NEOTECHA MODEL NTB/NTC LINED BALL VALVES
MODEL CODE OPTIONS AND DESCRIPTIONS - NORTH AMERICA AND EUROPE ONLY
Series
NTB - 0050 R0 A1 01 16 - D2 L11 U0 TD P0 I B - F04 NP1 TPZ + GS-001
SERIES
Code Description
NTB Model NTB, Ball Valve
NTC Model NTC, C-Ball Valve
SIZE
Code Description
0015 DN 15 / NPS ½
0020 DN 20 / NPS ¾
0025 DN 25 / NPS 1
0040 DN 40 / NPS 1½
0050 DN 50 / NPS 2
0065 DN 65 / NPS 2½
0080 DN 80 / NPS 3
0100 DN 100 / NPS 4
0150 DN 150 / NPS 6
ZZZZ Special
Size
End Connection
Drilling / Schedule
Face to Face
Pressure Rating
Body Material
Ball Material
Stem Material
Seat Material
Packing / Gaskets / Seals Material
Operator Mounting Type
Actuation Type
Operator Mounting Flange
FACE TO FACE
Code Description
01 EN558 Series 01
03 EN558 Series 03 - ASME B16.10 DF
Gate CL.150 / API 609 DF Long Pattern
ZZ Special
PRESSURE RATING
Code Description
16 16 bar / 230 psi
ZZ Special
BODY MATERIAL
Code Description
D2 Ductile Iron A395 60-40-18 / EN 5.3103
(JS1049)
ZZ Special
Optional Feature 1
Optional Feature 2
SEAT MATERIAL
Code Description
TD TFM
TE TFM Conductive
R0 RPTFE
ZZ Special
PACKING / GASKETS / SEALS MATERIAL
Code Description
P0 PTFE
ZZ Special
OPERATOR MOUNTING TYPE
Code Description
S Standard (Refer to Product Literature)
I ISO 5211
ACTUATION TYPE
END CONNECTION
Code Description
R0 Flange - Raised Face (RF)
ZZ Special
BALL MATERIAL
Code Description
L11 Stainless Steel - PFA
L21 Stainless Steel - Conductive PFA
ZZZ Special
Code Description
B Bare Stem
L Default Handle / Lever
DRILLING / SCHEDULE
Code Description
A1 ASME 150
P3 PN 16
J3 JIS 10K
ZZ Special
STEM MATERIAL
Code Description
U0 Stainless Steel Duplex
ZZ Special
Actuation Option
Emerson.com/FinalControl © 2020 Emerson. All Rights Reserved. VCREF-13737-EN20/02
NEOTECHA MODEL NTB/NTC LINED BALL VALVES
MODEL CODE OPTIONS AND DESCRIPTIONS - NORTH AMERICA AND EUROPE ONLY
Series
Size
End Connection
Drilling / Schedule
Face to Face
Pressure Rating
Body Material
Ball Material
Stem Material
Seat Material
Packing / Gaskets / Seals Material
Operator Mounting Type
Actuation Type
Operator Mounting Flange
Optional Feature 1
Optional Feature 2
NTB - 0050 R0 A1 01 16 - D2 L11 U0 TD P0 I B - F04 NP1 TPZ + GS-001
OPERATOR MOUNTING FLANGE
Code Description
F04 PCD F04 - 42 mm (ISO 5211)
F05 PCD F05 - 50 mm (ISO 5211)
F07 PCD F07 - 70 mm (ISO 5211)
F10 PCD F10 - 100 mm (ISO 5211)
F12 PCD F12 - 125 mm (ISO 5211)
F14 PCD F14 - 140 mm (ISO 5211)
F16 PCD F16 - 165 mm (ISO 5211)
ADDITIONAL ACTUATION OPTIONS
Code Description
HS-## Standard Handle
GS-### Standard Gear
PS-### Standard Pneumatic
HZ Other Handle
GZ Other Gear Operators
PZ Other Pneumatic Actuators
EZ Other Electric Actuators
[1]
[1]
[2]
[3]
[3]
[3]
[3]
F04 PCD F04 - 42 mm (ISO 5211)
F05 PCD F05 - 50 mm (ISO 5211)
F07 PCD F07 - 70 mm (ISO 5211)
F10 PCD F10 - 100 mm (ISO 5211)
F12 PCD F12 - 125 mm (ISO 5211)
F14 PCD F14 - 140 mm (ISO 5211)
F16 PCD F16 - 165 mm (ISO 5211)
NOTES
1. Additional characters identify specific handle or
gear. For the full list, consult the Handles and
Gear Operators Addendum (VCREF-14325).
2. Additional characters identify actuator
configuration.
3. Required operator, mouting and accessory
OPTIONAL FEATURES
Code Description
part number(s) are specified per order
acknowledgement.
NP1 Additional 316 Stainless Steel Tag
TPZ Special Hydrostatic Test Report
Actuation Option
NOTE
For the full list of optional features, consult your local
Emerson representative.
NOTE
For the full list of optional features, consult your local Emerson representative.
