NELCO CONTACT AB
Safe Operation & Maintenance Instruction
Battery Pump
NBHP 18V
–––
Version: 2017/08
Battery Pumps are carefully inspected for quality and tested for
safety. We follow ISO 9001: 2008/ ISO 14001: 2004/ IECQ QC 080001/
OHSAS 18001: 2007 Standards
ATTENTION!
Safe Operation & Maintenance Instructions must be followed.
Table of Contents
Safety Instructions .............................................................. 1
Scope of Delivery ............................................................... 2
Product Description ............................................................ 3
Strap Installation Instruction ............................................... 4
Functional Features ............................................................ 5
Battery Charging / Battery Cartidge .................................... 6
Strap Installation Instruction ............................................... 6
Maintenance ....................................................................... 7
Oil Refilling INstruction ....................................................... 8
Table of Components / Diagram of Components ................ 9
1
arrange safety equipments when
operating this tool in case accidents
happened.
operating this product. Projectiles or
hydraulic fluid can cause serious
Thank you for using NELCO products. This manual must be read
hand.
carefully prior to operating this product. Special attention should be
paid to the section “Safety Instructions”. Damages and injuries caused
by improper use of this product are NOT included in our warranty. We
would like to remind you to work safely and to keep this manual on
Safety Instructions
Follow all instructions to ensure safety.
WARNING
Read all information regarding your
hydraulic power source and be familiar
with its operation.
Keep hands and feet away from the tool
and work piece during operation, in
order to avoid injury.
ATTENTION
This product is NOT an insulator. Always
Always wear safety goggles when
injuries.
NELCO C O N TAC T A B
2
Scope of Delivery
1
Battery pump
1 2 Battery 18 V DC / Li-ion
2 3 Charger
1 4 Hydraulic hose
1
5
Shoulder strap
1 6 Instruction manual
1 7 Remote controller
1
No. Description Quantity
3
Product Description
Specifications:
Dimensions: 321.7mm(L) x 182mm(W) x 319.5mm(H)
Approximate Weight (w/0 battery): 7.3kg
Approximate Weight (with 2 batteries): 8.5kg
Max Pressure: 700 bar
Oil Required: 1500 cc
Oil Delivery:
1.2 L / min at low pressure
0.3 L / min at high pressure
Features:
Operate with powerful, high-capacity Li-ion batteries along and
interchangeable of A、B battery individual detect capacity.
Environmentally design for saving energy as automatic switch to
sleep mode after 3 minutes without any activate action.
Display related pumping pressure and battery capacity on OLED
display.
Maintenance warning attached: Buzzer alert at long deep if
crimping or cutting is not completed and losing pressure when
failure caused.
Shoulder strap for high wearing comfort.
7 modes for different applications that can be selected by the
functional knob.
NELCO C O N TAC T A B
4
Product Description
Battery Specifications:
Brand: BOSCH
Type: Lithium-ion (Li-ion)
Capacity: 4.0 Ah
Output Voltage: 18V
Charger Specifications:
Model No.: AL 1860 CV
Input Voltage: 230V
Approximate charging time per battery: 45mins <4.0Ah>
Strap Installation
The battery pumps are ready to use for overhead operation
with the secured strap as easy carrying propose.
Step 1:
Hook up the strap ring into the
hook ring that is on the handle.
Step 2:
Hook up the strap ring into the
hook ring that can be found
under the functional knob.
Step 3:
Check the strap attached the
battery pump completely and
secured.
5
Functional Features
1. Power off
2. Crimping mode:
Keep pressing the button to
advance piston. The
pressure will be released to
retract the piston when it
reaches max pressure.
3. Cutting and jack mode:
Keep pressing the button to advance the piston. The pressure will be
held when it reaches max pressure.
4. Auto mode
The piston will automatically advance to max pressure and
self-retracting when advance button is pressed.
5. Semi-auto mode
The piston will automatically advance and hold at max pressure when
the advance button is pressed, and require pressing retract button to
retract piston.
6. Setting mode:
Able user to choose the pressure unit to be PSI or BAR.
Display the work time (usage count) of this pump.
7. P: Maximum pressure / T: Current pressure
8. Battery power
※ The system counts a work time when the pressure is over 200 bars. An
alert signal will pop up to remind users to maintain the pump when the
work time is over 5000.
NELCO C O N TAC T A B
6
Battery Charging
• Remove batteries before exchanging the tool
1. Plug the AC charger plug into the
wall socket. Ensure the electrical
outlet meets the charger’s specifications.
2. Position the battery cartridge into the battery charger. The LED
indicator light will go out when the battery is fully charged.
3. Charging time for the 4.0 Ah battery cartridge is approx. 45 minutes.
When stored in the charger, the battery will stay fully charged.
Battery Cartridge
1. To remove batteries, press on the
battery latch and pull the battery out.
2. To install batteries, slide batteries
Install
Or
Remove
into the contacts until it clicks into
place. The batteries should be
secured and unmovable.
ATTENTION
head, cleaning the tool head, or changing the
hydraulic oil.
• Do not disassemble or attempt to repair the
battery cartridge. Follow battery disposal
guidelines.
7
Maintenance
• Turn off the power and release
to look for the leak.
Keep the pump free of dirt and metal chips. Use a lubricant to
clean the tool when necessary.
Routine renewal of pump oil is required. Particles mixed in the pump
oil is the most common cause of product failure.
Do NOT lift the pump by the hydraulic hose or couplers, or let the
pump drop to the ground or into the carrying case.
Do NOT keep this product in places with high temperatures, high
humidity, or direct sunlight.
Suggested working temperatures：-10°C ~ 40°C. Check hydraulic
fluid specifications.
Hydraulic fluid temperatures over 65°C might soften packings and
seals and cause fluid leaks.
The hydraulic fluid pressure should only be adjusted by NELCO
service representatives
.
Inform NELCO authorized distributors in case of any abnormalities
or malfunctions of the product.
DO NOT DISASSEMBLE OR ATTEMPT TO REPAIR THIS PUMP.
NELCO C O N TAC T A B
ATTENTION
pressure before cleaning the tool
head or pump.
• If you notice a leak on the pump, hose
or tool head, do not use your hands
8
Refilling Hydraulic Fluid
1. Make sure the oil pressure has been released to zero.
2. Remove batteries. (Picture 1)
3. Loosen the valve bolt. (Picture 1)
4. Put a funnel to easily pour in the oil. (Picture 2)
5. Pour in new hydraulic oil and make sure the amount
of the hydraulic oil reach to 1500c.c.
6. Fasten the valve bolt.
Picture 1 Picture 2
9
Table of Components
No.
Part Name
Q’ty
No.
Part Name
Q’ty
1
Housing
1
17
Compression Spring
1
2
Housing
1
18
Screw
1 3 Pump Assembly
1
19
Washer
4 4 Circuit Board
1
20
Washer
4
5
Shackle
3
21
Nuts
4
6
Valve Bolt
1
22
Connector
3 7 Plug Connector (female)
1
23
Screw
3
8
Plug Connector (male)
1
24
Screw
14 9 Release Knob
1
26
Adaptor
1
10
Shift Lever Pin
1
27
Back-up Ring
2
11
Washer
1
28
O-ring
2
12
Oil Reservoir
1
29
Circlip
1
13
Switch
1
30
Screw
4
14
Retaining Wire Ring
1
31
Pipe Clamps
2
15
Nut
1
32
Washer
10
16
Valve Bolt
1
NBHP 18V
Diagram of Components
NELCO C O N TAC T A B
10
NELCO CONTACT AB
Manufacture & Quality Certificate
We hereby certify that the following
was manufactured in accordance with our
specifications and has passed our quality inspection.
Item: Battery Pump
Model No.: NBHP 18V
Serial No.:
Date of Inspection:
Q.C. Supervisor:
For NELCO Authorized
Distributor Use Only:
NELCO product
For Industry or Individual
Buyer Use Only:
/ /
Date of Purchase (dd/mm/yy)
/ /
Date of Purchase (dd/mm/yy)
