46-inch High Bright LCD Public Display
NEC MultiSync X462HB
Let your image
shine...
3
2
An ideal solution for digital
signage in high ambient light
environments.
Product Highlights
NEC MultiSync X462HB
Outstanding Performance
Delivering Genuine Benefits
The 46” NEC X462HB shines a new light of performance on outdoor digital signage, drive-thru menu
boards and video walls that are placed in heavily-lit environments. With its high-bright (1200 cd/
m2), professional-grade panel and remarkable contrast ratio (3500:1), the 46” NEC X462HB displays
images at amazing brightness levels no matter the lighting condition. Ideal for environments heavy
with ambient light, this model boasts a quarter-lambda polarizing film that allows for outdoor
viewing with polarized sunglasses in both landscape and portrait display orientations. The result is
an image with greater visibility that outperforms displays with standard brightness and polarization,
which can appear dim or washed out when placed in areas with high ambient light.
• Ultra high bright panel designed for high ambient light
situations
• Full connectivity, including option slot
• A panel specifically designed for heavy duty applications
• Advanced thermal panel design
• Quarter-lambda polarizing film for optimal viewing
Typical environment with high ambient light
•
Individual and Group ID functions allow users to control
settings for a dened individual display or group of displays
within a video wall
•
Display Wall Calibrator Kit (optional) provides a quick,
accurate and easy-to-use means of matching all displays in
color and brightness to create uniformity across the video
wall
CableComp+™ uses a digitised signal delay circuit to
automatically compensate for each red, green and blue
cable’s length and video signal delay, ensuring sharp image
reproduction despite long cables and low output level.
Advanced screen saver functions include an array of
features designed to reduce the risk of image persistence and
extend display life.
Suitable Applications
The X462HB’s full high-definition screen performance
is enhanced by 30+ advanced features of the Digital
Signage Technology Suite, including advanced thermal protection and improved operating temperature,
which helps maintain the display’s performance in
even the most demanding environments.
Quarter-lambda polarizing film allows viewing of content
regardless of display orientation or the use of polarized
sunglasses.
Thermal protection starts with an extra thermal layer
on the display panel to diffuse heat followed by fan-based
technology specially designed to work in both landscape and
portrait modes and be controlled locally or remotely. Internal
temperature sensors control self-protective circuits, while
special self-diagnostics communicate the status of the thermal
characteristics.
Sealed panel design provides protection in less than
optimal environments, while protecting against particles like
dust, grease, or steam from getting behind the glass and
damaging the unit.
Enhanced video wall capabilities allow you to expand
your messaging options. Technologies include:
•
TileMatrix™ allows you to create video walls (up to 100
displays in a 10x10 matrix)
•
TileComp™ works in tandem with TileMatrix to compensate
for the bezel width and create a more seamless video wall
•
Copy function allows the user to apply the settings from
one display to all others in the RS-232 daisy chain, reducing
setup time and saving money.
Centralised, Convenient, Cost Efficient Maintenance
and Control
With free LAN control software – the industry’s most extensive
control, diagnostic and communication provide the highest
level of remote display management. These include:
•
RS-232 enables multi-display control and daisy chain,
allowing for individual and group-addressable control, and
simple, effective setup and monitoring of the display
•
Ethernet connectivity adds the same RS-232 control plus
automatic email notication for diagnostic purposes
•
NaViSet™ software offers an intuitive graphical interface,
allowing for easy adjustment of display settings via mouse
and keyboard. NaViSet Administrator provides all the
advanced control to remotely located IT professionals.
•
DDC/CI standard allows for PC control of the display based
on the VESA command set
Easy Connection
Enhanced input options include quick input change,
customised detection and naming. DisplayPort and HDMI,
along with a LAN interface for control of the screen are unique
in this combination in a public display and secure future
proong.
Real-time clock/round-the-clock scheduling
Allows for advanced scheduling of monitor powering up/down.
• Retail (shopping centres
and retail stores)
• Transportation (train
stations, bus terminals)
• Fast food restaurants
(menu boards)
• Pubs and clubs
• Semi outdoor solutions
(within suitable casing/
protection)
Plus many, many more...
Eco-Friendly Features
•
An ambient light sensor, which ensures consistent
brightness no matter the lighting conditions, with efcient
product design and high quality components ensuring
power consumption is signicantly minimized.
•
A carbon footprint metre, which helps track and calculate
the conservation of green gas emissions.
•
Improved operating temperature allows for improved
installation exibility
•
Industrial-strength, premium-grade panel with additional
thermal protection, internal temperature sensors with self
diagnostics and fan-based technology
Extended Functionality
A built-in expansion slot future-proofs your display investment,
allowing for seamless integration of NEC and third-party
components, including an HD-SDI card, single-board computer
and DVI daisy chain capability, avoiding additional cables and
mounting brackets.
NEC MultiSync X462HB
About NEC Australia Pty Ltd. NEC Australia is a leading supplier and integrator of ICT solutions to carriers, government and busi-
nesses. With over 800 staff and 200 partners, we research, develop and deploy advanced IT/Network communication solutions
and services using best-of-breed technologies in multi-vendor environments. Our business encompasses Hosted Application and
Network Services, Systems Integration, IP Communications Servers, PBX, Broadband Access Systems, Data Centre and Cloud
Technology Services along with Digital Signage and Data Technology products.
CS_Arts Vic | v. 20.11.09
NEC Australia Pty Ltd reserves the right to change product specifications, functions, or features, at any time, without notice. Please refer to your local NEC representatives for further details. Although all efforts have
been made to ensure that the contents are correct, NEC shall not be liable for any direct, indirect, consequential or incidental damages resulting from the use of the equipment, manual or any related materials. The
information contained herein is the property of NEC Australia Pty Ltd and shall not be reproduced without prior written approval from NEC Australia Pty Ltd.
Copyright © 2010 NEC Australia Pty Ltd. All rights reserved. NEC, NEC logo, and UNIVERGE are trademarks or registered trademarks of NEC Corporation that may be registered in Japan and other jurisdictions. All
other trademarks are the property of their respective owners. All rights reserved. Printed in Australia. Note: This disclaimer also applies to all related documents previously published.
For more information, visit www.nec.com.au, email displays@nec.com.au or call 131 632
Detailed Specifications
Panel Technology S-PVA (P-DID)
Active Screen Area (W x H) [mm] 1920 x 1080
Screen Size [inch/cm] 46 inch
Pixel Pitch [mm] 0.53
Viewing Angle [°] 178o horizontal / 178o vertical
Screen Aspect Ratio 16:9
Contrast Ratio (typ.) 3500:1
Brightness (typ.) [cd/m²] 1200
Response Time (typ.) [ms] 8 (grey-to-grey)
Colours [Mio.] 16.77
Horizontal Frequency [kHz] 31.5 - 91.1 (analog/digital)
Vertical Frequency [Hz] 50 - 85
Optimum Resolution 1920 x 1080 at 60 Hz
Native Resolution 1920 x 1080 at 60 Hz
Supported Resolutions 720 x 400; 640 x 480; 800 x 600; 832 x 624; 1024 x 768; 1280 x 1024; 1600 x 1200; 1280 x 768;
1360 x 768; 1920 x 1080
Video Input Digital: 1 x DisplayPort; 1 x DVI-D (with HDCP); 1 xHDMI, Analog: VGA 15-pin D-sub; 5 BNC (RGBHV,
DVD/HD or Video); RCA Composite; BNC Composite; RCA (Y, Cb/Pb, CR/Pr) Component; S-Video
Video Output Analog: 5 BNC (RGBHV); BNC Composite
Audio Input RCA Audio (2); Stereo Mini-Jack; HDMI Audio; DisplayPort Audio
Audio Output 1 x Cinch (RCA), External Speaker Jack (2)
Option Slot Built-in PC; CAT 5 receiver; DVI daisy chain board; HD-SDI board; Media Player
External Control Input RS-232C; Ethernet (RJ45); IR Remote; DDC/CI
External Control Output RS-232C; IR Remote
Power Consumption on Mode [W] 320 (Eco Mode Standy: <0.5W)
Power Management VESA DPMS
Power Supply 100-240 V; 0.7 A/1.2 A
Ambient Humidity (operating) [%] 20 to 80
Ambient Temperature (operating) [°C] +5 to +35
VESA Mounting [mm] 300 x 300 (4-hole)
Dimensions (W x H x D) [mm] Without stand: 1,055.4 x 608.6 x 140
Supported TV Standards (no tuner) NTSC; PAL; SECAM
Weight (kg) 31.0
Remote Control D-sub 15 and DVI-D (DDC/CI); Ethernet; RS-232C (9-pin D-sub) Input and Output; Remote Control IR
Shipping Content Signal Cable VGA - VGA CD-ROM (User Guides/Manuals); Display; Power Cable; Remote Control
(IR); Batteries; Clamp; Cable cover, Screws; User Manual
Warranty 3 years warranty incl. backlight
