NESiGate-CA
NetEx/IP Host Channel-to-IP Gateway
Release 2.8.2
Reference Manual
MAN-REF-CASW
Revision Record
Revision Description
01 (Oct 2000) Initial manual release by Network Executive Software.
02 (Jan 2001) Added procedures for new CDROM distribution and software keys
03 (Jan 2002) Updated for RedHat 7.2 distribution and miscellaneous corrections and additions.
04 (Apr 2002) Miscellaneous updates to correspond with version 2.3 release.
05 (xxx 2002) Added documentation for Hitachi IBM-compatible configuration requirements.
06 (Oct 2002) Added documentation for NG_CA service
07 (Dec 2002) Removed Integration section to NESiGate Software Installation Guide
08 (Jun 2005) Added Software RAID configuration to install
09 (Aug 2005) Updated for release 2.7.2
09 (Jan 2006) Updated for release 2.7.4
10 (Jan 2006) Updated for release 2.7.5
11 (Feb 2006) Updated for release 2.7.6
12 (Oct 2006) Updated for release 2.8
13 (Dec 2006) Updated for release 2.8.1
14 (Feb 2007) Updated for release 2.8.2
© 2000-2006 Network Executive Software, Inc. Reproduction is prohibited without prior permission of
Network Executive Software. Printed in the USA. All rights reserved.
The U.S. Department of Commerce restricts the distribution of technical information contained in this
document when exported outside the U.S. Therefore, careful attention should be given to compliance
with all applicable U.S. Export Laws if any part of this document is to be exported.
Page ii MAN-REF-CASW
Table of Contents
Revision Record.....................................................................................................................................
Copyrights and Trademarks ...................................................................................................................v
Notice to the Customer..........................................................................................................................vi
NESiGate Modification Policy..........................................................................................................vi
Introduction..............................................................................................................................................1
Customization...........................................................................................................................................3
Overview................................................................................................................................................3
Configure NESiGate...............................................................................................................................3
Device Number ..................................................................................................................................3
GNA Address.....................................................................................................................................4
IP Address..........................................................................................................................................4
Using a Web Browser to Configure NESiGate......................................................................................4
Define the Channel Boards(s) ............................................................................................................4
Define the Devices.............................................................................................................................4
Add Routes (optional)........................................................................................................................5
ii
Define IP Interface.............................................................................................................................5
Reboot NESiGate...............................................................................................................................5
Web Browser Interface............................................................................................................................7
Overview................................................................................................................................................7
Browser Considerations .....................................................................................................................7
Browser Considerations .....................................................................................................................7
Initial Screen ......................................................................................................................................7
System, Product, SNMP & Network Configuration ..........................................................................8
NESiGate Board/Channel Commands ...............................................................................................9
Display Board Config.....................................................................................................................9
Channel Define Board and Channel Undefine Board ....................................................................9
Channel Command drop-down menu...........................................................................................10
Channel Display Interface Config................................................................................................10
Channel Display ESCON Config.................................................................................................11
Channel Display Info....................................................................................................................11
MAN-REF-CASW Table of Contents Page iii
Channel Display Stats ..................................................................................................................12
Channel Clear Stats......................................................................................................................13
Channel Start Interface.................................................................................................................13
Channel Stop Interface.................................................................................................................13
Channel Undefine Interface..........................................................................................................13
Channel Define Interface..............................................................................................................14
Channel Set Debug.......................................................................................................................15
NESiGate Router Commands...........................................................................................................16
Command drop-down menu.........................................................................................................16
Route Display Config...................................................................................................................16
Route Display Info .......................................................................................................................16
Route Display Locals ...................................................................................................................16
Route Display Routes...................................................................................................................17
Route Display Stats......................................................................................................................17
Route Clear Stats..........................................................................................................................17
Route Set Debug...........................................................................................................................18
Help Debug ..................................................................................................................................18
Route Add Route..........................................................................................................................18
Route Delete Route ......................................................................................................................19
Route Delete All Routes...............................................................................................................19
NESiGate IP Interface Commands...................................................................................................20
Command drop-down menu.........................................................................................................20
IP Interface Display Config..........................................................................................................20
IP Interface Display Info..............................................................................................................21
IP Interface Display Stats.............................................................................................................22
IP Interface Clear Stats.................................................................................................................23
HELP Debug................................................................................................................................23
IP Interface Set Debug .................................................................................................................23
IP Interface Define Interface........................................................................................................24
Appendix A: Configuration Worksheet ...............................................................................................25
Appendix B: NESiGate Sense Bytes .....................................................................................................27
Page iv MAN-REF-CASW
Copyrights and Trademarks
This document contains references to the trademarks of the following corporations.
Corporation Trademarks
International Business Machines ESCON®
Netscape Communications Corp. Netscape®
Unisys Corporation SBCON
Additional trademark references:
Linus Torvalds Linux®
MAN-REF-CASW Page v
Notice to the Customer
Comments about this manual may be submitted via mailto:pubs@netex.com or by visiting our website:
http://www.netex.com
Always include the complete title of the document with your comments.
Information on Network Executive Software’s general software support policy (e.g., alternate contact
methods, support severity level descriptions, and service status definitions) may be found at
http://www.netex.com/services/supportpolicy.html.
Details on Network Executive Software’s warranty and support policies specific to NESiGate may be
found at
NESiGate Modification Policy
NESiGate is an appliance that contains proprietary software and firmware. Modifications to the software, firmware, or hardware platform that are not specifically authorized by NESi are prohibited.
Examples of prohibited activities include (but are not limited to) the following items:
http://www.netex.com/services/warrantyNG.html.
• Installing other software on NESiGate
• Modifying the file system (including adding, deleting, or moving files and/or directories, or
changing permission levels, ownership, or other attributes of files and/or directories)
• Adding or deleting user accounts
• Starting or stopping system services
• Adding or removing hardware components
Any unauthorized modifications to NESiGate may affect its operation and/or obstruct NESi’s ability to
diagnose problems and provide corrections. Any work resulting from unauthorized modifications shall
be paid by the customer at NESi’s then-current support rates and may result in the immediate termination of warranty/support coverage.
Page vi MAN-REF-CASW
Introduction
This manual provides an overview of the procedures used to integrate and customize the NetEx/IP components onto a NESiGate-CA host channel platform, and to provide a description of the command and
web browser interfaces.
This manual is divided into four sections:
1) Integration: Integration of NESiGate software on the hardware platform is covered in the NESi-
Gate Software Installation Guide. Refer to that guide, then return to this manual to complete the
configuration of NESiGate as an Channel Adapter (CA) type device
2) Customization: this section is targeted to the end-user who is responsible for customizing NESi-
Gate for use as a host-based NetEx/IP channel device. It is assumed the NESiGate already has the
appropriate NESiGate-OS installed. To complete the customization, the reader must be familiar
with channel device and network addressing concepts.
3) Web Browser Interface: this section is targeted to the end-user who is responsible for customizing
the NESiGate for use as a host-based NetEx/IP channel device, and who is responsible for configuring and controlling operational aspects of the device.
MAN-REF-CASW Page 1
Page 2 Introduction MAN-REF-CASW
Customization
Overview
This section provides an overview of the procedures used to complete the customization of the NESiGate-CA for use with Host-Based NetEx/IP products. This section is targeted to the end-user responsible for customization. The reader must be familiar with channel device and network addressing concepts.
Configure NESiGate
There are three important addressing elements involved in delivering NetEx/IP channel data that is not
IP-aware, and transferring it over an IP network to the correct destination:
• Device Number
• GNA Address
• IP Address
Device Number
The Device Number on the host and Device Index on the NESiGate channel board are numeric representations of the same unique "device". On the Host operating system, a "Device Number" is defined as
a Unit Address on a Logical Control Unit (a physical control unit may consist of from 1-16 logical control units). The Physical Control Unit may be connected to a Port on an ESCON Director. Multiple
inbound Host channels may be connected to the ESCON Director and provide connectivity to the device
from multiple partitions (LPARs) across multiple hosts.
Similarly, on the NESiGate ESCON board, a "Device Index" is defined as a Unit Address on a Logical
Control Unit (up to 16 may exist). The Physical Control Unit may be connected to a Port on an ESCON
Director, which may provide connectivity to multiple LPARs across multiple hosts.
Since both the Device Number and Device Index represent the same unique device (from different perspectives), the same addressing components must be specified exactly the same in both definitions.
Failure to do so will prevent the NESiGate devices from functioning properly.
When defining devices on the ESCON channel board, the following items are specified: Device Unit
Address, Logical Control Unit, the Director port to which the host channel is connected, and Partition-id
(LPAR). The Device Index values are not specified by the user. They are automatically generated
when the channel configuration is defined.
A maximum of 64 devices are supported on each ESCON interface.
Refer to the “
vices.
Channel Define Interface” button on page 66614 for a description of defining the channel de-
MAN-REF-CASW Customization Page 3
GNA Address
The GNA address represents a NetEx/IP network address that is associated with a given device. It is
specified in the NetEx/IP Network Configuration Table (NCT). It is also specified during the customization of the NESiGate Channel Driver. At that time, an association is established between a particular
GNA address and a Device Index.
IP Address
The IP address represents a NetEx/IP network node address. There is no channel device awareness inherent in an IP address. However, during the NESiGate customization task, IP host names are defined,
each having a format based on its GNA address. This enables NESiGate to perform a direct mapping
between GNA and IP addresses. This mapping is transparent to the NetEx/IP running on the host, as
well as to all NetEx/IP applications.
Using a Web Browser to Configure NESiGate
The NESiGate Web Browser Interface may be used to configure NESiGate. Before configuring the
NG-CA specific items, the common System and Network configuration should be completed. See the
“Installation Guide” (NG-SW) manual for details.
Refer to the "Web Browser Interface" section on page 7 for a complete description of the commands
used in this section.
Define the Channel Boards(s)
The channel board(s) are automatically configured by the NESiGate initialization software. Normally,
no re-configuration of the board config is required.
Define the Devices
This step is required. If this step is not performed, the ESCON devices will respond as the correct device without regard to LPAR or ESCON director port affinity. If this does not match the real configuration, incorrect results will occur.
Select the Board/Channel link in the navigation menu. This will open the page that is titled: NESiGate
CA Board/Channel.
Using the device configuration data from a completed worksheet provided in “
tion Worksheet” on page
14 for a description of this command.
page
25, use the "Channel Define Interface" button to define the devices. Refer to
Appendix A: Configura-
Repeat this step as many times as necessary until all required channel interfaces are defined.
Page 4 Customization MAN-REF-CASW
Add Routes (optional)
This step is only necessary if static GNA routes are to be defined, and have NOT been configured using
the System page “GNA-host Mapping” command. If static GNA routes are not defined, NESiGate will
use DNS services to resolve GNA to IP addressing.
Select the Router link in the navigation menu. This will open the page that is titled: NESiGate Router.
Using the device configuration data from a completed worksheet provided in “
tion Worksheet” on page
for a description of this command.
Repeat this step as many times as necessary until all required routes are defined.
25, use the "Route Add Route" button to define the routes. Refer to page 18
Appendix A: Configura-
Define IP Interface
This step is only necessary if default IP parameters are to be modified. It is rarely needed.
Select the IP Interface link in the navigation menu. This will open the page that is titled: NESiGate
IP Interface.
Use the "IP Interface Define Interface" button to define the IP interface parameters. Refer to page
for a description of this command.
24
Reboot NESiGate
After the configuration changes have been made, the NESiGate unit must be rebooted to make the
changes effective:
• Vary the devices offline to the host operating system.
• Browse to the “System Config” page of the NESiGate
• In the “Misc Commands” menu, select “REBOOT with NG on”
• Click the “DoIt” button
• After NESiGate is back up vary the devices online to the host operating system.
MAN-REF-CASW Customization Page 5
Page 6 Customization MAN-REF-CASW
Web Browser Interface
Overview
The Apache web server is used on NESiGate to provide a web-enabled configuration facility. Connecting NESiGate to an intranet infrastructure enables usage of a web browser to configure the Channel,
Router, IP, and Control components. The browser can also be used to display configuration information, and control various operational aspects of the components.
Browser Considerations
The browser can be hosted on any system, as long as that system has connectivity to NESiGate. However, the browser must be configured to refresh pages on each page reference.
Browser Considerations
The browser can be hosted on any system, as long as that system has connectivity to NESiGate. However, the browser must be configured to refresh pages on each page reference.
Initial Screen
When the browser first connects to NESiGate, a password entry window will be displayed. Enter the
ngadmin userid you have been assigned and its password to gain access to the NesiGate. Default userids and passwords are described in the common NESiGate Installation Manual.
The initial screen displayed when the password has been accepted includes a “Welcome” screen with
general information on the right and a dropdown navigation list of the available command frames and
HELP links on the left.
MAN-REF-CASW Web Browser Interface Page 7
System, Product, SNMP & Network Configuration
The navigation links will bring you to the area for re-configuring and displaying common information.
Refer to the NESiGate Installation Manual for a description of these commands.
Page 8 Web Browser Interface MAN-REF-CASW
NESiGate Board/Channel Commands
Display Board Config
This button displays the channel boards that have been previously defined.
Prior to selecting this button, provide the following data on the selection screen:
Board Name the name of the board to display.
If no name is specified in the Board Name window, then all defined channel boards are displayed.
Channel Define Board and Channel Undefine Board
This button deletes or adds the specified channel board from the configuration.
Prior to selecting this button, provide the following data on the selection screen:
Board Name a 1-8 character name by which the board will be identified in subse-
quent define and display commands.
For ‘Define Board’ the following additional information is needed:
Channel Type select either ESCON/SBCON, or
If the board is a Bus&Tag interface, select DCI, 3.0 MB, or 4.5 MB,
depending on the speed of the channel to which the board is connected.
PCI Bus PCI bus number on which the ESCON board is installed.
PCI Device PCI device in which the ESCON board is installed.
The PCI Bus and Device numbers are dynamically determined and the channel boards are automatically
defined. The Bus and Device numbers can be viewed by selecting the “Display Board Config” button.
MAN-REF-CASW Web Browser Interface Page 9
Channel Command drop-down menu
From this drop-down menu, the following commands can be initiated -
• Channel Display Interface Config
• Channel Display ESCON Config
• Channel Display Info
• Channel Display Stats
• Channel Clear Stats
• Channel Start Interface
• Channel Stop Interface
• Channel Undefine Interface
After selecting the desired command and entering the necessary parameters, click the GO button to process. Results of the command will be returned to the browser for display.
Channel Display Interface Config
This command displays the current channel configuration. Prior to selecting this button, provide the
following data on the selection screen:
IFname the name of the channel interface to display.
If IFname is not specified, all defined channel interfaces are displayed.
Page 10 Web Browser Interface MAN-REF-CASW
Channel Display ESCON Config
This command shows the currently defined and currently loaded ESCON subchannel ranges and their
index values, as illustrated in
Prior to selecting this button, provide the following data on the selection screen:
IFname the name of the channel interface to display.
If IFname is not specified, all defined channel interfaces are displayed.
NESIGate Channel Display Escon Config
Current Loadable (/etc/nesigate/conf/chlescon.cfg)
;ESCON configuration
;indexNN=subchannel,emulation,controlunit,channellink,lpar,tag
slot=196609
index1=0,HCM,1,ef,0,nesiweb
index2=1,HCM,1,ef,0,nesiweb
index3=2,HCM,1,ef,0,nesiweb
index4=3,HCM,1,ef,0,nesiweb
index5=4,HCM,1,ef,0,nesiweb
index6=5,HCM,1,ef,0,nesiweb
index7=6,HCM,1,ef,0,nesiweb
index8=7,HCM,1,ef,0,nesiweb
Figure 1.
Figure 1. Output from ‘Display ESCON Config’
Channel Display Info
This command displays detailed channel interface information. 8Prior to selecting this button, provide
the following data on the selection screen:
IFname the name of the channel interface to display. If not specified, all defined chan-
nel interfaces are displayed.
Device# limit the display of the channel interface to a particular device. For an ESCON
channel interface running in “configured” mode, this parameter is the Device
Index. For an ESCON channel interface running in “non-configured” mode, or
for a Bus & Tag channel interface, this parameter is an offset from the UADD
specification. If the UADD parameter is not used, this parameter is an offset
from the low-order byte of the startGNA address.
MAN-REF-CASW Web Browser Interface Page 11
Channel Display Stats
This command displays statistics for a particular channel interface. Prior to selecting this button, provide the following data on the selection screen:
IFname the name of the channel interface to display. If not specified, all defined chan-
nel interfaces are displayed.
Device# limit the display of the channel statistics to a particular device. For an ESCON
channel interface running in “configured” mode, this parameter is the Device
Index. For an ESCON channel interface running in “non-configured” mode, or
for a Bus & Tag channel interface, this parameter is an offset from the UADD
specification. If the UADD parameter is not used, this parameter is an offset
from the low-order byte of the startGNA address.
Example: specific interface
id txpacks txbytes rxpacks rxbytes
-------- -------- ------------ -------- ----------- 2 0 0 0 0
txMiscEr rxMiscEr haltIO streamTo sysReset cmdRej intvReq
-------- -------- -------- -------- -------- -------- ------- 0 0 0 0 0 0 0
busOutCk equipCk dataCk overRun delayTx delayRx dataTo
-------- -------- -------- -------- -------- -------- ------- 0 0 0 0 0 0 0
where id : id for display only – minor number
txpacks : # messages sent to the channel
txbytes : # data bytes sent to the channel
rxpacks : # messages read fro m the channel
rxbytes : # data bytes read from the channel
txMiscEr : # transmit to the channel errors
rxMiscEr : # receive from the channel errors
haltIO : halt I/O count
streamTo : I/O streaming timeout count
sysReset : system reset count
cmdRej : command reject count
intvReq : intervention required count
busOutCk : bus out check count
equipCk : equipment check count
dataCk : data check count
overRun : overrun count
delayTx : # stream delayed messages destined for the channel
delayRx : # stream delayed messages coming from the channel
dataTo : data timeout count
Page 12 Web Browser Interface MAN-REF-CASW
Channel Clear Stats
This command clears all or selected channel statistics. Prior to selecting this button, provide the following data on the selection screen:
IFname - specify the name of the channel interface to clear.
Device# - limit the clear of the channel interface to a particular device. For an ESCON
channel interface running in “configured” mode, this parameter is the Device
Index. For an ESCON channel interface running in “non-configured” mode, or
for a Bus & Tag channel interface, this parameter is an offset from the UADD
specification. If the UADD parameter is not used, this parameter is an offset
from the low-order byte of the startGNA address.
Channel Start Interface
This command starts a defined channel interface. Prior to selecting this button, provide the following
data on the selection screen:
IFname the name of the channel interface to start.
Channel Stop Interface
This command stops a defined channel interface. Prior to selecting this button, provide the following
data on the selection screen:
IFname the name of the channel interface to stop.
Channel Undefine Interface
This command removes a defined channel interface.
Prior to selecting this button, provide the following data on the selection screen:
IFname the name of the channel interface to stop.
MAN-REF-CASW Web Browser Interface Page 13
Channel Define Interface
This button defines a channel interface, which consists of a range of devices for use by a particular
NetEx/IP.
⇒ Note: a channel board must be defined first before defining any channel interfaces.
Prior to selecting this button, provide the following data on the selection screen:
IFname a name by which the interface will be identified.
Prot the channel protocol version.
HCM is the traditional HYPERchannel mode message/data format.
HCM2 is a single-CCW protocol which is more efficient for small
channel transfer applications. The host NetEx must support this (currently only supported in H210IP 6.1 and later).
On board the name of the board on which this interface is being defined. Auto-
Define uses ‘board1’ and ‘board2’
StartGna the GNA address of the first device in the form 'UUSS', where 'UU' is
the NETADDR for this ADAPTER definition in the NCT. ‘SS’ must
be the same as the first device address lower byte. The SMGDREF
definition for this ADAPTER definition in the NCT must be in the
range 'SS' to 'SS' + Number of devices.
Number of devices the number of devices being defined for this interface (4 is normally
Input (optional) the low-order byte of the input device.
UADD the unit address of the device.
Max Data - (optional) the memory allocation size used by the Channel driver to
For ESCON devices only -
CU - the control unit number. Up to sixteen control units can be specified,
CHlink - the ESCON director port number to which the channel is connected that
sufficient). The maximum number of devices that can be defined per
interface definition is 16.
buffer data coming off or going on the channel. This value must be at
least as large as the NetEx/IP segsize parameter. The default is 65535
bytes.
ranging from 0-F. A unique Control Unit should be defined for each
concurrent host, or host partition, running NetEx/IP. Note: CU 0 must
be used if connection is to a Unisys system.
is used for communicating to the ESCON board. If the ESCON interface is connected directly to the channel without going through an ES-
Page 14 Web Browser Interface MAN-REF-CASW
CON Director, a port number of 1 should be specified if connection is
to an IBM or Hitachi IBM-compatible system; a port number of 2
should be specified if connection is to a Unisys system.
LPAR - the partition number of the host driving this interface if the channel is
defined as SHARED. If the system is running in BASIC mode, or if
the system is running in LPAR mode but the channels are defined as either RECONFIGURABLE or DEDICATED, then the value specified
for LPAR must be zero.
⇒ Caution: It is extremely important that the values specified for UADD, CU, Chlink, and
LPAR exactly match the values specified in the host system's device configuration. Failure to
do so will make the devices unusable.
The total number of devices supported on each ESCON interface board is 64. Use this selection button
multiple times until all required device interfaces are defined.
Channel Set Debug
This button sets the debug trace level for all interfaces, or for a specific channel interface. Prior to selecting this button, provide the following data on the selection screen:
IFname the name of the channel interface for which to enable debug.
VALUE:
0 : no console tracing
1 : console trace only H level messages
2 : console trace level H and M messages
3 : console trace level H, M, and L messages
4 : console trace level H, M, L, and D messages
5 : console trace the actual streams messages
6 : console trace the message data
7 : console trace all the data
global set Channel debug level globally
MAN-REF-CASW Web Browser Interface Page 15
NESiGate Router Commands
This screen is used to define, process, or view router configuration data.
Command drop-down menu
From this drop-down menu, the following commands can be initiated -
• Route Display Config
• Route Display Info
• Route Display Locals
• Route Display Routes
• Route Display Stats
• Route Clear Stats
After selecting the desired command, click the GO button to process. Results of the command will be
returned to the browser for display.
Route Display Config
This command displays the current configured routes.
Route Display Info
This command displays information for the router control stream or a particular stream identified by
Link Index. The Link Index can be obtained by first displaying the channel configuration with the
"
Channel Display Interface Config" command.
Route Display Locals
This command displays all current defined local routes (device to GNA mappings).
Page 16 Web Browser Interface MAN-REF-CASW
Route Display Routes
This command displays all current defined external routes (IP address to GNA mappings).
Route Display Stats
This command displays statistics for the router control stream or for a particular stream identified by the
Link Index. The Link Index can be obtained by first displaying the channel configuration with the
"
Channel Display Interface Config" command.
Sample output:
id txmsgs txbytes rxmsgs rxbytes outDrop inDrop
-------- -------- ------------ -------- ------------ -------- ------- 2 0 0 0 0 0 0
where id : control or L_INDEX
txmsgs : the number of messages sent from the router to the lower stream
txbytes : the number of bytes sent from the router to the lower stream
rxmsgs : the number of messages received fro m a lower stre am
rxbytes : the number of bytes received from a lower stream
outDrop : the number of dropped messages from an upper stream
inDrop : the number of dropped messages from a lower stream
Route Clear Stats
This command clears statistics for the router control stream or for a particular stream identified by the
Link Index. The Link Index can be obtained by first displaying the channel configuration with the
"
Channel Display Interface Config" command.
control clear statistics for the Control stream
index clear statistics for the stream linked under the Router at L_INDEX. L_INDEX can be
obtained by first displaying the channel configuration.
MAN-REF-CASW Web Browser Interface Page 17
Route Set Debug
This button sets the debug trace level globally, for the control stream or for a particular stream identified
by the Link Index. The Link Index can be obtained by first displaying the channel configuration with
the "
Channel Display Interface Config" command.
VALUE:
0 : no console tracing
1 : console trace only H level messages
2 : console trace level H and M messages
3 : console trace level H, M, and L messages
4 : console trace level H, M, L, and D messages
5 : console trace the actual streams messages
6 : console trace the streams message data
7 : console trace all the data
global set Router debug level globally
control set Router debug level for the Router control stream.
L_INDEX set Router debug level for the stream linked under the Router at L_INDEX. L_INDEX
can be obtained by first displaying the channel configuration
Help Debug
This button displays help information for the "Route Set Debug" command in a separate window.
Route Add Route
This button defines a mapping of a GNA route to an IP address. If the GNA already has a route defined,
it will be changed.
Prior to selecting this button, provide the following data on the selection screen:
StartGNA specify the GNA address of the destination host.
IP Addr specify the IP address to which the StartGNA value should be routed.
Num specify the number of consecutive StartGNA addresses to route.
Chg running (temp) select this box to make a temporary change. The change will only re-
main in effect until the unit is restarted.
Chg file (perm) select this box to make a permanent change.
Page 18 Web Browser Interface MAN-REF-CASW
Route Delete Route
This button deletes a currently defined route. Prior to selecting this button, provide the following data
on the selection screen:
StartGNA specify the GNA address of the destination host to delete.
Chg running (temp) select this box to make a temporary change. The change will only re-
main in effect until the unit is restarted.
Chg file (perm) select this box to make a permanent change.
Route Delete All Routes
This button deletes all defined routes. Prior to selecting this button, provide the following data on the
selection screen:
Non-Configured select this box to delete only the routes that were found by DNS look-
ups.
Configured select this box to delete only the routes that were defined with Route
Add commands.
Chg running (temp) select this box to make a temporary change. The change will only re-
main in effect until the unit is restarted.
Chg file (perm) select this box to make a permanent change.
MAN-REF-CASW Web Browser Interface Page 19
NESiGate IP Interface Commands
This screen is used to define, control, or view IP configuration data. They are normally not used.
Command drop-down menu
From this drop-down menu, the following commands can be initiated -
• IP Interface Display Config
• IP Interface Display Info
• IP Interface Display Stats
• IP Interface Clear Stats
After selecting the desired command, click the GO button to process. Results of the command will be
returned to the browser for display.
IP Interface Display Config
This command displays the current IP configuration.
type prot minor l_index ref optfl lport mxrcvbyt mxsndbyt
-------- ----- ----- ------- -------- ----- ------ -------- ------- MSG UDP 2 4 c2a4ba20 0 6950 512000 512000
where type : currently only MSG is supported
prot : currently only UDP is supported
minor : the streams minor number associated with this interface
l_index : the streams link index associated with the router side of this IP interface
ref : reference # for this interface (address of connection control block)
opt fl : option flags 0x80 : checksum off
lport : local port number associated with this interface
mxrcvbyt : maximum socket receive byte count
mxsndbyt : maximum socket send byte count
Page 20 Web Browser Interface MAN-REF-CASW
IP Interface Display Info
This command displays detailed information for a particular IP interface stream ID. The ID can be obtained by first displaying the IP configuration with the "
id ref state db prot fl backlog rdCred padLen
------------ -------- -------- -- ---- -- ------- ------ ------
msg:2 cf715020 0 0 UDP 80 0 -1 0
waitWrQ waitConQ stream sk sock unsolId saveUid svFl
-------- -------- -------- -------- -------- -------- -------- ----
0 0 cdbdc800 cf054b80 cda4d08c 0 0 0
abrtR rPort rAddr lPort lAddr mxRcvByt mxSndByt con
----- ----- -------- ----- -------- -------- -------- --------
0 0 0 6950 0 512000 512000 cf715020
where id : temporary id for display only – minor number
ref : reference # for this connection (address of connection control block)
state : current state of this connection (currently unused)
db : stream debug level
prot : protocol (currently only UDP supported)
fl : stream flags 0x80 : read queue is being serviced
0x40: write queue is being serviced
0x20: control stream
backlog : currently unused
rdCred: currently unused (should always be -1)
padLen : currently unused
waitWrQ : currently unused
waitConQ : currently unused
stream : the address of the stream control block
sk : address of IP sock structure
sock : address of IP socket structure
unsolId : unsolicited id (currently unused)
saveUid : temporary save area
svFl : temporary save area
abrtR : abort reason code (currently unused)
rPort : remote port number if connected (currently unused)
rAddr : remote IP address if connected (currently unused)
lPort : local port number
lAddr : local IP address (0 if any address)
mxRcvByt : maximum socket receive byte count
mxSndByt : maximum socket send byte count
con : address of connection control block
IP Interface Display Config" command.
MAN-REF-CASW Web Browser Interface Page 21
id device minor db sdb gdb gsdb mt fl retId hcCon
------------ -------- -------- -- --- --- ---- --- -- ----- --------
msg 4801 1 0 OFF 2 OFF ON 0 0 cf715020
openFl streamFl readQ writeQ stream numCons
-------- -------- -------- -------- -------- --------
2 2 cd80e154 cd80e190 cdbdc800 1
cons
--------------------------------------------
cf715020
where id : temporary id for display only – minor number
device : the stream device number associat ed with this interface
minor : the streams minor number associated with this interface
db : connection debug level
sdb : socket debug level
gdb : global debug level
gsdb : global socket debug level
mt : memory trace on or off
fl : connection flags 0x80 : hc connection
0x08 : no checksum socket option
0x04 : debug socket option
retId : current retry timeout id
hcCon : address of special hc connection control block
openFl : device open flags
streamFl : device stream flags
readQ : the address of the stream read queue
writeQ : the address of the stream write queue
stream : address of stream control block
numCons : number of connections using this interface
cons : list of connection control block addresses
IP Interface Display Stats
This command displays statistics for the stream or a connection.
Example 1: no connection specified
id txmsgs txbytes rxmsgs rxbytes
------------ -------- ------------ -------- ------------
msg 0 0 0 0
txdelay rxdelay outDrop inDrop
-------- -------- -------- --------
0 0 0 0
Page 22 Web Browser Interface MAN-REF-CASW
Example 2: specific connection (1)
igs msg 1:
id txmsgs txbytes rxmsgs rxbytes
------------ -------- ------------ -------- ------------
msg:1 0 0 0 0
txdelay rxdelay outDrop inDrop
-------- -------- -------- --------
0 0 0 0
where id : temporary id for display only – minor number:connection reference number
txmsgs : # messages sent to IP
txbytes : # bytes sent to IP
rxmsgs : # messages received from IP
rxbytes : # bytes received from IP
txdelay : # stream delayed messages destined for IP
rxdelay : # stream delayed messages coming from IP
outDrop : # dropped messages destined for IP
inDrop : # dropped messages coming from IP
IP Interface Clear Stats
This command clears the statistics for the stream or a connection.
HELP Debug
This button displays help information for the "IP Interface Set Debug" command in a separate window.
IP Interface Set Debug
This button sets the debug trace level globally or for a particular connection. The ID can be obtained by
first displaying the IP configuration with the "
IP Interface Display Config" command.
MAN-REF-CASW Web Browser Interface Page 23
IP Interface Define Interface
This button defines various IP interface parameters.
Prior to selecting this button, provide the following data on the selection screen:
port number - the local port number (normally set to 6950).
checksum - select this box to enable the checksum of IP packets.
Max Receive - the maximum receive buffer size (normally set to 512000).
Max Send - the maximum send buffer size (normally set to 512000).
Chg running (temp) - select this box to make a temporary change. The change will only re-
main in effect until the unit is restarted.
Chg file (perm) - select this box to make a permanent change
Page 24 Web Browser Interface MAN-REF-CASW
Appendix A: Configuration Worksheet
This worksheet can be used to record the necessary NESiGate configuration information.
HOST & IP Information
(Used for Network Configuration)
Example
Site Configuration
Host name netfin3
IP address (data) 11.1.2.27
IP address (management) 10.1.2.27
Domain name netexsw.com
Network mask 255.255.255.0
Default gateway 10.1.2.50
IP address of name server 10.1.3.1
OS device information
(Used for OS Definitions)
Device number (or name) 5200
Number of devices 4
Director port (device director port) F3
Control unit number (or name) 1
Unit address 0
LPAR number 0
Channel board Information
(Used for NESiGate board definitions)
Example
Example
Site Configuration
Site Configuration
Board name Board1
Channel type (ESCON, Bus & Tag) ESCON
For Bus & Tag channels:
Speed (DCI, 3.0MB, 4.5MB)
NESiGate Channel Information
(Used for NESiGate device definition)
IFname
type (must be MSG)
Board (name of channel board)
MAN-REF-CASW Appendix A Page 25
Example
IBM5200
MSG
Board1
Site Configuration
UADD (unit address)
0
StartGNA (starting GNA address)
Number of devices
Input device (not required)
Max Data
For ESCON devices only:
CU (control unit)
CHlink (channel director port)
LPAR
NESiGate Router Information
(Used for NESiGate Static Routes definitions) (Note 1)
StartGNA (remote GNA address)
IP Addr
Num (number of consecutive addresses
(repeat for all remote GNA addresses)
NESiGate DNS Entries
(Used for NESiGate Dynamic Routes definitions) (Note 1)
EA00
4
0
65535
1
EA
0
Example
DC00
10.1.2.15
4
Example
Site Configuration
Site Configuration
Add entries to the DNS server
NTX0000A110 10.1.2.25
Note 1: Either Static or Dynamic routing definitions must be used for each NetEx/IP GNA-to-IP map-
ping requirement.
Page 26 Appendix A MAN-REF-CASW
Appendix B: NESiGate Sense Bytes
Table 1. NESiGate Channel Sense Bytes defines the sense bytes that are returned from the NESiGate
channel interface board.
Sense Bytes
0
X’80’ – Command Reject
X’10’ – Equipment Check
Table 1. NESiGate Channel Sense Bytes
Subchannel not started error – only two byes of sense are returned X’8200’
……
…… X’80’ – Data Timeout
X’10’ – Waitmsg Timeout
8
…..
….. X’2A’ – Data Timeout
31
X’2B’ – Waitmsg Timeout
MAN-REF-CASW Appendix B Page 27
Page 28 Appendix B MAN-REF-CASW
Loading...
