NETGEAR GSM7248v2, GSM7224v2, FSM726v3 Cli Manual

202-10530-01
July 2009

NETGEAR, Inc.
350 Plumeria Dr.
San Jose, CA 95124 USA

ProSafe 7200 Managed
Switches CLI Manual,
Software Version 8.0

ii

v1.0, July 2009

© 2009 by NETGEAR, Inc. All rights reserved. FullManual.

Trademarks

NETGEAR and the NETGEAR logo are registered trademarks, and ProSafe is a trademark of NETGEAR, Inc.
Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation.
Other brand and product names are registered trademarks or trademarks of their respective holders. Portions of this

document are copyright Intoto, Inc.
July 2009

Statement of Conditions

In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to
make changes to the products described in this document without notice.

NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit
layout(s) described herein.

EN 55 022 Declaration of Conformance

This is to certify that the ProSafe 7200 Series Stackable Managed Switches is shielded against the generation of radio
interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is declared by
the application of EN 55 022 Class B (CISPR 22).

Certificate of the Manufacturer/Importer

It is hereby certified that the ProSafe 7200 Series Stackable Managed Switches has been suppressed in accordance with
the conditions set out in the BMPT-AmtsblVfg 243/1991 and Vfg 46/1992. The operation of some equipment (for
example, test transmitters) in accordance with the regulations may, however, be subject to certain restrictions. Please
refer to the notes in the operating instructions.

The Federal Office for Telecommunications Approvals has been notified of the placing of this equipment on the market
and has been granted the right to test the series for compliance with the regulations.

Bestätigung des Herstellers/Importeurs

Es wird hiermit bestätigt, daß dasProSafe 7200 Series Stackable Managed Switches gemäß der im BMPT-AmtsblVfg
243/1991 und Vfg 46/1992 aufgeführten Bestimmungen entstört ist. Das vorschriftsmäßige Betreiben einiger Geräte
(z.B. Testsender) kann jedoch gewissen Beschränkungen unterliegen. Lesen Sie dazu bitte die Anmerkungen in der
Betriebsanleitung.

Das Bundesamt für Zulassungen in der Telekommunikation wurde davon unterrichtet, daß dieses Gerät auf den Markt
gebracht wurde und es ist berechtigt, die Serie auf die Erfüllung der Vorschriften hin zu überprüfen.

Voluntary Control Council for Interference (VCCI) Statement

This equipment is in the Class B category (information equipment to be used in a residential area or an adjacent area
thereto) and conforms to the standards set by the Voluntary Control Council for Interference by Data Processing
Equipment and Electronic Office Machines aimed at preventing radio interference in such residential areas. When used
near a radio or TV receiver, it may become the cause of radio interference. Read instructions for correct handling.

v1.0, July 2009

iii

Product and Publication Details

Model Number: FSM72xx/GSM72xx
Publication Date: July 2009
Product Family: managed switch
Product Name: ProSafe 7200 Series Stackable Managed Switches
Home or Business Product: Business
Language: English
Publication Part Number: 202-10530-01
Publication Version Number 1.0

v1.0, July 2009

iv

Managed Switch CLI Manual, Release 8.0

v

v1.0, July 2009

Contents

About This Manual

Audience ...........................................................................................................................ix

About the Software ........................................................................................................... ix

Scope.......................................................................................................................... x

Product Concept ......................................................................................................... x

Chapter 1
Using the Command-Line Interface

Command Syntax ...........................................................................................................1-1

Command Conventions ..................................................................................................1-2

Common Parameter Values ...........................................................................................1-3

Unit/Slot/Port Naming Convention ..................................................................................1-3

Using the “No” Form of a Command ..............................................................................1-4

Managed Switch Modules ..............................................................................................1-5

Command Modes ...........................................................................................................1-5

Command Completion and Abbreviation ........................................................................1-9

CLI Error Messages ........................................................................................................1-9

CLI Line-Editing Conventions .......................................................................................1-10

Using CLI Help .............................................................................................................1-11

Accessing the CLI .........................................................................................................1-12

Chapter 2
Stacking Commands

Dedicated Port Stacking .................................................................................................2-1

Front Panel Stacking Commands .................................................................................2-10

Chapter 3
Switching Commands

Port Configuration Commands .......................................................................................3-2

Spanning Tree Protocol (STP) Commands ..................................................................3-10

VLAN Commands .........................................................................................................3-30

Double VLAN Commands ............................................................................................3-45

Managed Switch CLI Manual, Release 8.0

vi

v1.0, July 2009

Voice VLAN Commands ...............................................................................................3-47

Provisioning (IEEE 802.1p) Commands .......................................................................3-50

Protected Ports Commands .........................................................................................3-51

Private Group Commands ............................................................................................3-53

GARP Commands ........................................................................................................3-55

GVRP Commands ........................................................................................................3-58

GMRP Commands .......................................................................................................3-60

Port-Based Network Access Control Commands .........................................................3-63

Storm-Control Commands ............................................................................................3-77

Port-Channel/LAG (802.3ad) Commands ....................................................................3-89

Port Mirroring ..............................................................................................................3-112

Static MAC Filtering ....................................................................................................3-114

DHCP Snooping Configuration Commands ...............................................................3-119

Dynamic ARP Inspection Commands ........................................................................3-130

IGMP Snooping Configuration Commands ................................................................3-138

IGMP Snooping Querier Commands ..........................................................................3-147

Port Security Commands ............................................................................................3-153

LLDP (802.1AB) Commands ......................................................................................3-157

LLDP-MED Commands ..............................................................................................3-168

Denial of Service Commands .....................................................................................3-179

MAC Database Commands ........................................................................................3-191

ISDP Commands ........................................................................................................3-193

Chapter 4
Routing Commands

Address Resolution Protocol (ARP) Commands ............................................................4-1

IP Routing Commands ...................................................................................................4-8

Router Discovery Protocol Commands ........................................................................4-20

Virtual LAN Routing Commands................................................................................... 4-24

DHCP and BOOTP Relay Commands .........................................................................4-25

IP Helper Commands ...................................................................................................4-27

ICMP Throttling Commands .........................................................................................4-30

Chapter 5
Quality of Service (QoS) Commands

Class of Service (CoS) Commands ................................................................................5-2

Differentiated Services (DiffServ) Commands ................................................................5-8

Managed Switch CLI Manual, Release 8.0

vii

v1.0, July 2009

DiffServ Class Commands ...........................................................................................5-10

DiffServ Policy Commands ...........................................................................................5-19

DiffServ Service Commands ........................................................................................5-25

DiffServ Show Commands ...........................................................................................5-26

MAC Access Control List (ACL) Commands ................................................................5-32

IP Access Control List (ACL) Commands .....................................................................5-37

IPv6 Access Control List (ACL) Commands .................................................................5-44

Auto-Voice over IP Commands ....................................................................................5-48

Chapter 6
Utility Commands

Auto Install Commands ..................................................................................................6-2

Dual Image Commands ..................................................................................................6-4

System Information and Statistics Commands ...............................................................6-6

Logging Commands .....................................................................................................6-18

System Utility and Clear Commands ............................................................................6-24

Simple Network Time Protocol (SNTP) Commands .....................................................6-34

DHCP Server Commands ............................................................................................6-40

DNS Client Commands ................................................................................................6-55

Packet Capture Commands .........................................................................................6-61

Serviceability Packet Tracing Commands ....................................................................6-63

Cable Test Command ...................................................................................................6-83

sFlow Commands .................................................................................................. 6-84

Chapter 7
Management Commands

Configuring the Switch Management CPU .....................................................................7-2

Network Interface Commands ........................................................................................7-4

Console Port Access Commands ...................................................................................7-8

Telnet Commands ........................................................................................................7-11

Secure Shell (SSH) Commands ...................................................................................7-16

Management Security Commands ...............................................................................7-19

Hypertext Transfer Protocol (HTTP) Commands .........................................................7-20

Access Commands .......................................................................................................7-28

User Account Commands .............................................................................................7-29

SNMP Commands ........................................................................................................7-40

RADIUS Commands .....................................................................................................7-52

Managed Switch CLI Manual, Release 8.0

viii

v1.0, July 2009

TACACS+ Commands ..................................................................................................7-67

Configuration Scripting Commands ..............................................................................7-71

Pre-login Banner and System Prompt Commands .......................................................7-73

Chapter 8
Log Messages

Core ................................................................................................................................8-1

Utilities ............................................................................................................................8-4

Management ................................................................................................................... 8-6

Switching ......................................................................................................................8-10

QoS ..............................................................................................................................8-16

Routing/IPv6 Routing ....................................................................................................8-17

Multicast .......................................................................................................................8-21

Stacking ........................................................................................................................8-23

Technologies ................................................................................................................8-23

O/S Support ..................................................................................................................8-26

Chapter 9
Captive Portal Commands

Capitve Portal Global Commands ..................................................................................9-1

Captive Portal Configuration Commands .......................................................................9-5

Captive Portal Status Commands ................................................................................9-14

Captive Portal Client Connection Commands ..............................................................9-19

Captive Portal Interface Commands .............................................................................9-23

Captive Portal Local User Commands .........................................................................9-24

Captive Portal User Group Commands ........................................................................9-31

Chapter 10
Command List

ix

v1.0, July 2009

About This Manual

This document describes command-line interface (CLI) commands you use to view and configure
7200 Series Switch software. You can access the CLI by using a direct connection to the serial port
or by using telnet or SSH over a remote network connection.

Audience

This document is for system administrators who configure and operate systems using 7200 Series
Switch software. It provides an understanding of the configuration options of the software.

Software engineers who integrate software into their hardware platform can also benefit from a
description of the configuration options.

This document assumes that the reader has an understanding of the software base and has read the
appropriate specification for the relevant networking device platform. It also assumes that the
reader has a basic knowledge of Ethernet and networking concepts.

Refer to the release notes for the application-level code. The release notes detail the platform­specific functionality of the Switching, Routing, SNMP, Configuration, Management, and other
packages. The suite of features the packages support is not available on all the platforms to which
software has been ported.

About the Software

The software has two purposes:

• Assist attached hardware in switching frames, based on Layer 2, 3, or 4 information contained
in the frames.

• Provide a complete device management portfolio to the network administrator.

Note: This document contains both standalone and stacking commands.

Managed Switch CLI Manual, Release 8.0

x

v1.0, July 2009

Scope

The software encompasses both hardware and software support. The software is partitioned to run
in the following processors:

• CPU – This code runs the networking device management portfolio and controls the overall
networking device hardware. It also assists in frame forwarding, as needed and specified. This
code is designed to run on multiple platforms with minimal changes from platform to
platform.

• Networking device processor – This code does the majority of the packet switching, usually at
wire speed. This code is platform dependent, and substantial changes might exist across
products.

Product Concept

Fast Ethernet and Gigabit Ethernet switching continues to evolve from high-end backbone
applications to desktop switching applications. The price of the technology continues to decline,
while performance and feature sets continue to improve. Devices that are capable of switching
Layers 2, 3, and 4 are increasingly in demand. The software provides a flexible solution to these
ever-increasing needs.

The exact functionality provided by each networking device on which the software base runs
varies depending upon the platform and requirements of the NETGEAR0 software.

The software includes a set of comprehensive management functions for managing both the
software and the network. You can manage the software by using one of the following three
methods:

• Command-Line Interface (CLI)

• Simple Network Management Protocol (SNMP)

• Web-based

Each of the management methods enables you to configure, manage, and control the software
locally or remotely using in-band or out-of-band mechanisms. Management is standards-based,
with configuration parameters and a private MIB providing control for functions not completely
specified in the MIBs.

Conventions, Formats, and Scope

The conventions, formats, and scope of this manual are described in the following paragraphs:

Managed Switch CLI Manual, Release 8.0

xi

v1.0, July 2009

• Typographical Conventions. This manual uses the following typographical conventions::

• Formats. This manual uses the following formats to highlight special messages:

• Scope. This manual is written for the 7200 Series Switch.

Italic Emphasis, books, CDs, file and server names, extensions

Bold User input, IP addresses, GUI screen text

Fixed Command prompt, CLI text, code

italic URL links

Note: This format is used to highlight information of importance or special interest.

Tip: This format is used to highlight a procedure that will save time or resources.

Warning: Ignoring this type of note may result in a malfunction or damage to the

equipment.

Danger: This is a safety warning. Failure to take heed of this notice may result in

personal injury or death.

Product Version ProSafe 7000 Series Managed Switch
Manual Publication Date July 2009

Note: Product updates are available on the NETGEAR, Inc. website at

http://kbserver.netgear.com

Managed Switch CLI Manual, Release 8.0

xii

v1.0, July 2009

How to Print This Manual

To print this manual, your computer must have the free Adobe Acrobat reader installed in order to
view and print PDF files. The Acrobat reader is available on the Adobe Web site at

http://www.adobe.com.

Revision History

Part Number

Version
Number

Date Description

202-10530-01 1.0 July 2009 Product update: New firmware and new user Interface

1-1

v1.0, July 2009

Chapter 1

Using the Command-Line Interface

The command-line interface (CLI) is a text-based way to manage and monitor the system. You can
access the CLI by using a direct serial connection or by using a remote logical connection with
telnet or SSH.

This chapter describes the CLI syntax, conventions, and modes. It contains the following sections:

• “Command Syntax” on page 1-1

• “Command Conventions” on page 1-2

• “Common Parameter Values” on page 1-3

• “Unit/Slot/Port Naming Convention” on page 1-3

• “Using the “No” Form of a Command” on page 1-4

• “Managed Switch Modules” on page 1-5

• “Command Modes” on page 1-5

• “Command Completion and Abbreviation” on page 1-9

• “CLI Error Messages” on page 1-9

• “CLI Line-Editing Conventions” on page 1-10

• “Using CLI Help” on page 1-11

• “Accessing the CLI” on page 1-12

Command Syntax

A command is one or more words that might be followed by one or more parameters. Parameters
can be required or optional values.

Some commands, such as show network or clear vlan, do not require parameters. Other
commands, such as network parms, require that you supply a value after the command. You
must type the parameter values in a specific order, and optional parameters follow required
parameters. The following example describes the network parms command syntax:

Format network parms <ipaddr> <netmask> [gateway]

Managed Switch CLI Manual, Release 8.0

Using the Command-Line Interface 1-2

v1.0, July 2009

• network parms is the command name.

• <ipaddr> and <netmask> are parameters and represent required values that you must
enter after you type the command keywords.

• [gateway] is an optional parameter, so you are not required to enter a value in place of the parameter.

The CLI Command Reference lists each command by the command name and provides a brief
description of the command. Each command reference also contains the following information:

• Format shows the command keywords and the required and optional parameters.

• Mode identifies the command mode you must be in to access the command.

• Default shows the default value, if any, of a configurable setting on the device.

The show commands also contain a description of the information that the command shows.

Command Conventions

In this document, the command name is in bold font. Parameters are in italic font. You
must replace the parameter name with an appropriate value, which might be a name or number.
Parameters are order dependent.

The parameters for a command might include mandatory values, optional values, or keyword
choices. Table 1 describes the conventions this document uses to distinguish between value types.

Table 1. Parameter Conventions

Symbol Example Description

<> angle brackets <value> Indicates that you must enter a value in place of the

brackets and text inside them.

[] square brackets [value] Indicates an optional parameter that you can enter in

place of the brackets and text inside them.

{} curly braces {choice1 |

choice2}

Indicates that you must select a parameter from the list of

choices.
| Vertical bars choice1 | choice2 Separates the mutually exclusive choices.
[{}] Braces within

square brackets

[{choice1 |
choice2}]

Indicates a choice within an optional element.

Managed Switch CLI Manual, Release 8.0

Using the Command-Line Interface 1-3

v1.0, July 2009

Common Parameter Values

Parameter values might be names (strings) or numbers.To use spaces as part of a name parameter,
enclose the name value in double quotes. For example, the expression “System Name with
Spaces” forces the system to accept the spaces. Empty strings (““) are not valid user-defined
strings. Table 2 describes common parameter values and value formatting.

Unit/Slot/Port Naming Convention

Managed switch software references physical entities such as cards and ports by using a unit/slot/
port naming convention. The software also uses this convention to identify certain logical entities,
such as Port-Channel interfaces.

Table 2. Parameter Descriptions

Parameter Description

ipaddr This parameter is a valid IP address. You can enter the IP address in the following

formats:

a (32 bits)
a.b (8.24 bits)
a.b.c (8.8.16 bits)
a.b.c.d (8.8.8.8)

In addition to these formats, the CLI accepts decimal, hexadecimal and octal formats
through the following input formats (where n is any valid hexadecimal, octal or decimal
number):

0xn (CLI assumes hexadecimal format)
0n (CLI assumes octal format with leading zeros)
n (CLI assumes decimal format)

ipv6-address FE80:0000:0000:0000:020F:24FF:FEBF:DBCB, or

FE80:0:0:0:20F:24FF:FEBF:DBCB, or
FE80::20F24FF:FEBF:DBCB, or
FE80:0:0:0:20F:24FF:128:141:49:32

For additional information, refer to RFC 3513.

Interface or
unit/slot/port

Valid unit, slot, and port number separated by forward slashes. For example, 0/1
represents slot number 0 and port number 1.

Logical Interface Represents a logical slot and port number. This is applicable in the case of a port-

channel (LAG). You can use the logical unit/slot/port to configure the port-channel.

Character strings Use double quotation marks to identify character strings, for example, “System Name

with Spaces”. An empty string (“”) is not valid.

Managed Switch CLI Manual, Release 8.0

Using the Command-Line Interface 1-4

v1.0, July 2009

The slot number has two uses. In the case of physical ports, it identifies the card containing the
ports. In the case of logical and CPU ports it also identifies the type of interface or port.

The port identifies the specific physical port or logical interface being managed on a given slot.

Using the “No” Form of a Command

The no keyword is a specific form of an existing command and does not represent a new or
distinct command. Almost every configuration command has a no form. In general, use the no
form to reverse the action of a command or reset a value back to the default. For example, the no

Table 3. Type of Slots

Slot Type Description

Physical slot numbers Physical slot numbers begin with zero, and are allocated up to the maximum

number of physical slots.

Logical slot numbers Logical slots immediately follow physical slots and identify port-channel (LAG) or

router interfaces.

CPU slot numbers The CPU slots immediately follow the logical slots.

Table 4. Type of Ports

Port Type Description

Physical Ports The physical ports for each slot are numbered sequentially starting from zero.
Logical Interfaces Port-channel or Link Aggregation Group (LAG) interfaces are logical interfaces

that are only used for bridging functions.
VLAN routing interfaces are only used for routing functions.
Loopback interfaces are logical interfaces that are always up.
Tunnel interfaces are logical point-to-point links that carry encapsulated packets.

CPU ports CPU ports are handled by the driver as one or more physical entities located on

physical slots.

Note: In the CLI, loopback and tunnel interfaces do not use the unit/slot/port format. To

specify a loopback interface, you use the loopback ID. To specify a tunnel
interface, you use the tunnel ID.

Managed Switch CLI Manual, Release 8.0

Using the Command-Line Interface 1-5

v1.0, July 2009

shutdown configuration command reverses the shutdown of an interface. Use the command
without the keyword no to re-enable a disabled feature or to enable a feature that is disabled by
default. Only the configuration commands are available in the no form.

Managed Switch Modules

Managed switch software consists of flexible modules that can be applied in various combinations
to develop advanced Layer 2/3/4+ products. The commands and command modes available on
your switch depend on the installed modules. Additionally, for some show commands, the output
fields might change based on the modules included in the software.

The software suite includes the following modules:

• Switching (Layer 2)

• Quality of Service

• Management (CLI, Web UI, and SNMP)

• IPv6 Management—Allows management of the device through an IPv6 through an IPv6
address without requiring the IPv6 Routing package in the system. The management address
can be associated with the network port (front-panel switch ports), a routine interface (port or
VLAN) and the Service port.

• Stacking

Not all modules are available for all platforms or software releases.

Command Modes

The CLI groups commands into modes according to the command function. Each of the command
modes supports specific software commands. The commands in one mode are not available until
you switch to that particular mode, with the exception of the User EXEC mode commands. You
can execute the User EXEC mode commands in the Privileged EXEC mode.

The command prompt changes in each command mode to help you identify the current mode.

Table 5 describes the command modes and the prompts visible in that mode.

Note: The command modes available on your switch depend on the software modules

that are installed. For example, a switch that does not support BGPv4 does not have
the Router BGPv4 Command Mode.

Managed Switch CLI Manual, Release 8.0

Using the Command-Line Interface 1-6

v1.0, July 2009

Table 5. CLI Command Modes

Command Mode Prompt Mode Description

User EXEC Switch> Contains a limited set of commands to view

basic system information.

Privileged EXEC Switch# Allows you to issue any EXEC command, enter

the VLAN mode, or enter the Global
Configuration mode.

Global Config Switch (Config)# Groups general setup commands and permits

you to make modifications to the running

configuration.
VLAN Config Switch (Vlan)# Groups all the VLAN commands.
Interface Config Switch (Interface <unit/slot/port>)#

Switch (Interface Loopback <id>)#
Switch (Interface Tunnel <id>)#

Manages the operation of an interface and

provides access to the router interface

configuration commands.

Use this mode to set up a physical port for a

specific logical connection operation.
Line Config Switch (line)# Contains commands to configure outbound

telnet settings and console interface settings.
Policy Map

Config

Switch (Config-policy-map)# Contains the QoS Policy-Map configuration

commands.
Policy Class

Config

Switch (Config-policy-class-map)# Consists of class creation, deletion, and

matching commands. The class match

commands specify Layer 2, Layer 3, and

general match criteria.
Class Map Config Switch (Config-class-map)# Contains the QoS class map configuration

commands for IPv4.
Ipv6_Class-Map

Config

Switch (Config-class-map)# Contains the QoS class map configuration

commands for IPv6.
Router OSPF

Config

Switch (Config-router)# Contains the OSPF configuration commands.

Router OSPFv3
Config

Switch (Config rtr)# Contains the OSPFv3 configuration commands.

Router RIP Config Switch (Config-router)# Contains the RIP configuration commands.
Router BGP

Config

Switch (Config-router)# Contains the BGP4 configuration commands.

MAC Access-list
Config

Switch (Config-mac-access-list)# Allows you to create a MAC Access-List and to

enter the mode containing MAC Access-List

configuration commands.

Managed Switch CLI Manual, Release 8.0

Using the Command-Line Interface 1-7

v1.0, July 2009

Table 6 explains how to enter or exit each mode.

TACACS Config Switch (Tacacs)# Contains commands to configure properties for

the TACACS servers.
DHCP Pool

Config

Switch (Config dhcp-pool)# Contains the DHCP server IP address pool

configuration commands.
DHCPv6 Pool

Config

Switch (Config dhcp6-pool)# Contains the DHCPv6 server IPv6 address pool

configuration commands.

Stack Global
Config Mode

Switch (Config stack)# Allows you to access the Stack Global Config

Mode.
ARP Access-List

Config Mode

Switch (Config-arp-access-list)# Contains commands to add ARP ACL rules in

an ARP Access List.

Table 6. CLI Mode Access and Exit

Command Mode Access Method Exit or Access Previous Mode

User EXEC This is the first level of access. To exit, enter logout.
Privileged EXEC From the User EXEC mode, enter

enable.

To exit to the User EXEC mode, enter exit or
press Ctrl-Z.

Global Config From the Privileged EXEC mode,

enter configure.

To exit to the Privileged EXEC mode, enter exit,
or press Ctrl-Z.

VLAN Config From the Privileged EXEC mode,

enter vlan database.

To exit to the Privileged EXEC mode, enter exit,
or press Ctrl-Z.

Interface Config From the Global Config mode,

enter
interface <unit/slot/port>
or interface loopback <id>
or interface tunnel <id>

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

Line Config From the Global Config mode,

enter
lineconfig.

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

Policy-Map
Config

From the Global Config mode,
enter
policy-map <name> in.

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

Policy-Class-Map
Config

From the Policy Map mode enter
class.

To exit to the Policy Map mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

Table 5. CLI Command Modes (continued)

Command Mode Prompt Mode Description

Managed Switch CLI Manual, Release 8.0

Using the Command-Line Interface 1-8

v1.0, July 2009

Class-Map
Config

From the Global Config mode,
enter
class-map, and specify the
optional keyword ipv4 to specify
the Layer 3 protocol for this class.
See “class-map” on page 5-10 for
more information.

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

Ipv6-Class-Map
Config

From the Global Config mode,
enter
class-map and specify the
optional keyword ipv6 to specify
the Layer 3 protocol for this class.
See “class-map” on page 5-10 for
more information.

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

Router OSPF
Config

From the Global Config mode,
enter
router ospf.

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

Router OSPFv3
Config

From the Global Config mode,
enter
ipv6 router ospf.

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

Router RIP
Config

From the Global Config mode,
enter
router rip.

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

Router BGP
Config

From the Global Config mode,
enter
router bgp <asnumber>.

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

MAC Access-list
Config

From the Global Config mode,
enter

mac access-list extended

<name>.

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

TACACS Config From the Global Config mode,

enter

tacacs-server host

<ip-addr>, where <ip-addr> is
the IP address of the TACACS
server on your network.

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

DHCP Pool
Config

From the Global Config mode,
enter
ip dhcp pool <pool-name>.

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

Table 6. CLI Mode Access and Exit (continued)

Command Mode Access Method Exit or Access Previous Mode

Managed Switch CLI Manual, Release 8.0

Using the Command-Line Interface 1-9

v1.0, July 2009

Command Completion and Abbreviation

Command completion finishes spelling the command when you type enough letters of a command
to uniquely identify the command keyword. Once you have entered enough letters, press the
SPACEBAR or TAB key to complete the word.

Command abbreviation allows you to execute a command when you have entered there are enough
letters to uniquely identify the command. You must enter all of the required keywords and
parameters before you enter the command.

CLI Error Messages

If you enter a command and the system is unable to execute it, an error message appears. Table 7
describes the most common CLI error messages.

DHCPv6 Pool
Config

From the Global Config mode,
enter
ip dhcpv6 pool <pool-name>.

To exit to the Global Config mode, enter exit. To
return to the Privileged EXEC mode, enter Ctrl-
Z.

Stack Global
Config Mode

From the Global Config mode,
enter the stack command.

To exit to the Global Config mode, enter the exit
command. To return to the Privileged EXEC
mode, enter Ctrl-Z.

ARP Access-List
Config Mode

From the Global Config mode,
enter the arp access-list
command.

To exit to the Global Config mode, enter the

exit command. To return to the Privileged

EXEC mode, enter Ctrl-Z.

Table 7. CLI Error Messages

Message Text Description

% Invalid input detected at '^' marker. Indicates that you entered an incorrect or unavailable command.

The carat (^) shows where the invalid text is detected. This
message also appears if any of the parameters or values are not
recognized.

Table 6. CLI Mode Access and Exit (continued)

Command Mode Access Method Exit or Access Previous Mode

Managed Switch CLI Manual, Release 8.0

Using the Command-Line Interface 1-10

v1.0, July 2009

CLI Line-Editing Conventions

Table 8 describes the key combinations you can use to edit commands or increase the speed of

command entry. You can access this list from the CLI by entering help from the User or
Privileged EXEC modes.

Command not found / Incomplete
command. Use ? to list commands.

Indicates that you did not enter the required keywords or values.

Ambiguous command Indicates that you did not enter enough letters to uniquely identify

the command.

Table 8. CLI Editing Conventions

Key Sequence Description

DEL or Backspace Delete previous character
Ctrl-A Go to beginning of line
Ctrl-E Go to end of line
Ctrl-F Go forward one character
Ctrl-B Go backward one character
Ctrl-D Delete current character
Ctrl-U, X Delete to beginning of line
Ctrl-K Delete to end of line
Ctrl-W Delete previous word
Ctrl-T Transpose previous character
Ctrl-P Go to previous line in history buffer
Ctrl-R Rewrites or pastes the line
Ctrl-N Go to next line in history buffer
Ctrl-Y Prints last deleted character
Ctrl-Q Enables serial flow
Ctrl-S Disables serial flow
Ctrl-Z Return to root command prompt
Tab, <SPACE> Command-line completion

Table 7. CLI Error Messages

Message Text Description

Managed Switch CLI Manual, Release 8.0

Using the Command-Line Interface 1-11

v1.0, July 2009

Using CLI Help

Enter a question mark (?) at the command prompt to display the commands available in the current
mode.

(switch) >?

enable Enter into user privilege mode.
help Display help for various special keys.
logout Exit this session. Any unsaved changes are lost.
ping Send ICMP echo packets to a specified IP address.
quit Exit this session. Any unsaved changes are lost.
show Display Switch Options and Settings.
telnet Telnet to a remote host.

Enter a question mark (?) after each word you enter to display available command keywords or
parameters.

(switch) #network ?

javamode Enable/Disable.
mgmt_vlan Configure the Management VLAN ID of the switch.
parms Configure Network Parameters of the router.
protocol Select DHCP, BootP, or None as the network config
protocol.

If the help output shows a parameter in angle brackets, you must replace the parameter with a
value.

(switch) #network parms ?

<ipaddr> Enter the IP address.

If there are no additional command keywords or parameters, or if additional parameters are
optional, the following message appears in the output:

<cr> Press Enter to execute the command

You can also enter a question mark (?) after typing one or more characters of a word to list the
available command or parameters that begin with the letters, as shown in the following example:

Exit Go to next lower command prompt
? List available commands, keywords, or parameters

Table 8. CLI Editing Conventions (continued)

Key Sequence Description

Managed Switch CLI Manual, Release 8.0

Using the Command-Line Interface 1-12

v1.0, July 2009

(switch) #show m?

mac-addr-table mac-address-table monitor

Accessing the CLI

You can access the CLI by using a direct console connection or by using a telnet or SSH
connection from a remote management host.

For the initial connection, you must use a direct connection to the console port. You cannot access
the system remotely until the system has an IP address, subnet mask, and default gateway. You can
set the network configuration information manually, or you can configure the system to accept
these settings from a BOOTP or DHCP server on your network. For more information, see

“Network Interface Commands” on page 7-4.

2-1

v1.0, July 2009

Chapter 2

Stacking Commands

The Stacking Commands chapter includes the following sections:

• “Dedicated Port Stacking” on page 2-1

• “Front Panel Stacking Commands” on page 2-10

Dedicated Port Stacking

This section describes the commands you use to configure dedicated port stacking.

stack

This command sets the mode to Stack Global Config.

Note: The commands in this chapter are in one of two functional groups:
Note: Show commands display switch settings, statistics, and other information.
Note: Configuration commands configure features and options of the switch. For

every configuration command, there is a show command that displays the
configuration setting.

The Primary Management Unit is the unit that controls the stack.

Format stack
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Stacking Commands 2-2

v1.0, July 2009

member

This command configures a switch. The <unit> is the switch identifier of the switch to be
added/removed from the stack. The <switchindex> is the index into the database of the
supported switch types, indicating the type of the switch being preconfigured. The switch index is
a 32-bit integer. This command is executed on the Primary Management Unit.

no member

This command removes a switch from the stack. The <unit> is the switch identifier of the
switch to be removed from the stack. This command is executed on the Primary Management Unit.

switch priority

This command configures the ability of a switch to become the Primary Management Unit. The
<unit> is the switch identifier. The <value> is the preference parameter that allows the user
to specify, priority of one backup switch over another. The range for priority is 1 to 15. The switch
with the highest priority value will be chosen to become the Primary Management Unit if the
active Primary Management Unit fails. The switch priority defaults to the hardware management
preference value 1. Switches that do not have the hardware capability to become the Primary
Management Unit are not eligible for management.

Format member <unit> <switchindex>
Mode Stack Global Config

Note: Switch index can be obtained by executing the show supported switchtype

command in User EXEC mode.

Format no member <unit>
Mode Stack Global Config

Default enabled
Format switch <unit> priority <value>
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Stacking Commands 2-3

v1.0, July 2009

switch renumber

This command changes the switch identifier for a switch in the stack. The <oldunit> is the
current switch identifier on the switch whose identifier is to be changed. The <newunit> is the
updated value of the switch identifier. Upon execution, the switch will be configured with the
configuration information for the new switch, if any. The old switch configuration information will
be retained, however the old switch will be operationally unplugged. This command is executed on
the Primary Management Unit.

movemanagement

This command moves the Primary Management Unit functionality from one switch to another.
The <fromunit> is the switch identifier on the current Primary Management Unit. The
<tounit> is the switch identifier on the new Primary Management Unit. Upon execution, the
entire stack (including all interfaces in the stack) is unconfigured and reconfigured with the
configuration on the new Primary Management Unit. After the reload is complete, all stack
management capability must be performed on the new Primary Management Unit. To preserve the
current configuration across a stack move, execute the copy system:running-config
nvram:startup-config (in Privileged EXEC) command before performing the stack move.
A stack move causes all routes and layer 2 addresses to be lost. This command is executed on the
Primary Management Unit. The system prompts you to confirm the management move.

Note: If the management unit is renumbered, then the running configuration is no longer

applied (i.e. the stack acts as if the configuration had been cleared)

Format switch <oldunit> renumber <newunit>
Mode Global Config

Format movemanagement <fromunit> <tounit>
Mode Stack Global Config

Managed Switch CLI Manual, Release 8.0

Stacking Commands 2-4

v1.0, July 2009

slot

This command configures a slot in the system. The <unit/slot> is the slot identifier of the
slot. The <cardindex> is the index into the database of the supported card types, indicating the
type of the card being preconfigured in the specified slot. The card index is a 32-bit integer. If a
card is currently present in the slot that is unconfigured, the configured information will be deleted
and the slot will be re-configured with default information for the card.

no slot

This command removes configured information from an existing slot in the system.

set slot disable

This command configures the administrative mode of the slot(s). If you specify [all], the
command is applied to all slots, otherwise the command is applied to the slot identified by
<unit/slot>.

Format slot <unit/slot> <cardindex>
Mode Global Config

Note: Card index can be obtained by executing show supported cardtype command in

User EXEC mode.

Format no slot <unit/slot> <cardindex>
Mode Global Config

Note: Card index can be obtained by executing show supported cardtype command in

User EXEC mode.

Managed Switch CLI Manual, Release 8.0

Stacking Commands 2-5

v1.0, July 2009

If a card or other module is present in the slot, this administrative mode will effectively be applied
to the contents of the slot. If the slot is empty, this administrative mode will be applied to any
module that is inserted into the slot. If a card is disabled, all the ports on the device are
operationally disabled and shown as “unplugged” on management screens.

no set slot disable

This command unconfigures the administrative mode of the slot(s). If you specify [all], the
command removes the configuration from all slots, otherwise the configuration is removed from
the slot identified by <unit/slot>.

If a card or other module is present in the slot, this administrative mode removes the configuration
from the contents of the slot. If the slot is empty, this administrative mode removes the
configuration from any module inserted into the slot. If a card is disabled, all the ports on the
device are operationally disabled and shown as “unplugged” on management screens.

set slot power

This command configures the power mode of the slot(s) and allows power to be supplied to a card
located in the slot. If you specify [all], the command is applied to all slots, otherwise the
command is applied to the slot identified by <unit/slot>.

Use this command when installing or removing cards. If a card or other module is present in this
slot, the power mode is applied to the contents of the slot. If the slot is empty, the power mode is
applied to any card inserted into the slot.

Format set slot disable [<unit/slot> | all]
Mode Global Config

Format no set slot disable [<unit/slot> | all]
Mode Global Config

Format set slot power [<unit/slot> | all]
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Stacking Commands 2-6

v1.0, July 2009

no set slot power

This command unconfigures the power mode of the slot(s) and prohibits power from being
supplied to a card located in the slot. If you specify [all], the command prohibits power to all
slots, otherwise the command prohibits power to the slot identified by <unit/slot>.

Use this command when installing or removing cards. If a card or other module is present in this
slot, power is prohibited to the contents of the slot. If the slot is empty, power is prohibited to any
card inserted into the slot.

reload (Stack)

This command resets the entire stack or the identified <unit>. The <unit> is the switch
identifier. The system prompts you to confirm that you want to reset the switch.

show slot

This command displays information about all the slots in the system or for a specific slot.

Format no set slot power [<unit/slot> | all]
Mode Global Config

Format reload [<unit>]
Mode User EXEC

Format show slot [<unit/slot>]
Mode User EXEC

Term Definition
Slot The slot identifier in a <unit/slot> format.

Slot Status The slot is empty, full, or has encountered an error
Admin State The slot administrative mode is enabled or disabled.
Power State The slot power mode is enabled or disabled.
Configured Card

Model Identifier

The model identifier of the card preconfigured in the slot. Model Identifier is a 32­character field used to identify a card.

Managed Switch CLI Manual, Release 8.0

Stacking Commands 2-7

v1.0, July 2009

If you supply a value for <unit/slot>, the following additional information appears:

show supported cardtype

This commands displays information about all card types or specific card types supported in the
system.

If you do not supply a value for <cardindex>, the following output appears:

If you supply a value for <cardindex>, the following output appears:

Pluggable Cards are pluggable or non-pluggable in the slot.

Power Down Indicates whether the slot can be powered down.

Term Definition
Inserted Card

Model Identifier

The model identifier of the card inserted in the slot. Model Identifier is a 32-character
field used to identify a card. This field is displayed only if the slot is full.

Inserted Card
Description

The card description. This field is displayed only if the slot is full.

Configured Card
Description

The card description of the card preconfigured in the slot.

Format show supported cardtype [<cardindex>]
Mode User EXEC

Term Definition
Card Index (CID) The index into the database of the supported card types. This index is used when

preconfiguring a slot.

Card Model
Identifier

The model identifier for the supported card type.

Term Definition
Card Type The 32-bit numeric card type for the supported card.

Model Identifier The model identifier for the supported card type.
Card Description The description for the supported card type.

Term Definition

Managed Switch CLI Manual, Release 8.0

Stacking Commands 2-8

v1.0, July 2009

show switch

This command displays information about all units in the stack or a single unit when you specify
the unit value.

When you do not specify a value for <unit>, the following information appears:

When you specify a value for <unit>, the following information appears:

Format show switch [<unit>]
Mode Privileged EXEC

Term Definition
Switch The unit identifier assigned to the switch.

Term Definition
Management

Status

Indicates whether the switch is the Primary Management Unit, a stack member, or the
status is unassigned.

Preconfigured
Model Identifier

The model identifier of a preconfigured switch ready to join the stack. The Model
Identifier is a 32-character field assigned by the device manufacturer to identify the
device.

Plugged-In Model
Identifier

The model identifier of the switch in the stack. Model Identifier is a 32-character field
assigned by the device manufacturer to identify the device.

Switch Status The switch status. Possible values for this state are: OK, Unsup ported, Code

Mismatch, Config Mismatch, or Not Present.

Code Version The detected version of code on this switch.

Term Definition
Management

Status

Indicates whether the switch is the Primary Management Unit, a stack member, or the
status is unassigned.

Hardware
Management
Preference

The hardware management preference of the switch. The hardware management
preference can be disabled or unassigned.

Admin
Management
Preference

The administrative management preference value assigned to the switch. This
preference value indicates how likely the switch is to be chosen as the Primary
Management Unit.

Switch Type The 32-bit numeric switch type.
Model Identifier The model identifier for this switch. Model Identifier is a 32-character field assigned by

the device manufacturer to identify the device.

Managed Switch CLI Manual, Release 8.0

Stacking Commands 2-9

v1.0, July 2009

show supported switchtype

This commands displays information about all supported switch types or a specific switch type.

If you do not supply a value for <switchindex>, the following output appears:

If you supply a value for <switchindex>, the following output appears:

Switch Status The switch status. Possible values are OK, Unsupported, Code Mismatch, Config

Mismatch, or Not Present.

Switch
Description

The switch description.

Expected Code
Version

The expected code version.

Detected Code
Version

The version of code running on this switch. If the switch is not present and the data is
from pre-configuration, then the code version is “None”.

Detected Code in
Flash

The version of code that is currently stored in FLASH memory on the switch. This code
executes after the switch is reset. If the switch is not present and the data is from pre­configuration, then the code version is “None”.

Up Time The system up time.

Format show supported switchtype [<switchindex>]
Mode User EXEC

Privileged EXEC

Term Definition
Switch Index (SID) The index into the database of supported switch types. This index is used when

preconfiguring a member to be added to the stack.

Model Identifier The model identifier for the supported switch type.
Management

Preference

The management preference value of the switch type.

Code Version The code load target identifier of the switch type.

Term Definition
Switch Type The 32-bit numeric switch type for the supported switch.

Term Definition

Managed Switch CLI Manual, Release 8.0

Stacking Commands 2-10

v1.0, July 2009

Front Panel Stacking Commands

This section describes the commands you use to view and configure front panel stacking
information.

stack-port

This command sets front panel stacking per port to either stack or ethernet mode. This
command is not supported on the FSM7226RS or FSM7250RS.

show stack-port

This command displays summary stack-port information for all interfaces.

Model Identifier The model identifier for the supported switch type.
Switch

Description

The description for the supported switch type.

Default stack
Format stack-port <unit/slot/port> [{ethernet | stack}]
Mode Stack Global Config

Format show stack-port
Mode Privileged EXEC

Term Definition
QOS Mode Front Panel Stacking QOS Mode for all Interfaces.

Term Definition

Managed Switch CLI Manual, Release 8.0

Stacking Commands 2-11

v1.0, July 2009

For Each Interface:

show stack-port counters

This command displays summary data counter information for all interfaces.

Term Definition
Unit The unit number.

Interface The slot and port numbers.
Configured Stack

Mode

Stack or Ethernet.

Running Stack
Mode

Stack or Ethernet.

Link Status Status of the link.
Link Speed Speed (Gbps) of the stack port link.

Format show stack-port counters
Mode Privileged EXEC

Term Definition
Unit The unit number.

Interface The slot and port numbers.
Tx Data Rate Trashing data rate in megabits per second on the stacking port.
Tx Error Rate Platform-specific number of transmit errors per second.
Tx Total Error Platform-specific number of total transmit errors since power-up.
Rx Data Rate Receive data rate in megabits per second on the stacking port.
Rx Error Rate Platform-specific number of receive errors per second.
Rx Total Errors Platform-specific number of total receive errors since power-up.

Managed Switch CLI Manual, Release 8.0

Stacking Commands 2-12

v1.0, July 2009

show stack-port diag

This command shows front panel stacking diagnostics for each port and is only intended for Field
Application Engineers (FAEs) and developers. An FAE will advise on the necessity to run this
command and capture this information.

Format show stack-port diag
Mode Privileged EXEC

Term Definition
Unit The unit number.

Interface The slot and port numbers.
Diagnostic Entry1 80 character string used for diagnostics.
Diagnostic Entry2 80 character string used for diagnostics.
Diagnostic Entry3 80 character string used for diagnostics.

3-1

v1.0, July 2009

Chapter 3

Switching Commands

This chapter describes the switching commands available in the managed switch CLI.
The Switching Commands chapter includes the following sections:

• “Port Configuration Commands” on page 3-2

• “show port description” on page 3-9

• “VLAN Commands” on page 3-30

• “Double VLAN Commands” on page 3-45

• “Voice VLAN Commands” on page 3-47

• “Provisioning (IEEE 802.1p) Commands” on page 3-50

• “Protected Ports Commands” on page 3-51

• “Private Group Commands” on page 3-53

• “GVRP Commands” on page 3-58

• “GMRP Commands” on page 3-60

• “Port-Based Network Access Control Commands” on page 3-63

• “Storm-Control Commands” on page 3-77

• “Port-Channel/LAG (802.3ad) Commands” on page 3-89

• “Port Mirroring” on page 3-112

• “Static MAC Filtering” on page 3-114

• “DHCP Snooping Configuration Commands” on page 3-119

• “Dynamic ARP Inspection Commands” on page 3-130

• “IGMP Snooping Configuration Commands” on page 3-138

• “IGMP Snooping Querier Commands” on page 3-147

• “Port Security Commands” on page 3-153

• “LLDP (802.1AB) Commands” on page 3-157

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-2

v1.0, July 2009

• “LLDP-MED Commands” on page 3-168

• “Denial of Service Commands” on page 3-179

• “MAC Database Commands” on page 3-191

• “ISDP Commands” on page 3-193

Port Configuration Commands

This section describes the commands you use to view and configure port settings.

interface

This command gives you access to the Interface Config mode, which allows you to enable or
modify the operation of an interface (port).

interface range

This command gives you access to a range of port interfaces, allowing the same port configuration
to be applied to a set of ports.

Warning: The commands in this chapter are in one of three functional groups:

• Show commands display switch settings, statistics, and other information.

• Configuration commands configure features and options of the switch. For every
configuration command, there is a show command that displays the
configuration setting.

• Clear commands clear some or all of the settings to factory defaults.

Format interface <unit/slot/port>
Mode Global Config

Format interface range <unit/slot/port>-<unit/slot/port>
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-3

v1.0, July 2009

interface vlan

This command gives you access to to the vlan virtual interface mode, which allows certain port
configurations (for example, the IP address) to be applied to the VLAN interface. Type a question
mark (?) after entering the interface configuration mode to see the available options.

interface lag

This command gives you access to the LAG (link aggregation, or port channel) virtual interface,
which allows certain port configurations to be applied to the LAG interface. Type a question mark
(?) after entering the interface configuration mode to see the available options.

auto-negotiate

This command enables automatic negotiation on a port.

Format interface vlan <vlan id>
Mode Global Config

Note: The IP address cannot be assigned to a LAG virtual interface. The interface must

be put under a VLAN group and an IP address assigned to the VLAN group..

Format interface lag <lag id>
Mode Global Config

Default enabled
Format auto-negotiate
Mode Interface Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-4

v1.0, July 2009

no auto-negotiate

This command disables automatic negotiation on a port.

auto-negotiate all

This command enables automatic negotiation on all ports.

no auto-negotiate all

This command disables automatic negotiation on all ports.

description

Use this command to create an alpha-numeric description of the port.

Note: Automatic sensing is disabled when automatic negotiation is disabled.

Format no auto-negotiate
Mode Interface Config

Default enabled
Format auto-negotiate all
Mode Global Config

Format no auto-negotiate all
Mode Global Config

Format description <description>
Mode Interface Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-5

v1.0, July 2009

mtu

Use the mtu command to set the maximum transmission unit (MTU) size, in bytes, for frames that
ingress or egress the interface. You can use the mtu command to configure jumbo frame support
for physical and port-channel (LAG) interfaces. For the standard 7000 seriesimplementation, the
MTU size is a valid integer between 1522 - 9216 for tagged packets and a valid integer between
1518 - 9216 for untagged packets.

no mtu

This command sets the default MTU size (in bytes) for the interface.

shutdown

This command disables a port.

Note: To receive and process packets, the Ethernet MTU must include any extra bytes

that Layer-2 headers might require. To configure the IP MTU size, which is the
maximum size of the IP packet (IP Header + IP payload), see “ip mtu” on page 4-

12.

Default 1518 (untagged)
Format mtu <1518-9216>
Mode Interface Config

Format no mtu
Mode Interface Config

Note: You can use the shutdown command on physical and port-channel (LAG)

interfaces, but not on VLAN routing interfaces.

Default enabled

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-6

v1.0, July 2009

no shutdown

This command enables a port.

shutdown all

This command disables all ports.

no shutdown all

This command enables all ports.

Format shutdown
Mode Interface Config

Format no shutdown
Mode Interface Config

Note: You can use the shutdown all command on physical and port-channel (LAG)

interfaces, but not on VLAN routing interfaces.

Default enabled
Format shutdown all
Mode Global Config

Format no shutdown all
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-7

v1.0, July 2009

speed

This command sets the speed and duplex setting for the interface.

speed all

This command sets the speed and duplex setting for all interfaces.

show port

This command displays port information.

Format speed {<100 | 10> <half-duplex | full-duplex>}
Mode Interface Config

Acceptable
Values

Definition

100h 100BASE-T half duplex
100f 100BASE-T full duplex
10h 10BASE-T half duplex
10f 10BASE-T full duplex

Format speed all {<100 | 10> <half-duplex | full-duplex>}
Mode Global Config

Acceptable
Values

Definition

100h 100BASE-T half duplex
100f 100BASE-T full duplex
10h 10BASE-T half duplex
10f 10BASE-T full duplex

Format show port {<unit/slot/port> | all}
Mode Privileged EXEC

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-8

v1.0, July 2009

show port protocol

This command displays the Protocol-Based VLAN information for either the entire system, or for
the indicated group.

Term Definition
Interface Valid unit, slot, and port number separated by forward slashes.

Type If not blank, this field indicates that this port is a special type of port. The possible

values are:

• Mirror - this port is a monitoring port. For more information, see “Port Mirroring” on

page 3-112.

• PC Mbr- this port is a member of a port-channel (LAG).

• Probe - this port is a probe port.

Admin Mode The Port control administration state. The port must be enabled in order for it to be

allowed into the network. - May be enabled or disabled. The factory default is enabled.

Physical Mode The desired port speed and duplex mode. If auto-negotiation support is selected, then

the duplex mode and speed is set from the auto-negotiation process. Note that the
maximum capability of the port (full duplex -100M) is advertised. Otherwise, this object
determines the port's duplex mode and transmission rate. The factory default is Auto.

Physical Status The port speed and duplex mode.
Link Status The Link is up or down.
Link Trap This object determines whether or not to send a trap when link status changes. The

factory default is enabled.

LACP Mode LACP is enabled or disabled on this port.

Format show port protocol {<groupid> | all}
Mode Privileged EXEC

Term Definition
Group Name The group name of an entry in the Protocol-based VLAN table.

Group ID The group identifier of the protocol group.
Protocol(s) The type of protocol(s) for this group.
VLAN The VLAN associated with this Protocol Group.
Interface(s) Lists the unit/slot/port interface(s) that are associated with this Protocol Group.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-9

v1.0, July 2009

show port description

This command displays the port description for every port.

show port status

This command displays the Protocol-Based VLAN information for either the entire system, or for
the indicated group.

Format show port description <unit/slot/port>
Mode Privileged EXEC

Term Definition
Interface Valid slot and port number separated by forward slashes

Description Shows the port description configured via the “description” command

Format show port status {<unit/slot/port> | all}
Mode Privileged EXEC

Term Definition
Interface Valid slot and port number separated by forward slashes.

Media Type “Copper” or “Fiber” for combo port.
STP Mode Indicate the spanning tree mode of the port.
Physical Mode Either “Auto” or fixed speed and duplex mode.
Physical Status The actual speed and duplex mode.
Link Status Whether the link is Up or Down.
Loop Status Whether the port is in loop state or not.
Partner Flow

Control

Whether the remote side is using flow control or not.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-10

v1.0, July 2009

Spanning Tree Protocol (STP) Commands

This section describes the commands you use to configure Spanning Tree Protocol (STP). STP
helps prevent network loops, duplicate messages, and network instability.

spanning-tree

This command sets the spanning-tree operational mode to enabled.

no spanning-tree

This command sets the spanning-tree operational mode to disabled. While disabled, the spanning­tree configuration is retained and can be changed, but is not activated.

spanning-tree bpdufilter default

Use this command to enable BPDU Filter on all the edge port interfaces.

no spanning-tree bpdufilter default

Use this command to disable BPDU Filter on all the edge port interfaces.

Default enabled
Format spanning-tree
Mode Global Config

Format no spanning-tree
Mode Global Config

Default disabled
Format spanning-tree bpdufilter
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-11

v1.0, July 2009

spanning-tree bpduflood

Use this command to enable BPDU Flood on the interface.

no spanning-tree bpduflood

Use this command to disable BPDU Flood on the interface.

spanning-tree bpduguard

Use this command to enable BPDU Guard on the switch.

no spanning-tree bpduguard

Use this command to disable BPDU Guard on the switch.

Default enabled
Format no spanning-tree bpdufilter default
Mode Global Config

Default disabled
Format spanning-tree bpduflood
Mode Interface Config

Format no spanning-tree bpduflood
Mode Interface Config

Default disabled
Format spanning-tree bpduguard
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-12

v1.0, July 2009

spanning-tree bpdumigrationcheck

Use this command to force a transmission of rapid spanning tree (RSTP) and multiple spanning
tree (MSTP) BPDUs. Use the <unit/slot/port> parameter to transmit a BPDU from a
specified interface, or use the all keyword to transmit BPDUs from all interfaces. This command
forces the BPDU transmission when you execute it, so the command does not change the system
configuration or have a “no” version.

spanning-tree configuration name

This command sets the Configuration Identifier Name for use in identifying the configuration that
this switch is currently using. The <name> is a string of up to 32 characters.

no spanning-tree configuration name

This command resets the Configuration Identifier Name to its default.

Format no spanning-tree bpduguard
Mode Global Config

Format spanning-tree bpdumigrationcheck {<unit/slot/port> | all}
Mode Global Config

Default base MAC address in hexadecimal notation
Format spanning-tree configuration name

<name>

Mode Global Config

Format no spanning-tree configuration name
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-13

v1.0, July 2009

spanning-tree configuration revision

This command sets the Configuration Identifier Revision Level for use in identifying the
configuration that this switch is currently using. The Configuration Identifier Revision Level is a
number in the range of 0 to 65535.

no spanning-tree configuration revision

This command sets the Configuration Identifier Revision Level for use in identifying the
configuration that this switch is currently using to the default value.

spanning-tree edgeport

This command specifies that this port is an Edge Port within the common and internal spanning
tree. This allows this port to transition to Forwarding State without delay.

no spanning-tree edgeport

This command specifies that this port is not an Edge Port within the common and internal
spanning tree.

Default 0
Format spanning-tree configuration revision

<0-65535>

Mode Global Config

Format no spanning-tree configuration revision
Mode Global Config

Default enabled
Format spanning-tree edgeport
Mode Interface Config

Format no spanning-tree edgeport
Mode Interface Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-14

v1.0, July 2009

spanning-tree forceversion

This command sets the Force Protocol Version parameter to a new value.

• Use 802.1d to specify that the switch transmits ST BPDUs rather than MST BPDUs (IEEE

802.1d functionality supported).

• Use 802.1s to specify that the switch transmits MST BPDUs (IEEE 802.1s functionality
supported).

• Use 802.1w to specify that the switch transmits RST BPDUs rather than MST BPDUs (IEEE

802.1w functionality supported).

no spanning-tree forceversion

This command sets the Force Protocol Version parameter to the default value.

spanning-tree forward-time

This command sets the Bridge Forward Delay parameter to a new value for the common and
internal spanning tree. The forward-time value is in seconds within a range of 4 to 30, with the
value being greater than or equal to “(Bridge Max Age / 2) + 1”.

Default 802.1s
Format spanning-tree forceversion

<802.1d | 802.1s | 802.1w>

Mode Global Config

Format no spanning-tree forceversion
Mode Global Config

Default 15
Format spanning-tree forward-time

<4-30>

Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-15

v1.0, July 2009

no spanning-tree forward-time

This command sets the Bridge Forward Delay parameter for the common and internal spanning
tree to the default value.

spanning-tree guard

This command selects whether loop guard or root guard is enabled on an interface. If neither is
enabled, then the port operates in accordance with the multiple spanning tree protocol.

no spanning-tree guard

This command disables loop guard or root guard on the interface.

spanning-tree max-age

This command sets the Bridge Max Age parameter to a new value for the common and internal
spanning tree. The max-age value is in seconds within a range of 6 to 40, with the value being less
than or equal to 2 x (Bridge Forward Delay - 1).

Format no spanning-tree forward-time
Mode Global Config

Default none
Format spanning-tree guard { none | root | loop }
Mode Interface Config

Format no spanning-tree guard
Mode Interface Config

Default 20
Format spanning-tree max-age

<6-40>

Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-16

v1.0, July 2009

no spanning-tree max-age

This command sets the Bridge Max Age parameter for the common and internal spanning tree to
the default value.

spanning-tree max-hops

This command sets the MSTP Max Hops parameter to a new value for the common and internal
spanning tree. The max-hops value is a range from 6 to 40.

no spanning-tree max-hops

This command sets the Bridge Max Hops parameter for the common and internal spanning tree to
the default value.

spanning-tree mst

This command sets the Path Cost or Port Priority for this port within the multiple spanning tree
instance or in the common and internal spanning tree. If you specify an <mstid> parameter that
corresponds to an existing multiple spanning tree instance, the configurations are done for that
multiple spanning tree instance. If you specify 0 (defined as the default CIST ID) as the
<mstid>, the configurations are done for the common and internal spanning tree instance.

Format no spanning-tree max-age
Mode Global Config

Default 20
Format spanning-tree max-hops <1-127>
Mode Global Config

Format no spanning-tree max-hops
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-17

v1.0, July 2009

If you specify the cost option, the command sets the path cost for this port within a multiple
spanning tree instance or the common and internal spanning tree instance, depending on the
<mstid> parameter. You can set the path cost as a number in the range of 1 to 200000000 or
auto. If you select auto the path cost value is set based on Link Speed.

If you specify the external-cost option, this command sets the external-path cost for MST instance
‘0’ i.e. CIST instance. You can set the external cost as a number in the range of 1 to 200000000 or
auto. If you specify auto, the external path cost value is set based on Link Speed.

If you specify the port-priority option, this command sets the priority for this port within a
specific multiple spanning tree instance or the common and internal spanning tree instance,
depending on the <mstid> parameter. The port-priority value is a number in the range of 0 to 240
in increments of 16.

no spanning-tree mst

This command sets the Path Cost or Port Priority for this port within the multiple spanning tree
instance, or in the common and internal spanning tree to the respective default values. If you
specify an <mstid> parameter that corresponds to an existing multiple spanning tree instance,
you are configuring that multiple spanning tree instance. If you specify 0 (defined as the default
CIST ID) as the <mstid>, you are configuring the common and internal spanning tree instance.

If the you specify cost, this command sets the path cost for this port within a multiple spanning
tree instance or the common and internal spanning tree instance, depending on the <mstid>
parameter, to the default value, i.e. a path cost value based on the Link Speed.

If you specify external-cost, this command sets the external path cost for this port for mst ‘0’
instance, to the default value, i.e. a path cost value based on the Link Speed.

If you specify port-priority, this command sets the priority for this port within a specific multiple
spanning tree instance or the common and internal spanning tree instance, depending on the
<mstid> parameter, to the default value.

Default • cost—auto

• external-cost—auto

• port-priority—128

Format spanning-tree mst

<mstid> {{cost <1-200000000> | auto} | {external-

cost <1-200000000> | auto} | port-priority <0-240>}

Mode Interface Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-18

v1.0, July 2009

spanning-tree mst instance

This command adds a multiple spanning tree instance to the switch. The parameter <mstid> is a
number within a range of 1 to 4094, that corresponds to the new instance ID to be added. The
maximum number of multiple instances supported by the switch is 4.

no spanning-tree mst instance

This command removes a multiple spanning tree instance from the switch and reallocates all
VLANs allocated to the deleted instance to the common and internal spanning tree. The parameter
<mstid> is a number that corresponds to the desired existing multiple spanning tree instance to
be removed.

spanning-tree mst priority

This command sets the bridge priority for a specific multiple spanning tree instance. The
parameter <mstid> is a number that corresponds to the desired existing multiple spanning tree
instance. The priority value is a number within a range of 0 to 61440 in increments of 4096.

Format no spanning-tree mst <mstid> <cost | external-cost | port-priority>
Mode Interface Config

Default none
Format spanning-tree mst instance <mstid>
Mode Global Config

Format no spanning-tree mst instance <mstid>
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-19

v1.0, July 2009

If you specify 0 (defined as the default CIST ID) as the <mstid>, this command sets the Bridge
Priority parameter to a new value for the common and internal spanning tree. The bridge priority
value is a number within a range of 0 to 61440. The twelve least significant bits are masked
according to the 802.1s specification. This causes the priority to be rounded down to the next
lower valid priority.

no spanning-tree mst priority

This command sets the bridge priority for a specific multiple spanning tree instance to the default
value. The parameter <mstid> is a number that corresponds to the desired existing multiple
spanning tree instance.

If 0 (defined as the default CIST ID) is passed as the <mstid>, this command sets the Bridge
Priority parameter for the common and internal spanning tree to the default value.

spanning-tree mst vlan

This command adds an association between a multiple spanning tree instance and one or more
VLANs so that the VLAN(s) are no longer associated with the common and internal spanning tree.
The parameter <mstid> is a number that corresponds to the desired existing multiple spanning
tree instance. The vlan range can be specified as a list or as a range of values. To specify a list of
VLANs, enter a list of VLAN IDs, each separated by a comma with no spaces in between. To
specify a range of VLANs, separate the beginning and ending VLAN ID with a dash ("-").

Default 32768
Format spanning-tree mst priority

<mstid> <0-61440>

Mode Global Config

Format no spanning-tree mst priority

<mstid>

Mode Global Config

Format spanning-tree mst vlan <mstid> <vlanid>
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-20

v1.0, July 2009

no spanning-tree mst vlan

This command removes an association between a multiple spanning tree instance and one or more
VLANs so that the VLAN(s) are again associated with the common and internal spanning tree.

spanning-tree port mode

This command sets the Administrative Switch Port State for this port to enabled.

no spanning-tree port mode

This command sets the Administrative Switch Port State for this port to disabled.

spanning-tree port mode all

This command sets the Administrative Switch Port State for all ports to enabled.

Format no spanning-tree mst vlan <mstid> <vlanid>
Mode Global Config

Default disabled
Format spanning-tree port mode
Mode Interface Config

Format no spanning-tree port mode
Mode Interface Config

Default disabled
Format spanning-tree port mode all
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-21

v1.0, July 2009

no spanning-tree port mode all

This command sets the Administrative Switch Port State for all ports to disabled.

spanning-tree edgeport all

This command specifies that every port is an Edge Port within the common and internal spanning
tree. This allows all ports to transition to Forwarding State without delay.

no spanning-tree edgeport all

This command disables Edge Port mode for all ports within the common and internal spanning
tree.

spanning-tree bpduforwarding

Normally a switch will not forward Spanning Tree Protocol (STP) BPDU packets if STP is
disabled. However, if in some network setup, the user wishes to forward BDPU packets received
from other network devices, this command can be used to enable the forwarding.

Format no spanning-tree port mode all
Mode Global Config

Format spanning-tree edgeport all
Mode Global Config

Format no spanning-tree edgeport all
Mode Global Config

Default 2
Format spanning-tree bpduforwarding
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-22

v1.0, July 2009

no spanning-tree bpduforwarding

This command will cause the STP BPDU packets received from the network to be dropped if STP
is disabled.

show spanning-tree

This command displays spanning tree settings for the common and internal spanning tree. The
following details are displayed.

Format no spanning-tree bpduforwarding
Mode Global Config

Format show spanning-tree
Mode • Privileged EXEC

• User EXEC

Term Definition
Bridge Priority Specifies the bridge priority for the Common and Internal Spanning tree (CST). The

value lies between 0 and 61440. It is displayed in multiples of 4096.

Bridge Identifier The bridge identifier for the CST. It is made up using the bridge priority and the base

MAC address of the bridge.

Time Since
Topology
Change

Time in seconds.

Topology
Change Count

Number of times changed.

Topology
Change

Boolean value of the Topology Change parameter for the switch indicating if a topology
change is in progress on any port assigned to the common and internal spanning tree.

Designated
Root

The bridge identifier of the root bridge. It is made up from the bridge priority and the base
MAC address of the bridge.

Root Path Cost Value of the Root Path Cost parameter for the common and internal spanning tree.
Root Port

Identifier

Identifier of the port to access the Designated Root for the CST

Root Port Max
Age

Derived value.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-23

v1.0, July 2009

show spanning-tree brief

This command displays spanning tree settings for the bridge. The following information appears.

Root Port
Bridge Forward
Delay

Derived value.

Hello Time Configured value of the parameter for the CST.
Bridge Hold

Time

Minimum time between transmission of Configuration Bridge Protocol Data Units
(BPDUs).

Bridge Max
Hops

Bridge max-hops count for the device.

CST Regional
Root

Bridge Identifier of the CST Regional Root. It is made up using the bridge priority and the
base MAC address of the bridge.

Regional Root
Path Cost

Path Cost to the CST Regional Root.

Associated
FIDs

List of forwarding database identifiers currently associated with this instance.

Associated
VLANs

List of VLAN IDs currently associated with this instance.

Format show spanning-tree brief
Mode • Privileged EXEC

• User EXEC

Term Definition
Bridge Priority Configured value.

Bridge Identifier The bridge identifier for the selected MST instance. It is made up using the

bridge priority and the base MAC address of the bridge.

Bridge Max Age Configured value.
Bridge Max Hops Bridge max-hops count for the device.
Bridge Hello Time Configured value.
Bridge Forward Delay Configured value.
Bridge Hold Time Minimum time between transmission of Configuration Bridge Protocol Data

Units (BPDUs).

Term Definition

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-24

v1.0, July 2009

show spanning-tree interface

This command displays the settings and parameters for a specific switch port within the common
and internal spanning tree. The <unit/slot/port> is the desired switch port. The following
details are displayed on execution of the command.

Format show spanning-tree interface <unit/slot/port>
Mode • Privileged EXEC

• User EXEC

Term Definition
Hello Time Admin hello time for this port.

Port Mode Enabled or disabled.
BPDU Guard Effect Enabled or disabled.
Root Guard Enabled or disabled.
Loop Guard Enabled or disabled.
TCN Guard Enable or disable the propagation of received topology change notifications and

topology changes to other ports.

BPDU Filter Mode Enabled or disabled.
BPDU Flood Mode Enabled or disabled.
Auto Edge To enable or disable the feature that causes a port that has not seen a BPDU for

‘edge delay’ time, to become an edge port and transition to forwarding faster.

Port Up Time Since
Counters Last Cleared

Time since port was reset, displayed in days, hours, minutes, and seconds.

STP BPDUs
Transmitted

Spanning Tree Protocol Bridge Protocol Data Units sent.

STP BPDUs Received Spanning Tree Protocol Bridge Protocol Data Units received.
RSTP BPDUs

Transmitted

Rapid Spanning Tree Protocol Bridge Protocol Data Units sent.

RSTP BPDUs Received Rapid Spanning Tree Protocol Bridge Protocol Data Units received.
MSTP BPDUs

Transmitted

Multiple Spanning Tree Protocol Bridge Protocol Data Units sent.

MSTP BPDUs Received Multiple Spanning Tree Protocol Bridge Protocol Data Units received.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-25

v1.0, July 2009

show spanning-tree mst port detailed

This command displays the detailed settings and parameters for a specific switch port within a
particular multiple spanning tree instance. The parameter <mstid> is a number that corresponds
to the desired existing multiple spanning tree instance. The <unit/slot/port> is the desired
switch port.

Format show spanning-tree mst port detailed <mstid> <unit/slot/port>
Mode • Privileged EXEC

• User EXEC

Term Definition
MST Instance ID The ID of the existing MST instance.

Port Identifier The port identifier for the specified port within the selected MST instance. It is made up

from the port priority and the interface number of the port.

Port Priority The priority for a particular port within the selected MST instance. The port priority is

displayed in multiples of 16.

Port Forwarding
State

Current spanning tree state of this port.

Port Role Each enabled MST Bridge Port receives a Port Role for each spanning tree. The port

role is one of the following values: Root Port, Designated Port, Alternate Port, Backup
Port, Master Port or Disabled Port

Auto-Calculate
Port Path Cost

Indicates whether auto calculation for port path cost is enabled.

Port Path Cost Configured value of the Internal Port Path Cost parameter.
Designated

Root

The Identifier of the designated root for this port.

Root Path Cost The path cost to get to the root bridge for this instance. The root path cost is zero if the

bridge is the root bridge for that instance.

Designated
Bridge

Bridge Identifier of the bridge with the Designated Port.

Designated Port
Identifier

Port on the Designated Bridge that offers the lowest cost to the LAN.

Loop
Inconsistent
State

The current loop inconsistent state of this port in this MST instance. When in loop
inconsistent state, the port has failed to receive BPDUs while configured with loop guard
enabled. Loop inconsistent state maintains the port in a "blocking" state until a
subsequent BPDU is received.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-26

v1.0, July 2009

If you specify 0 (defined as the default CIST ID) as the <mstid>, this command displays the
settings and parameters for a specific switch port within the common and internal spanning tree.
The <unit/slot/port> is the desired switch port. In this case, the following are displayed.

Transitions Into
Loop
Inconsistent
State

The number of times this interface has transitioned into loop inconsistent state.

Transitions Out
of Loop
Inconsistent
State

The number of times this interface has transitioned out of loop inconsistent state.

Term Definition
Port Identifier The port identifier for this port within the CST.

Port Priority The priority of the port within the CST.
Port Forwarding

State

The forwarding state of the port within the CST.

Port Role The role of the specified interface within the CST.
Auto-Calculate

Port Path Cost

Indicates whether auto calculation for port path cost is enabled or not (disabled).

Port Path Cost The configured path cost for the specified interface.
Auto-Calculate

External Port
Path Cost

Indicates whether auto calculation for external port path cost is enabled.

External Port
Path Cost

The cost to get to the root bridge of the CIST across the boundary of the region. This
means that if the port is a boundary port for an MSTP region, then the external path cost
is used.

Designated
Root

Identifier of the designated root for this port within the CST.

Root Path Cost The root path cost to the LAN by the port.
Designated

Bridge

The bridge containing the designated port.

Designated Port
Identifier

Port on the Designated Bridge that offers the lowest cost to the LAN.

Term Definition

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-27

v1.0, July 2009

show spanning-tree mst port summary

This command displays the settings of one or all ports within the specified multiple spanning tree
instance. The parameter <mstid> indicates a particular MST instance. The parameter {<unit/
slot/port> | all} indicates the desired switch port or all ports.

If you specify 0 (defined as the default CIST ID) as the <mstid>, the status summary displays for
one or all ports within the common and internal spanning tree.

Topology
Change
Acknowledgem
ent

Value of flag in next Configuration Bridge Protocol Data Unit (BPDU) transmission
indicating if a topology change is in progress for this port.

Hello Time The hello time in use for this port.
Edge Port The configured value indicating if this port is an edge port.
Edge Port

Status

The derived value of the edge port status. True if operating as an edge port; false
otherwise.

Point To Point
MAC Status

Derived value indicating if this port is part of a point to point link.

CST Regional
Root

The regional root identifier in use for this port.

CST Internal
Root Path Cost

The internal root path cost to the LAN by the designated external port.

Loop
Inconsistent
State

The current loop inconsistent state of this port in this MST instance. When in loop
inconsistent state, the port has failed to receive BPDUs while configured with loop guard
enabled. Loop inconsistent state maintains the port in a "blocking" state until a
subsequent BPDU is received.

Transitions Into
Loop
Inconsistent
State

The number of times this interface has transitioned into loop inconsistent state.

Transitions Out
of Loop
Inconsistent
State

The number of times this interface has transitioned out of loop inconsistent state.

Format show spanning-tree mst port summary

<mstid> {<unit/slot/port> | all}

Mode • Privileged EXEC

• User EXEC

Term Definition

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-28

v1.0, July 2009

show spanning-tree mst summary

This command displays summary information about all multiple spanning tree instances in the
switch. On execution, the following details are displayed.

Term Definition
MST Instance ID The MST instance associated with this port.

Interface Valid unit, slot, and port number separated by forward slashes.
STP Mode Indicates whether spanning tree is enabled or disabled on the port.
Type Currently not used.
STP State The forwarding state of the port in the specified spanning tree instance.
Port Role The role of the specified port within the spanning tree.

Desc Indicates whether the port is in loop inconsistent state or not. This field is blank if the loop

guard feature is not available.

Format show spanning-tree mst summary
Mode • Privileged EXEC

• User EXEC

Term Definition
MST Instance ID

List

List of multiple spanning trees IDs currently configured.

For each
MSTID:

• Associated
FIDs

• Associated
VLANs

• List of forwarding database identifiers associated with this instance.

• List of VLAN IDs associated with this instance.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-29

v1.0, July 2009

show spanning-tree summary

This command displays spanning tree settings and parameters for the switch. The following details
are displayed on execution of the command.

show spanning-tree vlan

This command displays the association between a VLAN and a multiple spanning tree instance.
The <vlanid> corresponds to an existing VLAN ID.

Format show spanning-tree summary
Mode • Privileged EXEC

• User EXEC

Term Definition
Spanning Tree

Adminmode

Enabled or disabled.

Spanning Tree
Version

Version of 802.1 currently supported (IEEE 802.1s, IEEE 802.1w, or IEEE 802.1d) based
upon the Force Protocol Version parameter.

BPDU Guard
Mode

Enabled or disabled.

BPDU Filter
Mode

Enabled or disabled.

Configuration
Name

Identifier used to identify the configuration currently being used.

Configuration
Revision Level

Identifier used to identify the configuration currently being used.

Configuration
Digest Key

A generated Key used in the exchange of the BPDUs.

Configuration
Format Selector

Specifies the version of the configuration format being used in the exchange of BPDUs.
The default value is zero.

MST Instances List of all multiple spanning tree instances configured on the switch.

Format show spanning-tree vlan <vlanid>
Mode • Privileged EXEC

• User EXEC

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-30

v1.0, July 2009

VLAN Commands

This section describes the commands you use to configure VLAN settings.

vlan database

This command gives you access to the VLAN Config mode, which allows you to configure VLAN
characteristics.

network mgmt_vlan

This command configures the Management VLAN ID.

no network mgmt_vlan

This command sets the Management VLAN ID to the default.

Term Definition
VLAN Identifier The VLANs associated with the selected MST instance.

Associated
Instance

Identifier for the associated multiple spanning tree instance or “CST” if associated with
the common and internal spanning tree.

Format vlan database
Mode Privileged EXEC

Default 1
Format network mgmt_vlan <1-4093>
Mode Privileged EXEC

Format no network mgmt_vlan
Mode Privileged EXEC

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-31

v1.0, July 2009

vlan

This command creates a new VLAN and assigns it an ID. The ID is a valid VLAN identification
number (ID 1 is reserved for the default VLAN). The vlan-list contains VlanId's in range <1­4093>. Separate non-consecutive IDs with ',' and no spaces and no zeros in between the range; Use
'-' for range.

no vlan

This command deletes an existing VLAN. The ID is a valid VLAN identification number (ID 1 is
reserved for the default VLAN). The vlan-list contains VlanId's in range <1-4093>. Separate non­consecutive IDs with ',' and no spaces and no zeros in between the range; Use '-' for range.

vlan acceptframe

This command sets the frame acceptance mode per interface. For VLAN Only mode, untagged
frames or priority frames received on this interface are discarded. For Admit All mode, untagged
frames or priority frames received on this interface are accepted and assigned the value of the
interface VLAN ID for this port. With either option, VLAN tagged frames are forwarded in
accordance with the IEEE 802.1Q VLAN Specification.

Format vlan <vlan-list>
Mode VLAN Config

Format no vlan <vlan-list>
Mode VLAN Config

Default all
Format vlan acceptframe {vlanonly | all}
Mode Interface Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-32

v1.0, July 2009

no vlan acceptframe

This command resets the frame acceptance mode for the interface to the default value.

vlan ingressfilter

This command enables ingress filtering. If ingress filtering is disabled, frames received with
VLAN IDs that do not match the VLAN membership of the receiving interface are admitted and
forwarded to ports that are members of that VLAN.

no vlan ingressfilter

This command disables ingress filtering. If ingress filtering is disabled, frames received with
VLAN IDs that do not match the VLAN membership of the receiving interface are admitted and
forwarded to ports that are members of that VLAN.

vlan makestatic

This command changes a dynamically created VLAN (one that is created by GVRP registration) to
a static VLAN (one that is permanently configured and defined). The ID is a valid VLAN
identification number. VLAN range is 2-4093.

Format no vlan acceptframe
Mode Interface Config

Default disabled
Format vlan ingressfilter
Mode Interface Config

Format no vlan ingressfilter
Mode Interface Config

Format vlan makestatic <2-4093>
Mode VLAN Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-33

v1.0, July 2009

vlan name

This command changes the name of a VLAN. The name is an alphanumeric string of up to 32
characters, and the ID is a valid VLAN identification number. ID range is 1-4093.

no vlan name

This command sets the name of a VLAN to a blank string.

vlan participation

This command configures the degree of participation for a specific interface in a VLAN. The ID is
a valid VLAN identification number, and the interface is a valid interface number.

Participation options are:

Default • VLAN ID 1 - default

• other VLANS - blank string

Format vlan name <1-4093> <name>
Mode VLAN Config

Format no vlan name <1-4093>
Mode VLAN Config

Format vlan participation {exclude | include | auto} <1-4093>
Mode Interface Config

Participation
Options

Definition

include The interface is always a member of this VLAN. This is equivalent to registration fixed.
exclude The interface is never a member of this VLAN. This is equivalent to registration

forbidden.

auto The interface is dynamically registered in this VLAN by GVRP. The interface will not

participate in this VLAN unless a join request is received on this interface. This is
equivalent to registration normal.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-34

v1.0, July 2009

vlan participation all

This command configures the degree of participation for all interfaces in a VLAN. The ID is a
valid VLAN identification number.

You can use the following participation options:

vlan port acceptframe all

This command sets the frame acceptance mode for all interfaces.

The modes defined as follows:

With either option, VLAN tagged frames are forwarded in accordance with the IEEE 802.1Q
VLAN Specification.

Format vlan participation all {exclude | include | auto} <1-4093>
Mode Global Config

Participation
Options

Definition

include The interface is always a member of this VLAN. This is equivalent to registration fixed.
exclude The interface is never a member of this VLAN. This is equivalent to registration

forbidden.

auto The interface is dynamically registered in this VLAN by GVRP. The interface will not

participate in this VLAN unless a join request is received on this interface. This is
equivalent to registration normal.

Default all
Format vlan port acceptframe all {vlanonly | all}
Mode Global Config

Mode Definition
VLAN Only

mode

Untagged frames or priority frames received on this interface are discarded.

Admit All mode Untagged frames or priority frames received on this interface are accepted and assigned

the value of the interface VLAN ID for this port.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-35

v1.0, July 2009

no vlan port acceptframe all

This command sets the frame acceptance mode for all interfaces to Admit All. For Admit All
mode, untagged frames or priority frames received on this interface are accepted and assigned the
value of the interface VLAN ID for this port. With either option, VLAN tagged frames are
forwarded in accordance with the IEEE 802.1Q VLAN Specification.

vlan port ingressfilter all

This command enables ingress filtering for all ports. If ingress filtering is disabled, frames
received with VLAN IDs that do not match the VLAN membership of the receiving interface are
admitted and forwarded to ports that are members of that VLAN.

no vlan port ingressfilter all

This command disables ingress filtering for all ports. If ingress filtering is disabled, frames
received with VLAN IDs that do not match the VLAN membership of the receiving interface are
admitted and forwarded to ports that are members of that VLAN.

vlan port pvid all

This command changes the VLAN ID for all interface.

Format no vlan port acceptframe all
Mode Global Config

Default disabled
Format vlan port ingressfilter all
Mode Global Config

Format no vlan port ingressfilter all
Mode Global Config

Default 1
Format vlan port pvid all <1-4093>
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-36

v1.0, July 2009

no vlan port pvid all

This command sets the VLAN ID for all interfaces to 1.

vlan port tagging all

This command configures the tagging behavior for all interfaces in a VLAN to enabled. If tagging
is enabled, traffic is transmitted as tagged frames. If tagging is disabled, traffic is transmitted as
untagged frames. The ID is a valid VLAN identification number.

no vlan port tagging all

This command configures the tagging behavior for all interfaces in a VLAN to disabled. If tagging
is disabled, traffic is transmitted as untagged frames. The ID is a valid VLAN identification
number.

vlan protocol group

This command adds protocol-based VLAN groups to the system. The <groupName> is a
character string of 1 to 16 characters. When it is created, the protocol group will be assigned a
unique number that will be used to identify the group in subsequent commands.

Format no vlan port pvid all
Mode Global Config

Format vlan port tagging all <1-4093>
Mode Global Config

Format no vlan port tagging all
Mode Global Config

Format vlan protocol group <groupname>
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-37

v1.0, July 2009

vlan protocol group add protocol

This command adds the <protocol> to the protocol-based VLAN identified by <groupid>.
A group may have more than one protocol associated with it. Each interface and protocol
combination can only be associated with one group. If adding a protocol to a group causes any
conflicts with interfaces currently associated with the group, this command fails and the protocol
is not added to the group. The possible values for protocol are ip, arp, and ipx.

no vlan protocol group add protocol

This command removes the <protocol> from this protocol-based VLAN group that is
identified by this <groupid>. The possible values for protocol are ip, arp, and ipx.

vlan protocol group remove

This command removes the protocol-based VLAN group that is identified by this <groupid>.

protocol group

This command attaches a <vlanid> to the protocol-based VLAN identified by <groupid>.
A group may only be associated with one VLAN at a time, however the VLAN association can be
changed.

Default none
Format vlan protocol group add protocol <groupid> <protocol>
Mode Global Config

Format no vlan protocol group add protocol <groupid> <protocol>
Mode Global Config

Format vlan protocol group remove <groupid>
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-38

v1.0, July 2009

no protocol group

This command removes the <vlanid> from this protocol-based VLAN group that is identified
by this <groupid>.

protocol vlan group

This command adds the physical interface to the protocol-based VLAN identified by
<groupid>. You can associate multiple interfaces with a group, but you can only associate each
interface and protocol combination with one group. If adding an interface to a group causes any
conflicts with protocols currently associated with the group, this command fails and the
interface(s) are not added to the group.

no protocol vlan group

This command removes the interface from this protocol-based VLAN group that is identified by
this <groupid>.

Default none
Format protocol group <groupid> <vlanid>
Mode VLAN Config

Format no protocol group <groupid> <vlanid>
Mode VLAN Config

Default none
Format protocol vlan group <groupid>
Mode Interface Config

Format no protocol vlan group <groupid>
Mode Interface Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-39

v1.0, July 2009

protocol vlan group all

This command adds all physical interfaces to the protocol-based VLAN identified by
<groupid>. You can associate multiple interfaces with a group, but you can only associate each
interface and protocol combination with one group. If adding an interface to a group causes any
conflicts with protocols currently associated with the group, this command will fail and the
interface(s) will not be added to the group.

no protocol vlan group all

This command removes all interfaces from this protocol-based VLAN group that is identified by
this <groupid>.

vlan pvid

This command changes the VLAN ID per interface.

no vlan pvid

This command sets the VLAN ID per interface to 1.

Default none
Format protocol vlan group all <groupid>
Mode Global Config

Format no protocol vlan group all <groupid>
Mode Global Config

Default 1
Format vlan pvid <1-4093>
Mode Interface Config

Format no vlan pvid
Mode Interface Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-40

v1.0, July 2009

vlan tagging

This command configures the tagging behavior for a specific interface in a VLAN to enabled. If
tagging is enabled, traffic is transmitted as tagged frames. If tagging is disabled, traffic is
transmitted as untagged frames. The vlan-list contains VlanId's in range <1-4093>. Separate non­consecutive IDs with ',' and no spaces and no zeros in between the range; Use '-' for range.

no vlan tagging

This command configures the tagging behavior for a specific interface in a VLAN to disabled. If
tagging is disabled, traffic is transmitted as untagged frames. The vlan-list contains VlanId's in
range <1-4093>. Separate non-consecutive IDs with ',' and no spaces and no zeros in between the
range; Use '-' for range.

vlan association subnet

This command associates a VLAN to a specific IP-subnet.

no vlan association subnet

This command removes association of a specific IP-subnet to a VLAN.

Format vlan tagging <vlan-list>
Mode Interface Config

Format no vlan tagging <vlan-list>
Mode Interface Config

Format vlan association subnet <ipaddr> <netmask> <1-4093>
Mode VLAN Config

Format no vlan association subnet <ipaddr> <netmask>
Mode VLAN Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-41

v1.0, July 2009

vlan association mac

This command associates a MAC address to a VLAN.

no vlan association mac

This command removes the association of a MAC address to a VLAN.

show vlan

This command displays a list of all configured VLAN

.

show vlan <vlanid>

This command displays detailed information, including interface information, for a specific
VLAN. The ID is a valid VLAN identification number.

Format vlan association mac <macaddr> <1-4093>
Mode VLAN database

Format no vlan association mac

<macaddr>

Mode VLAN database

Format show vlan
Mode • Privileged EXEC

• User EXEC

Term Definition
VLAN ID There is a VLAN Identifier (VID) associated with each VLAN. The range of the VLAN ID

is 1 to 4093.

VLAN Name A string associated with this VLAN as a convenience. It can be up to 32 alphanumeric

characters long, including blanks. The default is blank. VLAN ID 1 always has a name of
“Default.” This field is optional.

VLAN Type Type of VLAN, which can be Default (VLAN ID = 1) or static (one that is configured and

permanently defined), or Dynamic (one that is created by GVRP registration).

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-42

v1.0, July 2009

show vlan brief

This command displays a list of all configured VLANs.

Format show vlan <vlanid>
Mode • Privileged EXEC

• User EXEC

Term Definition
VLAN ID There is a VLAN Identifier (VID) associated with each VLAN. The range of the VLAN ID

is 1 to 3965.

VLAN Name A string associated with this VLAN as a convenience. It can be up to 32 alphanumeric

characters long, including blanks. The default is blank. VLAN ID 1 always has a name of
“Default.” This field is optional.

VLAN Type Type of VLAN, which can be Default (VLAN ID = 1) or static (one that is configured and

permanently defined), or Dynamic (one that is created by GVRP registration).

Interface Valid unit, slot, and port number separated by forward slashes. It is possible to set the

parameters for all ports by using the selectors on the top line.

Current The degree of participation of this port in this VLAN. The permissible values are:

• Include - This port is always a member of this VLAN. This is equivalent to registration
fixed in the IEEE 802.1Q standard.

• Exclude - This port is never a member of this VLAN. This is equivalent to registration
forbidden in the IEEE 802.1Q standard.

• Autodetect - To allow the port to be dynamically registered in this VLAN via GVRP. The
port will not participate in this VLAN unless a join request is received on this port. This
is equivalent to registration normal in the IEEE 802.1Q standard.

Configured The configured degree of participation of this port in this VLAN. The permissible values

are:

• Include - This port is always a member of this VLAN. This is equivalent to registration
fixed in the IEEE 802.1Q standard.

• Exclude - This port is never a member of this VLAN. This is equivalent to registration
forbidden in the IEEE 802.1Q standard.

• Autodetect - To allow the port to be dynamically registered in this VLAN via GVRP. The
port will not participate in this VLAN unless a join request is received on this port. This
is equivalent to registration normal in the IEEE 802.1Q standard.

Tagging The tagging behavior for this port in this VLAN.

• Tagged - Transmit traffic for this VLAN as tagged frames.

• Untagged - Transmit traffic for this VLAN as untagged frames.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-43

v1.0, July 2009

show vlan port

This command displays VLAN port information.

Format show vlan brief
Mode • Privileged EXEC

• User EXEC

Term Definition
VLAN ID There is a VLAN Identifier (vlanid) associated with each VLAN. The range of the VLAN

ID is 1 to 3965.

VLAN Name A string associated with this VLAN as a convenience. It can be up to 32 alphanumeric

characters long, including blanks. The default is blank. VLAN ID 1 always has a name of
“Default.” This field is optional.

VLAN Type Type of VLAN, which can be Default (VLAN ID = 1) or static (one that is configured and

permanently defined), or a Dynamic (one that is created by GVRP registration).

Format show vlan port {<unit/slot/port> | all}
Mode • Privileged EXEC

• User EXEC

Term Definition
Interface Valid unit, slot, and port number separated by forward slashes. It is possible to set the

parameters for all ports by using the selectors on the top line.

Port VLAN ID The VLAN ID that this port will assign to untagged frames or priority tagged frames

received on this port. The value must be for an existing VLAN. The factory default is 1.

Acceptable
Frame Types

The types of frames that may be received on this port. The options are 'VLAN only' and
'Admit All'. When set to 'VLAN only', untagged frames or priority tagged frames received
on this port are discarded. When set to 'Admit All', untagged frames or priority tagged
frames received on this port are accepted and assigned the value of the Port VLAN ID for
this port. With either option, VLAN tagged frames are forwarded in accordance to the

802.1Q VLAN specification.

Ingress
Filtering

May be enabled or disabled. When enabled, the frame is discarded if this port is not a
member of the VLAN with which this frame is associated. In a tagged frame, the VLAN is
identified by the VLAN ID in the tag. In an untagged frame, the VLAN is the Port VLAN ID
specified for the port that received this frame. When disabled, all frames are forwarded in
accordance with the 802.1Q VLAN bridge specification. The factory default is disabled.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-44

v1.0, July 2009

show vlan association subnet

This command displays the VLAN associated with a specific configured IP-Address and net mask.
If no IP address and net mask are specified, the VLAN associations of all the configured IP­subnets are displayed.

show vlan association mac

This command displays the VLAN associated with a specific configured MAC address. If no
MAC address is specified, the VLAN associations of all the configured MAC addresses are
displayed.

GVRP May be enabled or disabled.
Default Priority The 802.1p priority assigned to tagged packets arriving on the port.

Format show vlan association subnet [<ipaddr> <netmask>]
Mode Privileged EXEC

Term Definition
IP Subnet The IP address assigned to each interface.

IP Mask The subnet mask.
VLAN ID There is a VLAN Identifier (VID) associated with each VLAN.

Format show vlan association mac [<macaddr>]
Mode Privileged EXEC

Term Definition
MAC Address A MAC address for which the switch has forwarding and or filtering information. The

format is 6 or 8 two-digit hexadecimal numbers that are separated by colons, for example
01:23:45:67:89:AB. In an IVL system the MAC address will be displayed as 8 bytes.

VLAN ID There is a VLAN Identifier (VID) associated with each VLAN.

Term Definition

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-45

v1.0, July 2009

Double VLAN Commands

This section describes the commands you use to configure double VLAN (DVLAN). Double
VLAN tagging is a way to pass VLAN traffic from one customer domain to another through a
Metro Core in a simple and cost effective manner. The additional tag on the traffic helps
differentiate between customers in the MAN while preserving the VLAN identification of the
individual customers when they enter their own 802.1Q domain.

dvlan-tunnel ethertype

This command configures the ether-type for all interfaces. The ether-type may have the values of

802.1Q, vMAN, or custom. If the ether-type has a value of custom, the optional value of the
custom ether type must be set to a value from 0 to 65535.

mode dot1q-tunnel

This command is used to enable Double VLAN Tunneling on the specified interface.

no mode dot1q-tunnel

This command is used to disable Double VLAN Tunneling on the specified interface. By default,
Double VLAN Tunneling is disabled.

Default vman
Format dvlan-tunnel ethertype {802.1Q | vman | custom} [0-65535]
Mode Global Config

Default disabled
Format mode dot1q-tunnel
Mode Interface Config

Format no mode dot1q-tunnel
Mode Interface Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-46

v1.0, July 2009

mode dvlan-tunnel

Use this command to enable Double VLAN Tunneling on the specified interface.

no mode dvlan-tunnel

This command is used to disable Double VLAN Tunneling on the specified interface. By default,
Double VLAN Tunneling is disabled.

show dot1q-tunnel

Use this command without the optional parameters to display all interfaces enabled for Double
VLAN Tunneling. Use the optional parameters to display detailed information about Double
VLAN Tunneling for the specified interface or all interfaces.

Note: When you use the mode dvlan-tunnel command on an interface, it becomes

a service provider port. Ports that do not have double VLAN tunneling enabled are
customer ports.

Default disabled
Format mode dvlan-tunnel
Mode Interface Config

Format no mode dvlan-tunnel
Mode Interface Config

Format show dot1q-tunnel [interface {<unit/slot/port> | all}]
Mode • Privileged EXEC

• User EXEC

Term Definition
Interface Valid unit, slot, and port number separated by forward slashes.

Mode The administrative mode through which Double VLAN Tunneling can be enabled or

disabled. The default value for this field is disabled.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-47

v1.0, July 2009

show dvlan-tunnel

Use this command without the optional parameters to display all interfaces enabled for Double
VLAN Tunneling. Use the optional parameters to display detailed information about Double
VLAN Tunneling for the specified interface or all interfaces.

Voice VLAN Commands

This section describes the commands you use for Voice VLAN. Voice VLAN enables switch ports
to carry voice traffic with defined priority so as to enable separation of voice and data traffic
coming onto the port. The benefits of using Voice VLAN is to ensure that the sound quality of an
IP phone could be safeguarded from deteriorating when the data traffic on the port is high.

EtherType A 2-byte hex EtherType to be used as the first 16 bits of the DVLAN tunnel. There are

three different EtherType tags. The first is 802.1Q, which represents the commonly used
value of 0x8100. The second is vMAN, which represents the commonly used value of
0x88A8. If EtherType is not one of these two values, then it is a custom tunnel value,
representing any value in the range of 0 to 65535.

Format show dvlan-tunnel [interface {<unit/slot/port> | all}]
Mode • Privileged EXEC

• User EXEC

Term Definition
Interface Valid unit, slot, and port number separated by forward slashes.

Mode The administrative mode through which Double VLAN Tunneling can be enabled or

disabled. The default value for this field is disabled.

EtherType A 2-byte hex EtherType to be used as the first 16 bits of the DVLAN tunnel. There are

three different EtherType tags. The first is 802.1Q, which represents the commonly used
value of 0x8100. The second is vMAN, which represents the commonly used value of
0x88A8. If EtherType is not one of these two values, then it is a custom tunnel value,
representing any value in the range of 0 to 65535.

Term Definition

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-48

v1.0, July 2009

Also the inherent isolation provided by VLANs ensures that inter-VLAN traffic is under
management control and that network- attached clients cannot initiate a direct attack on voice
components. QoS-based on IEEE 802.1P class of service (CoS) uses classification and scheduling
to sent network traffic from the switch in a predictable manner. The system uses the source MAC
of the traffic traveling through the port to identify the IP phone data flow.

voice vlan (Global Config)

Use this command to enable the Voice VLAN capability on the switch.

no voice vlan (Global Config)

Use this command to disable the Voice VLAN capability on the switch.

voice vlan (Interface Config)

Use this command to enable the Voice VLAN capability on the interface.

You can configure Voice VLAN in one of three different ways:

Default disabled
Format voice vlan
Mode Global Config

Format no voice vlan
Mode Global Config

Default disabled
Format voice vlan {<id> | dot1p <priority> | none | untagged}
Mode Interface Config

Parameter Description
dot1p Configure the IP phone to use 802.1p priority tagging for voice traffic and to use the

default native VLAN (VLAN 0) to carry all traffic. Valid <priority> range is 0 to 7.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-49

v1.0, July 2009

no voice vlan (Interface Config)

Use this command to disable the Voice VLAN capability on the interface.

voice vlan data priority

Use this command to either trust or untrust the data traffic arriving on the Voice VLAN port.

show voice vlan

When the interface parameter is not specified, only the global mode of the Voice VLAN is
displayed.

When the interface is specified:

none Allow the IP phone to use its own configuration to send untagged voice traffic.
untagged Configure the phone to send untagged voice traffic.

Format no voice vlan
Mode Interface Config

Default trust
Format voice vlan data priority {untrust | trust}
Mode Interface Config

Format show voice vlan [interface {<unit/slot/port> | all}]
Mode Privileged EXEC

Term Definition
Administrative

Mode

The Global Voice VLAN mode.

Parameter Description

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-50

v1.0, July 2009

.

Provisioning (IEEE 802.1p) Commands

This section describes the commands you use to configure provisioning, which allows you to
prioritize ports.

vlan port priority all

This command configures the port priority assigned for untagged packets for all ports presently
plugged into the device. The range for the priority is 0-7. Any subsequent per port configuration
will override this configuration setting.

vlan priority

This command configures the default 802.1p port priority assigned for untagged packets for a
specific interface. The range for the priority is 0–7.

Term Definition
Voice VLAN Interface Mode The admin mode of the Voice VLAN on the interface.

Voice VLAN ID The Voice VLAN ID
Voice VLAN Priority The do1p priority for the Voice VLAN on the port.
Voice VLAN Untagged The tagging option for the Voice VLAN traffic.
Voice VLAN CoS Override The Override option for the voice traffic arriving on the port.
Voice VLAN Status The operational status of Voice VLAN on the port.

Format vlan port priority all <priority>
Mode Global Config

Default 0
Format vlan priority <priority>
Mode Interface Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-51

v1.0, July 2009

Protected Ports Commands

This section describes commands you use to configure and view protected ports on a switch.
Protected ports do not forward traffic to each other, even if they are on the same VLAN. However,
protected ports can forward traffic to all unprotected ports in their group. Unprotected ports can
forward traffic to both protected and unprotected ports. Ports are unprotected by default.

If an interface is configured as a protected port, and you add that interface to a Port Channel or
Link Aggregation Group (LAG), the protected port status becomes operationally disabled on the
interface, and the interface follows the configuration of the LAG port. However, the protected port
configuration for the interface remains unchanged. Once the interface is no longer a member of a
LAG, the current configuration for that interface automatically becomes effective.

switchport protected (Global Config)

Use this command to create a protected port group. The <groupid> parameter identifies the set
of protected ports. Use the name <name> pair to assign a name to the protected port group. The
name can be up to 32 alphanumeric characters long, including blanks. The default is blank.

no switchport protected (Global Config)

Use this command to remove a protected port group. The groupid parameter identifies the set of
protected ports. Use the name keyword to remove the name from the group.

Note: Port protection occurs within a single switch. Protected port configuration does not

affect traffic between ports on two different switches. No traffic forwarding is
possible between two protected ports.

Format switchport protected <groupid> name <name>
Mode Global Config

Format NO switchport protected <groupid> name
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-52

v1.0, July 2009

switchport protected (Interface Config)

Use this command to add an interface to a protected port group. The <groupid> parameter
identifies the set of protected ports to which this interface is assigned. You can only configure an
interface as protected in one group.

no switchport protected (Interface Config)

Use this command to configure a port as unprotected. The groupid parameter identifies the set
of protected ports to which this interface is assigned.

show switchport protected

This command displays the status of all the interfaces, including protected and unprotected
interfaces.

Note: Port protection occurs within a single switch. Protected port configuration does not

affect traffic between ports on two different switches. No traffic forwarding is
possible between two protected ports.

Default unprotected
Format switchport protected <groupid>
Mode Interface Config

Format no switchport protected <groupid>
Mode Interface Config

Format show switchport protected <groupid>
Mode • Privileged EXEC

• User EXEC

Term Definition
Group ID The number that identifies the protected port group.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-53

v1.0, July 2009

show interfaces switchport

This command displays the status of the interface (protected/unprotected) under the groupid.

Private Group Commands

This section describes commands used to configure private group and view private group
configuration information.

Private group can be used to create a group of ports that can or can not share traffic to each others
in the same VLAN group. The main application is to isolate a group of users from another without
using VLAN.

switchport private-group

This command is used to assign one port or a range of ports to private group <privategroup-name>
(or <private-group-id>).

The ingress traffic from a port in private group can be forwarded to other ports either in the same
private group or anyone in the same VLAN that are not in a private group.

Name An optional name of the protected port group. The name can be up to 32 alphanumeric

characters long, including blanks. The default is blank.

List of Physical
Ports

List of ports, which are configured as protected for the group identified with <groupid>. If
no port is configured as protected for this group, this field is blank.

Format show interfaces switchport <unit/slot/port> <groupid>
Mode • Privileged EXEC

• User EXEC

Term Definition
Name A string associated with this group as a convenience. It can be up to 32 alphanumeric

characters long, including blanks. The default is blank. This field is optional.

Protected port Indicates whether the interface is protected or not. It shows TRUE or FALSE. If the group

is a multiple groups then it shows TRUE in Group <groupid>.

Term Definition

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-54

v1.0, July 2009

By default, a port does not belong to any private group. A port cannot be in more than one private
group. An error message should return when that occurred. To change a port’s private group, first
the port must be removed from its private group.

no switchport private group

This command is used to remove the specified port from the given private group.

private-group name

This command is used to create a private group with name <private-group-name>. The name
string can be up to 24 bytes of non-blank characters. The total number of private groups is 192
such that the valid range for the ID is <1-192>.

The <private-group-id> field is optional. If not specified, a group id not used will be assigned
automatically.

The mode can be either “isolated” or “community”. When in “isolated” mode, the member port in
the group cannot forward its egress traffic to any other members in the same group. By default, the
mode is “community” mode that each member port can forward traffic to other members in the
same group, but not to members in other groups.

Default port not associated with any group.
Format switchport private-group [<privategroup-name>|<privategroup-id>]
Mode Interface Config

Format no switchport private-group [<privategroup-name>|<privategroup-id>]
Mode Interface Config

Format {<privategroup-name> mode [community|isolated]|<groupid>}
Mode Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-55

v1.0, July 2009

no private-group name

This command is used to remove the specified private group.

show private-group

This command displays the private groups’ information.

GARP Commands

This section describes the commands you use to configure Generic Attribute Registration Protocol
(GARP) and view GARP status. The commands in this section affect both GARP VLAN
Registration Protocol (GVRP) and Garp Multicast Registration Protocol (GMRP). GARP is a
protocol that allows client stations to register with the switch for membership in VLANS (by using
GVMP) or multicast groups (by using GVMP).

Format private-group name <privategroup-name>
Mode Global Config

Format show private-groupname [<private-group-name>|<private-group-

id>|port <unit/slot/port>]

Mode Priviledged EXEC

Term Definition
Interface Valid slot and port number separated by forward slashes.

Port VLANID

The VLAN ID associated with the port.

Private Group IDTotal number of private groups is 192.

Private Group
Name

The name string can be up to 24 bytes of non-blank characters

Private Group The mode can be either “isolated” or “community”.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-56

v1.0, July 2009

set garp timer join

This command sets the GVRP join time for one port (Interface Config mode) or all (Global Config
mode) and per GARP. Join time is the interval between the transmission of GARP Protocol Data
Units (PDUs) registering (or re-registering) membership for a VLAN or multicast group. This
command has an effect only when GVRP is enabled. The time is from 10 to 100 (centiseconds).
The value 20 centiseconds is 0.2 seconds.

no set garp timer join

This command sets the GVRP join time (for one or all ports and per GARP) to the default and only
has an effect when GVRP is enabled.

set garp timer leave

This command sets the GVRP leave time for one port (Interface Config mode) or all ports (Global
Config mode) and only has an effect when GVRP is enabled. Leave time is the time to wait after
receiving an unregister request for a VLAN or a multicast group before deleting the VLAN entry.
This can be considered a buffer time for another station to assert registration for the same attribute
in order to maintain uninterrupted service. The leave time is 20 to 600 (centiseconds). The value
60 centiseconds is 0.6 seconds.

Default 20
Format set garp timer join <10-100>
Mode • Interface Config

• Global Config

Format no set garp timer join
Mode • Interface Config

• Global Config

Default 60
Format set garp timer leave <20-600>
Mode • Interface Config

• Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-57

v1.0, July 2009

no set garp timer leave

This command sets the GVRP leave time on all ports or a single port to the default and only has an
effect when GVRP is enabled.

set garp timer leaveall

This command sets how frequently Leave All PDUs are generated. A Leave All PDU indicates
that all registrations will be unregistered. Participants would need to rejoin in order to maintain
registration. The value applies per port and per GARP participation. The time may range from 200
to 6000 (centiseconds). The value 1000 centiseconds is 10 seconds. You can use this command on
all ports (Global Config mode) or a single port (Interface Config mode), and it only has an effect
only when GVRP is enabled.

no set garp timer leaveall

This command sets how frequently Leave All PDUs are generated the default and only has an
effect when GVRP is enabled.

show garp

This command displays GARP information.

Format no set garp timer leave
Mode • Interface Config

• Global Config

Default 1000
Format set garp timer leaveall <200-6000>
Mode • Interface Config

• Global Config

Format no set garp timer leaveall
Mode • Interface Config

• Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-58

v1.0, July 2009

GVRP Commands

This section describes the commands you use to configure and view GARP VLAN Registration
Protocol (GVRP) information. GVRP-enabled switches exchange VLAN configuration
information, which allows GVRP to provide dynamic VLAN creation on trunk ports and
automatic VLAN pruning.

set gvrp adminmode

This command enables GVRP on the system.

no set gvrp adminmode

This command disables GVRP.

Format show garp
Mode • Privileged EXEC

• User EXEC

Term Definition
GMRP Admin Mode The administrative mode of GARP Multicast Registration Protocol (GMRP) for the

system.

GVRP Admin Mode The administrative mode of GARP VLAN Registration Protocol (GVRP) for the

system.

Note: If GVRP is disabled, the system does not forward GVRP messages.

Default disabled
Format set gvrp adminmode
Mode Privileged EXEC

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-59

v1.0, July 2009

set gvrp interfacemode

This command enables GVRP on a single port (Interface Config mode) or all ports (Global Config
mode).

no set gvrp interfacemode

This command disables GVRP on a single port (Interface Config mode) or all ports (Global Config
mode). If GVRP is disabled, Join Time, Leave Time and Leave All Time have no effect.

show gvrp configuration

This command displays Generic Attributes Registration Protocol (GARP) information for one or
all interfaces.

Format no set gvrp adminmode
Mode Privileged EXEC

Default disabled
Format set gvrp interfacemode
Mode • Interface Config

• Global Config

Format no set gvrp interfacemode
Mode • Interface Config

• Global Config

Format show gvrp configuration {<unit/slot/port> | all}
Mode • Privileged EXEC

• User EXEC

Term Definition
Interface Valid unit, slot, and port number separated by forward slashes.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-60

v1.0, July 2009

GMRP Commands

This section describes the commands you use to configure and view GARP Multicast Registration
Protocol (GMRP) information. Like IGMP snooping, GMRP helps control the flooding of
multicast packets.GMRP-enabled switches dynamically register and de-register group
membership information with the MAC networking devices attached to the same segment. GMRP
also allows group membership information to propagate across all networking devices in the
bridged LAN that support Extended Filtering Services.

set gmrp adminmode

This command enables GARP Multicast Registration Protocol (GMRP) on the system.

Join Timer The interval between the transmission of GARP PDUs registering (or re-registering)

membership for an attribute. Current attributes are a VLAN or multicast group. There is
an instance of this timer on a per-Port, per-GARP participant basis. Permissible values
are 10 to 100 centiseconds (0.1 to 1.0 seconds). The factory default is 20 centiseconds
(0.2 seconds). The finest granularity of specification is one centisecond (0.01 seconds).

Leave Timer The period of time to wait after receiving an unregister request for an attribute before

deleting the attribute. Current attributes are a VLAN or multicast group. This may be
considered a buffer time for another station to assert registration for the same attribute in
order to maintain uninterrupted service. There is an instance of this timer on a per-Port,
per-GARP participant basis. Permissible values are 20 to 600 centiseconds (0.2 to 6.0
seconds). The factory default is 60 centiseconds (0.6 seconds).

LeaveAll Timer This Leave All Time controls how frequently LeaveAll PDUs are generated. A LeaveAll

PDU indicates that all registrations will shortly be deregistered. Participants will need to
rejoin in order to maintain registration. There is an instance of this timer on a per-Port,
per-GARP participant basis. The Leave All Period Timer is set to a random value in the
range of LeaveAllTime to 1.5*LeaveAllTime. Permissible values are 200 to 6000
centiseconds (2 to 60 seconds). The factory default is 1000 centiseconds (10 seconds).

Port GVMRP
Mode

The GVRP administrative mode for the port, which is enabled or disabled (default). If this
parameter is disabled, Join Time, Leave Time and Leave All Time have no effect.

Note: If GMRP is disabled, the system does not forward GMRP messages.

Term Definition

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-61

v1.0, July 2009

no set gmrp adminmode

This command disables GARP Multicast Registration Protocol (GMRP) on the system.

set gmrp interfacemode

This command enables GARP Multicast Registration Protocol on a single interface (Interface
Config mode) or all interfaces (Global Config mode). If an interface which has GARP enabled is
enabled for routing or is enlisted as a member of a port-channel (LAG), GARP functionality is
disabled on that interface. GARP functionality is subsequently re-enabled if routing is disabled
and port-channel (LAG) membership is removed from an interface that has GARP enabled.

no set gmrp interfacemode

This command disables GARP Multicast Registration Protocol on a single interface or all
interfaces. If an interface which has GARP enabled is enabled for routing or is enlisted as a
member of a port-channel (LAG), GARP functionality is disabled. GARP functionality is
subsequently re-enabled if routing is disabled and port-channel (LAG) membership is removed
from an interface that has GARP enabled.

Default disabled
Format set gmrp adminmode
Mode Privileged EXEC

Format no set gmrp adminmode
Mode Privileged EXEC

Default disabled
Format set gmrp interfacemode
Mode • Interface Config

• Global Config

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-62

v1.0, July 2009

show gmrp configuration

This command displays Generic Attributes Registration Protocol (GARP) information for one or
all interfaces.

Format no set gmrp interfacemode
Mode • Interface Config

• Global Config

Format show gmrp configuration {<unit/slot/port> | all}
Mode • Privileged EXEC

• User EXEC

Term Definition
Interface The unit/slot/port of the interface that this row in the table describes.

Join Timer The interval between the transmission of GARP PDUs registering (or re-registering)

membership for an attribute. Current attributes are a VLAN or multicast group. There is
an instance of this timer on a per-port, per-GARP participant basis. Permissible values
are 10 to 100 centiseconds (0.1 to 1.0 seconds). The factory default is 20 centiseconds
(0.2 seconds). The finest granularity of specification is 1 centisecond (0.01 seconds).

Leave Timer The period of time to wait after receiving an unregister request for an attribute before

deleting the attribute. Current attributes are a VLAN or multicast group. This may be
considered a buffer time for another station to assert registration for the same attribute in
order to maintain uninterrupted service. There is an instance of this timer on a per-Port,
per-GARP participant basis. Permissible values are 20 to 600 centiseconds (0.2 to 6.0
seconds). The factory default is 60 centiseconds (0.6 seconds).

LeaveAll Timer This Leave All Time controls how frequently LeaveAll PDUs are generated. A LeaveAll

PDU indicates that all registrations will shortly be deregistered. Participants will need to
rejoin in order to maintain registration. There is an instance of this timer on a per-Port,
per-GARP participant basis. The Leave All Period Timer is set to a random value in the
range of LeaveAllTime to 1.5*LeaveAllTime. Permissible values are 200 to 6000
centiseconds (2 to 60 seconds). The factory default is 1000 centiseconds (10 seconds).

Port GMRP
Mode

The GMRP administrative mode for the port. It may be enabled or disabled. If this
parameter is disabled, Join Time, Leave Time and Leave All Time have no effect.

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-63

v1.0, July 2009

show mac-address-table gmrp

This command displays the GMRP entries in the Multicast Forwarding Database (MFDB) table.

Port-Based Network Access Control Commands

This section describes the commands you use to configure port-based network access control
(802.1x). Port-based network access control allows you to permit access to network services only
to and devices that are authorized and authenticated.

clear dot1x statistics

This command resets the 802.1x statistics for the specified port or for all ports.

clear radius statistics

This command is used to clear all RADIUS statistics.

Format show mac-address-table gmrp
Mode Privileged EXEC

Term Definition
Mac Address A unicast MAC address for which the switch has forwarding and or filtering information.

The format is 6 or 8 two-digit hexadecimal numbers that are separated by colons, for
example 01:23:45:67:89:AB. In an IVL system the MAC address is displayed as 8 bytes.

Type The type of the entry. Static entries are those that are configured by the end user.

Dynamic entries are added to the table as a result of a learning process or protocol.

Description The text description of this multicast table entry.
Interfaces The list of interfaces that are designated for forwarding (Fwd:) and filtering (Flt:).

Format clear dot1x statistics

{<unit/slot/port> | all}

Mode Privileged EXEC

Managed Switch CLI Manual, Release 8.0

Switching Commands 3-64

v1.0, July 2009

dot1x guest-vlan

This command configures VLAN as guest vlan on a per port basis. The command specifies an
active VLAN as an IEEE 802.1x guest VLAN. The range is 1 to the maximumVLAN ID
supported by the platform.

no dot1x guest-vlan

This command disables Guest VLAN on the interface.

dot1x initialize

This command begins the initialization sequence on the specified port. This command is only valid
if the control mode for the specified port is “auto” or “mac-based”. If the control mode is not 'auto'
or “mac-based”, an error will be returned.

Format clear radius statistics
Mode Privileged EXEC

Default disabled
Format dot1x guest-vlan <vlan-id>
Mode Interface Config

Default disabled
Format no dot1x guest-vlan
Mode Interface Config

Format dot1x initialize

<unit/slot/port>

Mode Privileged EXEC
