NEO-SLIM TRI
USER MANUAL V1.1
Page.1
Thank you for investing in our NEO-SLIM TRICOL
Small compact and built tough, including 16 Tri-Coloured LED emitters for homogenised colour mixing.
Please read through this user manual and keep it on file for your future referral.
TECHNICAL SPECIFICATIONS
LED
POWER
POWER CONSUMPTION
FUSE
CONTROL
DMX CHANNELS
DIMENSIONS
NET WEIGHT
16 3W 3in1 RGB
90-264VAC 50/60Hz
48W
1A-250V/2A-125V
DMX/Master-Slave/Audio/Auto modes
3/8
L360xW298xH102mm
4.8Kgs
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM TRI
USER MANUAL V1.1
Page.2
THIS LIGHT IS INTENDED FOR INDOORS AND UNDER ADEQUATELY PROTECTED STAGES.
DO NOT POWER IT ON WHEN THE PRODUCT IS IN THE PACKAGE ENSURE ADEQUATE VENTILATION PRIOR
TO OPERATION.
ENSURE THE UNIT'S POWER SUPPLY AND PLUG ARE ADEQUATELY GROUNDED. FAILURE TO DO SO CAN
RESULT IN ELECTRICAL SHOCK AND POSSIBLE ELECTROCUTION.
DO NOT ATTEMPT TO REPAIR THE UNIT UNLESS YOU ARE COMPETENT TO DO SO.
IF IN DOUBT SEEK PROFESSIONAL HELP.
DO NOT LOOK DIRECTLY INTO THE LIGHT SOURCE AS IT MAY CAUSE DAMAGE TO YOUR EYES.
WHAT'S INCLUDED-CHECK YOUR CONTENTS
(A) 1 SLIM RGBW
(B) 1 IEC POWER CABLE
(C) IR REMOTE CONTROL UNIT
GETTING STARTED
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM TRI
USER MANUAL V1.1
Page.3
SELECT CONTROL MODE
Using the DIP-SWITCH interface you can determine the control option you require.
Check the table below for details-
CONTROL DIPSWITCH
DMX 1-9 TO SET ADDRESS AUDIO #9+#10 SET TO “ON”
AUTO(MATIC) #10 SET TO “ON” MANUAL #8+#9+#10 SET TO “ON”
MASTER/SLAVE
When running in AUTO/AUDIO/MANUAL simply link subsequent units with DMX cable(s).
DMX DIPSWITCH VALUES
#1=1 #2=2 #3=4 #4=8 #5=16 #6=32 #7=64 #8=128 #9=256
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM TRI
USER MANUAL V1.1
Page.4
DETAILED DIAGRAM
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM TRI
USER MANUAL V1.1
Page.5
DMX CHANNEL MAPPING-SHORT MODE
DMX CHANNEL LABEL FUNCTION HEX VALUE
1 RED Linear colour 000-255
2 GREEN Linear colour 000-255
3 BLUE Linear colour 000-255
DMX CHANNEL MAPPING-FULL MODE
DMX CHANNEL LABEL FUNCTION HEX VALUE
1 Intensity Linear intensity 000-255
2 Strobe
Blackout 000-009
Linear 010-057
Random 058-105
Flash 106-153
Ramp up 154-201
Ramp down 202-249
On 250-255
3 RED Linear colour 000-255
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM TRI
USER MANUAL V1.1
Page.6
DMX CHANNEL MAPPING-FULL MODE CONTINUED
4 GREEN Linear colour 000-255
5 BLUE Linear colour 000-255
6 Macro select
No macro 000-009
Macro#1 010-031
Macro#2 032-063
Macro#3 064-095
Macro#4 096-127
Macro#5 128-159
Macro#6 160-191
Macro#7 192-223
Macro#8 224-255
7 Macro speed Slow to fast control 000-255
8 Macro time 0-100% XFADE 000-255
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM TRI
USER MANUAL V1.1
Page.7
AUTO/AUDIO* DIPSWITCH SETTINGS-MACRO SELECT
[0=OFF 1=ON X=RESERVED FOR SPEED/FADE/STROBE]
*AUDIO MODE DOES NOT REQUIRE SPEED CONTROL ONLY USE DIPSWITCH #9 & #10 IF YOU REQUIRE AUDIO MODE TO
FUNCTION.SET AUDIO SENSITIVITY WITH THE POTENTIONMETER LOCATED ON REAR OF UNIT.
DIPSWITCH
MACRO SELECT
1 2 3 4 5 6 7 8 9 10
MACRO 1 0 0 0 X X X X
0 *1 1
MACRO 2 1 0 0 X X X X
0 *1 1
MACRO 3 0 1 0 X X X X
0 *1 1
MACRO 4 1 1 0 X X X X
0 *1 1
MACRO 5 0 0 1 X X X X
0 *1 1
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM TRI
USER MANUAL V1.1
Page.8
SPEED/FADE/STROBE DIPSWITCH SETTINGS
[0=OFF 1=ON X=RESERVED FOR MACRO SELECT]
*AUDIO MODE DOES NOT REQUIRE SPEED CONTROL
SPEED/FADE/STROBE
SELECT
DIPSWITCH
1 2 3 4 5 6 7 8 9 10
SPEED 1 X X X 0 0
0 0 1
SPEED 2 X X X 1 0
0 0 1
SPEED 3 X X X 0 1
0 0 1
SPEED 4 X X X 1 1
0 0 1
STROBE X X X 1 X
0 0 1
FADE 100% X X X 0 1
0 0 1
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM TRI
USER MANUAL V1.1
Page.9
MANUAL DIPSWITCH SETTINGS [0=OFF 1=ON X=NO FUNCTION]
DIPSWITCH
COLOR SELECT 1 2 3 4 5 6 7 8 9 10
RED 25% 1 0 1 1 1
RED 50% 0 1 1 1 1
RED 100% 1 1 1 1 1
GREEN 25% 1 0 1 1 1
GREEN 50% 0 1 1 1 1
GREEN 100% 1 1 1 1 1
BLUE 25% 1 0 1 1 1
BLUE 50% 0 1 1 1 1
BLUE 100% 1 1 1 1 1
STROBE 1 1 1 1
TROUBLESHOOTING
DMX NOT RESPONDING
ENSURE THE CHANNEL ADDRESSING IS CORRECT TO YOUR CONSOLES PATCH.
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM TRI
USER MANUAL V1.1
Page.10
CHECK CABLES FOR CONTINUITY REPLACE IF NECESSARY.
NO POWER TO UNIT
CHECK THE POWERCON IS CONNECTED CORRECTLY, INSERT THE POWERCON AND
TWIST IT APPROX TEN DEGREES, IT SHOULD “CLICK” INTO POSITION.
CHECK FUSE AND/OR POWER SOURCE.
ERRATIC CONTROL WHEN IN DMX
ENSURE YOUR DMX NETWORK IS TERMINATED AT THE END OF THE CHAIN WITH AN
XLR TERMINATION PLUG.
CHECK POLARITY OF DMX CABLES.
CLEANING AND MAINTENANCE
We recommend periodic maintenance to ensure your fixture remains as good as the day you purchased it.
Ensure ventilation points are free of blockages, such as dust, balloons and small children.
Check this every month to prevent unit from possible overheating.
Clean external housing once a month with a damp cloth, a small amount of household detergent can be used to
remove buildup of oils, dust and death star debris,
Do not use solvents or acid/alkaline solutions to clean, doing so will damage the fixture.
SUPPORT AND ENQUIRIES
EMAIL
DLB@NEO-NEON.COM
DLD@NEO-NEON.COM
PHONE
+86 137 6072 6377
WWW.FACEBOOK.COM/NEONEONENTERTAINMENT
