Page 1
D58ML67N0
The integrated rangehood: offers a sleek and seamless design in
the kitchen with fully integrated installation.
√ Extraction rate: at 820 m3/h, it quickly ensures optimal kitchen air
quality.
√ LED lighting: for perfect, energy-efficient illumination of the
cooktop.
√ Intensive speed setting with reset: automatically resets the hood
to regular speed setting after 6 min.
Features
Technical Data
Typology : Traditional
Approval certificates : Australia Standards, CE, VDE
Length electrical supply cord (cm) : 150
Required niche size for installation (HxWxD) : 418mm x 836mm x
264mm
Minimum distance above an electric hob : 500
Minimum distance above a gas hob : 650
Net weight (kg) : 11.0
Type of control : Electronic
Maximum output air extraction (m3/h) : 610
Boost position output recirculating (m3/h) : 370
Maximum output recirculating air (m3/h) : 320
Boost position air extraction (m³/h) : 820
Number of lights : 2
Noise level (dB) : 64
Diameter of air outlet (mm) : 150 / 120
Grease filter material : Washable aluminium
EAN code : 4242004187172
Connection Rating (W) : 272
Current (A) : 3
Voltage (V) : 220-240
Frequency (Hz) : 50
Plug type : Gardy plug w/ earthing
Installation typology : Built-in
'!2E20AE-bihbhc!
Optional accessories
Z5135X3 Recirculating kit
86 cm Fully integrated rangehood
1/2
Page 2
D58ML67N0
86 cm Fully integrated rangehood
Features
Design & Innovation
●
For installation in a kitchen cabinet
●
Appliance colour: Stainless steel
●
Rim ventilation
●
Filter cover glass
●
Glass plate clear glass black printed
Power and Mode of Operation
●
Electronic controls
●
Push button controls (3 power levels plus intensive setting) with
Electronic display
●
Extraction rate according to EN 61591 ø 15 cm:
max. Normal use 610 m³/h
Intensive 820 m³/h
●
Noise min./max. Normal Level: 41/64 dB
Noise max. Intensive setting: 71 dB
●
Suitable for ducted extraction and recirculation
●
Accessories required for recirculated extraction: Recirculating kit
Comfort & Convenience
●
Automatic intensive revert setting - 6 min
●
Automatic run on time - 30 min
●
Noise level according to EN 60704-3 und EN 60704-2-13 exhaust
air:
Max. normal use: 64 dB(A) re 1 pW (50 dB(A) re 20 µPa sound
pressure)
Intensive: 71 dB(A) re 1 pW (57 dB(A) re 20 µPa sound pressure)
●
Twin channel high performance fan motor
●
EfficientDrive BLDC technology
●
2 x 1 Watt LED lights
●
Dishwasher safe metal grease filters
●
Saturation indicator for grease filters
Technical Information
●
Built-in dimensions: width: 84 cm, depth: 26 cm
●
Dimensions exhaust air (HxWxD): 418-418 x 860 x 300 mm
●
120 or 150 mm tube connection diameter
●
Power rating: 272 W
●
Average Energy Consumption: 52.6 kWh/year
●
Electrical cable length 1.5 m
2/2
