Page 1

DVD RECORDER/ VIDEO CASSETTE RECORDER

OWNER’S MANUAL

MODEL : NDRV-62

Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely.

PAL

RC289-W_BAUSNNK_5875

Page 2

Safety Precautions

This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

WARNING: Do not install this equipment in a confined space such as a book case or similar unit.

CAUTION:

Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over heating. The openings should be never be blocked by placing the product on a bed, sofa, rug or other similar surface.This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instruction have been adhered to.

CAUTION: CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED AVOID EXPOSURE TO THE BEAM.

CAUTION:

This DVD Recorder employs a Laser System.

To ensure proper use of this product, please read this owner’s manual carefully and retain for future reference should the unit require maintenance, contact an authorized service location (see service procedure).

Use of controls, adjustments, or the performance of procedures other than those specified herein may result in hazardous radiation exposure.

To prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser radiation when open. DO NOT STARE INTO BEAM.

CAUTION: The apparatus should not be exposed to water (dripping or splashing) and no objects filled with liquids, such as vases, should be placed on the apparatus.

CAUTION concerning the Power Cord

Most appliances recommend they be placed upon a dedicated circuit;

That is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be certain.

Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized servicer.

Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance.

To disconnect power from the mains, pull out the mains cord plug. When installing the product, ensure that the plug is easily accessible.

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK

OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

 The appliance is not intended for use by young

children or infirm persons without supervision.

 Young Children should be supervised to ensure that

they do not play with appliance.

 If the appliance is supplied from a cord extension

set or an electrical portable outlet device, the cord extension set on electrical portable outlet device must be positioned so that it is not subject to splashing or ingress of moisture.

Page 3

INTRODUCTION

Table of Contents

INTRODUCTION

Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . 2

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . 3

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10

Recordable Discs . . . . . . . . . . . . . . . . . . . . . . . 4

Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . 4

Disc-related terms . . . . . . . . . . . . . . . . . . . . . . 5

About Symbols . . . . . . . . . . . . . . . . . . . . . . . . . 5

About DVD-R and DVD-RW disc . . . . . . . . . . . . 6

About DVD+R and DVD+RW disc . . . . . . . . . . . 6

About DVD recording . . . . . . . . . . . . . . . . . . . . 7

Remote Control Operation Range . . . . . . . . . . . 8

Recording time and picture quality . . . . . . . . . . 9

Using an USB Memory Stick. . . . . . . . . . . . . . . 9

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . 10

Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Remote Control Overview . . . . . . . . . . . . . . . . 12

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

HOOKUP

Connections . . . . . . . . . . . . . . . . . . . . . . . . 14-18

Connecting to the Aerial . . . . . . . . . . . . . . . . . 14

Connections to Your TV. . . . . . . . . . . . . . . . . . 14

Connecting to an Amplifier . . . . . . . . . . . . . . . 15

Accessory Audio/Video (A/V) Connections

to Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting a Digital Camcorder . . . . . . . . . . . 16

Before Operation. . . . . . . . . . . . . . . . . . . . . 17-28

Auto Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Using the Home Menu . . . . . . . . . . . . . . . . . . 17

General Settings . . . . . . . . . . . . . . . . . . . . 17-21

•Auto Programming . . . . . . . . . . . . . . . 17-18

• Program Edit . . . . . . . . . . . . . . . . . . . . 18-19

• Clock Set . . . . . . . . . . . . . . . . . . . . . . . . . 20

• TV Aspect . . . . . . . . . . . . . . . . . . . . . . . . 20

• VCR Play System. . . . . . . . . . . . . . . . . . . 20

•Power Save Mode . . . . . . . . . . . . . . . . . . 20

•Factory Set . . . . . . . . . . . . . . . . . . . . . . . 21

Language Settings . . . . . . . . . . . . . . . . . . . . . 21

• Display Language. . . . . . . . . . . . . . . . . . . 21

• Disc Language . . . . . . . . . . . . . . . . . . . . . 21

Audio Settings . . . . . . . . . . . . . . . . . . . . . . . . 22

• Dolby Digital. . . . . . . . . . . . . . . . . . . . . . . 22

• DTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

• MPEG . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

• Sampling Frequency. . . . . . . . . . . . . . . . . 22

• DRC (Dynamic Range Control). . . . . . . . . 22

Lock (Parental Control) Settings. . . . . . . . . 23-24

• Set Password. . . . . . . . . . . . . . . . . . . . . . 23

• Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

• Area Code . . . . . . . . . . . . . . . . . . . . . . . . 24

Recording Settings . . . . . . . . . . . . . . . . . . 24-25

• Disc Record Mode . . . . . . . . . . . . . . . . . . 24

• VCR Record Mode . . . . . . . . . . . . . . . . . . 24

• VCR Record System . . . . . . . . . . . . . . . . 24

•DV Record Audio . . . . . . . . . . . . . . . . . . . 25

•Auto Chapter . . . . . . . . . . . . . . . . . . . . . . 25

Disc Settings . . . . . . . . . . . . . . . . . . . . . . . 25-27

• Initialize . . . . . . . . . . . . . . . . . . . . . . . . . . 25

• Finalize . . . . . . . . . . . . . . . . . . . . . . . . . . 26

• Disc Label . . . . . . . . . . . . . . . . . . . . . . . . 26

• Disc Protect . . . . . . . . . . . . . . . . . . . . . . . 27

• PBC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

•Auto Play . . . . . . . . . . . . . . . . . . . . . . . . . 27

• About DivX(R) . . . . . . . . . . . . . . . . . . . . . 27

General Explanation of On-Screen Display . . . 28

PLAYBACK

Operation with DVD and Video CD . . . . . . . 29-32

Playing a DivX Movie Disc. . . . . . . . . . . . . . . . 33

Audio CD and MP3/WMA Operation . . . . . . 34-35

Playing an Audio CD or MP3/WMA Disc . . . . . 34

Music menu options . . . . . . . . . . . . . . . . . . . . 34

JPEG File Operation . . . . . . . . . . . . . . . . . . 36-37

VCR Mode Tape Playback . . . . . . . . . . . . . . . . 38

RECORDING

Basic Recording . . . . . . . . . . . . . . . . . . . . . 39-40

Basic Recording from a TV . . . . . . . . . . . . . . . 39

Instant Timer Recording . . . . . . . . . . . . . . . . . 39

Copying from DVD to VCR . . . . . . . . . . . . . . . 40

Copying from VCR to DVD . . . . . . . . . . . . . . . 40

Timer Recording . . . . . . . . . . . . . . . . . . . . . 41-42

Recording from an External Input . . . . . . . 43-44

Recording from an External Components . . . . 43

Recording from a Digital Camcorder . . . . . . . . 43

What is DV? . . . . . . . . . . . . . . . . . . . . . . . . . . 44

EDITING

Title List and Chapter List Menu . . . . . . . . 45-48

Title and Chapter Editing . . . . . . . . . . . . . . 49-54

Titles, Chapters and Parts. . . . . . . . . . . . . . . . 49

Adding Chapter Markers . . . . . . . . . . . . . . . . . 49

Changing Title Thumbnails . . . . . . . . . . . . . . . 49

Making a New Playlist. . . . . . . . . . . . . . . . . . . 50

Adding Additional Title/Chapters to the Playlist 50

Deleting a Title/Chapter . . . . . . . . . . . . . . . . . 51

Deleting a Part . . . . . . . . . . . . . . . . . . . . . . . . 51

Naming a Title . . . . . . . . . . . . . . . . . . . . . . . . 52

Combining Two Chapters Into One . . . . . . . . . 52

Moving a Playlist Chapter . . . . . . . . . . . . . . . . 53

Protect a Title . . . . . . . . . . . . . . . . . . . . . . . . . 53

Hide a Title/Chapter . . . . . . . . . . . . . . . . . . . . 53

Divide One Title Into Two . . . . . . . . . . . . . . . . 54

Time Search . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Additional Information . . . . . . . . . . . . . . . . . . . 55

Overwrite Recording . . . . . . . . . . . . . . . . . . . . 55

Viewing Title List menu displayed on other

DVD recorders or players . . . . . . . . . . . . . . . . 55

Playing Your Recordings on other

DVD Players (Finalizing a Disc). . . . . . . . . . . . 55

REFERENCE

Language Code and Area Code List . . . . . . . . 56

Troubleshooting . . . . . . . . . . . . . . . . . . . . . 57-58

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 59

Page 4

Overview

Recordable Discs

DVD-RW (Digital Video Disc - ReWritable):

These Discs can be recorded on repeatedly. Recordings can be erased, then you can record again on the same Disc.

DVD-R (Digital Video Disc - Recordable):

These Discs can be recorded only once. After you finalize a DVD-R, you cannot record on it or edit it any more.

DVD+RW (Digital Video Disc + ReWritable):

These Discs can be recorded on repeatedly. Recordings can be erased, then you can record again on the same Disc.

DVD+R (Digital Video Disc + Recordable):

These Discs can be recorded only once. After you finalize a DVD+R, you cannot record on it or edit it any more.

DVD+R DL (Digital Video Disc + Recordable; Double Layer): Storage space

is nearly doubled with double layer DVD+R media, allowing consumers to burn up to

8.5GB of video on a single DVD+R disc.

otes

– This recorder cannot record CD-R or CD-RW discs. –

DVD-R/RW, DVD+R/RW and CD-R/RW discs recorded using a personal computer or a DVD or CD recorder may not play if the disc is damaged or dirty, or if there is dirt of condensation on the recorder’s lens.

– If you record a disc using a personal computer, even

if it is recorded in a compatible format, there are cases in which it may not play because of the settings of the application software used to create the disc. (Check with the software publisher for more detailed information.)

– The company does not hold any responsibility to

compensate the contents which should have been recorded, and any losses or damages (e.g. losses of business profit, or business intermission) that may arise from malfunction of this recorder (not recording/editing as intended). Problems arising in the following situations are included.

• When a DVD disc recorded on this recorder is used in a DVD recorder of another manufacturer, or used (insertion, playback, recording or editing) in a personal computer DVD drive.

• When a DVD that has been used as above is used again in this recorder.

• When a DVD disc recorded in a DVD recorder of another manufacturer, or in a personal computer DVD drive is used.

Playable Discs

DVD (8 cm / 12 cm disc)

Video CD (VCD) (8 cm / 12 cm disc)

Audio CD (8 cm / 12 cm disc)

In addition, this unit can play DVD-R/DVD-RW discs; DVD+R/DVD+RW discs; CD-R/CD-RW discs that contain audio titles, MP3 files, WMA files, or JPEG files; and SVCD.

otes

– Depending on the conditions of the recording equip-

ment or the CD-R/RW (or DVD±R/±RW) disc itself, some CD-R/RW (or DVD±R/±RW) discs cannot be played on the unit.

– Do not attach any seal or label to either side (the

labeled side or the recorded side) of a disc.

–

Do not use irregularly shaped CDs (e.g., heart-shaped or octagonal). Doing so may result in malfunctions.

Regional code of the DVD Recorder and DVDs

This DVD Recorder is designed and manufactured for playback of Region 4 encoded DVD software. The region code on the labels of some DVD discs indicates which type of DVD Recorder can play those discs. This unit can play only DVD discs labeled 4 or ALL. If you try to play any other discs, the message “Incorrect region code. Can’t play back” will appear on the TV screen. Some DVD discs may not have a region code label even though their playback is prohibited by area limits.

otes on DVDs and Video CDs

Some playback operations of DVDs and Video CDs may be intentionally fixed by software manufacturers. As this unit plays DVDs and Video CDs according to disc content designed by the software manufacturer, some playback features of the unit may not be available or other functions may be added. Refer also to the instructions supplied with the DVDs and Video CDs. Some DVDs made for business purposes may not be played on the unit.

Page 5

Overview (Continued)

Disc-related terms

Title (DVD only)

The main film content or accompanying feature content or music album. Each title is assigned a title reference number enabling you to locate it easily.

Chapter (DVD only)

Sections of a picture or a musical piece that are smaller than titles. A title is composed of one or several chapters. Each chapter is assigned a chapter number to enable you to locate the chapter you want. Depending on the disc, chapters may not be labeled.

Track (Video CD and audio CD only)

Sections of a picture or a musical piece on a video CD or an audio CD. Each track is assigned a track number, enabling you to locate the track you want.

Scene

On a video CD with PBC (Playback control) functions, moving pictures and still pictures are divided into sections called “Scenes”. Each scene available is displayed on the Scene menu and assigned a scene number, enabling you to locate the scene you want. A scene may be composed of one or several tracks.

Types of video CDs

There are two types of video CDs:

Video CDs equipped with PBC (Version 2.0)

PBC (Playback control) functions allow you to interact with the system via menus, search functions, or other typical computer-like operations. Moreover, high resolution still pictures can be played if they are included on the disc.

Video CDs not equipped with PBC (Version 1.1)

Operated in the same way as audio CDs, these discs allow playback of video pictures as well as sound, but they are not equipped with PBC.

About Symbols

About the symbol display

“ ” may appear on the TV screen during operation. This icon means the function explained in this owner’s manual is not available on that specific disc.

About the disc symbols for instructions

A section whose title has one of the following symbols are applicable only to those discs represented by the symbol.

Many functions of this recorder are dependent on the recording mode. One or more of the symbols ( , ,

) appear by each function explained in this manual so that you can see at a glance whether it’s relevant for the disc loaded.

DVD-R/RW with Video recording mode

DVD-RW with VR recording mode DVD+R disc DVD+RW disc DVD-Video disc Video CDs Audio CDs MP3 files JPEG files DivX files VHS Tape

The finalized DVD disc is as DVD-Video disc

DivX

DivX is the name of a revolutionary new video codec which is based on the new MPEG-4 compression standard for video.You will be able to play DivX movies using this recorder.

VHS

DivX

JPEG

MP3

VCD

DVD

+RW

Video

+RW+RVR

Video

INTRODUCTION

Page 6

Overview (Continued)

About DVD-R and DVD-RW disc

How are DVD-R and DVD-RW discs different?

The essential difference between DVD-R and DVD-RW is that DVD-R is a record-once medium, while DVD-RW is a re-recordable/erasable medium.You can re-record/ erase a DVD-RW disc approximately 1,000 times.

Can I play my recordable discs in a regular DVD player?

Generally, DVD-R discs and DVD-RW discs recorded in Video mode are playable in a regular DVD player, but they must be ‘finalized’ first. This process fixes the contents of the disc to make them readable to other DVD players as DVD-Video discs. DVD-RW discs recorded in VR (Video Recording) mode are playable in some players.

This indicates a product feature that is capable of playing DVD-RW discs recorded with Video Recording format.

What are ‘recording modes’?

There are two recording modes available using this recorder: VR mode and Video mode. When recording to a DVD-R disc, recordings are always in Video mode. DVD-RW discs can be formatted for VR mode recording or Video mode recording.

VR mode recording

•4 different picture quality/recording time settings available (XP, SP, LP, EP)

• Not playable on regular DVD players

• Recordings can be extensively edited

Video mode recording

•4 different picture quality/recording time settings available (XP, SP, LP, EP)

• Playable on regular DVD players (after finalizing)

• Limited editing features

ote

DVD-Video Format (Video mode) is a new format for recording on DVD-R/RW and DVD+R/RW discs that was approved by the DVD Forum in 2000. You may therefore experience problems playing recordable DVD discs in some players. Symptoms include video artifacts, audio and/or video dropouts and playback suddenly stopping. Our company cannot take responsibility for problems playing discs recorded on this recorder in other players.

Is editing a DVD like editing a video tape?

No. When you edit a video tape you need one video deck to play the original tape and another to record the edits. With DVD, you edit by making a ‘Playlist’ of what to play and when to play it. On playback, the recorder plays the disc according to the Playlist.

About word ‘Original’ and ‘Playlist’

Throughout this manual, you will often see the words Original and Playlist to refer to the actual content and the edited version.

• Original: content refers to what’s actually recorded on the disc.

• Playlist: content refers to the edited version of the disc — how the Original content is to be played.

About DVD+R and DVD+RW disc

How are DVD+R and DVD+RW discs different?

The essential difference between DVD+R and DVD+RW is that DVD+R is a record-once medium, while DVD+RW is a re-recordable/erasable medium. You can re-record/ erase a DVD+RW disc approximately 1,000 times.

DVD+RW mode recording

•5 different picture quality/recording time settings available (XP, SP, LP, EP)

• Playable on regular DVD players

• The edited contents is playable on regular DVD players only after finalizing

• Recordings can be edited the title/chapter

DVD+R mode recording

•5 different picture quality/recording time settings available (XP, SP, LP, EP)

• Playable on regular DVD players (after finalizing)

•Any edited contents are not be compatible on regular DVD players. (Hide, chapter combine, added chapter mark, etc.)

• Limited title/chapter editing features

DVD +R (Double Layer)

Double layer recording technology offers two recordable layers on a single DVD disc, providing nearly double the capacity of 4.7GB single layer DVDs. The greatest, most valuable benefit of double layer recording technology is increased capacity. Storage space is nearly doubled with double layer DVD+R media, allowing consumers to burn up to 8.5GB of video on a single DVD+R disc.

Page 7

Overview (Continued)

About DVD recording

otes

• This recorder cannot make recordings on CD-R or CD-RW discs.

• Our company takes no responsibility for recording failure due to power cuts, defective discs, or damage to the recorder.

•Fingerprints and small scratches on a disc can affect playback and/or recording performance. Please take proper care of your discs.

Disc types and recording formats, modes, and settings

This recorder can play various kinds of DVD discs: prerecorded DVD-Video discs, DVD-RW, DVD-R, DVD+RW and DVD+R discs. The disc format for DVD-R discs is always “Video format”—the same as pre-recorded DVD-Video discs. This means that once finalized, you can play a DVD-R in a regular DVD player.

By default, the DVD-RW disc format is Video format, though you can change this to Video Recording format, if required. (Reinitializing the disc will erase the contents of the disc.) The recording mode is closely related to the disc format. If the disc format is Video Recording format, then the recording mode is VR mode; if the disc format is Video mode, then the recording mode is Video mode (except for DVD-Video, which is not recordable, and so does not have a recording mode). Within the recording modes (which are fixed for the whole disc) are the record settings. These can be changed as required for each recording and determine the picture quality and how much space the recording will take up on the disc.

Notes for recording

• The recording times shown are not exact because the recorder uses variable bit-rate video compression. This means that the exact recording time will depend on the material being recorded.

• When recording a TV broadcast, if the reception is poor or the picture contains interference, the recording times may be shorter.

• If you record still pictures or audio only, the recording time may be longer.

• The displayed times for recording and time remaining may not always add up to exactly the length of the disc.

• The recording time available may decrease if you heavily edit a disc.

• If using a DVD-RW disc, make sure you change the recording format (Video mode or VR mode) before you record anything on the disc. See page 25 (Initialize) for how to do this.

• When using a DVD-R disc, you can keep recording until the disc is full, or until you finalize the disc. Before you start a recording session, check the amount of recording time left on the disc.

• When using a DVD-RW disc in Video mode, recording time available will only increase if you erase the last title recorded on the disc.

•The Erase Title option in the Title List-Original menu only hides the title, it does not actually erase the title from the disc and increase the recording time available (except for the last recorded title on a DVD-RW disc in Video mode).

•The overwrite recording is available with DVD+RW disc.

•Even though the recordable time of MLP mode with DVD+R DL discs is about 11 hours which is similar to single layer discs, it is because the resolution of DVD+R DL disc is higher than that of single layer discs.

Disc type Disc format Recording mode Functions

DVD-Video Video format n/a Playback only

DVD-RW Video Recording VR mode Playback, recording, Original/Playlist editing

format

Video format Video mode Playback, limited recording, limited editing (default)

DVD-R Video format Video mode Playback, limited recording, limited editing

DVD+RW +RW Video format DVD+RW Playback, limited recording, Title/Chapter editing

DVD+R(DL) +R Video format DVD+R Playback, limited recording, limited Title/Chapter editing

INTRODUCTION

Page 8

Overview (Continued)

Restrictions on video recording

•You cannot record copy-protected video using this recorder. Copy-protected video includes DVD-Video discs and some satellite broadcasts. If copy-protected material is encountered during a recording, recording will pause or stop automatically and an error message will be displayed on-screen.

• Video that is ‘copy-once only’ can only be recorded using a DVD-RW disc in VR mode with CPRM (see below).

• NTSC format signals from the analog or the DV inputs is not recorded correctly with this recorder.

• Video signals in SECAM format (from the built-in TV tuner or from the analog inputs) are recorded in PAL format.

What is ‘CPRM’?

CPRM is a copy protection system (with scramble system) only allowing the recording of ‘copy once’ broadcast programs. CPRM stands for Content Protection for Recordable Media. This recorder is CPRM compatible, which means that you can record copy-once broadcast programs, but you cannot then make a copy of those recordings. CPRM recordings can only be made on DVD-RW discs formatted in VR mode, and CPRM recordings can only be played on players that are specifically compatible with CPRM.

• Recording equipment should be used only for lawful copying and you are advised to check carefully what is lawful copying in the country in which you are making a copy. Copying of copyright material such as films or music is unlawful unless permitted by a legal exception or consented to by the rights owner.

• This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision corporation. Reverse engineering or disassembly is prohibited.

• CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN CASE OF 625 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPATIBILITY WITH THIS MODEL 625p RECORDER, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER.

Remote Control Operation Range

Point the remote control at the remote sensor and press the buttons.

Remote Control Battery Installation

Detach the battery cover on the rear of the remote control, and insert two R03 (size AAA) batteries with and aligned correctly.

Caution

Do not mix old and new batteries. Never mix different types of batteries (standard, alkaline, etc.).

Reset the Recorder

If you observe any of the following symptoms...

 The front panel display is not working.  The Recorder is not operating normally.

...you can reset the Recorder as follows:

 Press and hold the POWER button for at least five

seconds. This will force the unit to power off. Press the POWER button again to turn the unit back on.

 Unplug the power cord, wait at least five seconds,

and then plug it in again.

Page 9

INTRODUCTION

Overview (Continued)

Recording time and picture quality

There are five preset recording quality modes:

 XP – Highest quality setting, gives about

1 hour of recording time on a DVD (4.7GB).

 SP –

Default quality, sufficient for most applications, gives

about 2 hours of recording time on a DVD (4.7GB).

 LP – Slightly lower video quality, gives about 4 hour of

recording time on a DVD disc (4.7GB).

 EP – Lowest video quality, gives about 6 hour of

recording time on a DVD (4.7GB).

ote

You may see a fragmented picture or distorted subtitle during playing back the contents recorded in EP or MLP mode.

Using an USB Memory Stick

This unit can play the MP3 / WMA / JPEG files contained in the USB Memory Stick.

Inserting/Removing the USB Memory Stick

Inserting the USB Memory Stick

Insert straight-in until it fits into place.

Removing the USB Memory Stick

Withdraw the USB Memory Stick carefully.

otes

 Keep the USB Memory Stick out of reach of children.

If swallowed, seek medical advice immediately.

 This unit supports only USB Flash Memory with

FAT16 or FAT32 format.



Do not extract the USB Memory Stick while in use (play etc.).

 This unit may not support some USB memory stick.

Compatible USB Memory Stick

1. USB Memory Stick which require additional program installation when you have connected it to a computer, are not supported.

2. USB Flash Drive: USB Memory Stick that support USB1.1.

Using the USB Memory Stick

1. Insert an USB Memory Stick.

2. Press HOME on the remote control.

3. Select [MUSIC] or [PHOTO] option.

4. Select [USB] then press ENTER. Details for the options are on page 17.

5. Press RETURN (O) to exit the MUSIC or PHOTO List menu before extracting the USB Memory Stick.

otes

 The USB Memory Stick option in the HOME menu

is not selectable if the unit is in VCR mode.

 For details on each operation item, refer to relevant

pages.

Page 10

Overview (Continued)

Precautions

Handling the unit

When shipping the unit

The original shipping carton and packing materials come in handy. For maximum protection, re-pack the unit as it was originally packaged at the factory.

When setting up the unit

The picture and sound of a nearby TV, VCR, or radio may be distorted during playback. In this case, position the unit away from the TV, VCR, or radio, or turn off the unit after removing the disc.

To keep the surface clean

Do not use volatile liquids, such as insecticide spray, near the unit. Do not leave rubber or plastic products in contact with the unit for a long period of time. They will leave marks on the surface.

Cleaning the unit

To clean the cabinet

Use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit.

Notes on Discs

Handling discs

Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints will not get on the surface. Do not stick paper or tape on the disc.

Storing discs

After playing, store the disc in its case. Do not expose the disc to direct sunlight or sources of heat, or leave it in a parked car exposed to direct sunlight, as there may be a considerable temperature increase inside the car.

Cleaning discs

Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the center outward.

Do not use strong solvents such as alcohol, benzine, thinner, commercially available cleaners, or anti-static spray intended for older vinyl records.

NoYes

Page 11

INTRODUCTION

Front Panel

POWER

Switches the Recorder ON or OFF.

2. Disc Tray Insert a disc here.

3. PLAY/PAUSE (N/X) Starts playback. Pause playback or recording temporarily, press again to exit pause mode.

4. STOP (x) Stops playback or recording..

5. REC (z) Starts recording. Press repeatedly to set the recording time.

6. PROG. (V / v ) Scans up or down through memorized channels.

7. DUBBING Press to copy DVD to VCR (or VCR to DVD).

8. Z DVD Opens or close the disc tray.

9. Display window Shows the current status of the Recorder.

10. Remote Sensor Point the Recorder remote control here.

11. DVD/VCR Toggles control between the DVD deck and the VCR deck.

12. P/SCAN When you use the COMPONENT OUTPUT jacks, you can change the resolution 576i to 576p for the Progressive Scan output.

13. Cassette Compartment (VCR deck) Insert a video cassette here.

14. USB Port Connect an USB Memory Stick.

15. DV INPUT Connect the DV output of a digital camcorder.

16. AV IN 2 (VIDEO IN/AUDIO IN (Left/Right)) Connect the audio/video output of an external source (Audio system, TV/ Monitor, VCR, Camcorder, etc.).

17. Z VCR Ejects the tape in the VCR deck.

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17

Page 12

Remote Control Overview

POWER

Switches the recorder ON or OFF.

DVD

Select the Recorder’s function mode to

DVD.

VCR

Select the Recorder’s function mode to

VCR.

EJECT, OPEN/CLOSE

- Opens and closes the disc tray.

- Ejects the tape in the VCR deck.

0-9 numerical buttons

Selects numbered options in a menu.

CLEAR

- Removes a mark on the Marker Search menu.

- Reset tape counter to zero.

AV/INPUT

Changes the input to use for recording

(Tuner, AV1-3, or DV IN).

AUDIO ( )

Selects an audio language (DVD) or an

audio channel (CD).

SUBTITLE ( )

Selects a subtitle language.

ZOOM

Enlarges DVD video image.

I.SKIP (INSTANT SKIP)

Skips 30 seconds forward on the disc

(about the length of a typical TV com-

mercial).

z REC

Starts recording. Press repeatedly to set

the recording time.

REC MODE

Selects the recording mode:

XP, SP, LP, EP or MLP.

DUBBING

Press to copy DVD to VCR (or VCR to

DVD).

TITLE

Displays the disc’s Title menu, if

available.

CHP. ADD

Inserts a chapter marker when playing/

recording a VR mode DVD-RW (and

DVD+RW/+R) disc.

Feature is not available.

These buttons are not available

BACKWARD / FORWARD (m/M)

DVD: Search backward or forward.

- VCR: Rewinds the tape during the STOP mode, for fast reverse picture search and Advances the tape during the STOP mode, fast forward picture search.

SKIP (. / >)

Go to next chapter or track. Returns to beginning of current chapter or track or go to previous chapter or track.

PAUSE/STEP (X)

Pause playback temporarily / press repeatedly for frame-by-frame playback.

PLAY (N)

Starts playback.

STOP (x)

Stops playback or recording.

HOME

Accesses or removes the HOME menu.

b / B / v / V (left/right/up/down)

Selects an option in the menu.

PR/CH TRK (+/-)

Select channel programme of the recorder.

- To adjust tracking.

- To control vertical tremble during picture

still.

DISC MENU/LIST

Accesses menu on a DVD disc, Title List or Playlist menu.

ENTER

Acknowledges menu selection.

DISPLAY

Accesses On-Screen Display.

RETURN (O)

- Removes the menu.

- Displays the menu of a video CD with PBC.

PLAY MODE

Accesses the play mode function (Repeat, Repeat A-B).

MARKER

Marks any point during playback.

Displays Marker Search menu.

THUMBNAIL

Selects a thumbnail picture for the current title and chapter for use in the Original and Playlist menu.

Page 13

INTRODUCTION

Rear Panel

Caution Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

ANTENNA IN

Connect the aerial to this terminal.

COAXIAL (Digital audio output jack)

Connect to digital (coaxial) audio equipment.

AC Power Cord

Plug into the power source.

S-VIDEO OUTPUT

Connect to a S-Video Input on TV.

OPTICAL (Digital audio output jack)

Connect to digital (optical) audio equipment.

ANTENNA OUT

Passes the signal from the ANTENNA IN jack to your TV/monitor

VIDEO/AUDIO OUTPUT (Left/Right)

Connect to a TV with video and audio inputs.

AUDIO OUTPUT (Left/Right)

Connect to a TV with audio inputs.

COMPONENT OUTPUT (Y P

B PR

)

Connect to a TV with Y Pb Pr inputs.

INPUT1 (VIDEO / AUDIO (Left/Right))

Connect the audio/video output of an external source (Audio system, TV/Monitor, VCR, Camcorder).

Page 14

Connections

ips



Depending on your TV and other equipment you wish to connect, there are various ways you could connect the recorder. Use only one of the connections described below.



Please refer to the manuals of your TV, VCR, Stereo System or other devices as necessary to make the best connections.

Caution

– Make sure the Recorder is connected directly to the

TV. Tune the TV to the correct video input channel.

–

Do not connect the Recorder’s AUDIO OUTPUT jack to the phono in jack (record deck) of your audio system.

– Do not connect your Recorder via your VCR.

The DVD image could be distorted by the copy protection system.

Connecting to the Aerial

Remove the aerial cable plug from your TV set and insert it into the aerial socket at the back of the recorder. Plug one end of the aerial cable into the TV socket on the recorder and the other end into the aerial input socket on your TV set.

RF coaxial connection

Connect the ANTENNA OUT jack on the Recorder to the aerial input jack on the TV using the 75-ohm Coaxial Cable supplied (R). The ANTENNA OUT jack passes the signal through from the ANTENNA IN jack.

Connections to Your TV

Make one of the following connections, depending on the capabilities of your existing equipment.

Video connection

Connect the VIDEO OUT jack on the Recorder to the video in jack on the TV using the video cable (V).

S-Video connection

Connect the S-VIDEO OUTPUT jack on the Recorder to the S-Video in jack on the TV using the S-Video cable

(S).

Component Video connection

Connect the COMPONENT OUTPUT jacks on the Recorder to the corresponding input jacks on the TV using an Y Pb Pr cable (C).

Progressive Scan

connection

If your television is a high-definition or “digital ready” television, you may take advantage of the recorder’s progressive scan output for the highest video resolution possible. If your TV does not accept the Progressive Scan format, the picture will appear scrambled if you try Progressive Scan on the recorder.

Connect the COMPONENT OUTPUT jacks on the Recorder to the corresponding input jacks on the TV using an Y Pb Pr cable (C).

otes

– Set the resolution to “576p” by pressing P/SCAN for

progressive signal, see page 11.

– Progressive scan does not work with the S-VIDEO

connection.

– If you are using the COMPONENT OUTPUT jacks,

but are connecting the unit to a standard (analog) television, set the resolution to “576i”.

Audio (Left/Right) Connection

Connect the left and right AUDIO OUTPUT jacks of the Recorder to the audio left and right IN jacks on the TV using the audio cables (A1 or A2). Do not connect the Recorder’s AUDIO OUTPUT jack to the phono in jack (record deck) of your audio system.

Aerial

ANTENNA

INPUT

Rear of TV

AUDIO INPUT

VIDEO INPUT

Rear of Recorder

Rear of TV

S-VIDEO

COMPONENT/PROGRESSIVE

INPUT

SCAN VIDEO INPUT

S A

VIDEO INPUT

Rear of Recorder

Rear of TV

S-VIDEO

INPUT

COMPONENT/PROGRESSIVE

SCAN VIDEO INPUT

VIDEO

INPUT

AUDIO INPUT

Page 15

HOOKUP

Connections (Continued)

Connecting to an Amplifier

Connecting to an amplifier equipped with two channel analog stereo or Dolby Pro Logic ll/ Pro Logic

Connect the Left and Right AUDIO OUTPUT jacks on the Recorder to the audio left and right in jacks on your amplifier, receiver, or stereo system, using the audio cables (A).

Connecting to an amplifier equipped with two channel digital stereo (PCM) or to an Audio/ Video receiver equipped with a multi-channel decoder (Dolby Digital™, MPEG 2, or DTS)

Connect one of the Recorder’s DIGITAL AUDIO OUTPUT jacks (OPTICAL O or COAXIAL X) to the corresponding in jack on your amplifier. Use an optional digital (optical O or coaxial X) audio cable.

You will need to activate the recorder’s digital output. (See “Audio Settings” on page 22).

Digital Multi-channel sound

A digital multi-channel connection provides the best sound quality. For this you need a multi-channel Audio/Video receiver that supports one or more of the audio formats supported by your Recorder (MPEG 2, Dolby Digital and DTS). Check the receiver manual and the logos on the front of the receiver.

Caution:

Due to the DTS Licensing agreement, the digital output will be in DTS digital out when DTS audio stream is selected.

otes

–

If the audio format of the digital output does not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all.

– Six Channel Digital Surround Sound via digital con-

nection can only be obtained if your receiver is equipped with a Digital Multi-channel decoder.

–To see the audio format of the current DVD in the on-

screen display, press AUDIO.

– This recorder does not perform internal (2 channel)

decoding of a DTS sound track. To enjoy DTS multi channel surround, you must connect this recorder to a DTS compatible receiver via one of this recorder’s digital audio outputs.

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

Rear of Recorder

Amplifier (Receiver)

OPTICAL

DIGITAL INPUT

COAXIAL

AUDIO INPUTDIGITAL INPUT

Page 16

Connections (Continued)

Accessory Audio/Video (A/V) Connections to Recorder

Connect the INPUT1 or AV IN 2 on the recorder to the audio/video out jacks on your accessory component, using audio/video cables.

Connecting a Digital Camcorder

Using the front panel DV IN jack, it is possible to connect a DV digital camcorder or video deck or DVD-R/RW recorder and digitally transfer DV tapes or DVD-R/RW discs to DVD-R/RW.

Use a DV cable (not supplied) to connect the DV in/out jack of your DV camcorder/video deck to the front panel DV IN jack of this recorder.

ote

 This jack is for connection to DV equipment only.

It is not compatible with digital satellite tuners or D-VHS video decks.

 Do not disconnect the DV cable while recording the

contents of the connected digital camcorder.

DV Digital Camcorder

IN/OUT

Rear of Recorder

Front of Recorder

Page 17

HOOKUP

Before Operation

Auto Set Up

After resetting the unit, the Initial Setup Wizard function sets the language, tuner channels and clock automatically.

Select a language for the Setup menu and onscreen display. Use v / V to select a language

then press ENTER.

Please check your antenna connections. Press ENTER to move next step.

Press ENTER to begin the channel search.

Enter the necessary information for date and time.

b / B (left/right): Moves the cursor to the previous

or next column.

v / V (up/down): Changes the setting at the

current cursor position.

Press ENTER to confirm your setting.

Press ENTER to exit the Setup menu.

Using the Home Menu

From the Home Menu screen you can access certain functions.

Press HOME.

The Home menu appears. The unit will be in tuner mode always when the Home menu appears.

Use b / B to select the desired option.



Setup

Start: Displays the Setup menu.



- Auto Ch. Scan: Link to the Auto Programming. (on page 17 to 18)

- PR Edit: Link to the Program Edit. (page 18)

- Timer Record: See page 41.



Movie: Plays back the movie of the VCR or DISC.

Or Displays Movie menu.




- Disc: Displays Photo List menu for disc.

- USB: Displays Photo List menu for USB Memory Stick.



Music

- Disc: Displays Music List menu for disc.

- USB: Displays Music List menu for USB Memory Stick.



Easy Menu

- Dubbing: Copys the contents of a DVD to a VHS tape (and vice versa). Use b / B to select a mode and use v / V to select “OK”.

Disc Manager: See “Disc Settings” on page 25 to 27.

- Rec. Mode: See “Recording Settings” on page 24 to 25.

- DV Input: Changes to DV Input mode.

Use v / V to select the desired setting then press ENTER to confirm your selection.

Press HOME to exit the Home menu.

ote

The Movie, Photo and Music menus are only enabled when there are the Movie, Photo and Music files detected on inserted media.

General Settings

Auto Programming

This Recorder is equipped with a frequency synthesized tuner capable of receiving up to 99 TV channels.

Preparation:



Connect the Recorder to the desired type of aerial, as shown in ‘Connecting to the Aerial’ on page 14.

Page 18

Before Operation (Continued)

Press HOME.

The Home menu appears.

Use b / B to select the Setup option.

While the Start option is selected, press ENTER.

Press B to move to the second level.

Use v / V to select the Auto Programming option.

Press B to move to the third level.

“Start” icon is highlighted.

Press ENTER to begin the channel search.

The tuner will automatically cycle through all available channels in the area and place them in the tuner’s memory.

Program Edit (PR Edit in Home Menu)

You can edit a channel manually (add, delete, name, move, etc.).

Press HOME.

The Home menu appears.

Use b / B to select the Setup option.

While the Start option is selected, press ENTER.

Press B to move to the second level.

Use v / V to select the Program Edit option then press B to move to the third level.

“Edit” icon is highlighted.

Press ENTER.

Program List menu appears.

Use v / V to select a PR number then press ENTER.

Program List options appear on the left side of the menu display.

Use v / V to select an option then press ENTER to confirm.

Program Edit: Edits the selected program. Station Rename: Edits the station name. Move: Moves the program’s location on the

program list. Delete: Deletes the program from program list.

Press RETURN (O) repeatedly to exit Program List menu.

Program Edit

You can perform a search to select and store TV channels manually.

1. Use v / V to select a program on the Program List

menu then press ENTER. Program List options appear on the left side of the Program List menu.

2. Use v / V to select ‘Program Edit’ option from the

options then press ENTER. Program Edit menu appears.

3. See the descriptions on below to use Program Edit menu.

b / B (left/right): Moves the cursor to the previous or next column.

v / V (up/down): Changes the setting at the current cursor position.

PR: Indicates program number (display only)

Seek: Searches for a station automatically. Use

b / B to select Seek option then press v / V. Searching stops when the recorder tunes in a station.

Ch.: Changes the channel number to edit. Use b / B to select Ch. option then press v / V.

MFT: Changes the frequency for fine tuning. Use b / B to select MFT option then press v / V.

4. Choose OK then press ENTER to confirm the setting and returns to the Program List menu.

Page 19

HOOKUP

Before Operation (Continued)

Program Edit (Continued)

Station Rename

You can name stations independently. Names can be up to 5 characters long.

1. Use v / V to select a program on the Program List

menu then press ENTER. Program List options appear on the left side of the Program List menu.

2. Use v / V to select ‘Station Rename’ option from

Program List options then press ENTER. Keyboard menu appears.

3. Enter a name for the station. Use vVbBto select

a character then press ENTER to confirm your selection.

• English/Latin Capital: Switches the keyboard upper case characters.

• English/Latin Lowercase: Switches the keyboard to lower case characters.

• Symbol: Switches the keyboard to symbol characters.

• Space: Inserts a space at the cursor position.

• Delete: Deletes the previous character at the

cursor position.

• b / B: Moves cursor to left or right.

• OK: Select to finish.

• Cancel: Select to exit the menu.

4. Choose ‘OK’ icon then press ENTER to fix the name and return to the Program List menu.

Sort TV channels manually

You can sort the program’s position on the Program List menu.

1. Use v / V to select a program on the Program List

menu then press ENTER. Program List options appear on the left side of the Program List menu.

2. Use v / V to select ‘Move’ option from Program List

options then press ENTER.

3. Use v / V to select a desired position then press

ENTER to store.

Deleting a program

You can delete a program on the Program List menu.

1. Use v / V to select a program on the Program List

menu then press ENTER. Program List options appear on the left side of the Program List menu.

2. Use v / V to select ‘Delete’ option from Program List

options then press ENTER. The Program is deleted.

Page 20

Before Operation (Continued)

Clock Set

Press HOME.

The Home menu appears.

Use b / B to select the Setup option.

While the Start option is selected, press ENTER.

Press B to move to the second level.

Use v / V to select the Clock Set option.

Press B to move to the third level.

Enter the necessary information for date and time.

b / B (left/right): Moves the cursor to the previous or next column.

v / V (up/down): Changes the setting at the current cursor position.

Press ENTER to confirm your setting, then press HOME to exit the Setup menu.

TV Aspect

To record a wide screen format programme successfully the correct type of wide screen signal must be broadcast by the TV station.

You can choose: 4:3 Letter Box: Select when a standard 4:3 TV is connected. Displays theatrical images with masking bars above and below the picture. 4:3 Pan Scan: Select when a standard 4:3 TV is connected. The video material formatted in the Pan & Scan style is played back in that style (Both sides of the picture are cut off).

16:9 Wide: Select when a 16:9 wide TV is connected.

VCR Play System

Your video recorder uses two colour standards, PAL and MESECAM. During play your video recorder should select the colour system automatically, however if you experience problems you may need to do it manually.

Power Save Mode

You can set up the unit into an economic power save mode. Nothing is displayed in the display window in standby mode.

ON: Power Save Mode is active. OFF: Power Save Mode is not active.

ote

The Power Save Mode is not available in the standby mode for the timer recording.

Page 21

HOOKUP

Before Operation (Continued)

Factory Set

If you need to, you can reset the recorder to all its factory settings. Select ‘SET’ icon then press ENTER and auto setup menu will appear. (See page 17).

ote

Some options can not be reset.

Language Settings

Display Language

Select a language for the Setup menu and on-screen display.

Disc Language

Select a language for the disc’s Menu, Audio, and Subtitle.

- Original: The original language set for the disc is selected.

- Others:

To select another language, select Others option then press ENTER. Use the numbered buttons to key-in the corresponding 4-digit number according to the language code list on page 56. If you make a mistake, press b repeatedly to delete one by one and correct it.

Page 22

Before Operation (Continued)

Audio Settings

Each DVD disc has a variety of audio output options. Set the recorder’s Audio Output according to the type of audio system you use.

Dolby Digital

PCM: Select when connected to a 2-channel digital stereo

amplifier. The Recorder’s digital audio outputs sounds in the PCM 2ch format when you play a DVD video disc recorded on the Dolby Digital recording system. Bitstream: Select “Bitstream” if you connect the Recorder’s DIGITAL OUT jack to a Dolby Digital decoder (or an amplifier or other equipment with a Dolby Digital decoder).

DTS

OFF: If you select “OFF”, the DTS signal is not output

through the DIGITAL OUT jack. Bitstream: Select “Bitstream” if you connect the Recorder’s DIGITAL OUT jack to a DTS decoder (or an amplifier or other equipment with a DTS decoder).

MPEG

PCM: Select when connected to a 2-channel digital

stereo amplifier. The Recorder’s digital audio outputs sounds in the PCM 2ch format when you play a DVD video disc recorded on the MPEG2 recording system. Bitstream: Select “Bitstream” if you connect the Recorder’s DIGITAL OUT jack to a MPEG decoder (or an amplifier or other equipment with a MPEG decoder).

Sampling Frequency

If your receiver or amplifier is NOT capable of handling 96 kHz signals, select 48 kHz. When this choice is made, this unit will automatically convert any 96 kHz signals to 48 kHz so your system can decode them. If your receiver or amplifier is capable of handling 96 kHz signals, select 96 kHz. When this choice is made, this unit will pass each type of signal through without any further processing.

DRC (Dynamic Range Control)

With the DVD format, you can hear a program’s soundtrack in the most accurate and realistic presentation possible, thanks to digital audio technology. However, you may wish to compress the dynamic range of the audio output (the difference between the loudest sounds and the quietest ones). Then, you may listen to a movie at a lower volume without losing clarity of sound. Set DRC to ON for this effect.

Page 23

HOOKUP

Before Operation (Continued)

Lock (Parental Control) Settings

Set Password

To access the Rating, Set Password and Area Code features, you must enter a 4-digit security password.

Press HOME.

The Home menu appears.

Use b / B to select the Setup option.

While the Start option is selected, press ENTER.

Use v / V to select the Lock option.

Press B to move to the second level.

Use v / V to select the Set Password option.

Press B to move to the third level.

When you have not entered a password yet;

Enter a 4-digit password using the numbered buttons to create a personal 4-digit security password. Enter the 4-digit password again to verify.

When you have already entered a password;

You can change or delete the password. Use v / V to select “Change” or “Delete” then press

ENTER.

Change : Enter a 4-digit password using the numbered buttons to confirm the personal 4-digit security password, then enter a 4-digit new password twice.

Delete : Enter a 4-digit password using the numbered buttons to confirm the personal 4-digit security password.

If you make a mistake, press b repeatedly to delete password numbers one by one then correct it.

If you forget your 4-digit code

If you forget your password, to clear the current password, follow the procedure below.

1. Press HOME.

2. Use b / B to select the Setup option.

3. While the Start option is selected, press ENTER.

4. Use the Number buttons to enter the 6-digit number “210499”.

5. Select “OK” then press ENTER. The 4-digit password is cleared. Enter a new code as shown above.

Rating

Movies on DVDs may contain scenes not suitable for children. Therefore, discs may contain Parental Control information that applies to the complete disc or to certain scenes on the disc. These scenes are rated from Level 1 to 8, and alternatively, more suitable scenes are available for selection on some discs. Ratings are country-dependent. The Parental Control feature allows you to prevent discs from being played by your children or to have certain discs played with alternative scenes.

Follow steps 1-5 as shown above to the left (Set Password).

Use v / V to select the Rating option.

Press B to move to the third level.

Enter a 4-digit password using the numbered buttons to confirm the personal 4-digit security password.

Select a rating from 1 to 8 using the v / V but- tons. One (1) has the most playback restrictions. Eight (8) has the least playback restrictions.

No Limit: If you select No Limit, Parental Control is not active. The disc will play in full. Level 1 to 8: Some discs contain scenes not suitable for children. If you set a rating for the recorder, all disc scenes with the same rating or lower will be played. Higher rated scenes will not be played unless an alternative scene is available on the disc. The alternative must have the same rating or a lower one. If no suitable alternative is found, playback will stop.You must enter the 4-digit password or change the rating level in order to play the disc.

Press ENTER to confirm your rating selection, then press HOME to exit the menu.

Page 24

Area Code

Enter the code of a country/area whose standards were used to rate the DVD video disc, referring to the list (See “Area Code List”, page 56.).

Press HOME.

The Home menu appears.

Use b / B to select the Setup option.

While the Start option is selected, press ENTER.

Use v / V to select the Lock option.

Press B to move to the second level.

Use v / V to select the Area Code option.

Press B to move to the third level.

When you have not entered a password yet;

Enter a 4-digit password using the numbered buttons to create a personal 4-digit security password. Enter the 4-digit password again to verify.

When you have already entered a password;

Enter a 4-digit password using the numbered buttons to confirm the personal 4-digit security password.

If you make a mistake, press b repeatedly to delete password numbers one by one then correct it.

Select the first character using the v / V buttons.

1100

Shift the cursor using B buttons and select the second character using v / V buttons.

1111

Press ENTER to confirm your Area Code selection, then press HOME to exit the menu.

Recording Settings

Disc Record Mode

You can set the picture quality for DVD recording; XP (High Quality), SP (Standard Quality), LP (Low Quality), EP (Extend Quality)

Press HOME.

The Home menu appears.

Use b / B to select the Setup option.

While the Start option is selected, press ENTER.

Use v / V to select the Record option.

Press B to move to the second level.

Use v / V to select the Disc Record Mode option.

Press B to move to the third level.

Use v / V to select a desired Record Mode (XP, SP, LP or EP)

Press ENTER to confirm your selection, then press HOME to exit the menu.

VCR Record Mode

You can set the picture quality for VCR recording; SP (Standard Play), LP (Long Play)

VCR Record System

Your video recorder uses two colour standards, PAL and MESECAM. During recording your video recorder should select the colour system automatically, however if you experience problems you may need to do it manually.

Before Operation (Continued)

Page 25

HOOKUP

Before Operation (Continued)

DV Record Audio

You need to set this if you have a camcorder using 32kHz/12-bit sound connected to the front panel DV IN jack. Some digital camcorders have two stereo tracks for audio. One is recorded at the time of shooting; the other is for overdubbing after shooting. On the Audio 1 setting, the sound that was recorded while shooting is used. On the Audio 2 setting, the overdubbed sound is used.

Auto Chapter

When recording, chapter markers are inserted at specified intervals. You can change this interval to 5 minutes, or 10 minutes. If you select None, it switches off automatic chapter marking altogether.

Disc Settings

Initialize

If you load a completely blank disc, the recorder will initialize the disc.

DVD-R: The recorder initialize the disc to Video mode. The recording mode will always be Video mode.

DVD-RW:

The Initialize menu will appears. Select “OK” then press ENTER. The recorder initialize the disc to Video mode. If you change to VR mode, go to step 9. DVD+R(DL)/DVD+RW: The Initialize menu will appears. Select “OK” then press ENTER.

Also, you can reformat the DVD-RW/DVD+RW from the Setup menu as below.

Press HOME.

The Home menu appears.

Use b / B to select the Setup option.

While the Start option is selected, press ENTER.

Use v / V to select the Disc option.

Press B to move to the second level.

Use v / V to select the Initialize option.

Press B to move to the third level.

Start icon is highlighted.

Press ENTER.

Initialize menu appears.

In case of the initialized DVD-RW, use b / B to select a desired Disc Format Mode (VR Mode or Video Mode) then press ENTER. In case of DVD+RW, go to step 10.

1100

Use b / B to select “OK” then press ENTER. It takes a few moments to format the disc.

Caution

If you want to change the disc format, everything recorded on the disc will be erased.

Page 26

Before Operation (Continued)

Finalize

Finalizing ‘fixes’ the recordings in place so that the disc can be played on a regular DVD player or computer equipped with a suitable DVD-ROM drive. Finalizing a Video mode disc creates a menu screen for navigating the disc. This is accessed by pressing DISC MENU / LIST or TITLE.

Caution

Once you have finalized a DVD-R and DVD+R disc, you cannot edit or record anything else on that disc except DVD+RW. However, you can record and edit a DVD-RW disc by choosing “Unfinalize” option.

Follow steps 1-5 as shown on page 25 (Initialize).

Use v / V to select the Finalize option.

Press B to move to the third level.

Finalize is highlighted.

Press ENTER.

Finalize menu appears.

Select OK then press ENTER.

The recorder starts finalizing the disc.

ote

How long finalization takes depends on the type of disc, how much is recorded on the disc, and the number of titles on the disc.

If you load a DVD-RW that has already been finalized, you can ‘unfinalize’ it by choosing Unfinalize from the Finalize menu. After doing this, you can edit and re-record onto the disc.

Disc Label

Use this to enter a name for the disc. This name appears when you display disc information on-screen.

• The disc name can be up to 32 characters long.

•For discs formatted on a different Recorder, you will see only a limited character set.

Follow steps 1-5 as shown Initialize on page 25.

Use v / V to select the Disc Label option.

Press B to move to the third level.

Edit icon is highlighted.

Press ENTER.

Keyboard menu appears.

Enter a name for the disc. Use vVbBto select a character then press ENTER to confirm your selection. Refer step 3 as shown on page 19 (Station Rename).

Remote control buttons for entering a name

N (PLAY): Inserts a space at the cursor position. X (PAUSE/STEP): Deletes the after character at the

cursor position.

x (STOP), CLEAR: Deletes the previous character

at the cursor position.

. / >: Moves cursor to left or right. Numbers (0~9): Enters the character of correspon-

ding location on the selected column.

DISC MENU / LIST, DISPLAY: Switches the key-

board type (English/Latin Capital, English/Latin Lowercase, Symbols)

Choose OK then press ENTER to fix the name and return to the Setup menu.

Press HOME to exit the menu.

Page 27

HOOKUP

Before Operation (Continued)

Disc Protect

When recording in DVD+RW / +R disc or VR mode formatted DVD-RW disc, set to ON to prevent accidental recording, editing or deleting of the disc loaded. If you need to unlock the disc to make edits, select OFF.

PBC

Set Playback Control (PBC) to On or Off.

- ON:

Video CDs with PBC are played according to the PBC.

- OFF: Video CDs with PBC are played the same way as

Audio CDs.

Auto Play

You can set up the Recorder so a DVD disc automatically starts playing whenever the DVD is inserted. If Auto Play mode is set to On, this Recorder will search for title that has the longest playback time and then play back the title automatically.

ON: Auto Play function is active. OFF: Auto Play function is not active.

ote

The Auto Play function may not work for some DVDs.

About DivX(R)

We provide you with the DivX® VOD (Video On Demand) registration code that allows you to rent and purchase videos using the DivX® VOD service. For more information, visit www.divx.com/vod.

Select “About DivX(R)” option then press B.

Press ENTER while Enter is highlighted and the registration code will appear.

Use the registration code to purchase or rent the videos from Divx® VOD service at www.divx.com/vod. Follow the instructions and download the video onto a disc for playback on this unit.

ote

All the downloaded videos from DivX® VOD can only be played back on this unit.

Page 28

Before Operation (Continued)

General Explanation of On-Screen Display

This manual gives basic instructions for operating the Recorder. Some DVDs require specific operation or allow only limited operation during playback. When this occurs, the symbol appears on the TV screen, indicating that the operation is not permitted by the Recorder or is not available on the disc.

Displaying Information While Watching TV

During viewing the TV, press DISPLAY to display/ remove the information displayed on-screen.

e.g., when DVD-RW in VR mode is inserted.

Displaying Information on-screen

You can display various information about the disc or tape loaded on-screen.

Press DISPLAY repeatedly to display/change the information displayed on-screen.

The items displayed differ depending on the disc type, tape or playing status. Example : DVD-Video disc

You can select an item by pressing v / V and change or select the setting by pressing

b/ B.

For details about each item, see the pages in parenthesis.



TITLE: Current title (or track) number/total

number of titles (or tracks) (page 29)



CHAPTER: Current chapter number/total

number of chapters (page 29)



TIME: Elapsed playing time (page 30)



AUDIO: Selected audio language (DVD VIDEO

only) or audio channel (page 31 to 32)



SUBTITLE: Selected subtitle (page 32)



ANGLE: Selected angle/total number of angles

(page 31)



SOUND: Selected sound mode (page 32)

To remove the on-screen display, press DISPLAY or RETURN(OO) repeatedly until it disappears.

ote

If no button is pressed for 7 seconds, the on-screen display disappears.

Indicates disc name and format.

Indicates channel number, station name,

and audio input signal received by the

tuner.

Indicates the record mode,

free space, and elapsed

time progress bar.

Indicates current date and time.

Indicates output audio signal.

Page 29

HOOKUP

Operation with DVD and Video CD

Playing a DVD or Video CD

Playback Setup

 Before using the remote control, press the DVD but-

ton to select the device to be operated.

 Tu rn the TV on and select the video input source con-

nected to the Recorder.

 Audio system: Turn the audio system on and select

the input source connected to the Recorder.

Press OPEN/CLOSE (Z) to open the disc tray.

Load your chosen disc in the tray, with the playback side down.

Press OPEN/CLOSE (Z) to close the tray.

REAd appears on the display window, and playback starts automatically. If playback does not start, press N (PLAY). In some cases, the disc menu might appear instead.

If a menu screen is displayed

The menu screen may be displayed first after loading a DVD or Video CD which contains a menu.

Use the bBvVbuttons to select the title/chapter you want to view, then press ENTER to start playback. Press TITLE or DISC MENU / LIST to return to the menu screen.



Use the number buttons to select the track you want to view. Press RETURN (O) to return to the menu screen.



Menu setting and the exact operating procedures for using the menu may differ depending on the disc. Follow the instructions on each menu screen. You may also set PBC to OFF under Setup menu. See page 27.

otes

– If Parental Control is set and the disc is not within the

Rating settings (not authorized), the 4-digit code must be entered and/or the disc must be authorized (see “Rating”, on page 23).

–DVDs may have a Region Code.

Your recorder will not play discs that have a region code different from your recorder. The region code for this recorder is 4 (four).

General Features

ote

Unless stated otherwise, all operations described use the remote control. Some features may also be available on the Setup menu.

Moving to another TITLE

When a disc has more than one title, you can move to another title as follows:



Press DISPLAY twice then use v / V to select the title icon. Then, press the appropriate numbered but-

ton (0-9) or b / B to select a title number.

Moving to another CHAPTER/TRACK

When a title on a disc has more than one chapter/track, you can move to another chapter/track as follows:

 Press SKIP (. or >) briefly during playback to

select the next chapter/track or to return to the beginning of the current chapter/track.



Press SKIP (.) twice briefly to step back to the previous chapter/track.



To go directly to any chapter/track during playback, press DISPLAY twice. Then, use v / V to select chap-

ter icon (or for a Video CD, select track icon). Then, enter the chapter/track number using the numbered buttons (0-9) or press b / B.

1 Press BACKWARD (m) or FORWARD(M) during

playback.

The recorder will now go into SEARCH mode.

2 Press BACKWARD (m) or FORWARD(M) to

select the required speed: b (Reverse play), m,

mb, mm, mmb, mmm (backward) or M, MB, MM, MMB, MMM (forward).

With a Video CD, DivX disc, the Search speed changes: m, mb, mm (backward) or M, MB, MM (forward).

3 To exit SEARCH mode, press N (PLAY).

Still Picture and Frame-by-Frame Playback

1 Press PAUSE/STEP (X) during playback.

The recorder will now go into PAUSE mode.

2 You can advance or back up the picture frame-by-

frame by pressing b / B repeatedly during PAUSE mode.

3 To exit PAUSE mode, press N (PLAY).

ote

The picture frame-by-frame in reverse is not available for Video CD.

You can advance the picture frame-by-frame by pressing PAUSE/STEP (X) repeatedly on the remote control.

VCD+R+RWVR

Video

DVD

DivXVCD

+R+RWVR

Video

DVD

VCD+R+RWVRDVD

DivX

+RWVR

Video

DVD

VCD

DVD

Page 30

Operation with DVD and Video CD (Continued)

General Features (Continued)

Slow Motion

1 Press PAUSE/STEP (X) during playback.

The recorder will now go into PAUSE mode.

2 Press BACKWARD (m) or FORWARD(M) during

PAUSE mode.

The Recorder will enter SLOW mode.

3 Use the BACKWARD (m) or FORWARD (M) to

select the required speed: t 1/16, t 1/8, t 1/4, or t 1/2 (backward), or T 1/16, T 1/8, T 1/4, or T 1/2 (forward). With a Video CD, the Slow speed changes: T 1/8, T 1/4 or T 1/2 (forward).

4 To exit Slow Motion mode, press PLAY (N).

ote

Slow motion playback in reverse is not possible with Video CDs.

Repeat A-B

To repeat a sequence in a title:

1 Press PLAY MODE at your chosen starting point.

Repeat icon and A- appears on the TV screen.

2 Press ENTER again at your chosen end point.

Repeat icon and A-B

appears on the TV screen, and the

repeat sequence begins.

3 To stop the repeat A-B, press PLAY MODE repeatedly

until “OFF” appears on the TV screen..

ote

Repeat A-B can be done if the repeat time is not too short.

Play modes

While the disc is playing, press PLAY MODE repeatedly to select a play mode:

DVD, DVD-RW(Video), DVD+RW, and DVD+R:

REPEAT CHAPTER, REPEAT TITLE, REPEAT OFF Karaoke DVD: REPEAT CHAPTER, REPEAT TITLE, RANDOM, NORMAL VCD: REPEAT TRACK, REPEAT ALL, REPEAT OFF or

REPEAT TRACK, REPEAT ALL, RANDOM, NORMAL DVD-RW(VR): REPEAT CHAPTER, REPEAT TITLE,

REPEAT ALL, REPEAT OFF

By pressing SKIP (>) during Random playback, the unit selects another title (track) and resumes Random playback.

ote

 On a Video CD with PBC, you must set PBC to OFF

in the Setup menu. See page 27.

 The play mode may vary according to the recorded

content.

Time Search

The Time Search function allows you to start playing at any chosen time on the disc.

1 Press DISPLAY twice during playback. The on-screen

display appears on the TV screen.

The Time Search box shows the elapsed playing time of the current disc.

2 Within 7 seconds, use v / V to select the Time

Search icon in the on-screen display.

The “-:--:--” appears in the Time Search box.

3 Within 7 seconds, use the number buttons to enter

the required start time. Enter hours, minutes, and seconds from left to right in the box.

You can not enter an invalid time. If you enter the wrong numbers, press b/B to move the under bar (_) to the wrong number. Then enter the correct

numbers.

4 Within 7 seconds, press ENTER to confirm the start

time.

Playback starts from the selected time on the disc.

DivX+R+RWVR

Video

DVD

Karaoke DVDVCD+R

+RW

Video

VRDVD

Karaoke DVD

VCD+R+RWVR

Video

DVD

VCD+R+RWVR

Video

DVD

Page 31

PLAY BACK

Operation with DVD and Video CD (Continued)

General Features (continued)

Zoom

The Zoom function allows you to enlarge the video image and to move through the enlarged image.

1 Press ZOOM during playback or still playback to acti-

vate the Zoom function.

Each press of the ZOOM button changes the TV screen in the sequence shown below. x1 size → x2 size → x4 size → x1 size (normal size)

2 Use the bBvVbuttons to move through the

zoomed picture.

3 To resume normal playback, press CLEAR or press

ZOOM repeatedly until the normal picture appears.

ote

The zoom function may not work for some DVDs.

Marker Search

You can start playback from a memorized point. Up to six points can be memorized. To enter a mark, follow these steps.

1 During disc playback, press MARKER when

playback reaches the spot that you want to memorize.

The Marker icon will appear on the TV screen briefly.

2 Repeat step 1 to enter up to six Marker points on a

disc.

To Recall a Marked Scene

1 Press SEARCH.

The Marker Search menu will appear on the TV screen.

2 Use the bBvVbuttons to select a Marked scene

that you want to recall.

3 Press ENTER.

Playback will start from the Marked scene.

4 To remove the Marker Search menu, press

RETURN (O).

To clear a Marked Scene

1 Press SEARCH during playback or in stop mode.

The Marker Search menu will appear on the TV screen.

2 Use bBvVto select the Marked scene that you

want to erase.

3 Press CLEAR.

“Delete selected marker? Proceed?” message appears.

4 Use b / B to select “OK” then press ENTER. 5 Repeat steps 2-4 to erase additional Marked scene.

6 To remove the Marker Search menu, press

RETURN (O).

Checking the Contents of DVD Video Discs: Menus

DVDs may contain menus that allow you to access special features. To open the disc menu, press DISC MENU / LIST. Then, press the appropriate number button to select an option. Or, use the bBvVbuttons to highlight your selection, then press ENTER.

Title Menu

1 Press TITLE.

If the current title has a menu, the menu will appear on the TV screen. Otherwise, the disc menu may appear.

2 The menu may contain camera angles, spoken lan-

guage and subtitle options, and chapters for the title.

Disc Menu

1 Press DISC MENU / LIST.

The disc menu is displayed.

2 To remove the disc menu, press DISC MENU / LIST

again.

Camera Angle

If the disc contains scenes recorded at different camera angles, you can change to a different camera angle during playback.

1 Press DISPLAY twice during playback. 2 Use v / V to select the

ANGLE icon.

3 Press b / B repeatedly to select a desired angle.

The Camera Angle icon is displayed on the TV screen when alternate angles are available.

Changing the Audio Soundtrack

Press AUDIO then press b / B repeatedly during playback to hear a different audio language or audio soundtrack if available.

ote

Some discs feature both Dolby Digital and DTS soundtracks. There is no analog audio output when DTS is selected. To listen to the DTS soundtrack, connect this recorder to a DTS decoder via one of the digital outputs. See page 15 for connection details.

DVD

VCD+R+RWVR

Video

DVD

+R+RWVR

Video

DVD

Page 32

Operation with DVD and Video CD (Continued)

Changing the Audio Channel

With a Video CD, press AUDIO then press b / B repeat- edly during playback to hear a different audio channel (STEREO, LEFT or RIGHT). With DVD-RW discs recorded in VR mode that have both a main and a Bilingual audio channel, you can switch between Main (L), Bilingual (R), or a mix of both (Main + Bilingual) by pressing AUDIO.

3D Surround

This unit can produce a 3D Surround effect, which simulates multi-channel audio playback from two conventional stereo speakers, instead of the five or more speakers normally required to listen to multichannel audio from a home theater system.

1. Press DISPLAY twice during playback. The OnScreen Display appears on the TV screen.

2. Use v / V to select the Sound icon in the On-Screen Display.

3. Use b / B to select “3D SUR”. To turn off the 3D Surround effect, select “NORMAL”.

Subtitles

Press SUBTITLE then press b / B repeatedly during playback to see the different subtitle languages.

Finding Locations on a Disc

You can directly access any point on a video CD using this function. Use this function only while a video CD is playing. Playback jumps to the point specified.

1 Press SEARCH during playback.

The progress bar appears on the TV screen.

2 Use b / B to find a start position for playback. 3 Press ENTER to confirm the selected position.

Playback starts from the selected position.

ote

This function works only when no marker is memorized.

Last Condition Memory

This Recorder memorizes last scene from the last disc that is viewed. The last scene remains in memory even if you remove the disc from the Recorder or switch off the Recorder. If you load a disc that has the scene memorized, the scene is automatically recalled.

otes

– Settings are stored in memory for use any time. – This recorder does not memorize settings of a disc if

you switch off the recorder before commencing to play it.

DVD

VCD

DivXDVD

DivXVCD+R

+RWVR

Video

DVD

DivX+R+RWVR

Video

VCD

Page 33

PLAY BACK

Playing a DivX Movie Disc

Using this unit you can play DivX disc. Before playing DivX files, read “About DivX movie files” on right.

ote

This recorder cannot play back the DivX file(s) in the USB Memory Stick.

1. Insert a disc and close the tray. The Movie menu appears on the TV screen.

2. Press v / V to select a folder, and press ENTER. A list of files in the folder appears. If you are in a file

list and want to return to the Folder list, use the v / V buttons on the remote to highlight and press

ENTER.

3. If you want to view a particular file, press v / V to highlight a file and press PLAY (N).

You can use variable playback functions. Refer to pages 29-32.

4. Press STOP (x) to stop the playback. The Movie menu appears.

On a CD with MP3/WMA, JPEG and MOVIE file, you can switch Music, Photo and Movie menu. Press TITLE.

Notice for displaying the DivX subtitle

If the subtitle does not display properly during playback, press PAUSE/STEP (X) when the subtitle is displayed

and press and hold SUBTITLE about 3 seconds then press b / B to select another language code until the

subtitle is displayed properly.

Movie menu options

1. Press v / V to select a folder/file on the Movie menu

then press ENTER. Movie menu options appear.

2. Press v / V to select an option, and press ENTER.

 [Play] Start playback the selected title.  [Open] Opens the folder and a list of files in the

folder appears.

About DivX movie files

DivX disc compatibility with this recorder is limited as follows:

 Maximum resolution of the DivX file is 720x576

(W x H) pixel.

 The DivX subtitle file name has to be identified with

the DivX file name to display by this unit.

 The total number of files and folders on the disc

should be less than 1999.



If the number of the screen frame is over 29.97 frames per second, this unit may not operate normally.



If the video and audio structure of recorded file is not interleaved, returns to the menu screen.



If the file is recorded with GMC, the unit supports only 1-point of the record level.

GMC? GMC is the acronym for Global Motion Compensation. It is an encoding tool specified in MPEG4 standard. Some MPEG4 encoders, like DivX, have this option. There are different levels of GMC encoding, usually called 1-point, 2-point, or 3-point GMC.

Playable DivX file

“.avi”, “.divx”

Playable DivX subtitle

“.smi”, “.srt ”, “.sub (Micro DVD format only)”, “.txt (Micro DVD format only)”



Divx subtitle except those listed above is not displayed on the TV screen.

Playable Codec format

“DIV3”, “MP43”, “DIVX”, “DX50”

Playable Audio format

“AC3”, “PCM”, “MP2”, “MP3”, “WMA”

 Sampling frequency: within 8 - 48 kHz (MP3), within

32 - 48kHz (WMA)

 Bit rate: within 8 - 320kbps (MP3),

32 - 192kbps (WMA)

CD-R format

ISO 9660 and JOLIET

DVD±R/RW format

ISO 9660 (UDF Bridge format)

Page 34

Audio CD and MP3/WMA Operation

Playing an Audio CD or MP3/WMA Disc

The Recorder can play audio CDs. Also, the Recorder can play MP3/WMA formatted recordings on CD-ROM, CD-R, CD-RW, DVD±R, DVD±RW disc or USB Memory Stick. Before playing MP3/WMA recordings, read the notes on MP3/WMA Recordings on page 35.

Insert a disc and close the tray.

AUDIO CD or MP3/WMA CD menu appears on the TV screen.

AUDIO CD Menu MP3/WMA CD Menu

Use v / V to select a track then press PLAY (N).

Playback starts. During playback, the current track’s elapsed playing time will appear on the display window and menu. Playback will stop at the end of the disc.

ips



You can view TV channel or video input source by pressing RETURN. If you want to return to the Music menu, press DISC MENU / LIST.



On CDs with mixed content (audio tracks, MP3/WMA files and JPEG files), you can select among the Music-Audio CD menu, MusicMP3/WMA CD menu, and Photo CD menu by pressing TITLE repeatedly in Stop mode.



If you select an MP3 file and press DISPLAY, the file information is displayed. Press DISPLAY again to remove the file information. If you select a folder and press DISPLAY, the number of subfolders and number of MP3/WMA files in the folder are displayed.



If you are in a file list and want to return to the Folder list, use the v/V to highlight and press

ENTER to return to the previous menu screen.

To stop playback at any other time, press STOP (x).

Music menu options

1. To display menu options, select a track (or folder) on the menu then press ENTER.

2. Use v / V to select an option then press ENTER to confirm your selection.

Music-Audio CD menu options

Play: Starts playback of the selected track.

Random: Plays tracks in random order.

Music-CD menu options

• When you select a track.

Play: Starts playback of the selected track.

Random: Plays tracks in random order.

• When you select a folder.

Open: Displays sub-folders and MP3/WMA files only in

the folder.

Music-

USB Memory Stick

menu options

• When you select a track.

Play: Starts playback of the selected track.

Random: Plays tracks in random order.

• When you select a folder.

Open: Displays sub-folders and MP3/WMA files in the

folder.

WMA

MP3

WMA

MP3

Page 35

PLAYBACK

Audio CD and MP3/WMA Operation (Continued)

Pause

1 Press PAUSE/STEP (X) during playback. 2 To return to playback, press PLAY (N) or press

PAUSE/STEP (X) again.

Moving to Another Track



Press SKIP (. or >) briefly during playback to go to the next track or to return to the beginning of the current track.



Press SKIP (.) twice briefly to step back to the previous track.



On an Audio CD, to go directly to any track, enter the track number using the numbered buttons (0-9) during playback on the Track List.

Repeat A-B

To repeat a sequence in a track:

1 Press PLAY MODE at your chosen start point.

Repeat icon and ‘A-’ appears on the menu screen.

2 Press ENTER again at your chosen end point.

The Repeat icon and ‘A - B’ appears on the menu screen, and the repeat sequence begins.

3 To exit the sequence and return to normal play, press

PLAY MODE again.

The Repeat icon disappears from the menu screen.

Play modes

While the disc is playing, press PLAY MODE repeatedly to select a play mode:

CD: REPEAT TRACK, REPEAT ALL MP3 and WMA: REPEAT TRACK, REPEAT FOLDER

By pressing SKIP (>) during Random playback, the unit selects another track and resumes Random playback.

1 Press BACKWARD (m) or FORWARD(M) during

playback.

The recorder will now go into SEARCH mode.

2 Press BACKWARD (m) or FORWARD(M) to

select the required speed: m, ,, mm (backward) or M, <, MM (forward).

Search speed and direction are indicated on the menu screen.

3 To exit SEARCH mode, press N (PLAY).

Notes on MP3/WMA Recordings

About MP3



An MP3 file is audio data compressed by using the MPEG1 audio layer-3 file-coding scheme. We call files that have the “.mp3” file extension “MP3 files”.



The recorder can not read an MP3 file that has a file extension other than “.mp3”.

About WMA(Window Media Audio)



A WMA file is a Microsoft audio compression Technology file.



WMA(Windows Media Audio) offers double the audio.compression of the MP3 format.

MP3/WMA Disc compatibility with this recorder is limited as follows:

1. CD-R physical format should be “ISO 9660” and “JOLIET”.

2. If you record MP3/WMA files using the software which cannot create a FILE SYSTEM, for example “Direct-CD” etc., it is impossible to playback MP3/WMA files. We recommend that you use “Easy-CD Creator”, which creates an ISO 9660 or JOLIET file system.

3. Total number of files and folders on the disc should be less than 1999.

This Recorder requires discs/recordings to meet certain technical standards in order to achieve optimal playback quality. Pre-recorded DVDs are automatically set to these standards. There are many different types of recordable disc formats (including CD-R containing MP3 or WMA files) that require certain pre-existing conditions (see above) to ensure compatible playback.

Customers should also note that permission is required in order to download MP3/WMA files and music from the Internet. Our company has no right to grant such permission. Permission should always be sought from the copyright owner.

WMA

MP3

WMA

MP3

WMA

MP3

Page 36

Viewing a JPEG File

The recorder can play JPEG files from discs or USB Memory Stick. Before playing JPEG recordings, read “Notes on JPEG Recordings” on page 37.

Insert a disc and close the tray.

The Photo menu appears on the TV screen.

Use vVbB to select a folder, then press ENTER.

Open icon is highlighted on the left side of the menu.

Press ENTER.

A list of files in the folder appears.

ote

If the icon displays in the Photo menu, it means you cannot see those JPEG files.

Use vVbB to select a file, then press ENTER.

The options appear on the left side of the menu.



If you are in a file list and want to return to the Folder list, use the v / V buttons on the remote to highlight

the icon and press ENTER.



You can view TV channel or video input source by pressing RETURN. If you want to return to the Photo menu, press DISC MENU / LIST.



On CDs with mixed content (audio tracks, MP3/WMA files and JPEG files), you can select among the AUDIO CD menu, MP3/WMA CD menu, and Photo CD menu by pressing TITLE repeatedly in Stop mode.

Use v / V to select “Full Screen” option then press ENTER.

To stop viewing at any time, press STOP.

The Photo menu reappears.

Photo menu options

1. To display menu options, select a file (or folder) on the menu then press ENTER.

2. Use v / V to select an option then press ENTER to confirm your selection.

Photo-CD menu options

• When you select a photo file.

Full Screen: Shows the selected file as full screen.

Slide Show: Displays Slide Show menu. (page 37)

• When you select a folder.

Open: Displays sub-folders and JPEG files in the

folder.

Photo-

USB Memory Stick

menu options

• When you select a photo file.

Full Screen: Shows the selected file as full screen.

Slide Show: Displays Slide Show menu. (page 37)

• When you select a folder.

Open: Displays sub-folders and JPEG files in the

folder.

JPEG

JPEG File Operation

Page 37

JPEG File Operation (Continued)

Skip Images

While viewing a picture, press SKIP (. or >) once to advance to the next file or return to the previous file.

Rotate Images

Use v / V while viewing a picture to flip the picture clockwise or counterclockwise.

View Slide Shows

1. Select “Slide Show” option on the Photo menu.

2. Press ENTER. The Slide Show menu appears.

3. Use vVbB to set the options. Object: Selected file or All files. Speed: Sets the speed for Slide Show (Slow, Normal, or Fast)

4. Select the Start option then press ENTER to start the Slide Show.

5. Press STOP to stop the Slide Show and returns to the Photo menu.

ote

Use the MARKER button to select multiple files.

Notes on JPEG Recordings



Depending on the size and number of the JPEG files, it may take several minutes to read the contents of the media. If you don’t see an on-screen display after several minutes, some of the files are too big — reduce the resolution of the JPEG files to less than 4 mega pixels and burn another disc.



The total number of files and folders are free but the total number of files on the folder should be less than

1999.



Some discs may be incompatible due to different recording formats or the condition of the discs.

 When you are using software such as “Easy CD

Creator” to burn JPEG files on a CD-R, ensure that all selected files have the “.jpg” extension before copying them into the CD layout.

 If the files have “.jpe” extensions, please rename them

as “.jpg” files.

 File names without the “.jpg” extension

cannot be read by this recorder, even though the files are shown as JPEG image files in Windows Explorer



Progressive and lossless compression JPEG image files are not supported.

PLAYBACK

Page 38

VCR Mode Tape Playback

Preparation

 Before using the remote control, press the VCR but-

ton to select the device to be operated.

 Tu rn the TV on and select the video input source con-

nected to the Recorder.

 Audio system: Turn the audio system on and select

the input source connected to the Recorder.

Normal Playback

Insert a prerecorded video cassette.

The indicator will light and the Recorder will powerup automatically.

 Make sure that the TIMER indicator in the display

window is not lighted. If it is, press POWER once.

 If a tape without a safety tab is inserted, the Recorder

will start playback automatically.

Press PLAY (N) once.

PLAY icon appears on the TV screen.

 It is not necessary to select the tape speed for play-

back. It will be automatically selected by the Recorder.

Press STOP (x) to stop playback.

STOP icon appears on the TV screen.

If the tape reaches the end before STOP (x) is pressed, the Recorder will automatically stop, rewind and eject the tape, and turn itself off.

otes

 If you wish to watch the DVD playback during the VCR play-

back, press DVD (or DVD/VCR) to change to DVD mode and perform the DVD playback. If you press VCR (or DVD/VCR) to watch the VCR playback again, playback resumes from the point where playback was interrupted.

 You cannot playback from both DVD and VCR at the same

time.

Tracking Control

Auto Tracking

The automatic tracking function adjusts the picture to remove snow or streaks. The AUTO TRACKING function works in the following cases:

 A tape is played back for the first time.  Tape speed (SP, LP) changes.  Streaks or snow appear because of scratches on the tape.

Manual Tracking

If noise appears on the screen during playback, press either

PR/CH(TRK) (v/V)

on the remote control or

PROG. (v/V) on the front panel until the noise on the screen is reduced.

 In case of vertical jitter, adjust these controls very carefully.  Tr acking is automatically reset to normal when the tape is

ejected or the power cord is unplugged for more than 3 seconds.

Special Effect Playback

Special effects playback notes

 Horizontal lines (noise bars) will appear on the TV screen.

This is normal.

 The audio is automatically muted during special effect modes,

so there is no sound during search.

 During the high-speed picture search modes, a short time is

needed to stabilize tape speed when re-entering the PLAY mode. Slight interference may be observed during this time.

This function lets you visually search forward and backward for a desired scene on your tape. 1 Press BACKWARD (m) or FORWARD (M)

during playback. The Recorder will be activated in the SEARCH mode.

 If the Recorder is left in the SEARCH mode for more than

3 minutes, the Recorder will automatically enter the PLAY mode, to protect the tape and video heads.

2 To return to playback, press PLAY (N).

Still Picture and Frame-by-Frame Playback

1 Press PAUSE/STEP (X) during playback.

A still picture appears on the TV screen.

 If a still picture vibrates vertically, stabilize it by using

PR/CH(TRK) (v/V)

on the remote control.

 If the Recorder is left in the STILL mode for more than 5

minutes, the Recorder will automatically enter the STOP mode to protect the tape and video heads.

2 Press PAUSE/STEP (X) repeatedly to advance the

video picture one frame at a time while viewing a still picture.

3 To return to playback, press PLAY (N).

Slow Motion

1 While in still mode, press FORWARD (M).

The tape will be played back at a speed 1/19 times slower than the normal speed.

 During slow playback, use PR/CH(TRK) (v/V) on the

Remote Control to minimize noise bands.

 If slow motion mode continues for more than 3 minutes,

the Recorder will automatically change to normal play mode.

2 To return to playback, press PLAY (N).

Counter Memory Function

This is useful if there is a section of tape you want to view immediately after recording or if you want to return to the same point several times.

1 Begin recording or playing a tape. 2 Press DISPLAY repeatedly to display the real-time

counter on the TV screen.

3 At the point you want to locate later, reset the real-

time counter to 0:00:00 by pressing CLEAR. Continue to play or record.

4 Press STOP when recording or playback finishes. 5 Press RETURN (O).

The tape automatically stops when the tape counter returns to about “0:00:00”.

VHS

Page 39

PLAYBACK

Basic Recording

Basic Recording from a TV

Follow the instructions below to record a TV program. Recording starts immediately and continues until the disc or tape is full or you stop the recording.

Switch on the Recorder, select the device (VCR or DVD) for Recording and load a recordable disc or tape.

Also make sure that the TV input is set to this recorder. If you load a completely blank DVD-RW disc, Disc Initialize menu will appear, to select a desired Recording Mode to initialize the disc (See page 25).

Set a recording mode as necessary by pressing REC MODE repeatedly.

DVD: XP(High quality), SP (Standard quality),

LP (Low quality), EP (Extended quality)

VCR: SP (Standard Play), LP (Long Play)

Use PROG. (v/V) on the front panel or PR/CH(TRK)(v/V) on the remote control to

select the TV channel to record.

Use AUDIO to select the audio channel to record.

The table below shows what will be recorded on the different settings for different types of broadcast. The last column (Monitor Audio) shows what you’ll hear as it is recording.

Press REC (z) once.

Recording will start. (The REC indicator lights in the display window.)



Recording continues until you press STOP (x) or the disc (or tape) is full.



To record for a fixed length of time, see Instant Timer Recording on right.

Press STOP (x) to stop recording.

Instant Timer Recording

Instant Timer Recording allows you to make a recording easily of a preset length without using the program timer.

Follow steps 1-5 as shown left (Basic Recording from a TV).

Press REC (z) repeatedly to select the recording time length.

Recording starts after the first press. DVD: Each subsequent press increases the recording time by 10 minutes within free space. VCR: Each subsequent press increases the recording time by 30 minutes. Please confirm the VHS tape has enough remaining time to be recorded before recording.

Instant Timer Record Menu

Checking the Recording Time

Press REC (z) or DISPLAY once to check the recording time. The recalled setting will automatically return to the TV screen for a moment. Also, remaining time of recording is shown in the display window.

To Extend the Recording Time

The recording time can be extended anytime by pressing REC (z). Each subsequent press increases the recording time by 10 minutes (DVD) within free space or 30 minutes (VCR).

To Pause the Recording

1 Press PAUSE/STEP (X) to pause the disc or tape

during recording.

2 When you want to continue recording, press

PAUSE/STEP (X) or REC (z).

otes

• If you press PAUSE/STEP (X) during the Instant

Timer Recording, it will be canceled.

• The Recorder will automatically power off when the

Instant Timer Recording ends.

To record one TV program while watching another

1 Press TV/VCR to select the TV mode during record-

ing. The TV indicator appears.

2 Using the TV remote controller, select the channel to

be viewed.

When recording onto a video tape, you can change a recording channel in the recording pause mode. (You cannot change a recording channel in the DVD recording pause mode.)

ote

If you wish to watch the DVD playback during the VCR record ing, press DVD (or DVD/VCR) to change to DVD mode and per form the DVD playback.You cannot playback the VCR during the DVD recording.

TV Selected Audio Broadcast Audio Monitor Broadcast VR mode or Video, +R or Audio

Audio Tape +RW mode

L Ch R Ch L Ch R Ch

STEREO STEREO/MAIN STEREO STEREO STEREO

STEREO/SUB STEREO STEREO STEREO

MONO/MAIN MONO MONO MONO

MAIN+SUB STEREO/MAIN MAIN SUB MAIN MAIN MAIN

STEREO/SUB MAIN SUB SUB SUB SUB

MONO/MAIN MAIN SUB MAIN MAIN MAIN

MONO STEREO/MAIN MONO MONO MONO

STEREO/SUB MONO MONO MONO MONO/MAIN MONO MONO MONO

Page 40

Basic Recording (Continued)

Copying from DVD to VCR

You can copy the contents of a DVD to a VHS tape using the DUBBING button.

ote

If the DVD (or Discs) you are attempting to copy is copy protected, you will not be able to copy the disc. It is not permitted to copy Macrovision encoded DVDs (or Discs).

Insert a VHS Tape

Insert a blank VHS video tape into the VCR deck.

Insert a Disc

Insert the disc you wish to copy in the DVD deck and close the disc tray.

Select DVD mode by pressing DVD on the remote control or pressing DVD/VCR on the front panel.

Find the place on the DVD (or Disc) from which you want to start recording using the PLAY and PAUSE functions.

For best results, pause playback at the point from which you want to record.

Press the DUBBING button.

The Dubbing menu appears.

Use

vv /VV /bb /BB

to select the desired Record

Mode:

• SP (Standard Play)

• LP (Long Play, 2 times SP)

Select Dubbing then press ENTER or DUBBING to start copying.

If you press PAUSE/STEP during Copy mode, both the DVD and VCR decks go into Pause mode. While in Pause mode, you can adjust the DVD playback position using PLAY, BACKWARD, FORWARD, PAUSE/STEP, etc. The VCR deck will remain in Pause mode.To resume copying, press the DUBBING button twice.

Stop the Copy Process

To stop copying at any other time, press STOP (x). You must stop the Copy process manually when the DVD movie ends, or the unit may replay and record over and over again.

Copying from VCR to DVD

You can copy the contents of a VHS tape to a recordable DVD disc using the DUBBING button. This allows you to archive your old VHS tapes to DVD.

ote

If the VHS video tape you are attempting to copy is copy protected, you will not be able to copy the tape. It is not permitted to copy Macrovision encoded tapes.

Insert a recordable DVD disc

Insert a blank recordable DVD disc in the DVD deck and close the disc tray.

Insert a VHS Tape

Insert the VHS video tape you wish to copy into the VCR deck.

ote

When using a DVD±RW disc, you must initialize before copying; see page 25.

Select VCR mode by pressing VCR on the remote control or pressing DVD/VCR on the front panel.

Find the place on the VHS tape from which you want to start recording using the PLAY, BACKWARD, FORWARD and PAUSE functions.

For best results, pause playback at the point from which you want to record.

Press the DUBBING button.

The Dubbing menu appears.

Use

vv /VV /bb /BB

to select the desired Record

Mode:

• EP (Extended Quality)

• LP (Low Quality)

• SP (Standard Quality)

• XP (High Quality)

Select Dubbing then press ENTER or DUBBING to start copying.

If you press PAUSE/STEP during Copy mode, both the DVD and VCR decks go into Pause mode. While in Pause mode, you can adjust the VCR playback position using PLAY, BACKWARD, FORWARD, PAUSE/STEP, etc. The DVD deck will remain in Pause mode. To resume copying, press the DUBBING button twice.

Stop the Copy Process

To stop copying at any other time, press STOP (x). Copying will stop automatically when the VHS tape ends.

Page 41

RECORDING

Timer Recording

This Recorder can be programmed to record up to 16 programs within a period of 1 month.

Press HOME.

The Home menu appears.

Use b / B to select the TV option.

Use v / V to select the Timer Record option then press ENTER.

The Timer Record List will appear.

Use v / V to select the NEW then press ENTER.

The Timer Record menu will appear.

• Media – Choose a media (DVD or VCR).

• PR – Choose a memorized program number, or one of the external inputs from which to record.

• Date – Choose a date up to

1 month

in advance,

or select a daily or weekly program.

• Start Time – Set the recording start time.

• End Time – Set the recording end time.

• Mode – Choose a record mode. DVD: SP, LP, EP, XP or AT (Auto) VCR: SP, LP, AT (Auto) AT (Auto) mode determines how much time is available on the disc or tape and switches record mode, if necessary, to complete recording the program.

Enter the necessary information for your timer recording(s).

• b / B (left/right) – move the cursor left/right

• v / V (up/down) – change the setting at the cur-

rent cursor position

• Press RETURN (O) to exit the Timer Record

menu.

• Press RETURN (O) to display Timer Record

List.

Press ENTER to save the program.

The Timer Record List will appear.

Press RETURN (O) to exit the Timer Record List.

Make sure that you load a recordable disc or tape and press POWER to switch your unit to Standby.

otes

• The Timer indicator lights on the front panel display.

• If the Disc and Tape indicator are blinking, either no disc or tape is loaded, or the loaded disc is not recordable.

• The Recorder will record the audio according to the current TV tuner setting (Stereo, Mono or Bilingual). Use the AUDIO button to set the audio before switching the Recorder to Standby mode.

• You must press POWER to stop the Timer Recording.

• The Recorder will automatically power off when the Timer Recording ends.

If the unit is in DVD mode when the VCR timer recording ends, the unit will not automatically power off.

• There is a short delay when a timer recording finishes to confirm the recorded program. If two timer recordings are set to record sequentially (one right after the other), the very beginning of the later program may not be recorded

• If you wish to watch the DVD playback during the VCR timer recording, press DVD (or DVD/VCR) to change to DVD mode and perform the DVD playback.You cannot playback the VCR during the DVD timer recording.

The recommendable recordable DVD discs

DVD-R DVD+R DVD-RW DVD+RW DVD+R(DL)

Mitsubishi (8x, 16x) Mitsubishi (8x, 16x) Mitsubishi (4x) Mitsubishi (4x) Mitsubishi (2.4x)

That’s (8x, 16x) Ricoh (8x, 16x) Verbatim (4x) SONY (2.4x) Maxell (2.4x)

SONY (16x) SONY (16x) JVC (4x) Ricoh (2.4x, 4x) -

--Victor (4x) Verbatim (2.4x) - -

--Maxell (4x) - - -

Page 42

Timer Recording (Continued)

Checking Timer Recording Details

Programming can be checked whenever the Recorder is turned on. Follow steps 1-3 as shown on page 41.

• Use v / V to select a timer recording.

• Press ENTER to edit the selected program. Timer Record menu appears.

• Press CLEAR to delete the selected program from the Timer Record List.

Canceling a Timer Recording

You can clear a timer setting anytime before the recording actually starts.

• Use v / V to select a program you want to erase on the Timer Recorder List. Press CLEAR and the confirm message will appear. Press ENTER while the [OK] is selected to erase the recording.

Stopping a Timer Recording in Progress

After a timer recording has started, you can still cancel the program.

• Press POWER.

Timer Recording Troubleshooting

Even though the timer is set, the recorder will not record when:

• There is no disc (or tape) loaded.

•A non-recordable disc (or tape) is loaded.

• Disc Protect is set to ON in the Setup menu (see page 27).

•Power is turned on.

• There are already 99 titles (DVD-RW, DVD-R) or 49 titles (DVD+RW, DVD+R) recorded on the disc.

You cannot enter a timer program when:

•A recording is already underway.

• The time you’re trying to set has already passed.

• There are already 16 timer programs set.

If two or more timer programs overlap:

• The earlier program takes priority.

• When the earlier program finishes, the later program starts.

• If two programs are set to start at exactly the same time, the program entered first takes priority.

If the disc is damaged, the recording may not complete successfully. In this case even though the Check field shows “Rec. OK”, it may not be.

Page 43

RECORDING

Recording from an External Input

Recording from External Components

You can record from an external component, such as a camcorder or VCR, connected to any of the recorder’s external inputs.

Make sure that the component you want to record from is connected properly to the Recorder. See page 15.

Press AV/INPUT repeatedly to select the external input to record from.

•Tuner: Built-in tuner

•AV1: Audio/Video Input mounted on back panel

•AV2: Audio/Video Input mounted on front panel

•DV: DV IN mounted on front panel

ote

Check that the Audio In settings DV Record Audio are as you want them. See page 25.

Load a recordable disc or tape.

Select the recording mode as necessary by pressing REC MODE repeatedly.

DVD: XP(High Quality), SP (Standard Quality), LP (Low Quality),EP (Extended Quality)

VCR: SP (Standard Play), LP (Long Play)

Press REC (z) once.

Recording will start. (The REC indicator lights in the display window.)



Recording continues until you press STOP (x) or the disc or tape is full.



To record for a fixed length of time, see Instant Timer Recording on page 39.

Press STOP (x) to stop recording.

ote

If your source is copy-protected using CopyGuard, you will not be able to record it using this recorder. See Copyright on page 8 for more details.

Recording from a Digital Camcorder

You can record from a digital camcorder connected to the DV IN jack on the front panel of this recorder. Using the recorder’s remote, you can control both the camcorder and this recorder. Before recording, make sure that the audio input for the DV IN jack is set up (see page 25).

ips

• The source signal must be DVC-SD format.

• Some camcorders cannot be controlled using this recorder’s remote.

•

If you connect a second DVD Recorder using a DV cable, you cannot control the second DVD Recorder from this one.

•You can’t control this unit remotely from a component connected to the DV IN jack.

•You can’t record date and time information from a DV cassette.

Make sure your digital camcorder is connected to the front panel DV IN jack. See page 16.

Check that the DV audio input is as you require.

You can choose between Audio 1 (original audio) and Audio 2 (overdubbed audio).

•DV Input is set from the DV Record Audio in sub-menu of the Setup menu. See DV Record Audio on page 25 for more information.

Press AV/INPUT repeatedly to select the DV input.

DV appears in the display window.

Find the place on the camcorder tape that you want to the recording to start from.

For best results, pause playback at the point from which you want to record.

• Depending on your camcorder, you can use this recorder’s remote to control the camcorder using the STOP, PLAY and PAUSE functions.

Press REC (z) once to start recording.

• Recording is automatically stopped if the recorder

detects no signal.

•You can pause or stop the recording by pressing PAUSE/STEP (X) or STOP (x). You cannot

control the camcorder from this remote control during recording.

• In Video mode, the final frame of the recording may remain displayed on screen for a while after recording stops.

Page 44

Recording from an External Input (Continued)

What is DV?

You can connect a DV-equipped camcorder to this recorder using a single DV cable for input and output of audio, video, data and control signals.

• This recorder is only compatible with DV-format (DVCSD) camcorders. Digital satellite tuners and Digital VHS video recorders are not compatible.

•You cannot connect more than one DV camcorder at a time to this recorder.

•You cannot control this recorder from external equipment connected via the DV IN jack (including two DVD recorders).

• It may not always be possible to control the connected camcorder via the DV IN jack.

• Digital camcorders can usually record audio as stereo 16-bit/48kHz, or twin stereo tracks of 12-bit/32kHz. This recorder can only record one stereo audio track. Set DV Record Audio to Audio 1 or Audio 2 as required (see page 25).

•Audio input to the DV IN jack should be 32 or 48kHz (not 44.1kHz).

• Picture disturbance on the recording may occur if the source component pauses playback or plays an unrecorded section of tape, or if the power fails in the source component, or the DV cable becomes disconnected.

• Although DV Record Audio is set to Audio 2 and Audio 2 signal is not present, DV Record Audio will be reset to Audio 1 automatically.

DV-Related Messages

You may see the following messages appear on your TV screen when using the DV IN jack.

Not connected to Camcorder.

The camcorder is not connected properly, or the camcorder is switched off.

Too many devices connected.

The DV jack on this recorder supports connection to just one camcorder.

Check the tape.

There is no cassette loaded into the connected equipment.

Uncontrollable device.

This recorder cannot control the camcorder.

Updating the information.

Camcorder is updating the information for DV.

Camera mode.

Camcorder is set to camera mode.

Troubleshooting

If you can’t get a picture and/or audio through the DV IN jack, check the bullet points:

• Make sure the DV cable is properly connected.

•Try switching off the connected equipment then switch back on.

•Try switching the audio input.

otes

• Depending on the connected camcorder, you may not be able to control it using the remote control supplied with this recorder.

• Before you set the mode of your Camcorder to camera mode, turn down the volume of connected Sound device. There can be a howling sound.

Page 45

RECORDING

Title List and Chapter List Menu

Using the Title List-Original menu

The Title List-Original is where you build and edit your Playlist, and where you can delete titles and make other changes to the Original content of the disc. You can also play individual titles directly from the Title List-Original menu. The recorder must be stopped in order to edit using the Title List-Original.

Press DISC MENU / LIST repeatedly to display the Title List-Original menu.

• Use the v / V buttons to display the previous/

next page if there are more than 6 titles.

•To exit the Title List-Original menu, press

RETURN (O).

To view Title List-Original options, select the title you want then press ENTER.

Title List-Original options appears on the left side of the menu.

Use v / V to select an option then press ENTER to confirm.

Play: Starts playback of the selected title.

• Chapter: Moves Chapter List-Original menu of the

title. (refer to right on this page)

• Time: Search time for required start point of the title. (page 54)

Delete: Deletes the title. (page 51)

Protect: Protects accidental recording, editing or

deleting of the title. (page 53)

Edit: Selects Edit options.

• Title Name: Edits the title name. (page 52)

• Delete Part: Deletes a part of the Title. (page 51)

Playlist Add: Adds the title to the Playlist. (page

50)

Dubbing: Copies the title to a VHS tape.

Press RETURN (O) repeatedly to exit Title List-Original menu.

Press DISPLAY to display more detailed title information for selected title.

Using the Chapter List-Original menu

Press DISC MENU / LIST repeatedly to display Title List-Original menu.

Use vVbBto choose the title you want to view Chapter List-Original menu then press ENTER.

Title List-Original options appear on the left side of the menu.

Use v / V to select ‘Search-Chapter’ from Title List-Original options then press ENTER.

Chapter List-Original menu appear on the TV screen.

To view Chapter List-Original options, select the chapter you want then press ENTER.

Chapter List-Original options appear on the left side of the menu.

Use v / V to select an option then press ENTER to confirm.

Play: Starts playback of the selected chapter.

Title: Moves to Title List-Original menu of the

chapter. (refer to left on this page)

Delete: Deletes the chapter. (page 51)

Combine: Merges two chapters into one. (page

52)

Playlist Add: Adds the chapter to the Playlist. (page 50)

Press RETURN (O) repeatedly to exit Chapter List-Original menu.

Page 46

Title List and Chapter List Menu (Continued)

Using the Title List-Playlist Menu

Press DISC MENU / LIST repeatedly to display the Title List-Playlist menu.

• Use the v / V buttons to display the previous/

next page if there are more than 6 titles.

•

To exit the Title List-Playlist, press RETURN (O).

To view Title List-Playlist options, select the title you want then press ENTER.

Title List-Playlist options appear on the left side of the menu.

Use v / V to select an option then press ENTER to confirm.

Play: Starts playback of the selected title.

• Chapter: Moves Chapter List-Playlist menu of the

title. (refer to right on this page)

• Time: Search time for required start point of the title. (page 54)

Title Name: Edits the title name. (page 52)

Delete: Deletes the title from the Title List-Playlist

menu. (page 51)

Delete Part: Deletes a part of the Title. (page 51)

Dubbing: Copies the title to a VHS tape.

Press RETURN (O) repeatedly to exit Title List-Playlist menu.

Using the Chapter List-Playlist Menu

Press DISC MENU / LIST repeatedly to display the Title List-Playlist menu.

Use vVbBto choose the title you want to view Chapter List-Playlist menu then press ENTER.

Title List-Playlist options appear on the left side of the menu.

Use v / V to select ‘Search-Chapter’ from Title List-Playlist options then press ENTER.

Chapter List-Playlist menu appears on the TV screen.

To view Chapter List-Playlist options, select the chapter you want then press ENTER.

Chapter List-Playlist options appear on the left side of the menu.

Use v / V to select an option then press ENTER to confirm.

Play: Starts playback of the selected chapter.

Title: Moves to Title List-Playlist menu of the

chapter. (refer to left on this page)

Delete: Deletes the chapter from the Chapter List-Playlist menu. (page 51)

Move: Moves a chapter of Chapter List-Playlist menu to a position on the menu. (page 53)

Combine: Merges two chapters into one. (page

52)

Press RETURN (O) repeatedly to exit Chapter List-Playlist menu.

VRVR

Page 47

EDITING

Title List and Chapter List Menu (Continued)

Using the Title List menu

From the Title List display you can play, name and delete titles. Once a Video mode disc is finalized, the Title List screen changes its appearance and all you can do is select titles to play.

Press DISC MENU / LIST to display the Title List.

Use v / V to choose a title then press ENTER.

Title List options appear on the left side of the Title List display.

Use v / V to select an option then press ENTER to confirm.

Play: Starts playback of the selected title.

• Chapter: Moves Chapter List menu of the title.

• Time: Search time for required start point of the

title. (page 54)

Title Name: Edits the title name. (page 52)

Delete: Deletes the title from the Title List. Dubbing: Copies the title to a VHS tape.

Press RETURN (O) repeatedly to exit Title List.

Deleting a Title

Before a disc is finalized, you can delete titles recorded on the disc.

Caution

• If you delete a title from a DVD-R disc, the title will disappear from the Title List, but the available recording time will not increase.

• When deleting a title from a DVD-RW disc, the remaining time available for recording will only increase if it is the last title on the disc.

Press DISC MENU / LIST to display Title List

Use vVbBto choose a title you want to delete then press ENTER.

Title List options appears on the left side of the Title List menu.

Use v / V to select ‘Delete’ then press ENTER to confirm.

The confirm message for deleting will appear.

Use b / B to select ‘OK’ then press ENTER. The selected title is deleted. After pressing ENTER, the new, updated menu is displayed.

Repeat steps 2-4 to delete additional titles from the Title List.

Press RETURN (O) repeatedly to remove the Title List display.

If the disc has already been finalized

You should see a screen like the one below.

VideoVideo

Page 48

Title List and Chapter List Menu (Continued)

Using the Title List menu

The Title List is where you can see the all recorded titles, and where you can delete titles and make other changes to the Original content of the disc. You can also play titles directly from the Title List menu. The recorder must be stopped in order to edit using the Title List menu.

Press DISC MENU / LIST to display the Title List menu.

• Use the v / V buttons to display the previous/

next page if there are more than 6 titles.

•To exit the Title List menu, press RETURN (O).

To view Title List options, select the title you want then press ENTER.

Title List options appear on the left side of the menu.

Use v / V to select an option then press ENTER to confirm.

Play: Starts playback of the selected title except

the hidden chapters.

Full Play: Starts playback of the selected title including the hidden chapters.

• Chapter: Moves Chapter List menu of the title.

(refer to right on this page).

• Time: Search time for required start point of the title. (page 54)

Delete: Deletes the title. (page 51)

Protect: Protects accidental recording, editing or

deleting of the title. (page 53)

Edit: Selects Edit options.

• Title Name: Edits the title name. (page 52)

• Divide: Divides one title into two titles.

(page 54)

• Hide (Show): Hides (or Shows) the all chapters

within the title. (page 53)

Dubbing: Copies the title to a VHS tape.

Press RETURN (O) repeatedly to exit Title List menu.

Press DISPLAY to display more detailed title information for selected title.

Caution

If you press REC (zz) when the Title List menu appears, the selected title is erased then overwrite recording starts. (See page 55 for more details.)

Using the Chapter List menu

Press DISC MENU / LIST to display Title List menu.

Use vVbBto choose the title you want to view Chapter List menu then press ENTER.

Title List options appear on the left side of the menu.

Use v / V to select ‘Search-Chapter’ from Title List options then press ENTER.

Chapter List menu appears on the TV screen.

To view Chapter List options, select the chapter you want then press ENTER.

Chapter List options appear on the left side of the menu.

Use v / V to select an option then press ENTER to confirm.

Play: Starts playback of the selected chapter.

Title: Moves to Title List menu of the chapter. (refer

to left on this page)

Combine: Combines two chapters into one. (page

52)

Hide (Show): Hides (or Shows) the selected chapter. (page 53)

Press RETURN (O) repeatedly to exit Chapter List menu.

+R+RW

+RW

+R+RW

Page 49

EDITING

Title and Chapter Editing

Edits you make to the Original content changes the actual content of the disc. For example, if you delete a title or chapter from the Original content (Title or Chapter), that title or chapter is deleted from the disc, freeing up extra recording time. When you edit the Playlist, on the other hand, you are not changing the content of the disc. For example, when you delete a title from the Playlist, you are just telling the recorder not to play that title; nothing is actually deleted from the disc.

Titles, Chapters and Parts

Titles in the disc’s original content contain one or more chapters. When you insert a title into the Playlist, all the chapters within that title also appear. In other words, chapters in the Playlist behave exactly as chapters on a DVD-Video disc do. Parts are sections of Original or Playlist titles. From the Original and Playlist menu you can add or delete parts. Adding a chapter or title to the Playlist creates a new title made up of a section (ie., chapter) of an Original title. Deleting a part removes part of a title from the Original or Playlist menu.

Caution

• When editing using the Delete, Add and Move functions, the start and end frames may not be exactly as set in the start and end point display.

• During Playlist playback, you may notice a momentary pause between edits. This is not a malfunction.

Adding Chapter Markers

You can put a chapter marker during recording or playback. Once the chapter is marked, you can use the Chapter Search feature, as well as delete, combine and move chapters in the Chapter List-Original or Chapter List-Playlist menu.

ote

Chapter markers are inserted at regular intervals automatically. You can change this interval from the Initial Setup menu (see Auto Chapter on page 25).

Play the title.

At the point you want to start a new chapter, press CHP. ADD.

A chapter marker icon appears on the TV screen.

•You can also put chapter markers in during recording.

Changing Title Thumbnails

Each title displayed in the Title List menu is represented by a thumbnail picture taken from the start of that title or chapter. If you prefer, select a different still picture from within a title.

Play the title.

Press THUMBNAIL to make the currently displayed picture the one that appears in the Title List menu.

The still picture that you choose appears in the Title List menu.

You can also change the thumbnail picture of the title on the Chapter List menu of VR mode DVD-RW disc. Select a chapter on the Chapter List menu then press THUMBNAIL. The thumbnail picture of the title that includes the chapter is changed.

+R+RWVR

Page 50

Title and Chapter Editing (Continued)

Making a New Playlist

Use this function to add an Original title or chapter to the Playlist. When you do this, the whole title or chapter is put into the Playlist (you can delete bits you don’t need later — see Deleting an Original or Playlist title/chapter on page 51).

The title appears in the Playlist complete with the chapter markers that appear in the Original. However, if you add more chapter markers to the Original later, these are not automatically copied over into the Playlist title.

You can add up to 999 chapters to one disc .

Press DISC MENU / LIST repeatedly to display Title List-Original menu.

If you want to display the Chapter List-Original menu, refer to “Using the Chapter List-Original menu” on page 45.

Choose a title or chapter on the Original menu to put into the Playlist, then press ENTER.

Original (Title or Chapter) options appear on the left side of the Original menu.

Use v / V to select ‘Playlist Add’ from Original options then press ENTER.

Select ‘New Playlist’ then press ENTER.

The new title appears in the updated Playlist. All chapters of the title are added to the Playlist.

Adding Additional Title/Chapters to the Playlist

You can add an Original title or chapter to add to a Playlist title even if it is already registered.

Press DISC MENU / LIST repeatedly to display Title List-Original menu.

If you want to show the Chapter List-Original menu, refer to “Using the Chapter List-Original menu” on page 45.

Choose an Original title or chapter to put into the Playlist, then press ENTER.

Original menu options appear on the left side of the screen.

Use v / V to select ‘Playlist Add’ from Original menu options then press ENTER.

Choose a Title List-Playlist that is already registered to insert a title or chapter, then press ENTER.

The title or chapter appears in the updated Playlist menu.

Repeat steps 1-4 to add additional title or chapter on the Playlist.

Press RETURN (O) to exit, or DISC MENU / LIST to go back to the Title List-Original menu.

Page 51

EDITING

Title and Chapter Editing (Continued)

Deleting a Title/Chapter

When you erase a title or chapter from the Playlist menu on DVD-RW discs formatted in VR mode, you only remove it from the Playlist; the title/chapter remains in the Original menu.

If you choose to delete a title or chapter from Title ListOriginal or Chapter List-Original menu, the title or chapter is actually deleted from the disc and the remaining time available for recording increases. Titles/chapters deleted from the Original are also removed from the Playlist.

ote

It may not be possible to delete chapters that are less than 3 seconds long.

On the Title List or Chapter List menu, use vV bBto choose a chapter or title you want to

delete then press ENTER.

Options appear on the left side of the screen.

Select ‘Delete’ option on the options on the menu.

Press ENTER to confirm.

The confirm message for deleting will appear.

Use b / B to select ‘OK’ then press ENTER. The selected chapter or title is deleted. After pressing ENTER, the new, updated menu is displayed.

Repeat steps 1 - 4 to continue to delete from the menu.

Press RETURN (O) repeatedly to exit the menu.

otes

• When DVD+RW recording, the deleted title’s name is changed to ‘Deleted Title’.

• If two or more files are deleted, the deleted titles are combined into one.

Deleting a Part

You can delete a part which you do not want in the title.

Press DISC MENU / LIST repeatedly to display Title List-Original or Title List-Playlist menu.

Use vVbBto choose a title you want to delete then press ENTER.

The options appear on the left side of the menu.

Select ‘Edit-Delete Part’ from the options on the menu.

e.g., If you select “Delete Part” on Title List-Original menu.

Press ENTER.

Title Edit (Delete Part) menu appears on the TV screen. ‘Start Point’ icon is highlighted.

Starts playback and use pause step, search and slow-motion to find the starting point.

Press ENTER at the starting point of the section you want to delete.

‘End Point’ icon is highlighted. The part is indicated on the Progress Bar.

Use play, pause step, search and slow-motion to find the ending point.

Press ENTER at the ending point of the section you want to delete.

You can cancel the selected point, use v / V to select ‘Cancel’ icon then press ENTER.

If you finish edit, select ‘Done’ icon then press ENTER.

The confirm message for deleting will appear.

1100

Use b / B to select ‘OK’ then press ENTER. The selected part is deleted from the title.

1111

When finished editing, press RETURN (O).

otes

 It may not be possible to delete parts that are less

than 3 seconds long.

 This function is not available for the titles that are less

than 5 seconds long.

Page 52

Title and Chapter Editing (Continued)

Naming a Title

You can name titles independently.

On the Title List menu, use vVbBto choose the title you want to name then press ENTER.

Options appear on the left side of the menu.

Use v/V to select ‘Title Name’ option then press ENTER.

Keyboard menu appears.

e.g., If you select “Title Name” on Title List-Original menu.

Enter a name for the title. Use vVbBto select a character then press ENTER to confirm your selection. Refer step 3 as shown on page 19 (Station Rename).

Choose OK then press ENTER to fix the name and return to the previous menu screen.

Press RETURN (O) repeatedly to exit the menu.

otes

• Names can be up to 32 characters long.

•For discs formatted on a different DVD Recorder, you will see only a limited character set.

• When recording in DVD-R, DVD+R or DVD+RW, the entered name is displayed on the DVD player only

after finalizing.

Combining Two Chapters Into One

Use this function to combine two adjacent chapters into one.

ote

This function is not available if there is only one chapter within the title or if Highlight is in first chapter.

On the Chapter List menu, select the second chapter of the two chapters you want to combine then press ENTER.

Chapter List options appear on the left side of the menu.

Use v / V to select ‘Combine’.

The combine indicator appears between the two chapters you want to combine.

e.g., If you select “Combine” on Chapter List-Original menu.

Press ENTER to confirm.

After pressing ENTER, the new, updated menu is displayed.

Repeat steps 1 - 3 to continue to combine from the menu.

Press RETURN (OO) repeatedly to exit the menu.

ote This function is not accessible in the following cases;

• If there is only one chapter within the title.

• If two chapters created by erasing a part from an original title.

• If two chapters created from different titles.

• If two chapters created by moving a playlist chapter.

+R+RWVR

+R+RW

Video

Page 53

EDITING

Title and Chapter Editing (Continued)

Moving a Playlist Chapter

Use this function to re-arrange the playing order of Playlist chapters on the Title List-Playlist menu.

Press DISC MENU / LIST repeatedly to display Title List-Playlist menu.

To display the Chapter List-Playlist menu, refer to “Using the Chapter List-Playlist Menu” on page 46.

ote

This function is not available if there is only one chapter.

Select a chapter from the Chapter List-Playlist menu.

Press ENTER.

Chapter List-Playlist options appear on the left side of the menu.

Use v / V to select ‘Move’ from Playlist options then press ENTER.

Use vVbBto choose the place you want to move the chapter to then press ENTER.

After pressing ENTER, the new, updated menu is displayed.

Repeat steps 2 - 5 to continue to move from the menu.

Press RETURN (O) repeatedly to exit the menu.

Protect a Title

Use this function to protect against accidental recording, editing or deleting of the title.

Press DISC MENU / LIST to display Title List menu.

Use vVbBto choose a title you want to protect then press ENTER.

Options appear on the left side of the screen.

Select ‘Protect’ option on the options.

e.g., If you select “Protect” on Title List menu.(DVD+RW/+R)

Press ENTER to confirm.

The lock mark will appears on the title’s thumbnail.

If you select a title that has already been protected on the Title List menu, you can unprotect it by choosing “Unprotect” from the Title List menu options. After doing this, you can edit and delete the title.

Hide a Title/Chapter

Use this function to hide a title/chapter on the Title List or Chapter List menu.

On the Title List or Chapter List menu, use vVbBto choose a title or chapter you

want to hide then press ENTER.

Options appear on the left side of the screen.

Select ‘Hide’ option on the options.

e.g., If you select “Hide” on Title List menu.

Press ENTER to confirm.

The chapter’s or title’s thumbnail will be dim.

If you select a title that has already been dim on the Title List menu, you can show it by choosing “Show” from the Title List menu options. After doing this, you can see the title.

+R+RW

+R+RWVR

Page 54

Title and Chapter Editing (Continued)

Divide One Title Into Two

Use this command to split a title up into two new titles.

On the Title List menu, select a title you want to divide then press ENTER.

The menu options appear on the left side of the screen.

Select ‘Edit - Divide’ from the Title List menu options.

Press ENTER when ‘Divide’ option is highlighted.

Title Edit-Divide menu appears and goes into STOP mode.

Use play, pause step, search and slow-motion to find the point you want to divide the title.

When ‘Divide’ option is highlighted, press ENTER at the point.

You can clear the dividing point, use v / V to select ‘Cancel’ option then press ENTER. The dividing point is clear.

Choose ‘Done’ option then press ENTER to fix the dividing point.

The title is divided into two new titles. It takes up to 4 minutes to divide.

Time Search

You can select a start point for the title.

Use b / B / v / V to choose a title on the Title List menu then press ENTER.

The options appear on the left side of the menu.

Select Time option then press ENTER.

Example : Title List (DVD-VR).

Time Search menu appears on the TV screen.

Use b / B to find the point you want to start. The point increases in 1 minute steps.

If you press and hold b / B then the point increases in 5 minute steps.

Press ENTER to start at selected point.

+RW

The first title’s thumbnail

Current picture

The second title’s thumbnail

Current picture

Start time

End time

Selected time

Selected point

Page 55

EDITING

Additional Information

Overwrite Recording

To overwrite a new video recording to a previously recorded title, follow these steps. This feature is not available on DVD+R, which always record at the end of the Disc.

Select input source you want to record (channel, AV1-2, DV).

Press DISC MENU / LIST to display the Title List menu.

Use vVbBto choose a title you want to overwrite.

Press REC (zz) to start overwrite recording.

Overwrite recording is started from the start point of the title.

Press STOP (x) to stop the overwrite recording.

The new title is created and updated menu is displayed.

otes

 This function is not available with a protected title.  If you overwrite the longer recording than the current

title on the fully recorded disc, the next title is overwritten.

 If next title is protected, the overwriting stops at the

starting point of the title.

Viewing Title List menu displayed on other DVD recorders or players

You can view the Title List menu displayed on the another DVD player that is capable of playing DVD+RW or DVD+R discs.

Insert DVD+R or DVD+RW disc recorded already.

Press TITLE button.

Title List menu will appear as below.

You can remove the Title List menu by pressing STOP (x).

To play back a title, select the title you want then press ENTER or N (PLAY).

Playing Your Recordings on other DVD Players (Finalizing a Disc)

Most regular DVD players can play finalized discs recorded in Video mode, finalized DVD+R or DVD+RW. A small number of players can also play DVD-RW discs recorded in VR mode, finalized or not. Check the manual that came with the other player to check what kind of discs it will play.

Finalizing ‘fixes’ the recordings and editings in place so that the disc can be played on a regular DVD player or computer equipped with a suitable DVD-ROM drive. Finalizing a Video mode disc creates a menu screen for navigating the disc. This is accessed by pressing DISC MENU / LIST or TITLE.

To finalize a disc, refer to “Finalize” on page 26.

otes

 Unfinalized DVD+RW is playable on regular DVD

players.

 The edited contents of DVD+RW disc is compatible

on regular DVD players only after finalizing.

 Any edited contents of the DVD+R disc are not

compatible on regular DVD players. (Hide, chapter combine, added chapter mark, etc.)

+R+RW

+RW

Page 56

Language Code and Area Code List

Area Code

Afghanistan AF Argentina AR Australia AU Austria AT Belgium BE Bhutan BT Bolivia BO Brazil BR Cambodia KH Canada CA Chile CL China CN Colombia CO Congo CG Costa Rica CR Croatia HR Czech Republic CZ Denmark DK Ecuador EC Egypt EG El Salvador SV

Area Code

Ethiopia ET Fiji FJ Finland FI France FR Germany DE Great Britain GB Greece GR Greenland GL Heard and McDonald Islands

HM Hungary HU India IN Indonesia ID Israel IL Italy IT Jamaica JM Japan JP Kenya KE Kuwait KW Libya LY Luxembourg LU

Area Code

Malaysia MY Maldives MV Mexico MX Monaco MC Mongolia MN Morocco MA Nepal NP Netherlands NL Netherlands Antilles AN New Zealand NZ Nigeria NG Norway NO Oman OM Pakistan PK Panama PA Paraguay PY Philippines PH Poland PL Por tugal PT Romania RO Russian Federation RU

Area Code

Saudi Arabia SA Senegal SN Singapore SG Slovak Republic SK Slovenia SI South Africa ZA South Korea KR Spain ES Sri Lanka LK Sweden SE Switzerland CH Thailand TH Tu r ke y T R Uganda UG Ukraine UA United States US Uruguay UY Uzbekistan UZ Vietnam VN Zimbabwe ZW

Area Codes

Choose an area code from this list.

Language Code

Abkhazian 6566 Afar 6565 Afrikaans 6570 Albanian 8381 Ameharic 6577 Arabic 6582 Armenian 7289 Assamese 6583 Aymara 6588 Azerbaijani 6590 Bashkir 6665 Basque 6985 Bengali; Bangla 6678 Bhutani 6890 Bihari 6672 Breton 6682 Bulgarian 6671 Burmese 7789 Byelorussian 6669 Cambodian 7577 Catalan 6765 Chinese 9072 Corsican 6779 Croatian 7282 Czech 6783 Danish 6865 Dutch 7876 English 6978 Esperanto 6979 Estonian 6984 Faroese 7079

Language Code

Fiji 7074 Finnish 7073 French 7082 Frisian 7089 Galician 7176 Georgian 7565 German 6869 Greek 6976 Greenlandic 7576 Guarani 7178 Gujarati 7185 Hausa 7265 Hebrew 7387 Hindi 7273 Hungarian 7285 Icelandic 7383 Indonesian 7378 Interlingua 7365 Irish 7165 Italian 7384 Japanese 7465 Javanese 7487 Kannada 7578 Kashmiri 7583 Kazakh 7575 Kirghiz 7589 Korean 7579 Kurdish 7585 Laothian 7679 Latin 7665 Latvian, Lettish 7686

Language Code

Lingala 7678 Lithuanian 7684 Macedonian 7775 Malagasy 7771 Malay 7783 Malayalam 7776 Maltese 7784 Maori 7773 Marathi 7782 Moldavian 7779 Mongolian 7778 Nauru 7865 Nepali 7869 Norwegian 7879 Oriya 7982 Panjabi 8065 Pashto, Pushto 8083 Persian 7065 Polish 8076 Por tuguese 8084 Quechua 8185 Rhaeto-Romance 8277 Rumanian 8279 Russian 8285 Samoan 8377 Sanskrit 8365 Scots Gaelic 7168 Serbian 8382 Serbo-Croatian 8372 Shona 8378 Sindhi 8368

Language Code

Singhalese 8373 Slovak 8375 Slovenian 8376 Somali 8379 Spanish 6983 Sudanese 8385 Swahili 8387 Swedish 8386 Tagalog 8476 Tajik 8471 Tamil 8465 Tatar 8484 Telugu 8469 Thai 8472 Tibetan 6679 Tigrinya 8473 Tonga 8479 Tu rkish 8482 Tu r kmen 8475 Tw i 8487 Ukrainian 8575 Urdu 8582 Uzbek 8590 Vietnamese 8673 Volapük 8679 Welsh 6789 Wolof 8779 Xhosa 8872 Yiddish 7473 Yo r uba 8979 Zulu 9085

Language Codes

Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu.

Page 57

EDITING

Symptom

No power.

No picture.

No sound.

The playback picture is poor.

The Recorder does not start playback.

The picture from the external input is distorted.

Some channels are skipped over when using v / V.

The picture or sound of broadcasting channel is weak or missing.

Camcorder image is not shown.

Camcorder image via A/V input or DV IN to Recorder is not shown on TV screen.

Cause

 The power cord is disconnected.

 The TV is not set to receive Recorder

signal output.

 The video cable is not connected

securely.

 The connected TV power is turned off.

 The equipment connected with the

audio cable is not set to receive Recorder signal output.

 The audio cables are not connected

securely.

 The power of the equipment connected

with the audio cable is turned off.

 The audio connecting cord is damaged.

 The disc is dirty.

 No disc is inserted.

 An unplayable disc is inserted.

 The disc is placed upside down.

 The disc is not placed within the guide.

 The disc is dirty.

 The Rating level is set.

 The video signal from the external com-

ponent is copy-protected.

 Those channels are not stored in the

recorder.

 Aerial or cables are loose.

 Camcorder is off.

 Recorder INPUT SELECT is

incorrect.

Solution

 Plug the power cord into the wall outlet

securely.

 Select the appropriate video input mode

on the TV so the picture from the Recorder appears on the TV screen.

 Connect the video cable securely.

 Tu rn on the TV.

 Select the correct input mode on the

audio receiver so you can listen to the sound from the Recorder.

 Connect the audio cable securely.

 Tu rn on the equipment connected with

the audio cable.

 Replace it with new one.

 Clean the disc.

 Insert a disc.

 Insert a playable disc. (Check the disc

type, color system, and regional code.)

 Place the disc with the playback side

down.

 Place the disc on the disc tray correctly

inside the guide.

 Clean the disc.

 Cancel the Rating function or change

the rating level.

 You cannot connect via this recorder.

Connect the component directly to your TV.

 Restore channels. See “Program Edit”

on pages 18-19.

 Tighten connections or replace cable.

 Tu rn camcorder on and operate

properly.

 Use AV/INPUT to select input channel

(AV1, AV2, DV, etc.)

Troubleshooting

Check the following guide for the possible cause of a problem before contacting service.

Page 58

Troubleshooting (Continued)

Symptom

Can’t play a disc recorded using this recorder on another player.

Cannot record or did not record successfully.

Timer recording is not possible.

Stereo Audio Record and/or Playback is not present.

The remote control does not work properly.

Cause

 The disc was recorded in Video mode.

 Some players will not play even a

finalized disc recorded in Video mode.

 The disc was recorded in VR mode.

 Discs recorded with copy-once material

cannot be played on other players.

 The remaining blank space on the disc

is insufficient.

 The source you are trying to record is

copy protected.

 When setting the recording channel, the

channel is tuned on the TV’s own tuner.

 When recording to a Video mode disc,

programs that are copy-once protected cannot be recorded.

 Clock in Recorder is not set to correct

time.

 Timer has been programmed

incorrectly.

 Timer record indicator light does not

appear after programming timer.

 TV is not Stereo-compatible.

 Broadcast program is not in stereo for-

mat.

 Recorder A/V Out jacks are not con-

nected to TV A/V In jacks.

 Recorder Audio/Video Out is not select-

ed for viewing at the TV.

 Recorder’s TV audio channel is set to

mono.

 The remote control is not pointed at the

remote sensor of the Recorder.

 The remote control is too far from the

Recorder.

 There is an obstacle in the path of the

remote control and the Recorder.

 The batteries in the remote control are

exhausted.

Solution

 Finalize the disc. (page 26)

 No solution.

 The other player must be RW

compatible in order to play it.

 No solution.

 Use another disc.

 You cannot record the source.

 Select the channel on the recorder’s

built-in TV tuner.

 Use a VR mode formatted disc for

copy-once material.

 Set clock to correct time. See “Clock

Set” on page 20.

 Reprogram Timer. See “Timer

Recording” on page 41-42.

 Reprogram Timer.

 No solution.

 Make A/V connections. Stereo is

available only via A/V output from Recorder.

 Select AUX or A/V source as TV input.

 Set TV audio channel mode to Stereo.

See page 39.

 Point the remote control at the remote

sensor of the Recorder.

 Operate the remote control within 7 m.

 Remove the obstacle.

 Replace the batteries with new ones.

Moisture Condensation

Moisture condensation can occur:

• When the Recorder is moved from a cold place to a warm place.

• Under extremely humid conditions.

In locations where moisture condensation may occur:

•

Keep the Recorder plugged into an AC power outlet with POWER On. This will help prevent condensation.

• When condensation has occurred, wait a few hours for the Recorder to dry before using it.

Page 59

REFERENCE

Specifications

General

Power requirements AC 200-240V, 50/60 Hz

Power consumption 24W

Dimensions (approx.) 430 X 78.5 X 260 mm (w x h x d)

Net weight (approx.) 4.6 kg

Operating temperature 5˚C to 35˚C

Operating humidity 5 % to 90 %

Television system PAL B/G, colour system

Recording format PAL

System

Laser Semiconductor laser, wavelength 650 nm

Video head system Double azimuth 4 heads, helical scanning

Signal system PAL

Recording

Recording format DVD VideoRecording, DVD-VIDEO Recordable discs DVD-ReWritable, DVD-Recordable, DVD+ReWritable, DVD+Recordable,

DVD+Recordable (Double Layer)

Recordable time DVD (4.7GB) : Approx. 1 hour (XP mode), 2 hours (SP mode),

4 hours (LP mode), 6 hours (EP mode), 11 hours (MLP mode) DVD+R DL (8.5GB) : Approx. 2 hours (XP mode), 3 hours 40 minutes (SP mode), 7 hours 10 minutes (LP mode), 9 hours (EP mode), 11 hours (MLP mode)

Video recording format

Sampling frequency 27MHz

Compression format MPEG 2

Audio recording format

Sampling frequency 48kHz

Compression format Dolby Digital

Playback

Frequency response DVD (PCM 48 kHz): 8 Hz to 22 kHz, CD: 8 Hz to 20 kHz

DVD (PCM 96 kHz): 8 Hz to 44 kHz

Signal-to-noise ratio More than 100 dB (AUDIO OUT connector)

Harmonic distortion Less than 0.008% (AUDIO OUT connector)

Dynamic range More than 95 dB (AUDIO OUT connector)

Inputs

ANTENNA IN Aerial input, 75 ohms

VIDEO IN 1.0 Vp-p 75 ohms, sync negative, RCA jack x 2 AUDIO IN -6.0 dBm more than 47 kohms, RCA jack (L, R) x 2

DV IN 4 pin (IEEE 1394 standard)

USB IN 4 pin (USB 1.1 standard)

Outputs

VIDEO OUT 1.0 Vp-p 75 ohms, sync negative, RCA jack x 1

S-VIDEO OUT (Y) 1.0 V (p-p), 75 Ω, negative sync, Mini DIN 4-pin x 1

COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 Ω, negative sync, RCA jack x 1

(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2

Audio output (digital audio) 0.5 V (p-p), 75 Ω, RCA jack x 1

Audio output (optical audio) 3 V (p-p), Optical connector x 1

Audio output (analog audio) 1 KHz, -6 dBm, 600 Ω, RCA jack (L, R) x 1



Design and specifications are subject to change without notice.

Page 60

NEC Australia Pty. Ltd.

ABN 86 001 217 527

Home Electronics Group

NEC Service Centres

New South Wales

Sydney 184 Milperra Rd, Revesby 2212 131-632

Newcastle 120 Parry Street, Newcastle West 2302 131-632

Victoria

Melbourne Unit 1/6 Garden Road, Clayton 3168 131-632

Queensland

Brisbane Unit 4 / 305 Montague Road, West End 4101 131-632

Southport Shop 1, 48 Ferry Road, Southport 4215 131-632

South Australia

Adelaide 84A Richmond Rd, Keswick, 5053 131-632

Western Australia

Perth 45 Sarich Court, Osborne Park 6017 131-632

For Service in outer areas, please contact your NEC retailer for the address of the nearest Authorised NEC Service

Centre

NEC Australia Pty. Ltd.

Display and Home Group

244 Beecroft Road EPPING 2121

Tel: 131 632

Fax: (02) 9877 2353

PH:131-632

Page 61

P/NO : MFL36995875

NEC NDRV-62 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
