
not plugged into an extension cord, power strip, or surge protector.
- Press the Factory Reset button on the Powerline device for 2 seconds to return the
device to its factory default settings.
• Amber. Power saving mode occurs when the Ethernet link is inactive. The Ethernet link is
inactive when:
- The Ethernet cable is unplugged.
Turn LEDs Off or
- The peripheral device that is connected through the Ethernet port is turned off.
- The Powerline device is idle for 10 minutes.
Troubleshooting
36
Page 37
Universal WiFi Extender - Powerline Edition (XAVN2001)
The Powerline device returns to normal mode within 2 seconds once the Ethernet link is
active. Power saving mode is disabled by default. To enable power saving mode, use
NETGEAR web genie. (See
Access NETGEAR Web genie on page 31.)
Powerline LED
• Off. The Powerline devices cannot find each other. Make sure that the Powerline devices
are plugged into wall outlets with power and that they use the same network encryption
key.
- Move the Powerline device to an outlet that is closer to the computer or devices.
- If you set a private encryption key, make sure that all Powerline devices are using the
same encryption key.
- If the problem occurred after you set the encryption key, reset each device to its
factory default settings. Then try setting the encryption key again.
• Amber or red. Move the Powerline device to another electrical outlet with a faster
connection.
Ethernet LED Is Off
There is no Ethernet connection.
• If your Powerline device is connected to the LAN port of your router, make sure that:
- Your router and modem are turned on.
- The computer connected directly to the router can access the Internet.
• If your Powerline device is connected to a computer, game console, Blu-ray player, or
other peripheral device, make sure that:
- The peripheral device is turned on.
- The Powerline device is securely connected to the peripheral device using an
Ethernet cable.
• Press the Factory Reset button on each Powerline device for 2 seconds to return the
device to its factory default settings.
Wireless LED Is Off
If the Wireless LED stays off, use NETGEAR web genie to turn on the wireless radio. The
Wireless LED is lit when the wireless radio is turned on.
To turn on the wireless radio:
1. Log in to the web genie for your WiFi extender. See Access NETGEAR Web genie on
page 31.
2. From the menu on the left, select Advanced > Wireless Settings.
3. On the screen that displays, select the Enable Wireless Device Radio check box.
4. Click Apply to save your changes.
Troubleshooting
37
Page 38
Universal WiFi Extender - Powerline Edition (XAVN2001)
If You Do Not See All Your Devices with the NETGEAR genie
If you click the Refresh icon on the NETGEAR genie Powerline Utility screen and you do not
see all the devices that you expect, some Powerline devices might be using different
encryption keys. If the encryption keys are different, do one of the following:
• Reset your Powerline devices to their factory default settings. Then set the encryption key
for all of your Powerline devices.
• Connect your computer to one Powerline device at a time and use NETGEAR genie to
set the encryption key for each device.
If You Do Not See the Powerline Icon on Your Network Map
If you navigate to the Network Map on NETGEAR genie and you do not see the Powerline
icon:
• Make sure that you have the latest version of NETGEAR genie installed. Some older
versions of NETGEAR genie might not support Powerline products.
• Your computer’s antivirus software might be blocking the Powerline communication
protocol. Temporarily disable your antivirus software and relaunch NETGEAR genie.
Symantec Endpoint Protection
The antivirus software Symantec Endpoint Protection v11.0.5002.333 filters the NETGEAR
Powerline network traffic and prevents Powerline devices from appearing on the Network
Map. To allow Powerline network traffic to pass through the Symantec Endpoint Protection
filter, you must add a firewall rule to the filter.
Note: Symantec Endpoint Protection v12.0.1001.95 does not have this
issue.
To add a firewall rule for your Powerline devices:
1. Open the Symantec Control Center and click the Options button under Network Threat
Protection.
Troubleshooting
38
Page 39
Universal WiFi Extender - Powerline Edition (XAVN2001)
2. Select Configure Firewall Rules from the menu.
The following screen displays:
3. Click Add to add a firewall rule.
Troubleshooting
39
Page 40
Universal WiFi Extender - Powerline Edition (XAVN2001)
The following screen displays:
4. In the General tab, do the following:
a. In the
Rule name field, type a name for the firewall rule.
b. Select the Allow this traffic ra
c. Config
ure the firewall settings as shown or as you prefer.
dio button.
Troubleshooting
40
Page 41
Universal WiFi Extender - Powerline Edition (XAVN2001)
5. Click the Ports and Protocols tab.
The following screen displays:
a. From the Protocol drop-down menu, select Ethernet.
b. I
n the Ethernet type field, type 0x88E1.
c. Click OK to create the
firewall rule for your Powerline devices.
The rule appears in the firewall rule list.
6. Make sure that the check box next to the rule is selected and click OK.
7. Rest
art the computer and launch NETGEAR genie. The Powerline icon should now display
on the Network Map screen.
Troubleshooting
41
Page 42
A. Supplemental Information
This appendix provides technical specifications and safety information for the WiFi extender.
This appendix includes the following sections:
• Technical Specifications
• Safety Information
A
42
Page 43
Universal WiFi Extender - Powerline Edition (XAVN2001)
Technical Specifications
Feature Specification
Data and routing protocols IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-Tx)
AC input 100–240V, 0.2A (max.)
Power consumption Normal: 4W, Power saving mode: 2W
Dimensions 86 x 67 x 40 mm (3.38 x 2.63 x 1.57 in.)
Weight 0.168 kg (0.37 lb)
Operating temperature 0 to 40C (32º to 104ºF)
Operating humidity 10–90% maximum relative humidity, noncondensing
Storage humidity 5–95% maximum relative humidity, noncondensing
Security encryption type 128-bit AES
MAC addresses 8 (active) / 16 (total): number of nodes that can be added to a
single network
Bandwidth 200 Mbps
Compatibility Not HomePlug v1.0 or HomePlug v1.0 Turbo compatible
Data transfer rate Up to 200 Mbps with real throughput greater than 80 Mbps
Frequency band 2–75 Mbps
Modulation type OFDM symbol modulation
Electromagnetic emissions FCC Part 15 Class B; CE-EMC Class B; 3-home FCC Certificate
Safety agency approvals UL Listed (UL 1950) /cUL IEC950; CE LVD; TUV CB, TUV CG
Wireless Wireless communication Enabled
Wireless network name
(SSID)
Security See product label.
Transmission speed Auto
Country/Region United States (varies by region)
Operating mode 802.11n, 802.11g, 802.11b
Data rate Up to 300 Mbps
a. Maximum wireless signal rate (IEEE Standard 802.11). Actual throughput will vary. Network conditions
and environmental factors, including volume of network traffic, building materials and construction, and
network overhead, lower actual data throughput rate.
See product label.
a
Supplemental Information
43
Page 44
Universal WiFi Extender - Powerline Edition (XAVN2001)
Safety Information
Follow these safety guidelines to ensure your own personal safety and to help protect your
system from potential damage.
• AC input: 100–240V, 0.25A (max.)
• Operating temperature: 0–40 degrees C.
• Maximum wireless signal rate derived from IEEE Standard 802.11 specifications.
• Actual data throughput will vary. Network conditions and environmental factors, including
volume of network traffic, building materials and construction, and network overhead,
lower actual data throughput rate.
• Do not service any product except as explained in your system documentation.
• Opening or removing covers that are marked with the triangular symbol with a lightning
bolt can expose you to electrical shock. Only a trained service technician should service
components inside these compartments.
• Use the product only with approved equipment.
• Allow the product to cool before removing covers or touching internal components.
• To help avoid damaging your system, be sure that the voltage selection switch (if
provided) on the power supply is set to match the power available at your location:
- 110 volts (V), 60 hertz (Hz) in most of North and South America and some Far
Eastern countries such as South Korea and Taiwan
- 100V, 50 Hz in eastern Japan and 100V, 60 Hz in western Japan
- 230V, 50 Hz in most of Europe, the Middle East, and the Far East
• The peripheral power cables are equipped with three-prong plugs to help ensure proper
grounding. Do not use adapter plugs or remove the grounding prong from a cable.
• Observe extension cable and power strip ratings. Make sure that the total ampere rating
of all products plugged into the extension cable or power strip does not exceed 80
percent of the ampere ratings limit for the extension cable or power strip.
• To help protect your system from sudden, transient increases and decreases in electrical
power, use a surge suppressor, line conditioner, or uninterruptible power supply (UPS).
• For additional safety instructions, see Appendix B, Notification of Compliance.
Supplemental Information
44
Page 45
B. Notification of Compliance
WARNING!
NETGEAR Wireless Powerline Products
Safety Instructions and Precautions
Use the following safety guidelines to ensure your own personal
safety and to help protect your product from potential damage. To
reduce the risk of bodily injury, electrical shock, fire, and damage
to the equipment, observe the following precautions.
• The socket-outlet shall be installed near the equipment and shall be easily accessible.
• Observe and follow service markings.
• If any of the following conditions occur, unplug the product from the electrical outlet and
replace the part or contact your service provider/retailer:
- The power cable, extension cable, or plug is damaged.
- An object has fallen into the product.
- The product has been exposed to water.
- The product has been dropped or damaged.
B
- The product does not operate correctly when you follow the operating instructions.
• Keep your system away from radiators and heat sources. Also, do not block cooling
vents.
• Do not spill food or liquids on your system components, and never operate the product in
a wet environment.
• Do not push any objects into the openings of your system. Doing so can cause fire or
electric shock by shorting out interior components.
• Operate the product only from the type of external power source indicated on the
electrical ratings label.
• Be sure that attached devices are electrically rated to operate with the power available in
your location.
• Use only approved power cables. If you have not been provided with a power cable for
your system or for any AC-powered option intended for your system, purchase a power
cable that is approved for use in your country. The power cable must be rated for the
product and for the voltage and current marked on the product’s electrical ratings label.
45
Page 46
Universal WiFi Extender - Powerline Edition (XAVN2001)
The voltage and current rating of the cable should be greater than the ratings marked on
the product.
• T
o help prevent electric shock, plug the system and peripheral power cables into properly
grounded electrical outlets.
• Do not use adapt
er plugs. If you must use an extension cable, use a three-wire cable with
properly grounded plugs.
• Ob
serve extension cable and power strip ratings. Make sure that the total ampere rating
of all products plugged into the extension cable or power strip does not exceed 80
percent of the ampere ratings limit for the extension cable or power strip.
• T
o help protect your system from sudden, transient increases and decreases in electrical
power, use a surge suppressor, line conditioner, or uninterruptible power supply (UPS).
• Position
system cables and power cables carefully; route cables so that they cannot be
stepped on or tripped over. Be sure that nothing rests on any cables.
• Do not modify po
• Always follow your lo
wer cables or plugs.
cal and national wiring rules.
Regulatory Compliance Information
Europe – EU Declaration of Conformity
Products bearing the
• EMC Directive 200
• Low V
oltage Directive 2006/95/EC
If this product has telecommunications f
marking comply with the following EU directives:
4/108/EC
unctionality, it also complies with the requirements of
the following EU Directive:
• R&T
Compliance with these directives implies conformity to ha
TE Directive 1999/5/EC
rmonized European standards that
are noted in the EU Declaration of Conformity.
Intended for indoor use only in all EU member states, EFTA states, and Switzerland.
This device may not be used for setting up outdoor radio links in France and in some areas
the RF output
power may be limited to 10 mW EIRP in the frequency range of 2454 - 2483.5
MHz. For detailed information the end-user should contact the national spectrum authority in
France.
FCC Requirements for Operation in the United States
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Notification of Compliance
46
Page 47
Universal WiFi Extender - Powerline Edition (XAVN2001)
FCC Declaration Of Conformity
We, NETGEAR, Inc., 350 East Plumeria Drive, San Jose, CA 95134, declare under our sole
responsibility that the Universal WiFi Extender - Powerline Edition (XAVN2001) complies with
Part 15 of FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that may cause
undesired operation.
FCC Radio Frequency Interference Warnings & Instructions
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following methods:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an electrical outlet on a circuit different from that which the
radio receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modifications made to the product, unless expressly approved by NETGEAR, Inc., could void
the user's right to operate the equipment.
Canadian Department of Communications Radio Interference Regulations
This digital apparatus (Universal WiFi Extender - Powerline Edition (XAVN2001)) does not exceed the Class B limits
for radio-noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian
Department of Communications.
This Class [B] digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada
Industry Canada
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
IMPORTANT NOTE: Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator & your body.
Caution:
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence.
Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage
Notification of Compliance
47
Page 48
Universal WiFi Extender - Powerline Edition (XAVN2001)
préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un
fonctionnement indésirable.
NOTE IMPORTANTE: Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non
contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de
rayonnement et votre corps.
Notification of Compliance
48
Page 49
Index
A
AC Input 43
adding
firewall rule 38
Powerline device to network 11, 29
advanced wireless settings 33
B
bandwidth 43
basic functioning 36
buttons
described 7
troubleshooting 36
C
changing names of Powerline devices 25
compatibility 43
compliance 45
configuring wireless settings 30, 33
D
data transfer rate 43
default factory settings 28
dimensions 43
firewall rule, adding 38
firmware, updating 34
frequency band 43
G
genie, NETGEAR 21
genie, web 31
H
hardware 6
humidity, operating and storage 43
I
icons
Powerline utility 23
WPS 15
L
label 8
LEDs
descriptions 7
troubleshooting 36
turning on and off 26
link rate 24
E
electromagnetic emissions 43
encryption keys
default and private 17
setting 26
Ethernet LED
described 7
troubleshooting 37
Ethernet port 8
F
Factory Reset button
described 7
troubleshooting 36
M
MAC addresses
product label 8
specification 43
mode, wireless 33
model number 8
modulation type 43
N
name, changing for Powerline devices 25
NETGEAR genie 21
NETGEAR web genie 31
network key, default 8
49
Page 50
Universal WiFi Extender - Powerline Edition (XAVN2001)
networks
Powerline 8
wireless 12
O
On/Off switch 7
P
package contents 6
password
device 8
NETGEAR web genie 31
Pick A Plug feature 7
power consumption 43
Power LED
described 7
troubleshooting 36
Powerline LED
described 7
troubleshooting 37
Powerline networks
described 8
setting up 10
Powerline Utility 22
private encryption key 17
product label 8
R
reset button 7
resetting to factory settings 28
router settings, search for using NETGEAR genie 31
technical support 2
temperature, operating 43
trademarks 2
troubleshooting 35
LEDs 36
NETGEAR genie 38
Powerline icon 38
Symantec firewall 38
U
updating firmware 34
W
web genie 31
weight 43
Wi-Fi Protected Setup (WPS) 15
Wireless LED
described 7
troubleshooting 37
wireless mode 33
wireless network name (SSID) 8, 33
wireless networks
joining 16
setting up 12
wireless security 33
wireless settings 30, 33
wireless specifications 43
WPS security PIN 8
S
safety agency approvals 43
safety information 44
security
Powerline encryption 17
wireless 33
Security button 17
described 7
troubleshooting 36
security encryption types 43
security PIN, WPS 8
serial number 8
SSID 8, 33
T
technical specifications 42, 43
50
Loading...
