NEC PS7141E-1A, PS7141EL-1A DATA SHEET
2003, 2006
DESCRIPTION
The PS7141E-1A and PS7141EL-1A are solid state relays containing GaAs LEDs on the light emitting side (input
side) and MOS FETs on the output side.
They are suitable for analog signal control because of their low offset and high linearity.
The PS7141EL-1A has a surface mount type lead.
FEATURES
• 1 channel type (1 a output)
• Designed for AC/DC switching line changer
• Small package (6-pin DIP)
• Low offset voltage
• Ordering number of taping product: PS7141EL-1A-E3, E4: 1 000 pcs/reel
• Pb-Free product
• Safety standards
• UL approved: File No. E72422
• BSI approved: No. 8806/8807
• SEMKO approved: No. 313447
• DEMKO approved: No. 312887
• NEMKO approved: No. P4202453
• FIMKO approved: No. FI 20732
APPLICATIONS
• Exchange equipment
• Measurement equipment
• FA/OA equipment
<R>
<R>
The mark <R> shows major revised points.
The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.
DATA SHEET
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
6-PIN DIP, 400V BREAK DOWN VOLTAGE
NORMALLY OPEN TYPE
1-ch Optical Coupled MOS FET
Solid State Relay
OCMOS FET
PS7141E-1A
,
PS7141EL-1A
Document No. PN10439EJ02V0DS (2nd edition)
Date Published July 2006 NS CP(K)
Printed in Japan
−NEPOC Series−
PACKAGE DIMENSIONS (in millimeters)
9.25±0.5
3.5
±0.3
4.15±0.3
3.3±0.3
0.5±0.1
2.54
1.34±0.1
0.25 M
0 to 15˚
7.62
6.5±0.5
9.25±0.5
6.5±0.5
0.10
+0.10
–0.05
0.9±0.25
9.60±0.4
3.5
±0.3
1.34±0.1
0.25 M
2.54
PS7141E-1A
PS7141EL-1A
1. LED Anode
2. LED Cathode
3. NC
4. MOS FET Drain
5. MOS FET Source
6. MOS FET Drain
123
654
TOP VIEW
1. LED Anode
2. LED Cathode
3. NC
4. MOS FET Drain
5. MOS FET Source
6. MOS FET Drain
123
654
TOP VIEW
Data Sheet PN10439EJ02V0DS
2
PS7141E-1A,PS7141EL-1A
MARKING EXAMPLE
No. 1 pin
Mark
PS7141E-1A
NL601
Country Assembled
Type Number
Assembly Lot
6
01
Year Assembled
(Last 1 Digit)
LN
Rank Code
In-house Code
(L: Pb-Free)
Week Assembled
<R>
Data Sheet PN10439EJ02V0DS
3
PS7141E-1A,PS7141EL-1A
ORDERING INFORMATION
Part Number Order Number Solder Plating
Specification
Packing Style Safety Standard
Approval
Application Part
Number
*1
PS7141E-1A PS7141E-1A-A Pb-Free Magazine case 50 pcs Standard products PS7141E-1A
PS7141EL-1A PS7141EL-1A-A (UL, BSI, SEMKO,
PS7141EL-1A-E3 PS7141EL-1A-E3-A Embossed Tape 1 000 pcs/reel DEMKO, NEMKO,
PS7141EL-1A-E4 PS7141EL-1A-E4-A FIMKO approved)
*1 For the application of the Safety Standard, following part number should be used.
<R>
Data Sheet PN10439EJ02V0DS
4
PS7141E-1A,PS7141EL-1A
ABSOLUTE MAXIMUM RATINGS (TA = 25°C, unless otherwise specified)
Parameter Symbol Ratings Unit
Diode Forward Current (DC) IF 50 mA
Reverse Voltage VR 5.0 V
Power Dissipation PD 50 mW
Peak Forward Current
*1
IFP 1 A
MOS FET Break Down Voltage VL 400 V
Continuous Connection A IL 120 mA
Load Current
*2
Connection B 150
Connection C 250
Pulse Load Current
*3
(AC/DC Connection)
ILP 240 mA
Power Dissipation PD 560 mW
Isolation Voltage
*4
BV 1 500 Vr.m.s.
Total Power Dissipation PT 610 mW
Operating Ambient Temperature TA −40 to +85 °C
Storage Temperature Tstg −40 to +100 °C
*1 PW = 100
µ
s, Duty Cycle = 1%
*2 Conditions: I
F ≥ 5 mA. The following types of load connections are available.
Connection A V
L
(AC/DC)
1
6
25
4
3
I
L
L
Connection B
Connection C
1
6
2
5
43
I
L
L
V
L
(DC)
+
–
1
6
2
5
4
3
I
L
I
L
L
V
L
(DC)
+
–
1
6
2
5
4
3
I
L
L
V
L
(DC)
+
–
I
L
+ I
L
*3 PW = 100 ms, 1 shot
*4 AC voltage for 1 minute at T
A = 25°C, RH = 60% between input and output
Pins 1-3 shorted together, 4-6 shorted together.
Data Sheet PN10439EJ02V0DS
5
PS7141E-1A,PS7141EL-1A
