NEC NM-302E, NM-352E Owner's Manual
MICROWAVE OVEN
OWNER’S MANUAL & COOKING GUIDE
MODEL : NM-302E
NM-352E
PLEASE READ THIS OWNER’S MANUAL
THOROUGHLY BEFORE OPERATING.
2
You cannot operate your oven with the door open due to the safety interlocks built into the door
mechanism. These safety interlocks automatically switch off any cooking activity when the door is opened;
which in the case of a microwave oven could result in harmful exposure to microwave energy.
It is important not to tamper with the safety interlocks.
Do not place any object between the oven front face and the door or allow food or cleaner residue to
accumulate on sealing surfaces.
Do not operate your oven if it is damaged. It is particularly important that the oven door closes properly and
that there is no damage to the: (1) door(bent), (2) hinges and latches (broken or loosened), (3) door seals
and sealing surfaces.
Your oven should not be adjusted or repaired by anyone except qualified service personnel.
Warning
Precautions to avoid possible exposure to excessive microwave energy.
Please ensure cooking times are correctly set as over cooking may result in the FOOD catching
fire and subsequent damage to your oven.
When heating liquids, e.g. soups, sauces and beverages in your microwave oven, overheating the liquid
beyond boiling point can occur without evidence of bubbling. This could result in a sudden boil over of the
hot liquid. To prevent this possibility the following steps should be taken:
1. Avoid using straight sided containers with narrow necks.
2. Do not overheat.
3. Stir the liquid before placing the container in the oven and again halfway through the heating time.
4.
After heating, allow to stand in the oven for a short time, stir or shake again carefully and check the
temperature before consumption to avoid burns (especially, contents of feeding bottles and baby food jars).
5. The appliance is not intended for use by children and infirm persons without supervision. Young children
should be supervised to ensure that they do not play with the appliance.
Warning
Always allow food to stand after being cooked by microwaves and check the temperature of
them before consumption especially contents of feeding bottles and baby food jars.
How the Microwave Oven Works
Microwaves are a form of energy similar to radio and television waves and ordinary daylight. Normally,
microwaves spread outwards as they travel through the atmosphere and disappear without effect.
Microwave ovens, however, have a magnetron which is designed to make use of the energy in microwaves.
Electricity, supplied to the magnetron tube, is used to created microwave energy.
These microwaves enter the cooking area through openings inside the oven. A turntable or tray is located
at the bottom of the oven. Microwaves cannot pass through metal walls of the oven, but they can penetrate
such materials as glass, porcelain and paper, the materials of which microwave-safe cooking dishes are
constructed.
Microwaves do not heat cookware, though cooking vessels will eventually get hot from the heat generated
by the food.
A very safe appliance
Your microwave oven is one of the safest of all home appliances. When the door is opened, the
oven automatically stops producing microwaves. Microwave energy is converted completely to
heat when it enters food, leaving no “left over” energy to harm you when you eat your food.
PRECAUTIONS
3
PRECAUTIONS 2
CONTENTS 3
UNPACKING & INSTALLING 4
FEATURE DIAGRAM 6
CONTROL PANEL 6
OPERATING INSTRUCTIONS 7
SETTING CLOCK 7
JET START 7
TIME COOKING 7
2 STAGE COOKING 8
MICROWAVE POWER LEVELS 8
CHILD LOCK 8
ONE TOUCH COOKING 8
ONE TOUCH COOKING CHART 9
CUSTOM SET 10
MORE/LESS 11
AUTO WEIGHT DEFROST 12
MEAT 13
POULTRY 13
FISH 14
HEATING OR REHEATING GUIDE 15
FRESH VEGETABLE CHART 16
MICROWAVE-SAFE COOKWARE 17
FOOD CHARACTERISTICS & MICROWAVE COOKING 18
SAFETY PRECAUTIONS 20
QUESTION & ANSWERS 21
TECHNICAL SPECIFICATIONS 22
CONTENTS
4
UNPACKING & INSTALLING
Place your oven on a flat, level surface but make sure there is at least 10 cm of space on the
top, rear and sides so there is air flow for ventilation. Exhaust outlets are located in the back and
side of your oven. Blocking the outlets can damage your oven. THIS OVEN IS DESIGNED FOR
BUILDING IN. (Not over a heat source)
Unpack your oven and place it on a flat level surface.
By following the basic steps on these two pages you will be able to quickly check that your oven
is operating correctly. Pay particular attention to the guidance on where to install your oven.
When unpacking your oven make sure you remove all accessories and packing. Check to make
sure that your oven has not been damaged during delivery.
THIS OVEN SHOULD NOT BE USED FOR COMMERCIAL
CATERING PURPOSES
GLASS TRAY
ROLLER REST
5
UNPACKING & INSTALLING
Plug your oven into a standard household socket. Make sure your oven is the only appliance
connected to the socket. If your oven does not operate properly, unplug it from the
electrical socket and then plug it back in.
The DISPLAY will count down from 3 minutes. When it reaches 0 it will sound three BEEPS.
Open the oven door and test the temperature of the water. If your oven is operating the water
should be HOT. Be careful when removing the container it may be hot.
YOUR OVEN IS NOW INSTALLED
Fill a microwave safe container with 300 ml (1/2 pint) of water. Place on the GLASS TRAY
and close the oven door. If you have any doubts about what type of container to use please
refer to page 17.
Press the JET START button six times to set 3 minutes of cooking time. You will hear a
BEEP each time you press the button. Your oven will start before you have finished the sixth
press; don’t worry this is normal.
Open your oven door by pressing the DOOR OPEN button. Place the ROLLER REST inside
the oven and place the GLASS TRAY on top.
6
FEATURE DIAGRAM
Oven Front Plate
Window Door Screen
Door Seal
Display Window
Control Panel
Door Open Button
Safety Door Lock System
Turntable
Roller Rest
NOTE: A beep sounds when a pad on the
control panel is touched to indicate
setting has been entered.
CONTROL PANEL
Auto Cook
Auto Reheat
Potato
Frozen
Food
Fresh
Vegetables
Start
Pizza
More
1. Meat
2. Poultry
3. Fish
Time
Power
Custom
set
Jet Start
Less
Clock
Stop
Clear
Beverages
Baked
Food
Auto
Weight
Defrost
Dinner
Plate
123
4560
789
Your oven will be packed with the following
materials:
Glass Turntable .......................... 1 each
Owner's Manual &
Cooking Guide ............................ 1 each
Roller Rest .................................. 1 each
This microwave oven is designed for
household use only. It is not recommended
for commercial purposes.
7
SETTING CLOCK
This is a 12 hour clock.
When your oven is plugged in for the first time or
when power resumes after a power interruption,
the numbers in the display reset to 0.
NOTE:
To erase an ERROR, touch STOP/CLEAR pad.
JET START
A time-saving pad, this simplified control lets you
quickly set and start microwave cooking without
the need to touch START.
NOTE:
If you touch JET START, it will add 30 seconds up
to 3 minutes; after 3 minutes, every touch will add
1 minute up to 99 min 59 seconds.
TIME COOKING
This function allows you to cook food for a desired
time. And in order to give you the best results,
there are 10 power level settings in addition to
HI-POWER because many foods need slower
cooking (at less than HI-POWER).
When the cooking time is over, two short and one
long tone sounds. The word END shows in the
display window. Then the oven shuts itself off.
NOTE :
If you do not select the power level, the oven will
operate at power HIGH. To set HI-POWER
cooking, skip steps 4 & 5 above.
1. Touch STOP/CLEAR.
2. Touch CLOCK.
3. Enter the time by using
the number key pads.
[1], [1], [1], and [1].
4. Touch CLOCK.
The clock starts
counting.
➠➠
➠
Example:To set 11:11.
OPERATING INSTRUCTIONS
1. Touch STOP/CLEAR.
2. Touch JET START
4 times.
The oven begins
cooking and display
shows time counting
down.
Example:
To set
JET START
cooking 2 minutes.
1. Touch STOP/CLEAR.
2. Touch TIME.
3. Enter 5 minutes
30 seconds by touching
[5], [3],and [0].
4. Touch POWER.
P-HI appears in the
display. This is to tell you
that the oven is set on HI
unless a different power
setting is chosen.
5. Touch 8.
To select power level 80%.
Display shows P-80.
6. Touch START.
➠➠ ➠
➠➠
Example:To cook food on 80% Power(Power8)
for 5 minutes 30 seconds.
➠
Stop
Clear
Stop
Clear
Time
Power
8
Start
5 3 0
Stop
Clear
Jet Start
Clock
Clock
1 1 1 1
8
OPERATING INSTRUCTIONS (CONT’D)
2 STAGE COOKING
For Two Stage cooking, repeat time cooking
steps 2 through 5 on the previous page before
touching the START pad for additional Time and
Power program you want to add.
Auto Weight Defrost can be programmed before
the first stage to defrost first and then cook.
MICROW AVE POWER LEVELS
Your microwave oven is equipped with eleven
power levels to give you maximum flexibility and
control over cooking. The table below will give you
some idea of which foods are prepared at each of
the various power levels.
* The chart below shows the power level settings
for your oven.
MICROWAVE POWER LEVEL CHART
Power
Level
Use
* Boiling water.
* Browning beef mince.
* Making candy.
*
Cooking poultry, fish & vegetable pieces.
* Cooking tender cuts of meat.
* Reheating rice, pasta, & vegetables.
* Reheating prepared foods quickly.
* Cooking egg, milk and cheese dishes.
* Cooking cakes, breads.
* Melting chocolate.
* Cooking veal.
* Cooking whole fish.
* Cooking puddings and custard.
* Cooking ham, whole poultry, lamb.
* Cooking rib roast, sirloin tip.
* Thawing meat, poultry and seafood.
* Cooking less tender cuts of meat.
* Cooking pork chops, roast.
* Taking chill out of fruit.
* Softening butter.
*
Keeping casseroles and main dishes warm.
* Softening butter and cream cheese.
* Standing time.
* Independent timer.
High
9
8
7
6
5
4
3
2
1
0
CHILD LOCK
This is a unique safety feature that prevents
unwanted oven operation. Once the child lock is
set, no cooking can take place.
When child lock was already set, if you touch
START or one touch cook pad refer to page 9,
display shows LOCK. You can cancel the child
lock as follows.
ONE TOUCH COOKING
One Touch Cooking made easy! Your oven’s
menu has been preprogrammed to cook food
automatically. Tell the oven what you want then
let your microwave oven cook your selections.
1. Touch STOP/CLEAR for
3 seconds.
Touch and hold
STOP/CLEAR until LOCK
appears in the display and
two beeps are heard.
LOCK remains in the
display.
To set the child lock
1. Touch and hold
STOP/CLEAR until LOCK
disappears in the display.
The time of day returns to
the display window.
To cancel the child lock
1. Touch STOP/CLEAR.
* Place potatoes in the
oven and close the door.
2. Touch POTATO.
The oven begins the
cooking you selection
without the need to
touch START. Be sure
to close the door before
selecting categories.
➠
Example: To cook POTATOES, simply follow
the step below.
Stop
Clear
Stop
Clear
Stop
Clear
Potato
