NEO-SLIM ION RGBW
USER MANUAL V1.1
Page.1
Thank you for investing in our NEO-SLIM ION RGBW
Totally portable with it's Lithium-Ion battery cells and remote ready to give you a standalone solution for your
world of light. Coupled with it's dual IR receivers and you can set it up to your requirements with a touch of the
supplied remote. Please read through this user manual and keep it on file for your future referral.
TECHNICAL SPECIFICATIONS
LED
POWER
POWER CONSUMPTION
FUSE
CONTROL
DMX CHANNELS
DIMENSIONS
NET WEIGHT
24 1W RGBW
IN-100-240VAC 50/60hZ OUT-16V 1800mA
25W full power 12.5W half power
1A-250V/2A-125V
DMX/Master-Slave/Audio/Auto modes
4/9
L354xW298xH90mm
3.8Kgs
BATTERY SPECIFICATIONS
OPERATING 1 COL 2 COL 3 COL 4 COL
TIME FULL POWER
16
HOURS9 HOURS
6.5
HOURS
4.5
HOURS
TIME HALF POWER
32
HOURS
18
HOURS
13
HOURS9HOURS
CHARGE LIFE-500 TIMES APPROXIMATE
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM ION RGBW
USER MANUAL V1.1
Page.2
SAFETY FIRST
THIS LIGHT IS INTENDED FOR INDOORS AND UNDER ADEQUATELY PROTECTED STAGES.
DO NOT POWER IT ON WHEN THE PRODUCT IS IN THE PACKAGE ENSURE ADEQUATE VENTILATION
PRIOR TO OPERATION.
ENSURE THE UNIT'S POWER SUPPLY AND PLUG ARE ADEQUATELY GROUNDED. FAILURE TO DO SO
CAN RESULT IN ELECTRICAL SHOCK AND POSSIBLE ELECTROCUTION.
DO NOT ATTEMPT TO REPAIR THE UNIT UNLESS YOU ARE COMPETENT TO DO SO.
IF IN DOUBT SEEK PROFESSIONAL HELP.
DO NOT LOOK DIRECTLY INTO THE LIGHT SOURCE AS IT MAY CAUSE DAMAGE TO YOUR EYES.
WHAT'S INCLUDED-CHECK YOUR CONTENTS
(A) 1 SLIM RGBW
(B) 1 IEC POWER CABLE
(C) IR REMOTE CONTROL UNIT
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM ION RGBW
USER MANUAL V1.1
Page.3
GETTING STARTED
SELECT CONTROL MODE
Using the DIP-SWITCH interface you can determine the control option you require.
CONTROL DIPSWITCH
DMX 1-9 TO SET ADDRESS AUDIO #9+#10 SET TO “ON”
AUTO(MATIC) #10 SET TO “ON” MANUAL #8+#9+#10 SET TO “ON”
MASTER/SLAVE When running in AUTO/AUDIO/MANUAL simply link subsequent units with DMX cable(s).
DMX DIPSWITCH VALUES
#1=1
#2=2
#3=4
#4=8
#5=16
#6=32
#7=64
#8=128
#9=256
#10=CONTROL
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM ION RGBW
USER MANUAL V1.1
Page.4
DETAILED DIAGRAM
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM ION RGBW
USER MANUAL V1.1
Page.5
DMX CHANNEL MAPPING-SHORT MODE
DMX CHANNEL LABEL FUNCTION HEX VALUE
1 RED Linear colour 000-255
2 GREEN Linear colour 000-255
3 BLUE Linear colour 000-255
4 WHITE Linear colour 000-255
DMX CHANNEL MAPPING-FULL MODE
DMX CHANNEL LABEL FUNCTION HEX VALUE
1 Intensity Linear intensity 000-255
2 Strobe
Blackout 000-009
Linear 010-057
Random 058-105
Flash 106-153
Ramp up 154-201
Ramp down 202-249
On 250-255
3 RED Linear colour 000-255
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM ION RGBW
USER MANUAL V1.1
Page.6
DMX CHANNEL MAPPING-FULL MODE [CONTINUED]
DMX CHANNEL LABEL FUNCTION HEX VALUE
4 GREEN Linear colour 000-255
5 BLUE Linear colour 000-255
6 WHITE Linear colour 000-255
7 Macro select
No macro 000-009
Macro#1 010-031
Macro#2 032-063
Macro#3 064-095
Macro#4 096-127
Macro#5 128-159
Macro#6 160-191
Macro#7 192-223
Macro#8 224-255
8 Macro speed Slow to fast control 000-255
9 Macro time 0-100% XFADE 000-255
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM ION RGBW
USER MANUAL V1.1
Page.7
AUTO/AUDIO* DIPSWITCH SETTINGS-MACRO SELECT
[0=OFF 1=ON X=RESERVED FOR SPEED/FADE/STROBE]
*AUDIO MODE DOES NOT REQUIRE SPEED CONTROL
USE DIPSWITCH #9 & #10 IF YOU REQUIRE AUDIO MODE OPERATION.
DIPSWITCH
MACRO SELECT
1 2 3 4 5 6 7 8 9 10
MACRO 1 0 0 0 X X X X
0 *1 1
MACRO 2 1 0 0 X X X X
0 *1 1
MACRO 3 0 1 0 X X X X
0 *1 1
MACRO 4 1 1 0 X X X X
0 *1 1
MACRO 5 0 0 1 X X X X
0 *1 1
MACRO 6 1 0 1 X X X X
0 *1 1
MACRO 7 0 1 1 X X X X
0 *1 1
MACRO 8 1 1 1 X X X X
0 *1 1
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM ION RGBW
USER MANUAL V1.1
Page.8
*SPEED/FADE/STROBE DIPSWITCH SETTINGS
[0=OFF 1=ON X=RESERVED FOR MACRO SELECT]
*AUDIO MODE DOES NOT REQUIRE SPEED CONTROL
SPEED/FADE/STROBE
DIPSWITCH
1 2 3 4 5 6 7 8 9 10
SPEED 1 X X X 0 0
0 0 1
SPEED 2 X X X 1 0
0 0 1
SPEED 3 X X X 0 1
0 0 1
SPEED 4 X X X 1 1
0 0 1
STROBE X X X 1 X
0 0 1
FADE 100% X X X 0 1
0 0 1
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM ION RGBW
USER MANUAL V1.1
Page.9
MANUAL DIPSWITCH SETTINGS [0=OFF 1=ON X=NO FUNCTION]
DIPSWITCH
COLOR SELECT
1 2 3 4 5 6 7 8 9 10
RED 25% 1 0 1 1 1
RED 50% 0 1 1 1 1
RED 100% 1 1 1 1 1
GREEN 25% 1 0 1 1 1
GREEN 50% 0 1 1 1 1
GREEN 100% 1 1 1 1 1
BLUE 25% 1 0 1 1 1
BLUE 50% 0 1 1 1 1
BLUE 100% 1 1 1 1 1
WHITE 100% 1 1 1 1
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM ION RGBW
USER MANUAL V1.1
Page.10
IR REMOTE CONTROL GUIDE
No doubt you have used a remote control in your time, so here's another one to get to
grips with. Push all the buttons until you get what you need, but just in case you get
stuck, check out our guide below.
R G B W buttons activate/de-activate the red green blue and white LEDs.
Pressing a number from 1 thru 9 will set the level of the relevant colour button pushed.
Eg.Push RED then push 3 and you'll set the red channel at 30%
FADE button activates fade, you can select which colours to fade between by pushing the
RGBW buttons.
Pushing AUTO will enable the MACRO's to operate, subsequent
pushes of this button will cycle through all available macros.
The + key will set the speed of the selected macro.
Sound button activates sound mode, which does not mean your SLIM-ION will play a bar
of Zeppelin, rather it will just activate the internal MIC to allow sound to light sequencing.
Flash button will toggle the strobe and pushing a numeric key from 1-4 will set the rate of
strobe.
Blackout button cuts the light output to zero pushing again resumes the previous state.
NEO-NEON ENTERTAINMENT DIVISION
www.neo-entertainment.com
Neo-Neon LED Lighting International LTD.
Gong He Town, He Shan City
Guangdong, P.R.C. 529728
NEO-SLIM ION RGBW
USER MANUAL V1.1
Page.11
TROUBLESHOOTING
DMX NOT RESPONDING
ENSURE THE CHANNEL ADDRESSING IS CORRECT TO YOUR CONSOLES PATCH.
CHECK CABLES FOR CONTINUITY REPLACE IF NECESSARY.
NO POWER TO UNIT
CHECK BATTERY IS CHARGED.
WHEN UNIT IS FULL DISCHARGED APPROXIMATELY 10 MINUTES OF RECHARGING IS
REQUIRED TO REGAIN LIGHT OUTPUT.
ERRATIC CONTROL WHEN IN DMX
ENSURE YOUR DMX NETWORK IS TERMINATED AT THE END OF THE CHAIN WITH AN
XLR TERMINATION PLUG.
CHECK POLARITY OF DMX CABLES.
NO RESPONSE FROM IR CONTROL
RANGE FROM UNIT TO FAR OPERATING RANGE IS AT BEST 20 METERS.
REPLACE REMOTE'S INTERNAL BATTERY.
ENSURE UNIT TO REMOTES LINE OF SIGHT IS CLEAR FROM OBSTRUCTION.
CLEANING AND MAINTENANCE
We recommend periodic maintenance to ensure your fixture remains as good as the day you purchased it.
Ensure ventilation points are free of blockages, such as dust, balloons and small children.
Check this every month to prevent unit from possible overheating.
Clean external housing once a month with a damp cloth, a small amount of household detergent can be used to remove buildup
of oils, dust etc.
Do not use solvents or acid/alkaline solutions to clean, doing so will damage the fixture.
SUPPORT AND ENQUIRIES
EMAIL
DLB@NEO-NEON.COM
DLD@NEO-NEON.COM
PHONE
+86 137 6072 6377
WWW.FACEBOOK.COM/NEONEONENTERTAINMENT
