Neff KG7393I21R User Manual
Fridge-freezer
Холодильно-морозильная
комбинация
en Instruction for Use
ru Инcтpyкция пo экcплyaтaции
KG73..
KG74..
en Table of Contents
Safety and warning information ........... 3
Information concerning disposal ......... 6
Scope of delivery ................................... 7
Installation location ................................ 7
Observe ambient temperature
and ventilation ........................................ 7
Connecting the appliance .................... 8
Getting to know your appliance .......... 9
Switching the appliance on ................ 10
Setting the temperature ...................... 10
Special functions .................................. 11
Alarm functions .................................... 11
Usable capacity .................................... 12
Refrigerator compartment .................. 13
Super cooling ....................................... 14
Freezer compartment .......................... 14
Max. freezing capacity ........................ 15
ru Coдepжaниe
Укaзaния пo бeзoпacнocти
и пpeдyпpeждeния .............................. 26
Укaзaния пo yтилизaции ................... 30
Oбъeм пocтaвки .................................. 30
Mecтo ycтaнoвки ................................. 31
Teмпepaтypa oкpyжaющeй cpeды
и вeнтиляция ........................................ 31
Подключение бытового прибора ... 32
Знакомство с бытовым прибором . 33
Включение бытового прибора ....... 34
Уcтaнoвкa тeмпepaтypы .................... 35
Cпeциaльныe фyнкции ...................... 35
Функции сигнализации ..................... 36
Пoлeзный oбъeм ................................. 37
Xoлoдильнoe oтдeлeниe ................... 38
Cyпepoxлaждeниe .............................. 39
Mopoзильнoe oтдeлeниe .................. 40
Maкc. пpoизвoдитeльнocть
зaмopaживaния ................................... 40
Freezing and storing food .................. 15
Freezing fresh food ............................. 15
Super freezing ...................................... 17
Thawing frozen food ............................ 17
Interior fittings ....................................... 17
Sticker “OK” .......................................... 18
Switching off and disconnecting
the appliance ........................................ 19
Defrosting .............................................. 19
Cleaning the appliance ....................... 19
Light (LED) ............................................ 21
Tips for saving energy ........................ 21
Operating noises ................................. 22
Eliminating minor faults yourself ....... 23
Appliance self-test ............................... 25
Customer service ................................. 25
Зaмopaживaниe и xpaн
пpoдyктoв ............................................. 41
Зaмopaживaниe cвeжиx
пpoдyктoв питaния ............................. 41
Cyпepзaмopaживaниe ....................... 42
Paзмopaживaниe пpoдyктoв ............ 43
Cпeциaльнoe ocнaщeниe ................. 43
Haклeйкa «OK» ................................... 44
Bыключeниe прибора и вывoд
eгo из экcплya
Paзмopaживaниe ................................ 45
Чистка прибора .................................. 45
Ocвeщeниe (нa cвeтoдиoдax) .......... 47
Kaк cэкoнoмить элeктpoэнepгию .. 47
Paбoчиe шyмы ..................................... 48
Caмocтoятeльнoe ycтpaнeниe
мeлкиx нeиcпpaвнocтeй ................... 49
Caмoпpoвepкa приборa ................... 51
Сервисная
тaции .......................... 45
служба ............................. 51
eниe
enTable of Contents
enInstruction for Use
Safety and warning
information
Before you switch ON the
appliance
Please read the operating and
installation instructions carefully!
They contain important
information on how to install,
use and maintain the appliance.
The manufacturer is not liable if
you fail to comply with the
instructions and warnings.
Retain all documents for
subsequent use or for the next
owner.
Technical safety
The tubes of the refrigeration
circuit convey a small quantity of
an environmentally friendly but
flammable refrigerant (R600a). It
does not damage the ozone
layer and does not increase the
greenhouse effect. If refrigerant
escapes, it may injure your eyes
or ignite.
en
If damage has occurred
■ Keep naked flames and/or
ignition sources away from the
appliance,
■ thoroughly ventilate the room
for several minutes,
■ switch off the appliance and
pull out the mains plug,
■ inform customer service.
The more refrigerant an
appliance contains, the larger
the room must be in which the
appliance is situated. Leaking
refrigerant can form a
flammable gas-air mixture in
rooms which are too small.
The room must be at least 1 m³
per 8 g of refrigerant. The
amount of refrigerant in your
appliance is indicated on the
rating plate inside the appliance.
If the power cord of this
appliance is damaged, it must
be replaced by the
manufacturer, customer service
or a similarly qualified person.
Improper installations
and repairs may put the user
at considerable risk.
3
en
Repairs may be performed by
the manufacturer, customer
service or a similarly qualified
person only.
Only original parts supplied by
the manufacturer may be used.
The manufacturer guarantees
that only these parts satisfy the
safety requirements.
Do not use multiple sockets,
extension leads or adapters.
Important information when
using the appliance
■ Never use electrical
appliances inside the
appliance (e.g. heater, electric
ice maker, etc.). Explosion
hazard!
■ Never defrost or clean the
appliance with a steam
cleaner! The steam may
penetrate electrical parts and
cause a short-circuit. Risk
of electric shock!
■ Do not use pointed or sharp-
edged implements to remove
frost or layers of ice. You
could damage the refrigerant
tubes. Leaking refrigerant may
cause eye injuries or ignite.
■ Do not store products which
contain flammable propellants
(e.g. spray cans) or explosive
substances in the appliance.
Explosion hazard!
■ Do not stand on or lean
heavily against base
of appliance, drawers
or doors, etc
■ For defrosting and cleaning,
pull the mains plug out or
switch off the fuse. Do not pull
out the mains plug by tugging
on the power cord.
■ Store high-percentage alcohol
tightly closed and standing up.
■ Keep plastic parts and the
door seal free of oil and
grease. Otherwise, parts and
door seal will become
porous.
■ Never cover or block the
ventilation openings of the
appliance!
■ Do not store bottled or
canned drinks (especially
carbonated drinks) in the
freezer compartment. Bottles
and cans may burst!
■ Never put frozen food straight
from the freezer compartment
into your mouth.
Risk of low-temperature burns!
4
en
■ Avoiding placing children
and vulnerable people at
risk:
At risk are children, people
who have limited physical,
mental or sensory abilities, as
well as people who have
inadequate knowledge
concerning safe operation of
the appliance.
Ensure that children and
vulnerable people have
understood the hazards.
A person responsible for
safety must supervise or
instruct children and
vulnerable people who are
using the appliance.
Only children from 8 years
and above may use the
appliance.
Supervise children who are
cleaning and maintaining the
appliance.
Never allow children to play
with the appliance.
■ Avoid prolonged touching of
frozen food, ice or the
evaporator pipes, etc.
Risk of low-temperature burns!
Children in the household
■ Keep children away from
packaging and its parts.
Danger of suffocation from
folding cartons and plastic
film!
■ Do not allow children to play
with the appliance!
■ If the appliance features a
lock:
keep the key out of the reach
of children!
General regulations
The appliance is suitable
■ for refrigerating and freezing
food,
■ for making ice.
This appliance is intended for
use in the home and the home
environment.
The appliance is suppressed
according to EU Directive 2004/
108/EC.
The refrigeration circuit has
been checked for leaks.
This product complies with
the relevant safety regulations
for electrical appliances
(EN 60335-2-24).
This appliance is intended for
use up to a maximum height of
2000 metres above sea level.
5
en
Information concerning
disposal
* Disposal of packaging
The packaging protects your appliance
from damage during transit. All utilised
materials are environmentally safe and
recyclable. Please help us by disposing
of the packaging in an environmentally
friendly manner.
Please ask your dealer or inquire at your
local authority about current means of
disposal.
* Disposal of your old
appliance
Old appliances are not worthless
rubbish! Valuable raw materials can be
reclaimed by recycling old appliances.
This appliance is labelled in
accordance with European
Directive 2012/19/EU concerning
used electrical and electronic
appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the
framework for the return and
recycling of used appliances as
applicable throughout the EU.
m Warning
Redundant appliances
1. Pull out the mains plug.
2. Cut off the power cord and discard
with the mains plug.
3. Do not take out the trays
and receptacles: children are
therefore prevented from climbing in!
4. Do not allow children to play with
the appliance once it has spent its
useful life. Danger of suffocation!
Refrigerators contain refrigerant
and gases in the insulation. Refrigerant
and gases must be disposed
of professionally. Ensure that tubing
of the refrigerant circuit is not damaged
prior to proper disposal.
6
Scope of delivery
After unpacking all parts, check for any
damage in transit.
If you have any complaints, please
contact the dealer from whom you
purchased the appliance or our
customer service.
The delivery consists of the following
parts:
■ Free-standing appliance
■ Interior fittings (depending on model)
■ Bag containing installation materials
■ Operating instructions
■ Installation manual
■ Customer service booklet
■ Warranty enclosure
■ Information on the energy
consumption and noises
Installation location
A dry, well ventilated room is suitable as
an installation location. The installation
location should not be exposed to direct
sunlight and not placed near a heat
source, e.g. a cooker, radiator, etc. If
installation next to a heat source is
unavoidable, use a suitable insulating
plate or observe the following minimum
distances from the heat source:
■ 3 cm to electric or gas cookers.
■ 30 cm to an oil or coal-fired cooker.
The floor of the installation location must
not give way; if required, reinforce floor. If
the floor is uneven, compensate with
supports.
en
Distance from wall
When installing the appliance, ensure
that the door can be opened by 90°.
Observe ambient
temperature
and ventilation
Ambient temperature
The appliance is designed for a specific
climate class. Depending on the climate
class, the appliance can be operated at
the following temperatures.
The climate class can be found on
the rating plate. Fig. .
Climate class Permitted ambient
temperature
SN +10 °C to 32 °C
N +16 °C to 32 °C
ST +16 °C to 38 °C
T +16 °C to 43 °C
Note
The appliance is fully functional within
the room temperature limits
of the indicated climatic class. If
an appliance of climatic class SN
is operated at colder room temperatures,
the appliance will not be damaged up to
a temperature of +5 °C.
7
en
Ventilation
Fig. "
The air on the rear panel and on the side
panels of the appliance heats up.
Conduction of the heated air must
not be obstructed. Otherwise,
the refrigerating unit must work harder.
This increases power consumption.
Therefore: Never cover or block
the ventilation openings!
Connecting the
appliance
After installing the appliance, wait at least
1 hour until the appliance is switched on.
During transportation the oil in
the compressor may have flowed into
the refrigeration system.
Before switching on the appliance for
the first time, clean the interior of
the appliance (see chapter “Cleaning
the appliance”).
Electrical connection
The socket must be near the appliance
and also freely accessible following
installation of the appliance.
m Warning
Risk of electric shock!
If the length of the mains cable is
inadequate, never use multiple sockets
or extension leads. Instead, please
contact Customer Service for
alternatives.
The appliance complies with protection
class I. Connect the appliance to 220–
240 V/50 Hz alternating current via a
correctly installed socket with protective
conductor. The socket must be protected
by a 10 A to 16 A fuse.
For appliances operated in nonEuropean countries, check whether the
indicated voltage and current type match
the values of your electricity supply. This
information can be found on the rating
plate, Fig. ..
m Warning
Never connect the appliance
to electronic energy saver plugs.
Our appliances can be used with mains
and sine-controlled inverters. Mainscontrolled inverters are used
for photovoltaic systems which
are connected directly to the national
grid. Sine-controlled inverters must be
used for isolated applications (e.g. on
ships or in mountain lodges) which are
not connected directly to the national
grid.
8
Getting to know your
appliance
Please fold out the illustrated last page.
These operating instructions refer
to several models.
The features of the models may vary.
The diagrams may differ.
Fig. !
* Not all models.
A Refrigerator compartment
B Freezer compartment
1–11 Controls
12* Butter and cheese compartment
13 Shelf for small bottles
14 Shelf for large bottles
15 Light (LED)
16* Bottle shelf
17* Breakfast set
18 Cold storage compartment
19 Vegetable container with humidity
control
20* Frozen food container
en
Controls
Fig. $
1 “Super” button refrigerator
compartment
Switches super cooling on and
off.
2 Temperature display refrigerator
compartment
The numbers correspond to the
set refrigerator compartment
temperatures in °C.
3 Temperature selection buttons
refrigerator compartment
These buttons set
the temperature in the refrigerator
compartment.
4 “Fresh” button
Is used to switch fresh mode on
and off.
5 “eco” button
Is used to switch Eco mode on
and off.
6 Vacation button
Is used to switch holiday mode on
and off (see chapter entitled
Holiday mode).
7 "On/Off" button
is used to switch the whole
appliance on and off.
8 Alarm button
Used to switch off the warning
signal, see chapter “Alarm
function”.
9 “Super” button (freezer
compartment)
Switches super freezing
on and off.
10 Temperature display freezer
compartment
The numbers correspond
to the set freezer compartment
temperatures in °C.
9
en
11 Temperature selection buttons
freezer compartment
These buttons set
the temperature in the freezer
compartment.
Switching
the appliance on
Fig. $
1. Switch on the appliance with the On/
Off button 7.
A warning signal sounds,
the temperature display 10 flashes
and the alarm button 8 is lit.
2. The warning signal is switched off by
pressing the alarm button 8.
The appliance begins to cool. Light is
switched on when the door is open.
The factory has recommended
the following temperatures:
■ Refrigerator compartment: +4 °C
■ Freezer compartment: -18 °C
■ If the freezer compartment door
cannot be immediately re-opened after
it has been closed, wait until
the resulting low pressure has
equalised.
Setting
the temperature
Fig. $
Refrigerator compartment
The temperature can be set from +2 °C
to +8 °C.
Keep pressing temperature setting
button on refrigerator compartment 3,
until the required refrigerator
compartment temperature is set.
The value last selected is saved. The set
temperature is indicated on the
temperature display for the refrigerator
compartment 2.
Perishable food should not be stored
above +4 °C.
Operating tips
■ After the appliance has been switched
on, it may take several hours until
the set temperature has been
reached. Do not put any food
in the appliance beforehand.
■ The fully automatic NoFrost system
ensures that the freezer compartment
remains free of ice. Defrosting is not
required.
■ The sides of the housing are
sometimes heated slightly. This
prevents condensation in the area
of the door seal.
10
Freezer compartment
The temperature can be set from –16 °C
to –24 °C.
Keep pressing temperature setting
button freezer compartment 11 until
the required freezer compartment
temperature is set.
The value last selected is saved. The set
temperature is indicated on temperature
display for the freezer compartment 10.
Special functions
Fig. $
Fresh mode
Fresh mode gives food an even longer
shelf life.
Switching on:
Press the fresh button.
The appliance automatically sets the
following temperatures:
■ Refrigerator compartment: +2 °C
■ Freezer compartment: remains
unchanged
Switching off:
Press the fresh button.
Eco mode
The eco mode switches the appliance to
energy-saving operation.
Switching on:
Press the eco button.
en
Holiday mode
If leaving the appliance for a long
period of time, you can switch
the appliance over to the energy-saving
holiday mode.
The temperature of the refrigerator
compartment is automatically switched
to +14 °C.
Do not store any food in the refrigerator
compartment during this time.
Switching on:
Press the Vacation button.
The appliance automatically sets
the following temperatures:
■ cooling compartment: +14°C
■ Freezer compartment: remains
unchanged
Switching off:
Press the Vacation button.
Alarm functions
The appliance automatically sets
the following temperatures:
■ cooling compartment: +8°C
■ freezer compartment: -16°C
Switching off:
Press the eco button.
Door alarm
The door alarm (continuous sound)
switches on if the appliance door is open
for longer than one minute. Close
the door to switch off the warning signal.
11
en
Temperature alarm
The temperature alarm switches on
if the freezer compartment is too warm
and the frozen food is at risk of thawing.
When the alarm button 8 is pressed,
the freezer compartment temperature
display 10 indicates for five seconds
the warmest temperature reached
in the freezer compartment.
Then this value is deleted. The
temperature display for the freezer
compartment 10 indicates the set freezer
compartment temperature without
flashing.
Henceforth the “warmest temperature”
will be redefined and saved.
The alarm may switch on without any
risk to the frozen food:
■ when the appliance is switched on,
■ when large quantities of fresh food are
placed in the appliance,
■ if the freezer compartment door is
open too long.
Note
Do not refreeze thawing or thawed food.
Only ready meals (boiled or fried) may
be refrozen.
No longer store the frozen produce for
the max. storage period.
Usable capacity
Information on the usable capacity can
be found inside your appliance on
the rating plate. Fig. .
Fully utilising the freezer
volume
To place the maximum amount of frozen
food in the freezer compartment, you can
remove the containers. You can then
stack the food directly on the shelf and
on the floor of the freezer compartment.
Note
Avoid contact between food and rear
panel. Otherwise the air circulation will
be impaired.
Food or packaging could freeze to
the rear panel.
Removing the fittings
Pull out the frozen food container all
the way, lift at the front and remove.
Fig. *
Switching off the alarm
Press the alarm button 8 to switch off
the warning signal.
12
Refrigerator
compartment
The refrigerator compartment is the ideal
storage location for meat, sausage, fish,
dairy products, eggs, ready meals
and pastries.
en
Note the chill zones in the
refrigerator compartment
The air circulation in the refrigerator
compartment creates different chill
zones:
■ The coldest zones are in front of the
air outlet openings and in the chill
compartment, Fig. !/18.
Storing food
■ Store fresh, undamaged food. The
quality and freshness will then
be retained for longer.
■ In the case of ready-made products
and bottled goods, observe the bestbefore date or use-by date specified
by the manufacturer.
■ To retain aroma, colour
and freshness, pack or cover food
well before placing in the appliance.
This will prevent the transfer
of flavours and the discolouration
of plastic parts in the refrigerator
compartment.
■ Allow warm food and drinks to cool
down before placing in the appliance.
Note
Do not block air outlet openings with
food, otherwise the air circulation will be
impaired. Food which is stored directly
in front of the air outlet openings may be
frozen by the cold air flowing out.
Note
Store perishable food (e.g. fish,
sausage, meat) in the coldest zones.
■ Warmest zone is at the very top of the
door.
Note
Store e.g. hard cheese and butter in
the warmest zone. The aroma of hard
cheese can then continue to develop
and butter remains spreadable.
Vegetable container with
humidity control
Fig. (
To create the optimum storage climate
for fruit and vegetables, you can set
the humidity level in the vegetable
container:
■ Mainly vegetables as well as for a
mixed or small load – high air
humidity
■ Mainly fruit as well as for a large load
– low air humidity
13
en
Notes
■ Fruit sensitive to cold (e.g. pineapple,
banana, papaya and citrus fruit) and
vegetables sensitive to cold (e.g.
aubergines, cucumbers, zucchini,
peppers, tomatoes and potatoes)
should be stored outside
the refrigerator at temperatures
of approx. +8 °C to +12 °C for
optimum preservation of quality and
flavour.
■ Condensation may form in the
vegetable container depending on the
type and quantity of products stored.
Remove condensation with a dry cloth
and adjust air humidity in the
vegetable container with the humidity
controller.
Cold storage compartment
Fig. )
The cold storage compartment has lower
temperatures than the refrigerator
compartment. Even temperatures below
0 °C may occur.
Ideal for storing fish, meat and sausage.
Not suitable for lettuce and vegetables
and produce sensitive to cold.
The temperature of the chill
compartments can be varied using the
ventilation opening. Push temperature
controller upwards to reduce the
temperature. Push temperature controller
downwards to increase the temperature.
Fig. '
Super cooling
Super cooling sets the refrigerator
temperature to the coldest temperature
setting for approx. 6 hours. Then
the appliance automatically switches
to the temperature set prior to super
cooling mode.
Switch on super cooling mode, e.g.
■ before placing large quantities of food
in the refrigerator compartment.
■ for the fast cooling of drinks.
Switching on and off
Fig. $
Press “super” button 1.
The button is lit when super cooling is
switched on.
Note
When super cooling is switched on,
increased operating noises may occur.
Freezer compartment
Use the freezer compartment
■ To store deep-frozen food.
■ To make ice cubes.
■ To freeze food.
Note
Ensure that the freezer compartment
door has been closed properly. If
the door is open, the frozen food will
thaw. The freezer compartment will
become covered in thick ice. Also: waste
of energy due to high power
consumption!
14
Max. freezing capacity
Information about the max. freezing
capacity within 24 hours can be found
on the rating plate. Fig. .
Prerequisites for max. freezing
capacity
■ Switch on super freezing before
placing fresh products
in the compartment (see chapter
entitled “Super freezing”).
■ Remove containers; stack food
directly on the shelf and on the floor of
the freezer compartment.
■ Freeze large quantities of food
preferably in the very top
compartment where food freezes
particularly quickly and therefore also
gently.
en
Note when loading products
■ Preferably freeze large quantities
of food in the top compartment, where
food freezes particularly quickly
and therefore also gently.
■ Place the food over the whole area
of the compartments or the frozen
food containers.
Note
Food which is already frozen must not
come into contact with the food which
is to be frozen. If required, move
the frozen food to other frozen food
containers.
Storing frozen food
Insert frozen food container all the way to
ensure unrestricted air circulation.
Freezing fresh food
Freezing and storing
food
Purchasing frozen food
■ Packaging must not be damaged.
■ Use by the “use by” date.
■ Temperature in the supermarket
freezer must be -18 °C or lower.
■ If possible, transport deep-frozen food
in an insulated bag and place quickly
in the freezer compartment.
Freeze fresh and undamaged food only.
To retain the best possible nutritional
value, flavour and colour, vegetables
should be blanched before freezing.
Aubergines, peppers, zucchini and
asparagus do not require blanching.
Literature on freezing and blanching
can be found in bookshops.
Note
Keep food which is to be frozen away
from food which is already frozen.
15
en
■ The following foods are suitable for
freezing:
Cakes and pastries, fish and seafood,
meat, game, poultry, vegetables, fruit,
herbs, eggs without shells, dairy
products such as cheese, butter and
quark, ready meals and leftovers such
as soups, stews, cooked meat and
fish, potato dishes, soufflés and
desserts.
■ The following foods are not suitable
for freezing:
Types of vegetables, which are usually
consumed raw, such as lettuce or
radishes, eggs in shells, grapes,
whole apples, pears and peaches,
hard-boiled eggs, yoghurt, soured
milk, sour cream, crème fraîche and
mayonnaise.
Packing frozen food
To prevent food from losing its flavour
or drying out, place in airtight containers.
1. Place food in packaging.
2. Remove air.
3. Seal the wrapping.
4. Label packaging with contents
and date of freezing.
Unsuitable packaging:
Wrapping paper, greaseproof paper,
cellophane, bin liners and used shopping
bags.
Items suitable for sealing packaged
food:
Rubber bands, plastic clips, string, coldresistant adhesive tape, etc.
Bags and tubular film made of
polyethylene (PE) can be sealed with a
film heat sealer.
Shelf life of frozen food
Storage duration depends on the type
of food.
At a temperature of -18 °C:
■ Fish, sausage, ready meals and cakes
and pastries:
up to 6 months
■ Cheese, poultry and meat:
up to 8 months
■ Vegetables and fruit:
up to 12 months
Suitable packaging:
Cling wrap, tubular film made of
polyethylene, aluminium foil, freezer
containers.
These products are available from
specialist outlets.
16
en
Super freezing
Food should be frozen solid as quickly
as possible in order to retain vitamins,
nutritional value, appearance and flavour.
Several hours before placing fresh food
in the freezer compartment, switch on
super freezing to prevent an unwanted
temperature rise.
As a rule, 4–6 hours is adequate.
This appliance runs constantly
and the freezer compartment drops to
a very low temperature.
If the max. freezing capacity is to be
used, super freezing must be switched
on for 24 hours before the fresh produce
is placed in the freezer compartment.
Smaller quantities of food (up to 2 kg)
can be frozen without “super freezing”.
Note
When super freezing is switched on,
increased operating noises may occur.
Switching on and off
Fig. $
Press “super” button 9.
If the super freezing has been switched
on the button is lit.
Super freezing automatically switches off
after approx. 2½ days.
Thawing frozen food
Depending on the type and application,
select one of the following options:
■ at room temperature
■ in the refrigerator
■ in an electric oven, with/without fan
assisted hot-air
■ in the microwave
m Caution
Do not refreeze thawing or thawed food.
Only ready meals (boiled or fried) may
be refrozen.
No longer store the frozen produce for
the max. storage period.
Interior fittings
Shelves and containers
You can reposition the inner shelves
and the containers in the door as
required: pull shelf forwards, lower
and swivel out to the side. Lift
the container and remove.
17
Loading...
