Page 1
nemco
FOOD
EQUIPMENT
®
ONLY FROM
Buy once. Buy the original.
Always look for this mark of quality
Induction Range
Cookers & Warmers
Amazing new technology that’s exactly like cooking with gas—
but far more profitable!
Page 2
Game-Changing Efficiency.
Clean & Cool
Surrounding Air
Game-Changing Efficiency.
Chef-Worthy Performance.
Chef-Worthy Performance.
Nemco’s extraordinary
induction ranges mimic the
chef-level cooking performance
of conventional gas ranges,
but at a significantly higher
energy efficiency that can
put thousands of dollars to
your bottom line every year.
Page 3
Wow Your Accountant . . .
Clean & Cool
Surrounding Air
. . . Without Riling Your Chef
Nemco’s space-age-like induction technology uses a
magnetic field to energize cookware, literally making the pan
its own heating element. Thus, nearly every cent of every
dollar spent on induction cooking goes directly into your food.
By contrast, most of your gas-cooking dollar is wasted, as the
heat radiates into your kitchen—an effect that also unnecessarily increases your air-conditioning expense!
% of Energy Spend that
Actually Cooks
Nemco Induction
90%
Gas
30%
Energy Savings Off the Chart
90¢ of every induction-energy
dollar goes directly into your food,
versus only 30¢ of every gas
dollar, as most gas heat is lost up
the hood or out into the kitchen.
Equipped with an exclusive “continuous field” feature,
Nemco’s induction ranges are unlike any alternatives on the
market. ...That’s right. Other induction units are notorious for
automatically shutting off when lifting a pan from the surface
breaks the magnetic field. But Nemco’s induction maintains
the field on a lifted pan, allowing for the full scope of rangetop cooking actions.
Even chefs who traditionally
cook with gas can’t tell the difference!
Cooks Exactly Like Gas
Nemco's “continuous field”
technology maintains an energizing
effect on the pan even when lifted,
giving you the flexibility to ‘float’
the pan, ‘dip’ the edge, toss its
ingredients—essentially conduct
all the cooking techniques that,
until now, were only possible on
conventional gas ranges.
High Frequency Magnetic Field
Get Maximum Lifetime ROI
In trademark Nemco style, these induction ranges are built to
last, with glass that has the highest available impact resistance
compared to other units and a series of innovations designed
to protect the electronics inside—including a patented heat
insulation system and sensors that automatically adjust power
output to the ambient temperature.
Control Is All Yours
Nemco features simple touch controls, with the option to have the panel
built into or mounted remotely away from the unit. Remote advantages
include a timer function, seven warm-hold settings on the ranges and,
for front-of-the-house applications, the added peace of mind knowing
the controls are safely tucked away from potential customer tampering.
Nemco Induction
Gas
Electric
Say Goodbye to an Old Flame
Induction’s magnetic energy
alleviates all the potential issues
associated with pilot lights, open
flames or exposed hot-electric coils.
Even during cooking, induction’s
glass surface remains relatively
cool to the touch, minimizing the
risk of burning employees, charring
spilled foods that stain, or setting
entire establishments on fire.
Page 4
Drop-In Warmers
350–400 watts
A look so simple, sophisticated and smooth, Nemco’s dropin induction warmer models are perfect in virtually any
application, especially high-end front-of-the-house settings.
SImple Touch Control
General Specifications
Dimensions
Integrated Touch Controls
Equipment
Shipping Carton
Equipment Weight 14 lbs
Shipping Weight 16 lbs
Separately Mounted Controls
Equipment
Shipping Carton
Equipment Weight 15 lbs
Shipping Weight 17 lbs
Electrical Specification
Plug
Model Volts Watts Amps Configuration
9100* 120 350 3.0 NEMA 5-15P
9100-1* 208/240 400 2.0 NEMA 6-20P
9101 120 350 3.0 NEMA 5-15P
9101-1 208/240 400 2.0 NEMA 6-20P
*Integrated touch controls included.
(w x d x h) 14
(l x d x h) 18" x 15" x 7"
(w x d x h) 14
(l x d x h) 21" x 15" x 7"
9
/16" x 115/8" x 31/8"
9
/16" x 115/8" x 31/8"
Drop-In Ranges
1800–3500 watts
Achieve and easily maintain a sleek, clean look on your
range top with Nemco’s drop-in models that sit flush with
the counter surface and boast exceptional durability. The
glass features commercial-grade impact-resistance and
doesn’t burn spilled foods that otherwise stain.
Remote Control
General Specifications
Dimensions
Integrated Touch Controls
Equipment
Shipping Carton
Equipment Weight 14 lbs
Shipping Weight 16 lbs
Separately Mounted Controls
Equipment
Shipping Carton
Equipment Weight 15 lbs
Shipping Weight 17 lbs
Electrical Specification
Plug
Model Volts Watts Amps Configuration
Integrated Touch Controls
9110 120 1800 15.0 NEMA 5-15P
9110-C* 120 1800 15.0 NEMA 5-20P
9110-1 208/240 1800 8.6/7.5 NEMA 6-20P
9111-1 208/240 2600 12.5/10.8 NEMA 6-20P
Separately Mounted Controls
9120 120 1800 15.0 NEMA 5-15P
9120-C* 120 1800 15.0 NEMA 5-20P
9121-1 208/240 2600 12.5/10.8 NEMA 6-20P
9122-1 208/240 3500 16.8/14.6 NEMA 6-20P
*Canada.
(w x d x h) 14
(l x d x h) 18" x 15" x 7"
(w x d x h) 14
(l x d x h) 21" x 15" x 7"
9
/16" x 115/8" x 31/8"
9
/16" x 115/8" x 31/8"
Page 5
FOOD
EQUIPMENT
®
Portable Ranges
nemco
FOOD
EQUIPMENT
®
For use with portable & stockpot ranges
Buy once. Buy the original.
Always look for this mark of quality
1800–3500 watts
Take the show on the road. Nemco’s portable units are
great for temporary cooking venues or operations with
rush times that can stress kitchen space and capacity.
General Specifications
Dimensions
Equipment (w x d x h) 201/2" x 12" x 41/2"
Shipping Carton
Equipment Weight 16 lbs
Shipping Weight 18 lbs
Electrical Specification
Plug
Model Volts Watts Amps Configuration
9130 120 1800 15.0 NEMA 5-15P
9130-C* 120 1800 15.0 NEMA 5-20P
9131-1 208/240 2600 12.5/10.8 NEMA 6-20P
9132-1 208/240 3500 16.8/14.6 NEMA 6-20P
All models available with optional TempMaster™ temperature probe.
*Canada
(l x d x h) 25" x 16" x 9"
Even Better Than Cooking With Gas?
With Nemco’s proprietary TempMaster™, optional
external temperature probe, users can program
portable and stockpot induction ranges to cook
to and then hold foods at a precise temperature.
That’s control you can’t even get with gas!
Heavy-Duty Stockpot Ranges
For high-volume foods and ingredients, Nemco offers
high-power induction technology in larger-size units
capable of handling stockpot cookware.
10,000 watts
General Specifications
Dimensions
Model 9140-1
Equipment
Shipping Carton
Equipment Weight 53 lbs
Shipping Weight 60 lbs
Model 9141-1
Equipment
Shipping Carton
Equipment Weight 55 lbs
Shipping Weight 65 lbs
Electrical Specification
Plug
Model Volts Watts Amps Configuration
9140-1 208/240, 3ph 10,000 28.0/24.0 4 Wire Cord
9141-1 208/240, 3ph 10,000 28.0/24.0 4 Wire Cord
All models available with optional TempMaster™ temperature probe.
(w x d x h) 18" x 24" x 17"
(l x d x h) 28" x 22" x 17"
(w x d x h) 18" x 24" x 21
(l x d x h) 22" x 28" x 16
5
/8"
Page 6
FOOD
EQUIPMENT
®
Features:
nemco
FOOD
EQUIPMENT
®
Buy once. Buy the original.
Always look for this mark of quality
Approx Time to
Model Watts Warm/Hold Settings Power Settings Opt Temp Probe Timer Approx. Temp Range °F Boil 4 Qts Water
9100 350 1-7 - - - 95-195 9100-1 400 1-7 - - - 95-195 9101 350 1-7 - - - 95-195 9101-1 400 1-7 - - - 95-195 9130 1800 H1-H7 1-10 Ω
9131-1 2600 H1-H7 1-10
9132-1 3500 H1-H7 1-10
9110 1800 1-2 3-9 - - - 13 min.
9110-1 1800 1-2 3-8 - - - 13 min.
9111-1 2600 1-2 3-9 - - - 9 min.
9120 1800 H1-H7 1-10 - Ω - 13 min.
9121-1 2600 H1-H7 1-10 - Ω - 9 min.
9122-1 3500 H1-H7 1-10 - Ω - 6 min.
9140-1 10,000 H1-H7 1-10
9141-1 10,000 H1-H7 1-10
*Available with optional TempMaster™ temperature probe.
Ω
Ω
Ω
Ω
Ω
100-400* 13 min.
Ω
100-400* 9 min.
Ω
100-400* 6 min.
Ω
100-400* 2 min.
Ω
100-400* 2 min.
Replacement parts are available through Nemco’s 24-hour Zip Program.
Nemco reserves the right to make design, specification or model changes without notice.
Corporate HQ
301 Meuse Argonne | Hicksville, OH 43526
800.782.6761 • 419.542.7751 • f: 419.542.6690
Nemco West Distribution Center/Test Kitchen
4300 E Magnolia Street | Phoenix, AZ 85034
NemcoFoodEquip.com
Printed 5/17. Printed in the USA.
