NESO Technology 772A Users Manual

Pomona FD 770A

17” “Trinitron®” Color Monitor

User Manual

4/2001

IBM PC, IBM PS/2, and VGA are registered trademarks of International Business Machines Corp. Windows,
DOS are registered trademarks of Microsoft Corp. Macintosh is a registered trademark of Apple Computer Inc.
ENERGY STAR is a U.S. registered mark.

NESO reserve the right to make changes or improvement in this product described in this manual without notice.

1

FD 770A User’s Manual

2

Federal Communications Commission (F.C.C.) Statement

This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particu lar installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:

Relocate the receiving antenna

n

Increase the separation between the equipment and receiver

n

Connect the equipment into an outlet on a circuit different from that to which the

n

receiver is connected.
Consult the dealer or an experienced radio/TV devices technician for help.

n

Use only shielded cables or connect I/O devices to this equipment.

You are cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.

Table of Contents

Federal Communications Commission (F.C.C.) Statement ................................................... 2

Safety Precautions.................................................................................................................. 4

Quick Installation Guide ........................................................................................................ 6

Operation................................................................................................................................ 7

Front Panel Buttons ................................................................................................................ 7

On-Screen Display (OSD) Main Menu .................................................................................. 8

RECALL ........................................................................................................................ 8

PICT (Picture)................................................................................................................ 9

LANG (Language) ......................................................................................................... 9

SCREEN....................................................................................................................... 10

EXIT............................................................................................................................. 10

GEOM (Geometry) ...................................................................................................... 10

COLOR.........................................................................................................................11

iVIDEO .........................................................................................................................11

OPTION........................................................................................................................11

Specifications ....................................................................................................................... 13

Preset Display Modes........................................................................................................... 13

Troubleshooting.................................................................................................................... 14

Cleaning the Monitor ........................................................................................................... 15

.

3

FD 770A User’s Manual

4

Safety Precautions

Please read following instructions before use:

1. Please install the swivel base for this monitor before using it.

2. Avoid exposing the monitor to direct sunlight and ensure the area around the monitor is
free from moisture. Never allow any liquid to get inside the monitor.

3. Do not place any objects on the case.

4. Never place the monitor near a heat source such as a radiator.

5. To prevent overheating, the openings for ventilation on the top, rear, bottom and side of
the monitor should be kept free of any obstructions.

6. Do not open the case of the monitor, as doing so may expose you to dangerously high
voltage levels. Never attempt to perform repairs on the monitor yourself, but refer all
servicing to qualified personnel.

7. Disconnect the monitor from the power outlet when the monitor is not in use for
extended periods of time.

8. Continuous use of the monitor over long periods of time may result in permanent
damage to the CRT's screen elements. To increase the life of the CRT, make sure to turn
off the power or reduce its brightness when the monitor is not in use.

9. The monitor is equipped with a three-wire grounding-type plug. For safety, this device
should only be used with a grounding-type power outlet. If your outlet is not of this type,
contact your electrician for replacement.

Due to the safety requirements of different areas, please select a suitable power cord
according to the following rules, in addition to the electric rating:

A. Northern America Area: Please select a UL listed and CSA certified power cord.
B. Germany: Please select VDE certified power cord.
C. Nordic countries: Please select a power cord certified by SEMKO, NEMKO,

DEMKO or FIMKO

D. The other areas: Please select a power cord suitable to the local power system and

Never use a 3-to-2 prong adapter.

power outlet.

Usually when this product is sold, a suitable power cord is provided by the manufacturer.
However, this product is sometimes resold or transported to another area with a different
power system and safety requirements. Please pay attention to the selection of a
suitable power cord.

The plug on the power cord is intended to serve as the disconnect device, the
socket-outlet shall be installed near the equipment and shall be easily accessible.

10. This monitor is designed with a universal power supply that is suitable for 100 – 240
VAC and 50 – 60Hz frequency.

5
