This quick start guide is designed to get you up and running quickly with your
new NTC-220 Series Router. More advanced set up instructions can be found in
the user guide which can be downloaded from www.netcommwireless.com/
product/ntc-220.
Package contents
The NTC-220 Series package includes:
1 x NetComm NTC-220 Series Router
2
MPRT-00004-000 Rev9_NTC-220_QSG.indd 2 13/11/2018 10:36:29 AM
2 x Cellular antennas
1 x DIN rail mounting
bracket
rail mounting adapter
1 x 1.5m Yellow Ethernet cable
1 x Horizontal DIN
1 x Quick Start Guide
8P8C
1 x Six-way
terminal block
| Industrial IoT
NTC-220 Series 4G LTE Cat 1 Industrial IoT Router
Device overview
Reset button
SIM card slot
Aux antenna socket
Six-way terminal
block connector
Micro USB 2.0
OTG port
Serial port
RJ45 Fast
Ethernet port
Main antenna socket
GPS antenna socket
3
MPRT-00004-000 Rev9_NTC-220_QSG.indd 3 13/11/2018 10:36:30 AM
| Industrial IoT
Item
Aux antenna socket SMA female connector for auxiliary antenna (receive diversity).
Serial port
GPS antenna socket SMA female connector for GPS antenna.
Main antenna socket SMA female connector for main antenna.
Reset button
SIM card tray slot The removeable tray houses the SIM card.
Micro USB 2.0 OTG
port
Six-way terminal
block connector
Description
Female DE-9 port supporting 9-wire RS-232, RS-485 or RS-422
(software selectable).
Press and hold for less than 5 seconds to reboot to normal mode. The
LEDs are green and extinguish in sequence to indicate that the router
will reboot normally if the button is released during this period.
Press and hold for 5 to 15 seconds to reboot to recovery mode.
The LEDs are amber and extinguish in sequence to indicate that the
router will reboot to recovery mode if the button is released during
this period.
Press and hold for 15 to 20 seconds to reset the router to factory
default settings. The LEDs are red and extinguish in sequence to
indicate that the router will reset to factory default settings if the button
is released during this period.
Provides connectivity for optional external storage or a USB Ethernet
dongle. Supplies up to 0.5A to connected device.
Connect power source, ignition and I/O wires here. Power, ignition
and I/O wires may be terminated on the supplied terminal block and
connected to a power source. Refer to the diagram and table under
Step 5 of the Installing your device section for correct wiring of the
terminal block. Operates in the 8-40V DC range.
4
MPRT-00004-000 Rev9_NTC-220_QSG.indd 4 13/11/2018 10:36:30 AM
RJ45 Fast Ethernet
port
Connect one or several devices via a network switch here.
| Industrial IoT
NTC-220 Series 4G LTE Cat 1 Industrial IoT Router
Getting started
Depending on your chosen setup, you may need certain components to congure
your device correctly, such as:
An external power supply unit for the NTC-220 Series Router (not included).
A athead screwdriver for terminating power input wires.
A laptop or PC for advanced conguration.
Additional fasteners and screwdrivers for specic wall or rail mounting.
MPRT-00004-000 Rev9_NTC-220_QSG.indd 5 13/11/2018 10:36:30 AM
5
| Industrial IoT
Overview of LED
indicators
LED Icon
Name Colour State Description
Off Power off
Double ash Powering up
Power
Network
On Power on
On Power on in recovery mode
Slow ashing Hardware error
On Connected via WWAN
1
Blinking
Slow ashing Connecting PDP
On Registered network
Slow ashing Registered network
Slow ashing SIM PIN locked
Fast ashing SIM PUK locked
On Can’t connect
Trafc via WWAN
6
MPRT-00004-000 Rev9_NTC-220_QSG.indd 6 13/11/2018 10:36:32 AM
| Industrial IoT
NTC-220 Series 4G LTE Cat 1 Industrial IoT Router
LED Icon
Name Colour State Description
Off GPS function disabled
GPS /
Customizable
LED Indicator
On
Flashing Satellite detected, acquiring location.
GPS function is enabled but no satellite
is detected.
On Satellite detected, location acquired.
On LTE signal
Signal
strength
On WCDMA signal
On GSM signal
1
The term “blinking” means that the LED may pulse, with the intervals that the LED is on
and off not being equal. The term “ashing” means that the LED turns on and off at equal
intervals.
MPRT-00004-000 Rev9_NTC-220_QSG.indd 7 13/11/2018 10:36:33 AM
7
| Industrial IoT
Installing your device
Step 1: Insert the SIM card
Before inserting the SIM card, examine it for signs of damage or deformation that
could prevent it being safely inserted or allowing it to become stuck in the unit.
Examine the gold contact point of the SIM for signs of wear or damage that may
prevent it from working correctly.
Press the SIM Eject button to eject the SIM card tray. Place the SIM card in the
tray and then insert the loaded tray into the SIM card slot with the gold side facing
up. The SIM tray should slide easily into the slot, do not force the loaded SIM tray
into the slot.
Step 2: Attach the antennas
The NTC-220 Series Router is shipped with caps on the Main, Auxiliary and GPS
antenna sockets. To attach the supplied antennas, rst remove the antenna socket
caps from the Main and Auxiliary antenna sockets by turning them in an anticlockwise direction, then screw the antennas onto the sockets by turning them in
a clockwise direction. Please refer to the Device overview section for the antenna
socket layout. If you have purchased a GPS antenna, remove the socket cap from
the GPS antenna socket and attach the antenna to the socket in the same manner.
8
MPRT-00004-000 Rev9_NTC-220_QSG.indd 8 13/11/2018 10:36:34 AM
| Industrial IoT
NTC-220 Series 4G LTE Cat 1 Industrial IoT Router
Step 3: Mount the router
Mount your router in a suitable location using the options listed below.
1. Wall mount
Use a minimum of 2 screws
(5mm diameter) through the holes
on either side of the device.
DIN rail mounting bracket
V Bend allows you to snap the DIN
bracket onto the middle of a DIN rail
rather than sliding it onto the end.
MPRT-00004-000 Rev9_NTC-220_QSG.indd 9 13/11/2018 10:36:38 AM
4 x mounting holes allow you to
secure the DIN bracket to a wall,
using a minimum of 2 screws
(3.5mm diameter).
9
