Data Sheet | RN2120, RR2304, RN3138
ReadyNAS® 2120/2304/3138
Network Attached Storage (NAS)
High Performance Rackmount Storage for Small Businesses
Data is one of the most valuable assets in any business. The sharing, storing, archiving and disaster recovery of data are critical elements in an IT infrastructure. In addition to these universal IT requirements, for a small and medium size business, scalability, ease-of-use and cost effectiveness are essential measurements in selecting the right storage solution.
The 2000 and 3000 series Rackmount ReadyNAS offer the ideal solution to a small and medium size business (SMB)
that requires le serving and data
backup to support workgroups of up to 40 employees. The ReadyNAS 2000 and 3000 class products run the same ReadyNAS OS and apps, while the 3000 class products offer higher performance and faster data throughput.
All ReadyNAS support the entire suite of features in ReadyNAS OS, including 5 levels of data protection, ReadyDR disaster recovery, and virtualized storage for VMware and other virtualized networks.
These Rackmount NAS models also come with the latest ReadyNAS OS 6.7 software
for ultimate security and reliability. New features include Cloud backup to Amazon S3 (AWS) on top of Google Drive, Dropbox and Egnyte content management, 3D
conguration tool, future-proof and safer
Linux 4.4, unique desktop RAID 50 and 60 for more reliable storage, and many more business features that enables the ultimate business features in ReadyNAS.
Yield the benets of the latest industrial
and software design from NETGEAR with ReadyNAS storage.
All Inclusive Solution for Data Sharing, Storing & Securing
• File Sharing: Unied storage platform for sharing les between Windows, Mac and Linux-based
computers
Hard Drive Redundancy: RAID redundancy with automatic expansion and unlimited data snapshots for point-in-time restore.
Backup & Recovery: ReadyDR disaster recovery solution based on block level replication technology
App Managed: Easily manage your ReadyNAS from the palm of your hand with NETGEAR Insight app
Cloud Collaboration: Share selected folders and les with ReadyCLOUD with partners, clients or
internal teams
Key Business Features
•AutomaticBackup&Sync:Using the ReadyCLOUD app for PC, scheduled protec tion is easier than ever before
•BitRotProtection:A proprietary technology
protec ting your les from unplanned degradation
•UnlimitedSnapshots: Unlimited data snapshot
capability for on-box protection and exible data
recovery
•X-RAID&InstantProvisioning: Easily expand
capacity and feel condent knowing that data is
always protected
Virtualization: Thin provisioning, iSCSI support and certied with VMware
•Cloud-managedReplication:Maintain data sets in multiple locations or ensure protection of data
from remote or branch ofce locations
•iSCSIandThinProvisioning: Powerful tools for a business taking advantage of virtual infrastructures
•Anti-virus&Encryption: Keep data protected from outside threats and safe from prying eyes
•ModernGUIandCloud/RemoteAccessfrom Anywhere:Sleek modern inter face and patented
technology for secure remote access without
conguration effort
PAGE 1 of 9
Data Sheet | RN2120, RR2304, RN3138
ReadyNAS® 2120/2304/3138
Network Attached Storage (NAS)
ReadyNAS Desktop Model Comparison - 210 Series
Hardware ReadyNAS2120v2 ReadyNAS2304 ReadyNAS3138
CPU
Memory 2GB 2GB 4GB ECC UDIMM
Drive Bays 4 4 4
Drive Types Supported SATA/SDD 2.5” or 3.5” SATA/SDD 2.5” or 3.5” SATA/SSD 2.5” or 3.5”
Hot Swappable Drives Yes Yes Yes
Max Raw Internal Capacity (Based on 10TB drives)
eSATA Ports 2 0 2
Gigabit LAN Ports 2 2 4
USB Ports 1 x USB 2.0, 2 x USB 3.0 3 x USB 3.0 1 x USB 2.0, 2 x USB 3.0
Display Port (4k) 0 1 0
Power Supply
Fan (mm) 3 x 40 3 x 40 3 x 40
Dimensions DxWxH (mm) Without rackmount brackets With rackmount brackets
Weight (kg) 4.19 4.19 5.21
Chassis Warranty
SoftwareandFunctionality ReadyNAS2120v2 ReadyNAS2304 ReadyNAS3138
Certication and Compatibility VMware vSphere ESXi 6.0
Cloud-discovery, Setup and Management
Data Protection with Unlimited Snapshots
Web-managed Replication for Disaster Recovery
Real-time Antivirus Yes Yes Yes
iSCSI and Thin Provisioning Yes Yes Yes
ReadyDR No Ye s Ye s
Insight App Management No Ye s Ye s
Marvell® Armada XP Dual
Core 1.6GHz
(Based on 8TB drives)
32TB
Internal 180W:
input 100-240V AC,
50/60Hz
308 x 430 x 44 308 x 430 x 44
5 years with NBD
HW Replacement
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Intel Celeron Dual Core
2.0GHz
40TB 40TB
Internal 180W:
input 100-240V AC,
50/60Hz
308 x 485 x 44
5 years with NBD
HW Replacement
Intel Atom Quad Core 2.4GHz
with QuickAssist
Internal 180W:
input 100-240V AC,
50/60Hz
406 x 430 x 44 406 x 486 x 44
5 years with NBD
HW Replacement
PAGE 2 of 9
ReadyNAS Solutions
Apple Time Machine
FileSharing
These days, running a successful business often depends
on successful le sharing—application data, virtual images, client les, email, all the digital les that make your business go. With ReadyNAS, you nally have an advanced and easy-
to-use solution for centralizing, securing, and sharing those critical assets. Faster processors mean more simultaneous
users can access unied storage—across PC, Mac and Linux
environments. ReadyCLOUD and full Dropbox integration
make it easier than ever to sync your important les, photos or
videos across all of your web-connec ted devices.
Windows (CIFS/SMB)
Linux (NFS)
Mac (AFP)
Server (iSCSI)
Data Sheet | RN2120, RR2304, RN3138
ReadyNAS® 2120/2304/3138
Network Attached Storage (NAS)
Mac
ReadyNAS
PC
ReadyCloud ReadyNAS Remote FTP webDAV
iOS
Android
Snapshots
Windows Linux Mac
ReadyNAS
RAID
DisasterRecovery
The custom-built ReadyNAS OS protects stored data with
automatic RAID conguration, the continuous security of
Unlimited Snapshots, and easy-to-manage Cloud Replication. By maintaining multiple copies of vital data through cloud replication, it makes it easy for you to move data offsite to protec t against natural disasters and theft.
Hypervisor
VM
Backup
Unlimited snapshots give you complete control over the past, present, and future of your data. This enterprise-class feature
copies any point of time in the le system, can be manually or
automatically scheduled, and can restore any version with a simple click. Other data protection innovations for disk-based storage like Real Time Anti-Virus and Encryption bring new
condence to the integrity of your data and back-ups.
ReadyNAS Vault
ReadyNAS Replicate
Cloud-based Management
Central Oce
Remote Oce 1
Remote Oce 3
Remote Oce 2
Remote Oce 4
ReadyNAS
iSCSI LUN 1 iSCSI LUN 2
NFS 1
NFS 2
Virtualization
With Unlimited Snapshots, thin provisioning, and improved iSCSI suppor t, ReadyNAS delivers a virtualization platform with next­generation features at an affordable price.
PAGE 3 of 9
Technical Specications
DataProtection(Backup&Replication)
Unlimited block-based snapshots for continuous data protection
Restore Snapshots to any point in time
Restore Snapshot data from local admin GUI, ReadyCLOUD, or native Windows File Explorer
Scheduled and manual snapshots
File Synchronization (rsync)
Encrypted Remote Replication
Cloud managed Remote Replication (ReadyNAS to ReadyNAS). No licenses required for ReadyNAS OS 6 devices.
AES 256-bit volume based encryption
X-RAID2 (automatic single volume online expansion)
Single Disk, JBOD
RAID Levels: 0, 1, 5, 6, 10 (RAID level support depends on number of drives/bays)
RAID Global Hot Spare
eSATA Expansion
Backup to external storage (USB/eSATA)
Apple Time Machine support
Remote Apple Time Machine backup and restore (over ReadyNAS Remote)
ReadyNAS Vault™ Cloud backup (optional service)
Dropbox™ le synchronization (requires Dropbox account)
Real-time Anti-Virus scanning using signature and heuristic algorithms. (No end-user licenses required) Protection for viruses, malware, worms, and Trojans.
Bitrot automatic detection & correction for degraded media
StorageAreaNetworks(SAN),Virtualization
Unlimited iSCSI LUN Snapshot
Thin or thick provision LUNs
Multi-LUN per target
LUN mapping
LUN masking
SPC-3 Persistent Reservation (iSCSI)
MPIO (iSCSI)
MC/S (iSCSI)
Max # iSCSI Target: 256
Max # iSCSI LUN: 256
VMware ESXi 6.0 certied
Citrix XenServer 6
Windows Server 2008 Hyper-V
Actual SKU availability may vary per region. Please check the local website for product availability.
Windows Server 2008 Failover Clustering
Windows Server 2012 R2
Data Sheet | RN2120, RR2304, RN3138
ReadyNAS® 2120/2304/3138
Network Attached Storage (NAS)
PAGE 4 of 9
ReadyCLOUD(cloudaccesstoReadyNAS)
ReadyCLOUD portal based data access and management
VPN quality remote data transfer and management
Share data with friends & co-workers directly from portal
Share le via email link
ReadyCLOUDClientApplications
ReadyCLOUD client applications for Apple OS X, Microsoft Windows, Android, and Apple iOS
VPN quality remote data transfer and management
Simple remote access through ReadyCLOUD client (no rewall or router conguration needed)
Sync les/folders between PC (Mac/Windows) & ReadyNAS
Sync les/folders between multiple PCs and ReadyNAS
Sync les/folders between multiple users and ReadyNAS
Backup les/folders from PC to ReadyNAS
FileSystem&TransferProtocols
ReadyNAS OS 6.7 or later
Linux 4.x
Internal File System: BTRFS
External File System: EXT3, EXT4, NTFS, FAT32, HFS+
Copy-on-write le system
Microsoft Network (CIFS/SMB)
Apple OS X (AFP 3.3)
Linux/Unix (NFS v3)
Internet (HTTP)
Secure Internet (HTTPS)
File Transfer Protocol (FTP)
FTP over SSL / TLS (explicit)
FTP Passive mode with port range setup
FTP Bandwidth control
FTP Anonymous
FTP Transfer Log
Secure Shell (SSH)
Web Authoring (WebDAV)
Storage Array Network (iSCSI)
File Synchronization (rsync)
Local web le manager
Users/Groups
Max # Users: 8192
Max # User Groups: 8192
Max # Share Folder: 1024
Data Sheet | RN2120, RR2304, RN3138
ReadyNAS® 2120/2304/3138
Network Attached Storage (NAS)
PAGE 5 of 9
Users/Groups
Max # Concurrent Connections: 1024
Share Folder Level ACL Support
Advanced Folder Permissions with Subfolder ACL support for CIFS/SMB, AFP, FTP
Microsoft Active Directory (AD) Domain Controller Authentication
Local access list
ReadyCLOUD based ACL
Domain user login via CIFS/SMB, AFP, FTP
Management
ReadyCLOUD cloud based discovery and management
RAIDar local discovery agent share quota (Windows/Mac)
Save and restore system conguration (clone devices)
Local event log
Connection reporting (SMB)
Local Graphical User Interface (GUI) Languages: English, German, French, Japanese, Chinese, Russian, Swedish, Portuguese, Italian, Spanish, Polish, Czech, Dutch, Korean
Genie+ marketplace integration to add productivity, media, backup, surveillance and other applications
Unicode support
Volume Management
Thin provision Shares and LUNs
Instant Provisioning/Expansion with data protection
Restore to factory default
Operating Systems supported: Microsoft Windows 7, 8/8.1, 10, Microsoft Windows Server 2008 R2/2012, Apple OS X, Linux/Unix, Solaris, Apple iOS, Google Android
Supported Web Browsers (Microsoft Internet Explorer 9+, Mozilla Firefox 14+, Google Chrome 20+, Apple Safari 5+)
SystemMonitoring
Device capacity, performance, resource and health monitoring
Bad block scan
Hard Drive S.M.A.R.T.
File System Check
Disk Scrubbing
Disk Defragment
Volume balance
Alerts (SMTP email, LCD, SNMP, local log)
Auto-shutdown (hard drive, fan, UPS)
Auto-restart on power recovery
NetworkingProtocols
TCP/IP
IPv4
Next-generation Internet Protocol (IPv6)
Static IP Address
Dynamic IP Address
Data Sheet | RN2120, RR2304, RN3138
ReadyNAS® 2120/2304/3138
Network Attached Storage (NAS)
PAGE 6 of 9
NetworkingProtocols
Multiple IP Settings
DHCP Client
UPnP Discovery
Bonjour Discovery
Link Aggregation IEEE 802.3ad
Port Trunking (balanced round robin, active backup, balance xor, broadcast, 802.3ad link aggregation LACP, transmit load balancing, adaptive load balancing)
Hash Types IEEE 802.3ad LACP or XOR (Layer 2, Layer3, Layer 4)
Jumbo Frames
Static routes
Secure Shell (SSH)
Simple Network Management Protocol v2, v3
Network Time Protocol (NTP)
Media
ReadyDLNA (UPnP DLNA Media Server)
ReadyDLNA streams to any compliant device including Playstation and Xbox
ReadyDLNA mobile clients for remote media streaming (iOS, Android)
ReadyDLNA supported music formats (wav, wma, pcm, ogg, mp3, m4a, ac, aac)
ReadyDLNA supported photo formats (jpg, jpeg)
ReadyDLNA supported video formats (3gp, mp4, wmv, xvid, vob, ts, tivo, mts, mpeg, mpg, mp4, mov, mkv, m4v,
m4p, m2t, m2ts, v, c, a, divx, avi, asf)
ReadyDLNA supported playlist formats (pls, m3u)
ReadyNAS Surveillance supports up to 8 cameras (RN2120), 16 HD cameras (RR2304 and RN3138)
iTunes Server
iTunes supported audio formats (mp3, m4a, m4p, wav, aif)
iTunes supported video formats (m4v, mov, mp4)
iTunes supported playlist formats (m3u, wpl)
TiVo Archiving
Plex Media Server streams to DLNA and Plex clients (mobile, desktop, Google TV, Roku, Samsung & LG TVs)
Hardware
Intel Celeron Dual Core 2.0GHz (RR2304)
Intel Atom Quad Core 2.4GHz with QuckAssist (RN3138)
Memory: 2GB DDR3L (RR2304), 4GB ECC UDIMM (RN3138)
Floating Point CPU
Flash: 128MB for OS
Drive Bays: 4
Drive Types Supported: SATA/SSD 2.5” or 3.5”
Hot Swappable Drives
Two eSATA ports
Data Sheet | RN2120, RR2304, RN3138
ReadyNAS® 2120/2304/3138
Network Attached Storage (NAS)
PAGE 7 of 9
Hardware
Compliance
Environment
Data Sheet | RN2120, RR2304, RN3138
Network Attached Storage (NAS)
One USB 2.0 & Two USB 3.0 ports (RN3138)
Total solution capacity: 40TB
2xGigabit Ethernet ports with link aggregation and failover (RR2304)
4xGigabit Ethernet ports with link aggregation and failover (RN3138)
LEDs: Power, Activity, Disk, Backup, LAN
Integrated rackmount ears
Three 40mm fans
Dimensions (DxWxH): 308mm x 430mm x 44mm (RR2304) 406mm x 486mm x 44mm (RN3138)
Weight:
4.19 (RR2304)
5.21 (RN3138)
Power cord localized to country of sale
ENGR 10049 EST Environmental Stress Test Guideline
ENGR 10045 EVT Engineering Validation Test Guideline
ENGR 10048 CVT Compliance Validation Test Guideline
ENGR 10046 System Validation Test Guideline
ENGR 10023 HALT Accelerated Life
Test Guideline
ENGR 10036 CDG Component
Derating Guideline
Noise levels: <28dBA
Operating Temperature: 0-45C
Operating Humidity: 20-80% relative humidity, non-condensing
Power Consumption (Operation):
47.5W (RR2304) 55W (RN3138)
Power Consumption (Wake on LAN): 0.62W
Power Consumption (Power Off): 0.11W
Smart Fan
Scheduled Power on/off
Hard drive disk spin down
UPS Support
Network UPS with SNMP Management
Wake on LAN
Auto-power on (after shutdown)
AC Input Power Voltage 100V to 240V
Power Frequency: 50Hz to 60Hz, Single Phase
Certication: FCC Class B, CE Class B, RoHS, VCCI Class B
ReadyNAS® 2120/2304/3138
PAGE 8 of 9
Data Sheet | RN2120, RR2304, RN3138
ReadyNAS® 2120/2304/3138
Network Attached Storage (NAS)
Accessories
RTRAY04: Replacement/additional 3.5” or 2.5” hard drive tray
RRAIL04: Sliding rack mount rail
Add-onApplications
One click installation of add-on applications directly through local GUI
Application available for productivity, media, backup, surveillance, and many others
NETGEAR applications include Surveillance, Photo Sharing, Advanced conguration tools
Partner applications include BitTorrent Sync, Plex, Memeo, DVBlink
Community applications include Transmission, ownCloud, Qbittorrent, mqSQL, VPN server, Syslog, Wordpress, joomla, Media Wiki, and others
Application availability subject to change
Applications may impact overall performance
Software Development Kit (SDK) available for 3rd party developers
WarrantyandSupport
Hardware Limited Warranty 5 years
Next-Business-Day (NBD) Replacement Ye s
Technical Support (online, phone) 90 days free from date of purchase*
PMB0312 (1 yr)
ProSUPPORT OnCall 24x7 Service Packs**
PMB0332 (3 yrs) PMB0352 (5 yrs)
* This produc t comes with a limited warranty that is valid only if purchased from a NETGEAR authorized reseller, and covers unmodied hardware, fans and internal power
supplies – not sof tware or ex ternal power supplies, and requires product registration at https://insight.netgear.com or using the Insight App within 90 days of purchase; see https://www.netgear.com/about/warranty for details. Intended for indoor use only.
**The NETGEAR OnCall 24x7 contract provides unlimited phone, chat and email technical support for your net working product.
NETGE AR, the NETGEAR Logo, ProSUPPORT, ReadyNAS, ReadyNAS Cloud, ReadyNAS Vault, and X-R AID are trademarks of NETGEAR, Inc. in the Uni ted States and/or other
countries. Other brand names mentioned herein are for identication purposes only and may be trademarks of their respective holder(s). Information is subject to change
without notice. ©2020 NETGEAR, Inc. All rights reser ved.
NETGE AR, Inc. 350 E. Plumeria Drive, San Jose, CA 95134-1911 USA, 1-888-NETGEAR (638- 4327), E-mail: info@NETGEAR.com, ww w.NETGEAR.com
DS-2120/2304/3138-20Mar20
PAGE 9 of 9
Loading...
