NEC N8405-040F User's Guide

1
Note
Before using the product, make sure to read this User’s Guide. Keep this User’s Guide handy for
quick reference when necessary.
NEC SIGMABLADE Series
Blade Enclosure (SIGMABLADE-Hv2)
N8405-040F
First Edition
September 2008
FCC Compliance
This product has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interface when the device is operated in a commercial environment. This device generates uses and can radiate radio frequency energy and if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this device in a residential area is likely to cause harmful interface in which case the use will be required to correct the interference at his own expense.
Warning
To meet FCC rule, use the following racks with front and rear doors in place and closed. Never operate without doors and under doors are opened.
*NEC NX Cabinet Series ; cabinets [N8140-113/114/116/114] and front doors [N8140-115/118] or *APC “NetShelterR VX 42U Enclosure w/Sides Black” [AR2100BLK] or succession of this
CE Statement
Warning: This is a Class A product. In domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures (EN55022).
Trademarks
All other product and company names used in this publication are the trademarks or registered trademarks of their respective trademark owners.
Names used with sample applications are all fictitious. They are unrelated to any existing product names, names of organizations, or individual names.
2
PROPRIETARY NOTICE AND LIABILITY DISCLAIMER
The information disclosed in this document, including all designs and related materials, is the valuable property of NEC Corporation (NEC) and/or its licensors. NEC and/or its licensors, as appropriate, reserve all patent, copyright and other proprietary rights to this document, including all design, manufacturing, reproduction, use and sales rights thereto, except to the extent said rights are expressly granted to others.
The NEC Product(s) discussed in this document are warranted in accordance with the terms of the Warranty Statement accompanying each product. However, actual performance of each such product is dependent upon factors such as system configuration, customer data, and operator control. Since implementation by customers of each product may vary, the suitability of specific product configurations and applications must be determined by the customer and is not warranted by NEC.
To allow for design and specification improvements, the information in this document is subject to change at any time, without notice. Reproduction of this document or portions thereof without prior written approval of NEC is prohibited.
3
Notes for safety handling
Indicates a danger that could lead to a death or serious injury.
Indicates a danger that could lead to a burn, other injuries or damage to physical assets.
Attention
This symbol indicates there is a hazardous risk. Each image in the symbol illustrates a type of hazard.
Example
Risk of an
electric
shock
Prohibited
actions
This symbol indicates what you must not do. Each image symbolizes a particular type of prohibited action.
Example
Do not
disassemble
Mandatory
actions
This symbol indicates what you must do. Each image symbolizes a particular type of action necessary to avoid a hazard.
Example
Unplug
Do not plug the cord in a nonconforming outlet.
Use wall outlets with specified voltage and power type. Failure to observe this caution could result in a fire or current leakage.
Note
Keep this User’s Guide handy for quick reference when necessary.
Make sure to read “Notes for safety handling.” When you relocate the product, make sure to take
this guide with the product.
This section provides information for using the product safely.
SAFETY INDICATIONS
To use this product safely, follow the instructions in this User’s Guide. This guide explains components that pose a danger, types of dangers caused by failing to follow the instructions, and actions taken to prevent them; such components are labeled warning.
This guide and warning labels use “WARNING” and “CAUTION” to indicate a danger depending
on the degree. These terms are defined as follows:
This guide uses the following three types of symbols to give indications and precautions against a danger. They are defined as follows:
Example of indications in this guide
Symbol indicating attention Description of a danger Term indicating degree of danger
4
Descriptions of Symbols and Warning Labels
Indicates a risk of an electric shock.
Indicates a risk of a fire or smoke.
Indicates a risk of catching your fingers
Indicates a risk of injury due to a rotating object.
Indicates a risk of an injury due to heat.
Indicates that improper use may cause loss of eyesight due to laser beam.
Indicates a risk of an explosion.
Indicates a general precaution or warning that is not defined herein.
Do not disassemble, repair, or modify the equipment.
Avoid using water or liquid nearby. If it spills on the device, there is a risk of an electric shock or fire.
Do not touch with wet hands. There is a risk of an electric shock.
Indicates a general prohibition that is not defined herein.
Indicates the instruction to unplug the device and shut off the circuit breaker of the power distribution board.
Attention
Prohibited actions
Mandatory actions
5
General precautions
Do not use the device in an operation where human lives are involved or high reliability is required.
This device is not intended for using in controlling or using with facilities or systems where human lives are involved or high reliability is required, including medical devices or nuclear, aerospace, transportation, and traffic control facilities. NEC assumes no liability for any accidents or damage to physical assets resulting from the use of this equipment in such systems or facilities.
Do not disassemble, repair, or alter the device.
Unless described herein, never attempt to disassemble, repair, or alter the device. There is a risk of an electric shock or fire as well as malfunction.
Do not continue to use the device if any smoke, odor, or noises are detected.
If the device emits smoke, odor, or noise, immediately turn off the POWER switch, unplug the cords, and contact your sales representative. There is a risk of a fire.
Do not insert a wire or metal object.
Do not insert a wire or metal objects into a vent or disk drive slot. There is a risk of an electric shock.
Do not install or remove multiple CPU blades simultaneously.
Install or remove one CPU blade at a time. If you install or remove two or more CPU blade, or install a CPU blade while the cover of another slot is removed, there is a risk of an electric shock.
Do not look into the optical disk drive.
A laser beam used in the optical disk is harmful to the eyes. Do not look into or insert a mirror into the drive while the drive is powered. If a laser beam is caught in your eyes, you may lose your eyesight. Note that the laser beam is invisible.
Precautions for safety
Observe the precautions for safety described in this section. The Blade Enclosure
(SIGMABLADE-Hv2) on which this device is installed has power units. Carefully use them to avoid any electric shock.
.
6
Prevent water or foreign objects from the product.
Do not let liquid (such as water) or any foreign objects (such as pins or paper clips) into the product. There is a risk of fire, electric shock, and breakdown. When such things accidentally enter the server, immediately turn off the power and unplug the cords. Do not disassemble it yourself. Contact your sales representative.
Connect firmly.
Connect interface cables, option boards and modules as CPU blade securely. Install the card securely on the Blade Enclosure. Failure to connect or install securely may result in poor contact that can cause a fire or smoke.
Do not use any unauthorized interface cable.
Use only the interface cable that comes with this product. Use of an unauthorized interface cable may cause a fire when the electric current exceeds the rated flow. Also, observe the following to prevent an electric shock or fire caused by a damaged cord.
Do not touch the fan blades when moving.
Keep your hands or hairs away form the cooling fans on the rear of the Blade Enclosure; otherwise it may get your hand or hair caught in the fan, resulting in injury. Do not insert a stick or the like. Doing so may cause a persona injury as well as the malfunction of the device.
Do not touch the heated objects.
Immediately after the Blade Enclosure is powered off, components in the blade enclosure and CPU blades are very hot. Leave the Blade Enclosure until those components fully cool down before installing/removing any component. In addition, hot air is exhausted from the power supply fan. Keep your face and hands away from the air outlet.
Avoid contact with the Blade Enclosure during thunderstorms.
Disconnect the power plug from the outlet when a thunderstorm is approaching. If it starts thundering before you disconnect the power plug, do not touch any part of the Blade Enclosure including the cables, otherwise it may cause a fire or an electric shock.
Keep animals away.
Keep animals away from the product. Animals waste or hair may get inside the product and can cause a fire or an electric shock.
7
Power Supply and AC Cable
Do not hold the power plug with a wet hand.
Do not connect/disconnect the plug while your hands are wet, or it may cause an electric shock.
Do not connect to the protective earth conductor or to a gas pipe.
Never connect the protective earthing conductor or to a gas pipe, or it may cause a gas explosion.
Plug into a proper power source.
Use a proper wall outlet. Use of an improper power source may cause a fire or a leak. Do not install the Blade Enclosure where you need an extension cord. Use of a cord that does not meet the power specifications of the Blade Enclosure may heat up the cord and cause a fire. The maximum power consumption per power unit is described on the label of the power unit. Note the capacity of a power unit when it is connected to CPU blades.
Do not connect many loads on one electrical outlet.
The electric current exceeding the rated flow overheats the outlet, which may cause a fire.
Place the power supply tap where it is noticeable and easy to reach.
Place the power supply tap at a place where noticeable and easy to access so that power can be shut off in emergency.
Insert the power plug completely.
Heat generation resulting from a halfway inserted power plug (imperfect contact) may cause a fire. Heat will also be generated if condensation is formed on dusty blades of the halfway inserted plug, increasing the possibility of fire.
Use the proper power supply.
Use of an improper AC Cable may cause a fire when the electric current exceeds the rated flow. Also, observe the following to prevent an electric shock or fire caused by a damaged cord.
Do not stretch the cord harness. Do not pinch the AC Cable. Do not bend the AC Cable. Keep chemicals away from the AC Cable. Do not twist the AC Cable. Do not place any object on the AC Cable. Do not bundle AC Cables. Do not alter, modify, or repair the AC Cable. Do not secure the AC Cable with staples or equivalents. Do not use any damaged AC Cables. (Replace a damaged AC Cable with a new one of
the same specifications. Ask your sales representative for detail information of AC Cable
8
Installation and handling of the rack
Install server rack ONLY in a specified or designated environment.
Do not install the rack on which the Blade Enclosure is installed in an unsuitable place. Other devices installed on the Blade Enclosure or the rack may be affected, a fire may occur, or the rack may fall to cause injuries. For details about installation environment and quake-resistant engineering, see the manual attached to the rack or contact your maintenance service agent.
Do not install the Blade Enclosure in a non-conforming rack.
Install the blade enclose in a 19-inch rack conforming to the EIA standard. Do not install the blade enclosure in a nonconforming rack, otherwise devices on the Blade Enclosure may not function properly, and there is a risk of injuries or damage to physical assets. For more information about suitable racks on which the Blade Enclosure can be installed, contact your sales representative.
Set up noise treatment.
The blade enclosure may emit loud noises from fans when it is operating. It is recommended to install the Blade Enclosure in a dedicated room that is distant from people. Arrange acoustic noise treatment such as partitions if you work near the operating Blade Enclosure for a long period of time.
9
Do not carry or install alone.
Carry or install a rack by two or more people. If the rack is carried by one person, the rack may fall and can cause death or damage to physical assets. A tall rack such as a 44 U rack, in particular, is unsuitable if it is not fixed by a stabilizer. Make sure to support the rack by two or more people to carry and/or fix it.
Do not install the rack in such a manner that weights are imposed on a single spot.
Avoid concentration of weight loads of the rack and units installed on a single spot. Use stabilizer or connect two or more racks to balance loads. If not, the rack may fall and can cause injuries.
Do not carry or remove parts alone.
Do not work alone to install or remove a part such as rack door and tray. The part may fall off and get damaged, and there is a risk of injuries.
Use a lifter to install a unit.
Use a lifter to install/remove a unit. If not, a unit may fall and get damaged. There is a risk of injuries especially when you are working with a tall rack such as 44U rack.
Do not pull out a unit when the rack is not stabilized.
When you pull out a unit from the device, ensure that the rack is fixed by using stabilizer or quake-resistant engineering.
Do not pull out two or more units form the rack at the same time.
When two or more units are pulled out from the rack, the rack may fall. Pull out one unit at the same time.
Do not install excessive wiring beyond the rated power supply.
To prevent burns, fires, and damage to the rack, ensure that the rated load of the power branch circuit is not exceeded. For more information on installation and wiring of power-related facilities, contact your electrician or local power company.
10
Carry the Blade Enclosure by four or more people.
The enclosure weighs 68kg (max.) with no modules such as CPU blade or power unit installed. Carrying the enclosure by three or less people may result in injury. Carry the enclosure by four or more people and firmly hold the handles and the top panel (the upper side of the blade slots 1 and 8) of the enclosure. Use a lifter to install/remove the Blade Enclosure on the upper part of the rack. Do not hold the Front Bezel to lift the enclosure. The Front Bezel may be disengaged from the Blade Enclosure, causing personal injury.
Do not install the blade enclosure in a place other than specified.
Do not install the blade enclosure in a place other than specified in this guide. Avoid following locations. There is a risk of fire.
a dusty place a humid place located near a boiler, etc. a place exposed to direct sunlight an unstable place
Do not use or store the Blade Enclosure in a corrosive environment.
Avoid using or storing the Blade Enclosure in an environment with possible exposure to corrosive gas, such as those including but not limited to: sulfur dioxide, hydrogen sulfide, nitrogen dioxide, chlorine, ammonia and/or ozone. Avoid installing the Blade Enclosure in a dusty environment or that may be exposed to corrosive materials such as sodium chloride and/or sulfur. Avoid installing the Blade Enclosure in an environment that may have excessive metal flakes or conductive particles in the air. Such environments may cause corroding or short circuits within the Blade Enclosure, resulting in not only damage to the Blade Enclosure, but may also lead to a fire hazard. If there are any concerns regarding the environment at the planned site of installation or storage, please contact your sales representative.
Do not use the Blade Enclosure with its covers and fan units removed.
Do not use the Blade Enclosure with its covers and fans removed. If you use the Blade Enclosure without them, cooling efficiency inside the Blade Enclosure degrade to cause malfunction, and dust may get in to cause a fire or electric shock.
Be careful not to hurt your fingers
Need precaution for avoid pinching your fingers when installing or removing the blade server into or from a rack cabinet.
Be careful not to drop the Blade Enclosure.
Firmly hold the handles on both sides of the Blade Enclosure to install or remove it on the rack. Since brackets on the rack have no mechanism, such as stoppers and locks, to prevent devices from falling off, and this may cause injury. When you install or remove the Blade Enclosure, hold the handles on both sides of the enclosure firmly to lift, or use a lifter.
Do not impose loads on the Blade Enclosure while it is drawn out of the rack.
Do not impose loads on the top of the Blade Enclosure while it is drawn out from the rack. Frames may get distorted, and you may not be able to install the Blade Enclosure on the rack. There is a risk of the Blade Enclosure falling off and a risk of injuries as well.
Do not cover ventilation openings.
Do not cover ventilation openings and rack openings of the Blade Enclosure. If they are covered, the temperature inside the devices on the Blade Enclosure may rise, and may result in a fire.
Installation, relocation and storage of the blade enclosure
11
Do not leave the Blade Enclosure drawn out of the rack.
Do not operate or do maintenance with the Blade Enclosure drawn out. Since the brackets on the rack has no mechanism, such as stoppers or locks, to prevent the Blade Enclosure from falling off, having the Blade Enclosure fully drawn out of the rack can result in falling off of the Blade Enclosure and this can also result in injuries.
Do not hold any installed module or power unit cover.
When you carry the Blade Enclosure, do not hold any installed module or power unit cover. Because they are movable, you might drop the Blade Enclosure if you hold them.
12
Cautions during operation
Do not touch the Blade Enclosure when it starts to thunder.
Unplug the power plugs when a thunderstorm is approaching. If it starts to thunder before you unplug, do not touch the Blade Enclosure and cables. There is a risk of fire or an electric shock.
Keep animals away.
Keep animals away from the Blade Enclosure. Animals waste or hair may get inside the Blade Enclosure to cause a fire or an electric shock.
Do not pull out the Blade Enclosure from the rack while it is working.
Never pull out or remove the Blade Enclosure from the rack while a device on the Blade Enclosure is working. The device may malfunction, and there is a risk of injuries by the device which becomes loose and fall off from the rack.
Do not place any unfixed equipment on top of the Blade Enclosure.
Never place unfixed equipment(s) on top of the Blade Enclosure to avoid the risk of personal injury or damage to the equipment.
Do not leave the optical disk tray open.
If dust gets inside the optical disk drive, the drive may have problem reading your disks. The left-open optical disk tray may also lead to an injury when hitting it accidentally.
13
Unplug AC Cables before maintenance.
Before maintenance, power off all devices installed on the Blade Enclosure and unplug AC Cables. Even if devices are powered off, there is a risk of electric shock or fire as well as malfunction when maintenance is performed for the devices on the Blade Enclosure with their AC Cables plugged. Disconnect the power plugs from the power outlet occasionally and clean the plugs with a dry cloth. Heat will generate if condensation is formed on a dusty plug, and may lead to a fire.
Maintenance, cleaning and handling of internal devices
14
Disposing of your used NEC product
Inside the European Union
EU-wide legislation as implemented in each Member State requires that used electrical and electronic products carrying the mark (left) must be disposed separately from normal household waste. When disposing used NEC products, you should comply with applicable legislation or such terms which may have been agreed between NEC and your company regarding used products. The mark on the electrical and electronic products only applies to the current European Union Member States.
Unplug AC Cables before maintenance.
If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority and ask for the correct methods of disposal.
Warning labels
The warning label is attached on the Blade Enclosure (described below) so that the users stay alert to possible risks that may arise. Do not remove or damage these labels. If some labels are missing, about to peel off, or illegible, contact your sales representative. For information on symbols in the labels, see Safety indications at the top of this document.
15
TIPS:
About maintenance services
Diagnostic and maintenance services by personnel with expertise on maintenance of this product are available.
For Proper Operation
Observe the following precautions to use this device correctly. Failure to observe the precautions can result in malfunction or mechanical error.
Blade Enclosure
Use a rack that allows installation of the Blade Enclosure.
This product must be installed in a restricted access location.
Remove the dust on the exterior and fans located at the front and rear Blade Enclosure regularly.
Regular cleaning prevents various failures from occurring.
The voltage may drop momentarily due to lightning. It is recommended to use a device such as
uninterruptible power supply to tackle this problem.
Optional power unit and other electronic devices
These products are made of very static-sensitive parts. Eliminate static electricity before
handling the products. Do not touch plug terminals or parts with hands. Do not place the products directly on a desk.
Do no use any optional devices other than those shipped with switch modules/pass-through
cards or specified by NEC. Even if such optional devices can be installed on the Blade Enclosure, it may not work properly or can damage the Blade Enclosure.
It is recommended to use genuine NEC products for optional devices. Some optional devices
from other manufacturers are supported in this device. However, services for tackling malfunctions or damages caused by them are provided at your expense even in the warranty period.
Use of cellular phone or a pager around the Blade Enclosure
Turn off cellular phones and pagers. Radio interference may cause malfunctions of the Blade
Enclosure.
Failure action
When the device fails, shut off the branch circuit breaker of the power distribution board,
unplug the device and contact your sales maintenance personnel.
16
Table of Contents
Notes for safety handling ...................................................................................................... 4
SAFETY INDICATIONS ....................................................................................................................4
Descriptions of Symbols and Warning Labels ..........................................................................5
Precautions for safety ....................................................................................................................6
General precautions ................................................................................................................6
Power Supply and AC Cable ................................................................................................8
Installation and handling of the rack ....................................................................................9
Installation, relocation and storage of the blade enclosure ............................................. 11
Cautions during operation ................................................................................................... 13
Maintenance, cleaning and handling of internal devices ................................................. 14
Disposing of your used NEC product ............................................................................... 15
Warning labels .............................................................................................................................. 15
For Proper Operation ................................................................................................................... 16
Preface .................................................................................................................................... 19
Product Overview .................................................................................................................. 19
Accessories ............................................................................................................................ 19
Components ........................................................................................................................... 20
Front View ...................................................................................................................................... 20
CPU blade slots .................................................................................................................. 22
Rear View ....................................................................................................................................... 22
Power unit slots ................................................................................................................... 24
Fan Unit Slots ...................................................................................................................... 26
Notes on the Use of KVM and Optical Disk Drive Select Feature ............................... 28
KVM Select Feature ............................................................................................................ 28
Optical Disk Drive Select Feature...................................................................................... 29
Installation .............................................................................................................................. 30
Checking components ................................................................................................................. 30
Installing the Blade Enclosure to the rack ............................................................................. 30
Checking the parts for mounting........................................................................................ 31
Necessary equipment .......................................................................................................... 31
Installation procedure ........................................................................................................... 33
Mounting the Blade Enclosure unit .................................................................................... 34
Removal procedure .............................................................................................................. 35
Fan Unit .................................................................................................................................. 36
Installing fan units ............................................................................................................... 39
Removing fan units ............................................................................................................. 40
Power Units ............................................................................................................................ 41
Installing power units ........................................................................................................... 42
Removing power units ......................................................................................................... 43
Switch Modules ..................................................................................................................... 44
17
Supported switch modules and pass-through cards......................................................... 45
Internal connection between CPU blade and switch module slots ................................ 46
Installing switch modules .................................................................................................... 50
Removing switch modules .................................................................................................. 52
CPU Blades ............................................................................................................................ 53
Caution on installing half-weight, double-wide CPU blades ............................................ 55
Caution on installing full-height, single-width CPU blades .............................................. 56
Supported CPU blades ....................................................................................................... 57
Installing CPU blades .......................................................................................................... 58
Removing CPU blades ........................................................................................................ 60
Separators ...................................................................................................................................... 61
Removing separators ........................................................................................................... 62
Installing separators ............................................................................................................. 63
Assembling and disassembling a full-height CPU blade slot cover ................................ 64
Assembling a full-height CPU blade slot cover ................................................................ 65
Disassembling a full-height CPU blade slot cover ........................................................... 67
EM Card .................................................................................................................................. 68
Installing Enclosure Manager Cards (EM Cards) ............................................................. 69
Removing Enclosure Manager Cards (EM Cards) ........................................................... 69
Connecting Cables ................................................................................................................ 70
Front Panel .................................................................................................................................... 70
SUV (Serial, USB and Video) cable for the CPU blade ................................................ 70
USB connector ..................................................................................................................... 70
Rear panel ............................................................................................................................ 71
AC inlet ................................................................................................................................. 71
Emergency power off (EPO) ................................................................................................ 72
Power outlet/tap and PDU (Power Distribution Unit) ............................................................ 73
How to plug and unplug the power unit and the attached AC Cable .......................... 73
Emergency power off switch .............................................................................................. 74
Setting the disk .................................................................................................................... 75
When the disk eject failed ......................................................................................................... 76
Handling of the optical disk ................................................................................................ 77
Disposal .................................................................................................................................. 78
Transfer to third party .......................................................................................................... 78
Specification ........................................................................................................................... 78
18
Preface
Product Overview
Accessories
IMPORTANT:
Keep the accessories in a safe place. You may need them when an optional device is added or when the blade enclosure experiences a failure.
Thank you for purchasing the N8405-040F Blade Enclosure (SIGMABLADE-Hv2). This enclosure can house CPU blades for the NEC EXPRESS5800/BladeServer series, power units, fan boxes, and switch modules for the SIGMABLADE series, and can integrate the capabilities of modules to enable each CPU blade to function as a server. Be sure to carefully read this guide before using the Enclosure. Additional information is available in the Users Guide, Operating Manual, and Startup Guide applied with your CPU Blade(s).
This 10U (approximately 445mm) enclosure can house up to 16 CPU blades and up to eight switch modules for the SIGMABLADE series, enabling up to 16 servers to be aggregated in a single Enclosure. Installing an additional N8405-044F Power Unit Provides power redundancy. This redundancy allows the system to continue operating without interruption even if one of the power units fails.
This product is shipped with various accessories. See the attached components list to check everything is contained and not damaged. If any accessory is missing or damaged, contact your sales representative.
Notes:
1. No part of this material may be reproduced in any form without the prior written permission of NEC Corporation.
2. The contents of this Users Guide is subject to change without prior notice.
3. The contents of this Users Guide shall not be copied or altered without the prior written permission of NEC Corporation.
4. All efforts have been made to ensure the accuracy of all information in this Users Guide. If you notice any part of this document unclear, incorrect, or omitted in this Users Guide, contact the sales representative where you purchased this product.
5. NEC assumes no liability arising from the use of this product, nor any liability for incidental or consequential damages arising from the use of this Users Guide regardless of item 4.
19
Components
1-10
1-11
1-12
1-1
1-2
1-4
1-5
1-3
1-6
1-7
1-8
1-9
1-14
1-13
1-15
1-16
2
3
4
4-1
2-1
2-2
2-3
4-9
4-2
4-3
4-4
4-5
4-6
4-7
4-8
The optical disk drive (2) and the SIGMABLADEBLADE monitor details
The following are the names of device components.
Front View
20
1 CPU blade slot
Install the CPU blades into these slots. The last digit indicates the installation order.
2 Optical disk drive
Hold this handle when installing or removing the Blade Enclosure.
2-1 Access lamp 2-2 Eject button 2-3 Emergency hall
3 USB connector
This connects a USB device. The USB device is connected to the CPU blade in the slot specified by SIGMABLADE monitor.
4 SIGMABLADE monitor
4-1 LCD
This displays the system status and CPU blade status installed in the Blade Enclosure.
4-2 Power lamp
This indicates power status of Blade Enclosure and SIGMABLADE monitor. The lamp goes on green when the Blade Enclosure is powered. It goes off when the Blade Enclosure is powered off.
4-3 Status lamp
This indicates the statuses of Blade Enclosure and SIGMABLADE monitor. The lamp goes on green when the Blade Enclosure is powered. It goes off when the Blade Enclosure is powered off.
4-4 ID lamp
This identifies the CPU blade in the system. The light goes on blue when you press the ID button (4-5). When the remote console sends the turn-on command and the command is received, the lamp blinks blue. If you press the ID button while this lamp lights or it is flashing, the lamp goes off.
4-5 ID button
Press this button to turn on or off the ID lamp.
4-6 Reset button
Press this button to restart optical disk drive and USB devices connected to the USB.
4-7 Menu button
Press this button to restart optical disk drive and USB devices connected tot the USB.
4-8 Enter button
Use this button to select a menu or determine the selection.
4-9 [][][][] button
Use these buttons to move cursor, or change value on the cursor position.
21
1-10
1-1
1-2
1-3
1-4
1-5
1-7
1-8
1-9
7-2
3-3
3-1
7-1
3-2
3-4
3-6
3-8
4-1
4-2
4-3
4-4
4-5
4-6
3-5
3-7
1-6
2
6
When FAN unit (slot 6, 7, 9, 10) and power unit (slot 1 to 6) are mounted
Details of the external I/F (EM tray)
5-1
5-2
5-3
5-4
5-5
5-6
CPU blade slots
The Enclosure has CPU blade slots in the front that can accommodate up to 16 optional CPU blades. These slots should be populated in following order; 1, 9, 2, 10, 3, 11, 4, 12, 5, 13, 6, 14, 7, 15, 8 and 16.
* This does not apply when an FC Switch with 12 ports is connected. For details, see CPU Blades
on page 53.
Rear View
22
1 Fan unit slot
Slots to install the fan units. The last digit indicates a slot number.
2 Fan lamp
The lamp flashes amber three times when DC power is supplied to the Blade Enclosure. The lamp is off when the enclosure operates normally. If a fan fault is detected, the lamp goes on amber.
3 Switch module slot
The slots to install the switch module. The last digit indicates installation order.
4 Power unit slots
The slots to install the switch module. The last digit indicates the installation order.
5-1 Keyboard connector
Connector for PS2 keyboard
5-2 Mouse connector
Connector for PS2 mouse
5-3 Serial port connector
(Not supported)
5-4 UPPER
See the manual provided with the EM card.
5-5 LOWER
See the manual provided with the EM card.
5-6 Monitor connector
Connector for display unit
6 Power LED
The LED is off while no AC power is supplied to the power unit, and it goes on green when the AC power is supplied. When the EM card turns on DC power of the power unit, the lamp goes on green. The LED starts flashing amber when the temperature in the power unit reaches the warning level. If the power is shutdown by the protective circuit in the power unit due to detection of over-current, the LED goes on amber.
7 EM card slot
Slot to install an EM card. The last digit shows installation order.
23
Power unit slots
IMPORTANT:
Mount the power units of the same model number. If the ones with different model numbers are
used, the system does not work properly.
If power units are not installed as instructed in the table below, they will be detected as an
insufficient power error by the Enclosure Manager Card (EM Card). Even if this error is detected, powering on a powered-off CPU blade is unavailable when you turn it on.
The Enclosure can accommodate up to six power units in the rear. Slots 2, 3, 5 and 6 have blank covers, while slots 1 and 4 do not.
The number of CPU blades installed determines the number of power units required. Refer to the table below.
The number of CPU blades installed and the number of power units required
The number of power units required depends on the total power consumption of the CPU blades. Follow the steps below to determine the number of power units required.
1. Use the following formula to determine the total DC power consumption
Total DC power consumption (W) = Total CPU blade power consumption + 1260 (W), where 1260 is the power consumption of the blade enclosure.*
*The power consumption of the blade enclosure includes that of switch modules and fan units.
The total CPU blade power consumption should be determined by summing up the power con sumptions of the different types of CPU blades installed in the Blade Enclosure. For information on the power consumptions of different types of CPU blades, see the Users Guide for the configuration guide included with your CPU blade.
24
Loading...
+ 56 hidden pages
