For Your Safety
NOTE! Any Changes to the Settings can ONLY be done with a valid
SIM card inserted, and the Phone connected to a Service Provider!
Please note the followi ng issues when using yo ur device
Before using your device, please read th e user ’s guide carefully!
Please switch off your device when in or around aircraft. If
automatic switch-on is enabled for such features of your device as
alarm clock and reminder, please check and can cel the settings before
boarding.
Do not expose your device to high temperature or high voltage,
such as electric applianc es or electric heating cookers. Be sure to use
your device in a normal temperature. Your device may be damaged in a
temperature high er than 55°C or lower than -10° C.
Switch off your device in an area where a potentially explosive
atmosphere exists, for example, at a chemical p lant, gas station, or o il
depot.
Always keep your hands free to operate the vehicle while
driving. Do not place your device in the area above your car’s air bag,
preventing your device from inju ring you when the air big is exp anded.
Use only approved batteries, chargers and accessories. The use
of any other types may invalidat e any approval or warranty.
Do not attempt to disasse mble your device.
Because of possible interference, please keep your device away
from electric applian ces like televisions, radio reco rders, personal
computers, cardiac pacemakers, and hearing aids. Do not place your
device near your credit cards or other magnetic storage medias.
Do not drop or shake your device. Do not knock the screen of
your device with edge tools.
Use of the phone bag or plastic phone bag may ruin th e paint on
your device.
Do not use solvents, h arsh chemicals, o r strong detergents to
clean your device. Use a soft and clean cloth to clean it.
Do not expose your device to strong sunlight, or use it in smoky
or dusty areas.
Keep your device dry. Do not use it in areas of high humidity
like bathrooms. As your device is not waterproof, do not expose it to
rains or moistu res.
Use earphones and other accessories with care. Do not touch th e
antenna unnecessarily. Use only the supplied ant enna. Unauthorized
antennas could damage your device.
To remove the charger, hold the plug, other than the power cord,
and pull out.
Never rely solely upon your device for essential
communications, for example, medical emergencies.
Keep your device out of the reach of small children.
The statement s hall require a so cket outlet. That is installed near th e
equipment and t hat shall be easily accessible.
Please follow the guidelin es below when using batteries
Before use, please carefully read user’s guide.
Use chargers indoors. If recharging in a too high temperature,
the battery may become hot, smoky, burnt, distorted, or even
explosive.
Do not remove the b attery from the mobile.
Do not leave the batte ry in too hot or too cold places.
Do not dispose of the battery in a fire as they may explode.
Never put the battery in wat er; otherwise, it may be
short-circuited, and become heat, smoky, distorted, damaged, or even
explosive.
Keep the battery out of the reach of small children.
The GSM mobile phone shall only be connected to a USB
interface of version 2.0 or higher.
Please note the following issues when using chargers
Before use, please carefully read user’ s guide and signs on the
charger surface.
Do not disassemble or modify the charger. If the power cord is
damaged, do not use the charger to reduce risks of elec tric shock, fire
and damage.
Do not touch the charger with wet hands. If the charger is
exposed to water or other liquid , cut off the power immediately.
Do not short-circuit, knock or shake the charger. Do not expose
the battery to sunshine. Do not use it in areas of high humidity like
bathrooms. As the battery is not waterproof, do not expose it to rains
or moistures.
Do not use the charger near su ch electric applian ces as
televisions and radio recorders.
Hold the charger when unp lugging it fro m the socket.
Keep the charger out of the rea ch of small children
Warning: Your d evice has a sound recorder feature. When using
it, do obey related laws and regulat ions and respect privacy and
legitimate rights of others. Users shall take full responsibilities for
improper use of this feature and unautho rized replication and
distribution of the recordings.
Getting Started
z You can make calls only after your phone has connected to the
network and you are within network coverage area
z In home screen mode, enter numbers through the keypad ,and press
Dial to make ca lls ,or press left soft key after di aling to save
numbers.
z To dial calls through contacts(phonebook)- In home serene
mode, press
The Right soft key to enter the p honebook .Here ,you can
Scroll to find your desired contact and his/her phone
number by
Quick search or Name search, and press dial to make
the call.
z
Dial calls throu gh SMS, If the SMS you received contains a
phone number, you can dial the number contained in the
SMS or
dial the sender’s
number.
z In the In box menu, select and open your desired SMS, press left
soft key to enter. Options menu, then press use number to select
the phone number contained in the SMS or choo se the sender’s
number. Then, press options again and choose to Dial or save the
number
z Press right soft key to delete the last digit of your input
number .press and hold right soft key to dear all inputs .
z After a call is connected, press right soft key to enter hands free
mode. In this mode, do not hold the device near your ears as
exposure to high volume may damage your hearing .press right
soft key again to return mode from hands f ree mode.
z Press the End key to end a call.
z Press the End k ey to cancel a re ceiving call or send ke y to
answer.
Press the # k ey to mute an inco ming call. Press the“*” key twice
to get a “+”
SMS
To go to the SMS fun ction, please navig ate to Menu>Messages >SMS
From this menu, you can check your inbox, outbox, Write message ,
Template and settings.
To scroll between input types, click the “#” while in the w rite message
screen.
If the storage for messages is used up , you cannot receive any new
message. In the Inbox, select and delete old messages. When
there is space for messag es, the messages will be delivered to your
phone.
To save your sent messages, please select the option to “save And send”
before sending the message. The sent ite ms will be saved to
your
Outbox.
MMS & Email
Your Ellips e also allows you to send and receive MMS and malls, To use
the services a short set up is req uired. Please check our website
www.stuffbyneo.com
and download the full user manual fro m the
support section to learn how to u se these services.
Navigate to menu>settings>Blue tooth
To start / stop Bluetooth connection: If you wan t to connect or
disconnect the wireless Bluetooth, please choose
Menu>settings>Bluetooth>power
TO allow other devices to see your phone, switch the visibility on b y
navigating to Menu>s ettings>Bluetooth>settings>visibil ity
Open multimedia to send photos to another mobile phone from your
memory. To send a file, go to th e file manager fro m the Main Menu and
select a file .Once you have selected a file, click on the “option” key
and select “Forward”. Here you are presented with several options.
Select the“To Bluetooth” option.
Select the “Inquiry BT Device” option for your phone to search for
other devices. Once the device that you want to send to appears, select it
and click “Bond.” It will ask you to type a password th at the receiver
also has to type. Send the file.
When receiving a file using Bluetooth, your phone will ask you to type a
password that corresponds with the senders password. On ce the right
password is typed and you accept the file, you will begin to receive the
file. This may take several minutes depending on th e size, Once the file
is received, it auto matically saved to th e “Received” folder. You can see
the received folder by going to Menu>fil e manager
Audio player
※ Warning: Listen to music at a moderate level. Continuous exposure to
high volume may damage your hearing. Do not hold the device n ear
your ear when the loudspeaker is in use, because the volume may be
extremely loud.
Navigate to Menu>Multimedia>Audio player
z The audio payer of your device can be us ed to play music files.
z On the audio player screen, press Up to play, press Left for
previous track, and press Right for Next track.
z On the player screen, press left soft key to enter “List” where you
can select music files you would like to play, If there are no file s,
please select the “Option” key and select “Ref resh List”. From
the options menu you can also select “ settings”. Only music that
is stored on you r phone or Memory card in the folde r titles “My
Music” can be shown on the lis t.
Other Items
There are many other multi media functions available in the
Menu>Multimedia List.
Camera
Audio player
FM Radio
Vi d e o R e c o r de r
Video player
Image Viewer
Sound Recorder
Melody Composer
Small children
Your device and its enhancements may contain small parts. Keep them out of the
reach of small children.
Operating environment
This device meets RF exposure guidelines when used either in the normal use
position against the ear or when positioned at least 2.2centimetres (7/8 inch) away
from the body .when a carry case, belt clip, or holder is used for body- worn
operation, it should not contain metal and should position the device the
above-stated distance from your body.
To transmit data files or messages, this device requires a quality connection to the
network. In some cases, transmission of data files or messages may be delayed
until such a connection is available. Ensure the above separation distance
instructions are followed until the transmission is completed.
Parts of the device are magnetic. Metallic materials may be attracted to the device.
Do not place credit cards or other magnetic storage media near the device, because
information stored on them may be erased.
Medical devices
Operation of any radio transmitting equipment, i ncluding wireless phones, may
interfere with the functionality of inadequately protected medical devices. Consult
a physician or the manufacturer of the medical device to determine if they are
adequately shielded from exter nal RF energy or if you have any questions. Switch
off your device in health care facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities may be using equipment
that could be sensitive to external RF energy.
Implanted medical devices
Manufacturers of medical devices recommend that a minimum separation of
15.3centimetres (6 inches) should be maintained between a wire less device and an
implanted medical device, such as a pacemaker or implanted cardioverter
defibrillator, to avoid potential interference with the medical device. Persons who
have such devices should:
z Always keep the wireless device m ore than 15.3centimetres (6 inches)
from the medical device when the wireless device is turned on.
z Not carry the wireless device in a breast pocket.
z Hold the wireless device to the ear opposite the medical device to
minimize the potential for interference.
z Turn the wireless device off immediately if there is any reason to suspect
that interference is taking place.
z Read and follow the directions from the manufacturer of their implanted
medical device. If you have any questions about using your wireless device
with an implanted medical device, consult your health care provider.
Hearing aids
Some digital wireless devices may interfere with some hearing aids. If interference
occurs, consult your service provider.
Vehicles
RF signals may affect improperly installed or inadequately shielded electronic
systems in motor vehicles such as electronic fuel injection systems. electronic
antiskid(antilock)bra king systems,
Electronic speed control systems,and air bag systems.for more inform ation, check
with the manufacturer ,or its representative, of your vehicle or any equipment that
has been added.
Only qualified personnel should ser vice the device or install the device in a vehicle.
Faulty installation or service may be dangerous and m ay invalidate any warranty
that may apply to the device. Check regul arly that all wireless device equipment in
your vehicle is mounted and operating properly. Do not stor e or carry flammable
liquids,gases, or explosive materials in the same compartment as the device,its
parts,or
Enhancements. For vehicles equipped with an air bag , remember that air bags
inflate with great force.Do not place objects,including installed or portable
wireless equipment in the area over the air bag or in the air bag deployment
area.Ifin-vehicle wir e less equipment is improperly installed and the air bag
inflates,serious injury could result.
Using your device while flying in aircraft is pr ohibited. Switch off your device
before boarding an aircraft.The use of wireless teledevices in an aircraft,may be
dangerous to the operation of the aircraft, disrupt the wireless telephone
network,and may be illegal. A dditional safety information
Potentially explosive environments
Switch off your device when in any area with a potentially explosive
atmosphere,and obey all signs and i nstructions.potentially explosive atmospheres
include areas where you would normally be abvised to turn off your vehicle
Engine.sparks in such areas could cause an explosion or fire resulting in bodily
injury or even death.switch off the device at refuelling points such as near gas
pumps at service stations.Observe re strictions on the use of radio equipment on
fuel depots, storage, and distribution areas;chemical plants; or where blast ing
operations are in progress. Areas with a potentially explosive atmosphere are often,
but not always, clearly marked. They include below deck on boats , chemical
transfer or storage facilities and areas where the air contains chemicals or particl es
such as grain, dust,or metal powders.you should check with the manufacturers of
vehicles using liquefied petroleum gas (such as propane or butane )to determine if
this device can be safely used in their vicinity.
Emergency calls
Important:
This device operates using radio signals, wireless networ ks,
landlins networks,and user-programmed func tions. If your device supports
voice calls over the internet (internet calls ),activate both the internet calls and the
cellular phone.The device w i ll attempt to make emergency calls over both
The cellular networks and through your internet call provider if both are activated.
Connections is all conditions cannot be guaranteed.you should never rely solely on
any wireless device for essential communications like medical emergencies.
To make an emergency call:
1. If the device is not on, switch it on. Check for adequate signal
strength.Depending on your device,you may also need to complete the
following:
z Insert a SIM card if your device uses one
z Remove certain call re strictions you have activated in your device .
z Change your profile from offline or flight profile mode to an active profile.
2. press the end key as many times as needed to clear the display and ready the
device for calls.
3. Enter the official emergency number for your present location.Emergency
number vary by location.
4. press the call key.
When making an emergency call, give all the necessary information as
accuratrly as possible.your wireless device may be the only means of
communication at the scene of an accident .Do not end cal l until given
permission to do so.
RF Exposure Information and Statement
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue.
Device types Ellipse (FCC ID: WWF-NEOELLIPSE) has also been tested
against this SAR limit. The highest SAR value re ported under this standard
during product certification for use at the ear is 1.457 W/kg and when
properly worn on the body is 0. 894 W/kg. This device was tested for typical
body-worn operations with the back of the handset kept 1.5cm from the body.
To maintain com pliance with FCC RF exposure requirements, use
accessories that maintain a 1.5cm separation distance between the user's
body and the back of the handset. The use of belt clips, holsters and similar
accessories should not contain metallic components in its assembly. The use
of accessories that do not satisfy thes e requirements may not comply with
FCC RF exposure requirements, and should be avoided.
This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that m ay cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such modifications
could void the user’s author ity to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant t o part 15 of the FCC Rules. These
limits are designed to provide rea sonable protection against harmful
interference in a residential installation. This equipment generates uses and
can radiate radio frequency e nergy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, t here is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an exper ienced radio/TV technici an for help
Accessories
1. USB cable
2. Charger
3. Ear Phone
4. CD ROM
5. Quick Guide
6. Warranty card
7. 1G byte T-card
8. Plant card
9. Pouch
10. Lens clearning cloth
Loading...
