Nellie's Wow Mop User Manual

2 CONTENTS

3

Battery Replacement Program

4

WOW Mop Components

5

Carton Contents

6

Assembly

7

Instructions for Use

9

Operation Tips

10

Troubleshooting

12

Safety Instructions & Technical Parameters

Easy to use,

powerful and

eco-friendly! You

will love your new

WOW Mop!

3 BATTERY REPLACEMENT PROGRAM

Base Battery Replacement

Batteries don’t last forever. For the sake of
our planet, check out our battery replacement
program at nelliesclean.com/our-planet.

Notes:

•Do not try to replace the battery yourself.

•Overcharging the battery may cause damage.

•Please avoid charging for more than 3 hours.

Power Button

Spray Button

Nozzle

Handle

Pad Attach
(Shadowed Area)

Decorative
Casing

Reservoir

Base

5 CARTON CONTENTS

Measuring Cup

Charging Cord User Manual

WOW Wet Floor Pads

6 ASSEMBLY

Press down the lock catch
to make the aluminum pipe
connect with the handle
and decorative casing.

Decorative
Casing

Press down the lock catch
and insert the installed tube
into the hole of the base.

Cleaning
Pads

Place the cleaning pads on the
ground, lift the machine and
place on the cleaning pads.

Base

7 INSTRUCTIONS FOR USE

Power ON/OFF

Pull back the handle. After hearing a clicking
sound, the headlamp and power indicator will
light up. Bring handle to 90 degrees to turn off.

Note:
The machine will automatically turn into “sleep mode”
after 2 minutes of no use and the full battery light will
twinkle.

Reservoir

Adding Cleaning Solution

Open the cap of the reservoir and ll using the
measuring cup to add liquid. Do not overll.

Close the cap.

Best used with Nellie’s Floor Care on hardwood,
ceramic and tile.

Note:
Maximum capacity of the reservoir is 230mL.

Operating

Press the power button on the handle to make
the cleaning pads oscillate, and press it again
to stop.

While the pads are oscillating, hold down the
spray button to spray cleaning solution. Release
button to stop.

Notes:

•Do not operate while the mop is charging.

•The longest time of spraying is 5 seconds with
one press.

Power Button

Spray Button

Battery Lights

Three battery lights will show the status of the
battery. 100%, 65% and 30%. 3 lights will ash
when the machine is low in battery indicating to
charge immediately.

Notes:

• 3 lights on 100%

• 2 lights on 65%

• 1 light on 30%

• 3 lights ashing low battery

Charging Port

First Time Charging

Pull out the rubber cork and turn it until the
whole charging port is revealed. Plug the
charger into the charging port.

Note:
Use the original equipment manufactured adapter.

Pad Changing

Unplug/turn off the machine. Ensure that the
tank is empty. Hold the mop upside down and
remove the pads from the bottom.

9 OPERATION TIPS

Turning Off

Put handle in upright position to turn off.

Cleaning Pads

Machine wash pads with fragrance-free
detergent. Do not use fabric softener.

FYI Nellie’s Laundry Soda works great!

Replacing the Handle Battery

There are two screws located underneath the
top of the handle. Remove the screws and the
teal panel. Replace the battery.

The WOW Mop requires a 23A/12V battery.

10 TROUBLESHOOTING

Fault

Unit is wobbling.

Reduced spray or no spray.

Power button does not turn on the machine.

Cause

1. Mop pads are not installed properly.

1. Reservoir may be empty.

2. System isn’t completely primed.

3. Spray nozzle on base is clogged.

1. Handle is standing upright.

Treatment

1. Turn power OFF and follow instructions on

page 8 for replacing mop pads.

1. Rell reservoir.

2. Hold spray button for 10 to 15 seconds to

make sure the solution has owed to the spray

nozzle.

3. Turn power OFF. Use a pin to clean the spray
nozzle located at the front of the machine.

1. Recline handle.

11

Fault

No power.

Machine is leaking.

Lights are on but unit won’t start vibrating.

Cause

1. Battery depleted.

2. Charging cord damaged.

3. Battery failure.

1. Cap of reservoir is not closed properly.

1. The battery in the handle is depleted.

Treatment

1. Charge battery for approximately 3 hours.

Avoid overcharging.

2. Do not use. Contact Nellie’s customer service.

3. Do not use. Contact Nellie’s customer service.

1. Close the cap properly.

1. Follow instructions on page 9 to replace the

battery in the handle.

12

SAFETY INSTRUCTIONS & TECHNICAL PARAMETERS

Usage

For home use only.

Remove large particles or substances from
the oor before using. This product is not
for sweeping or vacuuming.

In case of jam caused by small objects,
power off before removing the objects.

Do not let children use the mop as a toy.

Use a rag to clean the mop when it’s
powered off.

Do not leave any solution in the reservoir
for more than 24 hours.

114–2455 Dollarton Highway, North Vancouver, BC, Canada V7H 0A2 nelliesclean.com

Battery & Charging

Do not use charger and charging batteries
provided by any third parties.

Do not self disassemble or remodel the battery
and charger.

Keep the charger away from heating sources
such as radiators.

Do not touch the charger with wet cloths
or wet hand.

Please send the used batteries for recycling by

certied organizations or learn more about our

Battery Replacement Program at
www.nelliesclean.com/our-planet.

If there is any damage to the cable please stop
using and contact Nellie’s customer service.

Name Parameters

Battery 2000 mAh

Voltage Rating 12 V

Rated Power 35 W

Power Charger Voltage 12.6 V

Charging Time 3 - 5 h

Run Time 55 min
