NetComm V220 Quick Install Guide

NETCOMM EXPRESS

TM

SERIES

Dual Port VoIP Adapter

1

Hardware Installation

1. With the supplied Ethernet cable, connect the LAN port of your modem/router
to the WAN port on the back of your VoIP ATA

2. If you would like your PC to be connected to the network through your VoIP ATA
connect another Ethernet cable (not supplied) from your PC to the LAN port on
the back of your VoIP ATA.

3. Connect your telephone handset to the Phone port. You can connect an
additional handset to the Phone 2 port.

5. Connect the supplied power adapter and press the power button to turn your
ATA on. After 2 minutes the Power and Ethernet LEDs will be lit.
