Refrigerator
en User manual
KI121.. / KF121.. / KI131.. / KF131..
KI141..
en Table of Contents
Safety and warning information ............ 3
Information concerning disposal .......... 5
Scope of delivery .................................... 5
Room temperature, ventilation
and cavity depth ...................................... 6
Installation location ................................. 6
Connecting the appliance ..................... 6
Getting to know your appliance ........... 7
Switching on the appliance ................... 8
Setting the temperature ......................... 8
Alarm function ......................................... 8
Usable capacity ....................................... 9
Refrigerator compartment ..................... 9
Super cooling ....................................... 10
Interior fittings ....................................... 11
Sticker “OK” .......................................... 11
Switching off and disconnecting
the appliance ........................................ 11
Cleaning the appliance ....................... 12
Odours ................................................... 13
Light (LED) ............................................ 13
Tips for saving energy ........................ 13
Operating noises ................................. 14
Eliminating minor faults yourself ....... 14
Appliance self-test ............................... 16
Customer service ................................. 16
enTable of Contents
enInstruction for Use
Safety and warning information
Before you switch ON the appliance
Please read the operating and
installation instructions carefully!
They contain important information
on how to install, use and maintain
the appliance.
The manufacturer is not liable if you
fail to comply with the instructions
and warnings. Retain all documents for
subsequent use or for the next owner.
Technical safety
This appliance contains a small quantity
of environmentally-friendly but flammable
R600a refrigerant. Ensure that the tubing
of the refrigerant circuit is not damaged
during transportation and installation.
Leaking refrigerant may cause eye
injuries or ignite.
If damage has occurred
■ Keep naked flames and/or ignition
sources away from the appliance,
■ thoroughly ventilate the room for
several minutes,
■ switch off the appliance and pull out
the mains plug,
■ inform customer service.
en
The more refrigerant an appliance
contains, the larger the room must be
in which the appliance is situated.
Leaking refrigerant can form a flammable
gas-air mixture in rooms which are too
small.
The room must be at least 1 m³ per 8 g
of refrigerant. The amount of refrigerant
in your appliance is indicated on
the rating plate inside the appliance.
If the power cord of this appliance is
damaged, it must be replaced by
the manufacturer, customer service or
a similarly qualified person.
Improper installations and repairs may
put the user at considerable risk.
Repairs may be performed by the
manufacturer, customer service
or a similarly qualified person only.
Only original parts supplied by the
manufacturer may be used.
The manufacturer guarantees that
only these parts satisfy the safety
requirements.
A extension cable may be purchased
from customer service only.
3
en
Important information when using the appliance
■ Never use electrical appliances inside
the appliance (e.g. heater, electric ice
maker, etc.). Risk of explosion!
■ Never use a steam cleaner to defrost
or clean the appliance!
The steam may penetrate electrical
parts and cause a short-circuit.
Risk of electric shock!
■ Do not use pointed or sharp-edged
implements to remove frost or
layers of ice. You could damage
the refrigerant tubing.
Leaking refrigerant may ignite or
cause eye injuries.
■ Do not store products which contain
flammable propellants (e.g. spray
cans) or explosive substances
in the appliance. Risk of explosion!
■ Do not stand or support yourself on
the base, drawers or doors, etc.
■ Before defrosting and cleaning
the appliance, pull out the mains plug
or switch off the fuse. Do not pull out
the mains plug by tugging the cable.
■ Bottles which contain a high
percentage of alcohol must be sealed
and stored in an upright position.
■ Keep plastic parts and the door seal
free of oil and grease.
Otherwise, parts and door seal will
become porous.
■ Never cover or block the ventilation
openings for the appliance.
■ People (childern incl.) who have
limited physical, sensory or
mental abilities or inadequate
knowledge must not use this
appliance unless they are supervised
or given meticulous instructions.
Children in the household
■ Keep children away from packaging
and its parts.
Danger of suffocation from folding
cartons and plastic film!
■ Do not allow children to play with the
appliance!
■ If the appliance features a lock:
keep the key out of the reach of
children!
General regulations
The appliance is suitable for refrigerating
food.
This appliance is intended for use in
the home and the home environment.
The appliance is suppressed according
to EU Directive 2004/108/EC.
The refrigeration circuit has been
checked for leaks.
This product complies with the
relevant safety regulations for
electrical appliances (EN 60335-2-24).
4
Information concerning
disposal
* Disposal of packaging
The packaging protects your appliance
from damage during transit.
All utilised materials are environmentally
safe and recyclable. Please help us
by disposing of the packaging in an
environmentally friendly manner.
Please ask your dealer or inquire at your
local authority about current means of
disposal.
* Disposal of your old appliance
Old appliances are not worthless
rubbish! Valuable raw materials can be
reclaimed by recycling old appliances.
This appliance is identified
according to the European
guideline 2002/96/EC on waste
electrical and electronic
equipment – WEEE. The directive
specifies the framework for an
EU-wide valid return and re-use
of old appliances.
en
Refrigerators contain refrigerant and
gases in the insulation.
Refrigerant and gases must be disposed
of professionally. Ensure that tubing
of the refrigerant circuit is not damaged
prior to proper disposal.
Scope of delivery
After unpacking all parts, check for any
damage in transit.
If you have any complaints, please
contact the dealer from whom
you purchased the appliance or our
customer service.
The delivery consists of the following parts:
■ Built-in appliance
■ Interior fittings (depending on model)
■ Bag containing installation materials
■ Operating instructions
■ Installation manual
■ Customer service booklet
■ Warranty enclosure
■ Information on the energy
consumption and noises
m Warning
Redundant appliances
1. Pull out the mains plug.
2. Cut off the power cord and discard
with the mains plug.
3. Do not take out the trays and
receptacles: children are therefore
prevented from climbing in!
4. Do not allow children to play with
the appliance once it has spent its
useful life. Danger of suffocation!
5
en
Room temperature, ventilation and cavity depth
Ambient temperature
The appliance is designed for a specific
climate class. Depending on the climate
class, the appliance can be operated at
the following temperatures.
The climate class can be found on
the rating plate. Fig. /
Climate class Permitted ambient temperature
SN +10 °C to 32 °C
N +16 °C to 32 °C
ST +16 °C to 38 °C
T +16 °C to 43 °C
Note
The appliance is fully functional within
the room temperature limits of the
indicated climatic class. If an appliance
of climatic class SN is operated at colder
room temperatures, the appliance
will not be damaged up to a temperature
of +5 °C.
Ventilation
The air on the rear panel of the appliance
heats up. Conduction of the heated air
must not be obstructed.
Otherwise, the refrigeration unit must
work harder. This increases power
consumption. Therefore: Never cover
or block the ventilation openings!
Cavity depth
A cavity depth of 560 mm is
recommended for the appliance.
If the cavity depth is smaller – at least
550 mm – the energy consumption
increases slightly.
Installation location
Install the appliance in a dry, well
ventilated room. The installation location
should neither be exposed to direct
sunlight nor near a heat source, e. g.
a cooker, radiator, etc. If installation next
to a heat source is unavoidable,
use a suitable insulating plate or observe
the following minimum distances to a
heat source:
■ 3 cm to electric or gas cookers.
■ 30 cm to an oil or coal-fired cooker.
Connecting the appliance
After installing the appliance, wait at least
1 hour until the appliance is switched on.
During transportation the oil in
the compressor may have flowed into
the refrigeration system.
Before switching on the appliance for
the first time, clean the interior of
the appliance (see chapter “Cleaning
the appliance”).
Electrical connection
The socket must be near the appliance
and also freely accessible following
installation of the appliance.
The appliance complies with the
protection class I. Connect the appliance
to 220–240 V/50 Hz alternating current
via a correctly installed socket with
protective conductor. The socket must
be fused with a 10 to 16 A fuse.
6
en
For appliances operated in nonEuropean countries, check whether the
stated voltage and current type match
the values of your mains supply.
This information can be found on
the rating plate. Fig. /
m Warning
Never connect the appliance to
electronic energy saver plugs.
Our appliances can be used with mains
and sine-controlled inverters.
Mains-controlled inverters are used for
photovoltaic systems which are
connected directly to the national grid.
Sine-controlled inverters must be used
for isolated applications (e.g. on ships or
in mountain lodges) which are not
connected directly to the national grid.
Getting to know your appliance
Please fold out the illustrated last page.
These operating instructions refer to
several models.
The features of the models may vary.
The diagrams may differ.
Fig. !
* Not all models.
1-5 Controls
6* Fan
7 Light
8 Glass shelf
9* Extendable glass shelf
10 Vegetable container with humidity
control
11 Butter and cheese compartment
12 Door shelf
13* Vario door shelf
14 Shelf for large bottles
Controls
Fig. "
1 On/Off button
Serves to switch the appliance
on and off.
2 “super” button
Is used to switch on the super
cooling (see chapter entitled
“Super cooling”).
3 Temperature selection button
Press this button to set the
temperature.
4 Temperature display
The numbers correspond to
the set refrigerator compartment
temperatures in °C.
5 Alarm button
Used to switch off the
warning signal,
see chapter “Alarm function”.
7
